What You’ll Need:
Crimping Wire Ferrules:
Advancing
How to....
Wire CuttersFerrules & TerminalsCrimper & Die Wire Stripper
Aven offers 3 dies for
crimping wire ferrules
10178, 10179 & 10187
Step 1:
Place cord terminal in
correct spot on die
Crimping Insulated Terminals:
Aven offers 2 dies for
crimping insulated terminals
10188 & 10189
Step 1:
Place insulated terminal in
correct spot on die
Crimping Heat Shrink Connectors:
Step 2:
Once terminal is secure into
crimpers, slide wire into terminal
Step 2:
Once terminal is secure into
crimpers, slide wire into terminal
Step 3:
Close the crimper to
crimp terminal to wire
Step 3:
Close the crimper to crimp
insulated terminal to wire
Aven offers 1 die for crimping
heat shrink connectors
1019 0
Click Here to Watch a Tutorial on Aven’s Crimping Tools
Step 1:
Place connector into correct spot
on die, insert wire and crimp
Step 2:
Place second wire into other side
of connector and crimp
Step 3:
To secure both wires place
connector under heat
Tools for
Advancing
Innovation
AVEN
®
Crimping Tool Frame & Dies
Dies sold separately, paired with tool frame, and in crimping tool kits on our website www.aventools.com
Crimping Tool Frame
Item #10195
Aven's professional grade crimping tool frame has a smooth
and efficient ratcheting mechanism that creates uniform and
secure crimps. Variety of dies to extend the versatility of this
tool are available. Ideal for professional electricians and
DIY enthusiasts. Tool and dies are made from alloy steel from
durability. Comes with a limited lifetime warranty.
*Dies Sold separately*
Item # Description Price
10187 Crimping Tool for Wire Ferrules AWG 4 and 2 (25 and 35mm2) | Crimping Die F1 $51.60
10179 Crimping Tool for Wire Ferrules 6 to 10 AWG | Crimping Die F $50.90
10178 Crimping Tool for Wire Ferrules 12 to 22 AWG | Crimping Die D $50.90
10189 Crimping Tool for Miniature Insulated Terminals 26-22/24-18/22-16 AWG | Crimping Die A3 $51.60
10188 Crimping Tool for Insulated Terminals 22-
10190 Crimping Tool for Heat Shrink Terminals 22-18/16-14/12-10/8 AWG Crimping Die A1 $51.60
10187D Crimping Die F1 | For Insu
10179DS Crimping Die F | AWG: 10/8/6 | DIN: 6/10/16 MM2 $20.83
10178DS Crimping Die D | For Cord End Terminals | 22/20/18/16/14/12 AWG $18.66
10189D Crimping Die A3 | For Miniature Insulated Terminals 26-22/24-18/22-16 AWG $20.83
10190D Crimping Die A1 | For Heat Shrink Terminals 22-18/16-14/12-10/8 AWG $20.83
10188D Crimping Die A | For Insu
lated Cord Terminals 4/2 $20.83
lated End Terminals 22-18/16-14/12-10 AWG $20.83
18/16-14/12-10 AWG Crimping Die A $51.60
aventools.com
Tools for
Advancing
Innovation
AVEN
®
156 pc Crimping & Stripping Tool Set
Item #10171-KIT
Aven's professional grade crimping tool has a
smooth and efficient ratcheting mechanism that
creates uniform and secure crimps. Ideal for
professional electricians and DIY enthusiasts. Tool
and dies are made from alloy steel for durability.
This kit includes 1 wire crimper frame, 5 quick-change
dies, 1 wire stripper, 148 piece wire connector set,
and 1 hard plastic case for easy travel and storage.
Crimping Tool Frame
#10195
Die Jaw Type: D
#10178DS
Die Jaw Type: F1
#10187D
Die Jaw Type: A3
#10189D
Die Jaw Type: F
#10179DS
Die Jaw Type: A
#10188D
Wire Stripper
Ferrules/Terminals Tool Box
Tools for
Advancing
Innovation
AVEN
®
6 pc Crimping Tool Set
Item #10170-KIT
Aven's professional grade crimping tool has a
smooth and efficient ratcheting mechanism that
creates uniform and secure crimps. Ideal for
professional electricians and DIY enthusiasts.
Tool and dies are made from alloy steel for
durability. This kit features quick-change dies that
are easy to exchange with no tools required.
Crimping Tool Frame
#10195
Die Jaw Type: D
#10178DS
Die Jaw Type: F1
#10187D
Die Jaw Type: A3
#10189D
Die Jaw Type: F
#10179DS
Die Jaw Type: A
#10188D
Tool Box
aventools.com
Tools for
Advancing
Innovation
AVEN
®
Electrician Scissors & Stripping Blades
Multi-Purpose Electrician Scissors Kit W/Scissors and Blade
Item #11010
This kit includes two popular electricians tools: Multi-Purpose Scissors with a wire
stripping groove embedded into the blade, and a cable stripping knife. Includes a
nylon belt pouch for easy access to the tools.
Electrician Cable Stripping Blade W/ Blade Protector
Item #11015
Featuring a stainless steel blade ideal for stripping and peeling cable wire. The blade
protector doubles as a handle for securing cable wire. Features an ergonomic handle
for comfortable repetitive use.
Multipurpose Electrician Scissors W/Wire Stripper
Item #11011
Featuring a notched blade for securely holding wire for stripping, a serrated blade edge
and ergonomic, plastic grips for comfortable handling, this two-in-one cutting and stripping
tool effortlessly cuts and strips soft cable wire.
Electrician Scissors W/ Wire Stripping Slots & Plastic Grips
Item #11013
Featuring two slots and a notched blade for easily stripping wire and plastic
comfort handles ideal for repetitive use.
5" Stainless Steel Scissors W/Wire Stripper
Item #11012
These general-purpose electricians scissors are designed for heavy duty use. The 5"
Electrician Scissors are notched to strip 23 to 19 AWG wire. The 2" stainless steel
cutting blade features a scraper and file on the back edge of the blade.
Twist wire to strip casing
Tools for
Advancing
Innovation
AVEN
®
CR-V Steel Insulated Set - 24pcs
Item #WD541
24 piece insulated tool kit, specifically engineered for electrical work.
In accordance with IEC 60900:2004 standard and with VDE & GS approved
Kit Contents
7 Wrenches (Single opened End)
1 Pliers (Lineman)
1 Pliers (Diagonal)
3 Screwdrivers (Slotted)
4 Screwdrivers (Phillips)
7 Sockets 1/2"
1 Wrench (Sliding T)
Tool Size
Wrench, Single Open End 10, 11, 12, 13, 14, 17, 19mm
Pliers, Lineman 8"
Pliers, Diagonal Cutting 6"
Slotted Screwdriver 3*50, 4*100, 5*100mm
Phillips Screwdriver #0*50, #1*75, #2*150, #1*100mm
Socket 1/2" 10, 11, 12, 13, 14, 17, 19mm
Sliding T Type Wrench 1/2"
