Avnet MicroZed 7010 Getting Started Manual

Page 1

Copyright © 2016 Avnet, Inc. AVNET, “Reach Further,” and the Avnet logo are registered

trademarks of Avnet, Inc. All other brands are the property of their respective owners.

LIT# Z7MB-IIOT-SK-GSG-v1-1

MicroZed
Industrial Internet of Things Starter Kit
Getting Started Guide

Version 1.1

Page 2

Version

Date

Comment

1.0

30 May 2016

Initial MiniZed Hardware User Guide

1.1

04 Feb 2018

Updated to comply with new Avnet branding

Document Control

Document Version: 1.1
Document Date: 04 February 2018

Prior Version History

Page 3

Contents

Getting Started with the MicroZed IIoT Starter Kit ................................................ 4

What’s Inside the Box? ......................................................................................... 5

MicroZed IIoT Starter Kit .......................................................................................................... 5

What’s on the Web? ............................................................................................. 6

Official Documentation: ............................................................................................................ 6

Tutorials and Reference Designs: ............................................................................................ 6

Trainings and Videos: ............................................................................................................... 6

MicroZed Documentation: ........................................................................................................ 6

Cloud Solutions: ....................................................................................................................... 7

Application Source Code: ......................................................................................................... 7

Wind River Pulsar Linux: .......................................................................................................... 7

Available through Avnet FAE: .................................................................................................. 7

MicroZed IIoT Key Features ................................................................................. 8

MicroZed IIoT Starter Kit Basic Setup and Operation ................................ ........... 9

MicroZed SOM Boot Mode ....................................................................................................... 9

Install Silicon Labs CP210x USB-to-UART Drivers on a PC.................................................. 11

MicroZed IIoT Hardware Setup .............................................................................................. 11

Pulsar Login and Firmware Upgrade ...................................................................................... 12

Running the Applications .................................................................................... 13

Run the SPI Application.......................................................................................................... 13

Run the I2C Application .......................................................................................................... 14

Run the IIoT Quickstart Demonstration .................................................................................. 15

Run the IIoT Bluemix Demonstration ..................................................................................... 18

Wind River Helix App Cloud ................................................................................................... 20

Getting Help and Support ................................................................................... 22

Avnet Support ......................................................................................................................... 22

Xilinx Support ......................................................................................................................... 23

Appendix I – Create Your Bluemix Service ......................................................... 24

Create a Starter Cloud Application ......................................................................................... 24

Create a Cloud Service .......................................................................................................... 27

Register a Device ................................................................................................................... 29

Complete the Bluemix Application .......................................................................................... 34

Clean up ................................................................................................................................. 38

Page 4

Getting Started with the MicroZed IIoT Starter Kit

The Avnet MicroZed IIoT Starter Kit enables hardware and software developers to create and
evaluate Zynq™-7000 All Programmable SoC designs, using on-board sensors to gather
information from the immediate surroundings and transmit the data to a Cloud environment.
Cloud services can be used for real-time data analysis and decision-making, data storage, post­analysis, real-time or historical display and an ever-growing list of domain-specific functions.

The kit includes a standalone MicroZed System-on-Module (SoM) containing a hard-wired Zynq
Processing System (PS) with peripherals as well as enabling the Zynq Programmable Logic
(PL) fabric. This PS system includes DDR3 memory, Flash memory, gigabit Ethernet, USB 2.0
Host, and a UART.

The MicroZed SoM is attached to an ArduinoTM Carrier Card. The carrier brings both Shield
expansion and Peripheral Module (2x6 pin connectors) expansion to the MicroZed System-On­Module. The carrier card is ideal for building quick prototypes that leverage the large number of
Arduino-compatible Shields and Pmod-compatible expansion boards.

The following sensors are included with the kit:

 ST Microelectronics motion MEMS and environmental sensor Shield

o 3-axis accelerometer + 3-axis gyroscope
o 3-axis magnetometer
o Humidity and temperature
o Pressure

 Maxim Integrated thermocouple-to-digital peripheral module

o Connects to 2x6 peripheral module
o SPI-based interface
o Measures temperatures from -270°C to +1800°C
o Includes K-type thermocouple

This Getting Started Guide outlines the steps to set up the hardware, load a sample hardware
design, and execute Linux applications running on the ARM® dual-core Cortex™-A9 MPCore™
Processing System. Readings are taken from the on-board sensors and transmitted to an IBM
Watson IoT BluemixTM application, where the data is analyzed and resulting commands are
sent back to the target. You will need to set up an IBM Watson IoT account to access the
Bluemix services. A free trial and free online training is available through Avnet by filling out the
registration at:

http://artofthepossibility.com/bluemix-free-trial

Page 5

What’s Inside the Box?

MicroZed IIoT Starter Kit

 MicroZed 7010 SoM
 Arduino Carrier Card +

(4) stand-offs and screws

 2 USB-A to microUSB-B cables
 Ethernet cable
 8GB microSD card +

microSD to SD card adapter

 ST Microelectronics motion MEMS

and environmental sensor Shield

 Maxim Integrated thermocouple-

to-digital peripheral module

 Wind River Pulsar Linux
 Documentation

o MZ IIoT Kit Quick Start Card
o Wind River Pulsar Quick Start Card

Page 6

What’s on the Web?

MicroZed IIoT is a community-oriented kit, with all materials being made available through the

www.microzed.org community website. Documentation specific to the Arduino carrier can be

found here:

http://microzed.org/product/arduino-cc

Official Documentation:

 Schematics (MicroZed 7010 and Arduino Carrier Card)
 Bill of materials
 Layout
 Hardware manual
 Board definition files

Tutorials and Reference Designs:

http://microzed.org/support/design/13591/

 MicroZed 7010 SPI and I2C Vivado Design Example1
 MicroZed 7010 SPI Peripheral Application with Wind River Pulsar Linux1
 MicroZed 7010 I2C Peripheral Application with Wind River Pulsar Linux1

Trainings and Videos:

http://microzed.org/support/trainings-and-videos

 Overview of MicroZed
 Introduction to Zynq-7000 All Programmable SoC
 Developing Zynq-7000 All Programmable SoC Software
 Developing Zynq-7000 All Programmable SoC Hardware
 Wind River Pulsar Linux for Avnet Designed SoMs

MicroZed Documentation:

http://microzed.org/support/documentation/1519

 MicroZed Getting Started Guide
 Getting Started with Pulsar Linux on Avnet Zynq Boards
 Wind River Pulsar Linux Overview

http://microzed.org/support/documentation/9031

 MZCC_ARD Getting Started Guide

Page 7

Cloud Solutions:

https://acm.avnetcloudsolutions.com/catalog/

 IBM Bluemix
 Amazon Web Services

Application Source Code:

https://github.com/Avnet/software

Wind River Pulsar Linux:

http://www.windriver.com/products/operating-systems/pulsar/

Available through Avnet FAE:

 Altium source database for schematic and layout

Page 8

MicroZed IIoT Key Features

MicroZed 7010 SoM

 Zynq™-7000 AP SoC XC7Z010-CLG400-1 Processor
 Memory

o 1 GB DDR3
o 128 Mb Quad-SPI Flash
o 4 GB microSD card

 Communication

o 10/100/1000 Ethernet
o USB Host 2.0 and USB-UART

 Expansion connectors

o 2 Micro-Header connectors (108 single-ended, 48 differential pairs, Agile Mixed

Signaling (AMS))

o Digilent Pmod™ Compatible header (8 MIO)

 Clocking

o 33.33333 MHz clock source for PS

 Configuration and Debug

o Xilinx Platform Cable JTAG connector

 General Purpose I/O

o 1 user LED
o 1 push button

Arduino Carrier Card

 Full Arduino-compatible Shield site with connection to MicroZed PL I/O
 Two 2x6 Pmod™-compatible peripheral interfaces for MicroZed

 Supports interface for PL based SDIO/SPI
 Supports interface for I2C/UART

 One 2x6 Pmod™-compatible peripheral interface to low-power MCU connector

ST Microelectronics motion MEMS and environmental sensor Shield

 Six sensor solutions connect on Shield sockets via I2C AXI soft IP

o 3-axis accelerometer and 3-axis gyroscope
o 3-axis magnetometer
o Humidity and temperature
o Pressure

 General Purpose I/O
 1 user LED

Maxim Integrated thermocouple-to-digital peripheral module

 Connects 2x6 peripheral module via SPI AXI soft IP
 Dual temperatures from on-board sensor and thermocouple sensor

o Thermocouple temperature range -270°C to +1800°C

Page 9

MicroZed IIoT Starter Kit Basic Setup and Operation

The MicroZed IIoT Starter Kit includes an 8 GB microSD card preloaded with a certified Wind
River Pulsar Linux image, augmented with SPI and I2C drivers for the sensor peripherals and a
bitstream to provide hardware support. The image also contains the following pre-built
applications:

1. HTS221 Temperature and Humidity sense example

2. Maxim 31855 Dual Temperature sense example

3. Cloud-connectivity example using IBM Watson IoT and Bluemix services

Wind River Pulsar Linux is an application-ready development and production platform, allowing
for on-target compilation and remote upgrade through the Smart Package Manager. The
platform also offers a connection to a Cloud-based SDK and visual debug environment on the
Wind River Helix App Cloud. This free service allows development on a remote target from any
Web browser. You may register here:

https://app.cloud.windriver.com/

For more details on Wind River Pulsar Linux, consult the Wind River Pulsar Quick Start Card
included in your kit, or visit:

http://www.windriver.com/products/operating-systems/pulsar/

MicroZed SOM Boot Mode

Before assembling the kit items, please take a moment to locate the key components on the
MicroZed SoM and ensure it is in the microSD boot configuration. MicroZed SoMs are available
standalone, and have the Boot MODE jumpers configured at the factory to boot from QSPI
flash. In QSPI flash mode, a memory-resident Linux kernel and file system will boot but will not
provide the software/hardware elements necessary to complete the procedures in this guide.

Page 10

MicroZed SoM Component Locations and Factory Boot Setting

Please check the Boot MODE jumpers and ensure they are in the position shown below. This
will allow the boot to source the image from the supplied microSD card (JP1 in the top position,
JP2 and JP3 in the bottom position).

MicroZed SoM microSD Boot Mode Jumper Settings

Page 11

Install Silicon Labs CP210x USB-to-UART Drivers on a PC

The USB-to-UART port on the MicroZed SoM is required to display serial output generated on the
target to a console on a host PC. To use a standard USB port on a host PC as a serial device,
you must first install drivers from Silicon Labs. The drivers will allow the USB connection to be
enumerated as a serial port, which can then be used to communicate with the target via a serial
communications program such as Tera Term Pro.

If not previously installed on your host system, visit:

http://microzed.org/support/documentation/1519

to download and install the drivers referenced in Avnet’s CP210x USB-to-UART Setup Guide.

MicroZed IIoT Hardware Setup

1. Attach the ST Micro X-NUCLEO-IKS01A1 Shield to the Arduino Carrier Card.

2. Plug the thermocouple into the Maxim 31855 Pmod and attach the assembly to the
connector (J3) top row at the end of the Arduino Carrier Card.

3. Insert the supplied Pulsar microSD card in the cage beneath the MicroZed SoM.

4. Attach the MicroZed SoM to the Arduino Carrier Card FMC connectors. Set the boot mode
jumpers for microSD-boot (see MicroZed SoM Boot Mode section).

5. Plug a DHCP-Server-connected Ethernet cable to the MicroZed SoM RJ-45. In order to
connect to the Watson IoT Bluemix service via Ethernet, the kit must be able to obtain a
LAN IP address from a DHCP server, and a gateway address that allows unfettered Internet
access.

6. Connect one microUSB cable between the AC/DC power supply and Arduino power port
(J7). The blue DONE LED adjacent to SW2 on the MicroZed SoM will illuminate as the
board boots Wind River Pulsar Linux.

Connect the USB-UART port on the MicroZed SoM (J2) to a free USB port on your PC. Use the
PC Device Manager to determine the COM port and set the console parameters to
115200,n,8,1. Optionally, reset the processor by pressing and releasing the RST button on the
MicroZed SoM (SW2) to view the entire boot.

Page 12

Pulsar Login and Firmware Upgrade

Once power has been applied to the kit, the boot sequence will initialize the Programmable
Logic with the supplied hardware system. Completion of this step is indicated by the illumination
of the blue DONE LED on the MicroZed SoM.

Once hardware initialization is complete, the Pulsar Linux software will boot from the microSD
card. On completion of the boot, the serial console on the host will display a login prompt, as
shown here:

1. Log in at the command prompt with user/pw:

root/incendia

2. To upgrade the device firmware, at the command prompt enter the following:

smart update

This procedure is typically done only on the first-time boot, but it can be repeated as
desired to manually check for updated repository contents.

The Smart Package Manager will automatically contact the Wind River public repository to
compare the contents on the microSD card with the current packages available. If necessary,

newer packages will be downloaded and installed automatically.

Page 13

Internal
Temperature
Sensor

Insert
Thermocouple
here

Running the Applications

Run the SPI Application

The SPI application reads temperature data from the Maxim 31855 Pmod sensors. There are
two sensors on the module, one providing ambient temperature at the module location and the
second from the end of the cable attached to the thermocouple.

Thermocouple and Cable

Pmod On-board Temperature Sensor Location

The sample application reads data from both sensors and displays the result on the PC host
serial console. On the target, the SPI interface is accessed from the application code using the
built in SPIDEV driver in the Pulsar Linux kernel.

At the command prompt, enter the following command:

./maxim31855_sensor

The temperatures are reported once on the console as shown below:

Note: The thermocouple must be inserted into the Pmod, or the application will detect an open
circuit and exit without displaying temperature values.

Page 14

HTS221
Temperature/Humidity
Sensor (U3)

Run the I2C Application

The I2C application reads temperature and humidity data from the ST Microelectronics HTS221
sensor, located on the Arduino Shield.

HTS221 Sensor Location

The sample application reads data values from the sensor and outputs the values continuously
to the PC host serial console.

On the target, an I2C driver in the Pulsar Linux uses the sysfs virtual file system to export
information about the I2C kernel subsystem to user space.

At the command prompt, enter the following:

./hts221_sensor

The temperature and humidity values are reported on the console as shown below:

To end data display, enter <CTRL>-C in the console.

Page 15

Run the IIoT Quickstart Demonstration

This demonstration reads data from selected onboard sensors and publishes (transmits) to the
Cloud-resident IBM Watson IoT public Quickstart service. Incoming values are displayed
graphically as they arrive. Your IIoT kit must be connected to the Internet for this demonstration
to operate correctly, but a Bluemix account is not required.

By default, data is read from the HTS221 temperature sensor on the ST Microelectronics
Arduino Shield and published to the cloud service. The application can be executed from the
command prompt using the format:

./IIoT_QuickStart_Demo <uniqueID>

where <uniqueID> is any alphanumeric string you choose. This string is simply used to isolate
your specific instance from other simultaneous access requests to the site by any number of
concurrent users. It is valid only for the duration of the application run, but can be reused or
changed in each subsequent execution. In the unlikely event that your <uniqueID> is refused,
simply choose another string that is less likely to be picked by another user.

The example below uses a <uniqueID> of abc123:

Notice that the live data transmission can be seen at the link shown above, in the format:

https://quickstart.internetofthings.ibmcloud.com/#/device/

Page 16

with <uniqueID> appended to the end. You may click the link above to go to the website and
enter your <uniqueID> in the text box provided, or copy the link directly from the serial console
and paste it into the browser of any Internet-connected device.

HTS221 Temperature Data in IBM Watson IoT QuickStart

Type <CTRL>-C in the IIoT Kit console to terminate the application instance.
You may read data from other sensors by supplying an optional selection parameter following

the <uniqueID>. For a list of the sensors currently available from the application, at the
command prompt type:

./IIoT_Quickstart_Demo abc123 –help

Page 17

Page 18

Run the IIoT Bluemix Demonstration

This demonstration builds on the Quickstart application, adding these features:

 Published data requires security credentials to connect to a Bluemix application
 The Bluemix application processes published data and communicates analytic results

back to the IIoT Kit through a callback registration mechanism

 Incoming results from Bluemix are received by the application and the User LED on the

MicroZed is accessed to convey status information

Your IIoT kit must be connected to the Internet for this demonstration to operate correctly, and
you must have registered with IBM Watson IoT to set up your own Bluemix account. If you have
not done so, to access your Bluemix trial and obtain a promotional code to access Avnet online
training at no charge, please visit:

http://artofthepossibility.com/bluemix-free-trial

Once you have your Bluemix account, you will need to configure the Watson IoT broker and
bind it to a running Bluemix application. For first time operation, see Appendix I for step-by­step instructions.

1. Ensure that your Cloud (Bluemix) application is running, as described in Appendix I.

2. To run the IIoT Bluemix demonstration, at the command prompt for the IIoT Kit enter:

./IIot_Bluemix_Demo

The application will read temperature and humidity values from the HTS221 sensor on the
Shield and transmit data to your Bluemix service.

Page 19

Additional sensor options for the sample demonstration program can be displayed by requesting
help at the command line.

./IIoT_Bluemix_Demo –help

Page 20

1

Wind River Helix App Cloud

Pulsar Linux provides an application-ready development environment on the MicroZed SoM,
allowing you to create and build programs in the command line environment directly on the
target. For details on this and other features of your software platform, consult the Wind River
Pulsar Quickstart Card included in the kit.

However, with Avnet Zynq SoMs you may also access a cloud-based Software Development
Kit. Using Wind River Helix App Cloud (HAC) allows development from any Internet-enabled
device with a web browser. Application source can be uploaded and downloaded easily from a
host system to the Cloud, or between the IIoT Kit and the Cloud. The HAC provides a full­screen, color-coded editor and a compatible tool-chain for your target, as well as complete
visual debugger. With your IIoT Kit connected to the Internet, you can debug applications
seamlessly on your target, regardless of the proximity of the device to your physical location.

To access the HAC, follow these steps:

1. Ensure the IIoT Kit is connected to the Internet and at the Pulsar command prompt enter:

registerTarget –n <RandomCode>

2. You will receive a Registration Key valid for approximately 20 minutes. Direct your host­based browser to:

https://app.cloud.windriver.com/

3. Sign in with your Wind River Support credentials1 and click the New Device button.

If you do not already have a Wind River Account, you may create one by clicking the Register Now

button on this site.

Page 21

4. Click on “Register an existing device…” and follow the on-screen prompts to create the
cloud-based SDK workspace for your IIoT Kit.

5. Once the IIoT kit is registered, you can create a new application project by clicking the
Create new project button.

For further details on getting started developing with the Wind River Helix Application Cloud on
the MicroZed IIoT Kit, view the online video Developing IIoT Applications on Wind River
Helix App Cloud at:

http://zedboard.org/support/trainings-and-videos

Page 22

Documentation

Reference Designs

Getting Help and Support

Avnet Support

Technical support is offered online through the MicroZed.org website support forums.
MicroZed IIoT Starter Kit users are encouraged to participate in the forums and offer help to
others when possible.

For questions regarding the MicroZed community website, please direct questions to:

MicroZed.org Web Master – [e-mail]

To access the most current collateral for the MicroZed IIoT Starter Kit, visit the community
support page (www.microzed.org/content/support) and click one of the icons shown below:

Scroll to the Industrial IoT Starter Kit and click the View button.

Technical questions for the MicroZed IIoT Starter Kit should be directed to the MicroZed
Support forums. Click the Support Forums link:

Enter questions under either MicroZed Hardware Design or Software Application Development.

Page 23

Xilinx Support

For questions regarding products within the Product Entitlement Account, send an email
message to the Customer Service Representative in your region:

Canada, USA and South America - [e-mail]

Europe, Middle East, and Africa - [e-mail]

Asia Pacific including Japan - [e-mail]

For technical support, including the installation and use of the product license file, contact
Xilinx Online Technical Support at www.xilinx.com/support. The following assistance resources
are also available on the website:

 Software, IP and documentation updates
 Access to technical support Web tools
 Searchable answer database with over 4,000 solutions
 User forums

Page 24

Appendix I – Create Your Bluemix Service

Create a Starter Cloud Application

These instructions assume you have already registered for an IBM Watson IoT account.

1. From your host computer, log into the Bluemix site, using the credentials you established

in the lab pre-work. The website is:

https://console.ng.bluemix.net.

2. From the Bluemix main menu, select CATALOG.

3. From the Starters list on the left, select Boilerplates.

4. Click the Internet of Things Platform Starter.

5. In the panel on the right, enter a unique application name. The name must consist

entirely of alphanumeric characters and/or the dash character.

Page 25

6. Click the CREATE button. You will see the staging message at the top of the page as

follows:

After a few minutes, the message changes to indicate the application has started
running, as shown below. Depending on the volume of traffic to the site, starting the
application can take anywhere from 2 to 10 minutes.

Page 26

7. Enter the following URL in your browser (or click the link in the app-running message):

http://<ApplicationName>.mybluemix.net

8. Click Go to your Node-RED flow editor.

This opens a new tab in your browser showing the Node-RED cloud application
development SDK.

The default application shown below is made up of different types of nodes, each with
different operational characteristics, and linked together to perform a logical circuit.

In this case, information arrives at the left in the blue input node, and is interpreted as
temperature data. In the lower chain, the temperature is evaluated based on a threshold
and a status message printed.

This is the Bluemix equivalent to a helloWorld program, and could be used with the Quickstart
service to create an unsecured application connection from the IIoT Kit. However, the goal is to
create a secure connection, so for the moment we will leave the application and create an IoT
Service. Leave this browser tab open, as you will return to it later.

Page 27

Create a Cloud Service

Quickstart is a public service that allows anyone to make an unsecured connection to the
sample application. However, now that we have a custom application, we want to provide a
more secure access point, through the IBM Watson IoT broker service. Once the service is
created, we can bind our application to it, so incoming data will be validated and then routed to
your application.

1. Return to the Dashboard tab in your browser.

2. From the Bluemix main menu, select CATALOG.

3. From the Services map on the left, select Internet of Things.

4. Click Internet of Things Platform.

5. In the rightmost panel, select the application to bind to the service from the App drop-

down (the application you created in earlier will be listed) and click the CREATE button.

Page 28

6. Accept the offer to restage the application by clicking the RESTAGE button when

presented. Once the application is running, you will have a new Bluemix option for
authentication, which can be used with the IIoT_Bluemx_Demo on the target.

As before, this operation will take a few minutes (2-10) to complete.

Page 29

Register a Device

Now we have an IoT Cloud application, bound to an IoT Service, and we are ready to establish
credentials to register an edge device.

1. You should still be in the Dashboard tab in the browser. Select it if you are not.

2. Click the Back to Dashboard link in the left panel.

3. Your application displays a new icon representing the IoT service bound previously.

Click the IoT icon in your application to display the Internet of Things Platform page.

4. In the Connect your Devices column, click the Launch Dashboard button.

Page 30

5. In the left panel, click Devices, then click the Add Device button.

6. You can add an existing device type (one created previously) or add a new device type.

If this is your first time registering a device, click the Create device type button.

If you are creating a device type, you will need to enter various parameters to associate
with the device type. For example, the manufacturer (Avnet) or the serial number which
is located on a white sticker on the bottom of the board.

7. Click the Create device type button (again) on the updated browser page.

8. Fill in the Name and Description of the new device type. You can follow the example

below or enter information of your choosing. Click the Next button at the bottom right.

9. In the Create Device Type panel, click in the check box next to Manufacturer to select it.

Click the Next button.

Page 31

10. In the Create Device Type panel, enter the Manufacturer as Avnet. Click the Next

button.

11. Click the Create button to skip the optional Metadata entry.

12. In the Add Device – Choose Device Type panel, select the device type you just

created and click the Next button.

13. In the Add Device – Device Info panel, enter the unique Device ID specified earlier in

the input node of your Bluemix application. Note that the Manufacturer field is
automatically filled in. If you expand the Additional fields, you can optionally enter
further device information. Click the Next button.

14. Click the Next button to skip the optional Metadata entry.

15. In the Add Device - Security panel, enter a simple token in the Provide a token

(optional) field. This will be easier to remember and enter later in the on-target
configuration file. However, In a production situation, a more complex value can be used
or generated. Make a note of the token you entered, and click Next.

Page 32

16. In the Add Device – Summary panel, review the information and click the ADD button.

The system will display your device credentials. For example:

Keep the authentication information handy, as you will need it to configure the edge
application so it can connect to the running Bluemix application.

TIP: Use the Windows snipping tool to save it temporarily to the desktop.

17. To use the new service, you need to create/update the configuration file with the new

authentication information. This is done on the target (MZ IIoT Kit) device.

a. Return to the terminal console (or reboot your target and log in) and ensure you

are still in the /root directory.

b. Launch the vi editor on the target to create a new file called device.cfg.

vi device.cfg

You will be creating a file exactly as show, replacing the highlighted text to
substitute the credentials you generated for your device in the previous step.

Page 33

c. Press the i keyboard key to enter Insert mode.

d. Use the arrow keys as needed to move around the file Use the backspace key

to erase the text you wish to replace. Type in the information you saved for your
device credentials, replacing each line as indicated with the true information. For
example, using the sample credentials shown in Step 16, your file contents would
appear as shown here:

org=8a8rej
type=MicroZed
id=MZ-1402120-7010
auth-method=token
auth-token=SecurityToken99

e. When you have completed entering all the information, return to command mode

by hitting the <ESC> key followed by a colon (ii:). The cursor will go to the bottom
of the screen.

f. Enter wq (for write-quit). At this point you should be back at the command line.

18. List your file with the cat instruction. It should appear exactly as you entered it. If not,

repeat the editing process until it is correct.

cat device.cfg.

Page 34

Using the example above, the listing appears as shown here:

The IIoT_Bluemix_Demo program automatically looks in its current directory for a configuration
file, so when it is launched, it will adopt your configuration credentials. These could be hard­coded in an application, but it is more convenient to use a configuration file.

Complete the Bluemix Application

1. Return to the Node-RED editor tab in your host browser, and double click the IBM IoT

App In node to edit the node.

a. Select the Bluemix Service as the Authentication method.
b. Uncheck the All box to the right of Device Type and enter the value you created

in the prior section (ie: MicroZed).

c. Uncheck the All box to the right of Device Id and enter the ID you selected for the

IIoT Kit.

d. Click the OK button.

Page 35

2. In the left-hand panel, scroll down to the output nodes and drag and drop the ibmiot

node onto Flow 1. Position the node to the right and above the safe node.

3. Click the bubble on the right side of the safe node and with the left mouse button

pressed, drag the cursor over to the left bubble on your new IBM IoT node to make a
connection between them. Repeat the connection using the right bubble on the danger
node.

4. Double-click the temp thresh node. Update the values in both boxes to 2500 (integer

representation of 25 degrees Celsius to two decimal places). Click the OK button.

5. Double-click the danger node. Add 10 spaces after critical as shown below. This will

correct an overwrite issue on the output console when switching between the safe and
danger nodes. Click the OK button.

6. Double-click the new IBM IoT node to open its properties. Fill the parameters as shown,

but substitute your own Device Type and Device ID for the example values:

Page 36

Make sure you capitalize JSON in the Format box. Click the OK button.

7. Click the Deploy button at the top right.

8. Return to the IIoT Kit console and run the IIoT_Bluemix_Demo application. You can

monitor the connection in the debug panel of the Node-RED flow editor, and you will see
new messages on the target console that indicate the Cloud is communicating back to
the target.

In the target console, enter: ./IIoT_Bluemix_Demo

Page 37

In the debug tab in your Node-RED application, you will see data start to flow:

Note: Clear the debug window by pressing the garbage can icon at the upper right.
TIP: If you do not see an Info/Debug tab, click the right hamburger menu icon (three

horizontal lines) and select View | Show Sidebar (check the box).

On the IIoT Kit console, you will see corresponding transmissions (JSON string above
each Publishing line) and the incoming response from the Bluemix application.

If you do not see the return messages on your console, the local credentials in the device.cfg
file on your target do not match those entered above in the Bluemix IBMiot output node
properties (step 6). Also make sure you did not forget to capitalize JSON in the output node
properties.

Page 38

Clean up

Once you are finished working with the Bluemix application and Watson IoT services, you
should close the Bluemix application and stop the service. This will prevent charges from
accumulating in the event you are not using a Free service.

1. Close the Node-Red tab in your browser by clicking the X icon.

2. Close the Watson IoT Platform tab by clicking the X icon.

3. In the Dashboard – IBM Bluemix tab, click Back to Dashboard.

4. Click the gear icon at the upper right of your running application.

Page 39

5. Select Stop App from the pop-up menu. Click the STOP button in the subsequent

dialog to confirm.

6. Once the application has stopped, you may log out from your Bluemix account by

clicking on the icon in the upper right of the page.

7. Click on the Log Out link that appears. Click the Log Out button in the new dialog to

confirm.

8. You may now close the browser.

9. If you still have the target application running, enter <CTRL>-C in the console.

10. To ensure a safe power down of the IIoT Kit, enter poweroff at the console prompt.

11. You may now disconnect the serial microUSB cable from the MicroZed SoM and the

power microUSB cable from the Arduino carrier.

12. Close the IIoT Kit serial console.
