DTXP4175 USB NiMH Charger and DTXC2031 Battery Instructions
Before using your factory assembled RTR, review the entire instruction manual to become familiar with the vehicle.
This is a quick start guide for care and usage of the charger and battery that comes with the vehicle.
DTXP4175 - Duratrax Onyx USB Charger
NiMH 6C Mini Connector
DTXC2031 - Duratrax NiMH Onyx 7.2V
1300mAh Flat Mini Connector
CAUTION: The DTXP4175 charger is for use
with 6-Cell 7.2v NiMH batteries ONLY and
should not be used with any other batteries.
CAUTION: Never leave the battery unattended
while charging. Always disconnect the battery
and unplug the charger when finished charging.
CAUTION HOT!!!
NiMH batteries may become hot while charging.
Allow to cool before handling the battery.
When using the DTXP4175 charger, the DTCX2031 battery should fully charge in 2-3 hours.
1.
Remove the body clips and body.
Install the battery.
2.
• Remove the battery from the vehicle
before charging.
• Place the battery on a fire resistant surface.
• Avoid any contact with water or other fluids.
1. Connect USB connector to USB power on
PC or USB AC wall adapter.
2. Connect battery to mini connector.
3. Charger will automatically begin charge
process.
Red LED: Charging
Green LED: Finish Charging
3.
Turn on the transmitte
r.
Note:
Power to the vehicle is controlled by
connecting / disconnecting the battery.
4.
Connect the battery to the ESC.
5.
Install the body and body clips.
4
Top View Parts
Front Shock
Absorber
Steering Knuckle
Steering Rack
Front Control Arm
Front Bumper
C-Hub
Spur/Pinion
(Under Cover)
Motor 40T
Battery Tray
Driveshaft
Front Body Mount
Steering Servo
Receiver Box and
Electronic Speed
Control (ESC)
Rear Shock
Absorber
Rear Swing Arm
Rear Differential
Battery Door
5
Getting-Started Checllist
The following checklist is a guide for getting you vehicle running for the first time.
Read ‘Cautions’ in Manual. (Page 2)
Charge battery pack. (Page 4)
Familiarize yourself with vehicle and
its components.
Install 4X AA batteries into Transmitter.
(Page 7)
Before vehicle operation
check all nuts and screws on moving parts
are securely tightened.
Install battery pack in vehicle. (Page 4)
Turn on transmitter first,
then plug in battery
(power ESC) (Page 4)
Drive vehicle, challenge yourself and
have fun!
Check to make sure steering and throttle
operation work correctly. (Page 7)
Maintain vehicle. (Next Page)
6
Range check radio system. (Next Page)
Range-Checking Your Radio System
The radio system should be checked before operating the vehicle to ensure it’s operating properly and has adequate range.
1. Turn on the transmitter first and then the vehicle.
2. Have a friend hold the vehicle while keeping hands and loose clothing away from moving parts.
3. Walk away until you are at the farthest distance you plan to operate the vehicle.
4. Steer the vehicle back and forth and throttle both forward and reverse making sure there is no erratic behavior.
5. If any erratic behavior is exhibited do not operate the vehicle, call customer service for further assistance.
RANGE-CHECKING FOR DISTANCE
Maintaining Your Vehicle
Just like a full size car or truck your RC vehicle must undergo periodic maintenance in order to ensure peak running performance. Preventative
maintenance will also help avoid needless breakages which could result in costly repairs. Below are some suggestions to properly maintain
your vehicle.
REPLACE ANY NOTICEABLE
BENT OR BROKEN PARTS
CHECK FOR WEAR ON
THE BALL JOINTS IN THE
STEERING AND SUSPENSION
(REPLACE IF NECESSARY)
LINKS
INSPECT SHOCK
ABSORBERS FOR SMOOTH
DAMPENED OPERATION
CHECK FOR ANY LOOSE
CONNECTIONS OR FRAYED
WIRING
CHECK WHEEL NUTS MAKING
SURE THEY’RE SNUG
CHECK TIRES MAKING SURE
THE BEADS ARE STILL FIRMLY
BONDED TO THE ENTIRE
CIRCUMFERENCE OF THE RIM
CHECK DRIVELINE FOR
SMOOTH BIND-FREE
OPERATION
CHECK STEERING
OPERATION FOR ANY BINDS
KEEP CHASSIS FREE OF DIRT
CHECK FOR LOOSE SCREWS
ON CHASSIS ESPECIALLY
THE KNUCKLE, C-HUB AND
AXLE LOCKOUT SCREWS
7
OR DEBRIS
INSPECT THE SPUR AND
PINION GEARS FOR DAMAGE
REPLACE TRANSMITTER
AA’S IF THE GREEN LIGHT IS
BLINKING
Warranty Info
AXIAL LIMITED WARRANTY
Your Axial product is warranted to be free of defects in materials and workmanship when new in the factory sealed box. This warranty does not cover damages due to normal wear and tear,
users' failure to perform routine maintenance, error of assembly or installation, modications or addition of aftermarket parts or o pti on par ts. This warranty lasts as long as the origina l
purchaser owns the product and is not transferable (verified by dated itemized sales receipt accompanied with product). In the event of a defect under this warranty, Axial will, at
our discretion, repair or replace the product, provided our inspection indicates that an original defect exists. Axial provides a 10-day warranty from the date of purchase on electronics
(i.e. servo, esc, radio). Axial reserves the right to replace any product which is no longer available with a product of comparable value and function. If Axial determines the repair is not
covered under warranty guidelines, there could be a charge applied for the repair and return shipping charges. Note: Purchasing products from unauthorized distributors may void warranty
and prevent support and service.
INTERNATIONAL CUSTOMER WARRANTY
Please return product to the dealer where the purchase was made. If your Axial product purchase was made through an on-line retailer, any warranty issues must be taken care of by that
retailer. Axial assumes no responsibility for Axial products sold internationally by on-line retailers.
REPAIR
For warranty repair, please contact Axial Customer Service at (877) 64-AXIAL (877-642-9425).
HOURS AVAILABLE:
8:00 am - 5:00 pm Monday through Friday, Central Time.
8
10
11
12
13
14
15
16
AX31516
Yeti Jr.™ Steering Knuckle Set
x1
AX31508
Yeti Jr.™ Rear Cage Battery Tray
AX31515
Yeti Jr.™ Front Carrier Set
x1
x1
AX31512
Yeti Jr.™ Chassis Components
AX31514
Yeti Jr.™ Front Lower Control Arm Set
AX80029
Shock Cap Parts Tree
x4
x1
x1
AX31518
Yeti Jr.™ Rear Axle Link Set
x1
AX31506
Yeti Jr.™ Molded Chasis Tub
17
x1
AX80032
Shock Parts
x2
AX31520
Yeti Jr.™ Battery Door
x1
AX31511
Dogbone and Center Driveline Set
AX31519
Yeti Jr.™ Body Cage
x1
x1
AX31510
AR18 Axle Housing
AX31513
Spur Gear 48P 60T
x1
x1
AX31522
1.55 Method Beadlock Style Wheels
(Black)
AX31517
Yeti Jr.™ Front Shock Tower and Bumper Set
x1
x4
AX80030
61-90mm Shock Body Set
AX31509
Center Shaft Drive Cup
x1
x1
AX31509
Output Support Sleeve
AX31505
46-63mm Shock Body Set
x4
x1
AX31509
10T Spider Gear
AX31509
Dierential Outputs Set
x8
18
AX31009
Mini servo saver mold
AX31509
20T Di Output Short Side
x1
x1
x2
AX31507
Jr. Helmet Set (White)
AX31509
20T Di Output Long Side
x1
x2
AXA013
M2x6mm Cap Head
x2
AX31280
M2.6x6mm Hex Socket Button Head
x4
AXA0413
M2.6x8mm Hex Socket
Tapping Flat Head
x4
AXA1060
3mm Body clip (Black)
x4
AXA0023
M2.6x8mm Cap Head
AX31398
M2.6x12mm Cap Head
AX31399
M2.6x18mm Cap Head
AX31493
M2.6x25mm Cap Head
AX31489
M2.5x10mm Step Screw - Hex Socket
AX31490
M2.5x12mm Step Screw - Hex Socket
AX31499
Ball Stud 4mm
AX31542
M2x12mm Hex Socket Button Head
x8
x4
x3
x1
x10
x1
x2
x2
AXA0065
M2.6x10mm Hex Socket Button Head
AX31195
M2.6x12mm Hex Socket Button Head
AX31491
M2.6x18mm Hex Socket Button Head
AXA117
M3x15mm Hex Socket Button Head
AXA0422
M2.6x6mm Hex Socket
Tapping Button Head
AXA0423
M2.6x8mm Hex Socket
Tapping Button Head
AXA0425
M2.6x12mm Hex Socket
Tapping Button Head
x4
x6
x2
x8
x10
x10
x11
AXA0414
M2.6x10mm Hex Socket
Tapping Flat Head
AXA146
M3x12mm Hex Socket Flat Head
AXA147
M3x16mm Hex Socket Flat Head
AXA180
M3x3mm Set Screw
AXA1041
M2.5 Nylon Locking Hex Nut
AX31543
Washer 2x7x0.5mm
AX31289
M8x10x0.3mm Shim
x1
x1
x1
x1
x4
x2
x2
AXA1392
E2 e-clip
AXA1179
O-Ring 2.5x1.5mm
AXA1163
O-Ring 7x1mm
AXA1358
Shock Damper 3x7x8
AXA1218
Bearing 5x10x4mm
AX31495
8x12x3.5mm Bearing
x10
x4
x8
x2
x2
x14
AX30162
1.5x8mm pin
AX31488
Shock Shaft 3x35mm Polished
AX30146
Shock Shaft 3x50mm Polished
AX31009
Servo Saver Spring
AX31502
Axle
x2
x2
x1
AX30168
2x8mm pin
AX31502
Cross Pin
x2
x2
AX31501
Spring 12.5x35mm 1.79 lbs/in
x1
x2
x2
AX31497
2.0x20mm Pin
AX31502
Shaft 6x54mm
AX31496
Pinion Gear 48P 10T
(2.3mm Motor Shaft)
x2
19
x4
x1
AX31441
Spring 12.5x60mm 1.13 lbs/in - (White)
AX31494
15T Pinion Gear
AX31492
M2.6 Caphead - Hex Socket Screw Shaft 40mm
AX31504
2.5mm shaft
x2
x2
AX31494
35T Ring Gear
x2
x2
x2
AX31399
AX31520
AX31520
AX31195
AX31195
AX31195
AX31195
AX31195
AX31512
AX31491
AX31512
AXA0065
AXA180
AX31491
AX31512
AX31491
AX31496
AX31195
AX31520
AX31520
AXA0065
AX31195
AXA1218
AX31520
AX31512
AXA1218
AX31511
AX31195
AX31513
AX31491
AXA0065
AXA0414
AX31509
Chassis and Transmission
AX31508
AX31491
AXA0065
AX31506
AXA0413
AXA0413
AX31499
AX31009
AXA1041
AX31009
AX31543
AX31009
AX31542
AX31280
AX31009
AX31280
AX31518
AX31499
AX31489
20
AX31489
AX31499
AX31499
AX31512
AX30168
AX31512
AX31497
AX31497
AX31512
AX31518
AX31499
AX31518
AX31495
AX31499
AX31517
AXA1060
AXA0065
AXA117
AXA0065
AX31517
AX31491
AXA117
AX31491
AX31499
AX31499
AX31495
AX31509
AX31495
AX31494
AX31512
AX31289
AX31509
AX31494
AX31509
AX31495
AXA0023
AX30162
AX31502
AX31515
AX31502
AX31516
AX31495
AXA0023
AXA1392
AX31502
AX31514
AX31504
AX31518
AX31499
AXA0023
AXA117
AX31518
AX31499
AX31516
AXA117
AX30162
AX31495
AX31502
AX31515
AX31502
AX31504
AX31502
AX31509
AX31514
AXA0023
AXA1392
AX31289
AX31495
AX31497
AX31509
AX31509
AX31491
AX31491
AX31517
AX31517
AXA0065
AXA0065
AX31492
AXA0413
AX31492
Front Axle
AX31495
21
AX31495
AX31511
AXA117
AX31490
AX31491
AXA117
AXA0023
AX31399
AXA0023
AX31509
AX31518
AX31289
AX31495
AX31494
AX31509
AX31495
AX31497
AX31509
AX31494
AX31289
Rear Axle
AX31510
AX31509
AX31509
AX31495
AX31518
AX31490
AX31495
AX31280
AX31493
AX31511
AX31398
AXA117
AX31398
AXA0023
AXA0023
AX31510
AX31509
AX31518
AX31491
AX31511
AX31495
AX31399
AXA117
22
AX31518
AXA1163
AXA1392
AX80032
AXA1392
AXA1179
AXA1179
AX80029
AX31518
AXA1358
AX31518
AX80029
AX80029
AX80029
AXA1163
AXA1392
AXA013
AXA1392
AX80032
AX30146
AX31488
AX31519
AX31505
AX80030
AXA1179
AX80032
AXA1179
AX80029
AX80032
AX80029
AX80029
AX31501
AX31441
AX80032
AX31518
AX31520
AX80032
AXA0425
AX80032
AXA0423
AX80032
Body & Shock Assembly
AXA0425
AXA0422
AXA0422
AXA0422
AXA0422
AX31523
AX31507
AX31507
AX31523
AXA0423
AXA0423
AXA0423
AXA0423
AXA0423
23
AXA147
Body & Wheel Assembly
AX31195
AX31516
AX31521
AX31521
AXA146
AX31522
AX31521
AX31521
AX31195
AXA1060
AXA1060
24
AX31516
AX31522
AX30146 Shock Shaft 3x50 (2pcs)
AX30162 Pin 1.5x8mm (6pcs.)
AX30168 Pin 2x8mm (6pcs.)
AX31009 2-Speed Hi/Lo Servo Saver Set
AX31195 M2.6x12mm Hex Socket Button Head (Black) (10pcs)
AX31280 M2.6x6mm Hex Socket Button Head (Black) (10pcs)
AX31289 Shim 10x8x0.3mm (6pcs)
AX31374 3mm Body Clip (Black) (10pcs)
AX31398 M2.6x12mm Cap Head (Black) (10pcs)
AX31399 M2.6x18mm Cap Head (Black) (10pcs)
AX31441 Spring 12.5x60mm 1.13 lbs/in - (White) (2pcs)
AX31488 Shock Shaft 3x35mm (2pcs)
AX31 489 M2.5x6x10mm Hex Socket Button Head Shoulder Screw (Black) (6pcs)
AX31 490 M2.5x6x12mm Hex Socket Button Head Shoulder Screw (Black) (6pcs)
AX31491 M2.6x18mm Hex Socket Button Head (Black) (10pcs)
AX31492 M2.6x40mm Cap Head (Black) (6pcs)
AX31493 M2.6x25mm Cap Head (Black) (6pcs)
AX31494 Bevel Gear Set - 35/15T
AX31495 Bearing 8x12x3.5mm (2pcs)
AX31496 Pinion Gear 48P 10T (2.3mm Motor Shaft)
AX31497 Pin 2x20mm (6pcs)
AX31499 Ball Stud 4mm M2.6x5mm (4pcs)
AX31501 Spring 12.5x35mm 1.79 lbs/in - (2pcs)
AX31502 Universal Joint Axle Set 48mm (2pcs)
AX31504 Hinge Pin 2.5x19mm (2pcs)
AX31505 46-63mm Shock Body Set
AX31506 Yeti Jr.™ Molded Chasis Tub
AX31507 Jr. Helmet Set (White)
AX31508 Yeti Jr.™ Rear Cage Battery Tray
AX31509 Dierential Outputs Set
AX31510 AR18 Axle Housing
AX31511 Dogbone and Center Driveline Set
AX31512 Yeti Jr.™ Chassis Components
AX31513 Spur Gear 48P 60T
AX31514 Yeti Jr.™ Front Lower Control Arm Set
AX31515 Yeti Jr.™ Front Carrier Set
AX31516 Yeti Jr.™ Steering Knuckle Set
AX31517 Yeti Jr.™ Front Shock Tower and Bumper Set
AX31518 Yeti Jr.™ Rear Axle Link Set
AX31519 Yeti Jr.™ Body Cage
AX31520 Yeti Jr.™ Battery Door
AX31521 1.55 BFGoodrich Krawler T/A Tires 3.2" - R35 Compound (2pcs)
AX31522 1.55 Method Beadlock Style Wheels (Black) (2pcs)
AX31523 Yeti Jr.™ Body - .040" (Clear)
AX31538 M2.6x10mm Hex Socket Button Head (Black) (10pcs)
AX31542 M2x12mm Hex Socket Button Head (Black) (10pcs)
AX31543 Washer 2x7x.05mm (10pcs)
AX80029 Shock Cap Parts Tree
AX80030 61-90 Schock Body Set
AX80032 Shock Parts
AXA0023 M2.6x8mm Cap Head (Black) (10pcs)
AXA013 M2x6 mm Cap Head (Black) (10pcs)
AXA0147 M3x16mm Hex Socket Flat Head (Black) (10pcs)
AXA0413 M2.6x8mm Hex Socket Tapping Flat Head (Black) (10pcs)
AXA0414 M2.6x10mm Hex Socket Tapping Flat Head (Black) (10pcs)
AXA0422 M2.6x6mm Hex Socket Tapping Button Head (Black) (10pcs)
AXA0423 M2.6x8mm Hex Socket Tapping Button Head (Black) (10pcs)
AXA0425 M2.6x12mm Hex Socket Tapping Button Head (Black) (10pcs)
AXA1041 M2.5 Nylon Locking Hex Nut - Silver (10pcs)
AXA1163 O-Ring 7x1mm (10pcs)
AXA117 M3x15mm Hex Socket Button Head (Black) (10pcs)
AXA1179 O-Ring 2.5x1.5mm (10pcs)
AXA1218 Bearing 5x10x4mm (2pcs)
AXA1358 Shock Damper 3x7x8 (10pcs)
AXA1392 E2 e-clip (10pcs)
AXA146 M3x12mm Hex Socket Flat Head - Black (10pcs)
AXA180 M3x3mm Set Screw (Black) (10pcs)
25
NOTES
26
NOTES
27
2803877
Loading...
