Put the battery in the car.
1
Make sure charger is correct for battery type selected for use.
Examples: Do NOT charge Lipo batteries with Nickel Metal Hydride
charger. Do NOT charge Nickel Cadmium batteries Lipo charger.
Stellen Sie sicher, Ladegerät ist korrekt für Batterietyp zur Verwendung ausgewählt.
Beispiele: Laden Sie keine Lipo-Akkus mit Nickel-Metall-Hydrid-Ladegerät. Laden Sie
keine Nickel-Cadmium-Akkus Lipo Ladegerät.
Assurez-vous que le chargeur est correcte pour le type de batterie sélectionné
à l'emploi. Exemples: Ne pas charger les batteries Lipo avec chargeur hydrure
métallique de nickel. Ne chargez pas les batteries au nickel-cadmium Lipo chargeur.
Install the battery.
2
Turn on the transmitter.
3
Turn on the electronic speed controller.
4
4
Top View Parts
Steering
Steering Servo
Steering Knuckle
Receiver Box
Spur/Pinion/Slipper
(Under Cover)
Driveshaft
C-Hub
Lower 4-link Bar
Transmission
Motor 35T
Upper 4-link Bar
Differential
(inside axle housing)
Battery Tray
Shock Absorber
5
Getting-Started Checklist
The following checklist is a guide for getting you vehicle running for the first time.
Read ‘Cautions’ in Manual. (Page 2)
Charge battery pack. (Page 4)
Familiarize yourself with vehicle and
its components.
Install 4X AA batteries into Transmitter.
(Page 7)
Even though the vehicle is new check
driveshaft setscrews and other screws to
make sure they are tight from the factory.
Install battery pack in vehicle. (Page 4)
Turn on transmitter first,
then plug in battery
(power ESC) (Page 4)
Drive vehicle, challenge yourself and
have fun!
Check to make sure steering and throttle
operation work correctly. (Page 7)
Maintain vehicle. (Next Page)
6
Range check radio system. (Next Page)
Range-Checking Your Radio System
The radio system should be checked before operating the vehicle to ensure it’s operating properly and has adequate range.
1. Turn on the transmitter first and then the vehicle.
2. Have a friend hold the vehicle while keeping hands and loose clothing away from moving parts.
3. Walk away until you are at the farthest distance you plan to operate the vehicle.
4. Steer the vehicle back and forth and throttle both forward and reverse making sure there is no erratic behavior.
5. If any erratic behavior is exhibited do not operate the vehicle, call customer service for further assistance.
RANGE-CHECKING FOR DISTANCE
Maintaining Your Vehicle
Just like a full size car or truck your RC vehicle must undergo periodic maintenance in order to ensure peak running performance. Preventative
maintenance will also help avoid needless breakages which could result in costly repairs. Below are some suggestions to properly maintain
your vehicle.
REPLACE ANY NOTICEABLE
BENT OR BROKEN PARTS
CHECK FOR WEAR ON
THE BALL JOINTS IN THE
STEERING AND SUSPENSION
(REPLACE IF NECESSARY)
LINKS
CHECK DRIVESHAFT SET
SCREWS AND RE-THREAD
LOCK IF NECESSARY
INSPECT SHOCK
ABSORBERS FOR SMOOTH
DAMPENED OPERATION
CHECK FOR ANY LOOSE
CONNECTIONS OR FRAYED
WIRING
CHECK TIRES MAKING SURE
CHECK WHEEL NUTS MAKING
SURE THEY’RE SNUG
CHECK SLIPPER CLUTCH IF
APPLICABLE, FOR PROPER
OPERATION
(SEE PAGE 25 STEP
23 FOR SETUP INSTRUCTIONS)
THE BEADS ARE STILL FIRMLY
BONDED TO THE ENTIRE
CIRCUMFERENCE OF THE RIM
CHECK RECEIVER ANTENNA
TO CONFIRM IT’S NOT
DAMAGED
KEEP CHASSIS FREE OF DIRT
OR DEBRIS
CHECK STEERING
OPERATION FOR ANY BINDS
7
6
CHECK FOR LOOSE SCREWS
ON CHASSIS ESPECIALLY
THE KNUCKLE, C-HUB AND
AXLE LOCKOUT SCREWS
INSPECT THE SPUR AND
PINION GEARS FOR DAMAGE
CHECK DRIVELINE FOR
SMOOTH BIND-FREE
OPERATION
REPLACE TRANSMITTER
AA’S IF THE GREEN LIGHT IS
BLINKING
AE-5 Forward/Reverse ESC w/ Drag Brake
Mount the ESC in an area that is well ventilated and isolated from vibration and shock.
Connect the ESC motor wires to the motor red-red & black-black.
Plug the receiver with into the throttle channel on the receiver. The black negative wire should be
towards the outside of the receiver.
Before plugging the battery into the ESC, make sure your transmitter is on and the throttle trim is set at
zero.
Connect the battery to the ESC, this will turn on the ESC.
Test forward and reverse control using the transmitter.
To calibrate the ESC, make sure the transmitter is on and the throttle control is at neutral.
Connect the battery to the ESC and wait 3 seconds to let the ESC initiate a self-test and automatic
throttle calibration.
When the ESC is ready to run a long beep sound will be emitted from the motor.
Always disconnect the battery when the vehicle is not in use.
Roll Cage Removal
8
Spur Gear
Spur Gear
Spur Gear
Final Drive Gear Ratio = (Spur/Pinion)x5.67
39.64:1
16.42:1
Gesamtubersetzung = (Spur/Pinion)x5.67
32 Pitch 38T/13T (Stock Gearing AX30392 or HD AX30395)
Pinion 56 60 64 68
11
12
13
14
15
16
17
28.85 30.91 32.97 35.03
26.44 28.33 30.22 32.11
24.41 26.15 27.90 29.64
22.67 24.88 25.90 27.52
21.15 22.67 24.18 25.69
19.83 21.25 22.67 24.08
18.67 20.00 21.33 22.67
NOTES
32 Pitch 36T/14T (Overdrive HD Gearing AX30401)
Pinion 56 60 64 68
11
12
13
14
15
16
17
25.38 27.19 29.00 30.81
23.26 24.92 26.58 28.25
21.47 23.01 24.54 26.07
19.94 21.36 21.94 22.60
19.61 19.94 21.27 22.60
17.45 18.69 19.94 21.18
16.42 17.59 18.77 19.94
32 Pitch 43T/13T (Underdrive HD Gearing AX30402)
Pinion 56 60 64 68
11
12
13
14
15
16
17
32.64 34.97 37.31 39.64
29.92 32.06 34.20 36.33
27.62 29.59 31.57 33.54
25.65 27.48 29.31 31.14
23.94 25.65 27.36 29.07
22.44 24.04 25.65 27.25
21.12 22.63 24.14 25.65
9
NOTES
10
Warranty Info
AXIAL LIMITED WARRANTY
Your Axial product is warranted to be free of defects in materials and workmanship when new in the factory sealed box. This warranty does not cover damages due to normal wear and tear,
users' failure to perform routine maintenance, error of assembly or installation, modications or addition of aftermarket parts or o pti on par ts. This wa rra nty lasts as long as the original
purchaser owns the product and is not transferable (verified by dated itemized sales receipt accompanied with product). In the event of a defect under this warranty, Axial will, at
our discretion, repair or replace the product, provided our inspection indicates that an original defect exists. Axial provides a 10-day warranty from the date of purchase on electronics
(i.e. servo, esc, radio). Axial reserves the right to replace any product which is no longer available with a product of comparable value and function. If Axial determines the repair is not
covered under warranty guidelines, there could be a charge applied for the repair and return shipping charges. Note: Purchasing products from unauthorized distributors may void warranty
and prevent support and service.
INTERNATIONAL CUSTOMER WARRANTY
Please return product to the dealer where the purchase was made. If your Axial product purchase was made through an on-line retailer, any warranty issues must be taken care of by that
retailer. Axial assumes no responsibility for Axial products sold internationally by on-line retailers.
REPAIR
For warranty repair, please contact Axial Customer Service at (877) 64-AXIAL (877-642-9425).
HOURS AVAILABLE:
8:00 am - 5:00 pm Monday through Friday, Central Time.
11
AX31301
10mm Shock Caps Set
x2
AX31300
10mm Shock Parts Tree 2 (Blue)
x2
AX80006
Servo Set
x1
AX80018
Hardware Parts Tree
AX80070
Axial Di Cover
x1
AX31266
12mm Hex Hub Adapter Narrow
AX80033
10mm Shock Set 1
x3
AX80069
x2
AX80062
XR10 C Hub Carrier Set
AX80078
Transmission Gear Cover
x2
x1
AX31065
Spur Gear 32P 64T
x1
x1
x4
AX80072
AX80079
Rock Buggy Skid Plate/Battery Tray
AX80061
Steering Knuckles Plastic Set
x1
x1
x1
AX80071
Straight Axle Adapter Rear
AX80083
Rock Buggy Links Set
x1
AX80090
Corbeau LG1 Seat(Black)
x1
x1
AX80081
Radio Case
AX80036
72-103mm Shock Body
x1
12
x1
AX80037
Interior Details Parts Tree-Black
AX80051
Dig Transmission Case
x1
x1
AX80074-001
Rcok Buggy Main Frame
x1
AX80074-002
Rcok Buggy Main Frame
x1
AX80074
Rock Buggy Main Frame
x1
AX80089
Rock Buggy Front End 2
AX80075
Wraith Tube Frame TOP
x1
x1
AX80076
Rock Buggy Rear Brace Set
x1
AX80077-001
Rcok Buggy Front end 1
13
x1
AX80073
AX80076
Rock Buggy Battery Brace
x1
x1
AX30162
Pin 1.5x8mm
AX30163
Pin 2x10mm
x2
x6
AXA1393
E2.5 e-clip
x1
AX30368
Axle 6x39mm
x2
AX30166
Pin 1.5x11mm
AX0175
Screw Shaft M3x20mm
AXA0286
M4x12mm
AX30113
Rubber Bump Stop 3.6x7x4
AX30450
Flange Pipe 3x4.5x5.5
AX30463
4.5x6.5mm Join Pin
AX30190
Shaft 5x18
AX30408
Input Shaft 5x29mm
x4
x4
x1
x4
x4
x1
x2
AX30413
Slipper spring
AX30112
Shock Diaphragm 13x4.5mm
AX31148
WB8-HD Joint Male Universal
x4
AX31148
WB8-HD Joint 10X15mm
AX30500
Heavy Duty Locker
x1
x2
x4
x4
AX30435
x4
Steel Outdrive Shaft
AX30437
Dig Lockout Shaft
AX30392
13T Bevel Gear
AX30724
13T 32P Pinion 3mm Motor Shaft
AX30392
38T Bevel Gear
x1
x1
AX31059
Slipper Plate
x2
AX30429
12mm Aluminum Hub
x4
x2
AX30411
Outer Slipper Plate
x1
x2
AX30385
x1
x2
AX30410
Lnner Slipper Plate
x1
AX30198
Slipper Drive gear Shaft 5x53.5
AX30155
Shock Shaft 3x59.5
AX30419
Solid Axle Dogbone 7x69mm
AX30419
Solid Axle Dogbone 7x125mm
AX30776
Straight Axle Shaft 6x104.2mm
AX30776
Straight Axle Shaft 6x160.2mm
x1
x4
x1
x1
x1
x1
AX30394
20T Drive Gear
x1
X31068
A
Slipper
Pad
x2
AX30224
Spring 14x70mm 1.43 lbs/in - Purple (2pcs)
AX30190
56x17mm Servo Plate
AX30491
AX10 Scorpion Motor Plate
x1
x2
x1
14
AXA1040
M3 Thin Hex Nut
x2
AXA180
M3x3mm
x12
AXA0422
M2.6x6mm
x16
AXA1041
M2.5 Nylon Lock Nut
AXA1052
M3 Thin Nylon Locking Hex Nut
AXA1053
M3 Nylon Locking Hex Nut
AXA1046
M4 Serrated Nylon Locking Nut (Blue)
AXA1070
Washer 3x6x0.5 mm
AXA1069
Washer 2.7x6.7x0.5 mm
AXA1071
Washer 4x8x0.5mm
AXA1091
Washer 5x10x0.5 mm
AXA1202
O-Ring 3.5x2mm
AXA1184
O-Ring 7.5x1.5mm
AXA1218
Bearing 5x10x4mm
AXA1221
Bearing 5x11x4mm
x4
x1
x8
x2
x8
x4
x1
AXA291
M4x4mm
x13
x4
x4
x1
AXA0187
Set Screw M3x20mm
AXA013
M2x6mm
AXA0113
M3x6mm
x4
AXA015
M2x10mm
AXA0023
M2.6X8mm
AXA083
M3x6mm
x16
x4
x5
AXA087
M3x16mm
AXA089
M3x25mm
x9
AXA115
M3x10mm
x14
x4
x8
x3
AXA091
M3x30mm
x2
AXA433
M3x6mm
x8
AXA434
M3x8mm
x2
AXA435
M3x10mm
x36
AXA436
M3x12mm
x1
AXA0437
M3x15mm
AXA0438
M3x18mm
AXA0439
M3x20mm
AXA440
M3x25mm
x9
AXA441
x46
x4
x2
x4
x4
AXA117
M3x15mm
x21
x19
AXA118
M3x18mm
x46
AXA1230
Bearing 10x15x4mm
AXA1225
Bearing 8x16x5mm
AXA1243
Bearing 15x21x4mm
AXA1356
Silicone Shock Bushing 7.5x8mm
AXA1280
M3x10mm Servo Flange Screw
x4
AXA144
x6
x1
M3x8mm
AXA412
M2.6x6mm
AXA413
M2.6x8mm
x10
x3
x2
AXA412
M2.6x10mm
x6
AXA416
M2.6x18mm
x2
x1
AXA463
x2
M3x6mm
AXA464
x4
M3x8mm
AXA465
M3x10mm
x1
x6
AXA466
M3x12mm
x6
15
AX80078
AX30491
AXA436
AXA089
AX80051
AXA1070
AXA083
AX24003
AXA291
AX30499
AXA1070
AX30724
AX31068
AXA083
AX31026
AX80090
AXA0113
AX30127
AX80051
AX31027
AX30413
AX31068
AXA466
AXA1218
AX80010
AX31026
AXA1045
AX80090
AXA1218
AXA0414
AX30190
AX30162
AXA0414
AX80051
AXA1221
AXA1218
AX80078
AXA1243
AXA013
AX31149
AX80078
AX30394
AXA1218
AXA0414
AXA0422
AX80079
AX30437
AX80010
AX30435
AXA1225
AXA0437
AX80090
AXA466
AXA465
AX80051
AXA463
AX80090
AXA466
AX80090
AXA0113
AX80037
AXA466
AXA0113
AXA013
AXA013
AXA466
AX80037
AX80037
AX80037
AX80037
AX4028
AX80037
16
AXA0422
AX80037
AXA0422
AXA013
AX4028
AXA013
AXA1040
AXA0422
AXA1040
AX80090
AXA465
AX80037
AX80090
AX80090
AX80037
AXA013
AXA013
AXA463
AXA465
AXA438
AXA0422
AXA0422
AXA0422
AX80075
AXA0422
AXA0422
AX4038
AXA0422
AXA0422
AX80076
AXA0422
AXA0422
AX4038
AXA0422
AXA0413
AXA0422
AXA0413
AXA438
AXA0413
AXA441
AXA0413
AXA441
AXA438
AX80077
AX80079
AXA438
AXA438
AX80082
AXA438
AXA438
AXA438
AXA436
AX80088
AX80074
AXA0437
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AXA0437
AXA438
AXA438
AXA438
AXA436
AXA438
AXA438
AX80088
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AXA438
AX80074
AXA438
AXA0416
AXA0416
AXA438
AX80081
AX80077
AXA0437
AXA0414
AX80089
AXA438
AX30566
AXA0414
AXA0437
AX80081
AX80076
AX80082
AX30566
AX80077
AXA436
AX24259
AX80075
AX24257
AX80081
AX80082
AX80077
AXA436
AXA438
AX24206
AX80077
AXA438
AXA438
AXA438
AX80081
AX80081
AXA0414
AXA0412
AXA0412
AXA0412
17
AX80018
AXA437
AXA0439
AX80034
AXA0286
AX80083
AX31148
AX31148
AX80018
AXA464
AXA433
AX31148
AX80083
AX80018
AX30450
AX31114
AXA437
AXA465
AXA091
AX31028
AXA187
AXA1052
AX80018
AXA118
AX31114
AX80018
AX80018
AXA144
AXA1053
AXA1052
AX80072
AXA0439
AX30450
AX80034
AX31114
AX80083
AX30419
AXA433
AX80018
AXA118
AX80072
AXA144
AX31114
AX31148
AX80018
AXA464
AXA0439
AXA187
AXA1052
AXA1221
AX31148
AX31148
AXA1052
AX80083
AXA0286
AX30777
AX31028
AX31114
AXA1221
AX80070
AX80069
AXA434
AXA1052
AXA1052
AXA180
AXA1052
AX80018
AXA087
AX80018
AX80070
AXA180
AXA1221
AXA118
AX30163
AXA118
AXA1221
AXA1393
AXA433
AXA180
AX30408
AX30392
AXA435
AXA087
AX30450
AX30419
AX30392
AX30778
AX30500
AXA1221
AX80061
AXA115
AXA115
AXA1230
AX30368
AXA433
AX30450
AX80062
AXA1230
AX80002
AX30385
AX80070
AX30368
AXA1230
AXA115
AXA435
AXA115
AX30778
AX80061
AXA1221
AX80062
AX80072
AXA464
AXA117
AXA436
18
AXA1280
AXA434
AX80006
AXA1070
AX80073
AX80018
AXA1280
AXA0113
AXA1053
AX80018
AX80018
AXA117
AXA1052
AXA1230
AXA117
AXA015
AX80018
AX80073
AX80070
AXA1052
AXA435
AX80070
AXA015
AXA015
AXA015
AXA464
AXA465
AX80072
AXA0439
AXA1053
AX80018
AXA015
AX80083
AXA435
AXA1230
AX80070
AXA435
AX80070
AX30385
AX30500
AXA0437
AXA435
AXA435
AX80002
AXA087
AX80070
AX30392
AX30163
AX30392
AX30408
AXA180
AXA1230
AXA015
AXA1393
AXA087
AXA1221
AX80069
AXA180
AX30776
AXA433
AXA1053
AX80083
AX80071
AXA433
AXA1221
AXA118
AX80018
AXA187
AXA091
AXA433
AX80018
AXA1221
AX80071
AXA0437
AX80083
AX80018
AXA433
AX30776
AXA440
AX80034
AX80018
AXA118
AXA118
AX80018
AXA1052
AX80018
AX80070
AXA1053
AXA180
AXA187
AXA0286
AXA1052
AX80083
AX80018
AXA1221
AX31028
AX31148
AX31148
AX31148
AX31028
AX31114
AXA144
AX31114
AXA144
AX31148
AX80070
AX31148
AX31114
AXA1052
AX80034
AX31114
AX31148
AX80018
AXA118
AXA440
AX80018
AXA1052
AXA0286
AX31114
19
AX30112
AXA1069
AXA1069
AX30155
AXA1202
AXA1202
AX80035
AX30224
AX30113
AX80034
AXA1356
AX80035
AXA1041
AX80033
AX80036
AXA435
AX08141
AX80035
AX08141
AX80035
AXA1184
AX80035
AX12021
AXA0023
AX31250
AX08141
AX12021
AX80034
AXA0023
AX31250
AX08141
AX12021
AXA180
AX30429
AX31028
AX31266
AXA180
AX30429
AX12021
AX08141
AX08141
AXA435
AX31266
AX31028
20
AX04028 Wraith Interior Set - .040" (Clear)
AX04038 Jeep® Wrangler Rock Racer Body - .040” (Clear) - Body Only
AX 0814 1 2.2 Trail Ready HD Series Beadlock w/Slim Ring - IFD™ Wheels -Black(2pcs)
AX12021 2.2 BFGoodrich Krawler T/A – R35 Compound (2pcs)
AX24003 20T Electric Motor
AX24206 2.4GHz Radio System (2 Channel) (AX-3, AR-3)
AX24259 Axial AE-2 Forward/Reverse ESC w/Drag Brake
AX30031 Antenna
AX30041 Velcro Strap 15x160mm
AX30112 Shock Diaphragm 13x4.5mm (6pcs)
AX30113 Rubber Bump Stop 3.6x7x4 (6pcs)
AX30155 Shock Shaft 3x59.5 (2pcs)
AX30163 Pin 2.0x10mm (6pcs.)
AX30190 Shaft 5x18 (2pcs.)
AX30224 Spring 14x70mm 1.43 lbs/in - Purple (2pcs)
AX30368 Axle 6x39mm (2pcs)
AX30385 Di Gasket 16x25x0.5mm (2pcs)
AX30392 Bevel Gear Set (38/13)
AX30394 20T Drive Gear
AX30408 Input Shaft 5x29mm (2pcs)
AX30413 Slipper spring 8.5x12 165 lbs/in - Black (2pcs)
AX30419 AR60 OCP Front Dogbone Set (2pcs)
AX30429 12mm Aluminum Hub (Black) (4pcs)
AX30435 Steel Outdrive Shaft Set (2pcs)
AX30437 Dig Lockout Shaft
AX30450 Flange Pipe 3x4.5x5.5 (4pcs)
AX30491 AX10 RTR Motor Plate
AX30499 Transmission Spacer 5x6.9x4.8mm - Grey (2pcs)
AX30500 Heavy Duty Locker (2pcs)
AX30724 Pinion Gear 32P 13T (3mm shaft)
AX30776 AR60 OCP Rear Axle Set (2pcs)
AX30777 56x17mm Servo Plate
AX30778 Zero Ackerman Steering Plate (2pcs)
AX31026 Slipper Plate Washer 33x5x1.5mm (2pcs)
AX31027 Spur Gear 32P 56T
AX31028 Pin 2.0x11mm (6pcs)
AX31068 Slipper Pad 32.8x15.2x1mm (2pcs)
AX31114 WB8-HD Driveshaft
AX31148 WB8-HD Driveshaft Coupler Set
AX31149 Slipper Drive Gear Shaft 5x54.50mm
AX31266 IFD™ Hex Hub Adapter (2pcs Narrow, 2pcs Wide)
AX80002 Di Case -Small
AX80006 Servo Set
AX80010 Gear Set
AX80018 Hardware Parts Tree
AX80033 10mm Shock Parts Tree 1
AX80034 10mm Shock Parts Tree 2
AX80035 10mm Shock Caps Parts Tree
AX80036 72-103mm Shock Body
AX80037 Interior Details Parts Tree - Black
AX80051 Dig Transmission Case
AX80061 XR10 Steering Knuckles Set
AX80062 XR10 C Hub Carrier Set
AX80069 AR60 OCP Axle Housing
AX80070 AR60 OCP Dierential Cover
AX80071 AR60 OCP Straight Axle Adapter
AX80072 AR60 OCP 4-Link Mount
AX80073 AR60 OCP Steering Link
AX80074 Wraith Tube Frame Rails
AX80075 Wraith Tube Frame Top
AX80076 Wraith Tube Frame Shock Mount (Rear)
AX80077 Wraith Tube Frame Bumper
AX80078 Transmission Spur Gear Cover
AX80079 Wraith Tube Frame Skid Plate/Battery Tray
AX80081 Wraith Tube Frame Electronics Box
AX80082 Wraith Tube Frame Brace Set
AX80083 Wraith Links Set
AX80087 Wraith Tube Frame Side (Left)
AX80088 Wraith Tube Frame Side (Right)
AX80089 Wraith Tube Frame Shock Mount (Front)
AX80090 Corbeau LG1 Seat (Black) (2pcs)
AXA0023 M2.6x8mm Cap Head (Black) (10pcs)
AXA0109 M3x10mm Oversized Flat Hex Socket (Black) (10pcs)
AXA0113 M3x6mm Hex Socket Button Head (Black) (10pcs)
AXA013 M2x6 mm Cap Head (Black) (10pcs)
AXA015 M2x10mm Cap Head (Black) (10pcs)
AXA0187 M3x20mm Set Screw (Black) (10pcs)
AXA0286 Screw Shaft M4x2.5x12mm (6pcs)
AXA0412 M2.6x6mm Hex Socket Tapping Flat Head (Black) (10pcs)
AXA0413 M2.6x8mm Hex Socket Tapping Flat Head (Black) (10pcs)
AXA0414 M2.6x10mm Hex Socket Tapping Flat Head (Black) (10pcs)
AXA0416 M2.6x18mm Hex Socket Tapping Flat Head (Black) (10pcs)
AXA0422 M2.6x6mm Hex Socket Tapping Button Head (Black) (10pcs)
AXA0437 M3x15mm Hex Socket Tapping Button Head (Black) (10pcs)
AXA0439 M3x20mm Hex Socket Tapping Button Head (Black) (10pcs)
AXA083 M3x6mm Cap Head (Black) (10pcs)
AXA087 M3x16mm Cap Head (Black) (10pcs)
AXA089 M3x25mm Cap Head (Black) (10pcs)
AXA091 M3x30mm Cap Head - Black (10pcs)
AXA1040 M3 Thin Hex Nut (Black) (10pcs)
AXA1041 M2.5 Nylon Locking Hex Nut - Silver (10pcs)
AXA1045 M4 Nylon Lock Nut (Black) (10pcs)
AXA1046 M4 Serrated Nylon Lock Nut (Blue) (4pcs)
AXA1052 M3 Thin Nylon Locking Hex Nut (Black)
AXA1053 M3 Nylon Locking Hex Nut (Black) (10pcs)
AXA1069 Washer 2.7x6.7x0.5 (10pcs)
AXA1070 Washer 3x6x0.5 (10pcs)
AXA115 M3x10mm Hex Socket Button Head (Black) (10pcs)
AXA116 M3x12mm Hex Socket Button Head - Black (10pcs)
AXA117 M3x15mm Hex Socket Button Head (Black) (10pcs)
AXA1184 O-Ring 7.5x1.5mm (S8) - (10pcs)
AXA1202 O-Ring 3.5x2mm (10pcs)
AXA1218 Bearing 5x10x4mm (2pcs)
AXA1221 Bearing 5x11x4mm (2pcs)
AXA1225 Bearing 8x16x5mm (2pcs)
AXA1230 Bearing 10x15x4mm
AXA1243 Bearing 15x21x4mm (2pcs)
AXA1356 Silicone Shock Bushing 7.5x8mm (6pcs)
AXA1393 E2.5 e-clip (10pcs)
AXA144 M3x8mm Hex Socket Flat Head (Black) (10pcs)
AXA180 M3x3mm Set Screw (Black) (10pcs)
AXA291 M4x4mm Set Screw (Black) (6pcs.)
AXA433 M3x6mm Hex Socket Tapping Button Head - Black (10pcs)
AXA434 M3x8mm Hex Socket Tapping Button Head (Black) (10pcs)
AXA435 M3x10mm Hex Socket Tapping Button Head (Black) (10pcs)
AXA436 M3x12mm Hex Socket Tapping Button Head (Black) (10pcs)
AXA438 M3x18mm Hex Socket Tapping Button Head (Black) (10pcs)
AXA440 M3x25mm Hex Socket Tapping Button Head (Black) (10pcs)
AXA441 M3x30mm Hex Socket Tapping Button Head (Black) (10pcs)
AXA463 M3x6mm Hex Socket Tapping Flat Head (Black) (10pcs)
AXA464 M3x8mm Hex Socket Tapping Flat Head (Black) (10pcs)
AXA465 M3x10mm Hex Socket Tapping Flat Head (Black) (10pcs)
AXA466 M3x12mm Hex Socket Tapping Flat Head (Black) (10pcs)
Electronics
AX24003 Axial 20T Electric Motor
AX24206 2.4GHz Radio System (2 Channel) (AX-3, AR-3)
AX24259 Axial AE-2 Forward/Reverse ESC w/Drag Brake
AX04027 Wraith Body - .040" (Clear)
AX08061 2.2 VWS Beadlock Wheels (Black) (2pcs) (Fits XR10)
AX08069 2.2 VWS Beadlock Rings (Black) (2pcs)
AX08132 2.2 VWS Machined Beadlock Rings (Orange) (2pcs)
AX08133 2.2 VWS Machined Beadlock Ring (Grey) (2pcs)
AX08135 2.2 Raceline Renegade Wheels - 41mm Wide (Black) (2pcs)
AX08137 2.2 Raceline Renegade Wheels - 41mm Wide (Chrome) (2pcs)
AX08142
AX12015 2.2 Ripsaw Tires - R35 Compound (2pcs)
AX24004 Axial 27T Electric Motor
AX24007 Axial 55T Electric Motor
2.2 Trail Ready HD Series Beadlock w/Slim Ring - IFD™ Wheels –Chrome/Black(2pcs)
21
AX24251 Axial NVS - Night Visions System
AX24252 Axial Double LED Light String (White LED)
AX24253 Axial Double LED Light String (Red LED)
AX24254 Axial Double LED Light String (Orange LED)
AX24255 Axial Single LED Light String (White LED)
AX24256 Axial 5 LED Light String (White LED)
AX24257 Simple LED Controler w/LED lights (4 white and 2 red)
AX30031 Antenna
AX30092 Axial 72-103mm Shock Set - 10mm Piston (2pcs)
AX30218 Spring 14x70mm 2.07 lbs/in - Super Soft (Red) (2pcs)
AX30219 Spring 14x70mm 2.47 lbs/in - Soft (White) (2pcs)
AX30220 Spring 14x70mm 2.85 lbs/in - Medium (Green) (2pcs)
AX30221 Spring 14x70mm 3.27 lbs/in - Firm (Yellow) (2pcs)
AX30222 Spring 14x70mm 3.55 lbs/in- Super Firm (Blue) (2pcs)
AX30223 Spring 14x70mm 1.04 lbs/in - Black (2pcs)
AX30224 Spring 14x70mm 1.43 lbs/in - Purple (2pcs)
AX30225 Spring 14x70mm 1.75 lbs/in - Orange (2pcs)
AX30395 Heavy Duty Bevel Gear Set 38T/13T
AX30401 Heavy Duty Bevel Gear Set 36T/14T
AX30402 Heavy Duty Bevel Gear Set 43T/13T
AX30469 Machined Hi-Clearance Links - Grey (2pcs)
AX30545 2.2 Internal Wheel Weight Ring 57g/2oz (2 pcs)
AX30546
AX30569 Pinion 48P 14T – Steel
AX30571 Pinion 48P 13T – Steel
AX30572 Pinion 48DP 14T
AX30573 Pinion 48P 15T – Steel
AX30672 Spurs 48DP 87T
AX30709 Universal 5 Bucket Light Bar Set
AX30760 XR10 Aluminum Steering Knuckle (Black) (2pcs)
AX30762 XR10 Aluminum C-Hub Carrier (Black) (2pcs)
AX30780 Universal Joint Axles
AX30781 Wraith Front Sway Bar Set (Soft, Medium, Firm)
AX30782 Wraith Rear Sway Bar Set (Soft, Medium, Firm)
AX30789 Axial AR60 OCP Aluminum Straight Axle Hub Carries
AX30790 Machined Heavy Duty Aluminum Straight Link 101mm - Grey (2pcs)
AX30793 Dig Component Set
AX30797 Wraith Stage 1 Aluminum Links Kit
AX30829 Axial AR60 OPC Machined Low Prole Dierential Cover
AX30830 Axial AR60 OPC Machined Link Mounts
AX30831 AR60 OCP Front Axle Set (Complete)
AX30834 Aluminum Servo Horn 23T
AX30835 Aluminum Servo Horn 24T
AX30836 Aluminum Servo Horn 25T
AX80080 Corbeau LG1 Seat (Grey) (2pcs)
AX8091 Axial 2.2 Rockster Beadlocks (Black)
AX8092 Axial 2.2 Rockster Beadlocks (Chrome)
AX8095 Axial 2.2 Rockster Beadlocks (Black Chrome)
AX8097 2.2 8 Hole Beadlocks (Black)
AX8112 2.2 Beadlock Ring - Grey (2pcs)
AX8117 2.2 Rock Beadlock Ring - Grey (2pcs)
AXA1105 Cone Washer 3x6.9x2mm - Grey (6pcs)
AXA1331 Flanged Ball 3x5.8x7mm (6pcs)
AXA1412 0.5x6mm Spacer - Grey (6pcs)
AXA1413 1x6mm Spacer - Grey (6pcs)
AXA1414 2x6mm Spacer - Grey (6pcs)
AXA1415 3x6mm Spacer - Grey (6pcs)
AXA1416 4x6mm Spacer - Grey (6pcs)
AXA1417 5x6mm Spacer - Grey (6pcs)
AXA1418 6x6mm Spacer - Grey (6pcs)
AXA1419 7x10mm Post - Grey (2pcs)
AXA1420 7x15mm Post - Grey (2pcs)
AXA1421 7x20mm Post - Grey (2pcs)
AXA1422 7x25mm Post - Grey (2pcs)
AXA1423 7x30mm Post - Grey (2pcs)
AXA1424 7x35mm Post - Grey (2pcs)
AXA1425 7x40mm Post - Grey (2pcs)
AXA1426 7x45mm Post - Grey (2pcs)
AXA1427 7x50mm Post - Grey (2pcs)
AXA1428 7x55mm Post - Grey (2pcs)
AXA1429 7x60mm Post - Grey (2pcs)
AXA1430 7x65mm Post - Grey (2pcs)
2.2 Internal Wheel Weight Insert 21g/0.75oz (4pcs) (for use with AX30545)
AXA1431 7x70mm Post - Grey (2pcs)
AXA1046 M4 Serrated Nylon Locking Nut (Blue)
22
NOTES
23
Loading...
