Axis T90D20 PoE IR-LED, T90D30 IR-LED, T90D25 W-LED, T90D25 PoE W-LED, T90D35 W-LED User Manual

AXIST90DIlluminatorSeries

AXIST90D20IR-LED

AXIST90D20PoEIR-LED

AXIST90D25W-LED

AXIST90D25PoEW-LED

AXIST90D30IR-LED

AXIST90D30PoEIR-LED

AXIST90D35W-LED

AXIST90D35PoEW-LED

AXIST90D40IR-LED

UserManual

AXIST90DIlluminatorSeries

TableofContents

Eyesafetyinformation.......................................3

Aboutthismanual..........................................4

Productoverview...........................................5

Productoverview................................................5

Remotecontrol.................................................6

Howtocongurethewires(onlyforAC/DCversions)..................6

Setup.....................................................8

Aboutthefactorydefaultsettings..................................8

Aboutoperatingandprogrammingmode............................8

AboutusingaPIN...............................................9

Howtodisablethecontrolbuttons.................................10

Howtore-enablethecontrolbuttons...............................10

HowtocontroltheilluminatorwithanAxisnetworkcamera............10

Howtoadjustthelightintensity...................................11

Howtoadjustthephotocellsensitivity..............................12

HowtoenableordisabletheLEDindicators..........................13

Howtoresettofactorydefaultsettings.........................14

Troubleshooting............................................15

Specications..............................................16

LEDIndicators..................................................16

2

AXIST90DIlluminatorSeries

Eyesafetyinformation

Eyesafetyinformation

CAUTION

IRvariants:

IRemittedfromthisproduct,EN62471RiskGroup2.Donotstareatthelamp.Avoidexposureoruseappropriateshielding
oreyeprotection.RiskGroup2forcornea/lensinfraredhazard.ForT90D20andT90D30variantsthehazarddistanceis
1500mm.ForT90D40thehazarddistanceis1840mm.MaxIRExposureHazardValue:69%ofRiskGroup2Limitat200
mmfromthelamp.

CAUTION

Whitelightvariants:

EN62471RiskGroup2.Possiblehazardousopticalradiationemittedfromthisproduct.Maybeharmfultoeyes.Donot
stareatthelamp.ForT90D25andT90D35variantsthehazarddistanceis1500mm.MaxwhitelightExposureHazard
Value:68%ofRiskGroup2Limitat200mmfromthelamp.

3

AXIST90DIlluminatorSeries

Aboutthismanual

Aboutthismanual

Thisusermanualdescribesmultipleproducts.Someoftheinstructionsmaynotberelevantforyourproduct.

4

AXIST90DIlluminatorSeries

Productoverview

Productoverview

Productoverview

Note

Theappearanceofyourproductmaydifferfromthefollowingimages.

1

Photocell

2

Power,photocellandtelemetryforAC/DCversionsornetworkcableforPoEversions

3

Breathergland

Wireconguration(AC/DCversionsonly)

1

Powerwire(red)

2

Powerwire(black)

3

Photocellwire(white)

4

Photocellwire(yellow)

5

Telemetrywire(purple)

6

Telemetrywire(orange)

5

AXIST90DIlluminatorSeries

Productoverview

1

Mountingbracket(pre-mounted)

2

Controlbutton(left)

3

LeftHandSideLED(LHS)

4

RightHandSideLED(RHS)

5

Controlbutton(right)

Thebaseplatemustberemovedinordertoaccessthetwocontrolbuttons.

Remotecontrol

Note

Theremotecontrolisanoptionalaccessory.

1

Powerlevelbuttons

2

Photocellsensitivitybuttons

3

Timerbuttons

4

Photocelldisablebutton

5

Telemetrydimmingbutton

6

Resetbutton

7

StatusbuttonforLEDandPIN

8

Disableremotecontrolsetupbutton

9

Telemetryinputbutton

Howtocongurethewires(onlyforAC/DCversions)

Connectthepowerwires(redandblack)toapowersourceequipment.Formoreinformation,seetheInstallationGuide.

6
