SCS 4.0 - AG2330 Installation Reference Guide
Overview
The Advanced Gateway 2330 can be configured to provide a number of voice
interfaces that allow connection to the PSTN as well as support of conventional
TDM-based telephony devices.
The gateway can be configured with T1/E1 PRI, BRI, FXS and FXO interfaces
providing flexible telephony connection for SCS users.
To provide access to the PSTN, the AG2330 supports the following „small
modules‟:
Foreign Exchange Office (FXO) modules, which can also be configured
as Centralized Automatic Message Accounting (CAMA) trunks
FXS modules, which can also be configured as Direct Inward Dialing
(DID) trunks
T1 modules, configured for T1 Channel Associated Signaling (CAS)
or Integrated Services Digital Network (ISDN) Primary Rate Interface
(PRI)
E1 modules, configured for E1 R2 or ISDN PRI
ISDN Basic Rate Interface (BRI) ST / U modules
AG 2330 Installation Reference
6 NN40010-551 Issue 1.3 SCS 4.0
AG 2330 Front Panel
Required Information
The following questions should be considered for the successful installation and
configuration of the AG 2330:
Which line modules will be used with the gateway – FXO. T1 / E1, PRI,
BRI?
Will FXS modules be used to add analogue phone devices to the system?
What is the Fully Qualified Domain Name of the SCS?
What is the IP address of the SCS?
Are SRV Records in use for DNS resolution?
o If not, the fully qualified domain name will be required. For example,
scsitel2.iteluk.com
o If SRV records are in use, only the domain name is required. For
example, iteluk.com
Will the gateway be assigned to a location, to restrict its access to specific
SCS users?
AG 2330 Installation Reference
NN40010-551 Issue 1.3 SCS 4.0 7
Flow Chart
Add the Gateway‟s configuration
details to the SCS
Refer to the “SCS Configuration”
section of this guide
Which
Modules will
be used?
FXO/T1/E1
Refer to the “Gateway Configuration
from the SCS – FXO/T1/E1/PRI”
section of this guide
FXS
Refer to the SCS 4.0 Configuring User
Profiles Guide and the SCS 4.0 Device
Configuration – Gateway Guide
Configure the AG 2330 from the
command line
Refer to the “AG/SR 2330 Gateway
Configuration” section of this guide
Which Ports
will be used?
Configure the gateway‟s general
network parameters
Refer to the “General Configuration”
section of this guide
T1/EI/PRI
Refer to the “T1/E1/PRI
Configuration” section of
this guide
FXO
Refer to the “FXO
Configuration” section of
this guide
FXS
Refer to the “FXS
Configuration” section of
this guide
