Axiom Manufacturing DEMO9S08DZ60 User guide

DOC-0407-010, REV A

DEMO9S08DZ60

Demonstration Board for Freescale MC9S08DZ60

Axiom Manufacturing • 2813 Industrial Lane • Garland, TX 75041

Email: [e-mail] Web: http://www.axman.com

DEMO9S08DZ60 DECEMBER 2, 2006

CONTENTS

CAUTIONARY NOTES ..............................................................................................................4

TERMINOLOGY.........................................................................................................................4

FEATURES................................................................................................................................5

REFERENCES...........................................................................................................................6

GETTING STARTED..................................................................................................................6

OPERATING MODES................................................................................................................6

RUN MODE........................................................................................................................... 6

DEBUG MODE......................................................................................................................7

MEMORY MAP ..........................................................................................................................7

SOFTWARE DEVELOPMENT...................................................................................................8

DEVELOPMENT SUPPORT......................................................................................................8

INTEGRATED BDM .............................................................................................................. 8

BDM_PORT HEADER........................................................................................................... 9

POWER......................................................................................................................................9

POWER SELECT.................................................................................................................. 9

PWR_SEL.........................................................................................................................9

VX_EN............................................................................................................................. 10

RESET SWITCH ......................................................................................................................10

LOW VOLTAGE RESET..........................................................................................................11

TIMING.....................................................................................................................................11

COMMUNICATIONS................................................................................................................ 11

RS-232 ................................................................................................................................ 11

COM CONNECTOR........................................................................................................ 12

LIN COMMUNICATIONS..................................................................................................... 12

LIN_EN............................................................................................................................ 12

CAN COMMUNICATIONS................................................................................................... 13

CAN TERMINATION....................................................................................................... 13

VRH/VRL..................................................................................................................................13

USER I/O..................................................................................................................................14

POT................................................................................................................................. 14

SWITCHES ..................................................................................................................... 14

LED’S.............................................................................................................................. 14

USER SIGNALS.................................................................................................................. 14

USER ENABLE ................................................................................................................... 15

MCU I/O PORT.........................................................................................................................15

2

DEMO9S08DZ60 DECEMBER 2, 2006

FIGURES

Figure 1: BDM_PORT Header....................................................................................................9

Figure 2: PWR_SEL Option Header...........................................................................................9

Figure 3: VX_EN Option Header ..............................................................................................10

Figure 4: CLK_SEL Option Header ..........................................................................................11

Figure 5: COM Connector.........................................................................................................12

Figure 6: LIN Connector ...........................................................................................................12

Figure 7: LIN_EN Option Header..............................................................................................12

Figure 8: CAN_PORT Connector .............................................................................................13

Figure 9: CTE Option Header...................................................................................................13

Figure 10: USER Option Header..............................................................................................15

Figure 11: MCU I/O PORT – J1................................................................................................16

Figure 12: MCU I/O PORT – J2................................................................................................16

TABLES

Table 1: Run Mode Setup...........................................................................................................6

Table 2: BDM Mode Setup .........................................................................................................7

Table 3: Memory Map.................................................................................................................8

Table 4: COM Connections ......................................................................................................12

Table 5: ATD Reference Voltage..............................................................................................14

Table 6: User I/O...................................................................................................................... 15

REVISION

Date Rev Comments

December 2, 2006 A Initial Release

3

DEMO9S08DZ60 DECEMBER 2, 2006

CAUTIONARY NOTES

1) Electrostatic Discharge (ESD) prevention measures should be used when handling this
product. ESD damage is not a warranty repair item.

2) Axiom Manufacturing does not assume any liability arising out of the application or use of
any product or circuit described herein; neither does it convey any license under patent
rights or the rights of others.

3) 3) EMC Information on the DEMO9S08DZ60 board:
a) This product as shipped from the factory with associated power supplies and cables,

has been verified to meet with requirements of CE and the FCC as a CLASS A product.

b) This product is designed and intended for use as a development platform for hardware

or software in an educational or professional laboratory.

c) In a domestic environment, this product may cause radio interference in which case the

user may be required to take adequate prevention measures.

d) Attaching additional wiring to this product or modifying the products operation from the

factory default as shipped may effect its performance and cause interference with
nearby electronic equipment. If such interference is detected, suitable mitigating
measures should be taken.

TERMINOLOGY

This development module utilizes option select jumpers to configure default board operation.
Terminology for application of the option jumpers is as follows:

Jumper – a plastic shunt that connects 2 terminals electrically
Jumper on, in, or installed - jumper is installed such that 2 pins are connected together
Jumper off, out, or idle - jumper is installed on 1 pin only. It is recommended that

jumpers be idled by installing on 1 pin so they will not be lost.

4

DEMO9S08DZ60 DECEMBER 2, 2006

FEATURES

The DEMO9S08DZ60 is a demonstration board for the MC9S08DZ60 microcontroller.
Application development is quick and easy with the integrated USB-BDM, sample software
tools, and examples. An optional BDM_PORT port is also provided to allow use of a
BDM_PORT cable. Two, 40-pin connectors provide access to all IO signals on the target
MCU.

• MC9S08DZ60, 64 LQFP

• 32K Bytes Flash

• 4K Bytes RAM

• 2K Bytes EEPROM

• Timing Sources

• 4 MHz XTAL

• OSC socket

• BNC connector

• Integrated P&E USB-BDM

• BDM_PORT header for BDM cable support (not installed)

• LIN PHY w/ 2, 4-pos Molex connectors

• HS-CAN PHY w/ 3-pos pin header connector

• LP Filters on ADC inputs

• 2 ea., MCU_PORT socket headers for access to MCU IO signals

• On-board +5V regulator

• Optional Power from USB-BDM or MCU_PORT connector

• Power Input Selection Jumpers

• Power input from USB-BDM

• Power input from on-board regulator

• Power input from Connector J1

• Optional Power output through Connector J1

• User Components Provided

• 3 Push Switches; 2 User, 1 Reset

• 1 4-pos DIP Switch

• 7 LED Indicators; 4 User, VDD, USB Power, USB Power Out

• 2ea. 5K ohm POTs w /LP Filter

• Jumpers

• Power Select

• VSEL

• VX_EN

• USER_EN

• Connectors

• 2 40-pin MCU I/O Connector

• 2.0mm Barrel Connector

• BDM_PORT

• USB Connectors

• DB9 Connector

Specifications:

Board Size 3.5” x 4.0”
Power Input: +6VDC to +18VDC

NOTE: LIN functionality supported when powered from PWR connector only

5

DEMO9S08DZ60 DECEMBER 2, 2006

REFERENCES

Reference documents are provided on the support CD in Acrobat Reader format.
DEMO9S08DZ60_UG.pdf DEMO9S08DZ60 User Guide (this document)

DEMO9S08DZ60_QSG.pdf DEMO9S08DZ60 Quick Start Guide
DEMO9S08DZ60 _SCH_B.pdf DEMO9S08DZ60 Schematic Rev. B
DEMO9S08DZ60_Silk_B.pdf DEMO9S08DZ60 Top Silk, Rev B

GETTING STARTED

To get started quickly, please refer to the DEMO9S08DZ60 Quick Start Guide. This quick start
will show the user how to connect the board to the PC, install the correct version of
CodeWarrior Development Studio, and run a simple LED test program.

OPERATING MODES

The DEMO9S08DZ60 board operates in two operating modes: Run Mode, or Debug Mode.
Run Mode executes the user application from Power-On or Reset. Debug Mode supports the
development and debug of applications. See the related sections below for quickly starting the
board in the desired operation mode.

RUN MODE

Run mode executes the user application when power is applied to the board or the RESET
button is pressed. Use the following settings to configure the DEMO9S08DZ60 board for RUN
Mode to get started quickly.

1. Connect auxiliary equipment to board as required by application.

2. Configure the board option jumpers for run mode.

Table 1: Run Mode Setup

PWR_SEL Pin1 – Pin2 (VB)
CLK_SEL Pin1 – Pin2 (Y1)
VX_EN As Required
USER As Required
LIN_EN As Required

NOTE: See Power section below to configure power input from PWR connecto r or from J1 connector.

3. Apply power to the board.

4. The programmed application will begin to execute.

6

DEMO9S08DZ60 DECEMBER 2, 2006

Debug Mode

Debug Mode supports application development and debug. Debug mode is available to the
user through the integrated USB-Multilink BDM or through the use of an external
HCS12/HCS08 BDM cable. Use of the integrated USB-Multilink BDM requires only a host PC
with an available USB port and an A/B type USB cable. A 6-pin BDM interface header
(BDM_PORT) supports the use of an external HCS12 BDM cable. The BDM_PORT header is
not installed in default configuration. The steps below describe using the integrated USB­Multilink BDM.

1. Connect auxiliary equipment to board as required by application.

2. Install and launch P&E PKGHCS08Z tool set, CodeWarrior Development Studio, or other
software capable of communicating with the HCS12/HCS08 MCU.

3. Configure the board option jumpers for DEBUG mode.

Table 2: BDM Mode Setup

PWR_SEL Pin1 – Pin2 (VB)
CLK_SEL Pin1 – Pin2 (Y1)
VX_EN As Required
USER As Required
LIN_EN As Required

NOTE: Refer to the Development Support section below for details on using an external HCS12 BDM cable.

4. Connect the supplied USB cable between an available USB port on the host PC and the
USB connector on the board.

5. Hosting development software will establish DEBUG communication.

6. Refer to BDM cable documentation for details on use of BDM.

MEMORY MAP

The table below shows the default memory map for the MC9S08DZ60 immediately out of
reset.

7

DEMO9S08DZ60 DECEMBER 2, 2006

Table 3: Memory Map

$0000 ­$007F
$0080 ­$107F
$1080 ­$13FF
$1400 ­$17FF
$1800 ­$18FF
$1900 ­$FFFF

REGISTERS 128 bytes
RAM 4096 bytes
FLASH 896 bytes
EEPROM 2 x 1024 bytes
High Page Registers 256
FLASH 59136 bytes

SOFTWARE DEVELOPMENT

Software development requires the use of an assembler or compiler supporting the HCS08
instruction set and a host PC operating a debug interface. CodeWarrior Development Studio
and Axiom IDE for Windows for Debugging and Flash programming are supplied with this
board.

DEVELOPMENT SUPPORT

Application development and debug for the target MC9S08DZ60 is supported through a
background debug mode (BDM) interface. The BDM interface consists of an integrated USB­Multilink BDM and a 6-pin interface header (BDM_PORT) to connect a HCS12/HCS08 BDM
cable.

Integrated BDM

The DEMO9S08DZ60 board features an integrated USB-Multilink BDM from P&E
Microcomputer Systems. The integrated USB-Multilink BDM supports application development
and debugging via background debug mode. All necessary signals are provided by the
integrated USB-Multilink BDM. A USB, type B, connector provides connection from the target
board to the host PC.

The integrated USB-Multilink BDM provides +5V power and ground to target board eliminating
the need to power the board externally. Power from the USB-Multilink BDM is derived from the
USB bus; therefore, total current consumption for the target board, and connected circuitry,
must not exceed 500mA. This current limit describes the current supplied by the USB cable
to the BDM circuit, the target board, and any connected circuitry. Excessive current drain will
violate the USB specification causing the bus to disconnect. Damage to the host PC USB hub
or the target board may result.

8

DEMO9S08DZ60 DECEMBER 2, 2006

BDM_PORT Header

A compatible HCS12 BDM cable can also attach to the 6-pin BDM interface header
(BDM_PORT). This header is not installed in default configuration. The figure below shows
the pin-out for the DEBUG header

Figure 1: BDM_PORT Header

BKGD

NOTE: This header is not installed in default configuration.

1 2
3 4
5 6

GND
RESET*
VDD

See the HC(S)08 Reference Manual for complete
DEBUG documentation

POWER

The DEMO9S08DZ60 is designed to allow the user to power the board through the USB­Multilink BDM during application development. A 2.0-mm barrel connector has been applied to
support stand-alone operation and to support LIN functionality. The board may also be
powered through connector J1. This connection may also be used to supply power from the
board to external circuitry.

During application development, the board may be powered from either the USB-BDM or the
PWR connector. To utilize LIN functionality, the board must be powered from PWR connector
with a typical input voltage of +12VDC.

POWER SELECT

Power may be applied to the board through the integrated USB-Multilink BDM circuitry, a

2.0mm barrel connector, or through connector J1. Power selection is achieved using 2

selection headers: PWR_SEL option header and the VX_EN option header.

PWR_SEL

The PWR_SEL option header selects power input either from the integrated USB-Multilink
BDM circuitry or from the on-board voltage regulator. The figure below details the PWR_SEL
header connections.

Figure 2: PWR_SEL Option Header

CONFIGURATION

VB

1 2 3

PWR_SEL

VDD

1 – 2: Selects power input from USB-ML12
2 – 3: Selects power input from on-board regulator or J1

9

DEMO9S08DZ60 DECEMBER 2, 2006

NOTE: Set PWR_SEL jumper to VB during application development. Use barrel connector

input (PWR) to support LIN functionality if needed.

Power from the integrated BDM is drawn from the USB bus and is limited to 500 mA. This
current limit accounts for the total current supplied over the USB cable to the BDM circuit, the
target board, and any connected circuitry. Current drain in excess of 500 mA will violate the
USB specification and will cause the USB bus to disconnect. Damage to the host PC or the
target board may also result.

The on-board voltage regulator (VR1) accepts power input through a 2.0mm barrel connector
(PWR). Input voltage may range from +6V to +18V. The voltage regulator (VR1) provides a
+5V fixed output limited to 250mA. Over-temperature and over-current limit built into the
voltage regulator provides protection from excessive stress. The user must consider the
maximum output current limit of VR1 when attempting to power off-board circuitry through
connector J1.

If powered from the PWR connector, the integrated BDM may still be used to develop and
debug application code. Alternately, the board may be powered from the integrated BDM
while the LIN bus is powered from the PWR connector.

VX_EN

The VX_EN option header is a 2-pin jumper that connects or disconnects input J1-1 directly to
the target board +5V voltage rail. J1-3 is directly connected to the ground plane. Use of this
feature requires a regulated +5V input power source. This power input is decoupled to
minimize noise but is not regulated. Care should be exercised when using this feature; no
protection is applied on this input and damage to the target board may result if over-driven.
Also, do not attempt to power the target board through this connector while also applying
power through the USB-Multilink BDM or the PWR connector; damage to the board may result.

Power may also be sourced to off-board circuitry through the J1 connector. The current
supplied from the USB bus or the on-board regulator limits current output to external circuitry.
Excessive current drain may damage the target board, the host PC USB hub, or the on-board
regulator. The figure below details the VX_EN header connections.

Figure 3: VX_EN Option Header

ON OFF

1 2

VX_EN

Enabled Disabled

CAUTION: Do not exceed available current supply from USB-Multilink BDM or on-board

regulator, when sourcing power through connector J1 to external circuitry.

RESET SWITCH

10

DEMO9S08DZ60 DECEMBER 2, 2006

The RESET switch provides a method to apply an asynchronous RESET to the MCU. The
RESET switch is connected directly to the RESET* input on the MCU. Pressing the RESET
switch applies a low voltage level to the RESET* input. A pull-up bias resistor allows normal
MCU operation. Shunt capacitance ensures an adequate input pulse width.

LOW VOLTAGE RESET

The MC9S08DZ60 utilizes an internal Low Voltage Detect (LVD) circuit. The LVD holds the
MCU in reset until applied voltage reaches an appropriate level. The LVD also protect against
under-voltage conditions. Consult the MC9S08DZ60 reference manual for details LVD
operation.

TIMING

The DEMO9S08DZ60 provide 1 internal and 2 external timing sources. The 32 kHz internal
timing source, with ±0.2% resolution, is active out of RESET. An external crystal with ±50ppm
resolution is also provided. A full-size socket allows alternate square-wave clock inputs to be
applied. The target MCU must be configured to select either external timing input source.
Refer to the target MCU documentation for details on configuring external timing inputs.

The CLK_SEL option header selects the on-board XTAL oscillator, or the optional CLOCK
oscillator socket. The figure below shows settings for CLK_SEL option header.

Figure 4: CLK_SEL Option Header

CLK_SEL

X1
Y1

1 2
3 4

Select XTAL oscillator X1 output
Select Clock oscillator Y1 output (default)

COMMUNICATIONS

The DEMO9S08DZ60 board applies two Serial Communications Interface (SCI) ports. SCI0 is
applied to RS-232 serial communications (COM) on the target board. SCI1 is applied to LIN
communications on the target board. RS-232 communications are supported through a DB9
connector. LIN communications are supported through a pair of 4-pin Molex connectors.

RS-232

An RS-232 translator provides RS-232 to TTL/CMOS logic level translation on the COM
connector. The COM connector is a 9-pin Dsub, right-angle connector. A ferrite bead on
shield ground provides conducted immunity protection. Communication signals TXD1 and
RXD1 are routed from the transceiver to the MCU. Hardware flow control signals RTS and
CTS are available on the logic side of the transceiver. These signals are routed to vias located
near the transceiver. RTS has been biased properly to support 2-wire RS-232
communications.

11

DEMO9S08DZ60 DECEMBER 2, 2006

Table 4: COM Connections

MCU Port COM Signal I/O PORT

CONNECTOR

PTE0/TXD1 TXD J1-5
PTE1/RXD1 RXD J1-7

COM Connector

A standard 9-pin Dsub connector provides external connections for the SCI0 port. The Dsub
shell is connected to board ground through a ferrite bead. The ferrite bead provides noise
isolation on the RS-232 connection. The figure below details the DB9 connector.

Figure 5: COM Connector

4, 6

TXD

RXD

1, 6

GND

1
2
3
4
5

1, 4

6

RTS

7

CTS

8

NC

9

Female DB9 connector that interfaces to the MCU internal SCI0 serial
port via the RS232 transceiver. Flow control is provided at test points on
the board.

Pins 1, 4, and 6 are connected together.

LIN Communications

The DEMO9S08DZ60 applies the MC33661D Local Interconnect Interface (LIN) physical layer
(PHY) for use in developing automotive control applications. The MC33661D physical layer
interface (PHY) supports LIN bus functionality for input voltages between +6V and +18V. Only
power applied to the PWR connector will enable the LIN bus. Two, 4-pin, Molex connectors
provide off-board connectivity. The figure below shows the pin-out of the LIN connector
looking into the connector.

Figure 6: LIN Connector

LIN I/O

GND

NOTE: +12V must be applied to the PWR connector when using the LIN functionality.

4 3
2 1

V

SUP

GND

REF: Mating Connector, Molex P/N,

39-01-2040, Housing
39-00-0039, Socket

LIN_EN

The LIN_EN option header connects or disconnects the LIN PHY to SCI1.

Figure 7: LIN_EN Option Header

LIN_EN

4 3
2 1

NOTE: +12V must be applied to the PWR connector when using the LIN functionality.

TX Enable LIN TX
RX Enable LIN RX

12

DEMO9S08DZ60 DECEMBER 2, 2006

CAN Communications

The DEMO9S08DZ60 provides a high-speed CAN physical layer interface (PHY). A 3-pin
connector provides connectivity to the off-board CAN bus. The CAN PHY connects to the
CAN0 channel on the MCU. The PHY supports data rates up to 1 MBPS with edge-rate
control to reduce EMI/RFI. The figure below shows the pin-out of the CAN_PORT connector.

Figure 8: CAN_PORT Connector

1
2
3

CAN_H
GND
CAN_L

The CAN PHY connects to the CAN0
channel in the MCU

CAN Termination

The DEMO9S08DZ60 applies a 121 ohm differential termination to the CAN bus. An option
jumper allows the user to selectively apply termination. Installing the CTE option jumper
applies termination to the differential CAN bus. Removing the CTE option jumper removes the
CAN termination.

Figure 9: CTE Option Header

ON OFF

1 2

CTE

Enabled Disabled

VRH/VRL

MCU inputs VRH and VRL provide the upper and lower voltage reference for the analog to
digital (ATD) converter. By default, VRH is tied to VDD and VRL is tied to ground. Adequate
filtering has been added to provide a voltage reference with minimal ripple. Either, or both,
references may be isolated to provide alternate ATD input references. A test point via on each
signal, labeled VRH, or VRL, provides a convenient attach point.

A 0-ohm configuration resistor allows isolation of each reference voltage. Removing R25
isolates VRH while removing R26 isolates VRL. Install 0805 sized 0-ohm resistors in these
locations to restore the board to default configuration.

Care must be exercised when using alternate input references. The associated isolation
resistor must be removed before applying an alternate voltage reference or the board may be
damaged. The table below summarizes the changes necessary to use alternate VRH and/or
VRL.

13

DEMO9S08DZ60 DECEMBER 2, 2006

Table 5: ATD Reference Voltage

Installed (Default) Removed
R25 VRH = VDD VRH provided by user
R26 VRL = GND VRL provided by user

NOTE: Damage to the board may result if an alternate reference voltage is attached without

first removing the associated configuration resistor.

USER I/O

User I/O includes 2 potentiometers, 1 4-position DIP switch, 2 push button switches, and 2
green LEDs for user I/O. The User option header block enables or disables each User I/O
individually.

POT

The DEMO9S08DZ60 target board provides 2 5K ohm trimmer potentiometers (POT) have
been provided to simulate analog input. Both parts are decoupled to minimize noise during
adjustment. Potentiometer RV1 connects to analog input PTB4/ADP12. Potentiometer RV2
connects to analog input PTB5/ADP13. . The figure below shows the USER enable position
and associated signal for the potentiometer.

SWITCHES

The DEMO9S08DZ60 target board provides 2 push button switches and one 4-position DIP
switch for user input. Each push button switch is an active low input with a pull-up resistor bias
to prevent indeterminate input conditions. Pressing a push-button switch causes a low logic
input on the associated input.

Each DIP switch position is an active low input. Use of the DIP switches requires enabling the
associated, internal PORTG pull-ups on the MCU prevent indeterminate input conditions.
Moving a DIP switch position to ON causes a low logic level on the associated input. The
figure below shows the USER enable position and associated signal for each user switch.

LED’s

The DEMO9S08DZ60 target board provides 2 green LEDs for output indication. Each LED is
an active low output. Writing a low logic level to an LED output causes the associated LED to
turn on. A series, current-limit resistor prevents excessive diode current. The figure below
shows the USER enable position and associated signal for each user LED.

User Signals

The following table shows the connections for each user I/O device.

14

DEMO9S08DZ60 DECEMBER 2, 2006

Table 6: User I/O

USER Ref Des Signal Device

1
2
3
4
5
6
7
8
9

10

RV1 PTB4/ADP12 Potentiometer

RV2 PTB5/ADP13 Potentiometer
SW1-1 PTG2 4-pos DIP Switch
SW1-2 PTG3 4-pos DIP Switch
SW1-3 PTG4 4-pos DIP Switch
SW1-4 PTG5 4-pos DIP Switch

LED1 PTC5/ADP21 Green LED
LED2 PTB3/ADP11 Green LED

SW1 PTB6/ADP14 Push Button Switch
SW2 PTB7/ADP15 Push Button Switch

User Enable

The User option header block enables or disables each User I/O device individually. User I/O
includes 4 green LEDs, 2 push button switches, one 4-position DIP switch, a Light Sensor, and
a potentiometer. Installing a shunt enables the associated option. Removing a shunt disables
the associated option. The table below shows the configuration option for each USER I/O.

Figure 10: USER Option Header

Shunt

USER Installed Removed Description

10

1
2
3
4
5
6
7
8
9

1 2
3 4
5 6
7 8

9 10
11 12
13 14
15 16
17 18
19 20

Enable Disable Potentiometer
Enable Disable Potentiometer
Enable Disable DIP Switch Position 1
Enable Disable DIP Switch Position 2
Enable Disable DIP Switch Position 3
Enable Disable DIP Switch Position 4
Enable Disable LED 1
Enable Disable LED 2
Enable Disable Push Button Switch 1
Enable Disable Push Button Switch 2

MCU I/O PORT

The MCU I/O PORT connectors (J1 and J2) provide access to the MC9S08DZ60 I/O signals.
The figures below show the pin-out for each MCU I/O connector.

15

DEMO9S08DZ60 DECEMBER 2, 2006

Figure 11: MCU I/O PORT – J1

J1

VX

VSS

PTE0/TXD1

PTE1/RXD1

PTG2

PTG3
PTD2/PID2/TPM1CH0
PTD3/PID3/TPM1CH1

PTE4/SCL/MOSI

PTE5/SDA/MISO

PTE3/SPSCK

PTE2/SS*

PTG4

PTG5

PTF3/TMP2CLK/SDA

PTF2/TPM1CLK/SCL
PTD4/PID4/TPM1CH2
PTD5/PID5/TPM1CH3
PTD6/PID6/TPM1CH4
PTD7/PID7/PTM1CH5

12
34
56
78

910
11 12
13 14
15 16
17 18
19 20
21 22
23 24
25 26
27 28
29 30
31 32
33 34
35 36
37 38
39 40

PTA7/PIA7/ADP7/IRQ
RESET*
BKGD/MS
PTF7
PTA0/PIA0/ADP0/MCLK
PTA1/PIA1/ADP1/ACMP1+
PTA2/PIA2/ADP2/ACMP1­PTA3/PIA3/ADP3/ACMP1O
PTA4/PIA4/ADP4
PTA5/PIA5/ADP5
PTA6/PIA6/ADP6
PTB0/PIB0/ADP8
PTE6/TXD2/TXCAN
PTE7/RXD2/RXCAN
PTB1/PIB1/ADP9
PTB2/PIB2/ADP10
PTD0/PID0/TPM2CH0
PTD1/PID1/TPM2CH1
PTC0/ADP16
PTC1/ADP17

Figure 12: MCU I/O PORT – J2

NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC

J2
41 42
43 44
45 46
47 48
49 50
51 52
53 54
55 56
57 58
59 60
61 62
63 64
65 66
67 68
69 70
71 72
73 74
75 76
77 78
79 80

PTF0/TXD2
PTF1/RXD2
PTB3/PIB3/ADP11
PTB4/PIB4/ADP12
PTB5/PIB5/ADP13
PTB6/PIB6/ADP14
PTB7//PIB7/ADP15
PTC2/ADP18
PTC3/ADP19
PTC4/ADP20
PTC5/ADP21
PTC6/ADP22
PTC7/ADP23
NC
NC
NC
NC
PTF4/ACMP2+
PTF5/ACMP2­PTF6/ACMP2O

16
