Aboutthismanual

Aboutthismanual

Thisusermanualdescribesmultipleproducts.Someoftheinstructionsmaynotberelevantforyourproduct.

3

AXISM30Series

Productoverview

Productoverview

1

SDcardslot(microSD)

2

StatusLED

3

RJ45connector

4

Controlbutton

4

AXISM30Series

Howtoaccesstheproduct

Howtoaccesstheproduct

AXISIPUtilityandAXISCameraManagementarerecommendedmethodsforndingAxisproductsonthenetworkandassigning
themIPaddressesinWindows®.Bothapplicationsarefreeandcanbedownloadedfromaxis.com/support

Theproductcanbeusedwiththefollowingbrowsers:

•Chrome

•Chrome

•Chrome

Ifyouneedmoreinformationaboutrecommendedbrowsers,gotoaxis.com/browser-support

TM

(recommended),Firefox

TM

(recommended)orSafari

TM

orFirefox

®

withotheroperatingsystems.

Howtoaccesstheproductfromabrowser

1.Startawebbrowser.

2.EntertheIPaddressorhostnameoftheAxisproductinthebrowser’saddresseld.

®

,Edge

®

®

,orOpera

withOSX

®

withWindows

®

®

ToaccesstheproductfromaMaccomputer(OSX),gotoSafari,clickonBonjourandselecttheproductfromthe
drop-downlist.

IfyoudonotknowtheIPaddress,useAXISIPUtilitytolocatetheproductonthenetwork.Forinformationabout
howtodiscoverandassignanIPaddress,seethedocumentAssignanIPAddressandAccesstheVideoStreamonAxis
Supportwebataxis.com/support

Note

ToshowBonjourasabrowserbookmark,gotoSafari>Preferences.

3.Enteryourusernameandpassword.Ifthisisthersttimetheproductisaccessed,therootpasswordmustrstbe
congured.

4.Theproduct’sliveviewpageopensinyourbrowser .

Aboutsecurepasswords

Important

Whensettingtheinitialpassword,thepasswordissentincleartextoverthenetwork.Ifthereisariskofnetworksnifng,
rstsetupasecureandencryptedHTTPSconnectionbeforeresettingthepasswords.

Thedevicepasswordistheprimaryprotectionforthedataandservices.Axis’productsdonotimposeapasswordpolicyasproducts
maybeusedinvarioustypesofinstallations,buttoprotectyourdatadothefollowing:

•Don’tusethedefaultpasswordthatcomeswiththeproducts.

•Useapasswordwithatleast8characters,preferablyusingapasswordgenerator .

•Don’texposethepassword.

•Changepasswordatarecurringinterval,atleastonceayear.

Setapasswordfortherootaccount

Important

Thedefaultadministratorusernamerootcannotbedeleted.Ifthepasswordforrootislost,theproductmustberesetto
thefactorydefaultsettings.

5

AXISM30Series

Howtoaccesstheproduct

Thedefaultrootaccounthasfullprivilegesandshouldbereservedforadministrativetasks.Alwayscreateauseraccountwithlimited
privilegesfordailyuse.Thisreducestheexposureoftheadministrativeaccount.

1.Makesuretofollowtheinstructionsaboutsecurepasswords,seeAboutsecurepasswordsonpage5.

2.Typeapasswordandthenretypeittoconrmthespelling.

3.ClickCreatelogin.Thepasswordhasnowbeencongured.

6

AXISM30Series

Setup

Setup

Abouttheproduct'sbuilt-inhelp

Youcanaccessthebuilt-inhelpthroughyourproduct’swebpage.Thehelpprovidesmoredetailedinformationontheproduct’s
featuresandtheirsettings.

Imagequality

Aboutcapturemodes

Acapturemodeconsistsofaresolutionandthecorrespondingframerateavailableintheproduct.Thecapturemodesetting
affectsthecamera’seldofviewandaspectratio.

Thelowerresolutioncapturemodeiscroppedoutfromthehighestresolution.

Theimageshowshowtheeldofviewandaspectratiocanchangebetweentwodifferentcapturemodes.

Howtoselectcapturemode

Whatcapturemodetochoosedependsontherequirementsofframerateandresolutionforthespecicsurveillancesetup.For
specicationsaboutavailablecapturemodes,seetheproduct’sdatasheet.Tondthelatestversionofthedatasheet,gotoaxis.com

Howtohidepartsoftheimagewithprivacymasks

Ifyouwanttohidepartsoftheimageduetoprivacyreasons,useoneorseveralprivacymasks.

Whatisaprivacymask?

7

AXISM30Series

Setup

Aprivacymaskisauser-denedareathatprohibitsusersfromviewingpartsofthemonitoredarea.Privacymasksappearasblocks
ofsolidcolorandareappliedonthevideostream.

Privacymasksarepresentonallsnapshots,recordedvideo,andrequestedstreams.TheycannotbebypassedthroughtheVAPIX®
applicationprogramminginterface(API).

Important

Ifyouaddmanyprivacymasks,thismayaffecttheproduct’sperformance.

Howtocreateaprivacymask

Tocreateoreditaprivacymask,gotoSettings>Privacymask.

Howtoreducenoiseinlow-lightconditions

Toreducenoiseinlow-lightconditions,youcanadjustoneormoreofthefollowingsettings:

•Makesurethattheexposuremodeisautomatic.

Note

Increasingthemaxshuttervaluecanresultinmotionblur.

•Theshutterspeedshouldbeasslowaspossible,whichmeansyoushouldsetmaxshuttertothehighestpossiblevalue.

•Reducesharpnessintheimage.

•Tryloweringthemaxgainvalue.

Howtoselectexposuremode

Thereareseveralexposuremodeoptionsinthecamerathatadjustsaperture,shutterspeed,andgaintoimproveimagequalityfor
specicsurveillancescenes.GotoSettings>Image>Exposureandselectbetweenthefollowingexposuremodes:

•Formostusecases,selectAutomaticexposure.

•Forenvironmentswithcertainarticiallighting,forexampleuorescentlighting,selectFlicker-free.

Selectthesamefrequencyasthepowerlinefrequency.

•Forenvironmentswithcertainarticiallightandbrightlight,forexampleoutdoorswithuorescentlightingatnightand
sunduringdaytime,selectFlicker-reduced.

Selectthesamefrequencyasthepowerlinefrequency.

•Tolockthecurrentexposuresettings,selectHoldcurrent.

Howtomonitorlongandnarrowareas

Usecorridorformattobetterutilizethefulleldofviewinalongandnarrowarea,forexampleastaircase,hallway,road,ortunnel.

8

AXISM30Series

Setup

1.Dependingonyourproduct,turnthecameraorthe3–axislensinthecamera90°or270°.

2.GotoSettings>Stream>Orientationontheproduct’swebpageandrotatetheview90°or270°.

Findoutmoreataxis.com/axis-corridor-format

Howtoenhancefacialrecognition

Tobetterrecognizethefaceofapersonpassingbythecamera,youcansettheoptimalpixelresolutionwiththecamera’spixel
counter.

1.GotoSettings>System>Orientationandclick.

2.Adjustthesizeandplacementoftherectangleinthecamera’sliveviewaroundtheareaofinterest,forexamplewhere
thefacesofpassingpersonsareexpectedtoappear.Youcanthenseethenumberofpixelsrepresentedbythesidesof
therectangle.

Note

Youcanuseanobjectofaknownsizeintheviewasareferencetodecidehowmuchresolutionisneededforrecognition.

9

AXISM30Series

Setup

Aboutviewarea

Aviewareaisacroppedpartofthefullview.Youcanstreamandstoretheviewareainsteadofthefullviewtominimizebandwidth
andstorageneeds.IfyouenablePTZfortheviewarea,youcanpan,tiltandzoomwithintheit.Byusingaviewareayoucan
removepartsofthefullview,forexamplesky.

Whenyousetupaviewarea,werecommendyoutosetthevideostreamresolutiontothesamesizeasorsmallerthantheviewarea
size.Ifyousetthevideostreamresolutionlargerthantheviewareasizeitimpliesdigitallyscaledupvideoaftersensorcapture,
whichrequiresmorebandwidthwithoutaddingimageinformation.

Howtohandlesceneswithstrongbacklight

UseWDRtomakebothdarkandbrightareasoftheimagevisible.

1.GotoSettings>Image.

2.TurnonWDRunderWidedynamicrange.

ImagewithoutWDR.

ImagewithWDR.

Note

IfyouuseWDR,youmayexperiencesomeWDRartifactsintheimage.

FindoutmoreaboutWDRandhowtouseitataxis.com/web-articles/wdr

Overlays

Aboutoverlays

Overlaysaresuperimposedoverthevideostream.Theyareusedtoprovideextrainformationduringrecordings,suchasatimestamp,
orduringproductinstallationandconguration.

10

AXISM30Series

Setup

Howtoshowatextoverlaywhenthecameradetectsmotion

Thisexampleexplainshowtodisplaythetext“Motiondetected”whenthecameradetectsmotion:

1.GotoSettings>Overlay.

2.Enter#Dinthetexteld.

3.Choosealignment,textsizeandappearance.

4.Includethetextoverlay.

5.GotoSystem>Events>Actionrules.

6.CreateanactionrulewithAXISVideoMotionDetectionastrigger.

7.Fromthelistofactions,selectOverlaytext.

8.Type“Motiondetected”.

9.Settheduration.

Streamingandstorage

Howtochoosevideocompressionformat

Decidingwhichcompressionmethodtochoosedependsonyourviewingrequirements,andonthepropertiesofyournetwork.The
availableoptionsare:

MotionJPEG

MotionJPEGorMJPEGisadigitalvideosequencethatismadeupofaseriesofindividualJPEGimages.Theseimagesarethen
displayedandupdatedataratesufcienttocreateastreamthatshowsconstantlyupdatedmotion.Fortheviewertoperceivemotion
videotheratemustbeatleast16imageframespersecond.Fullmotionvideoisperceivedat30(NTSC)or25(PAL)framespersecond.

TheMotionJPEGstreamusesconsiderableamountsofbandwidth,butprovidesexcellentimagequalityandaccesstoeveryimage
containedinthestream.

H.264orMPEG-4Part10/AVC

Note

H.264isalicensedtechnology.TheAxisproductincludesoneH.264viewingclientlicense.Installingadditionalunlicensed
copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.

H.264can,withoutcompromisingimagequality,reducethesizeofadigitalvideolebymorethan80%comparedtotheMotion
JPEGformatandbyasmuchas50%comparedtotheMPEG-4standard.Thismeansthatlessnetworkbandwidthandstoragespace
arerequiredforavideole.Orseenanotherway,highervideoqualitycanbeachievedforagivenbitrate.

H.265orMPEG-HPart2/HEVC

Note

H.265islicensedtechnology.TheAxisproductincludesoneH.265viewingclientlicense.Installingadditionalunlicensed
copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.

H.265can,withoutcompromisingimagequality,reducethesizeofadigitalvideolebyasmuchas50%morethanwith
theH.264standard.

Findoutmoreataxis.com/compression-formats

11

AXISM30Series

Setup

Howtoreducebandwidthandstorage

Important

Ifyoureducethebandwidthitcanresultinlessdetailsinthepicture.

1.GotoliveviewandselectH.264/H.265.

2.GotoSettings>Stream.

3.Dooneormoreofthefollowing:

-TurnontheZipstreamfunctionalityandselectthedesiredlevel.

-TurnondynamicGOPandsetahighGOPlengthvalue.

-Increasethecompression.

-TurnondynamicFPS.

Howtosetupnetworkstorage

Tostorerecordingsonthenetwork,youneedtosetupnetworkstorage:

1.GotoSettings>System>Storage.

2.ClickSetupunderNetworkstorage.

3.EntertheIPaddressofthehostserver.

4.Enterthenameofthesharedlocationonthehostserver.

5.Movetheswitchifthesharerequiresalogin,andenterusernameandpassword.

6.ClickConnect.

Events

Aboutevents

Theeventpagesallowyoutocongureyourproducttoperformactionswhendifferenteventsoccur.Forexample,theproduct
canstartarecordingorsendanemailnoticationwhenmotionisdetected.Thesetofconditionsthatdeneshowandwhen
theactionistriggerediscalledanactionrule.

Howtotriggeranaction

1.GotoSettings>System>Eventstosetupanactionrule.Theactionruledeneswhentheproductwillperformcertain
actions.Actionrulescanbesetupasscheduled,recurring,orforexample,triggeredbymotiondetection.

2.SelectwhatTriggermustbemettotriggertheaction.Ifyouspecifymorethanonetriggerfortheactionrule,all
ofthemmustbemettotriggertheaction.

3.SelectwhichActionthecamerashouldperformwhentheconditionsaremet.

Note

Ifyoumakechangestoanactiveactionrule,theactionruleneedstoberestartedforthechangestotakeeffect.

Note

Ifyouchangethedenitionofastreamproleusedinanactionrule,youneedtorestartanyactionrulesthatusethat
streamprole.

12

AXISM30Series

Setup

Howtorecordvideowhenthecameradetectsmotion

ThisexampleexplainshowtosetupthecameratostartrecordingtotheSDcardvesecondsbeforeitdetectsmotionandto
stoponeminuteafter.

MakesuretheAXISVideoMotionDetectionapplicationisrunning:

1.GotoSettings>Apps>AXISVideoMotionDetection.

2.Starttheapplicationifitisnotalreadyrunning.

3.Makesureyouhavesetuptheapplicationaccordingtoyourneeds.

Createanactionrule:

4.GotoSettings>System>Eventsandaddanactionrule.

5.Typeanamefortheactionrule.

6.Fromthelistoftriggers,selectApplicationsandthenselectAXISVideoMotionDetection(VMD).

7.Fromthelistofactions,selectRecordvideo.

8.Selectanexistingstreamproleorcreateanewone.

9.Setthepre-triggertimeto5seconds.

10.Setthepost-triggertimeto60seconds.

11.SelectSDcardfromthelistofstorageoptions.

12.ClickOk.

Applications

Aboutapplications

AXISCameraApplicationPlatform(ACAP)isanopenplatformthatenablesthirdpartiestodevelopanalyticsandotherapplications
forAxisproducts.Tondoutmoreaboutavailableapplications,downloads,trialsandlicenses,gotoaxis.com/applications

TondtheusermanualsforAxisapplications,gotoaxis.com

Note

•Itisrecommendedtorunoneapplicationatatime.

•Avoidrunningapplicationswhenthebuilt-inmotiondetectionisactive.

AXISPeopleCounter

AXISPeopleCounterisananalyticapplicationthatcanbeinstalledonanetworkcamera.

Thecounterisembeddedinthecamerawhichmeansyoudonotneedadedicatedcomputertoruntheapplication.
AXISPeopleCounterisintendedforretailenvironments,likestoresorshoppingmalls,orotherenvironmentswhereyouwantto
countpeople.

13

AXISM30Series

Setup

14

AXISM30Series

Troubleshooting

Troubleshooting

Howtoresettofactorydefaultsettings

Important

Resettofactorydefaultshouldbeusedwithcaution.Aresettofactorydefaultresetsallsettings,includingtheIPaddress,to
thefactorydefaultvalues.

Toresettheproducttothefactorydefaultsettings:

1.Disconnectpowerfromtheproduct.

2.Pressandholdthecontrolbuttonwhilereconnectingpower.SeeProductoverview.

3.Keepthecontrolbuttonpressedfor15–30secondsuntilthestatusLEDindicatorashesamber.

4.Releasethecontrolbutton.TheprocessiscompletewhenthestatusLEDindicatorturnsgreen.Theproducthasbeenreset
tothefactorydefaultsettings.IfnoDHCPserverisavailableonthenetwork,thedefaultIPaddressis192.168.0.90

5.UsetheinstallationandmanagementsoftwaretoolstoassignanIPaddress,setthepassword,andaccessthevideostream.

Theinstallationandmanagementsoftwaretoolsareavailablefromthesupportpagesonaxis.com/support

Howtocheckthecurrentrmware

Firmwareisthesoftwarethatdeterminesthefunctionalityofnetworkdevices.Oneofyourrstactionswhentroubleshootinga
problemshouldbetocheckthecurrentrmwareversion.Thelatestversionmaycontainacorrectionthatxesyourparticular
problem.

Tocheckthecurrentrmware:

1.Gototheproduct’swebpage.

2.Clickonthehelpmenu.

3.ClickAbout.

Howtoupgradethermware

Important

Preconguredandcustomizedsettingsaresavedwhenthermwareisupgraded(providedthatthefeaturesareavailablein
thenewrmware)althoughthisisnotguaranteedbyAxisCommunicationsAB.

Note

Whenyouupgradetheproductwiththelatestrmware,theproductreceivesthelatestfunctionalityavailable.Alwaysread
theupgradeinstructionsandreleasenotesavailablewitheachnewreleasebeforeupgradingthermware.Tondthelatest
rmwareandthereleasenotes,gotoaxis.com/support/rmware

1.Downloadthelatestrmwareletoyourcomputer,availablefreeofchargeataxis.com/support/rmware

2.Logintotheproductasanadministrator.

3.GotoSettings>System>Maintenanceintheproduct’swebpageandfollowtheinstructions.

4.Theupgradetakesawhile,don'tbreakthepowertotheproduct.Whentheupgradeisnished,theproductrestarts
automatically.

15

AXISM30Series

Troubleshooting

AXISCameraManagementcanbeusedformultipleupgrades.Findoutmoreataxis.com/products/axis-camera-management

Technicalissues,cluesandsolutions

Ifyoucan’tndwhatyou’relookingforhere,trythetroubleshootingsectionataxis.com/support

Problemsupgradingthermware

FirmwareupgradefailureIfthermwareupgradefails,theproductreloadsthepreviousrmware.Themostcommonreason

ProblemssettingtheIPaddress

Theproductislocatedona
differentsubnet

TheIPaddressisbeingused
byanotherdevice

isthatthewrongrmwarelehasbeenuploaded.Checkthatthenameofthermwarele
correspondstoyourproductandtryagain.

IftheIPaddressintendedfortheproductandtheIPaddressofthecomputerusedtoaccessthe
productarelocatedondifferentsubnets,youcannotsettheIPaddress.Contactyournetwork
administratortoobtainanIPaddress.

DisconnecttheAxisproductfromthenetwork.Runthepingcommand(inaCommand/DOS
window,typepingandtheIPaddressoftheproduct):

PossibleIPaddressconict
withanotherdeviceonthe
samesubnet

Theproductcannotbeaccessedfromabrowser

Cannotlogin

TheIPaddresshasbeen
changedbyDHCP

Certicateerrorwhenusing
IEEE802.1X

Theproductisaccessiblelocallybutnotexternally

Routerconguration

Firewallprotection

ThestaticIPaddressintheAxisproductisusedbeforetheDHCPserversetsadynamicaddress.
ThismeansthatifthesamedefaultstaticIPaddressisalsousedbyanotherdevice,theremay
beproblemsaccessingtheproduct.

WhenHTTPSisenabled,ensurethatthecorrectprotocol(HTTPorHTTPS)isusedwhenattempting
tologin.Youmayneedtomanuallytypehttporhttpsinthebrowser’saddresseld.

Ifthepasswordfortheuserrootislost,theproductmustberesettothefactorydefaultsettings.
SeeHowtoresettofactorydefaultsettings.

IPaddressesobtainedfromaDHCPserveraredynamicandmaychange.IftheIPaddresshas
beenchanged,useAXISIPUtilityorAXISCameraManagementtolocatetheproductonthe
network.Identifytheproductusingitsmodelorserialnumber,orbytheDNSname(ifthename
hasbeencongured).

Ifrequired,astaticIPaddresscanbeassignedmanually.Forinstructions,gotoaxis.com/support.

Forauthenticationtoworkproperly,thedateandtimesettingsintheAxisproductmustbe
synchronizedwithanNTPserver.GotoSettings>System>Dateandtime

CheckthatyourrouterallowsincomingdatatrafctotheAxisproduct.Theroutermustsupport
UPnP

ChecktheInternetrewallwithyournetworkadministrator.

•Ifyoureceive:Replyfrom<IPaddress>:bytes=32;time=10...
thismeansthattheIPaddressmayalreadybeinusebyanotherdeviceonthenetwork.
ObtainanewIPaddressfromthenetworkadministratorandreinstalltheproduct.

•Ifyoureceive:Requesttimedout,thismeansthattheIPaddressisavailable
forusewiththeAxisproduct.Checkallcablingandreinstalltheproduct.

®

.

Problemswithstreaming

MulticastH.264only
accessiblebylocalclients

Checkifyourroutersupportsmulticasting,oriftheroutersettingsbetweentheclientandthe
productneedtobecongured.TheTTL(TimeToLive)valuemayneedtobeincreased.

16

AXISM30Series

Troubleshooting

NomulticastH.264
displayedintheclient

PoorrenderingofH.264
images

Colorsaturationisdifferent
inH.264andMotionJPEG

Lowerframeratethan
expected

Can'tselectH.265encoding
inliveview

Problemsretrievingadditionalvideostreams

‘VideoError’displayedin
AXISCompanion,or

‘Stream:Error.Something
wentwrong.Maybethere
aretoomanyviewers.’in
Chrome/Firefox,or

‘503serviceunavailable’
errorinQuickTime,or

‘Cameranot
available’displayedin
AXISCameraStation,or

‘Errorreadingvideostream’
messageinbrowserwhen
usingtheJavaapplet

CheckwithyournetworkadministratorthatthemulticastaddressesusedbytheAxisproduct
arevalidforyournetwork.

Checkwithyournetworkadministratortoseeifthereisarewallpreventingviewing.

Ensurethatyourgraphicscardisusingthelatestdriver.Thelatestdriverscanusuallybe
downloadedfromthemanufacturer’swebsite.

Modifythesettingsforyourgraphicsadapter.Gototheadapter’sdocumentationformore
information.

•SeePerformanceconsiderationsonpage17.

•Reducethenumberofapplicationsrunningontheclientcomputer.

•Limitthenumberofsimultaneousviewers.

•Checkwiththenetworkadministratorthatthereisenoughbandwidthavailable.

•Lowertheimageresolution.

•Intheproduct’swebpage,setacapturemodethatprioritizesframerate.Changingthe
capturemodetoprioritizeframeratemightlowerthemaximumresolutiondepending
ontheproductusedandcapturemodesavailable.

•Themaximumframespersecondisdependentontheutilityfrequency(60/50Hz)of
theAxisproduct.

WebbrowsersdonotsupportH.265decoding.Useavideomanagementsystemorapplication
supportingH.265decoding.

Thiscameraisdesignedtodeliveruptofourdifferentstreams.Ifafthuniquestreamisrequested,
thecamerawillnotbeabletoprovideit,andanerrormessageisdisplayed.Theerrormessage
dependsonthewaythestreamisrequested.Thestreamsareusedonarstcome,rstserved
basis.Examplesofinstancesusingastreamare:

•Liveviewinginawebbrowserorotherapplication

•Whilerecording-continuousormotiontriggeredrecording

•Aneventusingimagesonthecamera,forexampleaneventsendingane-mailwithan
imageeveryhour

•Aninstalledapplication,suchasAxisVideoMotionDetection,willalwaysuseastream
regardlessofwhetheritisusedornot.

Thecameracandelivermorethanfoursimultaneousstreamsprovidedthecongurationofany
additionalstreamisidenticaltoanyoftherstfourstreams.Identicalcongurationimpliesexactly
thesameresolution,framerate,compression,videoformat,rotationetc.Formoreinformationsee
thewhitepaper“Maxnumberofuniquevideostreamcongurations”,availableataxis.com

Performanceconsiderations

Whensettingupyoursystem,itisimportanttoconsiderhowvarioussettingsandsituationsaffecttheperformance.Somefactors
affecttheamountofbandwidth(thebitrate)required,otherscanaffecttheframerate,andsomeaffectboth.Iftheloadonthe
CPUreachesitsmaximum,thisalsoaffectstheframerate.

Thefollowingfactorsarethemostimportanttoconsider:

•Highimageresolutionorlowercompressionlevelsresultinimagescontainingmoredatawhichinturnaffectsthe
bandwidth.

•AccessbylargenumbersofMotionJPEGorunicastH.264clientsaffectsthebandwidth.

•Simultaneousviewingofdifferentstreams(resolution,compression)bydifferentclientsaffectsbothframerateand
bandwidth.

17

AXISM30Series

Troubleshooting

Useidenticalstreamswhereverpossibletomaintainahighframerate.Streamprolescanbeusedtoensurethat
streamsareidentical.

•AccessingMotionJPEGandH.264videostreamssimultaneouslyaffectsbothframerateandbandwidth.

•Heavyusageofeventsettingsaffectstheproduct’sCPUloadwhichinturnaffectstheframerate.

•UsingHTTPSmayreduceframerate,inparticularifstreamingMotionJPEG.

•Heavynetworkutilizationduetopoorinfrastructureaffectsthebandwidth.

•Viewingonpoorlyperformingclientcomputerslowersperceivedperformanceandaffectsframerate.

•RunningmultipleAXISCameraApplicationPlatform(ACAP)applicationssimultaneouslymayaffecttheframerateand
thegeneralperformance.

18

AXISM30Series

Specifications

Specifications

Tondthelatestversionoftheproduct’sdatasheet,gototheproductpageonaxis.comandlocateSupport&Documentation.

LEDindicators

StatusLED

Unlit

GreenShowssteadygreenfor10secondsfornormaloperationafterstartupcompleted.

Amber

Amber/RedFlashesamber/redifnetworkconnectionisunavailableorlost.

RedFirmwareupgradefailure.

Indication

Connectionandnormaloperation.

Steadyduringstartup.Flashesduringrmwareupgradeorresettofactorydefault.

SDcardslot

NO

TICE

NO NO

TICE TICE

•RiskofdamagetoSDcard.Donotusesharptools,metalobjects,orexcessiveforcewheninsertingorremovingthe

SDcard.Useyourngerstoinsertandremovethecard.

•Riskofdatalossandcorruptedrecordings.DonotremovetheSDcardwhiletheproductisrunning.UnmounttheSDcard

fromtheproduct’swebpagebeforeremoval.

ThisproductsupportsmicroSD/microSDHC/microSDXCcards(notincluded).

ForSDcardrecommendations,seeaxis.com

Buttons

Controlbutton

Thecontrolbuttonisusedfor:

•Resettingtheproducttofactorydefaultsettings.SeeHowtoresettofactorydefaultsettingsonpage15.

•ConnectingtoanAXISVideoHostingSystemservice.Toconnect,pressandholdthebuttonforabout3secondsuntilthe
statusLEDashesgreen.

Connectors

Networkconnector

RJ45EthernetconnectorwithPoweroverEthernet(PoE).

19

UserManualVer.M1.6
AXISM30SeriesDate:September2017
©AxisCommunicationsAB,2017

PartNo.1741648
