Axor 28496xx1 User Manual
Installation Instructions / Warranty
Clubmaster
28496XX1
Clubmaster Showerhead
28496XX1
Technical Data:
Recommended water pressure 45-60 PSI
Max. water pressure 90 PSI
Max. flow rate 2.5 GPM
Installation Considerations:
This showerhead includes a self-sealing filter gasket. The filter gasket makes Teflon tape
•
unnecessary in most installations.
This showerhead includes a decorative rubber boot to cover the connection between the
•
showerhead and the showerarm. Use of the boot is optional.
If you notice a gradual decrease in flow over time, remove the Clubmaster™ from the
•
showerarm and clean the filter gasket of any debris that may have accumulated.
Quiclean™ pins automatically dislodge scale deposits from the shower channels when
•
the spray mode is changed.
In Massachusetts, the maximum output temperature of the shower valve can be no higher
•
than 112° F.
2
Installation
With 27438XX1 short cast showerarm:
Shorten the gray rubber boot before installation
(1).
Screw the showerhead to the showerarm by hand.
Finish tightening with a 17 mm wrench (2).
With 27411 showerarm:
Slide the boot onto the showerarm (1).
Screw the showerhead to the arm by hand, then
finish tightening with a 17 mm wrench (2).
Pull the boot down to cover the joint (3).
User Instructions
To change spray modes:
Turn the face ring in the direction of the arrows to
obtain the desired function: clockwise for soft aerated
spray, counter-clockwise for massage.
There is no "front and center" indexing position on the Clubmaster™.
3
