Avtech Voice Modem w/USB Installation Note

AVTECH

RJ-11 Port

OH & Data

LEDs

USB

Connector

AVTECH’s Voice Modem connects Device ManageR’s host

system to an analog phone line. With Device ManageR’s Dial
Out Plugin Bundle, this modem allows you to dial a phone
directly and play alert text or dial tones, or to send an alert text
message through a TAP service.

Voice Modem Package Contents

• One (1) Voice Modem

• One (1) installation CD-ROM

• One (1) Quick Installation Guide

• One (1) RJ-11 telephone cable

Voice Modem

Voice Modem w/USB

Installation Note

OH & Data LEDs

The OH and Data LEDs indicate the state of the modem:

LED Appearance Means

OH O Not in use / not connected

Lit solid (green) In use / connected

Data O No data transmission

Blinking (green) Data transmission

Install Your Voice Modem

Do not use this accessory in hazardous (classied) locations or life safety applications.

AVTECH Software, Inc. Temperature & Environment Monitoring... Made Easy! AVTECH.com

Voice Modem w/USB (MOD-VCE-2)

1. Connect the Voice Modem’s USB cable to a USB port on the Device ManageR’s host
system.

2. Congure your modem on Device ManageR’s host system. See Congure Your Voice

Modem in this document for instructions.

3. Connect one end of the included RJ-11 cable to the RJ-11 port on the Voice Modem and
the other end to your analog phone line.

Accessory Features & Specications

Supported Operating Systems

Power Supply USB

Included Yes

Connector Type USB 2.0

Operating Temperature Range 32° F to 131° F (0° C to 55° C)

Compatible Products Device ManageR software (with Dial Out Bundle)

Windows 8 (32/64-bit), 7 (32/64-bit),
Vista (32/64-bit), XP (32/64-bit)

AVT-170823-2.0.0
