Ayp WEX1236B PARTS LIST

WEX1236B (1999 & Before) Page 1 of 32
BRAKE/REAR MOWER LIFT ASSEMBLY

WEX1236B (1999 & Before) Page 2 of 32
BRAKE/REAR MOWER LIFT ASSEMBLY

Ref # Part Number Qty Description

1 71673 PLUNGER CAP T
2 123436X "ROD,PARK BRAKE"
3 123437X "BRKT,PARK BRAKE"
4 8156H FOOT PEDAL COVER
5 122504X "BRKT,CLU PEDAL LH"
6 76020312 SUB= 3145
7 19131016 WASHER
8 17490508 SCREW LT

9 76020412 COTTER PIN
10 19131316 WASHER
11 123543X "ROD,FRT BRAKE"
12 139933 PEDAL ASM CL/BK36
13 123394X "ROD,CLUTCH"
14 121978X "BRKT,LIFT SHAFT"
15 133332 PVT BRAKE ARM ASM
16 19251816 WASHER T
17 12000034 KLIP RING
18 151332 SPRING ROD BRAKE
19 73350600 NUT
20 73800600 NUT
21 131460 SUB= 532131460
22 144585 TRUNNION.LIFT.
24 19132012 WASHER
25 4921H SPRING.RETAINER
26 73930600 LOCKNUT
27 127369 "LINK, MOWER REAR"
28 140776 LIFT ASM MOW REAR
29 72110506 SUB= 72270506
30 73510500 NUT
31 3146R RETAINER.SPRING
34 73680600 SUB= 73690600

WEX1236B (1999 & Before) Page 3 of 32
DASH

WEX1236B (1999 & Before) Page 4 of 32
DASH

Ref # Part Number Qty Description

1 141523 CAP BLK FUEL LR

2 138393 TANK.ASM.DASH.LR

3 123487X HOSE CLAMP

4 8544R SUB= 295J

5 8548R FUEL LINE T

6 73640400 NUT HXKEP 1/4X20

7 2751R CLIP T

8 19091216 WASHER PM

9 74760428 BOLT
10 19091413 WASHER
11 121249X SPACER SPLIT
12 3720R SPRING M
13 126450X "KNOB,HGT RETAINER"
14 126115X KNOB
15 122023X ADJUSTER QUAD
16 124346X NUT
17 72110404 BOLT
18 130745 SUPT ASSY DASH
19 134744 CROSS BRACE
20 17060408 SCREW.1/4-20X1/2
21 134014 PLUG DOME

WEX1236B (1999 & Before) Page 5 of 32
DECALS

WEX1236B (1999 & Before) Page 6 of 32
DECALS

Ref # Part Number Qty Description

1 159739 DECAL CLUTCH/BRAK

3 162968 DECAL.HOOD.RH

4 162969 DECAL.HOOD.LH

5 136830 DECAL.V.BELT

6 162971 DECAL.PNL.SIDE

7 145498 DECAL.READ.O.MANU

8 145494 DECAL.DANGER.CUTF

9 162395 DECAL.FENDER.LOGO
10 162391 DECAL, DECK GRASSEATER
11 159736 "DECAL CHASSIS,HOT"
12 145005 DECAL.BATRY.3-3908
13 162970 DECAL INSRT STEER
14 126187X SUB= 532126187
15 165297 SUB= 272440
16 162598 DECAL.DRAWBAR.LDL
18 145437 DECAL.EURO.ST.CE.

138311 DECAL HANDLE LIFT
157065 MANUAL.OPERATOR'S
157216 MANUAL.OPERATOR'S
166284 MANUAL
C36 REAR BAGGER
MK36 MULCHER KIT

WEX1236B (1999 & Before) Page 7 of 32
ELECTRICAL

WEX1236B (1999 & Before) Page 8 of 32
ELECTRICAL

Ref # Part Number Qty Description

REFER REFER TO IMAGE
1 73640400 NUT HXKEP 1/4X20
2 108423X CABLE ASM.
3 144924 SUB= 123899X
4 69180 LOCKNUT
5 108236X BRACKET LT
6 109553X SWITCH INTERLOCKT
7 146374 KEEPER.ACTUAT.LR.
8 17021008 SCREW
9 140401 KEY MLD GEN DELTA

10 141226 COVER KEY SWITCH
11 140400 SUB= 145774
12 163088 SWITCH.IGNITION
15 121305X SWITCH SEAT
17 108824X FUSE HYT
18 128353 CABLE ASSY
19 166143 HARNESS.IGNITION
20 73350400 NUT
21 10090400 SUB= 10040400
22 71110408 BOLT HXHD FIN
24 131563 SUB= 154336
25 145673 SUB= 146154
26 74760412 BOLT LT
30 73510400 NUT
36 11150400 LOCKWASHER
39 141735 BRACKET SWT CLUTC
55 17490508 SCREW LT
70 166658 HARNESS.ENGINE

WEX1236B (1999 & Before) Page 9 of 32
ENGINE/THROTTLE

WEX1236B (1999 & Before) Page 10 of 32
ENGINE/THROTTLE

Ref # Part Number Qty Description

1 17060408 SCREW.1/4-20X1/2
2 133025 SUB= 532133025
3 SUPPLIER CHECK WITH SUPPLIER
4 71070512 SCREW
5 10040500 LOCKWASHER
6 165291 SUB= 272293
7 11050600 LOCKWASHER
8 121094X BOLT T
9 19101216 WASHER

10 10040400 LOCKWASHER
11 SUPPLIER CHECK WITH SUPPLIER
12 137437 MUFFLER
13 101326L DEFLECTOR.222573
14 17030808 SUB= 17030814
15 137180 SUB= 532137180
16 127951 "STOP,DASH THROTT"
17 17490624 SCREW LT
39 128861 NUT
