AYP CT1138B Parts List

CT1138B (1992) Page 1 of 25
38" MOWER

CT1138B (1992) Page 2 of 25
38" MOWER

Ref # Part Number Qty Description

1 129365 SUB= 145775
2 73680500 SUB= 73690500
3 72140506 BOLT
4 7631J RUNNER-LH M
5 110485X BEARING
6 128774 HSG ASM MANDREL
7 129895 BEARING.BALL
8 133172 SUB= 137646

9 127842 SUB= 138497
10 129962 WASHER BLADE
11 10030600 SUB= 10040600
12 850857 BLADE BOLT
13 128961 SUB= 140329
14 106736X DEFLECTOR-SHLD T
15 106735X ROD-HINGE T
16 105896X SUB= 137607
17 110452X NUT PUSH M
18 106734X SUB= 123713X
19 19111016 WASHER
20 105304X CAP-SLEEVE LT
21 128772 RUNNER RH
22 19111216 WASHER M
23 78158 SUB= 17580520
24 4939M SUB= 85902
25 74600636 BOLT
26 19131612 WASHER GT
27 127218 LINK.FRONT
28 73350800 NUT
29 130171 TRUNION
30 73800800 NUT.LK.W/WSH.1/2.
31 127224 LINK LIFT RH
32 128763 SPRING PIN
33 133710 SUSP ARM REAR
34 127223 LIFT LINK LH
35 73360700 NUT
36 110447X SUB= 132793
37 73710700 NUT LOCK YTH
38 133840 IDLER ARM ASSY
39 129963 WASHER
40 129206 SUB= 153532
41 73050900 SUB= 139729
42 131494 FLAT IDLER PULLEY
43 122052X SPACER RETAINER
44 19131612 WASHER GT
45 73680600 SUB= 73690600
46 131290 BELT-V.88.12.MW
47 133502 RETAINER SPACER
48 133503 IDLER ARM STIFF
49 120183X NYLON BEARING
50 122507X SUB= 145117
51 105767X PIN-GROOVE LT
52 109413X GRIP
53 124526X SUB= 125925X
54 122364X SUB= 125925X
55 122512X SUB= 532122512
56 122514X SUB= 136973
57 12000002 SUB= 2225J
58 19211416 WASHER

CT1138B (1992) Page 3 of 25
38" MOWER

Ref # Part Number Qty Description

59 131288 BRAKE ROD RH
60 131289 BRAKE ROD LH
61 76020312 SUB= 3145
62 133551 PIVOT ROD
63 133504 CLUTCH ROD SECOND
64 72110614 BOLT
65 133550 SUB= 142427
66 73350600 NUT
67 133205 TRUNION
68 4497H RETAINER M
69 127498 BUSHING
70 128759 SUB= 918128759
71 133573 CLUTCH ARM PRI AS
72 106932X KNOB T(3/8 HOLE)
73 121748X WASHER
74 12000029 RING
75 128903 SHOULDER BOLT
76 127845 SPRING KEEPER
77 127847 CLUTCH ARM SECOND
78 131870 RETURN SPRING
79 130840 BRAKE ASM
80 17490512 SCREW

130794 MANDREL ASM
131455 SUB= 142820

CT1138B (1992) Page 4 of 25
CHASSIS

CT1138B (1992) Page 5 of 25
CHASSIS

Ref # Part Number Qty Description

1 131052 CHASSIS WELDMENT

2 127866 DRAWBAR LT/YT

3 17490612 SCREW

4 74760612 SUB= 74780612

5 73680600 SUB= 73690600

6 124464X011 SADDLE

7 17490608 SCREW LT

8 2751R CLIP T

9 123042X013 DASH
10 5479J PLUG BUTTON T
11 122795X PANEL DASH LH
12 121794X COVER ACCESS
13 124031X012 SUB= 155934X010
14 17490608 SCREW LT
15 74180512 SCREW
16 73510500 NUT
17 133956X505 HOOD/GRILL ASM
18 126938X SUB= 532126938
19 133954 LENS SERVICE KIT
20 132257 SUB= 918132257
21 19091216 WASHER PM
22 108067X PAL NUT LT
23 4921H SPRING.RETAINER
24 74760612 SUB= 74780612
25 19131312 WASHER
26 73680600 SUB= 73690600
27 17490608 SCREW LT
30 109872X505 FENDER
31 109873X SUB= 136619
32 17490612 SCREW
33 105476X505 FOOTREST LH
34 105475X505 FOOTREST RH
35 72110606 BOLT
36 73680600 SUB= 73690600

CT1138B (1992) Page 6 of 25
DECALS

CT1138B (1992) Page 7 of 25
DECALS

Ref # Part Number Qty Description

1 109821X SUB= 138956

2 130443 NLA

3 130442 NLA

4 127036 NLA

5 128653 DECAL HP HOOD

6 127037 "DECAL,FENDER"

8 133796 DECAL

9 101892X DECAL T
10 125616X NLA
11 121349X DECAL WARNING
12 109820X DECAL YT
13 127075 "DECAL,STR WHL"
14 121549X DECAL
15 124326X NLA
16 108760X DECAL.ENG.27164
17 106202X REFLECTOR-TAIL YT

133086 OPER MANUAL
133787 PARTS MANUAL

CT1138B (1992) Page 8 of 25
DRIVE
