AYP YPQRT65A Parts List

YPQRT65A (1999) Page 1 of 14
DECALS

YPQRT65A (1999) Page 2 of 14
DECALS

Ref # Part Number Qty Description

1 156687 DECAL PANEL CNTRL
2 169730 DECAL, LOGO BELT GUARD
3 156715 DECAL SHIELD TINE
4 136942 DECAL.INSTRUCTION
5 110614X DECAL TI
6 102180X DECAL CRT
7 162384 DECAL.CAUTION

9 120076X SUB= 120075X
11 166855 DECAL
13 166856 DECAL, CHOKE
14 167483 DECAL

169756 MANUAL, OWNER'S (ENGLISH)
169757 MANUAL, OWNER'S (FRENCH)

YPQRT65A (1999) Page 3 of 14
HANDLE ASSEMBLY

YPQRT65A (1999) Page 4 of 14
HANDLE ASSEMBLY

Ref # Part Number Qty Description

1 164743 CONTROL.THROTTLE

2 9266R SUB= 624A78

4 159228 BAR ASM CONTROL

6 126951X "PANEL,CONT TI"

8 71191008 SCREW.PNHD.10-24
10 8206H GRIP T
11 4497H RETAINER M
12 81328 SHOULDER BOLT ST
13 109335X SHIFT HANDLE CRT
14 109313X GROMMET CRT
15 109337X SHIFT ROD CRT
16 72110608 BOLT D
17 109229X LOCK CRT
18 73930600 LOCKNUT
19 19131611 WASHER CRT
20 109228X LEVER LOCK CRT
21 150256X428 SUB= 150256X431
23 86777 SUB= 750097
24 9484R CONDIUT CLIP T
26 159231 CABLE.CLUTCH
27 73220400 SUB= 50675
28 10040400 LOCKWASHER
29 73731000 NUT
30 104164X TIE CABLE CRT
31 150696 BOLT PIVOT
33 72140404 BOLT
37 102604X GRIP BAR CRT
40 73510400 NUT
41 102744X SUB= 102744X431

YPQRT65A (1999) Page 5 of 14
MAINFRAME, LEFT SIDE
