AYP Y125H42A Parts List

Y125H42A (1995) Page 1 of 24
CHASSIS AND ENCLOSURES

Y125H42A (1995) Page 2 of 24
CHASSIS AND ENCLOSURES

Ref # Part Number Qty Description

1 140341 SUB= 145501
2 140356 SUB= 145009
3 17490612 SCREW
4 19131216 WASHER
4 11050600 LOCKWASHER
6 145206 SUB= 145206X431
8 126471X "CLIP,INSULATOR"

9 140637X011 DASH SILKSCRN 1
10 72140608 SUB= 72110608
11 135464 DASH PANEL LH
13 124031X012 SUB= 155934X010
14 17490608 SCREW LT
15 74180512 SCREW
16 73510500 NUT
17 105682X505 HOOD ASM.
18 126938X SUB= 532126938
24 74780616 BOLT
25 19131312 WASHER
26 73800600 NUT
28 128313 SUB= 532128313
29 108360X LENS RH LT
30 140001X505 FENDER PNT LT
31 136619 BRKT FENDER
33 105465X505 SUB= 145244X505
34 105464X505 SUB= 145243X505
35 72110606 BOLT
36 108067X PAL NUT LT
38 139886 BRACKET ASM LH
39 139887 BRACKET ASM RH
42 108361X LENS LH LT
45 132257 SUB= 918132257
46 127316X RETAINER
58 106213X "DUCT, INTAKE T"
72 109745X505 STRAP ASM GRILL
86 106927X505 SIDE PANEL ASM RH
87 106929X505 SIDE PANEL ASM LH
90 19091216 WASHER PM

103 127317X "SCREW,SPECIAL"
104 129664 WASHER
105 127318X "GROMMET,PLASTIC"
106 105797X "HINGE,HOOD,LH T"
107 105792X "HINGE,HOOD,RH T"

5479J PLUG BUTTON T

Y125H42A (1995) Page 3 of 24
DECALS

Y125H42A (1995) Page 4 of 24
DECALS

Ref # Part Number Qty Description

1 138956 DECAL.DASH.INSTR.

2 123689X NLA

3 124151X NLA

4 124152X NLA

5 138448 DECAL.PANEL.SIDE

6 133795 DECAL CAUTION

7 101892X DECAL T

8 105807X NLA

9 142337 DECAL SADL HYDRO
10 133671 FOOTREST PAD
11 137259 "DECAL, WARNING"
12 139141 DECAL.GRILL.YARDP
14 121549X DECAL
15 136832 DECAL
16 135013 NLA
17 142341 DECAL DRAWBAR LH
19 140837 DECAL BRAK PARK

138311 DECAL HANDLE LIFT
145278 MANUAL.OP.GENERIC
146284 MANUAL.P.Y125H42A
LBD48 SNOW BLADE
LSB42 SNOW THROWER
C42 GRASS CATCHER
LC05 WHEEL WTS.
CH11 TIRE CHAINS

Y125H42A (1995) Page 5 of 24
DRIVE

Y125H42A (1995) Page 6 of 24
DRIVE

Ref # Part Number Qty Description

1 140607 TRANSAXLE HYD 0319-0500

2 142431 SPRING RET BRAKE

3 144698 PULLEY.4.20.HYDRO

8 141003 ROD SHIFT FEND LT
10 76020416 PIN COTTER 1/8
15 74780544 BOLT HEX
16 73800500 NUT
18 74780616 BOLT
19 73800600 NUT
21 106933X KNOB T (1/2-HOLE)
22 145627 ROD.BRAKE.HYDRO.
24 73350600 NUT
25 106888X SPRING ROD LT
26 19131316 WASHER
27 76020412 COTTER PIN
28 145204 ROD.BRAKE.PARK.LT
29 71673 PLUNGER CAP T
30 130807 TRANSAXLE MTG BKT
31 127275X "KEEPER,BELT LH T"
32 74760512 BOLT
34 122424X SUB= 149001
35 120183X NYLON BEARING
36 19211616 WASHER LT
37 1572H SUB= 2882J
38 123674X PULLEY.IDLER.FLAT
39 74760644 BOLT
40 4470J SPACER T
41 109070X BELT KEEPER LT
42 19131312 WASHER
44 105706X "LY, BEARING"
45 110812X WASHER LT
46 12000039 KLIP RING
47 127783 SUB= 139245
48 123789X ARM IDLER
49 123205X RETAIN BELT
50 74760624 SUB= 74930624
51 73680600 SUB= 73690600
52 73680500 SUB= 73690500
53 105710X "LINK, CLUTCH T"
55 105709X "SPRING, RETURN LT"
56 74760620 SUB= 74780620
57 141416 BELT-V.HYDR.84.61
59 140312 KEEPER BELT CNTSP
62 8883R PEDAL COVER T
63 140186 PULLEY.ENGINE
64 71170764 BOLT
65 10040700 LOCKWASHER
66 129921 KEEPER.BELT.ENG.L
69 142432 SCREW HEXWSH H-L
70 134683 KEEPER BELT ENG
71 141417 STRAP.TORQ.LH.HYD
72 19132012 WASHER
73 141418 STRAP.TORQ.RH.HYD
74 121199X SPACER SPLIT
75 121749X WASHER
76 12000001 E-RING LT
77 123583X SQUARE KEY
78 121748X WASHER

Y125H42A (1995) Page 7 of 24
DRIVE

Ref # Part Number Qty Description

81 141420 SHAFT.CROSS.HYD
82 123782X "SPRING,TORSION"
83 19171216 WASHER
84 141423 ROD.TIE.BALL.HYD.
86 71208 BUSHING
87 19212016 WASHER D
88 12000008 KLIP RING
89 139988 SUB= 153764
91 74780536 NLA
92 74780524 HEX BOLT
93 142564 "LINE FUEL HYD 4"""
94 140462 "FAN 7"" HYDRO"
95 144643 SUB= 918144643
96 4497H RETAINER M
97 144201 KEEPER.BELT.RH.HY
98 73510600 NUT

100 19111216 WASHER M
103 50831 NUT NYLON 1/2-20
104 141421 ARM.CONTROL.PUMP
105 71070516 SCREW CAP 5/16-18
106 74780520 BOLT
108 17541026 SCREW.HXHD.10-20
109 145098 ADAPTOR.FAN.HYDRO

Y125H42A (1995) Page 8 of 24
ELECTRICAL
