LR15
Item ref: 153.750UK
RGB Signal Repeater
User Manual
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
Introduction
The LR15 is a signal repeater designed to allow extended runs of 12V or 24V RGB LED tape and strip.
Any RGB LED tape controller has a limited amount of current capacity, which means that it can only control a limited length of LED
tape. The LR15 acts as a signal repeater or amplifier so that further lengths of tape can be added to the controlled “incoming” length
of tape and all colours will be repeated across both tapes.
Setting up
Connect the Blue, Red, Green and Voltage+ connections at the end of the incoming tape to the B, R, G and + screw terminals
labeled “SIGNAL IN”
Connect the Blue, Red, Green and Voltage+ connections at the beginning of the continuation tape to the B, R, G and + screw
terminals labeled “OUTPUT”
Connect an appropriate DC power supply for the LED tapes (either 12V or 24V) to the screw terminals labeled “DC IN”
1. SIGNAL IN Blue, Red, Green and Voltage+ connections from incoming LED tape
2. DC IN 12Vdc or 24Vdc power supply connection
3. OUTPUT Blue, Red, Green and Voltage+ connections to continuation LED tape
Example of Connecting in an Array Format
Example of Connecting in Series
Specifications
Voltage
12/24Vdc
Working temperature
-20°C - 65°C
Max current per channel
5A
Dimensions
165 x 39 x 26mm
Weight
260g
Disposal: The “Crossed Wheelie Bin” symbol on the product means that the product is classed as Electrical or
Electronic equipment and should not be disposed with other household or commercial waste at the end of its useful life.
The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted.
Copyright© 2014. AVSL Group Ltd.
