The AVS-VCA-1
Dual VCA
User Guide
Thank you for purchasing from AvonSynth
Congratulations on your purchase of a brand new AvonSynth AVS-VCA-1
Dual VCA Eu
rorack Module. We trust that it will both serve and inspire you
as you create beautiful music with it for years to come.
In order to get the most out of your module, please ensure that you read
this User Guide in its entirety so that you fully understand all of its
functionality, and that you follow all necessary safety directions during use.
Included in the Box
Page 1 of 4
1 x Dual VCA Module 1 x 10 pin to 16 pin
fl
at-cable power cord
4 x M3 Mounting Screws
4 x Nylon Washers
Installation
Step 1: Power your system off. Place the module in your Eurorackcompatible rack in any convenient position. Affix the module to your
rails using the included mounting screws and nylon washers.
Neglecting to use these washers may result in unnecessary marking
of the unit.
Step 2: Triple check the polarity of the power connector before
connecting the power cord to your power supply. Ensure that the -12v
line marked on the back of the module connects to the same end of
the flat-cable that also connects to the -12v line on your power supply.
While AvonSynth modules use shrouded connectors that make this
process safer and more reliable, some systems do not conform to this
polarity standard, so careful checking is always necessary.
Connecting the module with incorrect polarity can result in damage
done to the module which cannot be covered by warranty.
Step 3: Power up your system and start patching!
www.AvonSynth.com
The AVS-VCA-1
User Guide
Features & Specifications
Fully Analogue Voltage Controlled Amplifiers
10
HP wide (50.5mm), 20mm deep
Two independent and identical VCAs in one module
Current consumption: +12V 25ma, -12V 25ma
Linear or Logarithmic response switch
Dual linked audio inputs
Dual linked CV inputs
At normal levels (+/-5v), a very transparent utility VCA, but gain and bias can be set
to overdrive the signal with very pleasing distortion characteristics.
Dual VCA
Description of Functionality
Together with the Init trimmers on the
rear, this knob sets the starting gain
of the VCA before CV is applied to it.
Turn to the right to add gain and
overdrive to the signal, or turn to
the left to ensure silence at times
when no CV input is present.
2-position switch that chooses between
a linear (up) and logarithmic (down)
response for the VCA. When using
analogue envelopes such as the
AVS-ADSR-1, linear will generally be
used. However, when using digital,
linear-shaped envelopes, it may be
desirable to use the logarithmic
response. In this case, extra gain
may need to be applied in order to
achieve the desired output level.
Gain
Curve Selector
Inputs for the signal whose amplitude
you would like to control. Both inputs
are summed - useful for controlling
two sources together, for example
as an oscillator mixer.
Signal Inputs
Inputs for the CVs used to control the
amplitude of the signal inputs. Both
inputs are summed - useful for applying
multiple CVs to the same amplifier, for
example, an ADSR amplitude envelope
and an LFO tremolo.
CV Inputs
The output of the CV-controlled
attenuated or boosted signal.
VCA Output
The bottom half of the module
is an identical reproduction of
the top half with entirely
independent circuitry.
Page 2 of 4www.AvonSynth.com
The AVS-VCA-1
User Guide
Waveform Diagrams
Dual VCA
Calibration Trimpots
Your new AVS-VCA-1 Dual VCA was expertly calibrated by hand for
maximum transparency and dynamic range. Multiturn trimpots
are used for increased accuracy in calibration and can be turned
using a small flat-head screwdriver or other suitable implement.
The Bias trimpots are used to adjust the level of DC offset created
by the module in the course of its operation. The module is
shipped with this set for minimum offset from ground, and
therefore maximum dynamic range. Increasing the amount of
bias applied in one direction will increase the amount of
asymmetrical distortion created, which may be desired in
certain applications.
The Init (Initial Position) trimpots are used to set the initial level
of gain or attenuation applied to the input signal. This is generally
set so that when the front panel gain knob is in the vertical position,
the CV input is zero, and the input signal is +/- 5v, the output
will be silent. As the CV input is increased, the output level
increases correspondingly.
Recalibrating this module requires the use of accurate multimeters,
oscilloscopes and signal generators. If you are not able to carry out
recalibration yourself, the engineers at AvonSynth will be happy to
recalibrate your module for you free of charge during the warranty period.
VCA 1 Bias
VCA 1 Init
VCA 2 Init
VCA 2 Bias
+10v
0v
-10v
0v
Linear Mode Logarithmic Mode
Signal
Input
CV
Input
Output
+10v
-10v
0v
+10v
-10v
+10v
0v
-10v
0v
Signal
Input
CV
Input
Output
+10v
-10v
0v
+10v
-10v
Page 3 of 4www.AvonSynth.com
The AVS-VCA-1
Dual VCA
User Guide
Warranty & Support
Safety Precautions
Please use this module in accordance with the following safety guidelines in order to
maximize the life of the module and ensure warranty from AvonSynth.
This product is covered by AvonSynth's warranty for one year from the manufacturing date.
Within this timeframe, any manufacturing defect will be repaired or replaced by AvonSynth.
Damage caused to the product due to not following the safety precautions above,
unauthorized modification of the hardware, or misuse such as subjecting the unit to reverse
or excessive voltages will void this warranty.
If you have any concerns about your AvonSynth hardware, please get in touch via
info@AvonSynth.com to discuss any issues. We will do our best to assist you in getting your
hardware operating correctly, and if necessary, we will provide an RMA (Return Merchandise
Authorization) to send back the unit for inspection. Any postal costs incurred in this process
will be the responsibility of the customer. Please do not send back merchandise before
receiving this authorization.
o
o
Keep water and other conductive liquids and materials away from this module.
It is not water proof, or even water resistant. Exposure to these can cause
short-circuits that can render the equipment unusable.
Be sure to keep this equipment in an environment with an ambient
temperature above -20 C and below +50 C. Excessively hot or cold
temperatures can be damaging to the electronic circuits used.
Modules with exposed circuit-boards are delicate. Take the utmost care when
handling and transporting this equipment, making sure not to subject it to
excessive forces. Ensure that the module is installed correctly while being
transported and that the original packing materials are used when sending
the module anywhere by post.
Page 4 of 4www.AvonSynth.com
