Axxess AXBT-TY1 Product Sheet

A XBT-TY 1

INTERFACE COMPONENTS

• AXBT-TY1 harness:

• 10-pin harness

• 28-pin harness

• 30-pin harness

• 12-pin AXSWC harness

• 16-pin AXBT harness

• AXCSD-6V

• AXBT interface

I N T E R FA C E

Data Interface

Toyota Camry 2018-Up

RAV4 2019-Up

Visit AxxessInterfaces.com for more detailed information about the product and up-to-date vehicle speciﬁc applications.

INTERFACE FEATURES

• Wiring harness for installing an aftermarket radio

• Provides power and four speakers

• Retains balance and fade

• Designed for non-ampliﬁed models

• Provides NAV outputs (parking brake, reverse, speed sense)

• Retains the factory backup camera

• Pre-wired AXSWC harness (AXSWC sold separately)

• Includes an AXCSD-6V 12-to-6V step-down for the factory camera

• Allows retention and adjustment of the * Personalization Options

• Adjust * Personalization Options through a Bluetooth application

• Smartphone application offering full control from either Android or Apple mobile devices

OPTIONAL ACCESSORIES (sold separately)

Steering Wheel Control Interface: AXSWC

* Actual options available vary per vehicle and per trim.

(Refer to owner’s manual for options available in vehicle.)

What Fits My Vehicle? See the Vehicle Fit Guide at

SALES 800-221-0932 REV. 10/5/20

AxxessInterfaces.com

Specifications and Main Features
