Ayp 7143B89 PARTS LIST
7143B89 (1998) Page 1 of 47
BRIGGS AND STRATTON ENGINE
7143B89 (1998) Page 2 of 47
BRIGGS AND STRATTON ENGINE
Ref # Part Number Qty Description
1 496412 CYLINDER ASSY
2 399265 P/N CONFLICT - CHECK WITH SUPPLIER
3 391086 SEAL, OIL
4 494238 BASE, ENGINE
5 495858 HEAD, CYLINDER
7 272614 GASKET, CYLINDER HEAD
8 495735 BREATHER ASSY
9 27803 GASKET, VALVE COVER
10 94621 SCREW, STEMS
11 281246 TUBE, BREATHER
12 271916 GASKET, CRANKCASE COVER 1/64"
12 271997 GASKET, CRANKCASE COVER .005"
12 271996 GASKET, CRANKCASE COVER .009"
13 94728 SCREW, CYLINDER HEAD
15 94239 PLUG, OIL DRAIN
16 495162 CRANKSHAFT
16 94196 KEY, TIMING GEAR
20 291675 SEAL, OIL
22 94624 SCREW, SEMS, BASE MOUNTING
23 492326 FLYWHEEL & RING GEAR ASSY, MAGNETO
24 222698 KEY, FLYWHEEL
25 495860 PISTON ASSY, STANDARD SIZE
25 495977 PISTON ASSY .010" OVERSIZE
25 495978 PISTON ASSY .020" OVERSIZE
25 495979 PISTON ASSY .030" OVERSIZE
26 495854 RING SET, PISTON, STANDARD SIZE
26 495852 RING SET, PISTON, .010" OVERSIZE
26 495851 RING SET, PISTON, .020" OVERSIZE
26 495855 RING SET, PISTON, .030" OVERSIZE
27 263129 LOCK, PISTON PIN
28 498319 PIN, PISTON, STD SIZE
29 494504 ROD ASSY, CONNECTING
29 495490 ROD ASSY, CONNECTING
32 94695 SCREW
32A 94648 SCREW
33 495856 VALVE, EXHAUST
34 495857 VALVE, INTAKE
35 262811 SPRING, VALVE
37 224502 GUARD, FLYWHEEL
40 224641 RETAINER, VALVE SPRING
45 262411 TAPPET, VALVE
46 496884 GEAR, CAM
51 272465 GASKET, CARBURETOR (CARBURETOR TO ELBOW)
52 272569 GASKET, CARBURETOR
52 CHECK WITH SUPPLIER
53 94637 STUD, CARBURETOR MOUNTING
73 224948 SCREEN, FLUSH ROTATING
75 225136 WASHER, SPRING
78 94626 SCREW, SEMS
93 281346 BUSHING, THROTTLE SHAFT
95 94098 SCREW, THROTTLE
98 495800 SCREW, IDLE SPEED
104 231789 PIN, FLOAT HINGE
105 231855 VALVE ASSY, INLET NEEDLE
106 231854 INLET VALVE SEAT
108 224540 VALVE, CHOKE
111 262719 SPRING, CHOKE
117 232118 JET, MAIN (STANDARD)
7143B89 (1998) Page 3 of 47
BRIGGS AND STRATTON ENGINE
Ref # Part Number Qty Description
117 232119 JET, MAIN (HIGH ALTITUDE)
118 498030 VALVE, IDLE, ADJUSTMENT
121 499233 CARBURETOR OVERHAUL KIT
123 94913 SCREW, TORX HEX
125 499153 CARBURETOR ASSY
130 224539 VALVE, THROTTLE
131 494379 SHAFT & LEVER, THROTTLE
133 494381 FLOAT, CARBURETOR
137 281165 GASKET, FLOAT BOWL
138 281164 WASHER, FLOAT BOWL SCREW
141 495931 SHAFT & LEVER, CHOKE
142 232117 NOZZLE, CARBURETOR
164 214047 ELBOW, CARBURETOR
166 94555 STUD, ROCKER ARM
171 281051 P/N CONFLICT - CHECK WITH SUPPLIER
187 492790 HOSE, FUEL
188 94627 SCREW, SEMS 3/4"
192 492160 SCREW ASSY, ROCKER ARM
201 262767 LINK, GOVERNOR
209 260695 SPRING, GOVERNOR
216 262766 LINK, CHOKE
219 490815 GOVERNOR GEAR
222 495611 PLATE, GOVERNOR CONTROL
224 94749 SCREW, HEX HEAD
225 495157 CRANK, GOVERNOR, 1/4" DIAMETER
227 493935 LEVER ASSY, GOVERNOR
230 94927 WASHER, GOVERNOR LEVER
232 262785 SPRING, GOVERNOR LINK
238 262836 CAP, VALVE
240 394358 FILTER, FUEL
265 221535 CLAMP
284 94704 SCREW, AIR CLEANER
294 810068 SCREW, SET
304 496318 HOUSING, BLOWER
305 94786 SCREW
306 225020 SHIELD, CYLINDER
307 94930 SCREW
309 497595 MOTOR, STARTING, 12 VOLT
310 497602 BOLT, THRU
311 497608 BRUSH SET
333 495859 ARMATURE, MAGNETO
334 94731 SCREW, SEMS
337 491055 PLUG, SPARK
346 93705 SUB= 69485
356 497708 WIRE ASSY
356A 497671 WIRE, STOP
356B 494705 WIRE, STOP
358 495993 GASKET SET
363 19203 PULLER, FLYWHEEL
383 89838 WRENCH SPARK PLUG
423 94903 SCREW, HEX HEAD
445 496894 CARTRIDGE, AIR CLEANER
455 222561 CUP, SCREEN MOUNTING
467 493903 KNOB, AIR CLEANER
474 393474 STATOR, ALTERNATOR, DUAL CIRCUIT
482 93621 SCREW, SEMS
510 497606 DRIVE, STARTER
523 495230 CAP AND DIPSTICK, OIL FILLER
7143B89 (1998) Page 4 of 47
BRIGGS AND STRATTON ENGINE
Ref # Part Number Qty Description
524 281370 SEAL, FILLER TUBE
525 496113 TUBE, OIL FILLER
535 272403 ELEMENT, AIR CLEANER
537 281106 O-RING, AIR CLEANER
544 497603 ARMATURE, STARTER
552 231597 BUSHING, GOVERNOR CRANK, 1/4" I.D.
562 94907 BOLT, GOVENOR LEVEL
592 231978 NUT, HEX
601 93053 CLAMP, HOSE, GREEN
611 493496 ELBOW, FUEL PIPE
614 93306 COTTER, HAIR PIN
615 263080 RETAINER
634 494455 SEAL, SPRING ASSY.
634A 491323 SEAL, GOVERNOR
635 280872 ELBOW, SPARK PLUG
646 224546 BRACE, AIR CLEANER
657 94906 SCREW
663 94929 SCREW, SELF-TAPPING
668 280848 SPACER
718 230192 PIN, DOWEL
726 392134 GEAR, RING
727 490324 COVER, STARTER
728 94951 SCREW, HEX HEAD
729 225170 RETAINER, WIRE
729A 281390 CLIP, WIRE
741 262932 GEAR, TIMING
757 213998 LINK, COUNTERWEIGHT
758 399891 COUNTERWEIGHT ASSY
759 298909 PIN ASSY, PISTON, STD
761 94593 SCREW, COUNTERWEIGHT
783 280104 GEAR, STARTER
801 394856 CAP, DRIVE
802 497605 P/N CONFLICT - CHECK WITH SUPPLIER
803 497604 HOUSING, STARTER
842 270920 SEAL, OIL FILLER CAP
847 496415 P/N CONFLICT - CHECK WITH SUPPLIER
851 493880 TERMINAL, IGNITION CABLE
868 494435 SEAL ASSEMBLY, VALVE
868A 272610 GASKET, VALVE
871 262835 BUSHING, GUIDE (INTAKE & EXHAUST)
872 281104 COVER, AIR CLEANER
875 495862 BODY, AIR CLEANER
877 393456 DIODE & CONNECTOR ASSY
947 497672 SOLENOID
965 94108 LOCKNUT, AIR CLEANER MOUNTING
975 495933 BOWL ASSEMBLY, CARBURETOR
977 494385 CARBURETOR GASKET KIT
987 281166 SEAL, THROTTLE SHAFT
1005 280687 FAN, FLYWHEEL
1006 224413 RETAINER, FAN
1019 496758 LABEL KIT
1022 272475 GASKET, COVER
1023 224552 COVER, ROCKER ARM
1026 494432 ROD, PUSH, INTAKE
1026 495136 ROD, PUSH, EXHAUST
1029 224554 ARM, ROCKER
1033 495992 VALVE OVERHAUL KIT
1034 495248 GUIDE ASSEMBLY, PUSH ROD
7143B89 (1998) Page 5 of 47
BRIGGS AND STRATTON ENGINE
Ref # Part Number Qty Description
1036 499364 LABEL KIT, EMISSIONS
1044 94673 SCREW, SHOULDER, HEX HEAD
1045 231828 EXTENSION, CRANKSHAFT
1058 272623 MANUAL, OWNER'S
1090 497607 P/N CONFLICT - CHECK WITH SUPPLIER
1091 281364 CAP, LIMITER
2500 28N707-1026 REPLACEMENT ENGINE
496050 REPLACEMENT SHORTBLOCK
7143B89 (1998) Page 6 of 47
BRIGGS AND STRATTON ENGINE
7143B89 (1998) Page 7 of 47
BRIGGS AND STRATTON ENGINE
Ref # Part Number Qty Description
1 496412 CYLINDER ASSY
2 399265 P/N CONFLICT - CHECK WITH SUPPLIER
3 391086 SEAL, OIL
4 494238 BASE, ENGINE
5 495858 HEAD, CYLINDER
7 272614 GASKET, CYLINDER HEAD
8 495735 BREATHER ASSY
9 27803 GASKET, VALVE COVER
10 94621 SCREW, STEMS
11 281246 TUBE, BREATHER
12 271916 GASKET, CRANKCASE COVER 1/64"
12 271997 GASKET, CRANKCASE COVER .005"
12 271996 GASKET, CRANKCASE COVER .009"
13 94728 SCREW, CYLINDER HEAD
15 94239 PLUG, OIL DRAIN
16 495162 CRANKSHAFT
16 94196 KEY, TIMING GEAR
20 291675 SEAL, OIL
22 94624 SCREW, SEMS, BASE MOUNTING
23 492326 FLYWHEEL & RING GEAR ASSY, MAGNETO
24 222698 KEY, FLYWHEEL
25 495860 PISTON ASSY, STANDARD SIZE
25 495977 PISTON ASSY .010" OVERSIZE
25 495978 PISTON ASSY .020" OVERSIZE
25 495979 PISTON ASSY .030" OVERSIZE
26 495854 RING SET, PISTON, STANDARD SIZE
26 495852 RING SET, PISTON, .010" OVERSIZE
26 495851 RING SET, PISTON, .020" OVERSIZE
26 495855 RING SET, PISTON, .030" OVERSIZE
27 263129 LOCK, PISTON PIN
28 498319 PIN, PISTON, STD SIZE
29 494504 ROD ASSY, CONNECTING
29 495490 ROD ASSY, CONNECTING
32 94695 SCREW
32A 94648 SCREW
33 495856 VALVE, EXHAUST
34 495857 VALVE, INTAKE
35 262811 SPRING, VALVE
37 224502 GUARD, FLYWHEEL
40 224641 RETAINER, VALVE SPRING
45 262411 TAPPET, VALVE
46 496884 GEAR, CAM
51 272465 GASKET, CARBURETOR (CARBURETOR TO ELBOW)
52 272569 GASKET, CARBURETOR
52 CHECK WITH SUPPLIER
53 94637 STUD, CARBURETOR MOUNTING
73 224948 SCREEN, FLUSH ROTATING
75 225136 WASHER, SPRING
78 94626 SCREW, SEMS
93 281346 BUSHING, THROTTLE SHAFT
95 94098 SCREW, THROTTLE
98 495800 SCREW, IDLE SPEED
104 231789 PIN, FLOAT HINGE
105 231855 VALVE ASSY, INLET NEEDLE
106 231854 INLET VALVE SEAT
108 224540 VALVE, CHOKE
111 262719 SPRING, CHOKE
117 232118 JET, MAIN (STANDARD)
7143B89 (1998) Page 8 of 47
BRIGGS AND STRATTON ENGINE
Ref # Part Number Qty Description
117 232119 JET, MAIN (HIGH ALTITUDE)
118 498030 VALVE, IDLE, ADJUSTMENT
121 499233 CARBURETOR OVERHAUL KIT
123 94913 SCREW, TORX HEX
125 499153 CARBURETOR ASSY
130 224539 VALVE, THROTTLE
131 494379 SHAFT & LEVER, THROTTLE
133 494381 FLOAT, CARBURETOR
137 281165 GASKET, FLOAT BOWL
138 281164 WASHER, FLOAT BOWL SCREW
141 495931 SHAFT & LEVER, CHOKE
142 232117 NOZZLE, CARBURETOR
164 214047 ELBOW, CARBURETOR
166 94555 STUD, ROCKER ARM
171 281051 P/N CONFLICT - CHECK WITH SUPPLIER
187 492790 HOSE, FUEL
188 94627 SCREW, SEMS 3/4"
192 492160 SCREW ASSY, ROCKER ARM
201 262767 LINK, GOVERNOR
209 260695 SPRING, GOVERNOR
216 262766 LINK, CHOKE
219 490815 GOVERNOR GEAR
222 495611 PLATE, GOVERNOR CONTROL
224 94749 SCREW, HEX HEAD
225 495157 CRANK, GOVERNOR, 1/4" DIAMETER
227 493935 LEVER ASSY, GOVERNOR
230 94927 WASHER, GOVERNOR LEVER
232 262785 SPRING, GOVERNOR LINK
238 262836 CAP, VALVE
240 394358 FILTER, FUEL
265 221535 CLAMP
284 94704 SCREW, AIR CLEANER
294 810068 SCREW, SET
304 496318 HOUSING, BLOWER
305 94786 SCREW
306 225020 SHIELD, CYLINDER
307 94930 SCREW
309 497595 MOTOR, STARTING, 12 VOLT
310 497602 BOLT, THRU
311 497608 BRUSH SET
333 495859 ARMATURE, MAGNETO
334 94731 SCREW, SEMS
337 491055 PLUG, SPARK
346 93705 SUB= 69485
356 497708 WIRE ASSY
356A 497671 WIRE, STOP
356B 494705 WIRE, STOP
358 495993 GASKET SET
363 19203 PULLER, FLYWHEEL
383 89838 WRENCH SPARK PLUG
423 94903 SCREW, HEX HEAD
445 496894 CARTRIDGE, AIR CLEANER
455 222561 CUP, SCREEN MOUNTING
467 493903 KNOB, AIR CLEANER
474 393474 STATOR, ALTERNATOR, DUAL CIRCUIT
482 93621 SCREW, SEMS
510 497606 DRIVE, STARTER
523 495230 CAP AND DIPSTICK, OIL FILLER
7143B89 (1998) Page 9 of 47
BRIGGS AND STRATTON ENGINE
Ref # Part Number Qty Description
524 281370 SEAL, FILLER TUBE
525 496113 TUBE, OIL FILLER
535 272403 ELEMENT, AIR CLEANER
537 281106 O-RING, AIR CLEANER
544 497603 ARMATURE, STARTER
552 231597 BUSHING, GOVERNOR CRANK, 1/4" I.D.
562 94907 BOLT, GOVENOR LEVEL
592 231978 NUT, HEX
601 93053 CLAMP, HOSE, GREEN
611 493496 ELBOW, FUEL PIPE
614 93306 COTTER, HAIR PIN
615 263080 RETAINER
634 494455 SEAL, SPRING ASSY.
634A 491323 SEAL, GOVERNOR
635 280872 ELBOW, SPARK PLUG
646 224546 BRACE, AIR CLEANER
657 94906 SCREW
663 94929 SCREW, SELF-TAPPING
668 280848 SPACER
718 230192 PIN, DOWEL
726 392134 GEAR, RING
727 490324 COVER, STARTER
728 94951 SCREW, HEX HEAD
729 225170 RETAINER, WIRE
729A 281390 CLIP, WIRE
741 262932 GEAR, TIMING
757 213998 LINK, COUNTERWEIGHT
758 399891 COUNTERWEIGHT ASSY
759 298909 PIN ASSY, PISTON, STD
761 94593 SCREW, COUNTERWEIGHT
783 280104 GEAR, STARTER
801 394856 CAP, DRIVE
802 497605 P/N CONFLICT - CHECK WITH SUPPLIER
803 497604 HOUSING, STARTER
842 270920 SEAL, OIL FILLER CAP
847 496415 P/N CONFLICT - CHECK WITH SUPPLIER
851 493880 TERMINAL, IGNITION CABLE
868 494435 SEAL ASSEMBLY, VALVE
868A 272610 GASKET, VALVE
871 262835 BUSHING, GUIDE (INTAKE & EXHAUST)
872 281104 COVER, AIR CLEANER
875 495862 BODY, AIR CLEANER
877 393456 DIODE & CONNECTOR ASSY
947 497672 SOLENOID
965 94108 LOCKNUT, AIR CLEANER MOUNTING
975 495933 BOWL ASSEMBLY, CARBURETOR
977 494385 CARBURETOR GASKET KIT
987 281166 SEAL, THROTTLE SHAFT
1005 280687 FAN, FLYWHEEL
1006 224413 RETAINER, FAN
1019 496758 LABEL KIT
1022 272475 GASKET, COVER
1023 224552 COVER, ROCKER ARM
1026 494432 ROD, PUSH, INTAKE
1026 495136 ROD, PUSH, EXHAUST
1029 224554 ARM, ROCKER
1033 495992 VALVE OVERHAUL KIT
1034 495248 GUIDE ASSEMBLY, PUSH ROD
7143B89 (1998) Page 10 of 47
BRIGGS AND STRATTON ENGINE
Ref # Part Number Qty Description
1036 499364 LABEL KIT, EMISSIONS
1044 94673 SCREW, SHOULDER, HEX HEAD
1045 231828 EXTENSION, CRANKSHAFT
1058 272623 MANUAL, OWNER'S
1090 497607 P/N CONFLICT - CHECK WITH SUPPLIER
1091 281364 CAP, LIMITER
2500 28N707-1026 REPLACEMENT ENGINE
496050 REPLACEMENT SHORTBLOCK
7143B89 (1998) Page 11 of 47
BRIGGS AND STRATTON ENGINE
7143B89 (1998) Page 12 of 47
BRIGGS AND STRATTON ENGINE
Ref # Part Number Qty Description
1 496412 CYLINDER ASSY
2 399265 P/N CONFLICT - CHECK WITH SUPPLIER
3 391086 SEAL, OIL
4 494238 BASE, ENGINE
5 495858 HEAD, CYLINDER
7 272614 GASKET, CYLINDER HEAD
8 495735 BREATHER ASSY
9 27803 GASKET, VALVE COVER
10 94621 SCREW, STEMS
11 281246 TUBE, BREATHER
12 271916 GASKET, CRANKCASE COVER 1/64"
12 271997 GASKET, CRANKCASE COVER .005"
12 271996 GASKET, CRANKCASE COVER .009"
13 94728 SCREW, CYLINDER HEAD
15 94239 PLUG, OIL DRAIN
16 495162 CRANKSHAFT
16 94196 KEY, TIMING GEAR
20 291675 SEAL, OIL
22 94624 SCREW, SEMS, BASE MOUNTING
23 492326 FLYWHEEL & RING GEAR ASSY, MAGNETO
24 222698 KEY, FLYWHEEL
25 495860 PISTON ASSY, STANDARD SIZE
25 495977 PISTON ASSY .010" OVERSIZE
25 495978 PISTON ASSY .020" OVERSIZE
25 495979 PISTON ASSY .030" OVERSIZE
26 495854 RING SET, PISTON, STANDARD SIZE
26 495852 RING SET, PISTON, .010" OVERSIZE
26 495851 RING SET, PISTON, .020" OVERSIZE
26 495855 RING SET, PISTON, .030" OVERSIZE
27 263129 LOCK, PISTON PIN
28 498319 PIN, PISTON, STD SIZE
29 494504 ROD ASSY, CONNECTING
29 495490 ROD ASSY, CONNECTING
32 94695 SCREW
32A 94648 SCREW
33 495856 VALVE, EXHAUST
34 495857 VALVE, INTAKE
35 262811 SPRING, VALVE
37 224502 GUARD, FLYWHEEL
40 224641 RETAINER, VALVE SPRING
45 262411 TAPPET, VALVE
46 496884 GEAR, CAM
51 272465 GASKET, CARBURETOR (CARBURETOR TO ELBOW)
52 272569 GASKET, CARBURETOR
52 CHECK WITH SUPPLIER
53 94637 STUD, CARBURETOR MOUNTING
73 224948 SCREEN, FLUSH ROTATING
75 225136 WASHER, SPRING
78 94626 SCREW, SEMS
93 281346 BUSHING, THROTTLE SHAFT
95 94098 SCREW, THROTTLE
98 495800 SCREW, IDLE SPEED
104 231789 PIN, FLOAT HINGE
105 231855 VALVE ASSY, INLET NEEDLE
106 231854 INLET VALVE SEAT
108 224540 VALVE, CHOKE
111 262719 SPRING, CHOKE
117 232118 JET, MAIN (STANDARD)
7143B89 (1998) Page 13 of 47
BRIGGS AND STRATTON ENGINE
Ref # Part Number Qty Description
117 232119 JET, MAIN (HIGH ALTITUDE)
118 498030 VALVE, IDLE, ADJUSTMENT
121 499233 CARBURETOR OVERHAUL KIT
123 94913 SCREW, TORX HEX
125 499153 CARBURETOR ASSY
130 224539 VALVE, THROTTLE
131 494379 SHAFT & LEVER, THROTTLE
133 494381 FLOAT, CARBURETOR
137 281165 GASKET, FLOAT BOWL
138 281164 WASHER, FLOAT BOWL SCREW
141 495931 SHAFT & LEVER, CHOKE
142 232117 NOZZLE, CARBURETOR
164 214047 ELBOW, CARBURETOR
166 94555 STUD, ROCKER ARM
171 281051 P/N CONFLICT - CHECK WITH SUPPLIER
187 492790 HOSE, FUEL
188 94627 SCREW, SEMS 3/4"
192 492160 SCREW ASSY, ROCKER ARM
201 262767 LINK, GOVERNOR
209 260695 SPRING, GOVERNOR
216 262766 LINK, CHOKE
219 490815 GOVERNOR GEAR
222 495611 PLATE, GOVERNOR CONTROL
224 94749 SCREW, HEX HEAD
225 495157 CRANK, GOVERNOR, 1/4" DIAMETER
227 493935 LEVER ASSY, GOVERNOR
230 94927 WASHER, GOVERNOR LEVER
232 262785 SPRING, GOVERNOR LINK
238 262836 CAP, VALVE
240 394358 FILTER, FUEL
265 221535 CLAMP
284 94704 SCREW, AIR CLEANER
294 810068 SCREW, SET
304 496318 HOUSING, BLOWER
305 94786 SCREW
306 225020 SHIELD, CYLINDER
307 94930 SCREW
309 497595 MOTOR, STARTING, 12 VOLT
310 497602 BOLT, THRU
311 497608 BRUSH SET
333 495859 ARMATURE, MAGNETO
334 94731 SCREW, SEMS
337 491055 PLUG, SPARK
346 93705 SUB= 69485
356 497708 WIRE ASSY
356A 497671 WIRE, STOP
356B 494705 WIRE, STOP
358 495993 GASKET SET
363 19203 PULLER, FLYWHEEL
383 89838 WRENCH SPARK PLUG
423 94903 SCREW, HEX HEAD
445 496894 CARTRIDGE, AIR CLEANER
455 222561 CUP, SCREEN MOUNTING
467 493903 KNOB, AIR CLEANER
474 393474 STATOR, ALTERNATOR, DUAL CIRCUIT
482 93621 SCREW, SEMS
510 497606 DRIVE, STARTER
523 495230 CAP AND DIPSTICK, OIL FILLER
7143B89 (1998) Page 14 of 47
BRIGGS AND STRATTON ENGINE
Ref # Part Number Qty Description
524 281370 SEAL, FILLER TUBE
525 496113 TUBE, OIL FILLER
535 272403 ELEMENT, AIR CLEANER
537 281106 O-RING, AIR CLEANER
544 497603 ARMATURE, STARTER
552 231597 BUSHING, GOVERNOR CRANK, 1/4" I.D.
562 94907 BOLT, GOVENOR LEVEL
592 231978 NUT, HEX
601 93053 CLAMP, HOSE, GREEN
611 493496 ELBOW, FUEL PIPE
614 93306 COTTER, HAIR PIN
615 263080 RETAINER
634 494455 SEAL, SPRING ASSY.
634A 491323 SEAL, GOVERNOR
635 280872 ELBOW, SPARK PLUG
646 224546 BRACE, AIR CLEANER
657 94906 SCREW
663 94929 SCREW, SELF-TAPPING
668 280848 SPACER
718 230192 PIN, DOWEL
726 392134 GEAR, RING
727 490324 COVER, STARTER
728 94951 SCREW, HEX HEAD
729 225170 RETAINER, WIRE
729A 281390 CLIP, WIRE
741 262932 GEAR, TIMING
757 213998 LINK, COUNTERWEIGHT
758 399891 COUNTERWEIGHT ASSY
759 298909 PIN ASSY, PISTON, STD
761 94593 SCREW, COUNTERWEIGHT
783 280104 GEAR, STARTER
801 394856 CAP, DRIVE
802 497605 P/N CONFLICT - CHECK WITH SUPPLIER
803 497604 HOUSING, STARTER
842 270920 SEAL, OIL FILLER CAP
847 496415 P/N CONFLICT - CHECK WITH SUPPLIER
851 493880 TERMINAL, IGNITION CABLE
868 494435 SEAL ASSEMBLY, VALVE
868A 272610 GASKET, VALVE
871 262835 BUSHING, GUIDE (INTAKE & EXHAUST)
872 281104 COVER, AIR CLEANER
875 495862 BODY, AIR CLEANER
877 393456 DIODE & CONNECTOR ASSY
947 497672 SOLENOID
965 94108 LOCKNUT, AIR CLEANER MOUNTING
975 495933 BOWL ASSEMBLY, CARBURETOR
977 494385 CARBURETOR GASKET KIT
987 281166 SEAL, THROTTLE SHAFT
1005 280687 FAN, FLYWHEEL
1006 224413 RETAINER, FAN
1019 496758 LABEL KIT
1022 272475 GASKET, COVER
1023 224552 COVER, ROCKER ARM
1026 494432 ROD, PUSH, INTAKE
1026 495136 ROD, PUSH, EXHAUST
1029 224554 ARM, ROCKER
1033 495992 VALVE OVERHAUL KIT
1034 495248 GUIDE ASSEMBLY, PUSH ROD
7143B89 (1998) Page 15 of 47
BRIGGS AND STRATTON ENGINE
Ref # Part Number Qty Description
1036 499364 LABEL KIT, EMISSIONS
1044 94673 SCREW, SHOULDER, HEX HEAD
1045 231828 EXTENSION, CRANKSHAFT
1058 272623 MANUAL, OWNER'S
1090 497607 P/N CONFLICT - CHECK WITH SUPPLIER
1091 281364 CAP, LIMITER
2500 28N707-1026 REPLACEMENT ENGINE
496050 REPLACEMENT SHORTBLOCK
Loading...
