AYP RY820G Parts List
RY820G (1997) Page 1 of 14
DECALS
RY820G (1997) Page 2 of 14
DECALS
Ref # Part Number Qty Description
1 128221 NLA
2 127210X NLA
3 132316 DECAL, LOGO
4 110678X NLA
5 110614X DECAL TI
6 104323X NLA
7 110612X DECAL TI
8 271948 DECAL, BRIGGS & STRATTON
9 120076X SUB= 120075X
10 272630 DECAL, 5 HP
157013 MANUAL, OWNER'S (ENGLISH)
158014 MANUAL.O.RY820G.F
RY820G (1997) Page 3 of 14
HANDLE
RY820G (1997) Page 4 of 14
HANDLE
Ref # Part Number Qty Description
1 8389J GRIP TI
2 121248X BUSHING
3 71191008 SCREW.PNHD.10-24
4 126949X505 HANDLE BRACKET
5 72110514 BOLT CARRIAGE CRT
6 108281X ROD SHIFT CRT
7 72110608 BOLT D
8 4497H RETAINER M
9 109229X LOCK CRT
10 73930600 LOCKNUT
11 19131611 WASHER CRT
12 109228X LEVER LOCK CRT
13 150217 HANDLE
14 145820 CABLE.CLUTCH.Z-BE
15 145821 BRACKET.CLUTCH.CA
17 102604X GRIP BAR CRT
18 150696 BOLT PIVOT
21 145829 BAR.ASM.CNTRL.VPL
22 150744 "GRIP,HANDLE"
24 73731000 NUT
25 127012X "CONT,THROTTLE"
26 146480 GROMMET.HANDLE.V27 10040500 LOCKWASHER
28 73800500 NUT
RY820G (1997) Page 5 of 14
MAINFRAME, LEFT
