Avenview RKVM-17-Dslide User Manual

www.avenview.com

1

RKVM Dslide Series

Models
RKVM-17-Dslide

- 1U Dual Slide

- 17” Screen Size

User’s Guide

© 2007 Avenview Inc. All rights reserved.

The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations
or warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to
specifications and product descriptions at any time without notice. No license, whether express, implied, or otherwise, to any intellectual
property rights is granted by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes
no liability whatsoever, and disclaims any express or implied warranty, relating to its products including, but not limited to, the implied
warranty of merchantability, fitness for a particular purpose, or infringement of any intellectual property right.

Reproduction of this manual, or parts thereof, in any form, without the express written permission of Avenview Inc. is strictly
prohibited.

www.avenview.com

2

Table of Contents

Section 1 – Getting Started .................................................................................................................... 4

1.1 Important Safegaurds ............................................................................................................ 4

1.2 Safety Instructions ................................................................................................................. 5

1.3 Regulatory Notices Federal Communications Commission (FCC) ......................................... 5

1.4 Package Contents ................................................................................................................... 6

1.5 Before Installation.................................................................................................................. 7

1.6 Unpacking .............................................................................................................................. 7

1.7 Optional Accessories .............................................................................................................. 7

1.8 Peripheral Products ............................................................................................................... 8

1.9 Structure Diagram .................................................................................................................. 8

1.10 Installation ............................................................................................................................. 9

1.11 How to Use The Slides ......................................................................................................... 10

1.12 Locking Bracket for RKVM-17-Dslide ................................................................................... 11

1.13 How to use the Dual Slides .................................................................................................. 12

1.14 Connect to Server via USB Interface .................................................................................... 13

1.15 Connect to KVM via USB Interface ...................................................................................... 13

1.16 Connect to Server via PS/2 Interface ................................................................................... 15

1.17 Connect to KVM via PS/2 Interface ...................................................................................... 15

Section 2: Operations ........................................................................................................................... 16

2.1 On-screen Display Operation ............................................................................................... 16

2.2 On-screen Menu .................................................................................................................. 17

Section 3: Specifications ....................................................................................................................... 19

3.1. Keyboard & Mouse .............................................................................................................. 20

Section 4: Optional Specifications ........................................................................................................ 21

4.1 KVM Options ........................................................................................................................ 21

4.2 DVI-D Option ........................................................................................................................ 21

4.3 S-Video + RCA Input Option ..................................................................................................... 21

www.avenview.com

3

4.4 S-Video + BNC Input Option ................................................................................................. 22

4.5 DC Power Option ................................................................................................................. 23

Section 5: Troubleshooting .................................................................................................................. 24

Section 6: Dimensions .......................................................................................................................... 24

www.avenview.com

4

Section 1 – Getting Started

1.1 Important Safegaurds

Please read all of these instructions carefully before you use the device. Save this manual for future
reference.

What the warranty does not cover

Any product, on which the serial number has been defaced, modified or removed.



Damage, deterioration or malfunction resulting from:



Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized



product modification, or failure to follow instructions supplied with the product.
Repair or attempted repair by anyone not authorized by us.



Any damage of the product due to shipment.



Removal or installation of the product.



Causes external to the product, such as electric power fluctuation or failure.



Use of supplies or parts not meeting our specifications.



Normal wear and tear.



Any other causes which does not relate to a product defect.



 Removal, installation, and set-up service charges.

www.avenview.com

5

1.2 Safety Instructions

Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.



Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned



environment with temperatures not exceeding 40° C (104° F).
When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling



and causing damage to other equipment or injury to persons nearby.
When the drawer is in an open position, do not cover, block or in any way obstruct the gap between



it and the power supply. Proper air convection is necessary to keep it from overheating.
Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.



If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the



voltage and current labelled on the equipment’s electrical ratings label. The voltage rating on the
cord should be higher than the one listed on the equipment’s ratings label.

Observe all precautions and warnings attached to the equipment.



If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to



prevent being damaged by transient over-voltage.
Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on



to the power supply or on other hardware may cause damage, fire or electrical shock.
Only qualified service personnel should open the chassis. Opening it yourself could damage the



equipment and invalidate its warranty.
If any part of the equipment becomes damaged or stops functioning, have it checked by qualified



service personnel.

1.3 Regulatory Notices Federal Communications Commission (FCC)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.

Any changes or modifications made to this equipment may void the user’s authority to operate this equipment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:

Re-position or relocate the receiving antenna.



Increase the separation between the equipment and receiver.



Connect the equipment into an outlet on a circuit different from that to which the receiver is



connected.

www.avenview.com

6

1.4 Package Contents

1

LCD Keyboard drawer x 1 pc,

2 Fasteners for rear L-bracket x 4 pcs

3 330mm rear mounting L-bracket x 1 pair



Mounting depth-adjustable from 390mm to 920mm

4 CB-6 2-in-1 USB keyboard cable x 1 pc or

CD-6 3-in-1 PS/2 keyboard cable x 1 pc

5 User manual x 1 pc

6 Power cord x 1 pc

7 Auto Switch power adapter (for external power version ) x 1 pc

www.avenview.com

7

1.5 Before Installation

PS/2 3-in-1 KVM cable

CD-6 6 feet
CD-10 10 feet
CD-15 15 feet
CD-33 33 feet

USB 2-in-1 KVM cable

CB-6 6 feet
CB-10 10 feet
CB-15 15 feet

SUN / iMAC USB to PS/2 adapter

SUN-31

Extended rear mounting L-bracket

430mm (16.9") extended rear L-bracket up to 1020mm
*Extended rear L-bracket in tailor-made length on request

Power Cord

IEC power cord
NEMA 5-15 power cord (US)
BS 1363 power cord (UK)
CEE 7/4 power cord (German)

AS 3112 power cord (Australia)

It is very important to locate the Rackmount Keyboard Drawer in a suitable environment.



The surface for placing and fixing the Rackmount Keyboard Drawer should be stable and level or



mounted into a suitable cabinet.
Make sure the place has good ventilation, is out of direct sunlight, away from sources of excessive



dust, dirt, heat, water, moisture and vibration.

 Convenience for connecting the Rackmount Keyboard Drawer to the related facilities should be well

considers too.

1.6 Unpacking

The LCD Keyboard Drawer comes with the standard parts shown on the package contents. Check and make
sure they are included and in good condition. If anything is missing, or damage, contact the supplier
immediately.

1.7 Optional Accessories

www.avenview.com

8

1.8 Peripheral Products

Item

Description

DB-15 KVM

8 / 16-port IP PS/2 KVM
8 / 16-port two console PS/2 KVM
4 / 8 / 16-port PS/2 KVM
8 / 16-port USB KVM

Cat5 KVM

16 / 32-port IP Cat5 KVM
16 / 32-port two console Cat5 KVM
16 / 32-port high density Cat5 KVM

KVM Extender

IP KVM extender
Cat5 PS/2 KVM Extender
Cat5 USB KVM Extender

1 SAMSUNG Class A TFT LCD Panel

2 Adjustable rear mounting L-bracket

3 LCD membrane button

4 Membrane switch (KVM option)

5 Keyboard & mouse

1.9 Structure Diagram
