Vertical Broiler
VB-4
18
1
2
3
7
9
8
4
5
10
11
6
28
1516
B
20
C
D
14
19
13
12
PAGE 1
23
22
rev:20151104.1
8859.00GD4.00.001.00.0
21 16 15 201718
A
Vertical Broiler
VB-3
1
2
3
7
9
B
4
10
C
11
5
D
19 14 13 12
PAGE 3
23
22
6
8
28
ACCPAC N0. NAME QTY.
81-V301 1 #2859.D30.GR030.01 ROTISSERIE MOTOR 110V 1
81-V001 2 #6254.00005.05 SWITCH 1
81-V002 #6267.00008.18 CABLE RECORD 1
81-V304 3 #2859.D20.01700146.7.12 HEAT PROTECTION PLATE 1
81-V305 5 #2859.D30.GR001.01 UPPER FIXING SCREW 1
81-V376 6 #2859.D30.GR003.01 BOTTOM FIXING SCREW 1
81-V372 7 #2KLP.460.680200004.00 SKEWER 736 mm 1
81-V377 8 #2859.D30.GR031.01 LOWER DISK 250MM 1
81-V374 9 #6260.00859.00 PIN 1
81-V032 10 #2859.D30.GR006.01 STAINLESS STEEL GRILL 210*130 DRB 1
81-V031 11 #2859.D30.GR005.01 STAINLESS STEEL GRILL 210*160 DRB 1
81-V014 12 #6260.00015.18 GAS VALVE KNOB FOR VB-3,4 1
81-VGV 13 #9PEL.10109.40 GAS VALVE FOR VB-3,4 PEL205 1
81-V069 14 #6267.00005.110 THERMOCOUPLE M8*1 FOR VB-3,4 1
81-V017 15 #6802.00001.110 DUAL BURNER 1
81-V379 16 #2KLP.460.5Y1X0E093.00 ORIFICE FOR VB SERIES 0.80MM PROPANE 1
81-V378 #2KLP.460.5Y1X0E135.00 ORIFICE FOR VB SERIES 1.30MM NG 1
81-V317 17 #2KLP.460.680200001.11 CERAMIC BURNER CONNECTOR 1
81-V003 18 #2KLP.460.680200001.120 SCREW RADIANS RECORD 1
81-V004 19 #2KLP.460.5Y1X50000.50 INTERM PROPANE GAS COUPLING 3/8'' 1
81-V080 20 #2859.M0007.02 GAS PIPE 1
81-V021 21 #6204.00006.01 CABLE HOLDER 1
81-V005 #6267.00006.90 INJECTOR BY-PASS 1,00 MM 1
81-V006 #6267.00006.93 INJECTOR BY-PASS 0,65 MM 1
81-VB22 22 #0859.S0008.00 OCTANGULAR GREASE PAN 1
81-VB23 23 #6802.00001.112 OCTANGULAR GREASE FILTER 1
81-VB24 28 #6267.00029.00 PIEZO IGNITOR 1
81-VB30 #6267.00031.20 IGNITER CABLE (ELECTRODE + PIEZO CABLE) 1
81-V007 #9OZT.18AWG.00 18AWG CABLE 1
81-V373 Skewer
