Axis F101-A XF P1367 Explosion-Protected Network Camera Manufacturer specific manual
F101-P1367-BD
Explosion Camera Proof Network Camera
Installation Manual
114309212018 F1XX SERIES
INSTALLATION REV-2A2
1
This pageintentionallyleft blank
114309212018 F1XX SERIES
INSTALLATION REV-2A2
2
Information in this document is subject to change without notice. All terms
October 1, 2018
UPDATE FM MARK
MARCH 12,2019
UPDATE CABLE TEMPERATURE REQUIREMENTS
JUNE 19, 2019
MARCH 14, 2020
MAY 11. 2020
mentioned in this manual that are known to be trademarks have been
appropriately capitalized. Spectrum Camera Solutions LLC acknowledges
all trademark(s) and the rights of the trademark(s) owned by the company
referred to herein.
Release Date: 11/01/2018
Document Name F101-P1367-BD INSTALLATION MANUAL
© Copyright 2018 by Spectrum Camera Solutions LLC All rights
reserved
Revision Record
Rev. Description Date
1 Initial Release
2
2A
2A1 UPDATED CERTIFICATE OF CONFORMANCE
2A2 UPDATED LABLES AND T CODES
114309212018 F1XX SERIES
INSTALLATION REV-2A2
3
Copyright Notice:
This document contains information proprietary to Spectrum Camera Solutions LLC
with all rights reserved worldwide. Any reproduction or disclosure of this publication,
or any part thereof, to persons other than Spectrum Camera Solutions, Inc.
personnel or customers is strictly prohibited, except by written permission of
Spectrum Camera Solutions, Inc. Unauthorized use, disclosure, reproduction, or
translation of this publication will result in Spectrum Camera Solutions, Inc.
exercising maximum possible legal action against all persons and / or organizations
involved.
Disclaimer:
Spectrum Camera Solutions LLC makes no representations or warranties with
respect to the contents hereof. Further, Spectrum Camera Solutions LLC reserves
the right to revise this publication and to make changes in the content hereof, without
obligation to notify any person or organization of such revision or changes.
Patent Notice:
Manufactured under United States US Patent 9917428 & US Patent D858611
Trademark Information:
Spectrum Camera Solutions LLC and its logo(s) are trademark(s) of Spectrum
Camera Solutions LLC.
114309212018 F1XX SERIES
INSTALLATION REV-2A2
4
Table of Contents
Legal Notices and Revision History Inside front cover
DESCRIPTION 6
LABELS 7
STANDARDS AND CERTIFICATIONS 8
DOCUMENT SYMBOLS 9
HOW TO USE THIS MANUAL 10
GENERAL SAFETY AND OPERATING INFORMATION 11-13
Page
SPECIFICATIONS 14-15
INSTALLATION 16-27
HARDWARE BOM 28
DISMANTLING & MAINTENANCE 29
MOUNTING OPTIONS 30-35
114309212018 F1XX SERIES
INSTALLATION REV-2A2
5
DESCRIPTION
The F1xx Series includes a full range of powder-coated Aluminum camera stations specifically designed for Hazardous Area Applications. Spectrum’s F1xx Series is utilizes the most robust and advanced camera technologies available.
114309212018 F1XX SERIES
INSTALLATION REV-2A2
6
Labels
114309212018 F1XX
SERIES INSTALLATION
REV-2A2
7
STANDARDS & CERTIFICATIONS
STANDARDS-
The equipment is manufactured in accordance with the IECEX scheme, the ATEX Directive 2014/34/EU and
with the following standards :
IEC 60079-0:2011
IEC 60079-1:2014
IEC 60079-31:2013
IEC 60529:2013
EN 60079-0:2012 + A11:2013
EN 60079-1:2014
EN 60079-31:2014
EN 60529:1991 + A1:2000 + A2:2013
ANSI/ISA 60079-0:2013
ANSI/UL 60079-1:2015
ANSI/ISA 60079-31:2015
ANSI/IEC 60529:2004
CAN/CSA-C22.2 No. 60079-0:2015
CAN/CSA-C22.2 No. 60079-1:2016
CAN/CSA-C22.2 No. 60079-31:2015
CAN/CSA-C22.2 No. 60529:2016
Specific Conditions of Use:
-The flameproof joints of the equipment are not intended to be repaired. Consult the manufacturer if dimensional
information on the flameproof joints is necessary.
-Follow the manufacturer’s instructions to reduce the potential of an electrostatic charging hazard on the surface
of the equipment in Group II and III environments.
NOTE: Use a clean cloth dampened with pure water for cleaning.
CERTIFICATIONS-
CERT NO. FM18US0262X & FM18CA0126X
US: Class I Division 1 Groups BCD T5 Ta= -40°C to +60°C, Type 4X, IP66
Class II/III Division 1 Groups EFG Ta= -40°C to +60°C, Type 4X, IP66
Canada: Class I Division 1 Groups BCD T5 Ta= -50°C to +60°C, Type 4X, IP66
Class II/III Division 1 Groups EFG Ta= -50°C to +60°C, Type 4X, IP66
Class I, Zone 1, AEx/Ex db IIB+H2 T5 Gb Ta = -50°C to +60°C, Type 4X, IP66
Zone 21, AEx/Ex tb IIIC T85°C Db Ta = -50°C to +60°C, Type 4X, IP66
CERT NO. FM18ATEX0073X & IECEx FMG 18.0029X
II 2 G Ex db IIB+H2 T5 Gb Ta = -50°C to +60°C, IP66
II 2 D Ex tb IIIC T85°C Db Ta = -50°C to +60°C, IP66
114309212018 F1XX SERIES
INSTALLATION REV-2A2
8
DOCUMENT SYMBOLS
The following symbols are used throughout this manual to alert users to potential
hazards or important information. Failure to heed the warnings and cautions listed
herein can lead to injury and equipment damage.
Symbol Label Description
WARNING:
CAUTION:
Consists of conditions, practices, or procedures that
must be observed to prevent personal injury and/or
equipment damage.
Risk of electric shock or high temperature parts may
result in injury if proper precautions are not taken.
NOTE:
Emphasizes important or essential information.
Locating Information:
NOTE: In the interest of completeness, manuals and drawings included with
the system may provide information pertaining to options not included with
your equipment. Information in application notes supersedes general
information in these documents. Information can be located in this manual
using any of the following aids.
114309212018 F1XX SERIES
INSTALLATION REV-2A2
9
How to use this Manual
General Manual:
This manual is intended to be used in conjunction with installed equipment
manual from internal equipment manufacturer.
Note: In the event of a conflict between the requirements of this general
installation manual and the internal equipment manual, the safety and
installation procedures described in this manual shall take precedence.
Safety Considerations:
This information that must be read and understood by all persons installing,
using, or maintaining this equipment. This manual is designed to aid
personnel in the correct and safe installation, operation, and maintenance of
the systems described. Personnel must consider all actions and procedures
for potential hazards or conditions that may not have been anticipated in the
written procedures. If a procedure cannot be performed safely, it must not be
performed until appropriate actions can be taken to ensure the safety of
equipment and personnel. The procedures in this manual are not designed to
replace or supersede required or common sense safety practices. All safety
warnings listed in any documents applicable to equipment and parts used in
or with the system described in this manual must be read and heeded before
commencing work on any part of the system.
NOTE: Refer to all ATEX, CSA, IECEx, NEC, NFPA and FM certificates
for any Special Conditions of Use. If the sign “X” is placed after the
certificate number, it indicates that the equipment or protective
system is subject to special conditions for safe use specified in the
schedule of the certificate.
NOTE: Review all material and safety information in this manual and
install in accordance with this document and all other applicable
ATEX, CSA, IECEx, NEC, NFPA70 Installation Methods and FM and
National standards.
Warning- Failure to follow appropriate safety procedures or
appropriate use of the equipment described in this manual can lead to
injury of personnel or equipment damage.
WARNING – EXPLOSION HAZARD – Do not open equipment
unless power has been removed or the area is known to be nonhazardous.
114309212018 F1XX SERIES
INSTALLATION REV-2A2
10
General Safety and Operating Information:
General safety and operating information applicable to electrical equipment installed within
hazardous locations. This information must be understood by all persons installing, using, or
maintaining the electrical equipment. This information is designed to aid personnel in safe
installation, operation, and maintenance of the “F" Series equipment. It is not designed to replace or
limit appropriate safety measures applicable to work performed by personnel. Any additional safety
and operating measures that are required must be determined by and followed by personnel
performing work on the electrical equipment.
WARNING: Deviation from the specified instructions or procedure steps can result
in injury to personnel, equipment malfunction or equipment damage.
WARNING: Return unit to factory for any repairs or replacement of parts, customer
not permitted to repair. This will void all warranties and hazardous area
certification(s) if non-authorized repair occurs.
General Precautions:
Slip resistant gloves and protective eyewear (glasses with side shields or goggles as appropriate)
should be worn when installing and servicing any part of electrical equipment. Hot components
should be allowed to cool before servicing if possible. Other appropriate equipment or clothing must
be used as required by the type of work performed. All applicable regulations and procedures must
be followed for the work performed. Before beginning any work on the equipment, carefully consider
all the potential hazards and ensure that appropriate measures are taken to prevent injury to
personnel or equipment damage.
CAUTION: Electrical equipment components may be hot even when power is
not applied. Take appropriate precautions to prevent injury from contact with hot
items.
CAUTION: Failure to allow adequate cooling of electrical equipment components
with hot surfaces before opening the enclosure can lead to injury of personnel or
equipment damage.
114309212018 F1XX SERIES
INSTALLATION REV-2A2
11
