Axis P7214 Installation Guide

INSTALLATION GUIDE

AXIS P7214 Video Encoder

ENGLISH DEUTSCH

FRAN

Ç
AIS

ITALIANO

ESPAÑOL

About this Document

Korea -

ࢇЕɼࢽࡈ%ࢷ࢕ળࢶଢԻ۰

࣯Իɼࢽ߾۰یࡈଜЕʨࡶּࢶࡳԻଜֲֻҘ
ࠇ߾۰یࡈଟܹ࢑ݡТЬࢶࢸ஢ࢻѹ673
VKLHOGHGWZLVWHGSDLUৼࢇٴࡶیࡈଜࠆࢿ૽
ࡶࠉʼଜݫݤࠝ

Japan -

この装置は、クラスB情報技術装置です。
この装置は、家庭環境で使用することを目的として
いますが、この装置がラジオやテレビジョン受信機
に近接して使用されると、受信障害を引き起こすこ
とがあります。取扱説明書に従って正しい取り扱い
をして下さい。本製品は、シールドネットワーク
ケーブル(STP)を使用して接続してください。また
適切に接地してください。

This document includes instructions for installing AXIS
P7214 on your network. Previous experience of networking
will be beneficial when installing the product.

Legal Considerations

Video and audio surveillance can be prohibited by laws that
vary from country to country. Check the laws in your local
region before using this product for surveillance purposes.
This product includes one (1) H.264 decoder license. To
purchase further licenses, contact your reseller.

Liability

Every care has been taken in the preparation of this
document. Please inform your local Axis office of any
inaccuracies or omissions. Axis Communications AB cannot
be held responsible for any technical or typographical errors
and reserves the right to make changes to the product and
documentation without prior notice. Axis Communications
AB makes no warranty of any kind with regard to the
material contained within this document, including, but not
limited to, the implied warranties of merchantability and
fitness for a particular purpose. Axis Communications AB
shall not be liable nor responsible for incidental or
consequential damages in connection with the furnishing,
performance or use of this material. This product is only to
be used for its intended purpose.

Intellectual Property Rights

Axis AB has intellectual property rights relating to
technology embodied in the product described in this
document. In particular, and without limitation, these
intellectual property rights may include one or more of the
patents listed at www.axis.com/patent.htm and one or more
additional patents or pending patent applications in the US
and other countries. This product contains licensed
third-party software. See the menu item “About” in the
product’s user interface for more information. This product
contains source code copyright Apple Computer, Inc., under
the terms of Apple Public Source License 2.0 (see
www.opensource.apple.com/apsl). The source code is
available from https://developer.apple.com/bonjour/

Equipment Modifications

This equipment must be installed and used in strict
accordance with the instructions given in the user
documentation. This equipment contains no
user-serviceable components. Unauthorized equipment
changes or modifications will invalidate all applicable
regulatory certifications and approvals.

Trademark Acknowledgments

Apple, Boa, Bonjour, Ethernet, Internet Explorer, Linux,
Microsoft, Mozilla, Real, SMPTE, QuickTime, UNIX, Windows,
Windows Vista and WWW are registered trademarks of the
respective holders. Java and all Java-based trademarks and
logos are trademarks or registered trademarks of Oracle
and/or its affiliates. UPnPTM is a certification mark of the
UPnPTM Implementers Corporation.

Regulatory Information

Electromagnetic Compatibility (EMC)

This equipment has been designed and tested to fulfill
applicable standards for:

• Radio frequency emission when installed according to the
instructions and used in its intended environment.

• Immunity to electrical and electromagnetic phenomena
when installed according to the instructions and used in
its intended environment.

USA - This equipment has been tested using a shielded

network cable (STP) and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and
receiver.

• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician
for help.

To be used in a residential area or a demanding electrical
environment, the product shall be connected using a
shielded network cable (STP) that is properly grounded.

Canada - This digital apparatus complies with CAN ICES-3

(Class B). The product shall be connected using a shielded
network cable (STP) that is properly grounded.

Cet appareil numérique est conforme à la norme CAN
NMB-3 (classe B). Le produit doit être connecté à l'aide d'un
câble réseau blindé (STP) qui est correctement mis à la terre.

Europe - This digital equipment fulfills the

requirements for RF emission according to the Class B limit
of EN 55022. The product shall be connected using a
shielded network cable (STP) that is properly grounded.

Australia - This digital equipment fulfills the

requirements for RF emission according to the Class B limit
of AS/NZS CISPR 22. The product shall be connected using a
shielded network cable (STP) that is properly grounded.

Safety

This product complies with EN/IEC/UL 60950-1, Safety of
Information Technology Equipment. The power supply used
with this product shall fulfill the requirements for Safety
Extra Low Voltage (SELV) and Limited Power Source (LPS)
according to EN/IEC/UL 60950-1.

Disposal and Recycling

When this product has reached the end of its useful life,
dispose of it according to local raws and regulations. For
information about your nearest designated collection point,
contact your local authority responsible for waste disposal.
In accordance with local legislation, penalties may be

applicable for incorrect disposal of this waste.

Europe

This symbol means that the product shall not be
disposed of together with household or
commercial waste. Directive 2012/19/EU on waste
electrical and electronic equipment (WEEE) is
applicable in the European Union member states.
To prevent potential harm to human health and the
environment, the product must be disposed of in an
approved and environmentally safe recycling process. For
information about your nearest designated collection point,
contact your local authority responsible for waste disposal.
Businesses should contact the product supplier for
information about how to dispose of this product correctly.
This product complies with the requirements of Directive
2011/65/EU on the restriction of the use of certain
hazardous substances in electrical and electronic equipment
(RoHS).

China

This product complies with the requirements of the
legislative act Administration on the Control of
Pollution Caused by Electronic Information
Products (ACPEIP).

Contact Information

Axis Communications AB
Emdalavägen 14
223 69 Lund
Sweden
Tel: [phone]
Fax: [phone]
www.axis.com

Support

Should you require any technical assistance, please contact
your Axis reseller. If your questions cannot be answered
immediately, your reseller will forward your queries through
the appropriate channels to ensure a rapid response. If you
are connected to the Internet, you can:

• download user documentation and software updates

• find answers to resolved problems in the FAQ database.
Search by product, category, or phrase

• report problems to Axis support staff by logging in to your
private support area

• chat with Axis support staff (selected countries only)

• visit Axis Support at www.axis.com/techsup/

Learn More!

Visit Axis learning center www.axis.com/academy/ for
useful trainings, webinars, tutorials and guides.

Safeguards

Please read through this Installation Guide carefully before installing the Axis product. Keep the
Installation Guide for further reference.

• Store the Axis product in a dry and ventilated environment.

• Avoid exposing the Axis product to vibration, shocks or heavy pressure. Do not install the
product on unstable brackets, unstable or vibrating surfaces or walls, since this could cause
damage to the product.

• Only use applicable tools when installing the Axis product; excessive force could cause
damage to the product.

• Do not use chemicals, caustic agents, or aerosol cleaners. Use a damp cloth for cleaning.

• Use only accessories that comply with technical specification of the product. These can be
provided by Axis or a third party.

• Use only spare parts provided by or recommended by Axis.

• Do not attempt to repair the product by yourself, contact Axis or your Axis reseller for ser­vice matters.

• This Axis product shall be used in compliance with local laws and regulations.

Transportation

• When transporting the Axis product, use the original packaging or equivalent to prevent
damage to the product.

ENGLISH

Battery Replacement

This Axis product uses a 3.0 V CR2032 lithium battery as the power supply for its internal real-time
clock (RTC). Under normal conditions this battery will last for a minimum of 5 years. Low battery
power affects the operation of the RTC, causing it to reset at every power-up. A log message will
appear when the battery needs replacing. The battery should not be replaced unless required!

If the battery does need replacing, please contact www.axis.com/techsup for assistance.

• Dispose of used batteries according to the manufacturer's instructions.

• Risk of explosion if battery is incorrectly replaced.

• Replace only with the same or equivalent battery, as recommended by the manufacturer.

AXIS P7214 Installation Guide Page 5

AXIS P7214 Video Encoder

Installation Guide

This installation guide provides instructions for installing a AXIS P7214 video encoder on your
network. For other aspects of using the product, see the User Manual available at www.axis.com

Installation steps

Follow these steps to install the AXIS P7214 on your local network (LAN):

1. Check the package contents against the list below.

2. Hardware overview. See page 6.

3. Install the hardware. See page 6.

4. Access the video stream. See page 7.

Package contents

Item Models/variants/notes

Axis video encoder models AXIS P7214
Power adapter models Type PS-K
Mounting kit • 4 screws and 4 plugs to mount the encoder to a concrete wall

Printed Materials AXIS P7214 Installation Guide (this document)

• 4 Surface protection pads

• Terminal block connectors (I/O: 6-pin connector, RS485/RS422:
2 x 2-pin connector)

ENGLISH

Page 6 AXIS P7214 Installation Guide

Mounting holes

power, status, network

LED indicators for

Power connector

RS485/RS422 connector

Network connector (PoE)

Control button

I/O connector

microSD memory
card slot

Video input connectors

Front view Rear view

2

3

4

1

IN 1 IN 2 OUT 1

Audio input 1

Audio output 1

Audio input 2

Front view

Hardware overview

AXIS P7214

Dimensions

AXIS P7214

Install the hardware

Important!

The casing of the AXIS P7214 is not approved for outdoor use - the product may only be installed in
indoor environments.

Notes:

• The AXIS P7214 can be placed on a flat surface or mounted. See below for mounting instructions.

• Punch out the protective pads and stick them to the underside of the video encoder to prevent scratches on
the surface where the video encoder is placed.

Mount the video encoder

The video encoder is supplied with a mounting kit containing screws and plugs for mounting the
video encoder on a concrete wall:

1. Place the video encoder against the wall, and mark the four mounting holes (see image on
page 6).

HxWxD = 37x109x172
Weight = 570g (1.26 lbs)

AXIS P7214 Installation Guide Page 7

2. Drill the four mounting holes.

3. Insert the provided wall plugs into the wall, and attach it to the wall using the screws provided.

Connect the cables

1. Connect the encoder to the network using shielded network cables. If using PoE see note below.

2. Optionally connect external input/output devices, e.g. alarm devices. See page 8 for information
on the terminal connector pins.

3. Optionally connect active speakers and/or external microphones.

4. Connect the cameras to the video inputs.

5. If powering the unit with DC input, connect the supplied indoor power adapter or an external
power supply. See note below.

6. Check that the indicator LEDs indicate the correct conditions. See the table on page 10 for
further details.

The unit can be powered using either the DC power input or PoE (Power over Ethernet). If powering the

Note:

unit using DC power, connect the power supply to the power connector at the rear of
the unit. If powering the unit using PoE, connect a PoE network cable.

Access the product

AXIS IP Utility and AXIS Camera Management are recommended methods for finding Axis products
on the network and assigning them IP addresses in Windows®. Both applications are free and can
be downloaded from www.axis.com/techsup

The product can be used with most operating systems and browsers. The recommended browsers
are

• Internet Explorer® with Windows®

• Safari® with OS X® and

• ChromeTM or Firefox® with other operating systems.

For more information about using the product, see the User Manual available at www.axis.com

ENGLISH

Page 8 AXIS P7214 Installation Guide

1

2

123

Unit connectors

Network connector - RJ45 Ethernet connector. Supports Power over Ethernet (PoE) Class 3 - max

12.95W. Using shielded cables is recommended.

Power input connector - 2-pin terminal block used for power input from the
supplied power adapter or an external power supply.

The external power supply alternatives are:

1. The Axis delivered PS-K P/N 34987.

2. An external 8-20 V DC limited power source with a maximum output current of
5A.

Function Pin number Description

GND 1 Ground
DC Power 2 Power input 8-20 V DC

max 8W

Audio in/out - Two 3.5 mm jacks for audio input, and one 3.5 mm jack for audio output. Stereo
plugs must be used.

• Audio Input 1, 2: Microphone or line level inputs (mono). A selectable 2.0V, 2.5V or 3.0V
microphone bias is available.

• Audio Output 1: Line level audio output (mono), that can be connected to a public
address (PA) system or an active speaker with a built-in amplifier.

Audio Input 1, Audio Input 2 Audio Output 1

1 Tip Microphone/Line in Line out (mono)
2 Ring
3 Sleeve GND GND

AXIS P7214 Installation Guide Page 9

I/O terminal connector - Used in applications for e.g. motion
detection, event triggering, time lapse recording and alarm
notifications. In addition to an auxiliary power and a GND pin, the
AXIS P7214 has 4 pins that can be configured as either input or
output. These pins provide the interface to:

• Transistor output - For connecting external devices
such as relays and LEDs. Connected devices can be activated by AXIS VAPIX API, output
buttons on the Live View page or by an Event Type. The output will show as active
(shown under Event Configuration > Port Status) if the alarm device is activated.

• Digital input - An alarm input for connecting devices that can toggle between an open
and closed circuit, for example: PIRs, door/window contacts, and glass break detectors.
When a signal is received the state changes and the input becomes active (shown
under Event Configuration > Port Status.).

Function Pin Notes Specifications

GND 1 Ground

3.3 VDC
Power output

Configurable
(Input or
Output)

2 Can be used to power auxiliary equipment. Max load = 250mA

3 - 6 Digital input - Connect to GND to activate, or

leave floating (or unconnected) to deactivate.
Digital output - Internal connection to ground

when activated, floating (unconnected) when
deactivated. If used with an external relay, a
diode must be connected in parallel with the
load, for protection against voltage transients.

0 to + 40V DC

Max load = 100mA
Max voltage = + 40V DC

ENGLISH

Page 10 AXIS P7214 Installation Guide

RS-485/422

RX/TX

1 2 3 4

T X

RS485/RS422 connector - Two 2-pin terminal blocks for RS485/RS422 serial interface used to
control auxiliary equipment, e.g. PTZ devices.

The RS485/RS422 serial port can be configured to support:

RS-485/422

• Two-wire RS485 half duplex

• Four-wire RS485 full duplex

• Two-wire RS422 simplex

• Four-wire RS422 full duplex point to point communication

Function Pin Notes

RS485/RS422 RX/TX A 1 (RX) For full duplex RS485/RS422
RS485/RS422 RX/TX B 2
RS485/RS422 TX A 3 (TX) For full duplex RS485/RS422
RS485/RS422 TX B 4

(RX/TX) For half duplex RS485

RX/TX

microSD memory card slot - The microSD memory card can be used for local recording with
removable storage.

BNC connector - Connect a 75 ohm coaxial video cable (max. length 800 feet (250 meters)).

For each video input 75 Ohm video termination can be enabled/disabled via the product's web page at

Note:

Video & Audio > Video Input > Video termination. These terminations are enabled on factory default.
In cases where the product is to be connected in parallel with other equipment, for optimum video
quality, it is recommended that termination be enabled for only the last device in the video signal
chain.

LED indicators

LED Color Indication

Network Green Steady for connection to a 100 Mbit/s network. Flashes for network activity.

Amber Steady for connection to 10 Mbit/s network. Flashes for network activity.
Unlit No network connection.

Status Green Steady green for normal operation.

Amber Steady during startup, during reset to factory default or when restoring settings.
Red Slow flash for failed upgrade.

Power Green Normal operation.

Amber Flashes green/amber during firmware upgrade.

AXIS P7214 Installation Guide Page 11

Tip!

Visit www.axis.com/techsup to check if there is updated firmware available for your AXIS
P7214. To see the currently installed firmware version, see the About web page.

Resetting to the factory default settings

This will reset all parameters, including the IP address, to the Factory Default settings:

1. Disconnect the power from the AXIS P7214, or if PoE is used disconnect the network cable.

2. Press and hold the Control button and reconnect power or the network cable if PoE is used.

3. Keep the Control button pressed until the Status indicator displays amber (this may take up to
15 seconds).

4. Release the Control button. When the Status indicator displays green (which can take up to 1
minute) the process is complete and the video encoder has been reset.

5. Re-assign the IP address, using one of the methods described in this document.

It is also possible to reset parameters to the original factory default settings via the web interface.
For more information, please see the online help or the user’s manual.

Further information

The user’s manual is available from the Axis Web site at www.axis.com

Warranty

For information about Axis' product warranty and thereto related information, please see
www.axis.com/warranty

ENGLISH

Page 12 AXIS P7214 Installation Guide

Mesures de sécurité

Lisez attentivement le présent Guide d’installation avant d'installer le produit Axis. Conservez le
Guide d’installation pour une utilisation ultérieure.

• Conservez le produit Axis dans un environnement sec et aéré.

• Évitez d'exposer le produit Axis aux vibrations, aux chocs ou à une forte pression.

N'installez pas le produit sur un support instable, ou des surfaces ou des murs instables ou
vibrants, car cela pourrait l'endommager.

• N'utilisez que les outils applicables pour installer le produit Axis ; une force excessive

pourrait endommager le produit.

• Pour le nettoyage, n’utilisez ni produits chimiques, ni substances caustiques ou aérosols.

Utilisez un chiffon humide pour le nettoyage.

• N’utilisez que des accessoires conformes aux caractéristiques techniques du produit. Ceux-

ci peuvent être fournis par Axis ou par un fournisseur tiers.

• Utilisez uniquement des pièces de rechange fournies ou recommandées par Axis.

• Ne tentez pas de réparer le produit vous-même, contactez Axis ou votre revendeur Axis

pour toute réparation.

• Ce produit Axis doit être utilisé conformément aux lois et réglementations locales en

vigueur.

Transport

FRAN

Ç
AIS

• Pour transporter le produit Axis et éviter de l'endommager, utilisez l'emballage d'origine ou

un emballage équivalent.

Remplacement des piles

Ce produit Axis nécessite une pile au lithium CR2032 de 3,0 V pour l'alimentation de son horloge en
temps réel interne. Dans des conditions normales d'utilisation, cette pile est censée durer au moins
5 ans. Si la pile est faible, le fonctionnement de l'horloge en temps réel peut être affecté et
entraîner sa réinitialisation à chaque mise sous tension. Un message enregistré apparaît lorsque la
pile doit être remplacée. Ne remplacez la pile qu'en cas de nécessité !

Si la pile doit être remplacée, veuillez contacter www.axis.com/techsup pour obtenir de l’aide.

• Jetez les piles usagées conformément aux consignes du fabricant.

• Le remplacement incorrect de la pile peut entraîner un risque d'explosion.

• Remplacez la pile par une pile identique ou équivalente uniquement, en respectant les

recommandations du fabricant.

AXIS P7214 Guide d’installation Page 15

Important !

Ce produit doit être utilisé
conformément aux lois et
réglementations locales en
vigueur.

Encodeur vidéo AXIS P7214

Guide d’installation

Ce guide d’installation vous explique comment installer un système AXIS P7214 sur votre réseau. u.
Pour toute autre information relative à l’utilisation du produit, consultez le manuel de l’utilisateur
disponible sur le site www.axis.com

Procédure d’installation

Procédez comme suit pour installer l’AXIS P7214 sur votre réseau local :

1. Vérifiez le contenu de l’emballage par rapport à la liste ci-dessous.

2. Description du matériel. Reportez-vous à la page 16.

3. Installation du matériel. Reportez-vous à la page 17.

4. Accéder au flux vidéo. Reportez-vous à la page 18

Contenu de l’emballage

Élément Modèles/variantes/remarques

Modèles d’encodeur vidéo
Axis

Modèles d’adaptateur
secteur

Kit de montage • 4 vis et 4 chevilles pour monter l’encodeur sur un mur en béton

Documentation imprimée Guide d’installation AXIS P7214 (le présent document)

AXIS P7214

Type PS-K

• 4 patins de protection de surface

• Connecteurs pour terminaux (E/S : connecteur à 6 broches,
RS485/422 : connecteur 2x 2 broches, alimentation : connecteur
à 2 broches)

FRAN

Ç
AIS

Page 16 AXIS P7214 Guide d’installation

Trous de fixation

l’alimentation, l’état et le réseau

Témoins DEL pour

Connecteur d’alimentation

Connecteur RS485/RS422

Connecteur réseau (PoE)

Bouton de commande

Connecteur d’E/S

Logement de carte
mémoire flash

Connecteurs d’entrée vidéo

Vue de face Vue arrière

2

3

4

1

IN 1 IN 2 OUT 1

Entrée audio 1

Sortie audio 1

Entrée audio 2

Vue de face

Description du matériel

AXIS P7214

Dimensions

AXIS P7214

H x L x P = 37 x 109 x 172
Poids = 570g
