Axxess CHTO-013 Installation Instructions Manual

CHRYSLER CAN BUS INTERFACE
©Copyright 2004-2010 Metra Electronics Corporation
1-800-221-0932
www.metraonline.com
CHTO-013
INSTALLATION INSTRUCTIONS
* IMPORTANT WARNING
THIS PRODUCT INCLUDES INSTRUCTIONS FOR INSTALLATION WHICH MUST BE CAREFULLY FOLLOWED. THE INSTRUCTIONS ARE WORDED IN SUCH A MANNER TO ASSUME THAT THE INSTALLER IS CAPABLE OF COMPLETING THESE TYPE OF ELECTRONIC INSTALLATIONS. IF YOU ARE UNCLEAR AS TO WHAT YOU ARE INSTRUCTED TO DO OR BELIEVE THAT YOU DO NOT UNDER­STAND THE INSTRUCTIONS SO AS TO PROPERLY AND SAFELY COMPLETE THE INSTALLATION YOU SHOULD CONSUL
T A TECHNICIAN WHO DOES HAVE
THIS KNOWLEDGE AND UNDERSTANDING. FAILURE TO FOLLOW THESE
INSTRUCTIONS CAREFULLY AND TO INSTALL THE INTERFACE AS DESCRIBED COULD CAUSE HARM TO THE VEHICLE OR TO SAFETY SYSTEMS ON THE VEHICLE. INTERFERENCE WITH CERTAIN SAFETY SYSTEMS COULD CAUSE HARM TO PERSONS AS WELL. IF YOU HAVE ANY QUESTIONS IN THIS REGARD PLEASE CALL THE HELP LINE OR THE METRA AT 1-800-221-0932 FOR ASSISTANCE.
CHTO-013 CHTO-013
* READ IMPORTANT WARNING INSIDE
BEFORE ATTEMPTING ANY INSTALLATION
THE CHTO-013 IS DESIGNED TO BE USED WITH VEHI­CLES THAT HAVE A FACTORY AMPLIFIED SYSTEM. THE CHTO-013 WILL PROVIDE A 12VOLT SWITCHED WIRE FOR PROPER RADIO OPERATION. THE CHTO-013 NOW PROVIDES MUTE, PARKING BRAKE, VSS OR SPEED SENSE, AND A REVERSE OUTPUT TO MAKE INSTALLING AN AFTERMARKET NAVIGATIONAL RADIO SIMPLER AND LESS TIME COMSUMING.
• Cutting Tool • Tape • Crimping Tool • Connectors
TOOLS REQUIRED FOR INST
ALLATION
AUDIO LEVEL CONTROL
When using the CHTO-013 with a radio that has a high audio pre-out voltage, usually greater than 2 volts, the audio signal may become distorted. To resolve this follow these steps:
1. Make sure the ignition is turned to the “off” position.
2. Disconnect both of the harnesses from the CHTO-013.
3. Locate the potentiometer next to the 14 pin connector at the end of the CHTO-013.
4. Taking a small flat headed screwdriver, turn the potentiometer counter-
clockwise to lo
wer the input level going to the factor
y amplifier.
5. After making the adjustment reconnect the wire harnesses.
4
REV. 05-10-10 INSTCHTO-013
POTENTIOMETER AUDIO LEVEL ADJUSTMENT
INTERF
ACE COMPONENTS
• CHTO-013
• 14 PIN HARNESS WITH RCA’S
• (2) 12 PIN HARNESSES TO 22 PIN CHRYSLER HARNESSES
CONNECTIONS TO BE MADE ON THE 14 PIN HARNESS
1. Connect the blue/white wire to the radio’s amplifier turn-on wire.
2. Connect the red wire to the radio’s Igniton or accessory wire.
3. Connect the RCA cables to the radio’s RCA outputs. If no RCA outputs are
available, use the Metra line output converter, part # ALOC648,
(SOLD SEPARATELY).
4. The white RCA goes to the left front RCA output of the radio.
5. The gray RCA goes to the right front RCA output of the radio.
6. The green RCA goes to the left rear RCA output of the radio.
7. The purple RCA goes to the right rear RCA output of the radio. The following wires on the 14 pin harness are for the aftermarket radios
that have navigation built in:
Connect the Brown wire to the mute wire of the aftermarket radio. Connect the Green wire to the parking brake wire of the aftermarket radio. Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
`radio. Connect the Green/Purple wire to the reverse wire of the aftermarket radio.
• When completed, plug the 14 pin harness into the CHTO-013.
INSTALLING THE CHTO-013
1. With all connections completed to the aftermarket radio, plug the 22 pin
connector into the vehicles corresponding wiring harnesses.
2. Cycle the key by turning the ignition on then back off, then back on again
to test the radio.
TESTING THE CHTO-013
1. Turn the ignition on then the radio to verify the radio works. Check balance
and fader controls for proper operation. If controls are backwards, check to see if the RCA’s are in the correct location.
21
CHTO-013
WIRING UP THE CHTO-013
* Important: Before beginning any of the following, disconnect the negative
battery terminal to prevent accidental short circuit.
*
*
NO
TE: THE ACCESSORY POWER SOURCE OF MOST ALL CHRYLSER VEHICLES KEEPS THE RADIO ON UNTIL ONE OF THE DOORS IS OPENED. THIS IS CALLED R.A.P. (RETAINED ACCESSORY POWER). THE CHTO-013 IS DESIGNED TO RETAIN THIS FEA­TURE.
* NO
TE: THE VEHICLES IGNITION SWITCH MUST BE IN THE OFF POSITION BEFORE PLUGGING THE CHTO-013 MODULE IN. ALSO THE KEY MUST BE CYCLED AT A MEDIUM PACE AT LEAST TWO TIMES BEFORE BEGINNING TESTING.
CONNECTIONS TO BE MADE ON THE 22 PIN HARNESS:
1. Connect the yelow wire to the radio’s 12v battery or memory wire.
2. Connect the black wire to the radio’s ground wire.
3. Connect the orange wire to the radio’s illumination wire. If wire is not present,
tape up wire.
4. F
or the Caliber only, connect the blue/white wire to the blue/white wire in
the 14 pin harness, which connects to the radio’s amplifier turn-on wire.
3
APPLICATIONS
*NO
TE:
THE CHTO-013 COMES WITH 2 DIFERENT CHRYSLER 22 PIN HARNESSES.THE APPLICATIONS WITH A (*) USE THE BIGGER OF THE TWO HARNESSES. THE BIGGER OF THE TWO HARNESSES ALSO HAVE 2 LARGER TERMINALS, ONE AT EACH END OF THE CONNECTOR.
Metra recommends MECP certified technicians.
K
NOWLEDGE IS POWER
Enhance your installation and fabrication skills by enrolling in the most recognized and respected mobile electronics school in our industry. Log onto www.installerinstitute.com or call 800-354-6782 for more information and take steps toward a better tomorrow.
CHRYSLER
300 2008-10 ASPEN 2008-09 SEBRING 2007-10* TOWN & COUNTRY 2008-10*
DODGE
AVENGER 2008-10* CALIBER 2007 CHALLENGER 2009-10 CHARGER 2008-10 DAKOTA 2008-09 DURANGO 2008-09 GRAND CARAVAN 2008* JOURNEY 2009-10* MAGNUM 2008
NITRO 2007-10* RAM 1500 2009-2010 RAM 2500/3500 2010
JEEP
COMMANDER 2006-2007 COMPASS 2007 GRAND CHEROKEE 2005-2007 PATRIOT 2007 WRANGLER 2007-10*
