P117F(R) Stackable Switch Installation Guide 1
Preface Safety Instructions
4. Austauschen einer durchgebrannten Sicherung NUR mit der gleichen Sorte und
Belastbarkeit wie sie auf der Sicherheitsaufschrift markiert ist. Die Aufschrift befindet sich
neben der Stromzufuhr wo sich auch der Sicherungskasten befindet.
5. Bedienen Sie das Gerät NICHT an einer Stelle an der die Umgebungstemperatur 50ºC
übersteigt.
6. Ziehen Sie das Netzkabel raus, BEVOR Sie versuchen die Hauptsicherung zu kontrollieren
oder auszutauschen.
2 P117F(R) Stackable Switch Installation Guide
Chapter 1
Overview
This guide is divided into four main sections:
• Overview: A general description of the features of the Avaya Stackable Switch
• Installation: Instructions for getting the P117F(R) Stackable Switch and P110
• Software Download: Step-by-step guide to downloading a new software
• Appendix: Pin Assignments for the console RJ45 connector.
Description
The P117F(R) is part of the P110 Switching System family of switches. The P110
family is composed of high-performance switches which may be used singly or
stacked in any combination to make up a multi-protocol, non-blocking, scalable
switch.
The P117F has 16 Ethernet (10BASE-T) ports and one 155 Mbps ATM port.
The P117FR has an additional ATM port for redundancy. The 10 Mbps ports are
typically used for workgroup connectivity, while the ATM port(s) can be used as
an uplink to an ATM backbone.
The P117F(R) can operate standalone or as part of a stack. A stack can be made up
of any combination of two, three or four P110 switches, and up to 32,000 MAC
addresses per stack are supported. A stack requires a P110 NMA to link the
switches. The units are physically linked using the P110 Exoplane, which makes
up a multi-gigabit, non-blocking backplane.
The P117F(R) can use Avaya automatic fairness mechanism on the Ethernet ports
to ensure that all ports gain fair access to the P110 Exoplane even at very high
network utilization. Congestion management works both on full and half duplex
ports, and ensures no packet loss should the buffers become saturated during peak
load conditions. A backup power supply (P110 BUPS) can be used for increased
fault tolerance.
P110 switches are fully manageable using MSNM, the Avaya SNMP-based
management system (or CajunView), and may be monitored using the SMON
Manager Switch Monitoring Application.
and P117FR (jointly referred to as the P117F(R)).
stack up and running.
version to the P117F(R) Stackable Switch on-board agent
P117F(R) Stackable Switch Installation Guide 3
Chapter 1 Description
4 P117F(R) Stackable Switch Installation Guide
Chapter 2
Installation
Setting the DIP switches
First, set the DIP switches. The position of the switches depends on the application.
The drawing below shows the default positions of the DIP switches on the rear
panel of the P110 switch.
Figure 1 The P117F(R) Stackable Switch Rear Panel Showing the
DIP Switches in their Default Positions
• LSV – Last SW Version: The on-board agent of the P117F(R) can use either the
latest downloaded software or a “Basic” version. The Basic version is factory
loaded.
Ensure the Use Switch is set to the OFF position.
Once you have set the DIP switch, you may proceed with the physical installation
of the switch.
Table 1 DIP Switches on the P117F(R) Stackable Switch
Switch Function OFF
LSV Last SW Version Use the “Basic”
software
version. This is
known as
Bank A
USE SWITCH Not applicable, for future use only
P117F(R) Stackable Switch Installation Guide 5
ON (Default)
Use the latest
downloaded
agent software.
This is known
as Bank B
Chapter 2 Installation
Installing the P117F(R) Stackable Switch
The procedure for getting the P117F(R) Stackable Switch up and running depends
on whether the switch is to operate in standalone or as part of a stack.
Standalone Operation - Plug ‘n’ Play
Getting the P110 switch working is quick and easy:
1. Connect the power cable to the switch,
2. Connect the cables to the front panel ports,
The switch is now fully operational.
To ensure proper ventilation, ensure that the P110 NMA slot is closed.
Keep the P110 Exoplane cables that came with the P110 switch in a safe place. You
will need them when you add another switch to the P110 stack.
The P117F(R) contains an on-board agent. The Software Download section on page
13 explains when you need to upgrade the on-board software to a higher version.
Stacking Operation
Before beginning to operate with the P117F(R) you need to allocate it an IP
address. Please refer to Agent Access Address on page 22.
To make the P117F(R) work as part of a stack the P110 NMA with the correct
software version is required. See the P117F(R) Stackable Switch Release Notes for
the required version. Also the on-board agent must have the same agent version
number as the P110 NMA.
To check what software version you have, see the agent configuration window in
CajunView (on UNIX) or MSNM or CajunView Manager (on Windows), or see the
setup main menu of the P110 NMA.
1. Turn off the main power to the stack, by individually switching off each
switch.
2. Place the P110 NMA in the top switch of the stack if it is not already there.
3. If the P110 NMA and P117F(R) on-board agent contain the latest software
version, go to step 4.
If the P110 NMA does not contain the latest software version, you have to
perform software download of the latest version. The software is on the
diskette that came with the P117F(R). Download is performed via the Software
Update Manager in MSNM or in CajunView or via TFTP using a terminal –
details can be found in the P110 NMA Installation Guide. (The download
procedure itself is the same as that described in Software Download on
page 18 of this document).
If the P117F(R) on-board agent does not contain the latest version, perform the
download as described in Software Download to the On-Board Agent on
page 13.
6 P117F(R) Stackable Switch Installation Guide
Chapter 2 Installation
4. Place the P117F(R) or other P110 switches in the stack. The P110 NMA must be
in the top switch of the stack.
To ensure proper ventilation, ensure that all empty P110 NMA slots in the
stack are closed.
5. Connect P110 switches using the supplied P110 Exoplane cables, as shown in
Figure 2. A switch connects to its upper neighbor through two Exoplane
cables, and to its lower neighbor through another two Exoplane cables. Make
sure you securely fasten the cables to the connectors.
Cabling Requirements:
• For correct operation, the P110 Exoplane must be fully connected, with all
units powered up. In a stack configuration, the P110 NMA must be installed
and connected to the P110 Exoplane.
Failure to observe this requirement will cause the P110 units to block all traffic
on attached stations and segments.
• When using the P114T or P114F in the stack, make sure all switches in the
stack are connected using P110 Exoplane cables (part number 108362203, with
white connectors and marked C/S:B) of the type supplied with the new P110
switch. Extra cables can be ordered from your local Avaya representative.
Figure 2 Rear view of a P110 stack, showing how the switches are linked via the P110
Exoplane cables. A P110 NMA resides in the uppermost switch.
6. Two terminators are supplied with the P110 NMA. Insert the two terminators
into the lowest two connectors at the bottom of the stack, as shown in Figure 2.
7. Turn on the mains power to the stack, by individually switching on each
switch.
8. Connect the cables to the front panel ports.
P117F(R) Stackable Switch Installation Guide 7
Chapter 2 Installation
The P110 NMA and the on-board agent in all P110 switches (e.g., P117F(R) and
P113F) must have the same version number.
8 P117F(R) Stackable Switch Installation Guide
Rack Mounting
P110 switches slot into a standard 19-inch rack. If the switches are to be rack
mounted, first place them in the rack, then connect the P110 Exoplane, as follows:
1. Snap open the ends of the front panel to reveal the fixing holes.
2. Slot the switch into the rack. Insert the switches into the rack so that the
3. Secure the switch in the rack using the screws. Use one screw on each side. Do
Figure 3 P110 rack mounting arrangement
Chapter 2 Installation
switches in a logical stack lie directly on top of each other. Ensure that the P110
screw holes are aligned with the rack hole positions exactly as shown in Figure
3 Stacking them in this way will allow the switches to be easily connected
using the Exoplane cables.
not overtighten the screws to avoid damaging the plastic.
4. Connect the P110 Exoplane cables, as described above, and as illustrated in
Figure 2.
5. Snap closed the hinged ends of the front panel.
P117F(R) Stackable Switch Installation Guide 9
Chapter 2 Installation
Diagnostics
Tables 2 and 3 explain the meaning of the P117F diagnostic LED indicators.
Figure 4 The P117F Front Panel LEDs and Buttons
Figure 5 The P117FR Front Panel LEDs and Buttons
10 P117F(R) Stackable Switch Installation Guide
Table 2 Meaning of the P117F Front Panel Buttons
g
o
Button Function Meaning
Chapter 2 Installation
Select
The buttons determine what function will be displayed by the 17 Port
LEDs (the top two rows of LEDs).
The five Function LEDs (above the Select buttons) show which
function is currently displayed by the Port LEDs. The Port LEDs can
display either Link, Collision, Transmit, Receive or Full Duplex.
If, for example, the Link (LNK) LED is lit, then LEDs 1 to 17 will
display the Link status of every port.
(For P117FR ATM port LEDs, see also Table 4).
Press left or ri
ht button to toggle the Port LED display between functi
Reset Press and hold both buttons simultaneously for two seconds to reset
the entire P110 stack. In a Reset, all LED indicators turn on. Pressing
Reset does not affect configuration settings.
Table 3 Meaning of the P117F(R) Stackable Switch front panel LEDs
LED Indicator Function Status Meaning
PWR Power OFF
ON
Blink
NMA Agent OFF
ON
RED NMA
OPR CPU
Reserved for future use
OFF
Operation
Blink
Function LED Port LED
LNK Link status OFF
ON
Blink once
Blink
Mains power not connected
Mains power connected
Working on back-up power supply
No agent in this module
This module contains an active agent
CPU is OK
CPU is faulty
(1 to 17)
Port Disabled
Port is enabled and link is OK
Link Test Fail
Partition (Ethernet only)
twice
COL Collision OFF
ON
No Collision (ATM is always OFF)
Collision occurred on line (Ethernet
only)
Tx Transmit to
line
Rx Receive
from line
FDX Half/Full OFF
OFF
ON
OFF
ON
No activity
Data transmitted
No activity
Data Received
Half duplex connection to port
P117F(R) Stackable Switch Installation Guide 11
Chapter 2 Installation
LED Indicator Function Status Meaning
duplex
ON
Table 4 Meaning of the additional P117FR front panel LEDs
LED
Function Status Meaning
Indicator
(Ethernet only)
Full duplex connection to port
(ATM is always ON)
M
S
Master port
(Upper ATM
connector)
Secondary port
(Lower ATM
connector)
Port LEDs
for the
ATM ports
R Redundancy status OFF
ON
Blink
These Port LEDs indicate status
according to the functional LEDs (see
Table 3)
Redundancy is disabled. Upper port
active
Redundancy is enabled. Upper port
active
Redundancy is enabled, and secondary
port (Lower ATM connector) is active
12 P117F(R) Stackable Switch Installation Guide
Loading...
