Avaya IP Office H323 User Manual

IP Office 4.2

H323 IP Telephone Installation

15-601046 Issue 15b - (16 July 2009)

© 2009 AVAYA All Rights Reserved.
Notice

While reasonable efforts were made to ensure that the information in this document was complete and accurate at the time of
printing, Avaya Inc. can assume no liability for any errors. Changes and corrections to the information in this document may be
incorporated in future releases.

Documentation Disclaimer
Avaya Inc. is not responsible for any modifications, additions, or deletions to the original published version of this
documentation unless such modifications, additions, or deletions were performed by Avaya.

Link Disclaimer
Avaya Inc. is not responsible for the contents or reliability of any linked Web sites referenced elsewhere within this
Documentation, and Avaya does not necessarily endorse the products, services, or information described or offered within
them. We cannot guarantee that these links will work all of the time and we have no control over the availability of the linked
pages.

License
USE OR INSTALLATION OF THE PRODUCT INDICATES THE END USER’S ACCEPTANCE OF THE TERMS SET FORTH
HEREIN AND THE GENERAL LICENSE TERMS AVAILABLE ON THE AVAYA WEBSITE AT
http://support.avaya.com/LicenseInfo/ (“GENERAL LICENSE TERMS”). IF YOU DO NOT WISH TO BE BOUND BY THESE
TERMS, YOU MUST RETURN THE PRODUCT(S) TO THE POINT OF PURCHASE WITHIN TEN (10) DAYS OF DELIVERY
FOR A REFUND OR CREDIT.
Avaya grants End User a license within the scope of the license types described below. The applicable number of licenses and
units of capacity for which the license is granted will be one (1), unless a different number of licenses or units of capacity is
specified in the Documentation or other materials available to End User. “Designated Processor” means a single stand-alone
computing device. “Server” means a Designated Processor that hosts a software application to be accessed by multiple users.
“Software” means the computer programs in object code, originally licensed by Avaya and ultimately utilized by End User,
whether as stand-alone Products or pre-installed on Hardware. “Hardware” means the standard hardware Products, originally
sold by Avaya and ultimately utilized by End User.
License Type(s): Designated System(s) License (DS).
End User may install and use each copy of the Software on only one Designated Processor, unless a different number of
Designated Processors is indicated in the Documentation or other materials available to End User. Avaya may require the
Designated Processor(s) to be identified by type, serial number, feature key, location or other specific designation, or to be
provided by End User to Avaya through electronic means established by Avaya specifically for this purpose.
Copyright
Except where expressly stated otherwise, the Product is protected by copyright and other laws respecting proprietary rights.
Unauthorized reproduction, transfer, and or use can be a criminal, as well as a civil, offense under the applicable law.

Third-Party Components
Certain software programs or portions thereof included in the Product may contain software distributed under third party
agreements (“Third Party Components”), which may contain terms that expand or limit rights to use certain portions of the
Product (“Third Party Terms”). Information identifying Third Party Components and the Third Party Terms that apply to them is
available on Avaya’s web site at: http://support.avaya.com/ThirdPartyLicense/

Avaya Fraud Intervention
If you suspect that you are being victimized by toll fraud and you need technical assistance or support, call Technical Service
Center Toll Fraud Intervention Hotline at [phone] for the United States and Canada. Suspected security
vulnerabilities with Avaya Products should be reported to Avaya by sending mail to: [e-mail].
For additional support telephone numbers, see the Avaya Support web site (http://www.avaya.com/support).

Trademarks
Avaya and the Avaya logo are registered trademarks of Avaya Inc. in the United States of America and other jurisdictions.
Unless otherwise provided in this document, marks identified by “®,” “™” and “SM” are registered marks, trademarks and
service marks, respectively, of Avaya Inc. All other trademarks are the property of their respective owners.

Documentation information
For the most current versions of documentation, go to the Avaya Support web site (http://www.avaya.com/support) or the IP
Office Knowledge Base (http://marketingtools.avaya.com/knowledgebase/).

Avaya Support
Avaya provides a telephone number for you to use to report problems or to ask questions about your contact center. The
support telephone number is 1 800 628 2888 in the United States. For additional support telephone numbers, see the Avaya
Web site: http://www.avaya.com/support.

H323 Phone Install Page 2

15-601046 Issue 15b (16 July 2009)IP Office 4.2

Contents

Contents

..................................................................... 717.1 Using a Windows DHCP Server

..................................................................... 747.2 Alternate Options

IP Office IP Phones1.

..................................................................... 81.1 What is New

..................................................................... 101.2 Supported Phones

..................................................................... 111.3 System Capacity

..................................................................... 121.4 Phone Firmware

..................................................................... 131.5 Simple Installation

..................................................................... 141.6 Complex Installation

..................................................................... 151.7 Installation Requirements

..................................................................... 161.8 Network Assessment

..................................................................... 171.9 Voice Compression

..................................................................... 191.10 QoS

..................................................................... 191.11 Potential VoIP Problems

..................................................................... 201.12 User PC Connection

..................................................................... 211.13 Power Supply Options

..................................................................... 231.14 File Server Options

..................................................................... 241.15 File Auto Generation

..................................................................... 251.16 Control Unit Memory Card

WML Server Setup8.

..................................................................... 778.1 Testing 4620 WML Browsing Using Xitami

..................................................................... 798.2 Setting the Home Page

..................................................................... 808.3 Apache Web Server WML Configuration

..................................................................... 808.4 Microsoft IIS Web Server WML Configuration

..................................................................... 818.5 Open URL Entry

...............................................................................83Index

Installation2.

..................................................................... 302.1 Creating/Editing the Settings File

..................................................................... 322.2 Manually Creating Extensions

..................................................................... 332.3 Phone Connection

..................................................................... 342.4 Static Address Installation

..................................................................... 352.5 Phone Registration

..................................................................... 362.6 Extension & User Setup

..................................................................... 362.7 Phone Security

..................................................................... 372.8 Backup Restore

..................................................................... 402.9 Listing Registered Phones

..................................................................... 412.10 Error Messages

Other Installation Options3.

..................................................................... 443.1 VPN Remote Phones

..................................................................... 473.2 VLAN and IP Phones

Static Administration Options4.

..................................................................... 554.1 QOS Option Settings

4.2 Secondary Ethernet (Hub)/IR Interface
Enable/Disable

..................................................................... 55

..................................................................... 564.3 View Details

..................................................................... 574.4 Self-Test Procedure

..................................................................... 584.5 Resetting a Phone

..................................................................... 594.6 Site Specific Option Number

..................................................................... 604.7 Automatic Gain Control

Restart Scenarios5.

..................................................................... 635.1 Boot File Needs Upgrading

5.2 No Application File or Application File Needs
Upgrading

5.3 Correct Boot File and Application File Already
Loaded

..................................................................... 63

..................................................................... 63

Infrared Dialling6.

..................................................................... 676.1 Enabling the IR Port

..................................................................... 676.2 Dialling Phone Numbers

..................................................................... 686.3 Beaming Files During a Call

Alternate DHCP Server Setup7.

H323 Phone Install Page 3

15-601046 Issue 15b (16 July 2009)IP Office 4.2

Chapter 1.

IP Office IP Phones

H323 Phone Install Page 5

15-601046 Issue 15b (16 July 2009)IP Office 4.2

1. IP Office IP Phones

IP Office IP Phones:

This documentation provides notes for the installation of supported Avaya 1600, 4600 and 5600 IP phones onto IP
Office phone systems. It should be used in conjunction with the existing installation documentation for those series of
phones, especially the following:

· 4600 Series IP Telephone LAN Administrator Guide (555-233-507).

· 1600 Series IP Telephones Administrators Guide (16-601443).

Avaya 3600 Series IP telephones, Avaya IP DECT telephones and Phone Manager Pro PC Softphone are covered by their
own separate installation documentation.

10

· DHCP versus Static IP Installation

Though static IP installation of H323 IP phones is possible, installation using DHCP is strongly recommended. The
use of DHCP eases both the installation process and future maintenance and administration. For static installations,
following a boot file upgrade, all static address settings are lost and must be re-entered.

· Network Assessment

High quality voice transmission across an IP network requires careful assessment of many factors. Therefore:

· We strongly recommend that IP phone installation is only done by installers with VoIP experience.

· The whole customer network must be assessed for its suitability for VoIP, before installation. Avaya may

refuse to support any installation where the results of a network assessment cannot be supplied. See Network

Assessment for further details.

16

H323 Phone Install Page 7

15-601046 Issue 15b (16 July 2009)IP Office 4.2

1.1 What is New

IP Office 5.0

The following changes specific to H323 IP phone support have been made as part of the IP Office 5.0 release.

· Embedded Memory Card Usage
In order to simplify H323 phone installation and maintenance, a number of changes have been made, employing
the Embedded Voicemail memory card supported by IP406 V2 and IP500 control units.

· Automatic File Loading
Using the Embedded File Management option within IP Office Manager, the option File | Upload Phone Files
will transfer all necessary phone firmware files required for phones supported by IP Office 5.0 to the memory
card. Those files are then available to the phones if the IP Office is configured as the HTTP/TFTP server for
phones.

· Auto-Generated File Operation
If the IP Office is configured as the HTTP/TFTP file server for H323 phones, the Embedded Voicemail memory
card is used as the file store. The file server normally requires copies of various .scr and .txt files to be
present. For IP Office 5.0, if those files are not present on the memory card, the IP Office will auto-generate a
suitable file when it is requested by a phone.

· Extension Quality of Service Measurement
Through the IP Office configuration, H323 IP phones (1600 Series, 4600 Series and 5600 Series) can be enabled
to send QoS information to the IP Office system. For other types of extension, when their call involves a VCM
channel, QoS information is available. The QoS information is round trip delay, jitter and packet loss. This
information is used in a number of ways.

· QoS Display
Within the IP Office System Status Application (SSA), the current QoS measurements are shown for calls. This
is in addition to the QoS measurement already displayed by SSA for IP trunks.

· QoS Alarms
QoS alarms thresholds can be set within the IP Office configuration. On calls where a threshold is exceeded,
an alarm is generated at the end of the call. The alarm will contain the maximum value of all the QoS
measurements. QoS alarms are shown in SSA. They can also be specified for output as alarms via SNMP,
Syslog and/or email.

· Resilience
IP Office 5.0 includes support for a number of 'resilience' features within an IP Office Small Community Network.
This includes support for registered H323 phones and their users if the IP Office with which they are registered
should not be available on the network. For details of resilience operation refer to the IP Office 5.0 Manager
manual.

· VLAN Setting
This option within the IP Office configuration (System | LAN1/LAN2 | VoIP) is applied to H323 phones using the IP
Office for DHCP support. If set to Disabled, the L2Q value indicated to phones in the DHCP response is 2
(disabled). If set to Not Present, no L2Q value is included in the DHCP response.

24

IP Office 4.2

The following changes specific to H323 IP phone support have been made as part of the IP Office 4.2 release.

· Support for 1600 Series Phones

IP Office 4.2 Q4 2008+ supports the 1603, 1608, 1616 IP phones.

· HTTP Server Support

For Avaya IP phones using IP Office DHCP, the address of the HTTP server from which those phones should
download their software and settings files can now be specified in the IP Office configuration. 4600 Series and
5600 Series phones attempt to load files via HTTPS and then HTTP before falling back to TFTP. 1600 Series IP
phones only support HTTPS or HTTP.

· HTTP-TFTP Relay
The IP Office control unit supports HTTP-TFTP relay for HTTP file requests from phones.

· HTTP-TFTP Using an Embedded Memory Card
For IP Office 4.2, using the Embedded Voicemail memory card is also supported for HTTP file requests for
up to 50 IP phones. This is done by setting the TFTP Server IP Address and HTTP Server IP Address
to the control unit IP address. This method is supported for up to 50 IP phones.

· HTTP-TFTP Using IP Office Manager
For the IP Office 4.2 Q4 2008 maintenance release, HTTP-TFTP Relay is support using IP Office Manager
as the TFTP server. This is done by setting the TFTP Server IP Address to the address of the Manager
PC and the HTTP Server IP Address to the control unit IP address. This method is supported for up to 5
IP phones.

H323 Phone Install Page 8

15-601046 Issue 15b (16 July 2009)IP Office 4.2

IP Office IP Phones: What is New

· HTTP User Backup and Restore
The HTTP file support methods detailed in this manual are for the download of phone firmware, settings and
language files to phones. HTTP support for phone user settings backup and restore requires a separate HTTP
server, the address of which is defined with the phone settings files rather than through the DHCP server
configuration settings.

· Secondary Site Specific Options Number

A Site Specific Option Number (SSON) is used by Avaya IP phones when requesting phone specific settings from a
DHCP server. When the IP Office is acting as the DHCP server, the matching number must be set in the IP Office
configuration. IP Office 4.2 now provides two fields for settings SSON numbers in order to support Avaya 4600
and 5600 Series IP Phones (which use a default SSON of 176) and Avaya 1600 Series phones (which use a default
SSON of 242).

· IP Phone Restart using System Status Application

Individual Avaya IP phones or groups of phones can be selected and then restarted remotely using the System
Status Application. This allows individual phones or groups of phones to be restarted in order to upgrade their
firmware.

· IP500 DHCP Enhancements

The scope of DHCP support on IP500 has been enhanced in a number of areas.

· Full Avaya IP Phone Support

Previous only a maximum of 5 IP phones have been supported if using the IP Office for DHCP and TFTP
functions. An external DHCP server is required to support more than 5 Avaya IP Phones. For IP Office 4.2+,
the IP500 supports the fill extension capacity of the IP500 control unit.

· Multiple DHCP IP Address Pools

On each IP Office LAN interface, up to 8 DHCP address ranges (called 'pools') can be specified. These pools do
not have to be on the same subnet as the IP Office itself. This allows devices being supported by IP Office
DHCP to be given addresses on a different subnet than the IP Office.

· DHCP for Avaya IP Phones Only

The DHCP pools provided by the IP Office can be restricted for use by Avaya IP phones only. The IP Office will
then not respond to DHCP request from other devices.

· Embedded Card File Management

For systems with a compact flash memory card installed, the contents of the card can be viewed through Manager.
This mode is accessed through the File | Advanced | Embedded File Management option. This view can also
be used to add and remove files from the card. This may be useful when the memory card is being used to store
music on hold files and or phone firmware files.

· IP500 VCM Controls

For IP Office 4.2+, the VCM controls for echo and comfort noise supported in the IP Office configuration (System
| VCM) are now also applied to IP500 VCM cards.

H323 Phone Install Page 9

15-601046 Issue 15b (16 July 2009)IP Office 4.2

1.2 Supported Phones

H323 IP
Phones

Supported
Models

IP Office Core
Software

Note

1600 Series

1603

Supported on IP Office 4.2 Q4 2008+.

1608

1616

3600 Series

3616

Supported on IP Office 2.1+.

Also known as Spectralink phones, these IP
phones connect via a WiFi network and
additional equipment. They are covered by
their own separate IP Office installation
documentation.

3626

3620

Supported on IP Office 3.2+.

3641

Supported on IP Office 4.1+.

3645

4600 Series

4601

Supported on IP Office 3.0+

These phones are supported on a range of
Avaya phone systems including IP Office.
However when used with IP Office the
firmware installed on the phones must be
that supplied with the IP Office
administration software.

4602

Supported on IP Office 2.1+.

4602SW

4606

Only supported up to IP Office 3.2.

4610SW*

Supported on IP Office 3.0+.

4612

Only supported up to IP Office 3.2.

4620

Supported on IP Office 2.0+.

4620SW

4624

Only supported up to IP Office 3.2.

4621SW*

Supported on IP Office 3.0+.

4625

Supported on IP Office 3.2+

5600 Series

5601

Supported on IP Office 3.0+.

These phones are supported on IP Office
only. They cannot be used with other
phone systems.

5602

5602SW

5610SW*

5620

5620SW

5621SW*

Supported on IP Office 3.2+.

This documentation provides installation notes for the following Avaya IP phone supported by IP Office.

· Other H323 IP Phones

Other H323 IP telephony devices are supported through the entry of an IP Office IP Endpoint license into the IP
Office configuration. However, no functionality on these devices beyond basic call answering and making is
guaranteed by Avaya. Therefore, installation of these devices should be thoroughly tested before any customer
deployment.

H323 Phone Install Page 10

*These phones can also be used with VPNremote firmware.

15-601046 Issue 15b (16 July 2009)IP Office 4.2

IP Office IP Phones: Supported Phones

IP Office Unit

Maximum

Extensions

Maximum VCM

Channels

Small Office Edition

28 Total/16 IP

[1]

3

[2]

or 16

[2]

IP406 V2

190

30

IP412

360

60

IP Office 500

384

[3]

128

1.3 System Capacity

System capacity can be separated into two aspects; the number of configurable phone extensions and the number of
simultaneous IP phone calls.

Extension Capacity

The maximum number of H323 IP phones supported by an IP Office system is based on that system's maximum capacity
for extensions of any type as listed in the table below. To find the capacity for IP phones remove the number of physical
non-IP extensions installed on the system, ie. extension ports on the IP Office control unit and any external expansion
modules.

1.The maximum extension capacity is 28 for all phone types but only 16 may be IP phones.

2.Fixed non-adjustable capacity.

3.384 for IP Office 5.0+. 272 for earlier versions.

Call Capacity

There are a number of situations where the IP Office system needs to provide a voice compression channel in order for
an IP phone to make calls. These channels are provided by Voice Compression Modules (VCMs) installed in the IP Office
system. The number of VCM channels required and how long the channel is required will depend on a number of factors.
For further details see Voice Compression .

A simple summary is:

· A VCM channel is required during call setup.

· The VCM channel is released if the call is to/from another IP device using the same compression codec (the

supported VCM codecs are G711, G729 and G723a).

· The VCM channel is used for the duration of the call when the call is to/from/via a non-IP device (extension or
trunk line).

· It should be remembered that VCM channels are also used for calls from non-IP devices to IP lines if those are
configured in the IP Office system (IP, SIP and SES lines).

· Calls from IP phones to the IP Office voicemail server use a VCM channel.

· Note that on Small Office Edition systems with Embedded Voicemail, an additional channel is used for every

call to voicemail.

17

H323 Phone Install Page 11

15-601046 Issue 15b (16 July 2009)IP Office 4.2

1.4 Phone Firmware

The firmware in Avaya IP phones is upgradeable and different releases of firmware are made available via the Avaya
support website. However H323 IP phones used on an IP Office system must only use the IP Phone software supplied
with the IP Office Manager application. Other versions of IP Phone software may not have been tested with IP Office and
so should not be used unless IP Office support is specifically mentioned in their accompanying documentation.

The phone firmware files are installed as part of the IP Office Manager application and are found in the applications
installation directory. By default this is c:\Program Files\Avaya\IP Office\Manager.

For IP Office 4.2+, they firmware files are also available on the IP Office Administrator Applications CD from which IP
Office Manager is installed. The files are located in the \program files\Avaya\IP Office\Manager folder of the
installation files. This makes it easier to locate all the files needed for IP phone installation though it also includes the .bin
files used for IP Office control and external expansion units.

H323 Phone Install Page 12

15-601046 Issue 15b (16 July 2009)IP Office 4.2

IP Office IP Phones: Phone Firmware

1.5 Simple Installation

The diagram below shows the simplest installation scenario.

· For IP Office control units other than the IP500, and for IP500 units running IP Office 4.0/4.1 software, this type
of installation is only supported for up to 5 IP phones.

· For IP500 control units running IP Office 4.2+, this type of installation can be used for DHCP support of up to 272
IP phones (the maximum extension capacity of IP500 systems). The IP Office control unit can also act as the file
server to up to 50 phones.

· DHCP Server

The IP Office unit is acting as the DHCP server for the Avaya IP phones. Key settings such as the file server
address are entered into the IP Office configuration and then provided to the phones in addition to their IP
address.

· For IP Office 4.2+, the IP Office DHCP server can be configured to provide DHCP addresses only in response
to requests from Avaya IP phones. This allows an alternate DHCP server to be used for other devices that use
DHCP.

· H323 Gatekeeper

IP phones require an H323 gatekeeper to which they register. The gatekeeper then controls connecting calls to the
phone. In this scenario the IP Office control unit acts as the H323 Gatekeeper.

· File Server

During installation, and occasionally for maintenance, the IP phones need to download software and settings files.
They can download the files from an HTTP server or TFTP server. The phones will try HTTP first and then TFTP.
There are a number of options for the file server role:

· TFTP Server

For all IP Office releases, for phones being supported by IP Office DHCP, the address of the TFTP server is set
as part of the IP Office configuration. If otherwise the only way to specify the TFTP server is via a separate
DHCP server or via static installation settings.

· IP Office Control Unit

For IP Office control units fitted with an additional memory card (Small Office Edition, IP406 V2 and
IP500), the IP Office itself can be used as the TFTP server. This requires the IP phone firmware files to be
transferred onto the memory card.

· HTTP Server

or IP Office 4.2+, phones being supported via IP Office DHCP, the address of the HTTP server is set as part of
the IP Office configuration. If otherwise the only way to specify the HTTP server is via a separate DHCP server
or via static installation settings.

· For IP Office 4.2, using an Embedded Voicemail memory card is supported for HTTP file requests for up to
50 IP phones. This is done by setting the TFTP Server IP Address and HTTP Server IP Address to the
control unit IP address. This is supported for up to 50 IP phones.

· For IP Office 4.2 Q4 2008 maintenance, using the IP Office Manager application is supported for HTTP file
requests for up to 5 IP phones. This is done by setting the TFTP Server IP address to that of the IP
Office Manager PC and the HTTP Server IP Address to the control unit IP address. This is supported for
up to 5 IP phones.

· Power Supply

The IP phones require a power supply. This is not provided by the IP Office.

· Individual Power Supply Units

An individual power supply unit can be used with each phone. This will require a power supply socket at each
phone location. Note that for phones using a button add-on, for example a EU24 or BM32 an individual power
supply unit is a requirement.

· Power over Ethernet Supply

Most Avaya IP phones can be powered from an 802.3af Power over Ethernet (PoE) power supply. The IP
Office system does not provide PoE ports so a separate PoE switch will be required.

H323 Phone Install Page 13

15-601046 Issue 15b (16 July 2009)IP Office 4.2

1.6 Complex Installation

The diagram below shows a scenario where more than 5 IP phones are being supported. The key difference is that the
file server and DHCP support must be done using 3rd-party applications.

· For IP Office 4.2+ running on an IP500 IP Office system, the full capacity of up to 272 extensions is supported
using the IP Office for DHCP. Control units with an Embedded Voicemail memory card installed can be used as the
HTTP file server for up to 50 IP phones.

· DHCP Server

In this scenario, the IP Office role as DHCP server must be replaced by an alternate DHCP server. This requires
that the DHCP function of the IP Office unit is switched off. Therefore the IP Office unit must be given a fixed IP
address (or act as a DHCP client).

· File Server

In this instance an alternative file server application must be used.

H323 Phone Install Page 14

15-601046 Issue 15b (16 July 2009)IP Office 4.2

IP Office IP Phones: Complex Installation

1.7 Installation Requirements

To install an IP phone on IP Office, the following items are required:

· o Extension Number and User Details

A full listing of the planned extension number and user name details is required. The planned extension number
must be unused and is requested by the phone during installation.

· o Power Supplies

Each phone requires a power supply. Avaya IP phones do not draw power from the IP Office. A number of options
exist for how power is supplied to the phones. See Power Supply Options .

· o LAN Socket

An RJ45 Ethernet LAN connection point is required for each phone.

· o Category 5 Cabling

All LAN cables and LAN cable infrastructure used with H323 IP phones should use CAT5 cabling. Existing CAT3
cabling may be used but will be limited to 10Mbps (maximum).

· o LAN Cables

Check that an RJ45 LAN cable has been supplied with the IP phone for connection to the power supply unit. You
will also need an additional RJ45 LAN cable for connection from the power unit to the customer LAN.

· A further RJ45 LAN cable can be used to connect the user's PC to the LAN via the IP phone [not supported on
4601, 4602, 5601 and 5602 H323 IP phones].

· o Voice Compression Channels

The IP Office Unit must have voice compression channels installed. Channels are required during the connection if
calls involving IP phones and may also be required during the call. See Voice Compression Channels for full
details.

· For Small Office Edition units, either 3 or 16 voice compression channels are pre-built into the unit.

· For IP400 control units, voice compression channels are provided by fitting a Voice Compression Module .

· For IP500 control units, channels are installed using a IP500 VCM base card and licenses or using IP400 VCM

modules on an IP500 Legacy Card.

· o DHCP Server

The IP Office Unit can perform this role for up to 5 IP phone devices. If another DHCP server already exists, this
may be able to do DHCP for the H323 IP phones, see Alternate DHCP Servers . Static IP addressing can also be
used, if required, but is not recommended.

· For IP500 IP Office 4.2+ systems, up to 272 IP phones are supported using the IP Office Manager.

· o HTTP or TFTP File Server

A PC running the IP Office Manager application can perform this role for up to 5 H323 IP phones. Otherwise an
alternate HTTP or TFTP server is required.

· o H323 Gatekeeper

The IP Office Unit performs this role.

· o IP Office Manager PC

A PC running Manager is required for IP Office Unit configuration changes. This PC should have a static IP address.

· o IP Telephone Software

The software for IP phone installation is installed into the IP Office Manager program folder during Manager
installation.

· o Licence Keys

IP Office supported H323 IP phones do not need a licence key entered on the system. The only exception are IP
phones running Avaya VPN remote software, see VPN Remote Phones .

21

70

44

17

17

H323 Phone Install Page 15

15-601046 Issue 15b (16 July 2009)IP Office 4.2

1.8 Network Assessment

· WARNING: A Network Assessment is Mandatory
When installing H323 IP phones on an IP Office system, it is assumed by Avaya that a network assessment has
been performed. If a support issue is escalated to Avaya, Avaya may request to see the results of the network
assessment and may refuse to provide support if a suitable network assessment was not performed.

Current technology allows optimum network configurations to deliver VoIP with voice quality close to that of the public
phone network. However, few networks are optimum and so care should be taken assessing the VoIP quality achievable
across a customer network.

Not every network is able to carry voice transmissions. Some data networks have insufficient capacity for voice traffic or
have data peaks that will impact voice traffic on occasion. In addition, the usual history of growing and developing
networks by integrating products from many vendors makes it necessary to test all the network components for
compatibility with VoIP traffic.

A network assessment should include a determination of the following:

· A network audit to review existing equipment and evaluate its capabilities, including its ability to meet both current
and planned voice and data needs.

· A determination of network objectives, including the dominant traffic type, choice of technologies and setting voice
quality objectives.

· The assessment should leave you confident that the network will have the capacity for the foreseen data and voice
traffic, and can support H323, DHCP, TFTP and jitter buffers in H323 applications.

The network assessment targets are:

· Latency: Less than 180ms for good quality. Less than 80ms for toll quality.
This is the measurement of packet transfer time in one direction. The range 80ms to 180ms is generally
acceptable. Note that the different audio codecs used each impose a fixed delay caused by the codec conversion
as follows:

· G711: 20ms.

· G723a: 80ms.

· G729: 40ms.

· Packet Loss: Less than 3% for good quality. Less than 1% for toll quality.

Excessive packet loss will be audible as clipped words and may also cause call setup delays.

· Jitter: Less than 20ms.
Jitter is a measure of the variance in the time for different packets in the same call to reach their destination.
Excessive jitter will become audible as echo.

· Duration: Monitor statistics once every minute for a full week.
The network assessment must include normal hours of business operation.

H323 Phone Install Page 16

15-601046 Issue 15b (16 July 2009)IP Office 4.2

IP Office IP Phones: Network Assessment

1.9 Voice Compression

Calls to and from IP devices can require conversion to the audio codec format being used by the IP device. In the IP
Office this conversion is done by voice compression channels. These support the common IP audio codecs G711, G723
and G729a.

For Small Office Edition control units either 3 or 16 integral channels are included. For IP400 control units channels can
be added by fitting IP400 VCM cards. For the IP500 control unit channels can be added using either IP400 VCM cards or
licensed IP500 VCM cards.

The voice compression channels are used as follows.

· IP Device to Non-IP Device
These calls require a voice compression channel for the duration of the call. If no channel is available busing indication
is returned to the call.

· IP Device to IP Device

· Call progress tones (for example dial tone, secondary dial tone, etc) do not require voice compression channels with

the following exceptions:

· Short code confirmation, ARS camp on and account code entry tones require a voice compression channel.

· Devices using G723 require a voice compression channel for all tones except call waiting.

· When a call is connected:

· If the IP devices use the same audio codec no voice compression channel is used.

· If the devices use differing audio codecs, a voice compression channel is required for each.

· Non-IP Device to Non-IP Device

No voice compression channels are required except for Small Office Edition Embedded Voicemail access.

· Music on Hold
This is provided from the IP Office's TDM bus and therefore requires a voice compression channel when played to an IP
device.

· Conference Resources and IP Devices
Conferencing resources are managed by the conference chip which is on the IP Office's TDM bus. Therefore, a voice
compression channel is required for each IP device involved in a conference. This includes services that use conference
resources such as call listen, intrusion, call recording and silent monitoring.

· Page Calls to IP Device
Page calls require 1 voice compression channel per audio codec being used by any IP devices involved. IP Office 4.0
and higher only uses G729a for page calls, therefore only requiring one channel but also only supporting pages to
G729a capable devices.

· Voicemail Services and IP Devices
Calls to the IP Office voicemail servers (Voice Mail Pro, Voicemail Lite and Embedded Voicemail) are treated as data
calls from the TDM bus. Therefore calls from an IP device to voicemail require a voice compression channel.

· On the Small Office Edition, embedded voicemail uses voice compression channels for audio conversion. Therefore

all calls to SOE embedded voicemail require a voice compression channel and calls from IP devices require two voice
compression channels.

· Fax Calls
These are voice calls but with a slightly wider frequency range than spoken voice calls. IP Office only supports fax
across IP between IP Office systems with the Fax Transport option selected. It does not currently support T38.

· SIP Calls

· SIP Line Call to/from Non-IP Devices

Voice compression channel required.

· Outgoing SIP Line Call from IP Device

No voice compression channel required.

· Incoming SIP Line Call to IP Device

Voice compression channel reserved until call connected.

Installing VCM Cards

Refer to the IP Office Installation manual.

H323 Phone Install Page 17

15-601046 Issue 15b (16 July 2009)IP Office 4.2

IP400 VCM Cards

IP400 VCM Cards

SAP Code

Small Office

Edition

IP406

V2

IP412

IP500

25ms echo
cancellation.

IP400 VCM5

[1]

700185119

IP400 VCM10

[1]

700185127

IP400 VCM20

[1]

700185135

IP400 VCM30

700293939

64ms echo
cancellation.

IP400 VCM4

700359854

IP400 VCM8

700359862

IP400 VCM16

700359870

IP400 VCM24

700359888

Number of IP400 VCM cards.

0

122

[2]

Maximum number of channels.

3/16

[3]

3060128

Name

Description

SAP Code

IPO 500 MC VCM 32

IP Office 500 Media Card Voice Coding Module 32

700417389

IPO 500 MC VCM 64

IP Office 500 Media Card Voice Coding Module 64

700417397

IPO LIC IP500 VCM LIC 4 CH

IP500 Addition VCM Channels License: 4 Channels

202961

IPO LIC IP500 VCM LIC 8 CH

IP500 Addition VCM Channels License: 8 Channels

202962

IPO LIC IP500 VCM LIC 16 CH

IP500 Addition VCM Channels License: 16 Channels

202963

IPO LIC IP500 VCM LIC 28 CH

IP500 Addition VCM Channels License: 28 Channels

202964

IPO LIC IP500 VCM LIC 60 CH

IP500 Addition VCM Channels License: 60 Channels

202965

Codec

IP500 VCM32

IP500 VCM64

G.7113264

G.729a3060

G.7232244

The following IP400 VCM cards are available.

1.These modules are still supported but are no longer available from Avaya.

2.Requires a IP500 Legacy Card Carrier for installation into an IP500 control unit.

3.The VCM channels in Small Office Edition control units are fixed at either 3 or 16 depending on the model.

IP500 VCM cards

The following IP500 VCM cards are available. Each card provides 4 unlicensed channels with the addition capacity of the
card requiring licenses within the IP Office configuration. Up to 2 IP500 VCM cards are supported in a system.

· The maximum number of simultaneous channels useable on an IP500 VCM base card is affected by the codec being
used. The following table assumes that all calls using the VCM use the same codec.

H323 Phone Install Page 18

15-601046 Issue 15b (16 July 2009)IP Office 4.2

IP Office IP Phones: Voice Compression

1.10 QoS

When transporting voice over low speed links it is possible for normal data packets (1500 byte packets) to prevent or
delay voice packets (typically 67 or 31 bytes) from getting across the link. This can cause unacceptable speech quality.

Therefore, it is vital that all traffic routers and switches in the network to have some form of Quality of Service (QoS)
mechanism. QoS routers are essential to ensure low speech latency and to maintain sufficient audible quality.

IP Office supports the DiffServ (RFC2474) QoS mechanism. This is based upon using a Type of Service (ToS) field in the
IP packet header. On its WAN interfaces, IP Office uses this to prioritize voice and voice signalling packets. It also
fragments large data packets and, where supported, provides VoIP header compression to minimize the WAN overhead.

Note

· IP Office does not perform QoS for its Ethernet ports including the WAN Ethernet port on the Small Office Edition.

1.11 Potential VoIP Problems

It is likely that any fault on a network, regardless of its cause, will initially show up as a degradation in the quality of VoIP
operation. This is regardless of whether the fault is with the VoIP telephony equipment. Therefore, by installing a VoIP
solution, you must be aware that you will become the first point of call for diagnosing and assessing all potential
customer network issues.

Potential Problems

· End-to-End Matching Standards

VoIP depends upon the support and selection of the same voice compression, header compression and QoS
standards throughout all stages of the calls routing. The start and end points must be using the same compression
methods. All intermediate points must support DiffServ QoS.

· Avoid Hubs

Hubs introduce echo and congestion points. If the customer network requires LAN connections beyond the capacity
of the IP Office Unit itself, Ethernet switches should be used. Even if this is not the case, Ethernet switches are
recommended as they allow traffic prioritization to be implemented for VoIP devices and for other device such as
the Voicemail Server PC.

· Power Supply Conditioning, Protection and Backup

Traditional phone systems provide power to all their attached phone devices from a single source. In a VoIP
installation, the same care and concern that goes into providing power conditioning, protection and backup to the
central phone system, must now be applied to all devices on the IP network.

· Multicasting

In a data only network, it is possible for an incorrectly installed printer or hub card to multicast traffic without that
fault being immediately identified. On a VoIP network incorrect multicasting will quickly affect VoIP calls and
features.

· Duplicate IP Addressing

Duplicate addresses is a frequent issue.

· Excessive Utilization

A workstation that constantly transmits high traffic levels can flood a network, causing VoIP service to disappear.

· Network Access

An IP network is much more open to users connecting a new device or installing software on existing devices that
then impacts on VoIP.

· Cabling Connections

Technically VoIP can (bandwidth allowing) be run across any IP network connection. In practice, Cat5 cabling is
essential.

H323 Phone Install Page 19

15-601046 Issue 15b (16 July 2009)IP Office 4.2

1.12 User PC Connection

H.232 IP
Phone

PC

Port

With

Voice

Priority

Supports

Gigabit

Adaptor

H.232 IP
Phone

PC

Port

With

Voice

Priority

Supports

Gigabit

Adaptor

1603

4620IP

1603SW

4620SW

1608

4621

1616

4624

*

4601

5601

4602

5602

4602SW

5602SW

4606

*

5610SW

4610SW

5620

4612

*

5620SW

To simplify the number of LAN connections from the user's desk, it is possible to route their PC Ethernet LAN cable via
some H323 IP phones. The LAN cable should be connected from the PC to the socket with a PC symbol ( ) at the back of
the IP phone. This port supports 10/100Mbps ethernet connections. The PC's network configuration does not need to be
altered from that which it previously used for direct connection to the LAN.

Those phones that include a PC pass-through port and also provide priority to phone voice traffic over PC data traffic are
normally indicated by an SW suffix in the phone name. However some phones have a PC pass-through port but do not
provide switching priority.

The table below summarizes the phones:

· *The 4606, 4612 and 4624 phones can be upgraded to provide voice priority switching by fitting an Avaya 30A
Switch Upgrade Base to the phone. In addition, this base also allows the phone to be powered from a IEEE

802.3af Power over Ethernet source.

· Gigabit Ethernet

If a 1000mbps ethernet connection is being used then a separate Gigabit Adapter (SAP 700416985) must be used.
This device splits the data and voice traffic before it reaches the phone, providing a 10/100Mbps output for the
phone and a 10/100/1000Bbps output for the PC. The adapter is powered from the phone's existing PoE supply or
1151 type power supply unit. Refer to the "Gigabit Ethernet Adapter Installation and Safety Instructions" (16-

601543).

H323 Phone Install Page 20

15-601046 Issue 15b (16 July 2009)IP Office 4.2

IP Office IP Phones: User PC Connection

1.13 Power Supply Options

Each H323 IP phone requires a power supply. They do not draw power from the IP Office phone system. Listed below are
the power supply options that can be used.

Spare Wire Power Options

The following power supplies use the normally unused pin 7 & 8 connections in the CAT3 or CAT5 network cable. This is
referred to as "spare wire" or "mid-span" power supply units. They can be used with 4600 Series and 5600 Series IP
phones.

· Avaya 1151D1 Power Supply Unit (PSU)

A power supply unit for a single IP phone. Has a LINE port for the LAN cable from the IP Office, and a PHONE port
for the LAN cable to the IP phone. Power into the PSU requires a 90 to 264V AC, 47 to 63HZ mains supply. A
green LED indicates when power is available.

· Avaya 1151D2 Power Supply Unit

Same as the 1151C1 above but with integral battery backup. When AC mains supply is removed, the battery will
power the IP phone for between 8 hours at light load (2 Watts) and 15 minutes at full load (20 Watts). A green
LED indicates when power is available. A yellow LED indicates when the backup is charging. The green LED flashes
when the phone is running from the backup battery.

Dedicated Plug-Top Power Supply Units

1600 Series IP phones can be powered using plug-top PSU's. Different models of PSU exist for various power outlet
sockets. These connect to the phone using a barrel connector.

H323 Phone Install Page 21

15-601046 Issue 15b (16 July 2009)IP Office 4.2

802.3af Power over Ethernet (PoE) Options

Phone

802.3af
Class

Phone

802.3af
Class

1603

[1]

Class 2

4606, 4612, 4624 Gen2

[2]

Class 0

1608

Class 2

4610SW, 5610

Class 2

1616

Class 2

4620

Class 3

4601, 5601

Class 2

4620SW

Class 2

4602

Class 1

4621SW

[3]

Class 2

4602SW, 5602SW

Class 2

4625SW

Class 3

IEEE 802.3af is a standard commonly known as Power over Ethernet (PoE). It allows network devices to receive power
via the network cable using the same wires as the data signals. All the H323 IP phones supported on IP Office also
support this standard. Note that for phones being used with an add-on unit such as an EU24, EU24BL or BM32, an
individual power supply must be used rather than PoE.

· Exceeding the Class limit of a PoE port or the total Class support of a PoE switch may cause incorrect operation.

1.Requires the addition of a 1603 PoE Splitter (SAP 700415607).

2.GEN1 versions of these phones cannot use PoE. The GEN of a phone can be determined from the label on
the base of the phone. The label text giving the phone's type, for example 4624D, is followed by two
digits which give its generation (GEN) number, for example 4624D01. GEN1 4612 and 4624 phones can
be Ethernet powered using a 30A Switch Upgrade Base unit.

3.4621SW with a Gigabit Adapter is Class 3.

· Avaya 1152A1 Power Distribution Unit (Mid-Span Power Unit)

This is a 1U high 19-inch rack mountable unit. It is available in models to support 6, 12 or 24 PoE devices
including H323 IP phones. For each device, it provides a RJ45 data in ports and a matching RJ45 data and power
out port. It can support a maximum of 200 Watts or a peak of 16.8 Watts per port.

· Power of Ethernet (POE) Switch

The Avaya P333T-PWR Switch is a Ethernet LAN switch which also provides PoE input for up to 24 devices
including H323 IP phones.

· IP Phone Inline Adaptor

This adaptor allows 4602, 4602SW, 4620, 4621 and 4625 H323 IP phones and 5600 Series equivalents to be
powered from a Cisco Catalyst power blade. Using these adaptors, up to 24 H323 IP phones can be supported on
a single power blade. The phones do not provide the Catalyst switch with information on their power requirements
and future changes to Catalyst switch software may affect operation.

H323 Phone Install Page 22

15-601046 Issue 15b (16 July 2009)IP Office 4.2

IP Office IP Phones: Power Supply Options

1.14 File Server Options

During installation and maintenance the phones download software and settings files. In order to do this the phone first
request files for an HTTPS server. If it gets no response it then tries to obtain the files from an HTTP server and finally
from a TFTP server. The address of the server to use is provided through DHCP or entered during static phone
installation.

· The phones will check the file server every time they are restarted. However if they do not find it they will
continue by using the existing files they have. Therefore there is no requirement for the file sever to be
permanently available. The file server is only required during phone installation and maintenance.

For Avaya IP phones using IP Office DHCP, IP Office 4.2+ allows the address of the HTTP server from which those phones
should download their software and settings files to be specified in the IP Office configuration. Previously only a TFTP
server IP address could be specified. 4600 Series and 5600 Series phones attempt to load files via HTTPS and then HTTP
before falling back to TFTP. 1600 Series IP phones only support HTTPS or HTTP.

The following options are available for the file server for IP phones being installed on an IP Office system.

1.IP Office Manager

When running, the IP Office Manager acts as a TFTP server. For systems other than an IP500 running IP Office

4.2+ this option is only supported for up to 5 IP phones.

· For IP Office 4.2 Q4 2008 maintenance, using the IP Office Manager application is supported for HTTP file
requests for up to 5 IP phones. This is done by setting the TFTP Server IP address to that of the IP Office
Manager PC and the HTTP Server IP Address to the control unit IP address.

2.IP Office Unit Memory Card
On Small Office Edition, IP406 V2 and IP500 control units fitted with an additional memory card, that card can be
used to store the software files. The control unit can then act as the TFTP server.

· For IP Office 4.2+, using an Embedded Voicemail memory card is supported for HTTP file requests for up to
50 IP phones. This is done by setting the TFTP Server IP Address and HTTP Server IP Address to the
control unit IP address.

· For IP Office 5.0+, a number of new options have been added for systems where the IP Office control unit
memory card is being used as the file server.

· Using the embedded file management controls within the IP Office Manager application (File |
Embedded File Management), the necessary .bin files can be automatically copied to the memory card
(File | Upload Phone Files).

· Various other files can be auto-generated by the IP Office if not present on the memory card.

3.3rd Party Software
TFTP and HTTP server software is available from many sources including Avaya.

24

H323 Phone Install Page 23

15-601046 Issue 15b (16 July 2009)IP Office 4.2

1.15 File Auto Generation

For IP Office 5.0+, for systems configure to use the IP Office control unit's memory card as the file server source, the IP
Office is able to auto-generate the necessary file if a specific file is not place on the card.

This operation is supported for the following files:

· 46xxupgrade.scr

This file will list the firmware files for 4600 Series and 5600 Series phones supported by the IP Office 5.0+
release. The last line will contain the filename 46xxsettings.txt.

· 16xxupgrade.txt

This file will list the the firmware files for 1600 Series series phones supported by the IP Office 5.0+ in release 5.
The last line will contain the filename 46xxsettings.txt.

· For both the files above, the appropriate .bin files must be manually copied to the memory card. The IP Office

5.0 Manager application provides a control for this (File | Upload Phone Files) through its embedded file
management option (File | Embedded File Management).

· The content of the files above System Locale dependant where different firmware files are required to support
certain language locales (for example Russia).

· 46xxsettings.txt
This file will match the file supplied with the IP Office 5.0+ Manager application except as follows:

· The BRIURI value will be set to indicate the IP Office memory card as

· The LANG1FILE to LANG4FILE values for 1600 Series phone non-English language files will be determined

from the best match to the system locale and the most common user locales. Languages supported are Dutch,
French, French (Canadian), German, Italian, Latin Spanish, Portuguese, Russian, Spanish.

· 1600 Series Language files
If the 46xxsettings.txt file is auto-generated, the matching 1600 Series phones specified in that file will also be
auto-generated.

· <ext>_16xxdata.txt
If the 46xxsettings.txt file is auto-generated, it will specify the IP Office memory card as the location for phones
to backup and restore user settings. If no file exists for a user, a file will be auto-generated.

H323 Phone Install Page 24

15-601046 Issue 15b (16 July 2009)IP Office 4.2

IP Office IP Phones: File Auto Generation

1.16 Control Unit Memory Card

The memory card used with the Small Office Edition and IP406 V2 systems can be used to store files other than those
used for embedded voicemail.

· Non-Avaya supplied Compact Flash memory cards can be used for this type of file storage. However, they will not
support embedded voicemail.

· If an Avaya supplied memory card is used, any files stored in this way will reduce the message storage capacity of
the Compact Flash memory card.

Transferring Files to the Card Using File Management

IP Office 4.2+ allows the contents of the memory card in a system to be viewed and updated. This is done using IP Office
Manager and requires the same user name and password access as used for configuration changes.

1.Within IP Office Manager, select File | Advanced | Embedded File Management.

2.The Select IP Office discovery menu is shown. Select the IP Office systems whose memory card you want to

view and click OK.

3.Enter a user name and password for configuration access to that system.

· TFTP: Received TFTP Error "Not Found" in the Manager status bar indicates that no card was detected in
the selected system. To select another system use File | Open File Settings. To return Manager to normal
configuration mode select File | Configuration.

4.The contents of the card are shown in Manager.

· For IP Office 5.0+, all the phone firmware files can be transferred by selecting File | Upload Phone Files.
This will automatically select the phone firmware files that Manager has available and transfer them to the
memory card.

· New files can be drag and dropped to the Files section of the currently selected folder or transferred using

File | Upload File....

· The transfer is serial and can be interrupted by other activities on the IP Office system. Therefore it is
recommended that files are transferred in small batches.

· Existing files can be deleted by right-clicking on the file and selecting Delete.

· Files can be downloaded from the card by right-clicking on the file and selecting Download. The file is

downloaded to the Manager applications working directory.

5.When transfers have been completed, to select another system use File | Open File Settings. To return Manager
to normal configuration mode select File | Configuration.

Transferring Files to the Card Using TFTP

This process allows a specified PC to send files to the memory card and tells the IP Office system to use the memory
card. The location of the bin files should be the top level folder of the card.

1.Using Manager, receive the IP Office system's configuration.

2.On the System tab of the System form, set the File Writer IP Address to the IP address of the PC from which
sending files to the memory card will be allowed.

3.Send this configuration back to the IP Office unit and allow it to reboot.

4.Within Windows, select Start | Run.

5.Enter cmd and then click OK.

6.Within the command window, you can use TFTP to upload files to the memory card. For example:

c:\tftp -i 192.168.42.1 put d:\IPSets Firmware\4601dbtel1_82.bin

7.The above command will send the file d:\IPSets Firmware\4601dbtel1_82.bin to the IP Office units LAN1 IP
address. For additional information about the TFTP command, enter TFTP. If a destination needs specifying, the
memory card is treated as the IP Office's drive a:.

8.Receive the IP Office system's configuration again.

9.On the System tab of the System form, set the TFTP Server IP Address to the unit's own LAN1 IP address.

10.Send this configuration back to the IP Office unit and allow it to reboot. The IP Office system will now look on the
memory card for any files it needs to download following a reboot.

11.If in future an upgrade or file transfer from the Manager PC is required, the TFTP Server IP Address will first need
to be changed back to the Manager PC's IP address.

H323 Phone Install Page 25

15-601046 Issue 15b (16 July 2009)IP Office 4.2

Chapter 2.

Installation

H323 Phone Install Page 27

15-601046 Issue 15b (16 July 2009)IP Office 4.2

2. Installation

Check the following before beginning installation:

1.o IP Office Manager PC

Check that the applications for configuring and monitoring an IP Office system are available and able to connect to
that system.

· o Check that IP Office Manager and IP Office System Status Application (SSA) or System Monitor are installed
and can be used to connect to the IP Office system.

· o Verify that you can receive the configuration from the system and send it back to the IP Office.

· o Ensure that the Manager PC has been given a static IP address.

2.o Voice Compression Channels

The IP Office Unit must be fitted with a voice compression channels . Use either SSA or System Monitor
application to verify that the voice compression channels are available. SSA list the VCM channels on the Resource
screen. The initial lines of Monitor output include the item VCOMP= which will state the number of channels
installed in the control unit.

3.o File Server Settings

Using Manager, receive the configuration from the IP Office. Select System and then select the System tab.
Check the following:

· o System Name

On the System tab ensure that a Name for the IP Office Unit has been entered.

· o TFTP Server IP Address

If using TFTP to download software file to the phones, enter the TFTP server address here. This address is
used by the IP phones (excluding 1600 Series) being supported by IP Office DHCP. If another DHCP server is
being used, that address must be set via the DHCP settings on that server, see Alternate DHCP Setup .

· The default 0.0.0.0 will cause the phones to broadcast for any TFTP server available on the same subnet
as themselves.

· To use the memory card installed in the system, enter the LAN1 IP address of the IP Office system (the
address is shown on the LAN1 tab). To use this option the card must be loaded with the IP phone
software files, see Control Unit Memory Card .

· If a 3rd-party TFTP server is being used, set the IP address to the address of the PC running that
software.

· o HTTP Server IP Address

IP Office 4.2+ supports the use of HTTP for file requests from IP phones. This is necessary for 1600 Series
phones and is supported by all other Avaya IP phones. This address is used by the IP phones being supported
by IP Office DHCP. If another DHCP server is being used, that address must be set via the DHCP settings on
that server, see Alternate DHCP Setup .

· The default 0.0.0.0 disables HTTP support.

· For IP Office 4.2, using the Embedded Voicemail memory card is also supported for HTTP file requests for

up to 50 IP phones. This is done by setting the TFTP Server IP Address and HTTP Server IP Address
to match the control units IP address. This is supported for up to 50 IP phones.

· If a 3rd-party HTTP server is being used, set the IP address to the address of the PC running that
software.

4.o H323 Gatekeeper Settings

Select System and then select the LAN1 tab. Select the Gatekeeper sub tab. Check the following settings:

· o H323 Gatekeeper Enabled

Ensure that this option is enabled.

· o H323 Auto-created Extn

This installation process assumes that this option is enabled until after installation of the phones has been
completed. If not enabled the you must manually add extensions to the IP Office configuration before
installation. See Manually Creating Extensions .

· o H323 Auto-create User

This installation process assumes that this option is enabled until after installation of the phones has been
completed. If not enabled the you must manually add users to the IP Office configuration before installation.

· o Primary Site Specific Option Number

Devices being supported by DHCP can request device specific information using a site specific option number
(SSON). This method is used for Avaya IP phones to request phone specific information from a DHCP server.
For IP phones beign supported by IP Office DHCP, the SSON set here should match that being used by the
phones. By default Avaya 4600 and 5600 Series IP phones use the 176 as their SSON.

· Secondary Site Specific Option Number (IP Office 4.2+)

This field allows a second SSON to be specified for use by IP phones. By default Avaya 1600 Series IP phones
use 242 as their SSON.

70

25

32

17

70

H323 Phone Install Page 28

15-601046 Issue 15b (16 July 2009)IP Office 4.2

5.o DHCP Server

If not using the IP Office for DHCP, check that the alternate DHCP server has been configured for the IP phones. It
will need to include details of the files server and gateway settings. See Alternate DHCP Setup . If using the IP

70

Office for DHCP, select System and then the LAN1 or LAN2 tab.

· o DHCP Mode

Check that the IP Office is set as Server. This allows it to respond to DHCP requests on its subnet.

· o Number of DHCP IP Addresses

Set this to a number sufficient for all the IP devices, including phones, that will be supported by the IP Office
DHCP.

· o Advanced/DHCP Pools (IP500 4.2+)
For IP Office 4.2+ on IP500 systems, multiple ranges of IP addresses can be configured for use by IP Office
DHCP. In addition, the IP Office DHCP can be restricted to Avaya IP phones only by selecting Apply to Avaya
IP Phones Only.

6.o IP Phone Software and Settings Files

The software for IP phone installation is supplied on the IP Office Administrator Applications CD. Those files must
be placed on the file server. The files are automatically installed as part of the IP Office Manager application and so
are already present if IP Office Manager is used as the file server.

· If another source is used as the file server, the software and settings files must be copied to that server. For
pre-IP Office 4.2 system the files must be copied from the Manager application folder. For IP Office 4.2+ the
files can be copied from the location program files\Avaya\IP Office\Manager on the installation CD.

· If it does not exist already an additional file, 46xxsettings.txt, is also required. See Creating a 46xxsettings.

txt File .

30

7.o Extension Number and User Name Details

A full listing of the planned extension number and user name details is required. The planned extension number
must be unused and is requested by the phone during installation.

Installation:

H323 Phone Install Page 29

15-601046 Issue 15b (16 July 2009)IP Office 4.2
