AYP 952200 Parts List

952200 (1999 & Before) Page 1 of 12
HANDLE ASSEMBLY

952200 (1999 & Before) Page 2 of 12
HANDLE ASSEMBLY

Ref # Part Number Qty Description

1 71091008 SCREW
2 126951X "PANEL,CONT TI"
3 104164X TIE CABLE CRT
4 8206H GRIP T
5 4497H RETAINER M
6 81328 SHOULDER BOLT ST
7 109335X SHIFT HANDLE CRT
8 109313X GROMMET CRT

9 109337X SHIFT ROD CRT
10 72110608 BOLT D
11 109229X LOCK CRT
12 5394H SUB= 73930600
13 19131611 WASHER CRT
14 109228X LEVER LOCK CRT
15 127013X417 SUB= 155117
16 10040400 LOCKWASHER
17 73220400 SUB= 50675
18 73731000 NUT
19 102162X CABLE.CLUTCH.CRT
20 9484R CONDIUT CLIP T
21 86777 SUB= 750097
22 102604X GRIP BAR CRT
23 102744X SUB= 102744X431
24 105216X "ASSY CONTROL, BAR"
25 127012X "CONT,THROTTLE"
26 72140404 BOLT
27 9266R SUB= 624A78

134328 MANUAL
134330 INSTRUCTION DECAL
134331 NLA
120431X DECAL TI

952200 (1999 & Before) Page 3 of 12
MAINFRAME, LEFT SIDE

952200 (1999 & Before) Page 4 of 12
MAINFRAME, LEFT SIDE

Ref # Part Number Qty Description

1 73510500 NUT

2 10040600 LOCKWASHER

3 73220600 NUT.HEX.3/8-16UNC

4 74930568 BOLT TI

5 1572H SUB= 2882J

6 110111X LEVER ASM CRT

7 72110404 BOLT

8 8700J PANEL TI

9 86777 SUB= 750097
10 9484R CONDIUT CLIP T
11 10040400 LOCKWASHER
12 73220400 SUB= 50675
13 23230506 SET SCREW
14 120938X SPACER
15 19111116 WASHER
16 100473M "SHEAVE 10"" CRT"
17 73220500 NUT.HEX.5/16-18
18 110651X SPACER CRT
19 2649M KEY T
20 110653X GUARD CRT
21 131691 SPLIT SPACER
22 104214X NUT TI
23 102190X TIRE.CHV.13X5.0-6

109208X SUB= 124258X

795R SUB= 65139
24 126875X RIVET.DRILL.1.75
25 4497H RETAINER M
26 131159X417 "GUARD, BELT"
27 132672 BELT-V
28 104679X PULLEY-IDLER TI
29 12000032 KLIP RING
30 105611X SUB= 918105611X
31 102384X BOLT CRT
32 102141X SHIFT ARM CRT
33 74760616 BOLT
34 102383X COUNTERWEIGHT CRT
35 74760524 BOLT.HEX.5/16-1.5
36 102331X BRACKET LH CRT
37 130816 ENGINE SHEAVE
38 131558 BELT GUARD BRKT

102180X DECAL CRT

134332 NLA
