Ayp CT14538C PARTS LIST

CT14538C (1996) Page 1 of 29
CHASSIS

CT14538C (1996) Page 2 of 29
CHASSIS

Ref # Part Number Qty Description

1 151169 CHASSIS WLDMT 11G
2 140356 SUB= 145009
3 17490612 SCREW
4 19131216 WASHER
5 146077 SUB= 155272
6 145208X016 SUB= 155924X015
8 126471X "CLIP,INSULATOR"

9 146757X011 DASH.SLKSC.LT.1PC
10 72140608 SUB= 72110608
11 146956 PANEL.DASH.LH.
13 146961X012 SUB= 155934X010
14 17490608 SCREW LT
15 74180512 SCREW
16 73510500 NUT
17 133956X505 HOOD/GRILL ASM
18 126938X SUB= 532126938
24 74780616 BOLT
25 19131312 WASHER
26 73800600 NUT
29 133954 LENS SERVICE KIT
30 109872X505 FENDER
31 136619 BRKT FENDER
33 105476X505 FOOTREST LH
34 105475X505 FOOTREST RH
35 72110606 BOLT
36 108067X PAL NUT LT
38 139886 BRACKET ASM LH
39 139887 BRACKET ASM RH
45 132257 SUB= 918132257
46 127316X RETAINER
60 72140606 BOLT
74 73680600 SUB= 73690600

140 150556 SUB= 158739

5479J PLUG BUTTON T

CT14538C (1996) Page 3 of 29
DANA TRANSAXLE

CT14538C (1996) Page 4 of 29
DANA TRANSAXLE

Ref # Part Number Qty Description

1 142671 HOUSING UPPER TRN

2 2274J SUB= 74760412

3 134400 SUB= 68003

4 105904X "SPRING, DETENT LT"

5 105905X "SCREW, SET LT"

6 138235 KIT SHIFTER ASM

7 134399 SHIFTER BOOT

8 134791 SCREW TAP W/SEAL

9 138241 SQUARE RING
10 142672 SUB= 2225J
11 134793 ASM KIT SHIM 4689
12 142673 BEARING FLAN-DANA
13 120415X WASHER T
14 142674 KEY WOODRUFF-DANA
15 138234 AS KIT INPUT SHFT
16 110078X PINION 14T T
17 105909X "RING,RETAINING LT"
18 105910X "CHAIN,24 PTCH LT"
19 105911X BEARING.FLNG.5510
20 142675 GEAR SPUR 14 TTH
21 138246 COLLAR CLUTCH
22 138236 ASM KIT CLTCH KEY
23 73810500 NUT.LOCK.5/16-24
24 142676 SHAFT INTERM DANA
25 2244J WOODRUFF KEY
26 105916X "RING,RETAINING LT"
27 120470X SPROCKET 18T T
28 110070X SPACER YT
29 142677 GEAR SPUR 37 TTH
30 142681 GEAR SPUR 35 TTH
31 120405X SUB= 124644X
32 108980X GEAR 25T LT
33 120406X GEAR SPUR 22 TT
34 134796 SPUR GEAR 19T
35 105925X "WASHER, PLAIN LT"
36 2232J WASHER 025
37 108978X SPACER
38 110079X ASSM GEAR COMB
39 124639X SHAFT IDLER
40 120472X SPACER T
41 105928X SPROCKET 9T LT
42 110084X SUB= 167148
43 134394 ASM KIT SHIM
44 120473X SHAFT T
45 142678 GEAR SPUR 12 TTH
46 142679 GEAR SPUR 15 TTH
47 120407X SUB= 124641X
48 106589X "GEAR, SPUR 25T LT"
49 120408X GEAR 28T T
50 105937X "GEAR, SPUR 31T LT"
51 2226J WASHER 060
52 134401 NEOPRENE WASHER
53 2264J WASHER 031
54 120474X SUB= 154658
55 110081X GEAR 15T T
56 105941X "RING,RETAINING LT"
57 110071X SUB= 120478X
58 120952X SHAFT T

CT14538C (1996) Page 5 of 29
DANA TRANSAXLE

Ref # Part Number Qty Description

59 110082X GEAR 1ST T
60 120475X SUB= 154659
61 142680 HOUSING LOWER TNS
62 120961X PUCK T
63 7294J BRAKE DISC. T
64 108989X SPACER LT
65 120953X SUB= 918120953X
66 120954X PIN T
67 134799 TAP SCREW
68 138244 SUB= 108992X
69 108996X WASHER LT
70 120956X NLA
71 106596X "SCREW, TAPPING LT"
72 120951X PUCK T
73 120416X SUB= 126976X

CT14538C (1996) Page 6 of 29
DECALS

CT14538C (1996) Page 7 of 29
DECALS

Ref # Part Number Qty Description

1 138955 DECAL.DASH.INST.

2 132627 GRILL DECAL

4 129823 NLA

5 146644 DECAL.INS.HD.RALL

6 133796 DECAL

7 4900J DECAL T

8 132628 FENDER DECAL

9 127035 NLA
10 135013 NLA
12 141745 DECAL HOOD RH RLY
13 127075 "DECAL,STR WHL"
14 141746 DECAL HOOD LH RLY
15 146451 DECAL.BTRY.DANGER
16 140837 DECAL BRAK PARK
17 136832 DECAL

138311 DECAL HANDLE LIFT
145761 "MANUAL.OP.GEN.38"""
154838 MANUAL PARTS
LSB42 SNOW THROWER
LBD48 SNOW BLADE
LC05 WHEEL WTS.
CH11 TIRE CHAINS
MK380 KIT.MULCHER
C38 GRASS CATCHER

CT14538C (1996) Page 8 of 29
DRIVE

CT14538C (1996) Page 9 of 29
DRIVE

Ref # Part Number Qty Description

1 142603 SUB= 160664

2 146682 SPRING.BRAKE.RETU

3 123666X PULLEY TRANS

4 12000028 SUB= 2267J

5 121520X STRAP TORQUE

6 17490512 SCREW

7 130802 SUB= 162240

8 131679 SHIFT ROD
10 76020416 PIN COTTER 1/8
11 105701X WASH-SHFT PLT LT
12 19151216 WASHER
13 74550412 BOLT.1/4-28.W/PAT
14 10040400 LOCKWASHER
15 74490544 BOLT.HX.FLG.5/16
19 73800600 NUT
21 106933X KNOB T (1/2-HOLE)
22 130804 BRAKE ROD
24 73350600 NUT
25 106888X SPRING ROD LT
26 19131316 WASHER
27 76020412 COTTER PIN
28 145204 ROD.BRAKE.PARK.LT
29 71673 PLUNGER CAP T
30 130807 TRANSAXLE MTG BKT
31 127275X "KEEPER,BELT LH T"
32 74760512 BOLT
34 151128 SHAFT FOOT PEDAL
35 120183X NYLON BEARING
36 19211616 WASHER LT
37 1572H SUB= 2882J
38 123674X PULLEY.IDLER.FLAT
39 74760644 BOLT
40 4470J SPACER T
41 153399 KEEPER BELT
42 19131312 WASHER
44 105706X "LY, BEARING"
45 110812X WASHER LT
46 12000039 KLIP RING
47 127783 SUB= 139245
48 123789X ARM IDLER
49 123205X RETAIN BELT
50 74760624 SUB= 74930624
51 73680600 SUB= 73690600
52 73680500 SUB= 73690500
53 105710X "LINK, CLUTCH T"
55 105709X "SPRING, RETURN LT"
56 74760620 SUB= 74780620
57 130801 SUB= 138255
58 127274X "KEEPER,BELT RH T"
59 140312 KEEPER BELT CNTSP
61 17490612 SCREW
62 8883R PEDAL COVER T
63 140186 PULLEY.ENGINE
64 71170764 BOLT
65 10040700 LOCKWASHER
66 153400 SUB= 129921
70 134683 KEEPER BELT ENG
72 19132012 WASHER
