Axxess AX-ADFD01 Installation Instructions Manual
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
AX-ADFD01
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 6/26/18 INSTAX-ADFD01
INTERFACE FEATURES
INTRODUCTION
TOOLS REQUIRED
• Crimping tool and connectors or solder gun,
solder, and heat shrink • Wire cutter • Zip ties
• Small flat-blade screwdriver • Tape
TABLE OF CONTENTS
Connections to be made
For models
without
a Sony/THX amplifier .....2-3
For models
with
a Sony/THX amplifier .........4-5
Installing & programming the AX-ADFD01
AX-ADBOX1 ........................................................... 5
AX-ADBOX2 ..........................................................6
Adjusting the AX-ADFD01 ......................................7
Extra features ......................................................... 7
Ford Data Interface 2007-up*
APPLICATIONS
See inside front cover
• Provides accessory power (12-volt 10-amp)
• Maintains the retained accessory power (R.A.P.) feature
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains rear seat entertainment (R.S.E.)
• Retains satellite radio
• Retains SYNC
• Retains the factory AUX-IN jack
• Pre-wired ASWC-1 harness (ASWC-1 sold separately)
• Can be used in both non-amplified and amplified models
(including Sony/THX)
• Retains balance and fade†
• Micro “B” USB updatable
The AX-ADFD01 harness is designed for, and must be used with, the
AX-ADBOX1 or AX-ADBOX2 interface (sold separately). Please refer to the
AX-ADBOX1 or AX-ADBOX2 for the 16-pin connector with stripped leads.
*Visit AxxessInterfaces.com for up-to-date vehicle specific applications.
† Excluding Sony/THX
INTERFACE COMPONENTS
• AX-ADFD01 harness
2
APPLICATIONS CONNECTIONS TO BE MADE
Attention! This interface will work with models that are either non-amplified, or amplified.
Please follow the instructions carefully for your model vehicle. Failure to do so will result in
either no sound, or low sound. If you are unsure if your vehicle is factory amplified or not, please
contact your local dealership.
For models
without
a Sony/THX amplifier:
From the 16-pin harness with stripped leads to the aftermarket radio (harness included with interface):
• Connect the Red wire to the accessory wire.
Note: If installing either an ASWC-1 or AX-LCD (both sold separately), connect the (2) Red
wires on the AX-ADFD01 harness as well.
• If the vehicle is equipped with a factory subwoofer, connect the Blue/White wire to the
amp turn on wire.
• If the aftermarket radio has an illumination wire, connect the Orange/White wire to it.
• If the aftermarket radio has a mute wire and the vehicle is equipped with SYNC, connect
the Brown wire to it. If the mute wire is not connected, the radio will turn off when SYNC
is activated.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
Continued on the next page
FORD
Econoline * 2014-up
Econoline 2009-2013
Edge (with NAV) 2007-2010
Escape 2008-2012
Expedition 2007-2014
Explorer (with NAV) 2009-2010
Explorer Sport Trac (with NAV) 2009-2010
F-150 * 2009-2012
F-150 STX/FX2 base/XLT base 2013
F-150 STX/XLT base 2014
F-250/350/450/550 XL/XLT * 2013-2016
F-250/350/450/550 (with NAV) 2011-2012
F-650/750 * 2016-up
Focus 2008-2011
Fusion 2010-2012
Mustang 2009-2014
Taurus 2010-2012
LINCOLN
MKX 2007-2010
MKZ 2007-2009
Navigator 2007-2014
MAZDA
Tribute 2008-2011
MERCURY
Mariner 2008-2011
Milan 2010-2011
Mountaineer (with NAV) 2009-2010
* With AM/FM/CD radio
3
REV. 6/26/2018 INSTAX-ADFD01
CONNECTIONS TO BE MADE (CONT.)
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire
• Tape off and disregard the following (4) wires, they will not be used in this application:
Green, Green/Black, Purple, Purple/Black
From the AX-ADFD01 harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• If installing either an ASWC-1 or AX-LCD (both sold separately), connect the (2) Red wires
to accessory power.
• Connect the Blue wire to the power antenna wire.
• Tape off and disregard the Blue/White wire with a red connector, it will not be used in
this application.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative output.
• If the vehicle is equipped with satellite radio or SYNC, and desired to be retained, connect
the Red and White RCA jacks labeled “RSE/SYNC/SAT” to the audio AUX-IN jacks.
Note: Most Ford radios have satellite radio built into the radio, so this feature is lost if so.
• If the vehicle is equipped without SYNC, and the AUX-IN jack is desired to be retained,
connect the Red and White RCA jacks labeled “FROM 3.5” to the audio AUX-IN jacks.
• If the vehicle is equipped with a factory subwoofer, connect the White RCA jack labeled
“SUBWOOFER” to the subwoofer out jack.
•
Disregard the Red RCA jack labeled “CENTER CHANNEL”, it will not be used in this application
.
12-pin pre-wired ASWC-1 harness:
This harness is to be used along with the optional ASWC-1 (sold separately) to retain steering
wheel audio controls. If the ASWC-1 is not being used, disregard this harness. If the ASWC-1
will be used, please refer to the ASWC-1 instructions for radio connections and programming.
Disregard the harness that comes with the ASWC-1.
DIN jack:
The DIN jack is to be used with the optional AX-LCD (sold separately) to retain satellite radio or
SYNC information.
Continue to Installing & Programming the AX-ADFD01
4
CONNECTIONS TO BE MADE
Attention! This interface will work with models that are either non-amplified, or amplified.
Please follow the instructions carefully for your model vehicle. Failure to do so will result in
either no sound, or low sound. If you are unsure if your vehicle is factory amplified or not, please
contact your local dealership.
For models
with
a Sony/THX amplifier:
From the 16-pin harness with stripped leads to the aftermarket radio (harness included with interface):
• Connect the Red wire to the accessory wire.
Note: If installing either an ASWC-1 or AX-LCD (both sold separately), connect the (2) Red
wires on the AX-ADFD01 harness as well.
• Connect the Blue/White wire to the amp turn on wire. This wire must be connected to
hear sound from the factory amplifier.
Note: If the vehicle is equipped with NAV, there will be an amp turn-on wire on the AX-
ADFD01 harness to connect as well.
• If the aftermarket radio has an illumination wire, connect the Orange/White wire to it.
• If the aftermarket radio has a mute wire and the vehicle is equipped with SYNC, connect
the Brown wire to it. If the mute wire is not connected, the radio will turn off when SYNC
is activated.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative output.
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire
From the AX-ADFD01 harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• If installing either an ASWC-1 or AX-LCD (both sold separately), connect the (2) Red wires
to accessory power.
• Connect the Blue wire to the power antenna wire.
• For NAV models only: Connect the Blue/White wire with a red connector to the amp turn
on wire. This wire must be connected to hear sound from the factory amplifier.
• If the vehicle is equipped with satellite radio or SYNC, and desired to be retained, connect
the Red and White RCA jacks labeled “RSE/SYNC/SAT” to the audio AUX-IN jacks.
Note: Most Ford radios have satellite radio built into the radio, so this feature is lost if so.
Continued on the next page
5
REV. 6/26/2018 INSTAX-ADFD01
Attention! The AX-ADFD01 will work with both the AX-ADBOX1 and AX-ADBOX2 interfaces,
but programming will be different. Refer to the proper page for whichever interface is being
used. Also note, the programming instructions for the AX-ADBOX2 reflect gen. 2. If installing a
gen. 1 AX-ADBOX2, refer to the AX-ADBOX1 programming instructions. Gen. 2 interfaces can be
distinguished by a blue reset button between the (2) connectors.
AX-ADBOX1
Installing the AX-ADFD01
With the key in the off position:
•
Connect the 16-pin harness with stripped leads, and the AX-ADFD01 harness, into the interface
.
• Connect the AX-ADFD01 harness to the wiring harness in the vehicle.
• If an ASWC-1 (sold separately) will be used, do not connect it until the AX-ADFD01 is
programmed and fully functional.
Programming the AX-ADFD01
Attention! If the interface ever loses power, the following steps will need to be performed
again. Please ensure that the owner of the vehicle knows this.
•
Turn the key (or push-to-start button) to the ignition position and wait until the radio comes on
.
Note: If the radio doesn’t not come on within 60 seconds, turn the key to the off position,
disconnect the interface, check all connections, reconnect the interface, and then try again
.
• Turn the key (or push-to-start button) to the off position, then to the accessory position.
Test all functions of the installation for proper operation, before reassembling the dash.
Continue to Adjusting the AX-ADFD01
INSTALLING & PROGRAMMING
THE AX-ADFD01
CONNECTIONS TO BE MADE
(CONT.)
• If the vehicle is equipped without SYNC, and the AUX-IN jack is desired to be retained,
connect the Red and White RCA jacks labeled “FROM 3.5” to the audio AUX-IN jacks.
• The DIN jack is to be used with the optional AX-LCD (sold separately) to retain SYNC
information.
• Connect the Red wire to accessory power.
• Connect the White RCA jack labeled “SUBWOOFER” to the subwoofer out jack.
• Connect the Red RCA jack labeled “CENTER CHANNEL” to the center channel out jack on the
radio/processor.
Note: If this jack is not present on the aftermarket radio, just leave be. Only the center
channel speaker will be lost.
• Tape off and disregard the following (4) wires, they will not be used in this application:
Green, Green/Black, Purple, Purple/Black
12-pin pre-wired ASWC-1 harness:
This harness is to be used along with the optional ASWC-1 (sold separately) to retain steering
wheel audio controls. If the ASWC-1 is not being used, disregard this harness. If the ASWC-1
will be used, please refer to the ASWC-1 instructions for radio connections and programming.
Disregard the harness that comes with the ASWC-1.
DIN jack:
The DIN jack is to be used with the optional AX-LCD (sold separately) to retain satellite radio or
SYNC information.
Continue to Installing & Programming the AX-ADFD01
