Stereo Microscope
Selection Guide
aventools.com | sales@aventools.com | 734.973.0099
Tools for
Advancing
AVEN
Innovation
Stereo Zoom
Microscopes
Binocular Trinocular Description Magnification Working Distance
SPZH-135 SPZHT-135
SPZ-50E SPZV-50E
SPZ-50 SPZV-50
DSZ-44 DSZV-44
DSZ-70 N/A
Aven’s Stereo Microscopes
Offers the best in class zoom ratio with super sharp 3D images,
wide field of view and long working distance (ESD SAFE)
Offers the best in class zoom ratio with super sharp 3D images,
wide field of view and long working distance
The ideal scope for a wide range of investigative/inspection
applications requiring high magnification
The high precision optics ensures excellent contrast and definition
3D images from edge to edge, the exceptional quality allows users
to efficiently perform tasks and maintain high productivity
The exceptional quality allows users to efficiently perform tasks and
maintain high productivity with a wide magnification range
6.7x - 50x 41mm - 240mm
6.7x - 50x 41mm - 240mm
21x -135x 84mm
10x - 44x 45mm - 150mm
20x - 70x 41mm -120mm
Tools for
Advancing
AVEN
Innovation
Let’s Get Started
Features to Look at
Binocular Microscope
Binocular microscopes are an excellent choice for high-volume
inspection stations, parts and quality inspections, medical or
scientific research, and most applications requiring high quality
3D images. All images are viewed through eyepieces for
optimum, field of view, depth of field, clarity, and color.
(You cannot capture images using binocular microscopes.)
Inspection Cameras
*For Trinocular Microscopes Only
Trinocular Microscope
Trinocular microscopes have all the advantages of binocular
scopes plus a trinocular port for attaching a camera. These
scopes are ideal for operators who require the depth of field
provided by traditional eyepieces as well as the option of
capturing a 2D image for further study.
Microscope Stands
Post Stands
Post stands require
a basic focus mount.
They can be adjusted
vertically.
By attaching an inspection camera onto your trinocular
microscope, you can view your inspection on a monitor and
digitally save images.
• USB models connect to your computer and require software
for image capture, measurement and annotation
• HDMI cameras connect directly to an HD monitor and save
images to an SD card or USB flash drive
• Advanced HDMI cameras have integrated imaging/
measurement software
Illumination Accessories
LED ring lights are ideal for lower range magnifications, while
Fiber-optic Illuminators (FOI) provide more intensity and focus of
light that work well with high-range magnifications. Fiber-optic
illuminators also save a significant amount of energy, making
them better for the environment and your budget.
Boom Stands
Boom stands require a tiltable arbor or E-arm focus mount. They
can be adjusted horizontally and vertically.
Articulating Arm Stands
Articulating arm stands require a tiltable
arbor or E-arm focus mount. They can be
adjusted horizontally and vertically as
well as swivel 360° providing operators
with the greatest range of working space
