MANO500 Series
Intel® Socket 1151 Core
TM
i7/ i5/ i3
Processors Mini ITX Motherboard
User’s Manual
ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2017 Axiomtek Co., Ltd.
All Rights Reserved
May 2017, Version A2
Printed in Taiwan
iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity. To prevent chipsets
from electrostatic discharge damage, please take care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel® and Celeron® are trademarks of Intel Corporation.
Windows® is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.
iv
Table of Contents
Disclaimers ...................................................................................................... ii
ESD Precautions ............................................................................................. iii
Chapter 1 Introduction ............................................. 1
1.1 Features ................................................................................................ 1
1.2 Specifications ........................................................................................ 2
1.3 Utilities Supported ................................................................................. 3
1.4 Block Diagram ....................................................................................... 4
Chapter 2 Board and Pin Assignments .................... 5
2.1 Board Layout ......................................................................................... 5
2.2 Rear I/O ................................................................................................. 7
2.3 Jumper Settings .................................................................................... 8
2.3.1 Clear CMOS (JP1) ...................................................................................... 9
2.3.2 AT/ATX Power Mode Select (JP2) .............................................................. 9
2.3.3 COM1 RS-232/422/485 Mode Select (JP3, JP4, JP5) ............................. 10
2.3.4 COM1Data/Power Select (JP6) ................................................................ 10
2.3.5 LVDS VDD Select (JP7) ............................................................................ 10
2.3.6 LVDS Backlight PWM/CCFL Select (JP8) ................................................. 10
2.4 Connectors .......................................................................................... 11
2.4.1 Audio Jack (CN2) ...................................................................................... 12
2.4.2 LAN and USB 3.0 Connectors (CN3 and CN4) ........................................ 12
2.4.3 DisplayPort Connector (CN5) .................................................................... 13
2.4.4 VGA Connector (CN6) ............................................................................... 13
2.4.5 COM Connector (CN7) .............................................................................. 14
2.4.6 HDMI Connector (CN8) ............................................................................. 14
2.4.7 LVDS Signal Header (CN9) ....................................................................... 15
2.4.8 Front Panel Header (CN10) ...................................................................... 16
2.4.9 PCI-Express Mini Card Connector (CN11)................................................ 17
2.4.10 mSATA Slot (CN12) ................................................................................... 18
2.4.11 USB 2.0 Wafers (CN13 and CN14) ........................................................... 19
2.4.12 GPIO Header (CN15) ................................................................................ 19
2.4.13 Front Audio Header (CN16) ...................................................................... 20
2.4.14 LVDS Backlight Control Header (CN17) ................................................... 20
2.4.15 Keyboard and Mouse Header (CN18) ...................................................... 20
2.4.16 eDP Connector (CN19) ............................................................................. 21
2.4.17 CMOS Battery Connector (BAT1) ............................................................. 21
2.4.18 Power Input Connectors (ATX1 and ATX2) ............................................... 22
2.4.19 COM Headers (COM3~COM6) ................................................................. 22
v
2.4.20 Fan Connectors (CPU_FAN1 and SYS_FAN1) ........................................ 23
2.4.21 SIM Card Slot (SIM1) ................................................................................ 23
2.4.22 SATA 3.0 Connectors (SATA1~SATA3) ..................................................... 23
Chapter 3 Hardware Description ........................... 25
3.1 Microprocessors .................................................................................. 25
3.2 BIOS.................................................................................................... 25
3.3 System Memory .................................................................................. 25
Chapter 4 AMI BIOS Setup Utility .......................... 27
4.1 Starting ................................................................................................ 27
4.2 Navigation Keys .................................................................................. 27
4.3 Main Menu .......................................................................................... 29
4.4 Advanced Menu .................................................................................. 30
4.5 Chipset Menu ...................................................................................... 42
4.6 Security Menu ..................................................................................... 49
4.7 Boot Menu ................................ ................................ ........................... 50
4.8 Save & Exit Menu ................................................................................ 51
Appendix A Watchdog Timer ................................... 53
B.1 About Watchdog Timer ........................................................................ 53
B.2 Sample Program ................................................................................. 53
Appendix B BIOS Flash Utility ................................ 55
vi
This page is intentionally left blank.
MANO500 Mini ITX Motherboard
Introduction 1
Chapter 1
Introduction
The MANO500 is a Mini-ITX motherboard which supports the new 14nm 6th/ 7th Generation
Intel® Core™ i7/ i5/ i3, Pentium® and Celeron
®
processors in LGA1151 package. Featuring the
new Intel® H110 /Q170 Express chipset with two DDR4 2133MHz memory support, this
motherboard is built to perform best stability and reliability for industrial applications.
The three SATA 3.0, four USB 3.0, and one RS-232/422/485 port provide robust storage and
I/O options. Users also can increase board functionality with PCI-Express x16 and
PCI-Express Mini Card slot. The high quality MANO500 allows four display interfaces via
HDMI, VGA, DisplayPort, and LVDS (co-layout with Embedded DisplayPort (eDP)) in triple
views, making it an ideal solution for gaming, workstation, digital signage, medical and other
IoT&M2M applications.
1.1 Features
LGA1151 Socket for 6
th
/ 7th Generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron®
processors (Skylake and Kabylake)
2 DDR4 2133MHz memory with maximum capacity up to 32 GB
1 PCI-Express x16
1 PCI-Express Mini Card and 1 SIM card slots
3 SATA-600
1 mSATA
4 USB 3.0 and 4 USB 2.0
MANO500 Mini ITX Motherboard
2 Introduction
1.2 Specifications
CPU
LGA1151 Socket for 6
th
and 7th Generation Intel® Core™ i7/ i5/ i3, Pentium® and
Celeron® processors.
Chipset
Intel
®
H110/Q170.
BIOS
AMI BIOS via SPI interface
System Memory
Two 288-pin LONG-DIMM sockets.
Maximum up to 32GB DDR4 memory.
Support 2133MHz.
Onboard Multi I/O
Controller: ITE8786.
One PS/2 keyboard and mouse.
Six serial ports:
- COM1 supports RS-232/422/485; COM2~COM6 support RS-232 only.
- COM1~COM2 on the rear I/O; COM3~COM6 in box headers.
USB Interface
Four USB 3.0 ports (on the rear I/O).
Four USB 2.0 ports (internal).
Ethernet
LAN1: 1000/100/10Mbps Gigabit/Fast Ethernet support Wake-on-LAN, PXE with
Intel® i219LM.
LAN2: 1000/100/10Mbps Gigabit/Fast Ethernet PXE with Intel
®
i211AT.
Serial ATA
Three SATA 3.0 port (6Gb/s).
One mSATA slot.
Audio
Realtek ALC662 5.1 channel HDA codec.
Support MIC-in/line-out.
Display
One 15-pin D-Sub as VGA connector. Resolution max. up to 1920x1200.
One HDMI with resolution max. up to 3840x2160 @30Hz or 2560x1600 @60Hz.
One DisplayPort with resolution max. up to 4096x2304 @60Hz.
One 24-bit dual channel LVDS and one 8-pin inverter connector. LVDS resolution is
max. up to 1920x1200.
One Embedded DisplayPort (eDP) with resolution max. up to 4096x2304 @60Hz;
co-layout with LVDS.
Expansion Interface
One PCI-Express x16 slot.
One PCI-Express Mini Card.
One SIM card slot.
MANO500 Mini ITX Motherboard
Introduction 3
Power Input
One ATX power input connector.
One 12V ATX power input connector for CPU Power.
Operating Temperature
0°C ~60°C.
Storage Temperature
-20°C ~60°C.
Form Factor
Mini ITX (6.7” x 6.7”, 17.0cm x 17.0cm).
Note
All specifications and images are subject to change without notice.
1.3 Utilities Supported
Chipset driver
Ethernet driver
Graphics driver
Audio driver
MANO500 Mini ITX Motherboard
4 Introduction
1.4 Block Diagram
MANO500 Mini ITX Motherboard
Board and Pin Assignments 5
Chapter 2
Board and Pin Assignments
2.1 Board Layout
MANO500 Mini ITX Motherboard
6 Board and Pin Assignments
MANO500 Mini ITX Motherboard
Board and Pin Assignments 7
2.2 Rear I/O
Jumpers/Headers/Connectors
1
Keyboard and Mouse Header (CN18)
18
COM1 Data/Power Select Jumper (JP6)
2
Front Audio Header (CN16)
19
eDP Connector (CN19)
3
Clear CMOS Jumper (JP1)
20
PCI-Express Mini Card Connector
(CN11)
4
System Fan Connector (SYS_FAN1)
21
SIM Card Slot (SIM1)
5
LVDS VDD Select Jumper (JP7)
22
DDR4 LONG-DIMM Sockets (DIMM1,
DIMM2)
6
LVDS Backlight PWM/CCFL Select Jumper
(JP8)
23
PCI-Express x16 Slot (CN1)
7
LVDS Signal Header (CN9)
24
ATX1 Power Input Connector (ATX1)
8
LVDS Backlight Control Header (CN17)
25
SATA 3.0 Connectors (SATA1~SATA3)
9
COM3~COM6 Headers (COM3~COM6)
26
CPU Socket
10
AT/ATX Power Mode Select Jumper (JP2)
27
mSATA Slot (CN12)
11
USB 2.0 Wafers (CN13, CN14)
28
Audio Jack (CN2)
12
Front Panel Header (CN10)
29, 30
COM1 and COM2 Connector (CN7)
13
GPIO Header (CN15)
31
LAN Connectors (CN3, CN4)
14
ATX2 Power Input Connector (ATX2)
32
USB 3.0 Connectors (CN3, CN4)
15
CPU Fan Connector (CPU_FAN1)
33
VGA Connector (CN6)
16
CMOS Battery Connector (BAT1)
34
DisplayPort Connector (CN5)
17
COM1 RS-232/422/485 Mode Select
Jumpers (JP3~JP5)
35
HDMI Connector (CN8)
MANO500 Mini ITX Motherboard
8 Board and Pin Assignments
Note
To identify the first pin of a header or jumper, please refer to the following
information:
Usually, there is a thick line or a triangle near the header or jumper pin 1.
Square pad, which you can find on the back of the motherboard, is usually
used for pin 1.
2.3 Jumper Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. The following
illustration shows how to set up jumper.
Before applying power to MANO500 Series, please make sure all of the jumpers are in factory
default position. Below you can find a summary table of all jumpers and onboard default
settings.
Note
Once the default jumper setting needs to be changed, please do it under power-off
condition.
MANO500 Mini ITX Motherboard
Board and Pin Assignments 9
Jumper
Description
Setting
JP1
Clear CMOS
Default: Normal Operation
1-2 Close
JP2
AT/ATX Power Mode Select
Default: ATX Mode
1-2 Close
JP3
COM1 RS-232/422/485 Mode Select
Default: RS-232
1-2 Close
JP4
3-5, 4-6 Close
JP5
3-5, 4-6 Close
JP6
COM1 Data/Power Select
Default: RS-232 Data
CN7 Pin 1: DCD
3-5 Close
CN7 Pin 9: RI
4-6 Close
JP7
LVDS VDD Select
Default: +3.3V
1-2 Close
JP8
LVDS Backlight PWM/CCFL Select
Default: PWM
1-2 Close
2.3.1 Clear CMOS (JP1)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can
clear the CMOS memory of date, time, and system setup parameters by erasing the
CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS,
which includes system setup information such as system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Remove the onboard battery.
3. Move the jumper clip from pins 1-2 (default) to pins 2-3. Keep the clip on pins 2-3
for about 5~10 seconds, then move the clip back to pins 1-2.
4. Re-install the battery.
5. Plug the power cord and turn ON the computer.
6. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter
data.
2.3.2 AT/ATX Power Mode Select (JP2)
This 3x1-pin p=2.54mm jumper allows you to select AT or ATX power mode.
Function
Setting
Normal operation (Default)
1-2 close
Clear CMOS
2-3 close
Function
Setting
ATX mode (Default)
1-2 close
AT mode
2-3 close
MANO500 Mini ITX Motherboard
10 Board and Pin Assignments
2.3.3 COM1 RS-232/422/485 Mode Select (JP3, JP4, JP5)
Use these jumpers (3x2-pin p=2.54mm) to set COM1 port to operate in RS-232, RS-422
or RS-485 communication mode.
JP3 JP4 JP5
2.3.4 COM1Data/Power Select (JP6)
The COM1 port has +5V power capability on DCD and +12V on RI by setting this jumper
(3x2-pin p=2.54mm).
2.3.5 LVDS VDD Select (JP7)
This motherboard supports voltage selection for flat panel displays. Use this 3x2-pin
p=2.54mm jumper to set up VDD power of the LVDS connector. To prevent hardware
damage, before connecting please make sure that the input voltage of LVDS panel is
correct.
2.3.6 LVDS Backlight PWM/CCFL Select (JP8)
This 3x1-pin p=2.54mm jumper enables you to select PWM or voltage control mode for
LVDS backlight control header (CN17). These two control modes are for adjusting the
brightness of LVDS panel.
Function
Setting
RS-232 mode
(Default)
JP3 1-2 close
JP4 3-5, 4-6 close
JP5 3-5, 4-6 close
RS-422 mode
JP3 3-4 close
JP4 1-3, 2-4 close
JP5 1-3, 2-4 close
RS-485 mode
JP3 5-6 close
JP4 1-3, 2-4 close
Function
Setting
Power: Set COM1 pin 1 to +5V
1-3 close
Data: Set COM1 pin 1 to DCD (Default)
3-5 close
Power: Set COM1 pin 9 to +12V
2-4 close
Data: Set COM1 pin 9 to RI (Default)
4-6 close
Function
Setting
+3.3V (Default)
1-2 close
+5V
3-4 close
+12V
5-6 close
Function
Setting
Controlled by PWM (Default)
1-2 close
Controlled by DC Voltage
2-3 close
MANO500 Mini ITX Motherboard
Board and Pin Assignments 11
2.4 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table showing connectors on the hardware.
Connector
Description
CN1
PCI-Express x16 Slot
CN2
Audio Jack
CN3, CN4
LAN and USB 3.0 Connectors
CN5
DisplayPort Connector
CN6
VGA Connector
CN7
COM1 and COM2 Connector
CN8
HDMI Connector
CN9
LVDS Signal Header
CN10
Front Panel Header
CN11
PCI-Express Mini Card Connector
CN12
mSATA Slot
CN13, CN14
USB 2.0 Wafers
CN15
GPIO Header
CN16
Front Audio Header
CN17
LVDS Backlight Control Header
CN18
Keyboard and Mouse Header
CN19
eDP Connector
BAT1
CMOS Battery Connector
ATX1
ATX1 Power Input Connector
ATX2
ATX2 Power Input Connector
COM3~COM6
COM3~COM6 Headers
CPU_FAN1
CPU Fan Connector
SYS_FAN1
System Fan Connector
SIM1
SIM Card Slot
SATA1~SATA3
SATA 3.0 Connectors
DIMM1~DIMM2
DDR4 LONG-DIMM Sockets
MANO500 Mini ITX Motherboard
12 Board and Pin Assignments
LAN
USB
2.4.1 Audio Jack (CN2)
The motherboard provides HD audio jack on the rear I/O. Install audio driver, and then
attach audio devices to CN2.
2.4.2 LAN and USB 3.0 Connectors (CN3 and CN4)
The motherboard comes with two high performance plug and play Ethernet interfaces
(RJ-45) which are fully compliant with the IEEE 802.3 standard. Connection can be
established by plugging one end of the Ethernet cable into this RJ-45 connector and the
other end to a 1000/100/10 Base-T hub.
The Universal Serial Bus (compliant with USB 3.0) connectors on the rear I/O are for
installing USB peripherals such as keyboard, mouse, scanner, etc.
Note
Speed LED turns orange for 1000Mbps or green for 100Mbps.
CN3 supports AMT when chipset is customized into Intel
®
Q170 and
Wake-on-LAN.
Pin Color
Signal
Green
Line-out
Pink
MIC-in
Pin
LAN Signal
Pin
LAN Signal
L1
Tx+ (Data
transmission positive)
L2
Tx- (Data transmission
negative)
L3
Rx+ (Data reception
positive)
L4
RJ-1 (For 1000 Base-T
only)
L5
RJ-1 (For 1000
Base-T only)
L6
Rx- (Data reception
negative)
L7
RJ-1 (For 1000
Base-T only)
L8
RJ-1 (For 1000 Base-T
only)
A
Active LED
B
Speed LED
Pin
USB Signal
Pin
USB Signal
1
USB3_POWER
2
USB -
3
USB +
4
GND
5
USB3_SSRX
6
USB3_SSRX+
7
GND
8
USB3_SSTX
9
USB3_SSTX+
MANO500 Mini ITX Motherboard
Board and Pin Assignments 13
2.4.3 DisplayPort Connector (CN5)
The DisplayPort interface is available through CN5.
2.4.4 VGA Connector (CN6)
The CN6 is a high rise 15-pin D-Sub connector which is commonly used for VGA display.
This VGA interface configuration can be configured via software utility.
Pin
Signal
1
DP_TX0_P
2
GND
3
DP_TX0_N
4
DP_TX1_P
5
GND
6
DP_TX1_N
7
DP_TX2_P
8
GND
9
DP_TX2_N
10
DP_TX3_P
11
GND
12
DP_TX3_N
13
GND
14
GND
15
DP_AUXP
16
GND
17
DP_AUXN
18
DP_HPD
19
GND
20
+3.3V
Pin
Signal
Pin
Signal
1
Red 2 Green
3
Blue 4 NC
5
GND
6
DETECT
7
GND
8
GND
9
VCC
10
GND
11
NC
12
DDC DATA
13
Horizontal Sync
14
Vertical Sync
15
DDC CLK
MANO500 Mini ITX Motherboard
14 Board and Pin Assignments
2.4.5 COM Connector (CN7)
The CN7 is a double-deck DB-9 connector for COM1 and COM2 serial port interfaces
where only COM1 is selectable for RS-232/422/485 mode by jumper settings (see
section 2.3.3). The pin assignments of RS-232/422/485 are listed in table below.
COM1:
COM1
COM2
Note
[*]
: Pin 1 of COM1 can be DCD/+5V and pin 9 of COM1 can be RI/+12V by
selecting JP6 (see section 2.3.4).
COM2:
2.4.6 HDMI Connector (CN8)
The HDMI (High-Definition Multimedia Interface) is a compact digital interface which is
capable of transmitting high-definition video and high-resolution audio over a single
cable.
Pin
RS-232
RS-422
RS-485
1
DCD#
[*]
TX-
485- 2 RXD
TX+
485+
3
TXD
RX+
N/C 4 DTR#
RX-
N/C 5 GND
GND
GND
6
DSR#
N/C
N/C 7 RTS#
N/C
N/C 8 CTS#
N/C
N/C 9 RI#
[*]
N/C
N/C
Pin
Signal
Pin
Signal
1
DCD
2
RXD
3
TXD 4 DTR
5
GND
6
DSR
7
RTS 8 CTS 9 RI
Pin
Signal
Pin
Signal
1
HDMI OUT_DATA2+
2
GND
3
HDMI OUT_DATA2-
4
HDMI OUT_DATA1+
5
GND
6
HDMI OUT_DATA1-
7
HDMI OUT_DATA0+
8
GND
9
HDMI OUT_DATA0-
10
HDMI OUT_Clock+
11
GND
12
HDMI OUT_Clock-
13
N/C
14
GND
15
HDMI OUT_SCL
16
HDMI OUT_SDA
17
GND
18
+5V
19
HDMI_HTPLG
MANO500 Mini ITX Motherboard
Board and Pin Assignments 15
2.4.7 LVDS Signal Header (CN9)
This motherboard has a 20x2-pin p=1.00mm header for LVDS panel interface.
Note
CN9 is co-layout with eDP connector (CN19); they can’t be accessed
simultaneously.
LVDS header P/N (CN9): GEAN-LEA electronic GLA1001WV-S-2x20.
[*]
: Panel power VDD is 3.3V by default, 5V or 12V is selectable by jumper
JP7, see section 2.3.5.
[**]
: Grounding of this pin is required to ensure normal LVDS output.
Pin
Signal
Pin
Signal
1
VDD
[*]
2
VDD
[*]
3
VDD
[*]
4
VDD
[*]
5
VDD
[*]
6
VDD
[*]
7
N/C 8 N/C 9 GND
10
GND
11
LVDS_B_DATA3-
12
LVDS_B_DATA0-
13
LVDS_B_DATA3+
14
LVDS_B_DATA0+
15
GND
16
GND
17
LVDS_B_CLK-
18
LVDS_B_DATA1-
19
LVDS_B_ CLK +
20
LVDS_B_DATA1+
21
GND
22
GND
23
LVDS_A_DATA0-
24
LVDS_B_DATA2-
25
LVDS_A_DATA0+
26
LVDS_B_DATA2+
27
GND
28
GND
29
LVDS_A_DATA1-
30
LVDS_A_DATA3-
31
LVDS_A_DATA1+
32
LVDS_A_DATA3+
33
LVDS_PRSNT#(Detect)
[**]
34
GND
35
LVDS_A_DATA2-
36
LVDS_A_CLK-
37
LVDS_A_DATA2+
38
LVDS_A_ CLK +
39
GND
40
GND
MANO500 Mini ITX Motherboard
16 Board and Pin Assignments
2.4.8 Front Panel Header (CN10)
This is front panel header (7x2-pin p=2.54mm).
Note
[*]
: The buzzer on motherboard will be active when pin 2 and pin 4 is
connected; the external speaker on chassis will be active when pin 2 and
pin 4 is open.
Pin
Signal
1
Power LED+
2
SPK-
[*]
3
GND
4
BUZZER-
5
Power LED-
6
N/C 7 N/C 8 SPK+
[*]
9
PWR-
10
PWR+
11
RESET-
12
RESET+
13
HD LED-
14
HD LED+
MANO500 Mini ITX Motherboard
Board and Pin Assignments 17
2.4.9 PCI-Express Mini Card Connector (CN11)
The CN11 complies with PCI-Express Mini Card Spec. V1.2.
Pin
Signal
Pin
Signal
1
WAKE#
2
+3.3VAUX
3
N/C 4 GND
5
N/C 6 +1.5V
7
+3.3VAUX
8
UIM_PWR
9
GND
10
UIM_DAT
11
REFCLK-
12
UIM_CLK
13
REFCLK+
14
UIM_REST
15
GND
16
UIM_VPP
17
N/C
18
GND
19
N/C
20
W_DISABLE#
21
GND
22
PERST#
23
PERN0
24
+3.3VAUX
25
PERP0
26
GND
27
GND
28
+1.5V
29
GND
30
SMB_CLK
31
PETN0
32
SMB_DATA
33
PETP0
34
GND
35
GND
36
USB_10-
37
GND
38
USB_10+
39
+3.3VAUX
40
GND
41
+3.3VAUX
42
N/C
43
GND
44
N/C
45
CL_CLK
46
N/C
47
CL_DATA
48
+1.5V
49
CL_RST_N
50
GND
51
N/C
52
+3.3VAUX
MANO500 Mini ITX Motherboard
18 Board and Pin Assignments
2.4.10 mSATA Slot (CN12)
Pin
Signal
Pin
Signal
1
N/C 2 +3.3VAUX
3
N/C 4 GND
5
N/C 6 +1.5V
7
N/C 8 N/C 9 GND
10
N/C
11
N/C
12
N/C
13
N/C
14
N/C
15
GND
16
N/C
17
N/C
18
GND
19
N/C
20
N/C
21
GND
22
PERST#
23
SATA0_RX_DP
24
+3.3VAUX
25
SATA0_RX_DN
26
GND
27
GND
28
+1.5V
29
GND
30
SMB_CLK
31
SATA0_TX_DN
32
SMB_DATA
33
SATA0_TX_DP
34
GND
35
GND
36
USB_9-
37
GND
38
USB_9+
39
+3.3VAUX
40
GND
41
+3.3VAUX
42
N/C
43
GND
44
N/C
45
N/C
46
N/C
47
N/C
48
+1.5V
49
N/C
50
GND
51
N/C
52
+3.3VAUX
MANO500 Mini ITX Motherboard
Board and Pin Assignments 19
2.4.11 USB 2.0 Wafers (CN13 and CN14)
These are 5x2-pin p=2.00mm headers for USB 2.0 interface.
2.4.12 GPIO Header (CN15)
This header (5x2-pin p=2.54mm) is for digital I/O interface.
Note
[*]
: “H” or “L” means the default voltage is High or Low level, and GPIO
output is 5V.
Pin
CN13 Signal
Pin
CN13 Signal
1
+5V 2 +5V 3 USB5-
4
USB6-
5
USB5+
6
USB6+
7
GND
8
GND
9
N/C
Pin
CN14 Signal
Pin
CN14 Signal
1
+5V 2 +5V 3 USB7-
4
USB8-
5
USB7+
6
USB8+
7
GND
8
GND
9
N/C
Pin
Signal
Pin
Signal
1
SIO_GPO74
(0xA06 Bit4, H)
[*]
2
SIO_GPI70
(0xA06 Bit0, H)
3
SIO_GPO75
(0xA06 Bit5, H)
4
SIO_GPI71
(0xA06 Bit1, H)
5
SIO_GPO76
(0xA06 Bit6, H)
6
SIO_GPI72
(0xA06 Bit2, H)
7
SIO_GPO77
(0xA06 Bit7, H)
8
SIO_GPI73
(0xA06 Bit3, H)
9
GND
10
GND
MANO500 Mini ITX Motherboard
20 Board and Pin Assignments
2.4.13 Front Audio Header (CN16)
This is front audio header (5x2-pin p=2.00mm) for convenient connection and control of
audio devices.
2.4.14 LVDS Backlight Control Header (CN17)
This is an 8x1-pin p=1.25mm header for LVDS backlight control interface.
Note
LVDS backlight control header P/N (CN17): GEAN-LEA electronic
GLA1252WV-S-8P.
[*]
: This signal is selectable by jumper JP8, see section 2.3.6.
2.4.15 Keyboard and Mouse Header (CN18)
This is a 6x1-pin p=2.00mm header for keyboard and mouse interface.
Pin
Signal
Pin
Signal
1
MIC_IN
2
GND
3
LINE_IN_L
4
GND
5
LINE_IN_R
6
GND
7
AUD_OUT_L
8
GND
9
AUD_OUT_R
10
GND
Pin
Signal
1
+12V
2
+12V
3
+5V
4
LVDS_BKL_EN
5
GND
6
GND
7
GND
8
LVDS_BKL_CTL
[*]
Pin
Signal
Pin
Signal
1
KB_CLK
2
KB_DATA
3
MS_CLK
4
GND
5
+5V 6 MS_DATA
MANO500 Mini ITX Motherboard
Board and Pin Assignments 21
2.4.16 eDP Connector (CN19)
Note
CN19 is co-layout with LVDS signal header (CN9); they can’t be
accessed simultaneously.
eDP connector P/N: Aces Electronics 50203-40.
[*]
: Panel power VDD is 3.3V by default, 5V or 12V is selectable by jumper
JP7, see section 2.3.5.
2.4.17 CMOS Battery Connector (BAT1)
This connector is for CMOS battery interface.
Pin
Signal
Pin
Signal
1
VDD
[*]
2
VDD
[*]
3
VDD
[*]
4
VDD
[*]
5
VDD
[*]
6
GND
7
GND
8
GND
9
GND
10
EMB_HPD
11
N/C
12
N/C
13
GND
14
EDP_TXN3C
15
EDP_TXP3_C
16
GND
17
EDP_TXN2_C
18
EDP_TXP2_C
19
GND
20
EDP_TXN1_C
21
EDP_TXP1_C
22
GND
23
EDP_TXN0_C
24
EDP_TXP0_C
25
GND
26
EMB_AUXP
27
EMB_AUXN
28
VSS_EDP_AMOLED
29
+3.3V
30
N/C
31
VCC_EDP_BKLT
32
VSS_EDP_AMOLED
33
GND
34
+5V
35
N/C
36
EDP_BKLTCTL
37
EDP_BKLTEN
38
VCC_EDP_BKLT
39
+3.3V
40
GND
41
ISH_I2C0_SCL_R
42
ISH_I2C0_SDA_R
43
+3.3V
44
N/C
Pin
Signal
1
GND
2
+3.3V
1
MANO500 Mini ITX Motherboard
22 Board and Pin Assignments
2.4.18 Power Input Connectors (ATX1 and ATX2)
Steady and sufficient power can be supplied to all components on the board by
connecting power connector. Please make sure all components and devices are
properly installed before connecting the power connector.
External power supply plug fits into this connector in only one orientation. Properly press
down power supply plug until it completely and firmly fits into this connector. Loose
connection may cause system instability.
ATX1 is a 4-pin connector for DC +12V power input.
2 4
1 3
ATX2 is a 24-pin connector for DC power input.
2.4.19 COM Headers (COM3~COM6)
The motherboard comes with 5x2-pin p=2.00mm headers for COM3~COM6 serial port
interfaces.
Pin
Signal
1
GND
2
GND
3
+ 12V IN
4
+ 12V IN
Pin
Signal
Pin
Signal
1
3.3V
13
3.3V 2 3.3V
14
-12V
3
GND
15
GND
4
+5V
16
PS_ON
5
GND
17
GND
6
+5V
18
GND
7
GND
19
GND
8
PWR OK
20
-5V 9 5VSB
21
+5V
10
+12V
22
+5V
11
+12V
23
+5V
12
3.3V
24
GND
Pin
Signal
Pin
Signal
1
DCD
2
DSR
3
RXD
4
RTS 5 TXD 6 CTS 7 DTR 8 RI
9
GND
10
N/C
MANO500 Mini ITX Motherboard
Board and Pin Assignments 23
2.4.20 Fan Connectors (CPU_FAN1 and SYS_FAN1)
This motherboard has two fan connectors. Find fan speed option(s) of CPU_FAN1 at
BIOS Setup Utility: Advanced\HW Monitor\PC Health Status.
CPU_FAN1 (4x1-pin p=2.54mm):
SYS_FAN1 (3x1-pin p=2.54mm):
2.4.21 SIM Card Slot (SIM1)
The SIM1 is for inserting SIM Card. It is mainly used in 3G wireless network application.
In order to work properly, the SIM Card must be used together with 3G module which is
inserted to CN11.
2.4.22 SATA 3.0 Connectors (SATA1~SATA3)
This Serial Advanced Technology Attachment (Serial ATA or SATA) connector is for
SATA 3.0 interface allowing up to 6.0Gb/s data transfer rate. It is a computer bus
interface for connecting to devices such as hard disk drive.
Pin
Signal
1
GND
2
+12V
3
FAN Speed Detection
4
FAN Speed Control
Pin
Signal
1
GND
2
+12V
3
FAN Speed Detection
Pin
Signal
Pin
Signal
1
UIM_PWR
7
UIM_VPP
2
UIM_REST
8
GND
3
UIM_CLK
9
GND
4
N/C
10
GND
5
N/C
11
GND
6
UIM_DAT
12
GND
Pin
Signal
1
GND
2
SATA_TX+
3
SATA_TX-
4
GND
5
SATA_RX-
6
SATA_RX+
7
GND
1
MANO500 Mini ITX Motherboard
24 Board and Pin Assignments
This page is intentionally left blank.
MANO500 Mini ITX Motherboard
Hardware Description 25
Chapter 3
Hardware Description
3.1 Microprocessors
The MANO500 Series supports 6th/7th Generation Intel® Core™ i7/ i5/ i3, Pentium® and
Celeron® processors, which enable your system to operate under Windows® 10 and Linux
environments. The system performance depends on the microprocessor. Make sure all correct
settings are arranged for your installed microprocessor to prevent the CPU from damages.
3.2 BIOS
The MANO500 Series uses AMI Plug and Play BIOS with a single SPI Flash.
3.3 System Memory
The MANO500 supports two 288-pin DDR4 LONG-DIMM sockets for maximum memory
capacity up to 32GB DDR4 SDRAMs. The memory module comes in sizes of 2GB, 4GB, 8GB
and 16GB.
MANO500 Mini ITX Motherboard
26 Hardware Description
This page is intentionally left blank.
MANO500 Mini ITX Motherboard
AMI BIOS Setup Utility 27
Chapter 4
AMI BIOS Setup Utility
The AMI UEFI BIOS provides users with a built-in setup program to modify basic system
configuration. All configured parameters are stored in a flash chip to save the setup information
whenever the power is turned off. This chapter provides users with detailed description about
how to set up basic system configuration through the AMI BIOS setup utility.
4.1 Starting
To enter the setup screens, follow the steps below:
1. Turn on the computer and press <Del> during the Power On Self Test (POST) to enter
BIOS setup, otherwise, POST will continue with its test routines.
2. Once you enter the BIOS, the main BIOS setup menu displays. You can access the other
setup screens from the main BIOS setup menu, such as the Advanced and Chipset
menus.
Note
If your computer cannot boot after making and saving system changes with BIOS
setup, you can restore BIOS optimal defaults by setting JP1 (see section 2.3.1).
It is strongly recommended that you should avoid changing the chipset’s defaults. Both AMI
and your system manufacturer have carefully set up these defaults that provide the best
performance and reliability.
4.2 Navigation Keys
The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS
setup utility hot keys can be used at any time during the setup navigation process. These keys
include <F1>, <F2>, <Enter>, <ESC>, <Arrow> keys, and so on.
Note
Some of the navigation keys differ from one screen to another.
MANO500 Mini ITX Motherboard
28 AMI BIOS Setup Utility
Hot Keys
Description
Left/Right
The Left and Right <Arrow> keys allow you to select a setup screen.
Up/Down
The Up and Down <Arrow> keys allow you to select a setup screen or sub
screen.
Enter
The <Enter> key allows you to display or change the setup option listed for a
particular setup item. The <Enter> key can also allow you to display the setup
sub screens.
+ Plus/Minus
The Plus and Minus <Arrow> keys allow you to change the field value of a
particular setup item.
F1
The <F1> key allows you to display the General Help screen.
F2
The <F2> key allows you to Load Previous Values.
F3
The <F3> key allows you to Load Optimized Defaults.
F4
The <F4> key allows you to save any changes you have made and exit Setup.
Press the <F4> key to save your changes.
Esc
The <Esc> key allows you to discard any changes you have made and exit the
Setup. Press the <Esc> key to exit the setup without saving your changes.
MANO500 Mini ITX Motherboard
AMI BIOS Setup Utility 29
4.3 Main Menu
When you first enter the setup utility, you will enter the Main setup screen. You can always
return to the Main setup screen by selecting the Main tab. System Time/Date can be set up as
described below. The Main BIOS setup screen is shown below.
BIOS Information
Display the BIOS information.
System Date/Time
Use this option to change the system time and date. Highlight System Time or System Date
using the <Arrow> keys. Enter new values through the keyboard. Press the <Tab> key or the
<Arrow> keys to move between fields. The date must be entered in MM/DD/YY format. The
time is entered in HH:MM:SS format.
Access Level
Display the access level of current user.
MANO500 Mini ITX Motherboard
30 AMI BIOS Setup Utility
4.4 Advanced Menu
The Advanced menu also allows users to set configuration of the CPU and other system
devices. You can select any of the items in the left frame of the screen to go to the sub menus:
► ACPI Settings
► CPU Configuration
► SATA Configuration
► PCH-FW Configuration
► AMT Configuration(for Chipset Q170 only)
► USB Configuration
► IT8786 Super IO Configuration
► Hardware Monitor
► Smart Fan Function
► Utility Configuration
For items marked with “”, please press <Enter> for more options.
MANO500 Mini ITX Motherboard
AMI BIOS Setup Utility 31
ACPI Settings
ACPI Sleep State
Select the ACPI (Advanced Configuration and Power Interface) sleep state. Configuration
options are Suspend Disabled and S3 (Suspend to RAM). The S3 (Suspend to RAM)
option selects ACPI sleep state the system will enter when suspend button is pressed.
MANO500 Mini ITX Motherboard
32 AMI BIOS Setup Utility
CPU Configuration
This screen shows CPU information, and you can change the value of the selected option.
Hyper-threading
Enable or disable Hyper-threading Technology, which allows a single physical processor to
multitask as multiple logical processors. When disabled, only one thread per enabled core
is enabled.
Intel (VMX) Virtualization Technology
Enable or disable Intel Virtualization Technology. When enabled, a VMM (Virtual Machine
Mode) can utilize the additional hardware capabilities. It allows a platform to run multiple
operating systems and applications independently, hence enabling a single computer
system to work as several virtual systems.
MANO500 Mini ITX Motherboard
AMI BIOS Setup Utility 33
SATA Configuration
During system boot up, the BIOS automatically detects the presence of SATA devices. In
the SATA Configuration menu, you can see the currently installed hardware in the SATA
ports.
SATA Controller(s)
Enable or disable the SATA Controller feature. The default is Enabled.
MANO500 Mini ITX Motherboard
34 AMI BIOS Setup Utility
SATA Mode Selection
Determine how SATA controller(s) operate. Operation mode options are:
- AHCI (Advanced Host Controller Interface)
- RAID (for Chipset Q170 only)
PCH-FW Configuration
This screen displays ME Firmware information.
AMT Configuration (for Chipset Q170 only)
Use this screen to configure AMT parameters.
MANO500 Mini ITX Motherboard
AMI BIOS Setup Utility 35
AMT BIOS Features
Enable or disable Active Management Technology BIOS features. The default is Enabled.
USB Configuration
USB Devices
Display all detected USB devices.
MANO500 Mini ITX Motherboard
36 AMI BIOS Setup Utility
IT8786 Super IO Configuration
You can use this screen to select options for the Super IO Configuration, and change the
value of the selected option. A description of the selected item appears on the right side of
the screen. For items marked with “”, please press <Enter> for more options.
Serial Port 1~6 Configuration
Use these items to enable or disable serial port 1~6.
MANO500 Mini ITX Motherboard
AMI BIOS Setup Utility 37
Hardware Monitor
This screen monitors hardware health status.
This screen displays the temperature of system and CPU, cooling fans speed in RPM and
system voltages (VCC_CPU, VCC_DDR, +12V, +5V and +3.3V).
MANO500 Mini ITX Motherboard
38 AMI BIOS Setup Utility
Smart Fan Function
This screen allows you to select CPU fan mode.
CPU FAN
This item allows you to select the fan speed option(s) of CPU_FAN1 (See Section 2.4.20)
which can be set to Full on, Automatic mode and Manual Mode.
MANO500 Mini ITX Motherboard
AMI BIOS Setup Utility 39
Automatic mode
Follow super I/O IT8786 integrated automatic mode as the below to adjust the fan speed.
MANO500 Mini ITX Motherboard
40 AMI BIOS Setup Utility
Manual Mode
Input the Fan Start PWM to start the fan.
MANO500 Mini ITX Motherboard
AMI BIOS Setup Utility 41
Utility Configuration
BIOS Flash Utility
BIOS flash utility configuration. For more detailed information, please refer to Appendix B.
MANO500 Mini ITX Motherboard
42 AMI BIOS Setup Utility
4.5 Chipset Menu
The Chipset menu allows users to change the advanced chipset settings. You can select any
of the items in the left frame of the screen to go to the sub menus:
► System Agent (SA) Configuration
► PCH-IO Configuration
For items marked with “”, please press <Enter> for more options.
MANO500 Mini ITX Motherboard
AMI BIOS Setup Utility 43
System Agent (SA) Configuration
This screen allows users to configure System Agent (SA) parameters. For items marked
with “”, please press <Enter> for more options.
Graphics Configuration
Open sub menu for parameters related to graphics configuration.
Memory Configuration
Open sub menu for information related to system memory.
MANO500 Mini ITX Motherboard
44 AMI BIOS Setup Utility
Graphics Configuration
Primary IGFX Boot Display
Select the video device which will be activated during POST (Power-On Self Test). The
default is Auto.
Secondary IGFX Boot Display
After selecting other than “auto” on “Primary IGFX Boot Display”, the Secondary IGFX
Boot Display will show up and the options are Disabled, HDMI and VGA.
MANO500 Mini ITX Motherboard
AMI BIOS Setup Utility 45
LVDS Panel Type
Select LVDS panel resolution.
MANO500 Mini ITX Motherboard
46 AMI BIOS Setup Utility
Backlight Control
This item is for backlight control setting. Selection options are PWM Inverted and PWM
Normal.
If the LCD brightness regards 5V PWM signal as the brightest, PWM Inverted shall be
selected.
MANO500 Mini ITX Motherboard
AMI BIOS Setup Utility 47
Memory Configuration
This screen shows the system memory information.
MANO500 Mini ITX Motherboard
48 AMI BIOS Setup Utility
PCH-IO Configuration
This screen allows you to set PCH parameters.
PCH LAN Controller
Enable or disable onboard PCH LAN controller.
Wake on LAN
After enabling PCH LAN Controller, enabling or disabling integrated LAN to wake the
system.
WOL After G3 State
Enable or disable Wake-on-LAN after Mechanical Off (System Power State G3).
MANO500 Mini ITX Motherboard
AMI BIOS Setup Utility 49
4.6 Security Menu
The Security menu allows users to change the security settings for the system.
Administrator Password
This item indicates whether an administrator password has been set (installed or
uninstalled).
User Password
This item indicates whether a user password has been set (installed or uninstalled).
MANO500 Mini ITX Motherboard
50 AMI BIOS Setup Utility
4.7 Boot Menu
The Boot menu allows users to change boot options of the system.
Setup Prompt Timeout
Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite
waiting.
Bootup NumLock State
Use this item to select the power-on state for the keyboard NumLock.
Quiet Boot
Select to display either POST output messages or a splash screen during boot-up.
Legacy PXE OpROM policy
Use this item to enable or disable the boot ROM function of the onboard LAN chip when
the system boots up.
Boot Option Priorities
These are settings for boot priority. Specify the boot device priority sequence from the
available devices.
MANO500 Mini ITX Motherboard
AMI BIOS Setup Utility 51
4.8 Save & Exit Menu
The Save & Exit menu allows users to load your system configuration with optimal or fail-safe
default values.
Save Changes and Exit
When you have completed the system configuration changes, select this option to leave
Setup and return to Main Menu. Select Save Changes and Exit from the Save & Exit menu
and press <Enter>. Select Yes to save changes and exit.
Discard Changes and Exit
Select this option to quit Setup without making any permanent changes to the system
configuration and return to Main Menu. Select Discard Changes and Exit from the Save &
Exit menu and press <Enter>. Select Yes to discard changes and exit.
Save Changes and Reset
When you have completed the system configuration changes, select this option to leave
Setup and reboot the computer so the new system configuration parameters can take
effect. Select Save Changes and Reset from the Save & Exit menu and press <Enter>.
Select Yes to save changes and reset.
Discard Changes and Reset
Select this option to quit Setup without making any permanent changes to the system
configuration and reboot the computer. Select Discard Changes and Reset from the Save
& Exit menu and press <Enter>. Select Yes to discard changes and reset.
Save Changes
When you have completed the system configuration changes, select this option to save
changes. Select Save Changes from the Save & Exit menu and press <Enter>. Select Yes
to save changes.
MANO500 Mini ITX Motherboard
52 AMI BIOS Setup Utility
Discard Changes
Select this option to quit Setup without making any permanent changes to the system
configuration. Select Discard Changes from the Save & Exit menu and press <Enter>.
Select Yes to discard changes.
Restore Defaults
It automatically sets all Setup options to a complete set of default settings when you select
this option. Select Restore Defaults from the Save & Exit menu and press <Enter>.
Save as User Defaults
Select this option to save system configuration changes done so far as User Defaults.
Select Save as User Defaults from the Save & Exit menu and press <Enter>.
Restore User Defaults
It automatically sets all Setup options to a complete set of User Defaults when you select
this option. Select Restore User Defaults from the Save & Exit menu and press <Enter>.
Boot Override
Select a drive to immediately boot that device regardless of the current boot order.
MANO500 Mini ITX Motherboard
Watchdog Timer 53
Appendix A
Watchdog Timer
B.1 About Watchdog Timer
Software stability is major issue in most application. Some embedded systems are not
watched by human for 24 hours. It is usually too slow to wait for someone to reboot when
computer hangs. The systems need to be able to reset automatically when things go wrong.
The watchdog timer gives us solution.
The watchdog timer is a counter that triggers a system reset when it counts down to zero from
a preset value. The software starts counter with an initial value and must reset it periodically. If
the counter ever reaches zero which means the software has crashed, the system will reboot.
B.2 Sample Program
1. Enter ADU, and press <F4> to select the superior ITE
2. PORT setting 002E, 002F
3. Address 07h setting 07 GPIO
4. Address 72h to set the countdown, for example Sec: C0, Min: 40
5. Address 73h set the countdown time, for example 10sec: 0A
MANO500 Mini ITX Motherboard
54 Watchdog Timer
This page is intentionally left blank.
MANO500 Mini ITX Motherboard
BIOS Flash Utility 55
Appendix B
BIOS Flash Utility
The BIOS Flash utility is a new helpful function in BIOS setup program. With this function you
can easily update system BIOS without having to enter operating system. In this appendix you
may learn how to do it in just a few steps. Please read and follow the instructions below
carefully.
1. In your USB flash drive, create a new folder and name it “Axiomtek”, see figure below.
2. Copy BIOS ROM file (e.g. MANO500.005) to “Axiomtek” folder.
3. Insert the USB flash drive to your system.
4. Enter BIOS setup menu and go to Advanced\Utility Configuration. Select BIOS Flash
Utility and press <Enter>.
MANO500.005
MANO500 Mini ITX Motherboard
56 BIOS Flash Utility
5. BIOS automatically detect all USB drive(s) attached to the system. In this example only
one USB drive is attached to the system. That’s why, you can see only one device is
displayed in figure below.
6. Select the USB drive containing BIOS ROM file you want to update using the <> or
<> key. Then press <Enter> to get into “Axiomtek” folder.
7. Now you can see the BIOS ROM file on the screen, press <Enter> to select.
8. Select Start to flash system BIOS option to begin updating procedure.
MANO500.005
MANO500 Mini ITX Motherboard
BIOS Flash Utility 57
9. Please wait while BIOS completes the entire flash update process: erase data, write new
data and verify data.
10. When you see the following figure, press <Enter> to finish the update process. After that
the system will shut down and restart immediately.
Loading...
