American Weigh Scales, Inc.
PP-50 (50 x 0.01g)
PP-300 (300 x 0.1g)
User Manual
POCKET
-PAL
D i g i t a l P o c k e t S c a l e
g
American Weigh POCKET-PAL
Thank you for purchasing the American Weigh
POCKET-PAL series digital scale. Please read all
operating instructions carefully before use. This
electronic scale is a precision instrument. With normal
care and proper treatment, it will provide years of
reliable service. Never load the scale with more than
the maximum capacity. Overloading will permanently
damage it! Avoid any exposure to extreme heat
or cold. Your scale works better when operated at
normal room temperature. Always allow the scale to
acclimatize to normal room temperature for at least
one hour before use. Give your scale sufcient warm
up time. Usually 30-60 seconds before calibration to
give the internal components a chance to stabilize.
Keep your scale in a clean environment. Dust, dirt,
moisture, vibration, air currents and a close distance to
other electronic equipment can all cause an adverse
effect on the reliability and accuracy of your scale.
Handle with care. Gently apply all items to be weighed
onto tray top. Although this scale is designed to be
quite durable, try to avoid rough treatment as this
may permanently damage the internal sensor. Avoid
shaking, dropping or otherwise shocking the scale.
This is a precision instrument and must be handled
with extreme care.
Only operate the scale on a stable, vibration free
surface.
I. OPERATION
Place Scale on a horizontal at surface.
1. Press [ON/OFF] key.
2. Wait until "0.0” is displayed.
3. Put the object(s) on the weighing platform.
4. Using the [UNIT] key, you can switch between the
weighing units.
II. TARE WEIGHING
1. Turn on scale as described above.
2. Place the "tare item" on the platform.
3. Press [ZERO] and wait until "0.0" is displayed.
4. Add the "net-weight-item".
III. CALIBRATION
Calibration is NOT required before rst use. Only
calibrate if scale is not weighing properly.
**Make sure you use the correct calibration weight for
your scale or the calibration will not be accurate**
PP-50: 50g calibration weight
PP-300: 200g calibration weight
1. Press the ON/OFF button.
2. When
is displayed, hold the UNIT button
until the the LCD shows "CAL", then release it.
3. The scale will then display the required calibration
weight (see above). At this point, place your
calibration weight (not included) onto the weighing
surface. The scale will calibrate automatically.
4. The scale will display the internal reference number
then shut down. Calibration is complete! Repeat if
necessary.
IV. TROUBLESHOOTING
The primary reasons for inaccuracy or malfunction
are low batteries, incorrect calibration, overload or
operating on an unstable surface. Please keep this in
mind and maintain and operate your scale properly.
This scale is a precise instrument and must be
handled with the utmost care and caution.
[Display] Elimination of errors
Change the batteries.
You are overloading the scale. Remove
the excess weight immediately to prevent
damage to the internal load cell.
Use the scale in a more stable position.
g
o z
O Z T
D W T
Specications
Model PP-50 PP-300
Capacity 50g / 1.764oz /
250ct / 771.5gn
300g / 10.585oz /
9.645ozt / 193dwt
Resolution 0.01g / 0.001oz /
0.05ct / 0.2gn
0.1g / 0.005oz /
0.005ozt / 0.1dwt
Dimensions 3” Diameter / 0.75” Height
Display Backlit LCD
Power 1x CR2032 (included)
Warranty 10 Year
