PeriProducer 3.00 Release Notes
(Software Release 3.00)
Avaya Business Communications Manager
Release 6.0
Document Status: Standard
Document Number: P0605081
Document Version: 2.4
Date: June 2010
© 2010 Avaya Inc.
All Rights Reserved.
Notices
While reasonable efforts have been made to ensure that the information in this document is complete and accurate at the time of printing,
Avaya assumes no liability for any errors. Avaya reserves the right to make changes and corrections to the information in this document
without the obligation to notify any person or organization of such changes.
Documentation disclaimer
Avaya shall not be responsible for any modifications, additions, or deletions to the original published version of this documentation
unless such modifications, additions, or deletions were performed by Avaya. End User agree to indemnify and hold harmless Avaya,
Avaya’s agents, servants and employees against all claims, lawsuits, demands and judgments arising out of, or in connection with,
subsequent modifications, additions or deletions to this documentation, to the extent made by End User.
Link disclaimer
Avaya is not responsible for the contents or reliability of any linked Web sites referenced within this site or documentation(s) provided by
Avaya. Avaya is not responsible for the accuracy of any information, statement or content provided on these sites and does not
necessarily endorse the products, services, or information described or offered within them. Avaya does not guarantee that these links will
work all the time and has no control over the availability of the linked pages.
Warranty
Avaya provides a limited warranty on this product. Refer to your sales agreement to establish the terms of the limited warranty. In
addition, Avaya’s standard warranty language, as well as information regarding support for this product, while under warranty, is
available to Avaya customers and other parties through the Avaya Support Web site: http://www.avaya.com/support
Please note that if you acquired the product from an authorized reseller, the warranty is provided to you by said reseller and not by Avaya.
Licenses
THE SOFTWARE LICENSE TERMS AVAILABLE ON THE AVAYA WEBSITE, HTTP://SUPPORT.AVAYA.COM/LICENSEINFO/
ARE APPLICABLE TO ANYONE WHO DOWNLOADS, USES AND/OR INSTALLS AVAYA SOFTWARE, PURCHASED FROM
AVAYA INC., ANY AVAYA AFFILIATE, OR AN AUTHORIZED AVAYA RESELLER (AS APPLICABLE) UNDER A
COMMERCIAL AGREEMENT WITH AVAYA OR AN AUTHORIZED AVAYA RESELLER. UNLESS OTHERWISE AGREED TO
BY AVAYA IN WRITING, AVAYA DOES NOT EXTEND THIS LICENSE IF THE SOFTWARE WAS OBTAINED FROM ANYONE
OTHER THAN AVAYA, AN AVAYA AFFILIATE OR AN AVAYA AUTHORIZED RESELLER, AND AVAYA RESERVES THE
RIGHT TO T AKE LEGAL ACTION AGAINST YOU AND ANYONE ELSE USING OR SELLING THE SOFTWARE WITHOUT A
LICENSE. BY INSTALLING, DOWNLOADING OR USING THE SOFTWARE, OR AUTHORIZING OTHERS TO DO SO, YOU,
ON BEHALF OF YOURSELF AND THE ENTITY FOR WHOM YOU ARE INSTALLING, DOWNLOADING OR USING THE
SOFTWARE (HEREINAFTER REFERRED TO INTERCHANGEABLY AS "YOU" AND "END USER"), AGREE TO THESE
TERMS AND CONDITIONS AND CREATE A BINDING CONTRACT BETWEEN YOU AND AVAYA INC. OR THE
APPLICABLE AVAYA AFFILIATE ("AVAYA").
Copyright
Except where expressly stated otherwise, no use should be made of the Documentation(s) and Pr oduct( s) p rovided by Avaya. All content
in this documentation(s) and the product(s) pr ov id ed by Avaya including the selection, arrangement and design of the content is owned
either by Avaya or its licensors and is protected b y copyright and other intellectual property laws including the sui generis rights relating
to the protection of databases. You may not modify, copy, reproduce, republish, upload, post, transmit or distribute in any way any
content, in whole or in part, including any code and software. Unauthorized reproduction, transmission, dissemination, storage, and or
use without the express written consent of Avaya can be a criminal, as well as a civil offense under the applicable law.
Third Party Components
Certain software programs or portions thereof included in the Product may contain software distributed under third party agreements
("Third Party Components"), which may contain terms that expand or limit rights to use certain portions of the Product ("Third Party
Terms" ). Information regarding distributed Linux OS source code (for those Products that have distributed the Linux OS source code),
and identifying the copyright holders of the Third Party Components and the Third Party Terms that apply to them is available on the
Avaya Support Web site: http://support.avaya.com/Copyright.
Trademarks
The trademarks, logos and service marks ("Marks") displayed in this site, the documentation(s) and product(s) pr ovided by Avaya are the
registered or unregistered Marks of Avaya, its affiliates, or other third parties. Users are not permitted to use such Marks without prior
written consent from A vaya or such third party which may own the Mark. Nothing contained in this site, the documentation(s) and
product(s) should be construed as granting, by implication, estoppel, or otherwise, any license or right in and to the Marks without the
express written permission of Avaya or the applicable third party. Avaya is a registered trademark of Avaya Inc. All non-Avaya
trademarks are the property of their respective owners.
Downloading documents
For the most current versions of documentation, see the Avaya Support. Web site: http://www.avaya.c om/support
Contact Avaya Support
Avaya provides a telephone number for you to use to report problems or to ask questions about your product. The support telephone
number is 1-800-242-2121 in the United States. For additional support telephone numbers, see the Avaya Web site: http://
www.avaya.com/support
Table of Contents
Table of Contents
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
How to Use This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Organization of This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Conventions Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . 9
Solaris and Windows 2000 Conventions . . . . . . . . . . . . . . . . . . . 10
Two-Button (Windows 2000) vs. Three-Button (Solaris) Mouse 11
Trademark Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
PeriProducer 3.00 New Features and Enhancements . . . . . 13
New Features and Enhancements . . . . . . . . . . . . . . . . . . . . . . . . 14
New Blocks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Call Conferencing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Block-level Access to Protocol Data . . . . . . . . . . . . . . . . . . 14
Blocking/Non-blocking Execution . . . . . . . . . . . . . . . . . . . . 15
Resource Pool Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Saving Partial Recorded Data . . . . . . . . . . . . . . . . . . . . . . . . 15
Call Progress Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
PeriProducer Block Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connection IDs (Caller I/O blocks) . . . . . . . . . . . . . . . . . . . 16
Accessory Toolkit Blocks. . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Answer Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Continue on Ring Detect Removed . . . . . . . . . . . . . . . . 16
Get Phone Number Options Removed . . . . . . . . . . . . . . 16
Disconnect Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Abandoned Call Counter Removed . . . . . . . . . . . . . . . . 16
Speak Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Speech Recognition/Text To Speech . . . . . . . . . . . . . . . 17
Speak a URL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Read Phone Block. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
System Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Diagnostic Functions Removed . . . . . . . . . . . . . . . . . . . 17
Condition Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Send Host Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Virtual Terminal (VT) Allocation . . . . . . . . . . . . . . . . . . 17
Setting Host Environment Parameters . . . . . . . . . . . . . . 18
Receive Host Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Asynchronous Operation . . . . . . . . . . . . . . . . . . . . . . . . 18
Send Fax Block. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Fax Composition Removed . . . . . . . . . . . . . . . . . . . . . . 19
Send Fax from TIFF File . . . . . . . . . . . . . . . . . . . . . . . . 19
Fax Mode Removed . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
# P0605081 Ver: 2.3 Page 3
PeriProducer 3.00 Release Notes
Receive Fax Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Receive Fax Direct into TIFF File . . . . . . . . . . . . . . . . . 19
Saving to Named Element . . . . . . . . . . . . . . . . . . . . . . . 19
Local Station ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Fax Mode Removed . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Originate Block. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Moved Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Record Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Asynchronous Recording . . . . . . . . . . . . . . . . . . . . . . . . 20
Full Duplex Recording . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Moved Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Recorded Element Destinations . . . . . . . . . . . . . . . . . . . 20
Abort Recording using Touch Tones . . . . . . . . . . . . . . . 20
Resource Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Asynchronous Execution Changes . . . . . . . . . . . . . . . . . 20
Resource Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Discontinued Features/Functions . . . . . . . . . . . . . . . . . . . . . . . . . 21
Fax Composition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Hardware Properties Window. . . . . . . . . . . . . . . . . . . . . . . . 21
Unsupported Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Obsoleted Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Other PeriProducer Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Enhanced Condition Data . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Default Text to Speech Resource Specification . . . . . . . . . . 22
System Folder Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Environment Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Using MultiMedia Elements. . . . . . . . . . . . . . . . . . . . . . . . . 38
Deleting Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Importing and Exporting Elements . . . . . . . . . . . . . . . . . 38
Receiving Speech Recognition Resource Results . . . . . . . . 38
Miscellaneous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
VRAM Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Downward Porting of .ppr Source Code . . . . . . . . . . . . . 39
MPS Release Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Porting 2.30 Applications to 3.00 . . . . . . . . . . . . . . . . . . . . . 41
Porting 2.30 Applications to 3.00 . . . . . . . . . . . . . . . . . . . . . . . . 42
Application Porting Considerations . . . . . . . . . . . . . . . . . . . 42
Porting Standard 2.30 Toolkit Applications to 3.00 . . . . . . . . . . 42
Load into PeriProducer 3.00 . . . . . . . . . . . . . . . . . . . . . . 42
Use the PeriProducer Command Line . . . . . . . . . . . . . . 42
Porting Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Porting MPS Toolkit Applications to 3.00 . . . . . . . . . . . . . . . . . 44
MPS Toolkit Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Replace Previous MPS Toolkit . . . . . . . . . . . . . . . . . . . . 44
Page 4 # P0605081 Ver: 2.3
Table of Contents
Load into PeriProducer 3.00 . . . . . . . . . . . . . . . . . . . . . . 45
Use the PeriProducer Command Line . . . . . . . . . . . . . . 45
Known Conversion Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Set Resource Label in 2.30 . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Unsupported 2.30 Resources . . . . . . . . . . . . . . . . . . . . . . . . 47
Resource Block Conversions . . . . . . . . . . . . . . . . . . . . . . . . 47
Flushing the Speak Prompt Buffer . . . . . . . . . . . . . . . . . . . . 48
System Transfer Connection ID Datacard . . . . . . . . . . . . . . 48
Automatic Detection of Speech or DTMF Input (AUTOID) 48
# P0605081 Ver: 2.3 Page 5
PeriProducer 3.00 Release Notes
This page has been intentionally left blank.
Page 6 # P0605081 Ver: 2.3
Preface
PeriProducer 3.00 Release Notes
Scope
The manual PeriProducer 3.00 Release Notes provides a summary of new features
and enhancements to PeriProducer 2.30.
This manual does not describe PeriProducer 3.00 features and enhancements in detail.
For a more complete description, see the PeriProducer User’s Guide.
Intended Audience
This manual is intended for application developers of Avaya Media Processing Server
(MPS) using the PeriProducer graphical application development tool. A basic
understanding of the PeriProducer product as well as attendance in a PeriProducer
training course is highly recommended.
How to Use This Manual
This manual uses many standard terms relating to computer system, software
application functions, and the Internet. However, it contains some terminology that
can only be explained in the context of the MPS system. Refer to the Glossary of
Avaya Media Processing Server Terminology for definitions of MPS specific terms.
Initially, you should read this manual at least once, from start to finish. Later, you can
use the Table of Contents to locate topics of interest for reference and review.
If you are reading this document online, use the cross-reference links (shown in blue)
to quickly locate related topics. <L
with your cursor over the cross-reference link. Click on any point in a Table of
Contents entry to move to that topic. Click on the page number of any Index entry to
access that topic page.
To familiarize yourself with various specialized textual references within the manual,
see Conventions Used in This Manual on page 9.
Periphonics is now part of Avaya. The name Periphonics, and variations thereof,
appear in this manual only where it is referred to in a product. (For examples, a
PeriProducer application, the PERImps package, the perirev command, etc.)
EFT> click once with your mouse while positioned
Page 8 # P0605081 Ver: 2.3
Organization of This Manual
The chapters are as follows:
Chapter 1 — PeriProducer 3.00 New Features and Enhancements
Discusses features and enhancements new to PeriProducer 3.00 and related materials.
Chapter 2 — Porting 2.30 Applications to 3.00
Outlines procedures and configurations for porting applications made with
PeriProducer 2.30 and bringing them into PeriProducer 3.00.
Procedures for installing PeriProducer (as part of the complete MPS software
package) are included in the Installing MPS Software on the Solaris Platform and
Installing MPS Software on the Windows Platform.
Conventions Used in This Manual
Preface
This manual uses different fonts and symbols to differentiate between document
elements and types of information. These conventions are summarized in the
following table.
Conventions Used in This Manual Sheet 1 of 2
Notation Description
Normal text
important term
system
command
command,
condition
and alarm
file name /
directory
Normal text font is used for most of the document.
The Italics font is used to introduce new terms, to highlight
meaningful words or phrases, or to distinguish specific terms from
nearby text.
This font indicates a system command and/or its arguments. Such
keywords are to be entered exactly as shown (i.e., users are not to
fill in their own values).
Command, Condition and Alarm references appear on the screen
in magenta text and reference the Command Reference Manual,
the PeriProducer User’s Guide, or the Alarm Reference Manual,
respectively. Refer to these documents for detailed information
Commands, Conditions, and Alarms.
about
This font is used for highlighting the names of disk directories, files,
and extensions for file names. It is also used to show displays on
text-based screens (e.g., to show the contents of a file.)
on-screen field
<KEY NAME>
This font is used for field labels, on-screen menu buttons, and
action buttons.
A term that appears within angled brackets denotes a terminal
keyboard key, a telephone keypad button, or a system mouse
button.
# P0605081 Ver: 2.3 Page 9
PeriProducer 3.00 Release Notes
Notation Description
Conventions Used in This Manual Sheet 2 of 2
Book Reference
cross reference
!
This font indicates the names of other publications referenced
within the document.
A cross reference is shown on the screen in blue. Click on the
cross reference to access the referenced location. A cross
reference that refers to a section name accesses the first page of
that section.
The Note icon identifies notes, important facts, and other keys to
understanding.
The Caution icon identifies procedures or events that require
special attention. The icon indicates a warning that serious
problems may arise if the stated instructions are improperly
followed.
The flying Window icon identifies procedures or events that apply
to the Windows 2000 operating system only.
The Solaris icon identifies procedures or events that apply to the
Solaris operating system only.
2
1
1. Windows 2000 and the flying Window logo are either trademarks or registered
trademarks of the Microsoft Corporation.
2. Solaris® is a registered trademark of The Open Group in the U.S. and other
countries.
Solaris and Windows 2000 Conventions
This manual depicts examples (command line syntax, configuration files, and screen
shots) in Solaris format. In certain instances Windows 2000 specific commands,
procedures, or screen shots are shown where required. The following table lists
examples of general operating system conventions to keep in mind when using this
manual with either the Solaris or Windows operating system.
Solaris Windows 2000
Environment $MPSHOME %MPSHOME%
Paths $MPSHOME\common\etc %MPSHOME%\common\etc
Command <command> & start /b <command>
Page 10 # P0605081 Ver: 2.3
Preface
Two-Button (Windows 2000) vs. Three-Button (Solaris) Mouse
<SELECT> Left button
<ADJUST> Left and Right
<MENU> Right button
Trademark Conventions
The following trademark information is presented here and applies throughout for
third party products discussed within this manual. Trademarking information is not
repeated hereafter.
Solaris
other countries.
Solaris, SunOS, OpenWindows, SPARC, and UltraSPARC are trademarks or
registered trademarks of Sun Microsystems, Inc. in the United States and other
countries.
®
<SELECT> Left button
<ADJUST> Middle button
together
<MENU> Right button
and Motif® are registered trademarks of The Open Group in the U.S. and
Microsoft, MSSQL, Windows, Windows 2000, Internet Explorer, and the Flying
Windows logo are either trademarks or registered trademarks of Microsoft
Corporation.
®
Oracle
Sybase
Informix
is a registered trademark of Oracle Corporation.
™
and SYBASE™ are trademarks of Sybase, Inc. or its subsidiaries.
®
and INFORMIX® are registered trademarks of Informix Corporation or its
affiliates.
# P0605081 Ver: 2.3 Page 11
PeriProducer 3.00 Release Notes
This page has been intentionally left blank.
Page 12 # P0605081 Ver: 2.3
PeriProducer 3.00
New Features and
Enhancements
This chapter covers:
1. New Features and Enhancements
2. PeriProducer Block Changes
3. Discontinued Features/Functions
4. Other PeriProducer Changes
PeriProducer 3.00 Release Notes
New Features and Enhancements
New Blocks
The following blocks are new to PeriProducer 3.00:
Block Function
Abort Abort input/output
Bridge Perform bridging functions (moved from Originate block in
Call Control Send data to telephony protocol layer/perform a hookflash
Call Conferencing Manage conference call functions
Call Progress Detection Manage call progress detection functions
Edit Sequence Manage touch tone input editing and user edit sequences
Line Operations Perform phone line operations (e.g., offer call, accept call,
PeriProducer 2.30)
(moved from Originate block in PeriProducer 2.30)
get line/application resource from pool)
Media Operations Perform operations on MultiMedia File elements or audio
files
Select Input * Not currently implemented
See the PeriProducer 3.00 User’s Guide for full descriptions of the blocks.
Call Conferencing
Call Conferencing allows up to 16 full participants (or 15 full participants with 19
listen port callers) to connect to a call. Per-line talk and listen privileges can be set at
the start of a conference and dynamically changed during the conference. Call
Conferencing includes the "coaching" feature which allows a conference
administrator (a "coach") to talk to another person in the conference (a "student") and
have the speech output heard only by the student.
The actual number of ports available on a system is determined by the DSP
configuration.
Block-level Access to Protocol Data
Telephone line function blocks (Answer, Disconnect, Call Control, Originate) can
send/receive protocol data directly to/from the telephony protocol layer using built-in
block functions. Specify data to send (or receive) using standard PeriProducer data
cards or literals (send only).
Page 14 # P0605081 Ver: 2.3
PeriProducer 3.00 New Features and Enhancements
Blocking/Non-blocking Execution
Many PeriProducer blocks allows the option of choosing blocking (execution waits at
that block until it receives success/failure message) or non-blocking (execution
continues to next block without waiting for message) execution. A "Wait" checkbox
enables/disables blocking execution for the applicable blocks. See Blocking/Nonblocking Operation in the PeriProducer 3.00 User’s Guide for details.
Resource Pool Support
The MPS allows resources (such as phone lines and applications) to be defined in the
configuration files as shared pools. In the appropriate blocks (e.g., Line Operations),
PeriProducer provides built-in block access to these resources.
Saving Partial Recorded Data
PeriProducer saves partially received Caller Message Recording messages and faxes
in the event of a receive failure. The partial data is either stored in a new file (if
receiving directly into a file) or the application receives a Media Storage token which
references an element in a MultiMedia File. This behavior can be optionally enabled
and disabled in a Record block.
Call Progress Detection
Using Call Progress Detection (CPD) is updated in PeriProducer 3.00. CPD is
controlled by dynamically enabling and disabling specific tone/event detection in the
Call Progress Detection block. All CPD events return to the application as the cpd
condition with the specific event (Busy, Reorder, etc.) in the condition data. See the
PeriProducer 3.00 User’s Guide for details.
# P0605081 Ver: 2.3 Page 15
PeriProducer 3.00 Release Notes
PeriProducer Block Changes
Connection IDs (Caller I/O blocks)
Phone line and resource numbers are replaced with Connection IDs (CIDs).
Connection IDs indicate the component name and the line number of the connection.
For example, the CID "mps24.1" indicates the connection is from line one on
component "mps24". The default Connection ID for the current phone line is available
in the System folder’s DefaultCID data card. The CID for an operation is supplied by
the system (e.g., when a resource is allocated).
Accessory Toolkit Blocks
The Table Search, Table Sort, Date Calculations, and Send email blocks moved from
the main toolkit to the accessory toolkit.
Answer Block
Continue on Ring Detect Removed
The "Continue on Ring Detect" option is removed. In general, use the "Get Call" ->
"Alert Call" states to accomplish the same result.
Get Phone Number Options Removed
The Get Dialed Phone Number and Get Caller’s Phone Number options are removed.
Depending on the specific telephony protocol, this information is automatically
returned by the system for all Answer block actions (except "Reject Call").
Disconnect Block
Abandoned Call Counter Removed
The MPS does not automatically track system abandoned calls. The "Mark as
abandoned" option is removed. To track abandoned calls, create application statistics
and use PeriReporter to display the reports.
Page 16 # P0605081 Ver: 2.3
PeriProducer 3.00 New Features and Enhancements
Speak Block
Speech Recognition/Text To Speech
All speech recognition and synthesis functions are performed by external resources.
Refer to the appropriate resource guides for details on using the resource for optimal
programming results.
Speak a URL
The element to speak can be specified by a valid URL address (e.g.,
http://server1/prompts/greeting1.wav).
Read Phone Block
The Read Phone Block now handles Speech Recognition Errors and provides a failure
path for a recognition error. The following recognition errors cause the application to
follow the "Recognition Error" path:
• Speech Too Early
• Too Much Speech
• Too Slow Recognition
System Block
Diagnostic Functions Removed
The diagnostics function is removed.
Condition Data
The "Get Condition Data" function is added. This replaces using the condition-data
call function. "Get Condition Data" requires a folder with the same structure, data
names, and data types expected with the condition (see Enhanced Condition Data on
page 22).
Send Host Block
Virtual Terminal (VT) Allocation
VT allocation functions are available from the Send Host block. These replace the VT
allocation Environment block options.
# P0605081 Ver: 2.3 Page 17
PeriProducer 3.00 Release Notes
Setting Host Environment Parameters
Host environment parameters are sent from the Send Host block. This function
replaces the Environment block "host" option.
new VT options
parameter option
Receive Host Block
Asynchronous Operation
The "Asynchronous" checkbox is replaced by the "Wait" checkbox (see
Blocking/Non-blocking Execution on page 15). Receive Host operates
asynchronously when the "Wait" checkbox is unchecked.
Page 18 # P0605081 Ver: 2.3
PeriProducer 3.00 New Features and Enhancements
Send Fax Block
Fax Composition Removed
The fax Composition feature is not supported. All controls/options used to create and
store composed faxes are removed.
Send Fax from TIFF File
PeriProducer 3.0 supports sending faxes directly from TIFF format files. TIFF faxes
no longer need to be imported into a MultiMedia File and accessed by a media storage
token (this is still supported).
Fax Mode Removed
PeriProducer 3.0 supports only Group 3 faxes.
Receive Fax Block
Receive Fax Direct into TIFF File
Applications can save an incoming fax directly to a TIFF-format file. In previous
versions of PeriProducer, faxes were stored in MultiMedia Files and had to be
exported to individual TIFFs.
Saving to Named Element
A fax can be saved to a specific-named element in a MultiMedia File. If the
application does not specify an element name, the fax is stored as a new element and
can be accessed by the returned media storage token.
Local Station ID
The Local Station ID (which typically represents the phone number of the station
receiving the fax) can be specified in the block. The Local Station ID is typically
displayed on the transmitting fax machine.
Fax Mode Removed
PeriProducer 3.0 supports only Group 3 faxes.
Originate Block
Moved Functions
All bridging functions are moved to the new 3.00 Bridge Block. Hookflash is moved
to the Call Control Block. The End Transfer function is deleted (the Disconnect block
can be used for this purpose).
# P0605081 Ver: 2.3 Page 19
PeriProducer 3.00 Release Notes
Record Block
Asynchronous Recording
Asynchronous recording allows for an unlimited duration message. Asynchronous
recording is explicitly started and stopped by "Begin" and "End" functions of the
Record block.
Full Duplex Recording
Full duplex recording saves all audio that occurs on a phone line, caller and system.
For example, an application can record a full conversation between a caller and a
referral agent. Recording can also be set to record either caller-only or system-only
output.
Moved Functions
Element deletion functions moved to the Media Operations Block.
Recorded Element Destinations
PeriProducer 3.00 supports recording directly into a specified audio format file
(typically WAV). Applications can also append recordings to existing MMF elements.
Abort Recording using Touch Tones
Callers can abort CMR recordings using a touch tone(s). Note that this differs from
using a touch tone to terminate (and subsequently save) a recording.
Resource Block
Asynchronous Execution Changes
There is no longer an "Async" checkbox in the Resource block. To perform the
resource receive asynchronously, uncheck the "Wait" box.
Resource Support
The following new resources are available in the Resource block: lvr-p, lvr-s, extts-r,
sip, DTMF, Player, Fax, Recorder, FullDuplex Recorder. Many resources are no
longer supported (see Unsupported Resources on page 21).
Page 20 # P0605081 Ver: 2.3
PeriProducer 3.00 New Features and Enhancements
Discontinued Features/Functions
Fax Composition
Fax composition is not supported in PeriPro 3.00. Faxes to be sent must be created by
external applications or received (and stored for later use) by the MPS.
Hardware Properties Window
The Hardware Properties Window is removed.
Unsupported Resources
The following resources are no longer supported in PeriProducer 3.00:
•mps
•abb
•asdi
•ast
•iwr
•ppd
•modem
•mts
•iscp
•ctx
•lcr
Obsoleted Functions
The Media Operations block in PeriProducer has obsoleted the file-to-message,
message-to-item and message-to-file functions.
# P0605081 Ver: 2.3 Page 21
PeriProducer 3.00 Release Notes
Other PeriProducer Changes
Enhanced Condition Data
Condition Data is now returned as a data structure consisting of different field/value
pairs. To access the expanded condition data, use the System block’s "Get Condition
Data" function and specify the appropriate response folder (templates provided in
$PPROHOME/sample/folders). To access all of the condition data, the folder
must have data cards defined as the same name and type as the associated condition
data field. The data for one field only can be obtained by specifying a datacard whose
name matches the desired field.
The condition data for many conditions have a "Status" field. The Status field value is
automatically copied into the System folder’s ConditionData card.
Default Text to Speech Resource Specification
To specify a default external Text to Speech resource (used with implicit resource
allocation for all "Speak as TTS" prompts), use the System folder’s DefaultTTSRsrc
datacard. The default value for DefaultTTSRsrc is "extts-b". This replaces the Text To
Speech Resource setting in the Hardware properties window of PeriProducer 2.30.
System Folder Changes
• The Constant TTSvoice card is no longer available.
• The ConfidenceLevel card is no longer available.
• The following constants are added:
•None
•All
•Any
•Flush
•On
•Off
• Speech ("S" to identify speech input)
• DTMF ("D" to identify DTMF input)
• The following datacards are added:
• AutoDetectTime
• DefaultCID
• DefaultOutPool
• TransferCID
• DefaultTTSRsc
• ApplicationNumber (replaces LineNumber)
Page 22 # P0605081 Ver: 2.3
PeriProducer 3.00 New Features and Enhancements
Environment Options
Many PeriProducer 2.30 Environment options have been obsoleted or replaced by
new environment options and/or block built-in functions in PeriProducer 3.00. The
following table lists the 2.30 Environment options and the analogous 3.00 option (if
any). Comments are provided where appropriate.
Environment Options Conversions Sheet 1 of 7
2.30 Environment Option 3.00 Equivalent
Phone Environment
answer Unsupported as environment option. Use the Answer block
(Answer function) to answer a call.
bargein Supported for legacy applications only
bargeinevent Unsupported (for legacy applications, this is an implied "start
of speech" event)
edit Unsupported as environment option. Use the Edit Sequence
Block to enable/disable DTMF input editing.
ekeybd Unsupported
emess Unsupported
eopt Unsupported
eretry Unsupported
first DtmfFirst (Application and System Environment options)
fkeybd Unsupported
fmess Unsupported
fopt Unsupported
fretry Unsupported
ikeybd Unsupported
imess Unsupported
inter DtmfInter (Application and System Environment options)
iopt Unsupported
iretry Unsupported
keepterm Unsupported as environment option. Use the "Retain" option
(for the termination character) in Edit Sequence block.
termchar Unsupported as environment option. Use the Edit Sequence
block to enable/set a termination character.
timeout Unsupported
tnabort Unsupported
tnext Unsupported
# P0605081 Ver: 2.3 Page 23
PeriProducer 3.00 Release Notes
2.30 Environment Option 3.00 Equivalent
tnull Unsupported
total LineTotalCall (Application and System Environment options)
trepeat Unsupported
typeahead Unsupported
tzone Unsupported
Phone Line Task Environment
autoid Supported for legacy applications only
backsp Unsupported as environment option. Use the Edit Sequence
busy LineStandbyMode, set to Busy (Application and System
callref Unsupported
delete Unsupported
Environment Options Conversions Sheet 2 of 7
block to enable/set a backspace edit sequence.
Environment options)
eXtext Unsupported. Use the Edit Sequence block to enable/set
user edit sequences.
getring Unsupported as environment option. Use the Answer block
"Get Call" and "Alert Call" functions to continue application
processing without answering the line.
noanswer LineStandbyMode, set to NoAnswer (Application and
System Environment options)
repeat Unsupported
vrepeat Unsupported
xterm Unsupported
Phone Resource Server Environment
prs Unsupported
abeep Unsupported
asetup Unsupported
cdtmf Unsupported
echo Unsupported
idle Unsupported
mdeblock Unsupported
rscconfig RscConfig (Application and System Environment options)
smaxlen Unsupported
smaxres Unsupported as environment option
Page 24 # P0605081 Ver: 2.3
PeriProducer 3.00 New Features and Enhancements
Environment Options Conversions Sheet 3 of 7
2.30 Environment Option 3.00 Equivalent
sminlen Unsupported as environment option
srecord Unsupported as environment option
tfield Unsupported as environment option
tfinal Unsupported as environment option
tfirst Unsupported
tstop Unsupported as environment option
Message Recording Environment
firstsil RecFirstSil (Application and System Environment options)
intersil RecInterSil (Application and System Environment options)
maxreclength Unsupported
silstrip RecSilStrip (Application and System Environment options)
Call Origination/Referral Environment
bctt Unsupported
bcvoc Unsupported
brtt Unsupported
brvoc Unsupported
hctt Unsupported
hcvoc Unsupported
hrtt Unsupported
hrvoc Unsupported
number Unsupported
pdial Unsupported
reftot Unsupported
tpickup Unsupported
vbridge Unsupported
Call Progress Detection Environment
cpansup Unsupported
cpdial Unsupported
cpdisc Unsupported
decide Unsupported
notone Unsupported
pickup Unsupported
# P0605081 Ver: 2.3 Page 25
PeriProducer 3.00 Release Notes
2.30 Environment Option 3.00 Equivalent
rsilence Unsupported
rvoice Unsupported
silence Unsupported
stop Unsupported
tone Unsupported
voice Unsupported
window Unsupported
Speech Management Environment
clear Supported for legacy applications only. Use the Abort block
vioabort Unsupported as environment option. Use the Abort block.
Host Environment
Environment Options Conversions Sheet 4 of 7
with the "Caller I/O Only" option enabled.
er er
freevt Supported for legacy applications only. Use the Send Host
block "Free VT" (in Control > Function > Controls) option.
getvt Supported for legacy applications only. Use the Send Host
block "Get VT" (in Control > Function > Controls) option.
headermode headermode
hostctl hostctl
intime intime
parameter Supported for legacy applications only. Use the Send Host
block "parameter" (in Function > Controls) option.
refer refer
rfno rfno
session session
setaid setaid
unlocks unlocks
usepool usepool
Advanced Phone Line Management
phone Unsupported as environment option
capdtmf Unsupported as environment option
capmf Unsupported as environment option
captdd Unsupported as environment option
detect Supported for legacy applications only
Page 26 # P0605081 Ver: 2.3
PeriProducer 3.00 New Features and Enhancements
Environment Options Conversions Sheet 5 of 7
2.30 Environment Option 3.00 Equivalent
dfirst Unsupported as environment option
dinter Unsupported as environment option
disc Unsupported
dtmf DtmfToneDur (Application and System Environment options)
eline Unsupported
endtone Unsupported
fconnect Supported for legacy applications only. Use the Answer
block "Answer Call" function.
finish Unsupported
flash Unsupported
gobusy Unsupported
guard DtmfGuard (Application and System Environment options)
indial Unsupported
keyin Unsupported
keyout Unsupported
mftone Unsupported
nansup Unsupported
nofhook Unsupported as environment option. Use the Answer block
"Get Call" and "Alert Call" functions.
rend Unsupported
reortext Unsupported
ringback Unsupported
ringtext Unsupported
rline Unsupported
rvalid Unsupported
sendcp Unsupported
ISDN Environment
cats Unsupported as environment option. Use the "Protocol Data"
fields in the Answer, Disconnect, Originate, and Call Control
blocks (as appropriate).
ccode Unsupported as environment option. Use the "Protocol Data"
fields in the Answer, Disconnect, Originate, and Call Control
blocks (as appropriate).
# P0605081 Ver: 2.3 Page 27
PeriProducer 3.00 Release Notes
2.30 Environment Option 3.00 Equivalent
cproc Unsupported as environment option. Use either the
smrt Unsupported as environment option. Use the "Protocol Data"
udata Unsupported as environment option. Use the "Protocol Data"
Optional Exception Conditions
crefer Unsupported as environment option
crepeat Unsupported as environment option
rngback Unsupported as environment option
Environment Options Conversions Sheet 6 of 7
"Protocol Data" fields in the Answer, Disconnect, Originate,
and Call Control blocks (as appropriate), or the Answer block
"Proceeding Call", function. Refer to the protocol-specific
documentation for details on sending call state information.
fields in the Answer, Disconnect, Originate, and Call Control
blocks (as appropriate).
fields in the Answer, Disconnect, Originate, and Call Control
blocks (as appropriate).
uedit3 Unsupported as environment option (in the context of taking
a digital system out of wait for an outdial complete message)
Generic Environment Options
Phone Line Manager
Options
Speech Manager Options Superseded by "Application and System Options"
Host Manager Options Superseded by "Host Environment"
Vengine Options Vengine Options
PeriWeb Options PeriWeb Options
VENGINE Environment
alarmdbtask alarmdbtask
apprestart apprestart
centurymark centurymark
debug debug
deltimedcall deltimedcall
hnowait Unsupported (a corresponding VENGINE runtime option is
Superseded by "Application and System Options"
available)
intermsg intermsg
maxmessage Unsupported
mode mode
notice notice
Page 28 # P0605081 Ver: 2.3
PeriProducer 3.00 New Features and Enhancements
Environment Options Conversions Sheet 7 of 7
2.30 Environment Option 3.00 Equivalent
numset numset
rscertime rscertime
rscintime rscintime
setvpsline setvpsline
softterm softterm
speak speak
timedcall timedcall
unnotice unnotice
vmstimedcall vmstimedcall
vpsrcvtime vpsrcvtime
webtimeout webtimeout
Conditions
When a PeriProducer 2.30 application is opened in 3.00, PeriProducer attempts to
automatically convert handle conditions to their counterparts in 3.00. Condition
conversions shown with a preceding dollar sign ("$") are displayed in the application
as the 2.30 condition but are automatically converted to the appropriate 3.00 condition
at runtime.
The following table lists the 2.30 condition, the corresponding 3.00 condition (if any),
and how PeriProducer 3.00 converts the condition when a 2.30 application is ported to
3.00.
Conditions Conversion Sheet 1 of 10
2.30 Condition 3.00 Condition Conversion
abend abend abend
addfail importfail w/Status
"ErrInUse" in condition data
addsucc importcmp importcmp
altlinkdown altlinkdown altlinkdown
ansfail answerfail answerfail
$addfail
asrdet asrdet asrdet
asyncdata Unsupported
# P0605081 Ver: 2.3 Page 29
PeriProducer 3.00 Release Notes
2.30 Condition 3.00 Condition Conversion
asyncfail Unsupported
autofail detinputfail detinputfail
autotim autotim autotim
avserr avserr avserr
badoperation badoperation badoperation
badparameter badparameter badparameter
calltim calltim calltim
carloss Unsupported
ccs7cc ccs7cc ccs7cc
Conditions Conversion Sheet 2 of 10
chartim getinputfail w/Status
"ErrInter" field in condition
data
cmrhigh Unsupported
cmrlow Unsupported
comfail comfail comfail
conn answercmp answercmp
crefer Unsupported
crepeat Unsupported
crepmax Unsupported
cticond cticond cticond
ctidown ctidown ctidown
ctifail ctifail ctifail
ctiup ctiup ctiup
ctxcc Unsupported
ctxfailcc Unsupported
ctxokcc Unsupported
getinputfail
cvoice Unsupported
dcdown Unsupported
dcup Unsupported
deadlock deadlock deadlock
delcomp delcmp delcmp
delfail delfail delfail
dialtn Unsupported
Page 30 # P0605081 Ver: 2.3
PeriProducer 3.00 New Features and Enhancements
Conditions Conversion Sheet 3 of 10
2.30 Condition 3.00 Condition Conversion
disable Unsupported
disc Dependent upon event which caused disc condition.
disc (caller hangup) $disc
disccmp (system-initiated
disconnect)
discfail discfail w/Status field in
condition data
dtmfzl recordfail w/Status
"ErrZeroLengthDTMF" in
condition data
dupkey dupkey dupkey
dupvalidx dupvalidx dupvalidx
enable Unsupported
endfail discfail $endfail
endfile endfile endfile
error error error
ertimeout Dependent upon event which caused ertimeout condition
ertimeout (gen’d by
VENGINE)
hrcvmapfail w/Status
"ErrTimeout" in condition
data (failed receive map)
$disc
$discfail
recordfail
$ertimeout
$ertimeout
hrcvtxtfail w/Status
"ErrTimeout" in condition
data (failed receive text)
expired expired expired
faxdet faxdet faxdet
forcefree forcefree forcefree
forward Unsupported
fromphone fromphone fromphone
frstim getinputfail w/Status
"ErrFirst" in condition data
ftomfail Unsupported
ftomsucc Unsupported
$ertimeout
getinputfail
# P0605081 Ver: 2.3 Page 31
PeriProducer 3.00 Release Notes
2.30 Condition 3.00 Condition Conversion
getfail Dependent upon event which caused getfail condition
Conditions Conversion Sheet 4 of 10
getfail (gen’d by VENGINE) $getfail
getrsrcfail (failed resource
get request)
rcvfaxfail w/Status
"ErrNoFaxAvail" in condition
data (failed receive fax when
fax not available)
sndfaxfail w/Status
"ErrNoFaxAvail" in condition
data (failed send fax when
fax not available)
getvtfail hgetvtfail hgetvtfail
getvtpass hgetvtcmp hgetvtcmp
gotres Dependent upon event which caused gotres condition
getrsrccmp $gotres
rcvfaxcmp $gotres
sndfaxcmp $gotres
green Unsupported
hctloff hctloff hctloff
hctlon hctlon hctlon
$getfail
$getfail
$getfail
heldres Unsupported
hkfcomp hookflshcmp hookflshcmp
hkffail hookflshfail hookflshfail
hostasyncevt hostasyncevt hostasyncevt
hostdown hostdown hostdown
Page 32 # P0605081 Ver: 2.3
PeriProducer 3.00 New Features and Enhancements
Conditions Conversion Sheet 5 of 10
2.30 Condition 3.00 Condition Conversion
hostfail Dependent upon event which caused hostfail condition
hrcvmapfail w/Status
"ErrNoData" or "ErrTimeout"
in condition data (failed to
receive map)
hrcvtxtfail w/Status
"ErrNoData" or "ErrTimeout"
in condition data (failed to
receive text)
hsndmapfail (failed to send
map)
hsndtxtfail (failed to send
text)
hsndaidfail (failed to send
AID key)
hostup hostup hostup
hstatdata hstatdata hstatdata
idle Unsupported
inf Dependent upon event which caused inf condition
inf (gen’d by VENGINE) $inf
rcvfaxfail w/Status
"ErrNoFaxAvail" in condition
data (failure to receive fax)
$hostfail
$hostfail
$hostfail
$hostfail
$hostfail
$inf
recordfail w/Status
"ErrZeroLengthDTMF" or
"ErrZeroLengthSilence" in
condition data (failure to
record CMR message)
intertimeout intertimeout (gend’ by
VENGINE)
invreq invreq invreq
ioerr ioerr ioerr
iscpf iscpf iscpf
isdncc Unsupported
iupdbusy Unsupported
iupdcomp Unsupported
iupdfail Unsupported
lengerr lengerr lengerr
linkdown linkdown linkdown
$inf
$intertimeout
# P0605081 Ver: 2.3 Page 33
PeriProducer 3.00 Release Notes
2.30 Condition 3.00 Condition Conversion
lockfail lockfail lockfail
logdeny logdeny logdeny
lost Unsupported
marshall mailshall marshall
mmfhigh mmfhigh mmfhigh
mmflow mmflow mmflow
modvar modvar modvar
mpscc Unsupported
mpsinfo Unsupported
mpsoc Unsupported
mpsof Unsupported
mtoffail exportfail exportfail
Conditions Conversion Sheet 6 of 10
mtofsucc exportcmp exportcmp
nilobjref nilobjref nilobjref
nonexistobj nonexistobj nonexistobj
norecfound norecfound norecfound
norestart norestart norestart
nospace nospace nospace
notfnd notfnd notfnd
notimpl notimpl notimpl
notlogon notlogon notlogon
notopen notopen notopen
oa speakcmp w/Status "Abort"
in condition data
oc Dependent upon event which caused oc condition
speakcmp w/Status "Done"
in condition data (completed
speak request)
sndfaxcmp (completed send
fax)
speakcmp
$oc
$oc
sndrsrccmp (completed
send resource)
$oc
Page 34 # P0605081 Ver: 2.3
PeriProducer 3.00 New Features and Enhancements
Conditions Conversion Sheet 7 of 10
2.30 Condition 3.00 Condition Conversion
of Dependent upon event which caused of condition
of (gen’d by VENGINE) $of
sndfaxfail w/Status
"ErrNoFaxAvail" in condition
data (failed send fax)
sndrsrcfail (failed send
resource)
speakfail (failed speak
request)
ofaxdet Unsupported
orberr orberr orberr
oscoc sndrsrccmp
oscof sndrsrcfail
outbad origfail w/Status
"ErrInvalidLineState" in
condition data
outbsy origfail w/Status "ErrBusy" in
condition data
outcomp origcmp origcmp
outfail origfail w/Status "ErrBusy",
"ErrInvalidLineState",
ErrNoAnswer", or
"ErrRejected" in condition
data
$of
$of
$of
origfail
origfail
$outfail
outnoa origfail w/Status
"ErrNoAnswer" in condition
data
outrej origfail w/Status
"ErrRejected" in condition
data
outvoa Unsupported
pgid pgid pgid
pgml pgml pgml
pgun pgun pgun
prsfree Dependent upon event which caused prsfree condition
prsfree (gen’d by VENGINE) $prsfree
freersrccmp (completed free
resource)
qiderr qiderr qiderr
origfail
origfail
$prsfree
# P0605081 Ver: 2.3 Page 35
PeriProducer 3.00 Release Notes
2.30 Condition 3.00 Condition Conversion
qzero qzero qzero
rcverr rcvrsrcfail $rcverr
rcvnull Dependent upon event which caused rcvnull condition
Conditions Conversion Sheet 8 of 10
rcvnull (gen’d by VENGINE) $rcvnull
hrcvmapfail w/Status
"ErrNoData" in condition
data (failed receive map)
hrcvtxtfail w/Status
"ErrNoData" in condition
data (failed receive text)
rcvoice Unsupported
rdcdown Unsupported
rdcup Unsupported
rdisable Unsupported
red Unsupported
refbad transferfail w/Status
"ErrInvalidLineState" in
condition data
refbeg transfercmp transfercmp
refcan disccmp $refcan
reffail transferfail w/Status
"ErrInvalidLineState" or
"ErrRejected" in condition
data
$rcvnull
$rcvnull
transferfail
$reffail
refrej transferfail w/Status
"ErrRejected" in condition
data
reftim calltim $reftim
renable Unsupported
reorder Unsupported
resumefail resumefail resumefail
rgreen Unsupported
ring alertcmp alertcmp
rinfail alertfail alertfail
rlost Unsupported
rngback Unsupported
transferfail
Page 36 # P0605081 Ver: 2.3
PeriProducer 3.00 New Features and Enhancements
Conditions Conversion Sheet 9 of 10
2.30 Condition 3.00 Condition Conversion
rred Unsupported
rscoc rscoc rscoc
rscof rscof rscof
rsilence Unsupported
rvoice Unsupported
rxdcdown Unsupported
rxdcup Unsupported
rxdisable Unsupported
ryellow Unsupported
sentcp sndtonecmp sndtonecmp
serverdown serverdown serverdown
setfail ctrlrsrcfail $setfail
setres ctrlrsrccmp ctrlrsrccmp
silence Unsupported
silzl recordfail w/Status
"ErrZeroLengthSilence" in
condition data
softterm softterm softterm
sqlerr sqlerr sqlerr
sslfail sslfail sslfail
stoptim Unsupported
stpring Unsupported
tcapcc tcapcc tcapcc
tftprecfail tftprecfail tftprecfail
tftprecsucc tftprecsucc tftprecsucc
tftpsendfail tftpsendfail tftpsendfail
tftpsendsucc tftpsendsucc tftpsendsucc
timeres timeres timeres
toomanyrows toomanyrows toomanyrows
recordfail
tophonefail tophonefail tophonefail
ttdata getinputcmp getinputcmp
ttdet ttdet ttdet
# P0605081 Ver: 2.3 Page 37
PeriProducer 3.00 Release Notes
2.30 Condition 3.00 Condition Conversion
Conditions Conversion Sheet 10 of 10
ttfail getinputfail w/Status
"ErrFirst" in condition data
uedit0 - uedit3 uedit0 - uedit3 uedit0 - uedit3
unexdata unexdata unexdata
unexhost unexhost unexhost
unexphone unexphone unexphone
valueperr valueperr valueperr
voice Unsupported
vrto vrto vrto
webfail webfail webfail
webtimeout webtimeout webtimeout
xdisable Unsupported
xmtcomp Unsupported
xmtfail Unsupported
yellow Unsupported
$ttfail
Using MultiMedia Elements
Deleting Elements
In PeriProducer 3.00, delete MMF elements using the Media Operations block
"Delete" function. The System Block "Delete MS Token or Vocabulary Item"
function is still available, but does not provide a failure path connector as does the
Media Operations block.
Importing and Exporting Elements
In PeriProducer 3.00, import and export MMF elements using the Media Operations
block "Import" and "Export" functions. The associated call functions are still
available, but using the System block does not provide a failure path connector as does
the Media Operations block.
Receiving Speech Recognition Resource Results
If the system uses DTMF detection and speech recognition, the application does not
need to start autoid and handle detection conditions (asrdet/ttdet). The Read
Phone operation passes back a field to the application which indicates the source of
the input (speech or DTMF, accordingly).
Page 38 # P0605081 Ver: 2.3
PeriProducer 3.00 New Features and Enhancements
Play the initial prompts with "Accept Input..." to allow for both DTMF and speech
input. To allow speech recognition bargein, enable the Prompt Interrupt feature (click
the button).
Miscellaneous
VRAM Language
VRAM is no longer supported.
Downward Porting of .ppr Source Code
Source code cannot be ported to previous versions of PeriPro.
MPS Release Level
You must use PeriPro 3.0 on MPS 2.1 or above.
# P0605081 Ver: 2.3 Page 39
PeriProducer 3.00 Release Notes
This page has been intentionally left blank.
Page 40 # P0605081 Ver: 2.3
Porting 2.30
Applications to 3.00
This chapter covers:
1. Porting PeriProducer 2.30 applications
to the 3.00 environment
2. Porting Standard 2.30 Toolkit Applications to 3.00
3. Porting MPS Toolkit Applications to 3.00
4. Known Conversion Issues
PeriProducer 3.00 Release Notes
Porting 2.30 Applications to 3.00
PeriProducer 3.00 supports legacy (PeriProducer 2.30) applications. Load the
application into PeriProducer and PeriProducer converts the application
automatically.
Before porting the application, read through the entire Release Notes to find out what
features are not supported/have changed and other issues.
Application Porting Considerations
Consider the following when porting the legacy application:
• Make a copy of the source file and port the copy.
• Back up the source file on another system and/or external media
• Save the ported copy as a different name (like <original_name>300)
Porting Standard 2.30 Toolkit Applications to 3.00
Applications that used the standard PeriProducer 2.30 toolkit are automatically
converted by PeriProducer 3.00. No other setup or configuration procedures are
required to convert the 2.30 legacy applications.
Load into PeriProducer 3.00
Load the legacy application into PeriProducer as you would any other application. The
conversion takes place automatically. The PeriProducer logo will indicate that the
application has changed and needs to be saved.
Use the PeriProducer Command Line
Use the following command line syntax to convert a legacy application:
peripro -c <application>
For example, to convert numdemo.ppr, enter peripro -c numdemo. You can
also use filename wildcards (e.g., peripro -c num*) to batch convert
applications. The example converts all applications in the current directory whose
names start with "num".
Page 42 # P0605081 Ver: 2.3
Porting 2.30 Applications to 3.00
Porting Events
During application porting, the following events occur:
• Conditions and environment options are converted when possible. Refer to
Conditions on page 29 and Environment Options on page 23 for conversions.
• Blocks are converted to their nearest possible counterparts in 3.00.
• Resources are obsoleted.
• The original file is renamed by changing its extension to .p2X.
• The "PeriPro 2.30 Runtime Behavior" option is enabled by default. See the
PeriProducer User’s Guide for information about the 2.30 Runtime Behavior
option.
• A file with name beginning with conversionlog_ followed by the
application name and with extension .txt is created and contains messages
pertaining to the conversion process. A similar file is created with the
extension .html and is in HTML format.
# P0605081 Ver: 2.3 Page 43
PeriProducer 3.00 Release Notes
Porting MPS Toolkit Applications to 3.00
Applications that use the MPS Toolkit require procedures to replace the old MPS
toolkit with a special conversion toolkit for porting to the PeriProducer 3.00 toolkit.
These special conversion toolkits are distributed with PeriProducer 3.00 by default.
MPS Toolkit Replacement
There are two replacement versions of MPS Toolkit: 1.30 and 2.00. The files are
located in $PPROHOME/conv as follows:
conv/
• IMpsfolder1.3 (IMps.folder for MPS Toolkit 1.3)
• IMpsfolder2.0 (IMps.folder for MPS Toolkit 2.0)
• mpsconvkit1.3 (mps.pprotoolkit for MPS Toolkit 1.3)
• mpsconvkit2.0 (mps.pprotoolkit for MPS Toolkit 2.0, including
conference toolkit components)
• IMps.folder (working file)
• mps.pprotoolkit (working file)
• mpsContainer.ppr (for debugging only)
conv/icons
• *.icon (i.e. all component icons)
conv/pprs
• *.ppr (i.e. all component pprs, including the ones below)
• mpsSpeak1_3.ppr (Speak for MPS Toolkit 1.3)
• mpsSpeak2_0.ppr (Speak for MPS Toolkit 2.0)
• mpsMoveConditionData1_3.ppr (MoveConditionData for MPS
Toolkit 1.3, directly specified in mpsconvkit1.3)
• mpsMoveConditionData2_0.ppr (MoveConditionData for MPS
Toolkit 2.0, directly specified in mpsconvkit2.0)
Replace Previous MPS Toolkit
Before converting a legacy MPS Toolkit application, replace the previous MPS toolkit
with a special conversion toolkit using the pproinfo -m [ 1.3 (for MPS Toolkit
1.3) | 2.0 (for MPS Toolkit 2.0) ] command. pproinfo -m copies the appropriate
conversion toolkit and system folder files to the proper PeriProducer areas.
Additionally, include $PPROHOME/conv in the $PPROPATH so that the
replacement MPS toolkit can be loaded under PeriProducer 3.00. $PPROPATH should
not include a path to the old MPS Toolkit.
Page 44 # P0605081 Ver: 2.3
Porting 2.30 Applications to 3.00
Load into PeriProducer 3.00
Perform the following to convert a legacy PeriProducer 2.30/MPS Toolkit 1.3/2.00
application by loading the legacy application into PeriProducer 3.00:
1. Identify which version of the MPS Toolkit was used by the PeriPro 2.30
application.
2. Replace the old MPS Toolkit (see Replace Previous MPS Toolkit on page
44).
3. Start PeriProducer with the -m option (peripro -m). This option
causes the conversion of certain conditions (generated by the MPS
resource) into their equivalent PeriProducer 3.00 conditions.
4. Load and save the PeriProducer 2.30 application.
Use the PeriProducer Command Line
Use the following command line syntax to convert a legacy application:
peripro -c -m <application>
For example, to convert numdemo.ppr, enter peripro -c -m mpsnumdemo.
You can also use filename wildcards (e.g., peripro -c mpsnum*) to batch
convert applications. The example converts all applications in the current directory
whose names start with "mpsnum".
# P0605081 Ver: 2.3 Page 45
PeriProducer 3.00 Release Notes
Conversion Logs
The conversion logs are detailed lists of issues encountered during conversion of
PeriProducer 2.30 applications to PeriProducer 3.00. The conversion logs are written
to the same directory as the source (2.30) application. The logs are named
conversion_appname.txt (in plain text format) and
conversion_appname.html (in HTML format).
Each log entry indicates an application function which required some translation to
become PeriProducer 3.00 compatible. A conversion is divided into three categories:
1. Information. This indicates something which should not affect the functionality of the application. A typical information message is the conversion of a 2.30 condition name to a new 3.00 condition name. The
application will react the same way in PeriProducer 3.00, just using a different condition name.
2. Warning. This indicates something which successfully converted but
may not work as expected in 3.00. A typical warning message is for an
obsoleted block setting which should not affect application function.
3. Severe. This indicates something which requires manual application editing in order for the application to run under PeriProducer 3.00. Severe
messages can include
• using features/resources no longer supported (such as fax composition)
• obsoleted environment settings, conditions, system datacards which do
not have an equivalent in PeriProducer 3.00
Page 46 # P0605081 Ver: 2.3
Known Conversion Issues
Set Resource Label in 2.30
PeriProducer 2.30 uses a Resource block Set operation to change the external resource
(e.g. OSCAR) label. PeriProducer 3.00 converts the Resource (Set) block to an
Environment block which sets the RscLabel parameter and enables the Wait option.
If the Resource (set) block had the failure connector enabled, the Environment block
has the failure connector enabled and connects to the same failure path as in the 2.30
application.
If the 2.30 application explicitly handled the setfail (or setres) condition for a
Resource set (instead of using the failure connector), you must manually edit the
converted application to explicitly handle the envfail (or envcmp) condition. The
setfail (or setres) condition in 2.30 automatically converts to
ctrlrsrcfail (or ctrlrsrccmp) in 3.00. If the resource label change fails in
3.00, the envfail condition occurs, not the ctrlrsrcfail condition.
Porting 2.30 Applications to 3.00
Unsupported 2.30 Resources
Several resources from PeriProducer 2.30 are not supported in PeriProducer 3.00 (see
Unsupported Resources on page 21). When an unsupported resource is encountered
during conversion, the unsupported resource is reported in the conversion log file. In
the application, the resource is changed from the resource name to "Unsupported" in
the associated Resource block. Depending on the resource type, you may not be able
to use the application with PeriProducer 3.00.
Resource Block Conversions
The following conversions occur automatically for 2.30 applications which use
external resources (Resources block):
• Receive Resource with the resource "phonePRS" is converted into a Read
Phone block.
• Receive Resource with the resource "lvr-X" (where X is any letter of a valid
2.30 resource) is converted into a Read Phone block.
• Send Resource with the resource "phonePRS" is converted into a Speak block
(with the prompt spoken as TTS Literal).
• Send Resource with the resource "extts-X" (where X is any letter of a valid
2.30 resource) is converted into a Speak block (with the prompt spoken as
TTS Literal).
• If Wait is enabled or a failure connector is available on a 2.30 Resource block,
Wait is enabled on the 3.00 converted block.
# P0605081 Ver: 2.3 Page 47
PeriProducer 3.00 Release Notes
Flushing the Speak Prompt Buffer
The PeriProducer 2.30 System block "Start Reprompt List" function flushes the list of
previously spoken output. This function is still supported in PeriProducer 2.30.
However, it is recommended that to flush the output list buffer, use a Resource block
with the Resource field set to "Player", the CID field set to System.DefaultCID, the
Operation set to "Control", and the Send From field set to System.Constants.Flush.
This suggestion action appears in a 2.30 application’s conversion log file.
System Transfer Connection ID Datacard
PeriProducer 3.00 introduces the system datacard "TransferCID". The system returns
the Connection ID (CID) of line which is used for a transfer operation back to the
TransferCID datacard. TransferCID should not be used in PeriProducer 3.00-native
applications to specify a CID for a transfer operation.
TransferCID is populated only if the transfer operation is performed synchronously
(Originate block with Wait enabled). If Wait is not enabled, TransferCID stays empty.
During 2.30 to 3.00 conversion, PeriProducer may use TransferCID in this capacity
(to specify a CID instead of receiving a value from the system). However, this is done
only when converting applications.
Automatic Detection of Speech or DTMF Input (AUTOID)
When converting applications that perform AUTOID (automatic detection of speech
or DTMF input) it is necessary to make sure that the prompt(s) prior to the
environment block(s) that setup autoid (detect timer and enable autoid) have, at
minimal, the DTMF and LVR resources on after the prompt completes.
Page 48 # P0605081 Ver: 2.3
Loading...
