Avenview SW-HDSDI-8X2 User Manual

www.avenview.com

1

8 Port HD/SD-SDI Video Switch

Models
SW-HDSDI-8X2

with 2 Port Splitter

User’s Guide

© 2008 Avenview Inc. All rights reserved.

The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations
or warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to
specifications and product descriptions at any time without notice. No license, whether express, implied, or otherwise, to any intellectual
property rights is granted by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes
no liability whatsoever, and disclaims any express or implied warranty, relating to its products including, but not limited to, the implied
warranty of merchantability, fitness for a particular purpose, or infringement of any intellectual property right.

Reproduction of this manual, or parts thereof, in any form, without the express written permission of Avenview Inc. is strictly
prohibited.

www.avenview.com

2

Table of Contents

Section 1: Getting Started ...................................................................................................................... 3

1.1 Important Safeguards ............................................................................................................ 3

1.2 Safety Instructions ................................................................................................................. 3

1.3 Regulatory Notices Federal Communications Commission (FCC) ......................................... 4

1.4 Introduction ........................................................................................................................... 4

1.5 Features ................................................................................................................................. 5

1.6 Package Contents ................................................................................................................... 5

1.7 Before Installation.................................................................................................................. 5

1.8 Panel Description ................................................................................................................... 6

1.9 IR Remote Control .................................................................................................................. 7

Section 2: Installation ............................................................................................................................. 8

Section 3: Specifications ......................................................................................................................... 9

www.avenview.com

3

Section 1: Getting Started

1.1 Important Safeguards

Please read all of these instructions carefully before you use the device. Save this manual for future

reference.

What the warranty does not cover

Any product, on which the serial number has been defaced, modified or removed.



Damage, deterioration or malfunction resulting from:



Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized



product modification, or failure to follow instructions supplied with the product.
Repair or attempted repair by anyone not authorized by us.



Any damage of the product due to shipment.



Removal or installation of the product.



Causes external to the product, such as electric power fluctuation or failure.



Use of supplies or parts not meeting our specifications.



Normal wear and tear.



Any other causes which does not relate to a product defect.



 Removal, installation, and set-up service charges.

1.2 Safety Instructions

The Avenview SW-HDSDI-8X2 HD/SD-SDI Matrix Switch has been tested for conformance to safety regulations
and requirements, and has been certified for international use. However, like all electronic equipments, the
SW-HDSDI-8X2 should be used with care. Please read and follow the safety instructions to protect yourself
from possible injury and to minimize the risk of damage to the unit.

Do not dismantle the housing or modify the module.



Dismantling the housing or modifying the module may result in electrical shock or burn.



Refer all servicing to qualified service personnel.



Do not attempt to service this product yourself as opening or removing housing may expose you to



dangerous voltage or other hazards

 Keep the module away from liquids.
 Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid

falls or spills on to the housing, unplug the module immediately.

 Have the module checked by a qualified service engineer before using it again.
 Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before

cleaning.
