AYP LO21H48H RP Parts List
TRACTOR - MODEL NO. YTH2148 (LO21H48H), PRODUCT NO. 954 57 20-35
SCHEMATIC
AMMETER
(OPTIONAL)
RED
IGNITION
SWITCH
BLACK
BROWN
RED
BATTERY
A
RED
FUSE
WHITE
S
B
G
BLACK
M
A1
A2L
CG
B
RED
F
H
E
A
BLACK
D
ORANGE
PTO (DISENGAGED)
BLUE
FUEL
LINE
BLACK
WHITE
CLUTCH / BRAKE
BLACK
(PEDAL UP)
(OPTIONAL)
RED
BLACK
HOUR
METER
RED
WHITE
IGNITION
UNIT
SOLENOID
RED
ELECTRIC CLUTCH
SEAT SWITCH
(NOT OCCUPIED)
GROUNDING
CONNECTOR
BLACK
SPARK PLUGS
(2 PLUGS
ON TWIN CYL. ENGINES)
M
STARTER
BLACK
GAP
IGNITION SWITCH
CIRCUITPOSITION
OFF
M+G+A1
B+A1ON + LIGHTS
B+A1ON
B+S+A1START
“MAKE”
NONE
L+A2
NONE
NONE
RED
FUEL SHUT-OFF
SOLENOID
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED
CLIPS WERE REMOVED FOR
SERVICING OF UNIT, THEY
SHOULD BE REPLACED TO
PROPERLY SECURE YOUR
WIRING.
02757
CHARGING SYSTEM OUTPUT
16 AMP DC @ 3600 RPM
RED
REMOVABLE
CONNECTIONS
REGULATOR
PTO SWITCH
OFF
BROWN
HEADLIGHTS
CIRCUITPOSITION
C+G,B+H
C+F,B+E,A+DON
NON-REMOVABLE
CONNECTIONS
28 VOLTS AC @ 3600 RPM
(REGULATOR DISCONNECTED)
ALTERNATOR
BLACK
FC
G
E
H
A
D
PTO SWITCH
CONNECTOR
B
29
REPAIR PARTS
TRACTOR - MODEL NO. YTH2148 (LO21H48H), PRODUCT NO. 954 57 20-35
ELECTRICAL
22
21
42
24
41
33
30
27
50
27
43
25
27
27
40
26
16
2
27
1
D
.
C
.
A
M
P
E
R
E
S
89
29
46
45
91
8
_27
Battery
28
30
REPAIR PARTS
TRACTOR - MODEL NO. YTH2148 (LO21H48H), PRODUCT NO. 954 57 20-35
ELECTRICAL
KEY PART
NO. NO. DESCRIPTION
1 532 14 49-27 Battery
2 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4
8 532 18 64-91 Box Battery
16 532 17 61-38 Switch Interlock Push-In
21 532 18 37-59 Harness Asm Light W/4152j
22 532 00 41-52 Bulb Light #1156
24 532 12 47-80 Cable Battery 6 Ga. 11" red
25 532 14 61-48 Cable Battery 6 Ga. 22" red w/16 wire
26 532 17 51-58 Fuse 20 AMP
27 873 51 04-00 Nut Keps Hex 1/4-20 unc
28 532 14 54-91 Cable Ground black
29 532 12 13-05 Switch Plunger Nc Gray
30 532 18 96-87 Switch Ign
33 532 14 04-01 Key Ign Molded Generic
40 532 18 80-24 Harness Ign.
41 871 11 04-08 Bolt Blk Fin Hex 1/4 - 20 x 1/2
42 532 13 15-63 Cover Terminal Red
43 532 17 88-61 Solenoid
45 532 12 28-22 Ammeter
46 532 16 96-35 Hourmeter Snap-In
50 532 17 46-51 Switch PTO
89 532 16 96-39 Bracket Snap-In Hourmeter
90 532 18 04-49 Cover Terminal
91 532 19 02-70 Strap Battery
NOTE: All component dimensions given in U.S. inches.
1 inch = 25.4 mm.
31
REPAIR PARTS
TRACTOR - MODEL NO. YTH2148 (LO21H48H), PRODUCT NO. 954 57 20-35
CHASSIS AND ENCLOSURES
259
212
28
17
213
258
212
217
90
31
209
10
277
276
10
30
214
39
278
58
159
280
208
11
166
9
280
209
55
53
209
166
209
158
64
209
142
26
60
143
144
26
1
13
144
60
26
142
2
74
209
38
14
209
37
38
26
145
37
208
14
chassis_elite husqy_4
32
REPAIR PARTS
TRACTOR - MODEL NO. YTH2148 (LO21H48H), PRODUCT NO. 954 57 20-35
CHASSIS AND ENCLOSURES
KEY PART
NO. NO. DESCRIPTION
1 532 17 46-19 Chassis Stamping
2 532 17 65-54 Drawbar
9 532 19 00-36 Dash P/L M
10 872 14 06-08 Bolt Carriage 3/8-16 x 1
11 532 17 49-96 Panel Dash Lh
13 532 18 17-19 Panel Dash Rh
14 817 49 06-08 Screw Thdrol 3/8-16 x 1/2
17 532 18 99-77 Hood
26 873 80 06-00 Nut Lock Hex W/Ins 3/8-16 unc
28 532 18 82-69 Grille/Lens Asm.
30 532 19 18-15 Fender Footrest STLT Pnt
31 532 13 99-76 Bracket Support Fender
37 817 49 05-08 Screw Thdrol 5/16-18 x 1/2 TYT
38 532 17 57-10 Bracket Asm Pivot Mower Rear
39 532 17 47-14 Bracket Pivot
53 532 18 83-72 Bracket Dash RH
55 532 18 83-73 Bracket Dash LH
58 532 18 93-52 Air Duct Engine
60 872 14 06-06 Bolt Rdhd Sqnk 3/8-16 unc x 3/4
64 532 17 49-97 Dash Lower STLT
74 873 68 06-00 Nut Crownlock 3/8-16 unc
90 532 12 43-46 Nut Self-thd Wsh-Hd 1/4
142 532 17 57-02 Plate Reinforcement STLT
143 532 18 66-89 Bracket Swaybar Chassis
144 532 17 55-82 Bracket Pnt Footrest STLT
145 532 15 65-24 Rod Pivot Chassis/Hood
166 532 17 18-75 Screw HWHD Hi-Lo #13-16 x 3/4
158 532 16 20-37 Bracket Parking Brake
159 532 18 54-34 Cupholder
208 817 67 06-08 Screw Thdrol 3/8-16 x 1/2 TYT Bl
209 817 00 06-12 Screw 3/8-16 x 3/4
212 532 18 82-67 Insert Lens Refl ect
213 532 18 99-79 Skirt Side LH
214 532 18 99-78 Skirt Side RH
217 532 18 54-36 Console Fuel Window
258 532 18 99-81 Lens RH
259 532 18 99-82 Lens LH
276 532 18 92-74 Bumper Hood RH
277 532 18 92-75 Bumper Hood LH
278 532 19 16-11 Screw 10 x 3/4 Single Lead Hex
280 817 00 06-16 Screw 3/18-16 x 1
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
33
REPAIR PARTS
TRACTOR - MODEL NO. YTH2148 (LO21H48H), PRODUCT NO. 954 57 20-35
DRIVE
85
16
69
197
247
32
89
30
52
81
95
245
85
169
10
57
251
21
246
198
112
8
263
161
14
163
82
263
159
52
165
158
162
83
156
62
32
59
168
61
166
36
35
41
38
56
28
39
120
34
37
64
63
65
17
66
23
254
202
9
49
27
47
120
50
36
35
150
48
151
51
53
77
15
96
30
75
77
19
24
29
78
22
76
252
25
252
1
74
252
27
55
drive-hydro.stlt_71
34
