• Provides NAV outputs (parking brake, reverse,
and speed sense)
•
Used in non-amplified models, or when
bypassing a factory amplifier
INTERFACE COMPONENTS
• AXRC-GM1 interface • AXRC-GM1 harness
APPLICATIONS
See inside front cover
Axxess Integrate
axxessinterfaces.com • metraonline.com
• Used in models without OnStar
• Retains all warning chimes
• High level speaker input
• Retains balance and fade
• Micro “B” USB updatable
Table of Contents
Connections to be made ............................................3
Installing the AXRC-GM1 ...........................................3
Initializing the AXRC-GM1 .........................................3
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
CAUTION!
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
All accessories, switches, climate controls panels, and
From the AXRC-GM1 harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Red wire to the accessory wire.
• Connect the Blue/White wire to the power antenna wire.
• If the aftermarket radio has an illumination wire, connect the Orange
wire to it.
Note:There are (2) Orange wires. If the Orange wire on the 24-pin
harness is populated on the factory side, use that wire. Otherwise,
use the other Orange wire.
• Tape off and disregard the Orange/White wire, it will not be used in
this application.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative speaker output.
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire.
Installing the AXRC-GM1
With the key in the off position:
• Connect the AXRC-GM1 harness into the interface.
• Connect the AXRC-GM1 harness to the vehicle.
Initializing the AXRC-GM1
Attention: If the interface loses power for any reason, the following steps
will need to be performed again.
• Turn the key (or push-to-start button) to the ignition position and wait
until the radio comes on.
Note: If the radio does not come on within 60 seconds, turn the key
to the off position, disconnect the interface, check all connections,
reconnect the interface, and then try again.
•
Turn the key to the off position, and then to the accessory position. Test all
functions of the installation for proper operation, before reassembling the dash
3
.
REV. 1/21/2020 INSTAXRC-GM1
Installation instructions for part AXRC-GM1
IMPORTANT
If you are having difficulties with the
installation of this product, please call our
Tech Support line at 1-800-253-TECH.
Before doing so, look over the instructions a
second time, and make sure the installation
was performed exactly as the instructions
are stated. Please have the vehicle apart
and ready to perform troubleshooting steps
before calling.
®
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Instrucciones de instalación para la pieza AXRC-GM1
REV. 1/21/2020 INSTAXRC-GM1
AXRC-GM1
GM Interfase de Bus de Datos
2000-2013
CARACTERÍSTICAS DE LA INTERFASE
• Provee corriente de accesorios (12 voltios 10 amperes)
• Retiene R.A.P. (corriente de accesorio retenida)
• Proporciona salidas de NAV (freno de mano, reversa y sensor de velocidad)
• Utilizados en los modelos no amplificados, o cuando sin pasar por un amplificador
de fábrica
• Se utiliza en los modelos sin OnStar
• Retiene todas las campanillas de advertencia
• Entrada de bocina de alto nivel
• Retiene el balance y la intensidad
• Actualizable por micro “B” USB
COMPONENTES DE LA INTERFASE
• Interfase AXRC-GM1 • Arnés AXRC-GM1
APLICACIONES
Ver interior de la portada
Axxess Integrate
axxessinterfaces.com • metraonline.com
Indice
Conexiones que se deben hacer ...............................3
Instalación del AXRC-GM1 ........................................3
Inicialización del AXRC-GM1 .....................................3
HERRAMIENTAS REQUERIDAS
• Cortacables • Ponchadora • Pistola soldadora
• Cinta
• Conectores (ejemplo: conectores de extremo,
de campana, etc.)
¡PRECAUCIÓN!
troles de clima y especialmente las luces del indicador de las bolsas
de aire deben estar conectados antes ciclar la ignición. Además, no
quite el radio de fábrica con la llave en la posición o de encendido ni
con el vehículo funcionando.
Todos los accesorios, interruptores, paneles de con-
Desde el arnés AXRC-GM1 al radio de mercado secundario:
• Conecte el cable negro al cable de tierra.
• Conecte el cable amarillo al cable de la batería.
• Conecte el cable rojo con el cable de accesorios.
• Conecte el cable azul/blanco al cable de encendido del amplificador.
• Si el radio de mercado secundario tiene un cable de iluminación, conecte
el cable anaranjado a ella.
Nota:Hay (2) cables de naranja. Si el cable naranja en el arnés de 24
clavijas está poblado en el lado de la fábrica, utilice ese cable. De lo
contrario, utilice el otro cable de naranja.
• Encinte e ignore el cable anaranjado/blanco, no se utilizará en esta aplicación.
•
Conecte el cable gris con la salida positiva de la bocina derecha delantera
• Conecte el cable gris/negro con la salida negativa de la bocina derecha delantera.
• Conecte el cable blanco con la salida positiva de la bocina izquierda delantera
• Conecte el cable
izquierda delantera.
• Conecte el cable verde con la salida positiva de la bocina izquierda trasera.
• Conecte el cable verde/negro con la salida negativa de la bocina izquierda trasera
Conecte el cable púrpura con la salida positiva de la bocina derecha trasera
•
•
Conecte el cable
derecha trasera.
blanco/negro
púrpura/negro
con la salida negativa de la bocina
con la salida negativa de la bocina
.
.
.
.
Conexiones que se deben hacer
Los siguientes (3) cables son para radios de mercado secundario con multimedios/
navegación que tienen estos cables.
• Conecte el cable azul/rosa al cable VSS o de detección de velocidad.
• Conecte el cable verde/púrpura al cable de reversa.
• Conecte el cable verde claro al cable de freno de mano.
Instalación del AXRC-GM1
Con la llave en la posición de apagado:
• Conecte el arnés AXRC-GM1 a la interfase.
• Conecte el arnés AXRC-GM1 al vehículo.
Inicialización del AXRC-GM1
Atención: Si la interfase pierde energía por cualquier razón, tendrán que
volverse a ejecutar los siguientes pasos.
• Gire la llave (o pulsar para botón de inicio) a la posición de encendido
and y esperar hasta que la radio se enciende.
Nota: Si la radio no se enciende dentro de 60 segundos, gire la llave
a la posición de apagado, desconecte la interfase, compruebe todas
las conexiones, vuelva a conectar la interfase, y vuelva a intentarlo.
• Gire la llave a la posición de apagado, y luego a la posición de accesorios.
Pruebe todas las funciones de la instalación para su correcto funcionamiento,
antes de volver a montar el tablero.
3
REV. 1/21/2020 INSTAXRC-GM1
