FRITZ!WLAN Repeater N/G
More Range for Every Wireless Network
Operation
n
Legal Notice
Legal Notice
FRITZ!WLAN Repeater N/G
This documentation and the software it describes are protected by copyright. AVM grants the nonexclusive right to use the software, which is supplied exclusively in what is known as object code
format. The licensee may create only one copy of the software, which may be used exclusively for
backup use.
AVM reserves all rights that are not expressly granted to the licensee. Without previous approval
in writing, and except for in cases permitted by law, it is particularly prohibited to
copy, propagate or in any other manner make this documentation or this software publicly ac-
cessible, or
process, disassemble, reverse engineer, translate, decompile or in any other manner open
the software and subsequently copy, propagate or make the software publicly accessible in
any other manner.
The licensing conditions are specified in the FRITZ!WLAN Repeater N/G user interface: Open the
user interface as described on page 15, click the question mark icon at the upper right, and open
the “Legal Notice”.
This documentation and software have been produced with all due care and checked for correctness in accordance with the best available technology. AVM GmbH disclaims all liability and warranties, whether express or implied, relating to the AVM product’s quality, performance or suitability for any given purpose which deviates from the performance specifications contained in the
product description. The licensee bears all risk in regard to hazards and impairments of quality
which may arise in connection with the use of this product.
AVM will not be liable for damages arising directly or indirectly from the use of the manual or the
software, nor for incidental or consequential damages, except in case of intent or gross negligence. AVM expressly disclaims all liability for the loss of or damage to hardware or software or
data as a result of direct or indirect errors or destruction and for any costs (including connection
charges) related to the documentation and the software and due to incorrect installations not performed by AVM itself.
The information in this documentation and the software are subject to change without notice for
the purpose of technical improvement.
We offer a manufacturer’s warranty for this original product. The warranty conditions are presented on page 28 of this manual.
© AVM GmbH 2008 – 2009. All rights reserved. Documentation release 09/2009
AVM Audiovisuelles Marketing
und Computersysteme GmbH
Alt-Moabit 95
D 10559 Berlin
AVM in the Internet: www.avm.de/en
Trademarks: Unless otherwise indicated, all trademarks mentioned are legally protected trade-
marks owned by AVM GmbH, especially product names and logos. Microsoft, Windows and the
Windows logo are trademarks owned by Microsoft Corporation in the USA and/or other countries.
Bluetooth is a trademark of Bluetooth SIG, Inc. licensed to AVM GmbH. All other products and
company names are trademarks of their respective owners.
AVM Computersysteme
Vertr iebs Gmb H
Alt-Moabit 95
D 10559 Berlin
FRITZ!WLAN Repeater N/G 2
Table of Contents
Table of Contents
Table of Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Symbols and Highlighting . . . . . . . . . . . . . . . . . . . . . . . . . 5
CONNECTING AND OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1 Security and Handling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 FRITZ!WLAN Repeater N/G . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2 Operation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Starting Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Connecting to Electrical Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 The Display of the FRITZ!WLAN Repeater. . . . . . . . . . . . . . . . . . . . . . . . 9
3.3 Connecting to an Access Point. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 Operating FRITZ!WLAN Repeater . . . . . . . . . . . . . . . . . . . 14
4.1 Operation Using the Display of the FRITZ!WLAN Repeater . . . . . . . . . 14
4.2 Operation Using a Web Browser on the Computer . . . . . . . . . . . . . . . 15
5 Music in the Network with the FRITZ!WLAN Repeater . . . 16
5.1 Program for the Audio Bridge. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.2 Connecting a Stereo System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.3 Connecting a Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.1 Checking the Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.2 Restricted Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.3 The WLAN Connection Cannot Be Established . . . . . . . . . . . . . . . . . . 20
6.4 Registration Not Possible. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.5 Microsoft WLAN Service (WZC) Is Not Supported . . . . . . . . . . . . . . . . 23
6.6 No Higher Data Rates Available . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
FRITZ!WLAN Repeater N/G 3
Table of Contents
6.7 Interference During Audio Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
PRODUCT DETAILS AND USEFUL INFORMATION . . . . . . . . . . . . 25
1 Product Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
1.1 Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
1.2 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
1.3 Declaration of CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
1.4 Manufacturer’s Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2 More about WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2.1 Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2.2 Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
2.3 Frequency Ranges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3 Customer Service Guide . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3.1 Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3.2 Information in the Internet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3.3 Updates and Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3.4 Support from the Service Team . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
FRITZ!WLAN Repeater N/G 4
Symbols and Highlighting
Symbols and Highlighting
The following sections present explanations about the symbols and
highlighting used in this manual.
This symbol indicates useful hints to assist you in working with the FRITZ!WLAN Repeater.
This symbol indicates important instructions that must be
observed to avoid malfunctions.
The table below explains the highlighting used in this
manual.
Highlighting Function Examples
Quotation marks Keys
Buttons
Settings pages
Menus
Commands
File paths
File names
Underlined text Text input fritz.repeater
“F1” key
“Help”
“Advanced”
“Edit / Paste”
“Copy”
“C:/My Documents”
“Info”
Pointed brackets Joker <MSN>
Bold Emphasis Do not click the but-
FRITZ!WLAN Repeater N/G 5
ton...
Security and Handling
I CONNECTING AND OPERATION
1 Security and Handling
What to Watch Out For
Safety Instructions When working with the FRITZ!WLAN Repeater N/G, observe
the following security instructions in order to protect yourself and the FRITZ!WLAN Repeater from harm.
Do not install the FRITZ!WLAN Repeater during an
electrical storm.
Disconnect FRITZ!WLAN Repeater from the power
supply during electrical storms.
Never let liquids get inside the FRITZ!WLAN Repeater.
Otherwise, electric shocks or short circuits may result.
The FRITZ!WLAN Repeater is intended for indoor use
only.
Do not open the FRITZ!WLAN Repeater housing. The
device contains hazardous components and should
only be opened by authorized repair technicians.
Insert the FRITZ!WLAN Repeater in a socket in a dry
location that is free of dust and protected from direct
sunlight.
Make sure to keep sufficient distance from potential
sources of interference like microwave devices or
electric devices with large metal housings, and from
radiators or walls.
FRITZ!WLAN Repeater N/G 6
FRITZ!WLAN Repeater N/G
2 FRITZ!WLAN Repeater N/G
An Overview
The FRITZ!WLAN Repeater extends the range of your wireless network.
To extend a network the FRITZ!WLAN Repeater is integrated into the radio network in just a few steps, providing for:
access to the Internet for computers located on the edge or out-
side of the range of your access point
the connection to a media receiver you can use to receive tele-
vision over the Internet
connection to audio devices like stereo systems and FM radios
Uses of the FRITZ!WLAN Repeater
FRITZ!WLAN Repeater N/G 7
Package Contents
2.1 Package Contents
The following is included in the FRITZ!WLAN Repeater N/G
package:
FRITZ!WLAN Repeater N/G
printed quick guide
2.2 Operation Requirements
In order to operate the FRITZ!WLAN Repeater, you must
have the following:
WLAN access point in accordance with
IEEE 802.11b/g/a/n (draft 2.0) and 2.4 or 5 GHz
For WPS functionality: a WPS-compliant WLAN access
point with up-to-date firmware
For first configuration without WPS: WLAN client that
supports the WPA encryption standard
For Installation Wizard and audio function: Microsoft
Windows Vista (32-bit) or Windows XP (32-bit) and
an Internet connection
WLAN access point with automatic IP address assign-
ment (DHCP)
Forwarding of IPv4-based protocols / Address Reso-
lution Protocol
FRITZ!WLAN Repeater N/G 8
Starting Operation
3 Starting Operation
Plugging in and Connecting the FRITZ!WLAN Repeater
This chapter contains instructions on the following topics:
connecting the FRITZ!WLAN Repeater to the electricity grid
the display of the FRITZ!WLAN Repeater
connecting the FRITZ!WLAN Repeater with an access point
Note the additional information in the section “Security
and Handling” on page 6.
3.1 Connecting to Electrical Power
Connect the FRITZ!WLAN Repeater to an electrical outlet.
The FRITZ!WLAN Repeater provides for optimum extension
of your wireless network when it is positioned halfway between your access point and the devices for which the
wireless network is to be extended.
Connecting the FRITZ!WLAN Repeater to the electricity grid
3.2 The Display of the FRITZ!WLAN Repeater
The FRITZ!WLAN Repeater has a touch-sensitive screen
that can be used to configure the basic settings of the device. The settings are opened using the three integrated
touch points, which are enabled depending on the function displayed.
FRITZ!WLAN Repeater N/G 9
Connecting to an Access Point
Touch Point Function
Center enable the displayed option
Left back / back to higher menu
Right forward / more options
FRITZ!WLAN Repeater: Touch points on the display
3.3 Connecting to an Access Point
To extend your radio network, connect the
FRITZ!WLAN Repeater to your WLAN access point via a
wireless connection. Use one of the three following possibilities to establish the wireless connection between the
devices.
Establishing a Connection Using WPS (page 11)
The quick WLAN connection WPS (WiFi Protected Setup) is
an automatic configuration process for wireless networks
and can be used with access points that are optimized for
WPS. AVM devices that support WPS include FRITZ!Box
Fon WLAN 7270/7240 and FRITZ!Box WLAN 3270.
Connecting Using the Online Wizard (page 13)
Connections to WLAN access points that do not support
WPS can be established in Windows Vista (32-bit) and
Windows XP (32-bit) using a Wizard.
FRITZ!WLAN Repeater N/G 10
Establishing a Connection Using WPS
Connecting Manually (page 13)
If the possibilities listed above are not available to you,
then establish the wireless connection manually.
Establishing a Connection Using WPS
Prerequisites To connect the FRITZ!WLAN Repeater with your WLAN ac-
cess point using WPS, the following prerequisites must be
met:
All of the devices involved must support WPS and
WPS must be enabled.
The access point must support the WPA/WPA2 en-
cryption standard.
The SSID (network name) of the access point must be
set to “visible” (announced).
The WPS function must be enabled.
Any active MAC address filter must be disabled tem-
porarily to establish the connection.
Establishing a
Connection
To connect the FRITZ!WLAN Repeater with a FRITZ!Box via
WPS, please keep the following instructions in mind:
1. Make sure that your FRITZ!Box has the latest firmware
installed.
2. Select the “push-button method (WPS-PBS)” setting
in the FRITZ!Box. This setting is located in the “Settings / Advanced Settings / WLAN / Security” menu
on the “WPS (WiFi Protected Setup) - Quick Connection” settings page.
3. Once you have connected the FRITZ!WLAN Repeater,
the display shows a circle, the WPS connection icon.
4. Press in the center of the circle.
FRITZ!WLAN Repeater N/G 11
Establishing a Connection Using WPS
5. Now press the WLAN button on the FRITZ!Box within
the next two minutes.
Hold the button down until the “WLAN” LED begins
flashing.
6. The FRITZ!WLAN Repeater and the FRITZ!Box now will
connect to each other automatically. The
FRITZ!WLAN Repeater automatically adopts the security settings of the FRITZ!Box and then displays the
WLAN status information (antenna icon) if the connection was established successfully.
7. Now you can operate the FRITZ!WLAN Repeater via a
web browser on your computer. Enter “fritz.repeater”
in the address field to open the user interface.
For devices from other manufacturers, consult the
documentation of your WLAN device to find out
whether it supports the WPS function.
FRITZ!WLAN Repeater N/G 12
hold down for
about 6 sec.
Connecting Using the Online Wizard
Connecting Using the Online Wizard
To configure the FRITZ!WLAN Repeater for the first time
without the WPS function, your WLAN adapter must support the WPA encryption method.
For WLAN connections to access points that do not support WPS, you can use an online Wizard. Perform the following steps:
1. Start a web browser on your computer.
2. Enter “www.avm.de/en/repeater” in the address
field.
3. Load and start the Configuration Wizard for the
FRITZ!WLAN Repeater on your computer and follow
the instructions on your screen.
Connecting Manually
To configure the FRITZ!WLAN Repeater for the first time
without the WPS function, your WLAN adapter must support the WPA encryption method.
Search, find and connect: These are the three steps to
take to connect the FRITZ!WLAN Repeater and the WLAN
access point manually.
1. Start the application of your WLAN client to search for
WLAN devices at your location.
2. Select the network named “FRITZ!WLAN
Repeater N/G”.
3. Enter the WPA/WPA2 key: “00000000” (8 zeros).
4. Start a web browser on your computer.
5. Enter “fritz.repeater” in the address field.
The FRITZ!WLAN Repeater Wizard then will guide you
through the remaining configuration steps.
FRITZ!WLAN Repeater N/G 13
Operating FRITZ!WLAN Repeater
4 Operating FRITZ!WLAN Repeater
The basic functions of the FRITZ!WLAN Repeater, for instance, turning
the audio function on and off, can be set directly on the device for maximum convenience. Advanced settings of the FRITZ!WLAN Repeater can
be configured using a web browser on your computer. Please follow the
following instructions.
4.1 Operation Using the Display of the FRITZ!WLAN Repeater
The following icons are shown on the display screen of the
FRITZ!WLAN Repeater for the basic settings:
Icon Description Icon Description
start query status
static: entry applied
flashing: confirm entry
WLAN on WLAN off
audio output enabled audio output disabled
radio enabled radio disabled
run WPS for the first
time
entry not applied
restart WPS
FRITZ!WLAN Repeater N/G 14
Operation Using a Web Browser on the Computer
Icon Description Icon Description
search run WLAN field strength
firmware update Factory Settings
display during night
service
display during hibernation
4.2 Operation Using a Web Browser on the Computer
You can operate the FRITZ!WLAN Repeater via a web
browser on your computer. This means you can make settings for the FRITZ!WLAN Repeater from any computer connected to the FRITZ!WLAN Repeater or the access point.
1. Start a web browser on your computer.
2. Enter “fritz.repeater” in the address field.
The user interface of the FRITZ!WLAN Repeater opens.
FRITZ!WLAN Repeater: user interface
Configure the settings desired and then click “Apply”.
If the web browser cannot display the user interface of the
FRITZ!WLAN Repeater, please note the information in the
section “Troubleshooting” from page 19.
FRITZ!WLAN Repeater N/G 15
Music in the Network with the FRITZ!WLAN Repeater
5 Music in the Network with the FRITZ!WLAN Repeater
With the FRITZ!WLAN Repeater you can listen to music files from your
computer on your stereo system or any FM radio.
The stereo system is connected to the FRITZ!WLAN Repeater by a cable
(digital/analog). An FM radio receives the music from the miniature FM
transmitter in the FRITZ!WLAN Repeater.
In order to configure your computer to play back music
files via the FRITZ!WLAN Repeater, first install the “Program for the Audio Bridge”. Please note the following:
5.1 Program for the Audio Bridge
Note the system requirements for this function: Microsoft
Windows Vista (32-bit) or Windows XP (32-bit) and an Internet connection.
1. Start a web browser on your computer.
2. Enter “fritz.repeater” in the address field.
3. Click “Audio Output”.
4. Click “Program for the Audio Bridge” and follow the
instructions.
5. Select the device for which the music playback is to
be enabled.
6. Confirm by clicking “Apply”.
7. Open the program for the audio bridge, FRITZ!Box Au-
dio and USB Remote Connection, and use the software to integrate the audio device into your wireless
network.
Your computer is now configured for playing back music
files via the FRITZ!WLAN Repeater. Connect the desired devices to the FRITZ!WLAN Repeater now.
FRITZ!WLAN Repeater N/G 16
Connecting a Stereo System
5.2 Connecting a Stereo System
Perform the following steps to connect a stereo system to
the FRITZ!WLAN Repeater:
1. Pick up an analog or a digital (optic) connecting ca-
ble (not included with delivery).
2. Connect your stereo system using the connection ca-
ble at one of the two sockets on your
FRITZ!WLAN Repeater.
This concludes the connection of the stereo system to the
FRITZ!WLAN Repeater.
Connecting a stereo system to the FRITZ!WLAN Repeater, digital (optic) or
analog (line-out)
5.3 Connecting a Radio
To connect an FM radio with the FRITZ!WLAN Repeater,
work through the following instructions:
1. Start a web browser on your computer.
2. Enter “fritz.repeater” in the address field.
3. Click “Audio Output”.
4. Enable the “FM” option.
FRITZ!WLAN Repeater N/G 17
Connecting a Radio
5. Click “Start Frequency Search” or use the arrow keys
to select a frequency.
6. Set the same frequency on your radio.
7. Confirm by clicking “Apply”.
This concludes the connection of the radio to the
FRITZ!WLAN Repeater.
Connecting a radio to the FRITZ!WLAN Repeater
FRITZ!WLAN Repeater N/G 18
Troubleshooting
6 Troubleshooting
Help for Errors
If you have problems with the FRITZ!WLAN Repeater, try to remedy them
yourself using the following information.
6.1 Checking the Power Supply
The display of the FRITZ!WLAN Repeater does not light up.
Possible Cause
The FRITZ!WLAN Repeater has no electricity.
Remedy
Make sure the FRITZ!WLAN Repeater is connected properly.
Make sure that the outlets the FRITZ!WLAN Repeater is
plugged into are live. Check this by plugging in a device you
know to be in working order, e.g. a reading lamp.
6.2 Restricted Access
The user interface of the FRITZ!WLAN Repeater cannot be
displayed in the web browser.
Possible Cause
The FRITZ!WLAN Repeater cannot be reached at the address
“fritz.repeater”.
Remedy
Open the network overview of your WLAN access point and
check the IP address of your FRITZ!WLAN Repeater. Take note of
the IP address given there, open a new window in your web
browser, and enter the IP address in the address field. Press
“Enter”. The user interface of the FRITZ!WLAN Repeater opens.
Other devices in the network cannot be accessed.
Possible Cause
The devices are not set to obtain their IP addresses automatically.
Remedy
FRITZ!WLAN Repeater N/G 19
The WLAN Connection Cannot Be Established
Check the TCP/IP properties. See the documentation of your access point for more information.
Possible Cause
The devices are not bound to TCP/IP.
Remedy
Check the network connection of the network adapter in the device in question. See the documentation of your access point for
more information.
Possible Cause
A firewall is running on the devices.
Remedy
Configure the firewall to allow access to the network.
6.3 The WLAN Connection Cannot Be Established
The WLAN connection between the FRITZ!WLAN Repeater and
the access point cannot be established.
Possible Cause
The FRITZ!WLAN Repeater is located beyond the range of the access point.
Remedy
Connect the FRITZ!WLAN Repeater at another location and restart it.
Possible Cause
The automatic connection with the access point via WPS failed
(see page 11).
Remedy
Restart the WPS procedure.
Possible Cause
WPS is disabled on the access point.
Remedy
Install the latest firmware on your WLAN access point and then
enable the WPS function in the user interface of your WLAN access point.
Possible Cause
FRITZ!WLAN Repeater N/G 20
The WLAN Connection Cannot Be Established
The encryption of your access point is set to WEP. WPS can only
be used with WPA/WPA2 encryption.
Remedy
Set up encryption with WPA/WPA2 in the user interface of your
access point.
Possible Cause
The WLAN function is disabled on your access point.
Remedy
Enable the WLAN function.
The WLAN connection between the FRITZ!WLAN Repeater and
the computer cannot be established.
Possible Cause
The WLAN adapter on the computer is not ready for operation.
Remedy
Some of the WLAN adapters installed in notebooks must be activated by flipping a switch on the notebook.
Possible Cause
The computer is located beyond the WLAN range of the
FRITZ!WLAN Repeater.
Remedy
Reduce the distance between your computer and the
FRITZ!WLAN Repeater.
Possible Cause
The FRITZ!WLAN Repeater and your access point are not connected to each other yet.
Remedy
Please note the information in the chapter “Connecting to an Access Point” on page 10.
Possible Cause
The encryption of the FRITZ!WLAN Repeater does not correspond
to the encryption of the WLAN adapter on the computer.
Remedy
FRITZ!WLAN Repeater N/G 21
Registration Not Possible
To configure the FRITZ!WLAN Repeater for the first time without
the WPS function, the WLAN adapter must be compatible with
the WPA/WPA2 encryption method. Check which kinds of encryption your WLAN adapter supports and set WPA/WPA2 as the
encryption method on your WLAN adapter.
Possible Cause
The FRITZ!WLAN Repeater and your WLAN adapter cannot be
connected to each other via WPS.
Remedy
The WPS function on the FRITZ!WLAN Repeater can only be used
to connect with a WLAN access point. Therefore you have to
check whether the network name and the encryption of the
FRITZ!WLAN Repeater and of your WLAN access point are identical (factory settings). Then start the WPS function on your WLAN
access point and switch to the reception area of the
FRITZ!WLAN Repeater.
Possible Cause
A WLAN radio network in the vicinity of the FRITZ!WLAN Repeater
of your access point is causing interference.
Remedy
Test a different radio channel. If possible, configure your access
point so that it automatically searches for a suitable channel.
Possible Cause
The MAC address filter of the access point is enabled and the
FRITZ!WLAN Repeater is not entered as an exception in the MAC
address list of the access point.
Remedy
Enter the MAC address of the repeater as an exception in the
MAC address filter of the access point.
6.4 Registration Not Possible
The FRITZ!WLAN Repeater cannot be registered at the access
point.
Possible Cause
On the access point the SSID is set to “hidden”.
Remedy
FRITZ!WLAN Repeater N/G 22
Microsoft WLAN Service (WZC) Is Not Supported
Set the SSID to “visible” (announced).
For registration with the WPS function the SSID must be visible.
After successful registration you can hide the SSID of the access
point again.
6.5 Microsoft WLAN Service (WZC) Is Not Supported
The WLAN connection to the FRITZ!WLAN Repeater cannot be
established using the Microsoft WLAN Service (WZC) in
Windows XP with Service Pack 2.
Possible Cause
The required Microsoft patch for WPA2 (IEEE 802.11i) may not
be not installed.
Remedy
Install the current patch for Microsoft Windows XP with Service
Pack 2 from the web page
http://support.microsoft.com/kb/91702/EN-US or install Ser-
vice Pack 3.
6.6 No Higher Data Rates Available
Higher data rates in accordance with the WLAN standard
IEEE 802.11n are not available on one of the WLAN clients
connected to the FRITZ!WLAN Repeater (e.g., your notebook).
Possible Cause
The connection between the FRITZ!WLAN Repeater and the
WLAN base station or between the FRITZ!WLAN Repeater and the
WLAN client is not encrypted using WPA2. The use of the
IEEE 802.11n standard—and thus the availability of higher
throughput rates—is possible only if the WLAN connection is secured using the WPA2 (AES-CCMP) security mechanism.
Remedy
Set the WLAN encryption of the FRITZ!WLAN Repeater and the
encryption of the WLAN base station to WPA2. It is also possible
to achieve the data throughput rates of the 802.11n standard if
all WLAN participants transmit wirelessly. Because of the security risk associated with an open wireless network, we expressly
advise against using this option!
FRITZ!WLAN Repeater N/G 23
Interference During Audio Output
6.7 Interference During Audio Output
The audio output is overmodulated or the music sounds very
distorted.
Possible Cause
Headphones are connected directly to the 3.5-mm stereo jack.
This stereo jack is a non-variable line-out jack.
Remedy
Connect the FRITZ!WLAN Repeater to the line-in input of your receiver (e.g. the amplifier), or use the miniature FM transmitter of
the FRITZ!WLAN Repeater to send the audio signals directly to
an FM radio.
The radio signal is subject to interference; the transmission has
static.
Possible Cause
The transmission frequency you set overlaps with adjacent
transmitters.
Remedy
Change the FM transmission frequency. Please note the information in the chapter “Connecting a Radio” from page 17.
Possible Cause
The FRITZ!WLAN Repeater is too far from the FM receiver, the signal is too weak.
Remedy
Reduce the distance between the FRITZ!WLAN Repeater and the
FM receiver.
FRITZ!WLAN Repeater N/G 24
Product Details
II PRODUCT DETAILS AND USEFUL INFORMATION
1Product Details
FRITZ!WLAN Repeater N/G
This chapter describes product details like technical data, the declaration of CE conformity and instructions for disposal of your FRITZ!WLAN
Repeater N/G.
1.1 Technical Specifications
Physical Specifications
Dimensions (w x h x d) approx. 101 x 76 x 76 mm
Supply voltage: 230 V / 50 Hz
Total power consumption: approx. 4.5 W
touch-sensitive LED matrix 7 x 15 mm
two integrated dual-band antennas
one optical S/PDIF jack
one 3.5-mm stereo jack socket (line-out)
FM transmitter 87.5 – 108 MHz (miniature FM
transmitter)
IEEE 802.11n (draft 2.0), compatible with
IEEE 802.11a/g/b
WEP 64/128, WPA, WPA2 (802.11i)
WLAN: 2.4 GHz max. 100 mW/5 GHz max. 200 mW
Transmission rate: up to 300 Mbit/s (gross); the user
data rate that can actually be achieved is somewhat
below the specified values
FM: max. 50 nW
Operating temperature: 0°C – +40°C
FRITZ!WLAN Repeater N/G 25
User Interface and Display
User Interface and Display
Settings and status messages via a web browser on a
Touch-sensitive LED matrix for the control, display of
1.2 Disposal
Electrical and electronic equipment must be disposed of
separately from household waste.
Labeling of electrical and electronic scrap
connected computer
connection, activity and status
In accordance with European regulations and the Electrical and Electronic Equipment Act (ElektroG), the
FRITZ!WLAN Repeater N/G, as well as all devices and electronic components contained in the FRITZ!WLAN
Repeater N/G package, may not be disposed with household waste. Please bring these to your local collection
points for disposal.
FRITZ!WLAN Repeater N/G 26
Declaration of CE Conformity
1.3 Declaration of CE Conformity
The manufacturer
herewith declares that the product
complies with the following directives:
1999/5/EC R&TTE Directive: Radio Equipment and Telecommuni-
2004/108/EC EMC Directive: Electromagnetic Compatibility
72/23/EEC Low Voltage Directive:Electrical equipment designed
The following norms were consulted to assess conformity:
EN 60950-1:2006
EN 301489-9 v1.4.1 (2007)
EN 301489-17 v1.2.1 (2002)
EN 301489-1 v1.5.1 (2004)
EN 55024/9.98 + A1/10.01 +
A2/01.03
The CE symbol confirms that this product conforms with the above mentioned norms and regulations.
AVM GmbH
Alt-Moabit 95
D-10559 Berlin
FRITZ!WLAN Repeater N/G
Type: WLAN repeater
cations Terminal Equipment
for use within certain voltage limits
EN 300 328 V1.6.1 (11/2004)
EN 301 893 V 1.4.1 (07/2007)
EN 301 357-1 v1.3.1
EN 301 357-3 v1.3.1
Berlin, 2008-10-24 Peter Faxel, Technical Director
Indication of Countries
The radio technology of this device is designed for use in all countries of the European Union and
in Switzerland, Norway and Iceland. In France only indoor operation is permitted.
FRITZ!WLAN Repeater N/G 27
Manufacturer’s Warranty
1.4 Manufacturer’s Warranty
We offer a manufacturer’s warranty of 5 years for this original product. The warranty period begins with the purchase date from the first end user. Compliance with the
warranty period can be proven by submission of the original invoice or comparable documents. This warranty does
not restrict your warranty rights based on the contract of
sale or other statutory rights.
We will remove defects to the product which are demonstrably due to faults in materials or manufacturing. Our
warranty does not cover defects which occur due to incorrect installation, improper use, non-observance of instructions in the user’s manual, normal wear and tear or defects in the environment of the system (third-party hardware or software). We may, at our discretion, repair or replace the defective product. Claims other than the right to
the removal of defects which is mentioned in these terms
of warranty are not constituted.
We guarantee that the software conforms with general
specifications, not, however, that the software meets your
individual requirements. Delivery costs will not be reimbursed. Products which have been replaced revert to our
ownership. Claims recognized under warranty entail neither an extension or recommencement of the warranty period. If we reject a warranty claim, this claim lapses no later than six months after being rejected by us.
This warranty shall be governed by German substantive
law, to the exclusion of the United Nations Convention on
Contracts for the International Sale of Goods (CISG).
© AVM GmbH 2008 – 2009. All rights reserved. Documentation release 09/2009
AVM Computersysteme
Vertr iebs Gmb H
Alt-Moabit 95
D 10559 Berlin
AVM in the Internet: www.avm.de/en
FRITZ!WLAN Repeater N/G 28
More about WLAN
2 More about WLAN
AVM and WLAN
WLAN (Wireless Local Area Network) is a radio technology that allows
networks access to the Internet to be provided without cable connections. This allows multiple users to share one wireless Internet connection.
2.1 Standards
The WLAN standards IEEE 802.11a, IEEE 802.11b,
IEEE 802.11g and IEEE 802.11n (on the basis of the preliminary draft 2.0 of the standard) and IEEE 802.11i were
developed by the Institute of Electrical and Electronic Engineers (IEEE).
The standards IEEE 802.11a, IEEE 802.11b, IEEE 802.11g
and IEEE 802.11n define the transmission rate within a
wireless LAN. The IEEE 802.11i standard is a security standard.
Standards for the Throughput Rate
Data Throughput The FRITZ!WLAN Repeater supports the IEEE 802.11n wire-
less standard and is downward compatible to 802.11a, b
and g networks.
The standards are intended for different frequency bands.
Standard Frequency Band Gross Data Throughput up to Net Data Throughput up to
802.11a 5 GHz 54 Mbit/s 54 Mbit/s
802.11b 2.4 GHz 11 Mbit/s 5 Mbit/s
802.11g 2.4 GHz 54 Mbit/s 25 Mbit/s
802.11n 2.4 / 5 GHz 300 Mbit/s 100 Mbit/s
The throughputs listed differentiate between gross and
net transmission rates. The net speed describes the transmission rate of the user data.
The standard used in a given WLAN depends on the settings of the WLAN access point.
29
Standards for the Throughput Rate
In order to communicate with each other, the
FRITZ!WLAN Repeater and the WLAN access point must
work in the same frequency band.
Range The range within a WLAN is highly dependent on the fol-
lowing factors:
the WLAN adapter used
the structural conditions
the amount of radio traffic on the same frequency
band. Other WLAN networks, microwave ovens or
Bluetooth transmitters (mobile telephones) may be
active.
where the FRITZ!WLAN Repeater is positioned
The FRITZ!WLAN Repeater provides for optimum extension of your wireless network when it is positioned halfway between your access point and the
devices for which the wireless network is to be extended. The device should also be operated in a location as central and free of obstruction as possible,
e.g. not in a closet, cabinet or below a radiator.
IEEE 802.11a This standard communicates with a maximum of
54 Mbit/s and works exclusively in the seldom used 5GHz range. This means it offers the opportunity to transmit
data relatively free of interference from external influences.
IEEE 802.11b With a maximum throughput rate of 11 Mbit/s, this is the
oldest standard for radio networks. Older WLAN access
points of the first generation can communicate with the
FRITZ!WLAN Repeater using 802.11b. However, if the
WLAN access point supports newer standards such as
802.11g, the latest standard should be used.
IEEE 802.11g This is currently the most common WLAN standard. It com-
municates with a maximum of 54 Mbit/s gross in the 2.4GHz frequency range (ISM) and guarantees broad compatibility with many WLAN devices.
30
The Standard for Security
IEEE 802.11n This standard allows for high throughput rates and rang-
es. The FRITZ!WLAN Repeater supports 802.11n in the 2.4GHz frequency band, or, if desired, also in the 5-GHz frequency band. Modulation processes and antenna techniques like MIMO (Multiple Input, Multiple Output) use
the entire frequency band available more effectively than
the older standards.
The use of the 802.11n standard—and thus the availability of higher throughput rates—is possible only if the
WLAN connection is secured using the WPA2 security
mechanism (AES-CCMP).
The Standard for Security
IEEE 802.11i The WPA2 security mechanism is defined in the
IEEE 802.11i standard. WPA2 is an extension of the familiar security mechanism WPA (Wi-Fi Protected Access).
The main feature of the extension of WPA to WPA2 is the
AES-CCMP encryption process.
Mechanism Encryption
WPA TKIP (Temporary Key Integrity Protocol)
WPA2 TKIP
AES-CCMP
based on the extremely secure AES (Advanced Encryption Standard) procedure.
CCM (Counter with CBC-MAC) defines how
the AES procedure is applied to WLAN
packets.
The FRITZ!WLAN Repeater supports the AES encryption
procedure as part of the WPA2 mechanism, and the TKIP
encryption procedure as part of the WPA mechanism. This
means that the FRITZ!WLAN Repeater can be used in combination with any WLAN adapters that also support WPA2
with AES or WPA with TKIP.
31
Security
2.2 Security
Security is of utmost importance within radio networks.
Radio signals can also be received outside of office or residential spaces and abused for criminal purposes.
Therefore it is important that no unauthorized users can
register in a WLAN to use its Internet access or shared network resources.
This is why the FRITZ!WLAN Repeater adopts the security
settings of your FRITZ!Box when it establishes a connection using WPS. For radio networks set up manually, these
security settings must be configured in the user interfaces
of the devices.
Encryption
The most important security setting is encryption. The
FRITZ!WLAN Repeater supports the security mechanisms
WEP (Wired Equivalent Privacy), WPA (Wi-Fi Protected Access) and WPA2 as follows:
As part of the WEP mechanism a static key is deter-
mined to serve for the encryption of the user data.
WLAN Radio Network Name (SSID)
In the factory settings of the FRITZ!WLAN Repeater a value
of “FRITZ!WLAN Repeater N/G” is preset as the default value of the SSID (Service Set Identifier). As soon as the initial configuration has been completed, the
FRITZ!WLAN Repeater automatically takes on the network
name of your WLAN base station. Depending on the WLAN
client used and how accessible it is, the network name of
the base station and the repeater will be listed once or
multiple times in the WLAN software. If you want to be
able to distinguish the FRITZ!WLAN Repeater from the
base station, you can change the network name of the
FRITZ!WLAN Repeater.
32
Frequency Ranges
2.3 Frequency Ranges
WLAN uses the frequency range around 2.4 GHz in the ISM
band or, alternatively, the frequency range at 5 GHz.
In order to communicate with each other, the
FRITZ!WLAN Repeater and the WLAN access point must
work in the same frequency band.
2.4-GHz Frequency
Band
In the 2.4-GHz frequency band WLAN works in the same
range as Bluetooth, microwave devices and various other
devices like some cordless telephones, radio-controlled
toys, garage-door openers and video bridges. This means
that interference may occur within WLANs operated in the
vicinity of such devices. Generally the only adverse effects
are to the transmission rate; aborted connections and data losses are rare.
WLAN in the 5-GHz frequency band is subject to less interference, as these radio frequencies are used much less often.
In the 2.4-GHz frequency range the European regulation
authorities have designated 13 channels for WLAN.
A channel can have a bandwidth of 20 MHz (throughput
up to 130 Mbit/s) or 40 MHz (throughput of up to
300 Mbit/s).
Channels located directly next to each other in the 2.4GHz band may overlap and result in mutual interference.
For instance, if several WLANs are operated close to each
other in the 2.4-GHz frequency range with a bandwidth of
20 MHz, a distance of at least five channels should be left
empty between each two channels used. This means that
if channel 1 is selected for one WLAN, the channels 6
through 13 can be selected for a second WLAN. This maintains the minimum distance between channels.
If your WLAN access point is equipped with an autochannel function, you can automatically have it search for a
WLAN channel in your frequency range that is subject to as
little interference as possible.
33
Frequency Ranges
5-GHz Frequency
Band
The FRITZ!WLAN Repeater can operate in the 5-GHz frequency band as an alternative. This frequency range is
used much less frequently than the most common 2.4GHz frequency range.
A prerequisite for use of the 5-GHz frequency band is that
all WLAN adapters in the network support this frequency
range in accordance with the IEEE 802.11a or
IEEE 8002.11n standard.
Bandwidth In both frequency ranges you can select between channel
bandwidths of 20 MHZ or 40 MHz (exception: channel 140
in the 5-GHz frequency band). The FRITZ!WLAN Repeater
initially attempts to select a channel with 40 MHz bandwidth (throughput up to 300 Mbit/s). If this is not possible
due to interference or channels already being used by other WLANs in the vicinity, the FRITZ!WLAN Repeater automatically switches over to a channel with 20 MHz bandwidth. Greater bandwidth provides for higher data
throughput:
Bandwidth (MHz) Maximum Data Throughput (Mbit/s)
20 130
40 300
Increasing bandwidths also increases the probability of
interference by wireless networks in the vicinity. Large
bandwidths reduce the frequency range available to other
wireless networks in the vicinity.
Allocation of the WLAN channels in the 2.4-GHz range
Channel Frequency (MHz) Channel Frequency (MHz)
1 2412 8 2447
2 2417 9 2452
3 2422 10 2457
4 2427 11 2462
5 2432 12 2467
6 2437 13 2472
7 2442
34
Frequency Ranges
Allocation of the WLAN channels in the 5-GHz range
Channel Frequency (GHz) Channel Frequency (GHz)
36 5.18 108 5.54
40 5.20 112 5.56
44 5.22 116 5.58
48 5.24 120 5.60
52 5.26 128 5.64
60 5.30 132 5.66
64 5.32 136 5.68
100 5.50 140 5.70 (20 MHz band-
width only)
104 5.52
35
Customer Service Guide
3 Customer Service Guide
Help on All Important Service Topics
AVM is there to help should any questions or problems arise. Here you
will find the important information you need, in the form of manuals,
updates and support.
Microsoft Updates In many cases problems which arise during operation can
be resolved by installing the current Microsoft Service
Pack or other Microsoft updates.
The current service packs and updates can be obtained
free of charge from Microsoft at the address:
www.microsoft.com
3.1 Documentation
To take advantage of all commands and features of your
FRITZ!WLAN Repeater N/G, consult the following documentation:
Help In the FRITZ!WLAN Repeater user interface you can open
the detailed Help by clicking the “Help” buttons.
Manual The manual can be downloaded from the Internet at the
following address:
www.avm.de/en/service/manuals
From the selection list, select the product group
“FRITZ!WLAN Repeater” and then “FRITZ!WLAN
Repeater N/G”. Then click the PDF icon.
The current Adobe Acrobat Reader for reading PDF documents can be downloaded from the Internet free of charge
at www.adobe.com
FRITZ!WLAN Repeater N/G 36
.
Information in the Internet
3.2 Information in the Internet
On its web site AVM presents comprehensive information
on your AVM products as well as new product announcements and new product versions.
Frequently Asked Questions (FAQs)
We would like to make our products as easy to use as possible. If you still have problems, sometimes a little tip is
all you need to resolve them. That is why we present you
with a selection of frequently asked questions.
The FAQs can be viewed at the following address:
www.avm.de/en/service/FAQs
3.3 Updates and Software
AVM provides firmware updates and various software for
the FRITZ!WLAN Repeater N/G for free downloading over
the Internet.
Firmware Use the “Firmware Update” Wizard on the
FRITZ!WLAN Repeater user interface to perform an update
of your firmware.
In the “Wizards / Firmware Update” menu you can download the firmware from the Internet and perform the update with a single mouse click.
FTP Experienced users can also download updates from the
AVM FTP server. Click the “FTP Server” link in the download area, or enter the following address:
ftp.avm.de
FRITZ!WLAN Repeater N/G 37
Support from the Service Team
3.4 Support from the Service Team
Should problems with your FRITZ!WLAN Repeater arise, we
recommend taking the following steps:
1. If you have questions about starting operation of
your FRITZ!WLAN Repeater, please consult the chapter “Starting Operation” from page 9.
2. Please see the information in the section “Product
Details” from page 25.
3. If you have any problems, seek first aid by consulting
the chapter “Troubleshooting” from page 19.
This chapter also presents useful tips on problems
with establishing connections.
4. The next step is to consult the FAQs in the Internet:
www.avm.de/en/service/FAQs
This site contains answers to questions our customers have frequently asked our Support team.
5. If you do not find the answer you need in the FAQs,
AVM Support will assist you. The support desk can be
reached by e-mail or by fax.
Please take advantage of the information sources
described above before contacting AVM support.
Support by E-mail
You can send us an English-language e-mail request at
any time using the “Service” area of our web site. The
“Service” area can be reached at:
www.avm.de/en/service
Select the product for which you need support from the
“Support” area. Click the “Mail Form” link to open the email form. Fill out the form and send it to AVM support by
clicking the “Send” button. Our Support team will respond
by e-mail as quickly as possible.
FRITZ!WLAN Repeater N/G 38
Support by Fax
Support by Fax
If necessary, you can reach AVM Support at the fax number:
+49 (0)30 / 39 97 62 66
The following information should be included in English in
your fax to the Support team:
Your name and address.
An e-mail address or fax number at which you can be
reached.
The serial number of the FRITZ!WLAN Repeater
The serial number is printed on the sticker attached
to the base of the device. Support staff will always
check this number to ensure that you are a registered
user.
Which operating system are you using (e.g.,
Windows Vista or Windows XP)?
At what step of the installation or in which applica-
tion does an error occur or an error message appear?
What is the exact wording of the message?
Which firmware does the FRITZ!WLAN Repeater use?
The firmware version is displayed on the “Overview”
page of the FRITZ!WLAN Repeater user interface.
Once you have gathered this information, please fax it to
AVM Support. The Support team will assist you in resolving your problem.
FRITZ!WLAN Repeater N/G 39
Glossary
Glossary
ADSL abbreviation for Asymmetric Digital Subscriber Line
designates a fast kind of file transfer that works with standard copper cables and transports signals in both directions at different speeds (upstream at 640 Kbit/s and
downstream at up to 9 Mbit/s).
ADSL2 abbreviation for Asymmetric Digital Subscriber Line 2
ADSL2 (G.992.3) is a further development of the ADSL
norm G.992.1/G.992.2).
ADSL2 offers range much greater than did the first ADSL
generation, and is significantly more robust than ADSL, as
it can simply disable single carrier frequencies when they
produce interference. This feature allows ADSL2 to prevent synchronization losses.
With a throughput rate of up to 12 Mbit/s downstream,
ADSL2 offers considerably greater bandwidth than ADSL.
ADSL2 is completely downward compatible, meaning that
terminal equipment compliant with ADSL can also be operated on ADSL2 lines, although they cannot exploit the
advantages of ADSL2.
ADSL2+ abbreviation for extended bandwidth Asymmetric Digital
Subscriber Line 2
ADSL2+ (G.992.5) is a further development of the ADSL
norm (G.992.1/ G.992.2).
ADSL2+ offers a doubled frequency range used for downstream transmission, and thus double the maximum
bandwidth achievable for downstream to 24 Mbit/s.
ADSL2+ is completely downward compatible, meaning
that terminal equipment compliant with ADSL and ADSL2
can also be operated on ADSL2+ lines, although they cannot exploit the advantages of ADSL2+.
FRITZ!WLAN Repeater N/G 40
Glossary
Alias Alias means different, else and also known as. An alias is
often a short, catchy substitute for a long, complicated
string of characters, for example, the actual name of the
user J.Smith@my-internetprovider.com in place of the
string 030123456@my-internetprovider.com. Here the
name J.Smith functions as an alias for 030123456.
Context Menu The context menu is a menu that is normally not visible.
The context menu opens only when you click with the right
mouse button on a button, a graphic or a word. Depending
on where you clicked, the context menu contains only the
most common menu commands for the given object.
If you are using an Apple computer, push the “Ctrl” button
while clicking.
Default Gateway see gateway
DHCP abbreviation for Dynamic Host Configuration Protocol
DHCP is a protocol for the dynamic negotiation of the operating parameters for the TCP/IP protocol (TCP is a transport protocol based on the Internet protocol).
The computers of a local IP network (DHCP clients) access
the DHCP server as part of their operating systems’ start
procedure.
The central administration of the TCP/IP operation parameters makes it possible to avoid address conflicts caused
by IP addresses accidentally assigned more than once.
DHCP Server The DHCP server assigns each client an IP address that is
has not yet been assigned at the present time. The DHCP
server also informs the client of the IP addresses of the
DNS server to be used and of the default gateway. In assigning the IP addresses the DHCP server selects from a
prescribed pool of IP addresses.
DNS abbreviation for Domain Name System
Domain Name Service takes care of determining the IP address for a given domain name. This Domain Name Service runs on every computer. It accepts the domain name
FRITZ!WLAN Repeater N/G 41
Glossary
entered by a user and inquires about the corresponding IP
address at a DNS server known to the service. If a DNS
server cannot answer the inquiry itself, it can inquire
about the IP address (DNS resolution) at other DNS servers.
If the Domain Name Service receives negative information
from the DNS server (domain name not known), it can
send inquiries to other DNS servers it knows or return a
corresponding error message to the user. If it receives the
desired IP address instead, the application can use the IP
address to retrieve the destination desired by the user.
This hierarchical system of DNS servers is known as the
Domain Name System. The addresses of the DNS servers
at which the Domain Name Service is to inquire by default
generally are handed over to the computer by the Internet
Service Provider automatically whenever a connection to
the Internet is established. In local networks addresses
can also be assigned via DHCP. Otherwise they must be
entered manually in the TCP/IP settings of the computer
by the user or the system administrator.
DSL Modem A DSL modem connects a computer to the Internet via the
DSL line. In contrast to the analog modem, a connection
via the DSL modem does not mean that the telephone line
is busy.
DSL Router A combination of a DSL modem and a router is called a
DSL router.
Dynamic DNS abbreviation for Dynamic Domain Name System
Dynamic DNS is a service which allows a computer always
to be reached under the same domain name despite constantly changing IP addresses. This means that even private users have an economical way of placing their own
Internet offers on their computer at home.
It works by transmitting the current IP address to a special
DDNS server each time the IP address changes. Except for
the few seconds between the cancellation of the old IP ad-
FRITZ!WLAN Repeater N/G 42
Glossary
dress and the notification of the new IP address, the computer can always be reached at the selected domain
name.
Dynamic IP
Address
A dynamic IP address is an IP address valid only for the
duration of one Internet or network session.
Every computer participating in the Internet must have a
uniquely assigned public IP address. Since only a limited
number of such IP addresses is available, they must be
used sparingly. That is why most of the Internet participants who dial in to the Internet receive a dynamic IP address. They are called dynamic because every participant
receives a new public address that has not been assigned
yet each time she or he dials in to the Internet.
By contrast, dynamic addresses are usually used in local
IP networks because they are easy to handle, and because
using them avoids incorrect IP address entries or unintentional double assignments. The DHCP service is responsible for assigning unique dynamic IP addresses.
FAQ abbreviation for Frequently Asked Questions
FAQs are collections with answers to frequently asked
questions on a certain subject area.
Fixed IP address Fixed IP addresses are IP addresses which are permanent-
ly assigned to a computer or another device like a network
printer.
Assigning fixed IP addresses makes sense in cases where
a local network has a sufficiently large pool of IP addresses available, or when a computer is always supposed to
be accessible at a certain address (such as a web server or
e-mail server).
Firewall A firewall protects a computer or local network against at-
tacks from the Internet.
Most firewalls work with packet filters, which merely
check the IP addresses and port numbers of incoming and
outgoing data packets and filter the packets according to
prescribed rules.
FRITZ!WLAN Repeater N/G 43
Glossary
Some firewalls also integrate additional concepts like IP
masquerading and NAT to decouple data traffic by distinguishing strictly between the internal and external network.
Especially effective firewalls go even further, analyzing
and evaluating the contents of the packets and filtering
them according to prescribed rules. Such techniques may
also include a Stateful Packet Inspection Firewall, for instance.
Firmware The firmware is saved in programmable components with-
in a device. Through the possibility of updating the firmware by computer at any time, manufacturers enjoy great
flexibility in reacting to the demands of the operational
environment, integrating new functions requested by customers, and eliminating errors discovered after production.
FTP abbreviation for File Transfer Protocol
The File Transfer Protocol allows files to be exchanged between two computers operating in the Internet. Data exchange takes place via an FTP server and what is known as
an FTP client. The more convenient FTP clients are available as stand-alone software or are components of some
ISDN data transfer software; simple FTP clients are now included in many web browsers.
Gateway Gateway is a general term designating an interface be-
tween two computer networks. Such a network interface
can be realized using a router or a bridge, for instance.
If a computer wants to transfer data packets to a computer
in another network, it must first transmit the packet to the
gateway. To do this, the computer must know the address
of the gateway.
If all packets that cannot be delivered in a local network
always are to be transmitted to their given recipients via
the same gateway, for this purpose the address of the
gateway must be saved as the default gateway in the network settings of the computer.
FRITZ!WLAN Repeater N/G 44
Glossary
Such a default gateway for the computer is negotiated automatically by the operating system or the dialing software whenever an ISDN-Controller or DSL-Controller establishes a connection to the Internet. If a router is used for
the shared Internet access in a local network, the IP address of the router must be entered as the default gateway
in the TCP/IP settings of each computer that wishes to use
the Internet connection. If the TCP/IP setting is configured
by means of a DHCP server, there is no need to enter the
gateway address manually.
IP abbreviation for Internet Protocol
The IP Internet Protocol is the most important basic protocol for the control of data exchange in local networks and
in the Internet. The Internet protocol works without a connection; in other words, data packets are transmitted from
the sender to the recipient without previous consultation.
The addresses of the recipient and the sender in the data
packets are given as IP addresses.
IP Address abbreviation for Internet Protocol address
In IP-based networks, for instance in the Internet and local
networks, all connected devices are addressed via their IP
addresses. So that data packets are sure to be delivered
to the right address, each IP address may be assigned only once within the Internet or a local IP network.
The IP address consists of four three-digit groups of numbers (for instance, 192.168.178.247). Each group of numbers can assume values between 000 and 255.
Every IP address contains two components: the network
address and the host address. These two components can
be read out of an IP address only if the subnet mask is also specified.
IP addresses can be public or private, and also fixed or assigned dynamically. See the corresponding entries in the
Glossary for more information.
FRITZ!WLAN Repeater N/G 45
Glossary
IP Addressing Addressing is one of the main functions of the Internet
Protocol (IP). Internet addresses can be written in decimal, octal or hexadecimal notation. The
FRITZ!WLAN Repeater uses “dotted-decimal” notation:
The four bytes of an address are represented by decimal
numbers separated by dots. The total volume of Internet
addresses, the address space, is separated into classes
(A, B, C, D, and E). The full set of IP addresses, called the
address space, is grouped into address classes designated as A, B, C, D and E. Only the first three of these five address classes are actually used. These classes can be described as follows:
Classes Properties Network address
Decimal value
Class A address
Class B address
Class C address
Few networks, many hubs 0-127
Intermediate distribution of
networks and hubs
Many networks, few hubs 192-223
128-191
Properties of IP Address Classes
Every IP address consists of two parts: the network address and the host address. The sizes of the network address and the host address are variable, and determined
by the first four bits (of the first byte) of the IP address.
IP
By means of IP masquerading a computer or LAN can be
Masquerading
protected from unauthorized connection request from the
Internet. Masquerading works by converting the IP addresses used in a network to one public IP address. From
the outside it appears that all requests are sent from a single computer.
IP Network A network in which data exchange takes place on the ba-
sis of the Internet Protocol is called an IP network.
FRITZ!WLAN Repeater N/G 46
Glossary
Public IP
Address
A public IP address is an IP address valid in the Internet.
Every computer or router participating in the Internet must
have a uniquely assigned public IP address. This address
is usually negotiated dynamically with the Internet Service
Provider when a connection to the Internet is dialed. The
Internet Service Provider assigns the negotiated IP address to the computer or router for the duration of an Internet session.
Private IP
Address
Private IP addresses are used for computers and other
network devices within local IP networks.
Since many local IP networks are not connected to the Internet except via single computers or routers (gateway),
certain address ranges are excluded from the publicly
available IP addresses so that they are available for assignment in local IP networks. An IP address may only be
assigned once within the local network. A private IP address may exist in any number of other local networks.
Subnetwork A local IP network can consist of one subnetwork or be di-
vided into multiple subnetworks. The division into subnetworks is performed when the local IP network is configured. The subnetworks of a local IP network are also IP
networks.
Subnet Mask The subnet mask indicates which part of an IP address is
the network address and which the address of the computer. The network address defines what is called the subnet.
Example 1
IP address: 192.168.178.247
Subnet mask: 255.255.255.0
The assignment of the first three groups of numerals in the subnet mask indicates that the first three groups of numerals in the
IP address define the network. The following addresses result:
FRITZ!WLAN Repeater N/G 47
Glossary
Example 1
Network address of the subnet: 192.168.178.0
Address of the computer in the
subnet:
IP address pool in the subnet: 192.168.178.0 -
Example 2
IP address: 192.168.178.247
Subnet mask: 255.255.0.0
The assignment of the first two groups of numerals in the subnet mask indicates that the first two groups of numerals in the
IP address define the network. The following addresses result:
Network address of the subnet: 192.168.0.0
Address of the computer in the
subnet:
IP address pool in the subnet: 192.168.0.0 -
192.168.178.247
192.168.178.255
The IP addresses
192.168.178.0 and
192.168.178.255 are reserved. This means that the
addresses from
192.168.178.1 to
192.168.178.254 are available for assignment to the
computers. Therefore a maximum of 254 computers can be
included in the subnetwork
192.168.178.247
192.168.255.255
That’s 65,536 IP addresses.
The IP addresses 192.168.0.0
and 192.168.255.255 are reserved. This means that the
addresses from 192.168.0.1 to
192.168.255.254 are available for assignment to the
computers.
FRITZ!WLAN Repeater N/G 48
Glossary
TCP/IP abbreviation for Transmission Control Protocol / Internet
Protocol
TCP/IP is the “language” of the Internet. TCP/IP is used to
refer to a suite of protocols used for data communication
over the Internet. TCP and IP are the network and transport
protocols underlying most Internet services, including file
transfer (FTP) and e-mail communication (SMTP). TCP/IP is
available for practically all computer systems. TCP/IP thus
offers the advantage of trouble-free communication between otherwise incompatible networks and systems.
Update A more recent version of software or firmware is called an
update. Updates are often free of charge, resolve minor
programming errors, and sometimes also offer new functions.
Upload This term designates the procedure of transmitting files
from one’s own computer to another computer in the Internet.
UPnP abbreviation for Universal Plug and Play (UPnP)
UPnP is an extension of the Microsoft Plug & Play standard
that allows devices to network globally and to exchange
services—without a central server or computer.
UPnP allows devices from all kinds of manufacturers (stereo systems, routers, printers, house controls) to be controlled via an IP-based network, with or without central
control through a gateway. It is based on a number of
standardized network protocols and data formats. Expressed simplistically, devices can communicate with
each other using UPnP to exchange information.
Today the UPnP forum specifies the UPnP standard and
certifies devices that are compliant with the standard.
FRITZ!WLAN Repeater N/G 49
Index
Index
A
access point
connecting to . . . . . . . . . . . . 10, 11
audio bridge. . . . . . . . . . . . . . . . . . . . 16
B
basic settings. . . . . . . . . . . . . . . . . . . . 9
C
connecting . . . . . . . . . . . . . . . . . . . . . . 9
electrical power . . . . . . . . . . . . . . . 9
manually. . . . . . . . . . . . . . . . . . . . 13
using the Online Wizard . . . . . . . 13
using WPS . . . . . . . . . . . . . . . . . . 11
contact for help . . . . . . . . . . . . . . . . . 38
copyright . . . . . . . . . . . . . . . . . . . . . . . 2
customer service . . . . . . . . . . . . . . . . 36
D
declaration of CE Conformity. . . . . . . 27
declaration of conformity . . . . . . . . . 27
display . . . . . . . . . . . . . . . . . . . . . .9
display,operation via. . . . . . . . . . . . . 14
disposal . . . . . . . . . . . . . . . . . . . . . . . 26
electrical equipment . . . . . . . . . . 26
electronic equipment . . . . . . . . . 26
documentation. . . . . . . . . . . . . . . . . . 36
, 26
FM radio . . . . . . . . . . . . . . . . . . . 16
frequency ranges
WLAN. . . . . . . . . . . . . . . . . . . . . . . 33
FRITZ!Box
connecting automatically . . . . . . 12
, 17
H
hazards . . . . . . . . . . . . . . . . . . . . . . . . . 6
help
customer service . . . . . . . . . . . . . 36
highlighting . . . . . . . . . . . . . . . . . . . . . 5
I
imprint . . . . . . . . . . . . . . . . . . . . . . . . . 2
information in the Internet. . . . . . . . .37
FAQs . . . . . . . . . . . . . . . . . . . . . . . 37
installation . . . . . . . . . . . . . . . . . . . . . . 9
requirements . . . . . . . . . . . . . . . . . 8
instructions
security . . . . . . . . . . . . . . . . . . . . . . 6
L
legal notice . . . . . . . . . . . . . . . . . . . . . . 2
M
manufacturer’s warranty . . . . . . . . . . 28
music playback. . . . . . . . . . . . . . . . . .16
E
electricity
connecting to . . . . . . . . . . . . . . . . . 9
encryption . . . . . . . . . . . . . . . . . . . . . 32
error search . . . . . . . . . . . . . . . . . . . . 19
F
factory settings
network name . . . . . . . . . . . . . . . 32
FAQs . . . . . . . . . . . . . . . . . . . . . . . . . . 37
fax number of support desk . . . . . . . 39
features . . . . . . . . . . . . . . . . . . . . . . . . 7
FRITZ!WLAN Repeater N/G 50
N
network name. . . . . . . . . . . . . . . . . . . 32
new firmware . . . . . . . . . . . . . . . . . . . 37
notice
legal . . . . . . . . . . . . . . . . . . . . . . . . 2
O
operation . . . . . . . . . . . . . . . . . . 14, 15
P
package contents . . . . . . . . . . . . . . . . . 8
Index
physical properties . . . . . . . . . . . . . . 25
playing back music from the computer16
product details. . . . . . . . . . . . . . . . . . 25
product overview . . . . . . . . . . . . . . . . . 7
program for the audio bridge . . . . . . 16
R
radio . . . . . . . . . . . . . . . . . . . . . . . . . . 17
recycling . . . . . . . . . . . . . . . . . . . . . . . 26
requirements
connecting using WPS. . . . . . . . . 11
S
security
operating instructions . . . . . . . . . . 6
serial number . . . . . . . . . . . . . . . . . . . 39
service team. . . . . . . . . . . . . . . . . . . . 38
sources of interference . . . . . . . . . . . . 6
SSID . . . . . . . . . . . . . . . . . . . . . . . . . . 32
stereo system. . . . . . . . . . . . . . . 16
support . . . . . . . . . . . . . . . . . . . . . . . . 38
by e-mail. . . . . . . . . . . . . . . . . . . . 38
information in the Internet . . . . . 37
service team. . . . . . . . . . . . . . . . . 38
support by fax . . . . . . . . . . . . . . . 39
symbols . . . . . . . . . . . . . . . . . . . . . . . . 5
, 17
frequency ranges . . . . . . . . . . . . . 33
standards . . . . . . . . . . . . . . . . . . . 29
WPS push button method . . . . . . . . . 11
T
technical specifications . . . . . . . . . . 25
physical properties . . . . . . . . . . . 25
touch points . . . . . . . . . . . . . . . . . . . . . 9
troubleshooting . . . . . . . . . . . . . . . . . 19
U
updates . . . . . . . . . . . . . . . . . . . . . . . 37
UPnP . . . . . . . . . . . . . . . . . . . . . . . . . . 49
W
warranty . . . . . . . . . . . . . . . . . . . . . . . 28
web browser,operation via . . . . . . . . 15
WEP security mechanism . . . . . . . . . 32
WLAN . . . . . . . . . . . . . . . . . . . . . . . . . 29
encryption . . . . . . . . . . . . . . . . . . 32
FRITZ!WLAN Repeater N/G 51
Loading...
