Averatec ALL-IN-ONE PC, ALL-IN-ONE User Manual

i

Before You Start

Regulations Information

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures :

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio TV technician for help.

Note

✓ The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority

to operate the equipment.

✓Shield interface cables and AC power cord, if any must be used in order to comply with the emission limits.

ii

Before You Start

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions :

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

iii

Before You Start

Optical Device Drive Notice

Battery Notice

Ethernet Notice

This equipment is indoor use and all the communication wirings are limited to inside of the building.

CAUTION

✓This appliance contains a laser system and is classified as a “CLASS 1 LASER PRODUCT.” To use this model properly, read the

instruction manual carefully and keep this manual for your future reference. In case of any trouble with this model, please
contact your nearest “AUTHORIZED service station.” To prevent direct exposure to the laser beam, do not try to open the
enclosure.

CAUTION

✓RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE

INSTRUCTIONS.

iv

Before You Start

Macrovision Notice

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property
rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other
limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Safety Instructions

1. Read the safety instructions carefully and thoroughly.

2. Save this User Guide for possible use later.

3. Keep this equipment away from humidity and high temperature.

4. Lay this equipment on a stable surface before setting it up.

5. The openings on the enclosure are used for air convection and to prevent the equipment from overheating. Do not
cover the openings.

6. Make sure that the power voltage is within its safety range and has been adjusted properly to the value of 100~240V
before connecting the equipment to the power inlet.

7. Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord.

8. Always unplug the power cord before inserting any add-on card or module.

9. All cautions and warnings on the equipment should be noted.

v

Before You Start

10. If any of the following situations arises, get the equipment checked by a service personnel:

• The power cord or plug is damaged.

• Liquid has penetrated into the equipment.

• The equipment has been exposed to moisture.

• The equipment has not worked well or you can not get it work according to Users Manual.

• The equipment was dropped and damaged.

• The equipment has obvious signs of breakage.

11. Never pour any liquid into the opening that could damage the equipment or cause an electrical shock.

12. Do not leave the equipment in an unconditioned environment with a storage temperature of 60°C (140°F) or above,
which may damage the equipment.

13. To prevent explosion caused by improper battery replacement, use the same or equivalent type of battery
recommended by the manufacturer only.

vi

Before You Start

WEEE Statement

vii

Before You Start

Before You Read

The information in this user’s guide is subject to change without notice.

TriGem Computer, Inc. shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental
or consequential damages resulting from the furnishing, performance, or use of this material.

AVERATEC is a trademark or registered trademark of TriGem Computer, Inc. in the United States and/or other countries.
All other product and brand names are trademarks of their respective owners.

©2008 TriGem Computer, Inc. All rights reserved.

Note

✓ Depending on the model, your computer’s components may vary and look slightly different than those pictured.

viii

Before You Start

Table of Content

Before You Start

Regulations Information i
Optical Device Drive Notice iii
Battery Notice iii
Ethernet Notice iii
Macrovision Notice iv
Safety Instructions iv
WEEE Statement vi
Before You Read vii
Table of Content viii

Chapter 1 Introduction

What is the Averatec All-In-One PC? 02

Chapter 2 Getting Started

Turning On and Off 05
Adjusting the Brightness of the Monitor 07
Adjusting the Speaker Volume 08
Connecting External Speakers 09
Using the Optical Drive 11
Connecting to the Internet 13
Using Your Webcam 14
Using the Wireless LAN 17
Using the Multi-Card Reader 19
Using the Internal Microphone 20

Chapter 3 System BIOS SETUP

Entering into the System BIOS Setup 22
BIOS Setup Menu 23

Chapter 4 Expansion of the system

Replacing the Main Memory 28
Using the Optional VESA Mount Kit 35

1

Chapter 1 Introduction

Introduction

Chapter

1

2

Chapter 1 Introduction

What is the Averatec All-In-One PC?

The Averatec All-In-One PC is an all inclusive desktop PC that is designed for quick installation and easy use without taking
up much desk space.

Features

Integrated PC and LCD monitor

The Averatec All-In-One PC is equipped with a 18.4" wide LCD monitor and fully functional PC. Nothing else is needed. The
All-In-One PC is designed to be a complete plug-and-play system.

Less cabling and more portability

The Averatec All-In-One PC eliminates all those messy cables, enhances system portability and results in less clutter.

Everything’s included!

The Averatec All-In-One PC includes everything necessary to be immediately productive. An industry-leading 18.4" wide
screen LCD monitor coupled with an advanced Intel® Atom processor to handle all your entertainment and productivity
applications. Additionally, the Averatec All-In-One PC comes with the following features:

• A large hard drive for all your storage requirements.

• A web cam for video chatting, recording and picture taking.

Slim CD drive

With a slim CD drive built-in, you can install all your CD or DVD based applications and also watch all your favorite DVD
movies.

3

Chapter 1 Introduction

Designed for the Internet

The Averatec All-In-One PC is designed for the Internet, so you can send emails or instant messages, talk to friends over
VoIP or just surf the web with ease.

Efficient computing

The Averatec All-In-One PC is designed to support all your basic computing needs and then some. With this PC, you can
enjoy the most popular tasks such as word processing, internet browsing and basic gaming.

Improved power management

The Averatec All-In-One PC, with it’s Intel Atom based CPU and efficient design, requires very low-power consumption.

Internal microphone

With the built-in microphone, you can fully enjoy chatting with your friends and family members via one of many on-line
communication applications such as Microsoft MSN or Yahoo’s Messenger.

4

Chapter 2 Getting Started

Getting Started

Chapter

2

5

Chapter 2 Getting Started

5

Chapter 2 Getting Started

Turning On and Off

Turning on

Press the power button on the front side of the PC.

Turning off

Case 1

Click Start to turn off computer.

1. Click Start and select Turn off computer. Turn off computer screen displays.

2. Click Turn Off.

6

Chapter 2 Getting Started

Case 2

Press the power button on the front side of the PC.
After closing all programs,the PC will be turned off. If the system is operating abnormally, you can reboot the PC
by holding down the power button until the PC turns off. Then press the power button again to boot back up.

Case 3

Power saving mode.
Saves your session and puts the computer in a lower-power state so that you can quickly resume working.
Click Stand By.
