AYP RL12536TB Parts List
RL12536TB (1999 & Before) Page 1 of 35
BRAKE/REAR MOWER LIFT
RL12536TB (1999 & Before) Page 2 of 35
BRAKE/REAR MOWER LIFT
Ref # Part Number Qty Description
1 71673 PLUNGER CAP T
2 123436X "ROD,PARK BRAKE"
3 123437X "BRKT,PARK BRAKE"
4 8156H FOOT PEDAL COVER
5 122504X "BRKT,CLU PEDAL LH"
6 76020312 SUB= 3145
7 19131016 WASHER
8 17490508 SCREW LT
9 76020412 COTTER PIN
10 19131316 WASHER
11 123543X "ROD,FRT BRAKE"
12 139933 PEDAL ASM CL/BK36
13 123394X "ROD,CLUTCH"
14 121978X "BRKT,LIFT SHAFT"
15 133332 PVT BRAKE ARM ASM
16 19251816 WASHER T
17 12000034 KLIP RING
18 151332 SPRING ROD BRAKE
19 73350600 NUT
20 73800600 NUT
21 131460 SUB= 532131460
22 144585 TRUNNION.LIFT.
24 19132012 WASHER
25 4921H SPRING.RETAINER
26 73930600 LOCKNUT
27 127369 "LINK, MOWER REAR"
28 140776 LIFT ASM MOW REAR
29 72110506 SUB= 72270506
30 73510500 NUT
31 3146R RETAINER.SPRING
34 73680600 SUB= 73690600
RL12536TB (1999 & Before) Page 3 of 35
DASH
RL12536TB (1999 & Before) Page 4 of 35
DASH
Ref # Part Number Qty Description
1 141523 CAP BLK FUEL LR
2 138393 TANK.ASM.DASH.LR
3 123487X HOSE CLAMP
4 8544R SUB= 295J
5 8548R FUEL LINE T
6 73640400 NUT HXKEP 1/4X20
7 2751R CLIP T
8 19091216 WASHER PM
9 74760428 BOLT
10 19091413 WASHER
11 121249X SPACER SPLIT
12 3720R SPRING M
13 126450X "KNOB,HGT RETAINER"
14 126115X KNOB
15 122023X ADJUSTER QUAD
16 124346X NUT
17 72110404 BOLT
18 130745 SUPT ASSY DASH
19 134744 CROSS BRACE
20 17060408 SCREW.1/4-20X1/2
21 134014 PLUG DOME
RL12536TB (1999 & Before) Page 5 of 35
DECALS
RL12536TB (1999 & Before) Page 6 of 35
DECALS
Ref # Part Number Qty Description
1 145545 DECAL.OP.INST.SYM
2 141744 DECAL HD RLY LH
3 141743 DECAL HD RLY RH
4 132627 GRILL DECAL
5 136830 DECAL.V.BELT
6 132628 FENDER DECAL
7 145498 DECAL.READ.O.MANU
8 145494 DECAL.DANGER.CUTF
10 145437 DECAL.EURO.ST.CE.
12 146451 DECAL.BTRY.DANGER
14 125690X DECAL
15 152786 DECAL.INS.HD.12.5
138311 DECAL HANDLE LIFT
154061 MANUAL OPERATOR'S (ENG)
154062 MANUAL.OP.GEN.36.
154621 MANUL.P.RL12536TB
C36 REAR BAGGER
MK36 MULCHER KIT
RL12536TB (1999 & Before) Page 7 of 35
ELECTRICAL
RL12536TB (1999 & Before) Page 8 of 35
ELECTRICAL
Ref # Part Number Qty Description
1 73640400 NUT HXKEP 1/4X20
2 4560J SUB= 2957J
3 146138 SUB= 123888X
4 69180 LOCKNUT
5 108236X BRACKET LT
6 109553X SWITCH INTERLOCKT
7 141736 SUB= 146613
8 17021008 SCREW
9 140401 KEY MLD GEN DELTA
10 141226 COVER KEY SWITCH
11 140400 SUB= 145774
12 144921 SUB= 163088
15 121305X SWITCH SEAT
17 108824X FUSE HYT
18 128353 CABLE ASSY
19 146063 HARNESS.IGN.FEND.
20 73350400 NUT
21 10090400 SUB= 10040400
22 71110408 BOLT HXHD FIN
24 131563 SUB= 154336
25 145673 SUB= 146154
26 74760412 BOLT LT
27 19091016 WASHER
28 10040400 LOCKWASHER
30 73220400 SUB= 50675
36 11150400 LOCKWASHER
39 141735 BRACKET SWT CLUTC
55 17490508 SCREW LT
70 140413 HARNESS ENG DUAL
RL12536TB (1999 & Before) Page 9 of 35
ENGINE/THROTTLE
RL12536TB (1999 & Before) Page 10 of 35
ENGINE/THROTTLE
Ref # Part Number Qty Description
1 17060408 SCREW.1/4-20X1/2
2 133025 SUB= 532133025
3 OHV125 ENGINE B&S 12.5 HP
4 123528X SCREW HEX HD CAP
5 10040500 LOCKWASHER
6 272293 GASKET ENG 1 313 LD TIN PLATED
7 11050600 LOCKWASHER
8 81328 SHOULDER BOLT ST
9 19101216 WASHER
10 10040400 LOCKWASHER
11 74760412 BOLT LT
12 138032 SUB= 156448
13 101326L DEFLECTOR.222573
14 17030808 SUB= 17030814
15 137180 SUB= 532137180
16 136382 STOP.THROTTLE
17 17490624 SCREW LT
39 128861 NUT
RL12536TB (1999 & Before) Page 11 of 35
FENDER/CHASSIS
