Axis AX-1330 User Manual [en, es, fr]
Pivot
Model: AX-1330
AXIS SHAVERS INSTRUCTION MANUAL
PLEASE READ DIRECTIONS COMPLETELY BEFORE USE.
AXIS/Bodyline Products International, Inc.
198 N. Brandon Drive
Glendale Heights, Illinois 60139 USA
Made in China
Congratulations!
You are now the proud owner of an
Axis Rechargeable/AC-powered
Shaver AX-1330.
Before using your shaver,
please read the instructions in this
manual carefully for its proper
use and care. Please keep the
manual handy for ready reference.
Axis Pivot |4| English
Axis Pivot |5| English
IMPORTANT SAFETY
INSTRUCTIONS
Before you start using your shaver, please review these basic
precautions that will aid in your use of this electrical device.
Please read all instructions before using your shaver.
DANGER
To minimize the risk of electric shock…
NEVER REACH for a shaver that has been dropped into water. Unplug
the unit immediately.
DO NOT USE your shaver while bathing or showering.
ALWAYS UNPLUG your shaver after use or prior to cleaning the unit,
except when charging the unit.
DO NOT PLACE OR STORE the shaver in water or any other liquid or
where it may accidentally fall or be pulled into water.
WARNING
To avoid burns, fire, electric shock or other injury…
1. Except when recharging your shaver, never leave the unit unattended when plugged in.
2. Always provide close adult supervision when using your shaver near
children or the disabled.
3. Follow all instructions in this manual carefully. Do not use attachments with your shaver that have not been specifically recommended
by Bodyline Products International Inc.
4. Do not use a unit that is not operating normally, has been immersed
in water or other liquid, or has a damaged cord or plug. Call 1-877-
Axis Pivot |6| English
Axis Pivot |7| English
263-9500 to arrange for service.
5. Never operate your shaver outdoors. Avoid use in the vicinity of
aerosol products or where oxygen is being administered. Also, keep
the cord away from heated surfaces.
6. When plugging in your shaver, first attach the cord to the unit and
then plug the cord into an electric outlet. When disconnecting, be sure
to switch the unit off, unplug the cord from the electric outlet and then
detach the cord from the shaver.
7. Do not insert foreign objects into any of the openings in the unit.
8. Never store the unit with the cord attached.
9. Store your shaver and power cord in a dry place.
10. Avoid exposing the unit to direct sunlight or ambient temperatures
above 140°F (60°C).
11. To avoid injury to the face, do not use the unit if the cutters or head
assembly have been damaged.
12. Never wrap the power cord around the unit. Damage to the power
cord may result.
13. This shaver is intended and designed for use on human facial hair only.
14. Never unplug or plug-in the shaver when your hands are moist or wet.
15. For home use only.
WASHABLE SHAVER
A shaving appliance the hand-held part of which
may be cleaned under water
16. Use only in dry condition
17. Do not submerge shaver into water.
18. The hand-held unit shall be detached from the power supply cord
Axis Pivot |8| English
Axis Pivot |9| English
before cleaning.
19. The shaver shall not be used until it has dried.
SAVE THESE INSTRUCTIONS
PRECAUTIONS ON USING THE SHAVER
> Do not keep the shaver in a humid place, a place where the shaver
is exposed to splashes of water, or in high temperatures.
> To clean the body case of the shaver, wipe it with a cloth soaked
with a diluted water solution of a neutral detergent. Do not use thinner or benzene as it will damage the plastic portions of the body.
> Do not recharge the shaver or use it with an AC power supply when
the room temperature is below 0° C or over 40° C. Also, never
recharge it under direct sunlight or near a heating element such as
heater or incandescent light.
> Do not recharge the shaver or use it with an AC power supply in a
humid place or a place where the shaver is exposed to splashes of
water.
> Do not leave the shaver unattended while it is recharged.
> If pre-shave lotion or shaver oil sticks to the body case of the
shaver, wipe it off completely. Otherwise, the plastic portions of the
shaver may be damaged.
> Before shaving, wipe off oiliness of your face. Otherwise, the shav-
ings will stick to the outer foil as the inner blade rubs against it. If
you find the outer foil soiled, wipe it clean with tissue paper or the
like before using the shaver.
> Excessive application of shaver oil will also soil the outer foil. In that
case, wipe the foil clean with tissue paper or the like before using
the shaver. When cleaning the shaver, take care not to apply an
excess amount of shaver oil on the inner blade and outer foil.
Axis Pivot |10| English
Axis Pivot |11| English
PARTS OF YOUR SHAVER
headguard
hairpocket
two foil
screens
center slot
trimmer
Accessories:
> Brush
> Travel pouch
> AC adaptor
headguard
hairpocket
center slot trimmer
two foil screens
dual inner cutters
cleaning brush
trimmer
AC adaptor
bottom view
socket
oscillator
hairpocket
release button
lock button
on/off switch
side panel
LED charging indicator
andlow battery indicator
Axis Pivot |12| English
Axis Pivot |13| English
Your shaver is designed and manufactured to exacting standards in
order to provide you with years of close, comfortable shaves.
It normally takes about three weeks for your skin to adjust to a new
electric shaver. As you use your shaver, you will develop a shaving style
that is most comfortable and effective for you. This “breaking in” period
may be somewhat longer for those with sensitive skin or those who
vary their shaving techniques. Upon unpacking your shaver, you may
notice a white/gray powder on the inner cutters and surface of the foil
screens.
This is a factory-applied lubricant that will help ease the breaking in
period and disappear with normal use.
Shaving Tips
1. Keep the unit clean and dry at all times.
2. Wash and dry your skin thoroughly prior to shaving.
3. In order to achieve the closest shave and avoid unnecessary wear
on the foils, be sure that both foils contact the skin simultaneously. Do
not hold the shaver at an angle where only one foil contacts the skin
— this will cause distortion of the foil and may result in skin irritation.
4. Stretch your skin with your free hand while using short, circular
strokes. This will make the hairs stand out from your face and allow the
cutting heads to reach them more easily. Shave against the grain for
optimum results.
5. To facilitate cutting and avoid foil wear, do not apply the shaver to
your skin with high pressure.
6. The normal replacement period for the foil screens is about 6
months. In order to maintain shaving performance and comfort,
replace the cutters at least once a year. To order replacement parts,
please refer to the “Ordering Replacement Parts” section of this
manual.
Axis Pivot |14| English
Axis Pivot |15| English
Using Your Shaver
1. Remove the protective plastic headguard.
2. Ensure that the foil screens and inner cutters are not damaged.
Replace damaged parts before using. To obtain replacement parts,
refer to the “Ordering Replacement Parts” section of this manual.
3. To turn the shaver on, depress the lock button and slide the on/off
switch up to the “on” position.
4. Gently stretch the skin of your face with your free hand while moving the shaver slowly and smoothly against the grain of your beard.
Hold the shaver at a 90° angle to your face while maintaining contact
with the foils.
5. To shave the chin area, gently pull the skin upward and stroke
the shaver in an easy up and down motion. To avoid damaging the
delicate foils, do not apply high pressure.
6. Turn shaver off and replace protective headguard.
To shave hard to reach/longer hairs, sideburns, mustaches
or beards:
The trimmer easily cuts the longer, hard to reach hairs of the face and
neck.
1. Slide the trimmer up into its locked position and stroke gently
against the hairs to be cut.
2. To trim sideburns, hold so that the trimmer lightly touches the skin at
a 90° angle and move downwards. To avoid draining the battery, keep
the trimmer in its off position when not in use.
Cleaning the Head and Cutter Assembly
Regular cleaning is necessary in order to maintain the optimal performance and maximum comfort from your shaver. Wipe the shaver’s
Axis Pivot |16| English
Axis Pivot |17| English
body using a damp cloth and mild soap or detergent. To avoid damag-
'JH
'JH
'JH
'JH
'JH
'JH
'JH
'JH
'JH
ing your shaver, do not use harsh cleansers or solvents.
Wet cleaning:
1. Switch the shaver off and ensure that the power cord is not attached. Depress the hairpocket release buttons on both sides of the
unit and gently lift the foil screen assembly off. (fig. 1)
2. Switch the shaver on and allow fresh cold or lukewarm water to run
over the cutters. (fig. 2)
3. When finished cleaning, switch the shaver off and replace the foil
screen assembly, making sure it
2
locks into place.
1
Using the cleaning brush:
3 4
1. Switch the shaver off and ensure
that the power cord is not attached.
Depress the hairpocket release buttons on both sides of the unit and
gently lift the foil screen assembly off. (fig. 1)
2. Gently brush the hairs from the inner cutters, the inside surface of
the foil screen assembly and the shaver’s case. (fig. 3) To remove the
inner cutters for cleaning, gently lift straight up from its mount. (fig. 4)
3. To clean the delicate outer foil screens, gently wipe the surface of
the foils with tissue paper, being sure not to apply a
great deal of pressure.
5
4. When finished cleaning, reseat the inner cutters
on the mounts and replace the hairpocket, making
sure it locks into place.
Axis Pivot |18| English
Axis Pivot |19| English
NOTE: to ensure proper operation, the outer foil frame assembly must
be properly seated. To avoid damaging the delicate foil screens, do not
remove them from their frame.
* To clean the trimmer, switch the shaver off and slide trimmer upwards
to deploy the trimmer. Gently brush the hairs from the trimmer blades.
(fig. 5)
* Your shaver should be cleaned with the brush provided after every
three wet cleanings.
* To avoid damage, be sure to thoroughly wipe pre-shave lotion or
shaver oil from the shaver’s body.
Worldwide Voltage
Your shaver features worldwide automatic dual voltage conversion
for 100-240 volt, 50-60 Hz AC current. You can plug the power/recharger cord into an electric outlet virtually anywhere in the world (an
adapter plug may be necessary) and the shaver will adjust automatically to the required voltage.
Recharging the Shaver
Your shaver features a green indicator light that flashes when recharging is needed, remains on while the shaver is charging, and turns off
when the shaver is fully charged. Use only the power/recharger cord
that came with the shaver. In addition, your shaver is designed to be
used while plugged into an electric outlet. The unit will not charge while
it is in use, so be sure to turn the unit off to allow charging when you
are finished shaving. Your shaver will provide a 3 minutes shave after 5
minutes of charging.
When using your shaver for the first time or has not been used for a
long time, charge the shaver for 16 hours.
1. Insure that the On/Off switch is in the “Off” position.
Axis Pivot |20| English
Axis Pivot |21| English
trimmer retainer
screw cover
screw
side panel
2. First, connect the power cord to the shaver and
then plug it into an electric outlet. The charging
indicator light will glow green to indicate that the
unit is charging normally. Recharging generally
takes one hour. When fully charged, your shaver
will provide approximately one week of shaving run
time.
Storing the Shaver and Power cord
If the shaver is to remain unused for a long period of time, store the
unit and power cord in a cool, dry place. Do not wrap the cord around
the unit during storage. Avoid twisting the power cord. Be sure to
unplug and untwist the cord if it becomes twisted during use or while
charging.
Removing the Batteries for Disposal/ Recycling
It is important that the rechargeable batteries in your shaver be
recycled or properly disposed of after it has reached the end of its
useful life.
Turn the On/Off Switch ON and
run the shaver until the inner
cutters stop.
1. Remove the headguard, hairpocket, and inner cutters.
2. Remove the trimmer retainer.
3. Remove the 3 screw covers
on the back of shaver. Remove 2
side panels.
4. Remove 3 screws on the back
of shaver.
5. Gently pull the two halves of the
shaver body apart. Be careful that
Axis Pivot |22| English
Axis Pivot |23| English
the component may jump out.
'JH
'JH
'JH
'JH
'JH
'JH
6. Pull the batteries out from the shaver.
7. Cut the wires that connect the batteries (2 wires for a battery) with
nippers.
WARNING! To avoid the risk of bursting and the subsequent release of
toxic materials, never mutilate or place the batteries in fire. To prevent
accidental burns, avoid short-circuiting the batteries. Dispose of batteries in accordance with local disposal /recycling requirements.
IMPORTANT! For best shaving performance and results, we recommend that you replace your shaver’s foil screens every six months and
inner cutters at least once a year.
To Replace Foil Screens
Skin irritation or a deterioration of shave quality typically indicates that
your foils need to be replaced. Replacement intervals will vary with
individual use and hair types.
7
8
1. Depress the hairpocket release
buttons on both sides of the shaver
and gently lift it off. (fig. 7)
2. Position the replacement head
assembly over the cutters. Be careful not to damage the foils. Gently
slide the head assembly down until it seats firmly into place. (fig. 8)
To Replace the Inner Cutters
NOTE: Always replace foil screens when replacing the inner cutters.
1. Remove the foil screen assembly by pressing
the release buttons on both sides of the shaver and
lifting the assembly off. (fig. 7)
2. Remove the inner cutters by grasping and lifting
upwards.(fig. 9)
9
Axis Pivot |24| English
Axis Pivot |25| English
3. Be sure to hold the replacement cutters firmly as you carefully insert
them into the inner cutter mounts.
4. Push the replacement cutters down firmly until they lock into place.
5. Replace the foil screen assembly and gently slide it down until you
hear it lock into place. (fig. 8)
Ordering replacement parts
Please contact Axis / BPI at 1-877-263-9500 to order replacement
parts for your Axis shaver. Please refer to the following part number.
AP-2 Replacement Outer Foil Frame and Inner Cutters for Model
AX-1330
> The above parts are available at the retailer from whom your shaver
was purchased.
If your shaver requires service:
Call Axis at 1-877-263-9500. To assist us in serving you, please have
the model number and date of purchase for your shaver available.
1-YEAR LIMITED WARRANTY
AXIS/Bodyline Products International, Inc. (BPI) warrants that your product,
except as noted below, is on the date of purchase free from defect in
material and workmanship for a period of one year. In the event of a defect
in material or workmanship, AXIS / BPI will repair or replace this product
with new parts, free of charge as follows:
1. The warranty is extended only to the original purchaser. A purchase
receipt or other proof of date of the original purchase is required for service
and parts replacement under this warranty.
2. Do not return the product to the retailer from whom this product was
purchased.
Axis Pivot |26| English
Axis Pivot |27| English
3. Contact AXIS/BPI toll-free at 1-877-263-9500 to obtain authorization
during the warranty period to return the defective product by mail, postage
prepaid.
LIMITATIONS AND EXCLUSIONS
There are no express warranties except as listed above.
This warranty only covers failures due to defects in materials or workmanship that occur during normal use. It does not cover foils, blades, cutters, or
attachments or damage that occurs in shipment, or failures that are caused
by products not supplied by AXIS / Bodyline Products International, Inc., or
failures that result from accident, misuse, abuse, and neglect from mishandling, misapplication, improper maintenance, improper cleaning, alteration,
modification, line power surge, or commercial use of the product, such as
hotel, office or rental use of the product, or service by anyone other than
AXIS / Bodyline Products International, Inc., or damage that is attributable
to acts of God.
AXIS / BODYLINE PRODUCTS INTERNATIONAL, INC. SHALL NOT BE
LIABLE FOR INCIDENTAL OR CONSEQUENTAL DAMAGES RESULTING
FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH
OF THIS WARRANTY.
ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANDISE AND FITNESSS FOR A PARTICULAR PURPOSE,
ARE LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH
ABOVE.
Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so
the above exclusions and limitations may not apply to you. This warranty
gives you specific legal rights and you may also have other rights, which
vary from state to state.
AXIS / Bodyline Products International, Inc.
198 N. Brandon Drive, Glendale Heights, Illinois 60139 USA
Made in China
Loading...
