AX92321-4U/8U
4-port/8-port USB3.0 PCI Express
Card with 4 independent host
controllers
User’s Manual
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or rights of any
third party, or any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
Copyright 2019 Axiomtek Co., Ltd.
All Rights Reserved
May 2019, Version A2
Printed in Taiwan
ii
ESD Precautions
The boards have integrated circuits sensitive to static electricity. To avoid damaging chipsets
from electrostatic discharge, observe the following precautions:
Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
Before handling a board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. This will help to discharge any static electricity on a
human body.
When handling boards and components, wear a grounding wrist strap available from
most electronic component stores.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Windows® is a trademark of Microsoft Corporation.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel® is a trademark of Intel Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.
iii
Table of Contents
Disclaimers ..................................................................................................... ii
ESD Precautions ........................................................................................... iii
Section 1 Introduction ............................................. 1
1.1 General Description ............................................................................ 1
1.2 Features ............................................................................................... 1
1.3 Specifications ...................................................................................... 2
1.4 Dimensions .......................................................................................... 3
Section 2 Connectors & Jumper ............................. 5
2.1 Connectors .......................................................................................... 5
2.1.1 12/24V Power Input (ATX1) ........................................................................ 5
2.1.2 4P Molex Male connector (ATX2) ............................................................... 6
2.2 Jumper setting for current limit ......................................................... 6
2.2.1 Output current USB port setting (JP1~JP8) ................................................ 6
2.2.2 Board ID (JP9~JP11) .................................................................................. 6
Chapter 3 Software .................................................. 9
3.1 software User Guide ........................................................................... 9
iv
AX92321-4U/8U 4/8 port USB 3.0 PCI Express Card
Section 1
Introduction
This section contains general information and detailed specifications of the AX92321-4U/8U
4/8-port USB 3.0 PCI Express card, including the following sections:
General Description
Features
Specifications
Dimensions
1.1 General Description
The AX92321 has two versions – 4-port or 8-port – for users to choose from for various
applications. The 4-port AX92321-4U has four independent Renesas μPD720202 USB 3.0
host controllers to offer up to 5 Gbps bandwidth per port, even when four ports are used
simultaneously. The AX92321-4U/8U can be configured to support maximum 900mA or
1500mA current output to supply stable power for various external USB devices. The
AX92321-4U/8U also support power on/off control for each port via software settings. This
USB 3.0 PCI Express card is able to operate under a wide operating temperature range of 0°C
to 70°C, allowing it to be used in harsh environments for vision and factory automation
applications.
1.2 Features
Four or eight USB 3.0 ports
Four independent USB 3.0 host controllers
900 mA/1500 mA max. per port configurable via jumper settings
Compliant with USB 3.0 Rev.1.0 and Intel® xHCI Rev.1.0
PCI Express x4 interface
Operating temperature from 0˚C to 70°C
Supports Windows7/10
Supports power on/off for each port via software settings
Introduction 1
AX92321-4U/8U 4/8 port USB 3.0 PCI Express Card
1.3 Specifications
Channels
4/8 x USB 3.0 type A connector
Controller
4 x Renesas μPD720202 host controllers; compliant with USB 3.0 specification and
Intel® xHCI specification, revision 1.0
Max. Current
900/1500 mA maximum per port configurable via jumper settings
Data Transfer Rate
Super speed (5.0 Gbps)/high speed (480.0 Mbps)/full speed (12.0 Mbps)/low speed
(1.5 Mbps)
Dimensions
W 168mm x D 107 mm
OS Support
Windows® 7, Windows® 10 (32/64-bit)
Environmental
Operating temperature: 0°C ~ 70°C
Operating humidity 10% ~ 95% non-condensing
Storage temperature: -20°C ~ 80°C
Certifications
CE compliance
Power Requirements
Power from PCIe slot (Max. 20W output)
2.1A@ +12V
0.8A @ +3.3V
Power from ATX power connector
(Max. 60W output for ATX power or 4P Molex power)
5A @ +12V or 2.5A @ +24V
0.8A @ +3.3V (from PCIe slot)
Power from 4P Molex power connector
5A @ +12V
0.8A @ +3.3V (from PCIe slot)
2 Introduction
1.4 Dimensions
AX92321-4U/8U 4/8 port USB 3.0 PCI Express Card
AX92321-4U Component Side
AX92321-4U Solder Side
Introduction 3
AX92321-4U/8U 4/8 port USB 3.0 PCI Express Card
AX92321-8U Component Side
AX92321-8U Solder Side
4 Introduction
AX92321-4U/8U 4/8 port USB 3.0 PCI Express Card
Connectors
Label
ATX1
2.1.1
ATX2
2.1.2
Pin
Signal
1
+12V / +24V
2
+12V / +24V
3
+12V / +24V
4
Ground (GND)
5
Ground (GND)
6
Ground (GND)
Section 2
Connectors & Jumper
2.1 Connectors
Connectors connect the board with other parts of the system. Loose or improper connection
might cause malfunctions. Make sure all connectors are properly and firmly connected.
The following table lists the function of each connector on the AX92321.
2.1.1 12/24V Power Input (ATX1)
Note: 24V is for Axiomtek’s system use only.
Connectors 5
AX92321-4U/8U 4/8 port USB 3.0 PCI Express Card
Jumper
Label
JP1~JP8
2.2.1
JP9~JP11
2.2.2
Pin
Description
1
12V
2
GND
3
GND
4
NC
Function
Setting
900mA
1-2 close
1500mA
2-3 close
Function
Setting
Bit=1
1-2 close
Bit=0
2-3 close
2.1.2 4P Molex Male connector (ATX2)
2.2 Jumper setting for current limit
The following table lists each jumper on the AX92321.
2.2.1 Output current USB port setting (JP1~JP8)
If a device over current setting, a USB port will stop providing current. When you restart
the system, the USB port will recover this function.
2.2.2 Board ID (JP9~JP11)
Default jumper setting is 0.
6 Connectors
AX92321-4U/8U 4/8 port USB 3.0 PCI Express Card
JP9
JP10
JP11
Board ID
0 0 0 0 0 0 1 1 0 1 0 2 0 1 1 3 1 0 0 4 1 0 1 5 1 1 0 6 1 1 1
7
Example:
When JP9, JP10 both set to 0 and JP11 set to 1, the board ID is 1 Please also refer to
the configuration as the picture below illustrates.
Note: When you use two or more cards in your system, please use this
configuration.
Connectors 7
AX92321-4U/8U 4/8 port USB 3.0 PCI Express Card
This page is intentionally left blank.
8 Connectors
AX92321-4U/8U 4/8 port USB 3.0 PCI Express Card
Chapter 3
Software
3.1 Software User Guide
The tool allows you to easily verify AX92321 module; further, It also supports power
on/off control for recovering each port.
1. Board ID List
This section will show available devices in your system.
2. Port Status
Check/Uncheck to control port status. (Checked as ON)
Note: AX92321-4U: Port1, Port3, Port5 and Port7 are not valid.
Software 9
