AYP 4186-64 Parts List

4186-64 (1996) Page 1 of 28
CHASSIS AND ENCLOSURES

4186-64 (1996) Page 2 of 28
CHASSIS AND ENCLOSURES

Ref # Part Number Qty Description

1 151169 CHASSIS WLDMT 11G
2 140356 SUB= 145009
3 17490612 SCREW
6 145206 SUB= 145206X431
8 126471X "CLIP,INSULATOR"

9 140398 DASHBOARD BLACK
10 72140608 SUB= 72110608
11 145222 PANEL.DASH.LH.PNT
13 145221 PANEL.DASH.RH.PNT
15 74180512 SCREW
16 73510500 NUT
17 150301X424 HOOD.PNT.
24 74780616 BOLT
25 19131312 WASHER
26 73800600 NUT
27 17030814 SUB= 91817030814
28 150197 GRILLE ASM PNT
29 146459 LENS.BAR.CLEAR
30 140002X424 FENDER YT/GT
31 137113 BRKT.ASM.FENDER
33 145244X424 FOOTREST.LH.LT/GT
34 145243X424 FOOTREST.RH.LT/GT
35 72110606 BOLT
36 108067X PAL NUT LT
38 139886 BRACKET ASM LH
39 139887 BRACKET ASM RH
43 17490612 SCREW
44 140675 STRAP ASM FENDER
45 147717 BEZEL.ASM.
47 105531X NUT-PUSH YT
50 145205 DASH.SUPT.YP/HUSQ
56 150271 EXT DASH LTYT
59 110436X SUB= 9151R
60 72140606 BOLT
64 150272 DASH.LOWER.LT
66 140299X012 PLATE SLKSCR YP
67 19111116 WASHER
72 144916X424 STRAP.GRILLE.424
73 17580408 SCREW CRT
74 73680600 SUB= 73690600
77 74191008 SCREW
79 2029J WELDNUT
80 109808X HOOD LATCH T
82 74981020 SCREW
83 7206J SPACER LT
85 73731000 NUT
86 150303X424 PANEL ASM SIDE RH
87 150302X424 PANEL ASM SIDE LH
90 19091216 WASHER PM
91 73220400 SUB= 50675
92 10040400 LOCKWASHER

108 74760612 SUB= 74780612
135 74291006 SCREW.10-24X3/8.
136 60867 ACORN NUT RB
137 110356X SNAP CAP LT
138 110357X WASHER LT
139 150195 BKT.SPT.HOOD/PANL
140 150556 SUB= 158739

4186-64 (1996) Page 3 of 28
CHASSIS AND ENCLOSURES

Ref # Part Number Qty Description

121794X COVER ACCESS
8022J PLUG-DASH T

4186-64 (1996) Page 4 of 28
DECALS

4186-64 (1996) Page 5 of 28
DECALS

Ref # Part Number Qty Description

2 135341 GRILL DECAL

3 135344 HOOD DECAL LH

4 135343 NLA

5 135062 NAMEPLATE LOGO

6 140837 DECAL BRAK PARK

7 133796 DECAL

8 4900J DECAL T

9 154999 DECAL.CHASSIS.18H
10 139346 "DECAL.V.BELT.44"""
11 135619 NLA
12 138955 DECAL.DASH.INST.
13 106202X REFLECTOR-TAIL YT
14 146451 DECAL.BTRY.DANGER
15 272091 DECAL ENGINE

133671 FOOTREST PAD
138311 DECAL HANDLE LIFT
155012 MANUAL.O.4186-64
TR40 40" DISC
LBD48 SNOW BLADE
LSB42 SNOW THROWER
TR30 10" PLOW
TR01 GRADER BLADE

4186-64 (1996) Page 6 of 28
DRIVE

4186-64 (1996) Page 7 of 28
DRIVE

Ref # Part Number Qty Description

1 138788 TRANSAX. PRLES.

2 110422X SUB= 146682

3 121327X PULLEY TRANSAXLE

4 12000004 RING

5 123787X STRAP TORQUE

6 17490512 SCREW

8 141002 ROD SHIFT FEND YT

9 137140 SUB= 142600
10 76020416 PIN COTTER 1/8
11 105701X WASH-SHFT PLT LT
13 74550412 BOLT.1/4-28.W/PAT
15 74490544 BOLT.HX.FLG.5/16
17 126197X WASHER
19 73800600 NUT
20 150280 BOLT.7/16-20X4.25
21 106933X KNOB T (1/2-HOLE)
22 145340 ROD.ASM.BK.44.MWR
23 137141 BRACKET.ASM.MTG
24 73350600 NUT
25 126909X "SPRING,ROD BRAKE"
26 19131316 WASHER
27 76020412 COTTER PIN
28 145204 ROD.BRAKE.PARK.LT
29 71673 PLUNGER CAP T
30 123780X BRKT TRANS LH
31 123791X KEEPER BELT LH
33 72140506 BOLT
34 151128 SHAFT FOOT PEDAL
35 120183X NYLON BEARING
36 19211616 WASHER LT
37 1572H SUB= 2882J
38 123674X PULLEY.IDLER.FLAT
39 74760644 BOLT
40 4470J SPACER T
41 153399 KEEPER BELT
42 19131312 WASHER
43 19111012 WASHER T
44 105706X "LY, BEARING"
45 110812X WASHER LT
46 12000039 KLIP RING
47 127783 SUB= 139245
48 123789X ARM IDLER
49 123205X RETAIN BELT
50 74760624 SUB= 74930624
51 73680600 SUB= 73690600
52 73680500 SUB= 73690500
53 105710X "LINK, CLUTCH T"
54 126471X "CLIP,INSULATOR"
55 105709X "SPRING, RETURN LT"
56 74760620 SUB= 74780620
57 123796X BELT.GRDRV.94.75
58 123792X "KEEPER,BELT RH"
59 140312 KEEPER BELT CNTSP
60 121218X KEEPER BELT ENGLH
61 17490612 SCREW
62 8883R PEDAL COVER T
63 136906 PULLEY ENGINE
65 10040700 LOCKWASHER

4186-64 (1996) Page 8 of 28
DRIVE

Ref # Part Number Qty Description

68 105730X "KEEPER,BLT ENG LT"
74 108097X SPACER HYT
75 123800X WASHER
76 12000053 E RING HYT
77 9396E SQ KEY STD
79 2228M SUB= 2228M1
80 123794X "ARM,SHIFT"
81 123772X "SHAFT,SHIFTER"
82 123782X "SPRING,TORSION"
83 19171216 WASHER
84 123793X "ROD,TIE "
85 150360 NUT.CNT.LOCK.1/4
86 71208 BUSHING
87 19212016 WASHER D
88 12000008 KLIP RING
89 139992 CONSOLE SHIFTER
90 124346X NUT
96 4497H RETAINER M

110 74760612 SUB= 74780612
111 123776X BRKT TRANS RH
115 19132203 WASHER GT
117 19091216 WASHER PM

4186-64 (1996) Page 9 of 28
ELECTRICAL
