INSTALLATION INSTRUCTIONS FOR PART OESWC-7552-STK
The OESWC-7552-STK is designed to allow you to add steering wheel control
options to 2007 and up Nissan vehicles. The column mounted OESWC-7552-
STK will allow the customer to adjust their radio without taking their eyes off the
road. The OESWC-7552-STK will come pre-programmed with your most popular
features, volume up, volume down, seek up, seek down, and source. But with
the option of remapping the buttons to t every customer needs, this makes this a
must have interface that the Axxess line offers.
OESWC-7552-STK
INTERFACE COMPONENTS
• A) ASWCSTALK • B) OESWC INTERFACE • C) (3) ROD ASSORTMENTS
• D) (2) 3/8 HEX NUTS • E) DECORATIVE NUT • F) (2)ANGLE MOUNT
• G) (2)FLAT MOUNT
• H) TWIST ON COVER • I) VEHICLE T-HARNESS
A B
E
C
F
H
D
G
I
TOOLS REQUIRED FOR INSTALLATION
•Cutting Tool •Tape •Crimping Tool
•Connectors (I.E. butt-connectors, bell caps, ECT…) • Female Spade Connectors
IGNITION
TERMINALS
WIRE
CUTTER
M3.5
M2.6
M3
M5
M4
ISO
6
2.5
1.5
*Important: Please check steering shroud before
drilling to make sure you have enough depth.
ASWCSTALK ASSEMBLY
1. Remove and drill a 3/8 hole in the steering wheel shroud.
2. Select desired length rod and thread a 3/8 hex nut on to the shorter
threaded section.
3. Run the four wires from the ASWCSTALK through the rod of choice
and screw it into the ASWCSTALK
4. Take the twist on cover, run the wires through, and twist the cap on to
the ASWCSTALK making sure to align the notches on the cover.
5. Screw the DECORATIVE NUT to the end of the rod with the smaller
end facing the ASWCSTALK
6. Select the desired angle mount and put it on to the rod with the angle
facing away from the ASWCSTALK.
7. Run wires through the steering wheel shroud and insert rod through
the shroud.
8. Secure the ASWCSTALK with the supplied 3/8 nut. (Do not over
tighten)
9. Run wires to where the ASWCSTALK interface will be.
1
