Axis 0433-001 User Manual

USER’S GUIDE

AXIS T92E Housing Series

AXIS T92E05 Protective Housing
AXIS T92E20 Outdoor Housing

ENGLISH DEUTSCH

FRAN

Ç
AIS

ITALIANO

ESPAÑOL

Legal Considerations

Korea -

ࢇЕɼࢽࡈ%ࢷ࢕ળࢶଢԻ۰
࣯Իɼࢽ߾۰یࡈଜЕʨࡶּࢶࡳԻଜֲֻҘ
ࠇ߾۰یࡈଟܹ࢑ݡТЬ

Video and audio surveillance can be prohibited by laws
that vary from country to country. Check the laws in
your local region before using this product for
surveillance purposes.

Trademark Acknowledgments

Apple, Boa, Bonjour, Ethernet, Internet Explorer, Linux,
Microsoft, Mozilla, Netscape Navigator, OS/2, Real,
SMPTE, QuickTime, UNIX, Windows, WWW are
registered trademarks of the respective holders. Java
and all Java-based trademarks and logos are trademarks
or registered trademarks of Sun Microsystems, Inc. in
the United States and other countries. Axis
Communications AB is independent of Sun
Microsystems Inc. UPnP™ is a certification mark of the
UPnP™ Implementers Corporation.

Electromagnetic Compatibility (EMC)

This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures: Re-orient or relocate
the receiving antenna. Increase the separation between
the equipment and receiver. Connect the equipment to
an outlet on a different circuit to the receiver. Consult
your dealer or an experienced radio/TV technician for
help. Shielded (STP) network cables must be used with
this unit to ensure compliance with EMC standards.

USA - This equipment has been tested and found to

comply with the limits for a Class B computing device
pursuant to Subpart B of Part 15 of FCC rules, which are
designed to provide reasonable protection against such
interference when operated in a commercial
environment. Operation of this equipment in a
residential area is likely to cause interference, in which
case the user at his/her own expense will be required to
take whatever measures may be required to correct the
interference.

Canada - This Class B digital apparatus complies with

Canadian ICES-003.

Europe - This digital equipment fulfills the

requirements for radiated emission according to limit B
of EN55022, and the requirements for immunity
according to EN55024 residential and commercial
industry.

Japan - This is a class B product based on the standard

of the Voluntary Control Council for Interference from
Information Technology Equipment (VCCI). If this is used
near a radio or television receiver in a domestic
environment, it may cause radio interference. Install and
use the equipment according to the instruction manual.

Australia - This electronic device meets the

requirements of the Radio communications
(Electromagnetic Compatibility) Standard AS/NZS
CISPR22:2002.

Safety

Complies to EN 60950-1 (IEC 60950-1), Safety of
Information Technology Equipment.

Equipment Modifications

This equipment must be installed and used in strict
accordance with the instructions given in the user
documentation. This equipment contains no
user-serviceable components. Unauthorized equipment
changes or modifications will invalidate all applicable
regulatory certifications and approvals.

Liability

Every care has been taken in the preparation of this
document. Please inform your local Axis office of any
inaccuracies or omissions. Axis Communications AB
cannot be held responsible for any technical or
typographical errors and reserves the right to make
changes to the product and documentation without
prior notice. Axis Communications AB makes no
warranty of any kind with regard to the material
contained within this document, including, but not
limited to, the implied warranties of merchantability
and fitness for a particular purpose. Axis
Communications AB shall not be liable nor responsible
for incidental or consequential damages in connection
with the furnishing, performance or use of this material.

RoHS

This product complies with both the European
RoHS directive, 2002/95/EC, and the Chinese
RoHS regulations, ACPEIP.

WEEE Directive

The European Union has enacted a Directive
2002/96/EC on Waste Electrical and Electronic
Equipment (WEEE Directive). This directive is
applicable in the European Union member
states. The WEEE marking on this product (see right) or
its documentation indicates that the product must not
be disposed of together with household waste. To
prevent possible harm to human health and/or the
environment, the product must be disposed of in an
approved and environmentally safe recycling process.
For further information on how to dispose of this
product correctly, contact the product supplier, or the
local authority responsible for waste disposal in your
area. Business users should contact the product supplier
for information on how to dispose of this product
correctly. This product should not be mixed with other
commercial waste.

Support

Should you require any technical assistance, please
contact your Axis reseller. If your questions cannot be
answered immediately, your reseller will forward your
queries through the appropriate channels to ensure a
rapid response. If you are connected to the Internet, you
can:

• download user documentation and firmware updates

• find answers to resolved problems in the FAQ database.
Search by product, category, or phrases

• report problems to Axis support by logging in to your
private support area

Safeguards

Please read through this User’s Guide carefully before installing the product. Keep the User’s Guide for further
reference.

CAUTION!

• Always use a shielded network cable (STP) between the camera and the end point and ensure that

the shield of the cable is connected to the protective earthing at the end point. Installations of Axis
cameras using a shielded network cable (STP) and a properly earthed end point have been tested to
comply with industry immunity standards’ levels such as surge protection. Any other installation
method will void the warranty and leave the unit at a risk.

• When transporting the Axis product, use the original packaging or equivalent to prevent damage to the
product.

• Store the Axis product in a dry and ventilated environment.

• Avoid exposing the Axis product to vibration, shocks or heavy pressure and do not install the camera on
unstable brackets, unstable or vibrating surfaces or walls, since this could cause damage to the product.

• Only use handtools when installing the Axis product, the use of electrical tools or excessive force could
cause damage to the product.

• Do not use chemicals, caustic agents, or aerosol cleaners. Use a damp cloth for cleaning.

• Only use accessories and spare parts provided or recommended by Axis.

• Do not attempt to repair the product by yourself, contact Axis or your Axis reseller for service matters.

IMPORTANT!

• This Axis product must be used in compliance with local laws and regulations.

ENGLISH

AXIS T92E05/T92E20 User’s Guide Page 5

AXIS T92E05/T92E20

User’s Guide

This User’s Guide provides instructions for installing AXIS T92E05 Protective Housing and AXIS
T92E20 Outdoor Housing.

To install the camera on the network, please see the Installation Guide provided with the camera.
For other details about the camera, see the User’s Manual, available from the CD provided with the
camera, or from www.axis.com.

Installation steps

1. Check the package contents against the list below.

2. Hardware overview. See page 6.

3. Install the hardware. See page 7.

Package contents

Item Models/variants/notes

Housing AXIS T92E05/T92E20
Wall bracket Wall bracket with internal cable channel
Network cable Outdoor network cable 5 m (16 ft.) with gasket

M20 Cable gland for IP66 (3x)
2x short Ethernet cables (AXIS T92E20 only)

Tools Torx T20 screw driver

Allen key

Holder mounting kit Stabilizing screw

Camera screw and washer

Printed materials AXIS T92E05/T92E20 User’s Guide (this document)

Drill template
Axis Warranty Document

ENGLISH

Optional accessories See www.axis.com for information on power accessories, product

documentation, installation tools and other software.

Page 6 AXIS T92E05/T92E20 User’s Guide

Cable cover

Bottom cover screw (4x)

Cable cover screw (2x)

Cable holes

Safety wire tab

Network cable (route

Bracket adjustment screw

through wall bracket)

Gasket

Bracket adapter

Network connector

Example image: AXIS T92E20 Outdoor Housing

Sunshield adjustment
screw (2x)

Caution!
May be hot

Heaters

Network cable

I/O cable

Holder

Holder screw (2x)

Camera screw and washer

Stabilizing screw

Sunshield and top cover

Bottom cover

Wall bracket

Bracket adapter screw (4x)

Hardware overview

AXIS T92E05/T92E20 User’s Guide Page 7

Install the hardware

Prepare the network cable

The provided network cable can be connected in several ways. The first option is to use the cable as
is, with the pre-mounted rubber gasket.

The second option is to use the provided plastic M20 cable gland, which must be used to achieve an
IP66 rating. Using any other cable gland may cause water to seep in and damage the camera.

If a cable other than the provided cable is used, you need to prepare a shielded network cable with
a gasket. Gently force the cable through the gasket provided and attach a network connector. It
may be necessary to pierce a hole in the gasket with the supplied

screwdriver.

ENGLISH

Caution:

• Do not force the network connector into the gasket.

• Do not pierce the gasket with a knife or other sharp object.

• Always use a shielded network cable (STP) between the camera and the end point and ensure that
the shield of the cable is connected to the protective earthing at the end point. Installations of Axis
cameras using a shielded network cable (STP) and a properly earthed end point have been tested to
comply with industry immunity standards’ levels such as surge protection. Any other installation
method will void the warranty and leave the unit at a risk.

Page 8 AXIS T92E05/T92E20 User’s Guide

Example images: AXIS M1114 Network camera and AXIS T92E05 Protective Housing

AXIS P1343 Network camera and AXIS T92E20 Outdoor Housing

Install the camera in the housing

1. Loosen the bottom cover screws and remove the top cover.

2. Loosen the holder screws and remove the holder.

3. Secure the camera and holder with the screws and washer according to the illustrations and
table below. Tighten the stabilizing screw just lightly and tighten the camera screw to 2 Nm. Be

careful not to overtighten the screws.

Camera model AXIS T92E05/AXIS T92E20 AXIS T92E20

Holder position and fasteners I/O cable Cold Startup Delay

No Off (O)

Yes Off (O)

Yes On (I)

AXIS T92E05/T92E20 User’s Guide Page 9

Network cable (route
through wall bracket)

Example image: AXIS P1343 Network Camera and AXIS T92E05 Protective Housing

4. If applicable, connect the network cable and the I/O cable, which are pre-installed in the
outdoor housing, to the camera, see illustration on page 10 and table on page 8.

5. Fit the holder on the bottom cover and adjust its position. Allow just enough distance,
approximately 5–10 mm (0.2–0.4 in.), between the camera lens and the front end of the plastic
inner housing to fit the top cover without the window scratching the lens.

6. Tighten the screws.

7. Optionally insert an SD memory card (not included) into the SDHC (Secure Digital High
Capacity) card slot. A standard or high capacity SD card is required to store images locally in
the camera.

8. If applicable, set the Cold Startup Delay switch to the correct position, see table on page 8 and
Cold Startup Delay Switch, on page 11.

Install the wall bracket

1. Use the supplied drill template to prepare a wall or pole for installation of the wall bracket.

2. Route the network cable through the wall bracket according to the wall bracket illustration in
Hardware overview, on page 6. Leave approximately 30 cm (11.8”) of cable for connecting the
camera.

3. Install the wall bracket on a wall or pole and make sure that the screws and plugs are
appropriate for the material (e.g. wood, metal, sheet rock, stone).

Install the camera on the bracket

ENGLISH

1. Loosen the cable cover screws and remove the cable cover from the bottom cover.

2. Install the camera with the bottom cover on the bracket and tighten the bracket adapter
screws.

3. Remove the gasket from one of the holes in the bottom cover, see illustrations on page 6 and
page 10.

4. Route the cable through the hole and attach the cable gasket to the hole.

Page 10 AXIS T92E05/T92E20 User’s Guide

Network cables

I/O cable

Example image: AXIS P1343 Network Camera and AXIS T92E20 Outdoor Housing

Cable cover

Cable cover screw (2x)

Cable holes

Bottom cover

Wall bracket

Bracket adapter screw (4x)

Bracket adjustment screw

Cable holes

Network connector (PoE IN)

Alarm output

Cold Startup Delay switch

LED indicator

(see text below)

Network connector (PoE OUT)

Bottom cover

Example image: AXIS T92E20 Outdoor Housing

5. Install the cable cover and tighten the cable cover screws.

6. Connect the camera to the network. Depending on the type of housing, connect the network
cable to the network connector on the camera or the housing, see illustrations on page 9 and
page 10.

7. If applicable, check that the Status LEDs indicate the correct conditions. See table on page 12
for further details. Note that the Status LED can be configured to be unlit during normal
operation.

8. Loosen the bracket adjustment screw to aim the camera to the point of interest and focus the
camera according to the instructions in the Installation Guide provided with the camera.

9. Take the top cover and attach the safety wire to the tab on the bottom cover.

AXIS T92E05/T92E20 User’s Guide Page 11

Example images: AXIS M1114 Network Camera and AXIS T92E05 Protective Housing

AXIS P1343 Network Camera and AXIS T92E20 Outdoor Housing

10. Install the top cover. Make sure to tighten diagonally opposite bottom cover screws a few turns
at a time until all are tight. This will help ensure that the bottom cover gasket is compressed
evenly. Do not attempt to tighten the screws completely the first time.

11. Loosen the sunshield adjustment screws and adjust the sunshield to the desired position.

ENGLISH

Further information

See the Installation Guide provided with the camera for information on how to assign an IP address,
set the password and access the video stream. The Installation Guide is also available from the Axis
Web site at www.axis.com

Cold Startup Delay Switch

AXIS T92E20 features Arctic Temperature Control, which is enabled by setting the Cold Startup
Delay switch to I (ON). When enabled, this function controls when the camera restarts after a
power cut, when temperatures are below 0 °C (32 °F); the camera is first heated to approximately
0 °C (32 °F) before it initializes. This prevents damage to camera models that include moving parts.

Note: The switch should be disabled for cameras without moving parts, since they do not require this

function, see table on page 8.

Page 12 AXIS T92E05/T92E20 User’s Guide

Status LED on housing electronics (fan/heater)

LED Color Indication

Power Green OK

Flashing
green

Single flash: Heater error
Double flash: Fan error
Triple flash: General error
Note: Alarm events will be triggered through the camera’s input port. See the
User’s Manual, available on the CD provided with the camera, or from
www.axis.com Contact your Axis reseller for information about spare parts and
troubleshooting.

Technical Specifications

Function/group Item Specification

Models AXIS T92E05 Protective Housing

AXIS T92E20 Outdoor Housing

General Casing Aluminium casing, polycarbonate sunshield and cable cover.

IP66- and NEMA 4X-rated, IK10 impact-resistant aluminum
enclosure

Operating conditions AXIS T92E05: -20°C to 55°C (-4°F to131°F)*

Approvals AXIS T92E05: IEC 60068-2-6, IEC 60068-2-27

Dimensions (HxWxD) 120 x 161 x 404 mm (4.7" x 6.4" x 15.9")
Weight AXIS T92E05: 2.4 kg (5.1 lb.)

Included accessories VT wall bracket, sunshield, 5 m (16 ft.) Ethernet cable with pre-

Humidity 15 – 100% (condensing)
AXIS T92E20: -40°C to 50°C (-40°F to122°F)*
Humidity 15 – 100% (condensing)

* Operating temperatures may vary depending on camera, see the User’s
Manual, available from the CD provided with the camera, or from
www.axis.com

AXIS T92E20: EN 55022 Class B, EN 61000-3-2, EN 61000-3-3,
EN 55024, EN 61000-6-1, EN 61000-6-2, EN 60950-22, IEC
60068-2-6, IEC 60068-2-27, FCC Part 15, Subpart B, Class B,
VCCI, Class B ITE, C-tick AS/NZS CISPR 22, ICES-003, Class B,
KCC Class B

AXIS T92E20: 2.5 kg (5.5 lb.)

mounted gasket, 2x short Ethernet cables (AXIS T92E20 only),
User’s Guide

Mesures de sécurité

Lisez attentivement le présent guide d’utilisation avant d’installer le produit. Conservez le guide d’utilisation si
vous souhaitez le consulter ultérieurement.

ATTENTION !

• Pour éviter d’endommager le produit Axis, utilisez l’emballage d’origine ou un équivalent pour le
transporter.

• Stockez le produit Axis dans un environnement sec et aéré.

• Évitez d’exposer le produit Axis à des vibrations, des chocs ou une trop forte pression et ne l’installez pas
sur des supports instables, ou des surfaces ou des murs instables ou vibrants. Cela risque de l’endommager.

• Utilisez uniquement des outils manuels pour l’installation du produit Axis, l’utilisation d’outils électriques
ou l’usage excessif de la force risque de l’endommager.

• N’utilisez ni produits chimiques, ni substances caustiques, ni nettoyeurs aérosol. Utilisez un linge humide
pour le nettoyage.

• Utilisez uniquement des accessoires et des pièces de rechange fournis ou recommandés par Axis.

• Ne tentez pas de réparer le produit vous-même, contactez Axis ou votre revendeur Axis pour tout problème
lié au service.

IMPORTANT !

• Ce produit Axis doit être utilisé conformément aux lois et réglementations locales en vigueur.

AXIS T9E05/T92E20 Guide d'utilisation Page 15

AXIS T92E05/T92E20

Guide d’utilisation

Ce guide d’utilisation fournit des instructions relatives à l’installation du caisson de protection
AXIS T92E05 et du caisson d’extérieur AXIS T92E20.

Pour installer la caméra sur le réseau, veuillez vous référer au guide d’installation fourni avec la
caméra. Pour en savoir plus sur la caméra, consultez le manuel de l’utilisateur, disponible sur le CD
fourni avec la caméra ou sur le site www.axis.com.

Procédure d’installation

1. Vérifiez le contenu de l’emballage par rapport à la liste ci-dessous.

2. Vue d’ensemble du matériel. Reportez-vous à la page 16.

3. Installation du matériel. Reportez-vous à la page 17.

Contenu de l’emballage

Élément Modèles/variantes/remarques

Caisson AXIS T92E05/T92E20
Support mural Support mural avec chemin de câble interne
Câble réseau Câble réseau d’extérieur 5 m avec joint

Presse-étoupe M20 pour IP66 (3x)
2x câble Ethernet court (Axis T92E20 seulement)

Outils Tournevis Torx T20

Clé hexagonale

Kit de montage du support Vis de stabilisation

Vis et rondelle de la caméra

Documentation imprimée Guide d’utilisation de l’AXIS T92E05/T92E20(ce document)

Gabarit de perçage
Document de garantie d’Axis

Accessoires en option Consultez le site www.axis.com pour plus d’informations sur les accessoires

d’alimentation, la documentation, les outils d’installation et les autres
logiciels.

FRAN

Ç
AIS

Page 16 AXIS T9E05/T92E20 Guide d'utilisation

Couvercle de câble

Vis du couvercle inférieur

Vis du couvercle de câble

Trous pour câbles

Patte de fil de sécurité

Câble réseau (acheminement

Vis de réglage du support

à travers le support mural)

Joint

Adaptateur de support

Vis d’adaptateur de support (x4)

Connecteur réseau

Exemple illustré : Caisson d’extérieur AXIS T92E20

Vis de réglage du
pare-soleil (x2)

Attention ! Peuvent
être chauds

Radiateurs

Câble réseau

Câble d’E/S

Support

Vis du support (2x)

Vis et rondelle de la caméra

Vis de stabilisation

Pare-soleil et couvercle supérieur

Couvercle

Support mural

(x4)

inférieur

(x2)

Vue d’ensemble du matériel

AXIS T9E05/T92E20 Guide d'utilisation Page 17

Installation du matériel

Préparation du câble réseau

Le câble réseau fourni peut être connecté de plusieurs façons. La première option consiste à utiliser
le câble tel quel, avec le joint en caoutchouc prémonté.

La deuxième option consiste à utiliser le presse-étoupe M20 en plastique fourni (obligatoire pour
l’obtention d’une classification IP66). L’utilisation de tout autre presse-étoupe risque d’entraîner
une infiltration d’eau et d’endommager la caméra.

Si vous utilisez un câble autre que celui fourni, il est nécessaire de préparer un câble réseau avec un
joint. Faites passer délicatement le câble à travers le joint fourni et complétez-le par un connecteur
réseau. Il peut être nécessaire de percer un trou dans le joint à l’aide du tournevis

fourni.

FRAN

Ç
AIS

Remarques :

• Ne forcez pas l’entrée du connecteur réseau dans le joint.

• Ne percez pas le joint avec un couteau ou tout autre objet tranchant.

• Utilisez toujours un câble réseau à paires torsadées blindé à usage extérieur pour la liaison entre la
caméra et le point terminal. Assurez-vous également que le point terminal soit correctement mis à la
terre. Les installations des caméras Axis à l’aide d’un câble réseau à paires torsadées blindé et du
point terminal correctement mis à terre ont été soumises à des tests rigoureux, conformément aux
niveaux de la norme relative à l’immunité de l’industrie, notamment la protection contre les
surtensions. Toute autre méthode d’installation annule la garantie et expose le produit à des risques.
Utilisez un câble réseau blindé.
