Assembly Instructions

Control Unit

Marex ECS

R419302112/07.2016, EN
English
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 3

Table of Contents

1 About this documentation ............................................ 5
1.1 Validity of the documentation................................................ 5
1.2 Required and additional documentations.......................... 5
1.3 Presentation of information................................................... 5
1.3.1 Safety messages ..................................................................... 6
1.3.2 Symbols ..................................................................................... 7
1.3.3 Designations ............................................................................. 7
1.3.4 Abbreviations ............................................................................ 8
2 Safety instructions ........................................................ 9
2.1 About this chapter.....................................................................9
2.2 Intended use................................................................................9
2.3 Improper use ............................................................................10
2.4 Personnel qualifications........................................................11
2.5 General safety instructions ..................................................11
2.6 Product- and technology-related safety messages......12
2.7 Operator‘s obligations............................................................13
3 General notes regarding property damages and
product damages ........................................................ 14
4 Scope of delivery ......................................................... 15
5 About this product ....................................................... 16
5.1 Performance description ......................................................16
5.2 Product description ................................................................17
5.3 Product overview.....................................................................19
5.4 Product identification.............................................................20
5.5 Classification.............................................................................21
6 Transport and storage ................................................ 22
6.1 Product transport....................................................................22
6.2 Delivery check ..........................................................................22
6.3 Product storage .......................................................................22
7 Assembly ..................................................................... 23
7.1 Installation conditions and installation site ....................25
7.2 Installing the Marex ECS Control Unit...............................27
7.3 Connecting the Marex ECS Control Unit via the wiring
harness.......................................................................................29
English
4 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Table of Contents
8 Commissioning ............................................................ 33
8.1 Starting the Marex ECS Control Unit up ...........................33
9 Maintenance and repair ............................................. 36
9.1 Cleaning......................................................................................36
9.2 Inspection...................................................................................36
9.3 Maintenance..............................................................................36
10 Disassembly and replacement .................................. 38
11 Disposal ....................................................................... 41
12 Error search and troubleshooting ............................ 42
12.1 Take control or change the control station .....................42
12.2 Alarm signals and acknowledgment.................................43
12.3 Troubleshooting the control head......................................44
12.4 Troubleshooting the actuator ..............................................45
13 Technical data ............................................................. 46
14 Accessories ................................................................. 47
15 Appendix ...................................................................... 49
16 Alphabetical Index ...................................................... 50
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 5
About this documentation

1 About this documentation

1.1 Validity of the documentation

These assembly instructions apply to the following products:
W Marex ECS Control Unit - R4193002110
The Marex ECS Control Unit is part of the Marex ECS ship control system. In context which refers to the ship’s direction of thrust, ’forward’ is used as equivalent term for ’ahead’ and ’reverse’ for astern. These assembly instructions are intended for mechanics and service technicians. These assembly instructions contain important information for properly and safely installing, starting up, operating, maintaining and dismantling the Marex ECS Control Unit. Read these assembly instructions completely, especially the chapter 2, Safety instructions, before working with the product.

1.2 Required and additional documentations

Before powering up the product make sure to read and understand the necessary documents.
O Observe the instructions for the other system components. O Observe the boat’s operating instructions.
Table 1: Required and additional documentations
Titl e Document No. Document type
Marex ECS R419302113 Quick Guide

1.3 Presentation of information

For a quick start and safe operation of the product, consistent symbols, terms and abbreviations are used and safety instructions are given in a consistent manner. For easy
English
6 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
About this documentation
understanding, explanations are provided in the following sections.

1.3.1 Safety messages

This documentation includes safety instructions placed before a sequence of actions during which there is a risk of damage to persons or property. The precautions described must be observed. Safety instructions are structured as follows:
SIGNAL WORD
Type and source of risk
Consequences
O Precautions
W Warning sign: Draws attention to the risk W Signal word: Identifies the hazard level W Type and source of risk: Identifies the type and source of the
hazard
W Consequences: Describes the consequences of non-
observance
W Prevention: Describes how to avert the danger
Table 2: Hazard classes according to ANSI Z535.6-2011
Warning sign
Signal word
DANGER
WARNING
Meaning
Indicates a hazardous situation
which, if not avoided, will result in
death or serious injury.
Indicates a hazardous situation
which, if not avoided, could result in
death or serious injury.
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 7
About this documentation
Table 2: Hazard classes according to ANSI Z535.6-2011
Warning sign
Signal word
CAUTION
NOTICE
Meaning
Indicates a hazardous situation
which, if not avoided, could result in
minor or moderate injury.
Property damage: The product or the
environment may be damaged.

1.3.2 Symbols

The following symbols mark notices which are not relevant to safety but contain useful knowledge for the proper operation of the product.
Table 3: Meaning of symbols
Symbol Meaning
If this information is not observed, the optimal use or
operation of the product cannot be ensured.
O
1.
2.
3.
single, independent step
Numbered instructions:
The numbers indicate the steps which must be executed
in a given order.
English

1.3.3 Designations

In this documentation the following designations are used:
8 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
About this documentation
Tab le 4: De si gn ati on s
Designation Meaning
Marex ECS Marex Easy Control System
MarexLink Wireless network tool to modifiy

1.3.4 Abbreviations

The following abbreviations are used in these assembly instructions:
Table 5: Abbreviations
Abbreviaton Meaning
CAN Controller Area Network
Asynchronous serial bus system for the networking
of control units
WLAN Wireless Local Area Network
GL Germanischer Lloyd
Classification society based in Hamburg, Germany
ABYC American Boat and Yacht Council
American association for the development of
standards in boating safety
single Single engine system
twin Twin engine systems
PORT Portside
STBD Starboard
(electronic ship remot control
system)
the settings of Marex ECS using
mobile devices.
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 9
Safety instructions

2 Safety instructions

2.1 About this chapter

The control unit has been manufactured in strict compliance with the generally accepted rules of technology. However, this does not exclude the risk of damage to persons or property if the general safety instructions in this chapter and the safety instructions in this document are not observed. O Read these assembly instructions completely and carefully
before starting to operate the Marex ECS Control Unit.
O Keep these assembly instructions in a location where they
are accessible to all users at any time.
O Always include these assembly instructions when passing
the Marex ECS Control Unit on to third parties.

2.2 Intended use

The Marex ECS Control Unit is used to control ship propulsions. It is suitable for applications on boats, yachts and smaller work boats and for the installation in the engine room. The MarexECS Control Unit may only be used in applications with diesel engines together with the MarexECS-system under the ambient conditions described in this manual. An emergency stop switch must be provided on every control station. You may use the Marex ECS Control Unit as follows:
W to output electric signals for the throttle control of marine
propulsions
W to output electric signals for the control of marine
transmissions
W to collect control signals via the STATION bus cable from the
control heads of Marex ECS
W to transmit control signals via the STATION bus cable to the
mechanical actuators of Marex ECS.
W to transmit control signals via the STATION bus cable to the
electric control units of the corresponding engine control units.
English
10 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Safety instructions
W The control unit described in this document cannot be
combined with the components of the first generation MarexECS: R417002550 R417002400 R419302102 R417002102 R417002103
Intended use includes having fully read and understood this documentation and especially chapter 2, Safety instructions.

2.3 Improper use

Any use other than as described in "Intended use" is improper and thus inadmissible. If, in applications relevant to safety, inappropriate products are installed or used, unintended operating conditions can be created in the application which may cause damage to persons and/or property. Therefore only apply a product within applications relevant to safety if this kind of use is clearly specified and permitted in the product's documentation as for example within explosive areas or in parts of a control system which are relevant for functional safety. Unintended use of the product does also include:
W connecting the Marex ECS Control Unit to inadmissible
supply voltage (see chapter 13, Technical data),
W combining the Marex ECS Control Unit with further
components which are not suitable for that purpose,
W exposing the Marex ECS Control Unit to ambient conditions
which are not admissible (see chapter 13, Technical data).
AVENTICS GmbH declines any responsibility for damage resulting from unintended use. The user of the equipment is fully responsible for any risk arising from unintended use of the product.
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 11
Safety instructions

2.4 Personnel qualifications

The activities described in these assembly instructions require basic knowledge of electrics and of the corresponding terminology. To ensure the safe use of the product, those activities may only be performed by authorized personnel or by instructed persons supervised by authorized personnel. An authorized person is someone who due to his/her expert training, knowledge and experience including his/her knowledge of the relevant regulations can assess the assigned tasks, recognize possible dangers and take appropriate safety measures. Authorized personnel must comply with the applicable specialist regulations.

2.5 General safety instructions

W Observe the valid regulations pertaining to accident
prevention and environmental protection.
W Observe the safety instructions and guidelines of the
country in which the product is used.
W Only use AVENTICS products in technically perfect condition. W Check the product for obvious defects as for example cracks
in the housing or missing screws, caps or sealings.
W Observe all instructions on the Marex ECS Control Unit. W Persons who install, operate, dismantle or maintain
AVENTICS products must not be under the influence of alcohol, other drugs or medications which affect the responsiveness.
W Use only accessories and spare parts approved by
AVENTICS in order to avoid hazards to persons as a consequence of unsuitable spare parts.
W Observe the technical data and environmental conditions
stated in the product documentation.
W If, in applications relevant to safety, inappropriate products
are installed or used, unintended operating conditions can be created in the application which may cause damage to persons and/or property. Therefore only apply a product within applications relevant to safety if this kind of use is
English
12 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Safety instructions
clearly specified and permitted in the product's documentation.
W Improper installation and use as well as wrong handling will
invalidate the warranty.
2.6 Product- and technology-related safety
messages
WARNING
Danger due to failure or malfunction
Failures or malfunctions of the Marex ECS Control Unit can, in the overall system, cause damage to persons and property. O Even if no special danger arises from the Marex ECS
Control Unit, you have to consider the impact of failures or malfunctions of the Marex ECS Control Unit on the overall system.
Assembly O Always disconnect the system from the power supply before
assembling the Marex ECS Control Unit, connecting or disconnecting plugs. Secure the system against being switched on unintentionally.
O Lay cables in such a way that they cannot be damaged and
nobody can trip over them.
O Before starting the product make sure that terminating
resistors and protective caps on connectors are properly fixed and undamaged in order to prevent that liquids and foreign particles penetrate into the product.
Commissioning O Make sure that all electric ports are used or covered. Only
start up products which are fully installed.
Operation O Only allow authorized persons to access the engine control
room.
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 13
Safety instructions

2.7 Operator‘s obligations

Installation and maintenance work is subject to the country­specific safety regulations and standards of the application. As an operator of a ship which shall be equipped with a Marex ECS Control Unit and further components of a ship remote control system, you are responsible that
W the product is in technically perfect condition, W the product is used as intended, W any staff handling the product has read and understood the
documentation,
W users of the product are trained and instructed, W the regulations related to safety, accident prevention and
environmental protection are complied with.
English
14 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA

General notes regarding property damages and product damages

3 General notes regarding
property damages and product
damages
Cleaning O Cover all openings with suitable protective caps to prevent
that cleaning agent penetrates into the system.
O Never use solvents or other aggressive cleaners. Clean the
product only by using a slightly moistened lint-free cloth. Only use water or mild cleaning agents.
O Never use pressure washers or steam cleaners to clean the
product.
Disposal O Dispose of the product according to national provisions of
your country.
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 15
Scope of delivery

4 Scope of delivery

The standard product delivery includes:
1 Marex ECS Control Unit R419302110
1 Assembly Instructions R419302112
1 Marex ECS Quick Guide R419302113
For the assembly:
2Mounting screws
2Washers
2Hexagon nuts
English
16 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
About this product

5 About this product

5.1 Performance description

The Marex ECS Control Unit is used to actuate marine transmissions and throttles of marine propulsions. The Marex ECS Control Unit provides in- and outputs to collect, process and output analog and digital signals. The following in- and output variables can be processed: 2 analog output signals 0 - 20mA, 2 analog output signals 0 - 10V 2 analog output signals PWM 2 analog input signals (frequency … Hz) 5 digital outputs (high-side-switch) 10 digital outputs (low-side-switch) 10 digital inputs The type and number of in- and outputs depends on the system configuration and the related Marex ECS wiring harness.
The Marex ECS Control Unit is designed for the operation with Marex ECS. Depending on the software some of the functions which are described in these assembly instructions may not be supported.
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 17
About this product

5.2 Product description

The Marex ECS Control Unit receives and processes the operation commands which are set via the Marex ECS control head(s) and transmits the resulting signals to the ship‘s propulsion system to control the throttle and transmission direction.
The Marex ECS Control Unit is connected to the Marex ECS components by the STATION bus cable which is used for the data communication between the components. Between ship propulsion and Marex ECS Control Unit the data can either be communicated via analog and digital interfaces or the PROPULSION bus cable.
English
18 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
STATION
STATION
GEAR
GEAR BOX ENGINE GEAR BOX ENGINE
THROTTLE
AUX
GEAR
THROTTLE
AUX
ALARM
POWER
POWER
PROPULSION
About this product
The following figure shows an example for Marex ECS twin including these components:
W Marex ECS Control Unit (R419302110) W Marex ECS twin wiring harness (R419302202) W Control stations equipped with Control Head Type 500-ECS-
twin (R417002880 or R417002808)
W Actuator 12VDC (R417002894) or 24 VDC (R417002895)
Fig. 1: System overview Marex ECS twin (example)
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 19
1
2
34
5
3
2
About this product

5.3 Product overview

Fig. 2: Overview Marex ECS Control Unit
1 Pressure equalization membrane
2 Rubber mounts
3 Bushings
4 94-pin socket
5 60-pin socket
English
20 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
1
2
3
4
About this product

5.4 Product identification

Fig. 3: Type plate of Marex ECS Control Unit
1 Date of manufacture
2 Material number
3 Serial number
4 Software version
Take down the control unit’s serial number in the space provided on the Marex ECS Quick Guide, chapter 17. The serial number is your password to access the wireless MarexLink network if you wish to modify the settings of your Marex ECS. Refer to the Marex ECS Quick Guide for more information on MarexLink.
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 21
About this product

5.5 Classification

The Marex ECS Control Unit has been designed and manufactured in compliance with the generally accepted rules of technology. It was tested in accordance to the following rules and guidelines and fulfills the requirements stipulated therein:
Germanischer Lloyd (GL) O Rules for Classification and Construction IV Part 7 Chapter 2,
Test Requirements for Electrical / Electronic Equipment and Systems, Edition 09/2012
O Environmental Categories C and F
DIN EN ISO 25197 O Small craft; Electrical devices; Protection against ignition of
surrounding flammable gases, Edition 03/2015
Regulations of American
Boat and Yacht Council
(ABYC)
O ABYC-Standard P24 ’Electric/Electronic Propulsion Control
Systems’, issue 2007
English
22 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Transport and storage

6 Transport and storage

6.1 Product transport

NOTICE
Damage due to improper transport
Improper transport can cause substantial material damage. O Be careful when unloading the packages on delivery and
in case of in-plant transport. Observe the symbols and instructions on the package.
O Only remove the ESD-packaging shortly before mounting
the wiring harness.

6.2 Delivery check

O Check the supply immediately on receipt for completeness
and transport damage.
O Proceed as follows if any visible damage is discovered
during receipt of delivery: – Do not accept the delivery or only under reservation. – Note the extent of damage on the transportation
documents or the delivery note.
– Submit a claim.

6.3 Product storage

O Do not destroy the packaging and only remove it shortly
before installation.
O Adhere to the following conditions for storage:
– Do not store packages outside. – Store the packages in a dry and dust-free place. – Do not expose the packages to aggressive media. – Protect the packages against solar radiation.
O Observe the storage temperature of 233 to 358K
(-40°C to +85°C).
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 23
Assembly

7 Assembly

CAUTION
Injury hazard and risk of property damage due to improper installation
Improper installation can cause damage to persons and property. O The Marex ECS Control Unit may only be installed by
AVENTICS or qualified personnel as specified in chapter
2.4.
O Prepare mounting work carefully. O Eliminate sources of danger at the site of installation. O Before you start working, make sure there is enough
room for the assembly.
O Consider also the size of the wiring harness when
choosing a place of installation.
O Be careful with sharp edged parts. O Only install the Marex ECS Control Unit if all connectors
are unplugged and the component is powered off.
English
24 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Assembly
NOTICE
Property damage caused by choosing an inappropriate site of installation or wrong handling
Installing the product at sites which do not meet the requirements in the technical specification or handling the product wrongly can lead to system failures and material damage. O Observe the technical specification of the products when
choosing the place of installation (see also chapter 13, Technical data).
O Never install the Marex ECS Control Unit in areas which
do not meet the protection class specified.
O Do not install the Marex ECS Control Unit in areas with
temperatures beyond the admissible range.
O Never expose the Marex ECS Control Unit to splash
water.
O Select an installation site which is low in vibrations. O Never fix the Marex ECS Control Unit on or on top of the
ship‘s engine.
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 25
1
2
Assembly

7.1 Installation conditions and installation site

NOTICE
Malfunction due to deviating electric potentials
Direct contact of the control unit‘s metal body to metallic surfaces can lead to malfunctions in the component‘s electronics. O Make sure the metal body of the Marex ECS Control Unit
does not touch a metallic surface when choosing the site of installation.
O Use the preinstalled rubber mounts to fasten the Marex
ECS Control Unit.
The Marex ECS Control Unit is designed for the installation in the Engine Control Room. Provide the necessary basis to mount the Marex ECS Control Unit:
1. Choose a suitable place of installation: It should be near the
ship‘s engine, but low in vibrations and even. (Fig.4).
Fig. 4: Possible installation sites in the engine control room
1 Marex ECS Control Unit
2 Boat engine (example)
English
26 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
80 mm
STATION/PR
INTERNAL
OPULSION
GEAR
THROTTLE
AUX
POWER
ALARM
10 m max.
10 m max.
30 m max. (12 V) 60 m max. (24 V)
(
max. total length: 250 m
)
3 m max.
PUSH/PULL
20 m max. 10 m max.
10 m max.
Assembly
2. Make sure there is sufficient space next to the control unit to
mount the wiring harness of your choice properly (Fig. 5): – Required space for the Marex ECS Wiring Harness:
800mm at maximum
– Required space for the 94-/60-pin-connectors including
retaining catch mechanism: 80mm at least
min. 800 mm
min.
Fig. 5: Mounting space required for control unit and wiring harness
3. Route the cables supplied professionally from their
connection site to the Marex ECS Control Unit. Consider the admissible cable lengths in your planning already, see also figures 6 and 1:
Fig. 6: Maximum cable lengths
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 27
Assembly

7.2 Installing the Marex ECS Control Unit

CAUTION
Injury hazard due to improper installation
Improper installation can cause damage to persons and property.
O Eliminate sources of danger at the site of installation. O Before you start working, make sure there is enough
room for the assembly.
O Be careful with sharp edged parts. O Only install the Marex ECS Control Unit if all connectors
are unplugged and the component is powered off.
O The installation may only be performed by qualified
personnel (see chapter 2.4).
1. Unpack the Marex ECS Control Unit. Remove the ESD
packaging.
2. Check if the rubber mounts are preinstalled and fit securely.
If the rubber mounts are missing or loose, you must not assemble or operate the Marex ECS Control Unit.
Fig. 7: Marex ECS Control Unit with preinstalled rubber mount
3. Fasten the Marex ECS Control Unit at the chosen installation
site, preferably in the Engine Control Room (Fig.4).
English
28 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Assembly
4. Drill two sufficiently deep, threaded M8 holes in a distance
which corresponds to the mounting holes of the Marex ECS Control Unit (220 mm) (Fig. 8):
Fig. 8: Drilling template
5. Use two M8 screws, nuts and washers to fasten the control
unit.
6. Tighten the screws with a torque of 10 Nm (fig. 9).
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 29
Assembly
Fig. 9: Marex ECS Control Unit, fastening
7.3 Connecting the Marex ECS Control Unit via
the wiring harness
Marex ECS features a preassembled wiring harness (Fig. 10) which provides the electric connections between the Marex ECS Control Unit and the power supply, propulsion system, gearbox and other Marex ECS components. Connectors and cables are color-coded and labeled so that they can be quickly identified and unmistakably assigned to their function.
CAUTION
Risk of damage to persons and property due to use of inadequate cables
The use of unsuitable cables can lead to failures or malfunctions of your Marex ECS remote control system. O Use only cables and connectors which are approved by
AVENTICS.
O Make sure that all cables and components are powered
off before connecting the Marex ECS Control Unit.
English
30 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
1
2 3
4
Assembly
NOTICE
Material damage due to improper plug connections
Misplugging connectors or plugging connectors inappropriately in the Marex ECS Control Unit can lead to system malfunctions and material damage. O Make sure that the retaining catches of the 60- and 94-
pin-connectors have clicked into place before starting up Marex ECS.
The Marex ECS Control Unit is connected to the wiring harness by means of the connectors (2) and (3) shown in fig. 10:
Fig. 10: Marex ECS Control Unit and wiring harness
1 Marex ECS Control Unit
2 94-pin male connector
3 60-pin male connector
4 Retaining catch
Proceed as shown in the pictures below to connect the Marex ECS Control Unit:
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 31
Assembly
1. Open the retaining catches of the 60- and 94-pin male
connectors on the wiring harness. Make sure to open the catches fully so that the connectors can be smoothly plugged and unplugged:
2. First, plug the larger connector in the corresponding socket
of the control unit:
3. Close the retaining catch by moving it in the direction of the
arrow until it clicks:
English
32 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Assembly
4. Plug the smaller male connector in the corresponding
socket of the Marex ECS Control Unit:
5. Close the retaining catch by moving it in the direction of the
arrow until it clicks:
6. Attach the Marex ECS wiring harness using the clamps
supplied:
The Marex ECS Control Unit and wiring harness are now properly installed.
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 33
Commissioning

8 Commissioning

The Marex ECS Control Unit is part of the Marex ECS ship remote control system. Whenever a system component is replaced or the system is enhanced by new components, Marex ECS must be (re)configured before starting its operation.
Automatic configuration Marex ECS features automatic configuration named
"auto-config". Only few steps are required to log on and configure components (see 8.1)
The Marex ECS Control Unit must only be used with these Marex ECS components:
W Marex ECS Control Head Type 500-ECS (R417002881,
R417002880, R417002810, R417002808)
W Marex ECS Wiring Harness (R419302201, R419302202) W Marex ECS Actuator (R417002894, R417002895) W and matching system cables

8.1 Starting the Marex ECS Control Unit up

Before starting up the Marex ECS Control Unit, all electrical connections between the components and the boat‘s propulsion system must be established (see 7, Assembly). Make sure that O all connectors are attached to the Marex ECS Control Unit
and the wiring harness
O the power supply is properly connected O all components are properly connected O the control unit‘s metal body does not touch a metallic
surface or the ship mass
O the retaining catches of the connectors (Fig. 10) have clicked
into place.
Always perform the following steps
O if you have installed a new Marex ECS Control Unit, O if you have replaced a Marex ECS Control Unit.
English
34 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Commissioning
Fig. 11: Marex ECS wiring harness with auto-config plug
Table 6: Executing the auto-config
1. Power Marex ECS completely off.
2. Disconnect the male part of the auto-
config plug from the wiring harness of the Marex ECS control unit.
3. Switch the power supply on.
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 35
Table 6: Executing the auto-config
Commissioning
The device status LEDs flash alternately red and green on all Marex ECS components.
The auto-config is running. The process may take a few minutes.
When the LEDs flash green on all components, the auto-config is finished.
4. Reattach the auto-config plug to the corresponding jack on the wiring harness. Make sure the plug fits securely. The configuration is complete. The device status LED’s are indicating the components’ status again. The control unit is ready for operation.
Repeat the auto-config if the process is interrupted or red LEDs flash or light up permanently.
If you wish to modify settings you can now make the necessary changes using the wireless MarexLink network.
5. Test all system functions first at standstill and later at slow speed. Refer to the Marex ECS Quick Guide.
The commissioning is complete if all functions are working without failure.
English
36 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Maintenance and repair

9 Maintenance and repair

9.1 Cleaning

O Clean the product only by using a slightly moistened, lint-
free cloth.
O Only use solvent-free, non abrasive cleaning agents. O Never use pressure washers or steam cleaners to clean the
Marex ECS Control Unit.

9.2 Inspection

Check at regular intervals if
W all connectors attached to the Marex ECS Control Unit and
Marex ECS Wiring Harness fit securely,
W all screws fixing the component are tightened with the
appropriate torque,
W there is no conductive earth connection, W the control unit‘s metal body does not touch a metallic
surface,
W the retaining catches of the 60- and 94-pin connectors have
clicked into place.
If the ship or remote control system is subjected to heavy vibrations, you will need to inspect more frequently the cable and screw connections to terminals, plugs and fastening points.

9.3 Maintenance

The Marex ECS Control Unit is basically maintenance-free. Servicing the control unit extends to cleaning and inspecting the exterior. The following safety instructions must be observed:
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 37
Maintenance and repair
WARNING
Injury hazard due to high temperatures, dangerous voltages or other risks
Improper maintenance can cause damage to persons or property. O The control unit‘s metal body will heat up in operation.
Let the component cool down before touching it for inspection or cleaning.
O Never open the control unit‘s body. There are no parts
inside which you can repair.
O Only service the Marex ECS Control Unit if it is powered
off.
O The Marex ECS Control Unit must only be repaired by
AVENTICS or authorized personnel.
English
38 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Disassembly and replacement

10 Disassembly and replacement

CAUTION
Injury hazard due to improper disassembly or replacement
Stored residual energy, sharp parts, points and corners on and in the component or on the required tools can cause injuries. If you replace the Marex ECS Control Unit while the ship is cruising, the ability to steer may be lost O Disassemble or replace the Marex ECS Control Unit only
in the habour or at the jetty.
O Disassemble or replace the Marex ECS Control Unit only
if the boat is not in operation.
O Have components disassembled or replaced only by
AVENTICS or authorized personnel (chapter 2.4).
Proceed as follows to disassemble the Marex ECS Control Unit:
1. Disconnect the power supply.
2. Open the retaining catch of the smaller, 60-pin male
connector:
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 39
Disassembly and replacement
3. Remove the 60-pin connector:
4. Open the retaining catch of the larger, 94-pin male
connector:
5. Remove the 94-pin male connector:
English
40 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Disassembly and replacement
6. Loosen the component’s fastening screws:
7. To install a new Marex ECS Control Unit, follow the steps
described in chapter 7.2.
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 41
Disposal

11 Disposal

NOTICE
Environmental damage due to improper disposal
Electronic components require special waste treatment and must only be disposed of by approved specialist companies. O Dispose of electronic scrap in an environmentally sound
way. Consult the responsible local authorities regarding the environmentally sound disposal.
O Dispose of the packaging in an environmentally compatible
way.
English
42 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA

Error search and troubleshooting

12 Error search and
troubleshooting
Malfunctions are signaled to the operator by the ALARM LEDs and the device status LEDs on the control head’s keypad.
WARNING
Hazard of a fatal accident or collision due to a system failure
When ALARM LEDs flash red or light up permanently this indicates a device failure or malfunction which may result in a system failure or even unexpected reaction of the boat. You may no longer be able to control the main propulsion engine. To prevent a fatal accident or collision, immediately take the following measures when the ALARM LED flashes or lights up:
O First bring the boat into a safe state! O Only then acknowledge the alarm and eliminate the
cause of the fault
If the active control head fails, Marex ECS automatically reduces the engine rpm to idle and disengages the clutch.

12.1 Take control or change the control station

Provided your Marex ECS features more than one control head, you can control your boat from another control head should the active control head fail. Choose a control head of which the device status LED lights up green and push the COMMAND key twice in order to activate it.
If this is not possible, change to the local control of the propulsion system, if available.
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 43
1 x
Error search and troubleshooting

12.2 Alarm signals and acknowledgment

If the ALARM LED of your control head flashes red accompanied by the buzzer:
O Bring the boat into a safe state! O Acknowledge the alarm by pushing the ALARM key. The
buzzer is muted and the ALARM LED changes its state:
– If the ALARM LED permanently lights up red, you have to
take troubleshooting measures immediately.
– Even if the ALARM LED turns off, you must check the
function of system and components immediately!
Twin-engine systems provide one ALARM LED each for port and starboard. In case of alarm, only one may flash or light up permanently. Then the failure only concerns one of the propulsion systems and the other propulsion side is not affected.
English
2 x
44 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Error search and troubleshooting

12.3 Troubleshooting the control head

In case of malfunctions, check the LEDs on the control head(s) and, if applicable, actuator(s) and carry out the corresponding steps as explained in the tables below:
Table 7: LED signals on the control head
LED-signal Meaning What to do
This control head is defective. O Replace the control head and repeat the
auto-configuration (see also chapter 8.1 and the documentation for the Marex ECS Control Head).
O If available, check also the function of the
other control heads by comparing the LED signals and referring to the instructions in this table.
O If available, check the function of the optional
actuator(s), see table 8.
This control head works fine,
but another system component
is defective.
O If available, check the function of the other
control heads, by comparing the LED signals and referring to the instructions in this table.
O If available, check the function of the optional
actuator(s), see table 8.
The communication of the
control head has failed or the
power supply is beyond the
admissible range.
Power supply failure. O Check the power supply, see also chapter
Do you still have the command and can control engine and gear? O Check the on-board power supply. If not, O check the STATION cables, see also chapter
7.3.
7.3.
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 45

12.4 Troubleshooting the actuator

In case of an alarm signal on the Marex ECS control head, it may be necessary to check the condition of the actuator(s). Two LEDs are provided under the transparent cover of the actuator to indicate its functional condition Compare the LED signals to the indications in the table below:
Table 8: LED-signals on the actuator
LED-signal Meaning What to do
This actuator is defective. O Replace the actuator, proceed as described in the
actuator’s documentation and repeat the Marex ECS auto-config (8.1).
This actuator works fine, but
another actuator may be
affected.
The actuator has stopped
working due to overload.
Power supply failure or the
power is beyond the admissible
range or the communication
between the actuator and the
control unit is disturbed.
O Check the function of all other actuators, if
available. Refer to the instructions in this table.
O Check manually if the actuator’s adjusting lever
can move freely by pulling the push/pull cable.
O Eliminate the cause of the stiff movement. O Dis- and reconnect the POWER cable and try again.
O Check the PROPULSION cable for proper
connection and visible damage. Replace the cable if defective.
O Measure the voltage at battery and system
components. Pay special attention to correct polarity and fuses.
O Make sure the wiring harness is properly
connected to the control unit with the retaining catches clicked into place.
Error search and troubleshooting
English
46 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Technical data

13 Technical data

Table 9: Technical data
Dimensions width x height x depth 245 x 48.8 x 205.3mm
Weight 2.4 kg approximately
Power supply 12VDC (-25%/+30%)
24VDC (-25%/+ 30%)
Power consumption 10A (12V)
10A (24V)
Admissible ambient temperature 248 to 350 K (-25C to 77°C)
Storage temperature 233 to 358 K (-40C to 85 C)
Protection class IP 65 - EN 60529 (IEC 60529)
Vibration resistance IEC 60068-2-6
Shock resistance 10g/11ms
Rel. humidity 5% - 98% including condensation
Material of body Die-cast aluminium
Range 2-13 Hz: ± 1.6mm Range 13-100 Hz: ± 4g
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 47
Accessories

14 Accessories

Part Material No.
Cables
POWER cable, 5m R419801567
POWER cable, 10m (not suitable for Marex ECS Actuators 12V DC) R419801316
POWER cable, dual battery connection, 5m R419801568
POWER cable, dual battery connection, 10m
(not suitable for Marex ECS Actuators 12V DC)
POWER cable, ignition input, 20m R419801547
GEAR control cable, forward/reverse, 10 m R419801334
GEAR control cable, forward/reverse, solenoid valve connector, 5m R419801335
GEAR control cable, forward/reverse, solenoid valve connector, 10m R419801336
THROTTLE control cable, 4 -20 mA, 10m R419801320
THROTTLE control cable, 4- 20 mA, 20m R419801321
THROTTLE control cable, 0 - 5V, 10 m R419801322
THROTTLE control cable, 0 - 5V, 20m R419801323
THROTTLE control cable, PWM, 10m R419801324
THROTTLE control cable, PWM, 20m R419801325
AUX control cable, start interlock contact, safety stop, high idle, 10m R419801344
AUX control cable, start interlock contact, 10m R419801345
ALARM control cable, alarm and monitoring system interface, 10m R419801319
STATION/PROPULSION bus cable, 1m R419801349
STATION/PROPULSION bus cable, 5m R419801350
STATION/PROPULSION bus cable, 10m R419801351
STATION/PROPULSION bus cable, 15m R419801352
STATION/PROPULSION bus cable, 20m R419801353
STATION/PROPULSION bus cable, 30m R419801354
STATION/PROPULSION bus cable connector, 0.15m R419801362
Wiring harness
Marex ECS single wiring harness R419302201
Marex ECS twin wiring harness R419302202
Control head
Control head type 500-ECS, single, chrome-plated R417002881
R419801522
English
48 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Accessories
Part Material No.
Control head type 500-ECS, twin, chrome-plated R417002880
Control head type 500-ECS, single, black R417002810
Control head type 500-ECS, twin, black R417002808
Terminating resistor
Bus terminating resistor 8941054274
Actuator
Marex ECS actuator 12VDC including mounting kit for push-pull cable type 33C R417002894
Marex ECS actuator 24VDC including mounting kit for push-pull cable type 33C R417002895
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 49
Appendix

15 Appendix

Fig. 12: Marex ECS Control Unit dimensional drawing
English
50 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Alphabetical Index

16 Alphabetical Index

W A
Abbreviations 8 ABYC 21 Accessories 47 Assembly 23
Autoconfig-plug 34 Gasoline engines 29 Installation conditions 25 Installation site 25 Installation, steps 27 Installing the control unit 27 Maximum cable length 26
Safety instructions 12 Autoconfig-plug 34 Automatic configuration 33
W C
Classification
Germanischer Lloyd 21 Cleaning 14, 36 Commissioning 33
Automatic
configuration 33
Preconditions 33
Safety instructions 12 Configuration, automatic 33 Connecting wiring harness 29 Connection to wiring har­ness, steps 31
Control head
Dimensions 46
Control Unit
Description 17 Performance description 16 Product identification 20
W D
Data, technical 46 Delivery
Check 22
Scope 15 Designations 7 Dimensional drawing 49 Dimensions 46 Disassembly 38 Disposal 14, 41 Documentation
Abbreviations 8
Designations 7
Required and
additional 5
Symbols 7
Validity 5
W E
Error search 42
W G
Gasoline engines 29 General notes property and product damages 14 General safety instructions 11
AVENTICS | ECS Control Unit | R419302112–BDL–001–AA 51
Alphabetical Index
Germanischer Lloyd 21
W I
Improper use 10 Inspection 36 Installation conditions 25 Installation site 25 Installation, steps 27 Installing control unit 27 Intended use 9
W L
Length of cables 26
W M
Maintenance 36 MarexLink 20 Maximum cable length 26
W O
Operation, safety instruction 12 Operator’s obligations 13
W P
Password MarexLink 20 Performance description 16 Personnel qualification 11 Power supply 46 Product- and technology­related safety messages 12 Product description 17 Product identification 20 Property and product da­mages, general notes 14 Protection class 46
W Q
Qualification of personnel 11
W R
Repair 36 Required documentation 5
W S
Safety instructions
Assembly 12
Commissioning 12
General 11
Operation 12
Repair 36, 37 Safety messages,product­and technology­related 12 Scope of delivery 15 Symbols 7
W T
Technical data 46
Dimensions 46
Power supply 46
Protection class 46
Temperature 46 Temperature, ambient 46 Transport 22 Troubleshooting 42, 45 Type plate 20
W U
Use
Improper 10
Intended 9
52 AVENTICS | ECS Control Unit | R419302112–BDL–001–AA
Alphabetical Index
W V
Validity of documentation 5
W W
Wiring harness 29, 47 Wiring harness, connect 29 Wiring harness, space required 26
AVENTICS GmbH
Ulmer Straße 4 30880 Laatzen, Germany Phone +49 511-213 62 51 Fax: +49 511-213 61 65 www.marex-shipcontrols.com marinesales@aventics.com
Further addresses: www.aventics.com
The data specified above only serve to describe the product. No statements concerning a certain condition or suitability for a certain application can be derived from our information. The given information does not release the user from the obligation of own judgement and verification. It must be remembered that our products are subject to a natural process of wear and aging.
An example configuration is depicted on the title page. The delivered product may thus vary from that in the illustration.
Translation of the original operating instructions. The original operating instructions were created in the German language.
R419302112–BDL–001–AA Subject to modifications. © All rights reserved by AVENTICS GmbH, even and especially in cases of proprietary rights applications. It may not be reproduced or given to third parties without its consent.
Loading...
