IP Office 3.0

5620SW + EU24 User’s Guide

40DHB0002USEP – Issue 1 (1st March 2005)

Page ii - Contents

Contents

The 5620 IP Telephone......................................................................................... 6

Overview of the 5620...............................................................................................................6

Call Appearance Keys .............................................................................................................8

Call Appearance/Function Key Icons .................................................................................................................9

Basic Call Handling Features ............................................................................ 10

Answer Incoming Calls ..........................................................................................................10

Make a Call............................................................................................................................ 10

Clearing a Call ....................................................................................................................... 10

Headset Working ................................................................................................................... 11

Speakerphone .......................................................................................................................11

Mute....................................................................................................................................... 12

Hold .......................................................................................................................................12

Speed Dial ............................................................................................................................. 12

Redial .................................................................................................................................... 12

Transfer ................................................................................................................................. 13

Conference ............................................................................................................................ 13

Speed Dials ......................................................................................................... 14

Overview of Speed Dials........................................................................................................ 14

Using Speed Dials ................................................................................................................. 15

Dialing a Speed Dial ......................................................................................................................................15

Adding a Speed Dial from the Call Log .........................................................................................................15

Editing a Speed Dial ......................................................................................................................................15

Deleting a Speed Dial ....................................................................................................................................15

Adding a New Speed Dial..............................................................................................................................16

Using the Call Log .............................................................................................. 18

Overview of the Call Log........................................................................................................18

Using the Call Logs................................................................................................................ 19

To Access the Call Logs...................................................................................................................................19

To Display an Individual Log Entry...................................................................................................................19

To Make a Call from an Individual Log entry....................................................................................................19

To Turn a Log Entry into a Speed Dial .............................................................................................................20

To Delete an Individual Log Entry ....................................................................................................................20

To Delete All Entries from a Log ......................................................................................................................20

To Exit the Call Logs ........................................................................................................................................20

Changing the 5620 Options ............................................................................... 21

Telephone Options Overview................................................................................................. 21

Application Options................................................................................................................ 22

Redial................................................................................................................................................................22

Phone Screen on Answer.................................................................................................................................22

Phone Screen on Calling..................................................................................................................................22

Display Call Timers...........................................................................................................................................23

Message Display Rate......................................................................................................................................23

Visual Alerting...................................................................................................................................................23

Personal Ringing ...................................................................................................................24

View IP Settings..................................................................................................................... 24

IP Address Settings .......................................................................................................................................24

Quality of Service (QoS) Information.............................................................................................................24

Phone Interface .............................................................................................................................................24

Miscellaneous Information .............................................................................................................................24

Adjusting the Display Contrast............................................................................................... 25

Logging off the 5620 IP Telephone........................................................................................ 25

Backup/Restore Options........................................................................................................ 25

Changing Feature Key Labels ............................................................................................... 26

Language Selection ............................................................................................................... 26

Page ii - Contents IP Office 3.0 5620SW + EU24 User’s Guide 40DHB0002USEP – Issue 1 (1st March 2005)

Contents - Page iii

)

Contents (Cont.

Function Keys..................................................................................................... 27

Overview of Function Keys .................................................................................................... 27

Function Key Programming ...................................................................................................28

Shorthand Programming Mode ........................................................................................................................29

Longhand Programming...................................................................................................................................30

Function Key Features...........................................................................................................30

Dial (#) ...........................................................................................................................................................30

Group (#)........................................................................................................................................................31

User (#) ..........................................................................................................................................................31

Absnt - Set Absent Text.................................................................................................................................31

Acct - Account Code Entry (!) ........................................................................................................................31

AD - Abbreviated Dial (!)................................................................................................................................32

Admin - Self-Administer (!).............................................................................................................................32

Apear - Appearance.......................................................................................................................................32

AutCB - Automatic Callback (!)......................................................................................................................32

Busy - Busy....................................................................................................................................................33

BusyH - Busy On Held...................................................................................................................................33

CFrwd - Call Forwarding All (!) ......................................................................................................................33

ClrCW - Clear CW .........................................................................................................................................34

CnfRV - Conference Meet Me .......................................................................................................................34

Conf+ - Conference Add................................................................................................................................34

CPark - Call Park (!).......................................................................................................................................34

CPkUp - Call Pickup (!)..................................................................................................................................35

CWOff - Call Waiting Off................................................................................................................................35

CWOn - Call Waiting On................................................................................................................................35

CWSus - Call Waiting Suspend.....................................................................................................................35

DCW - Dial CW..............................................................................................................................................36

Dir - Directory (!) ............................................................................................................................................36

Dirct - Dial Direct............................................................................................................................................36

DNDOn - Do Not Disturb On..........................................................................................................................36

DNDOf - Do Not Disturb Off...........................................................................................................................37

DNDX+ - Do Not Disturb Exception Add .......................................................................................................37

DNDX- - Do Not Disturb Exception Delete ....................................................................................................37

DPkUp - Directed Call Pickup (!) ...................................................................................................................37

Drop - Drop (!)................................................................................................................................................38

DTone - Secondary Dial Tone .......................................................................................................................38

Emrgy - Dial Emergency................................................................................................................................38

Flash - Flash Hook (#) ...................................................................................................................................38

FolTo - Follow Me To.....................................................................................................................................38

FwBNo - Forward On Busy Number..............................................................................................................39

FwBOn - Forward On Busy On......................................................................................................................39

FwBOf - Forward On Busy Off.......................................................................................................................39

FwdH+ - Forward Hunt Group Calls On ........................................................................................................40

FwdH- - Forward Hunt Group Calls Off .........................................................................................................40

FwdNo - Forward Number .............................................................................................................................40

FwdOf - Cancel All Forwarding......................................................................................................................40

FwNOn - Forward On No Answer On............................................................................................................41

FwNOf - Forward On No Answer Off.............................................................................................................41

FwUOn - Forward Unconditional On .............................................................................................................41

FwUOf - Forward Unconditional Off ..............................................................................................................41

GrpPg - Group Paging (!)...............................................................................................................................41

HdSet - Headset Toggle (!)............................................................................................................................42

Here- - Follow Me Here Cancel .....................................................................................................................42

Here+ - Follow Me Here ................................................................................................................................42

IP Office 3.0 5620SW + EU24 User’s Guide Contents - Page iii 40DHB0002USEP – Issue 1 (1st March 2005)

Page iv - Contents

)

Contents (Cont.

HfAns - Internal Auto-Answer (!)....................................................................................................................42

HGEna - Hunt Group Enable .........................................................................................................................43

HGDis - Hunt Group Disable .........................................................................................................................43

HGNS+ - Set Hunt Group Night Service (!) ...................................................................................................43

HGNS- - Clear Hunt Group Night Service .....................................................................................................43

HGOS+ - Set Hunt Group Out of Service......................................................................................................44

HGOS- - Clear Hunt Group Out of Service....................................................................................................44

Hold - Hold Call..............................................................................................................................................44

HoldCW - Hold Call Waiting...........................................................................................................................44

IAuto - Automatic Intercom ............................................................................................................................45

ICSeq - Set Inside Call Sequence .................................................................................................................45

IDial - Dial Intercom .......................................................................................................................................45

Inclu - Dial Inclusion.......................................................................................................................................45

Intru - Call Intrude ..........................................................................................................................................45

Listn - Call Listen ...........................................................................................................................................46

Login - Extn Login..........................................................................................................................................46

Logof - Extn Logout .......................................................................................................................................46

Music - Hold Music ........................................................................................................................................46

NATim - Set No Answer Time........................................................................................................................47

OCSeq - Set Outside Call Sequence ............................................................................................................47

Page - Page...................................................................................................................................................47

Park - Park (#)................................................................................................................................................47

Park - Call Park to Other Extension (!) ..........................................................................................................48

PCall - Priority Call.........................................................................................................................................48

PhyEx - Dial Physical Extension by Number .................................................................................................48

PickA - Call Pickup Any .................................................................................................................................49

PickG - Call Pickup Group.............................................................................................................................49

PickM - Call Pickup Members........................................................................................................................49

Prog - Abbreviated Dial Program (!) ..............................................................................................................49

Quota - Clear Quota ......................................................................................................................................50

Queue - Call Queue.......................................................................................................................................50

RBak+ - Ringback When Free.......................................................................................................................50

RBak - Cancel Ringback When Free.............................................................................................................50

RBSeq - Set Ringback Sequence .................................................................................................................51

Recor - Call Record .......................................................................................................................................51

Relay - Relay Pulse .......................................................................................................................................51

Rely+ - Relay On ...........................................................................................................................................51

Rely- - Relay Off ............................................................................................................................................51

Resum - Resume Call....................................................................................................................................52

Rtriv - Retrieve Call........................................................................................................................................52

Ride - Ride Call..............................................................................................................................................52

RngOf - Ringer Off (!) ....................................................................................................................................52

SAC - Send All Calls (!) .................................................................................................................................53

Spres - AD Suppress (!).................................................................................................................................53

Steal - Call Steal ............................................................................................................................................53

SusCW - Suspend CW ..................................................................................................................................53

Suspe - Suspend Call ....................................................................................................................................54

Timer - Timer (!).............................................................................................................................................54

TmDay - Time of Day (!) ................................................................................................................................54

Toggl - Toggle Calls.......................................................................................................................................54

VMRB- - Voicemail Ringback Off...................................................................................................................54

VMRB+ - Voicemail Ringback On..................................................................................................................55

VMCol - Voicemail Collect .............................................................................................................................55

VMOff - Voicemail Off ....................................................................................................................................55

VMOn - Voicemail On ....................................................................................................................................55

WUTim - Set Wrap Up Time..........................................................................................................................55

Page iv - Contents IP Office 3.0 5620SW + EU24 User’s Guide Error! No text of specified style in document.

Contents - Page v

)

Contents (Cont.

System Features................................................................................................. 56

Introduction............................................................................................................................ 56

Making Calls .......................................................................................................................... 56

Answering Calls ..................................................................................................................... 56

Call Waiting............................................................................................................................ 57

Call Forwarding...................................................................................................................... 57

Diverting Calls........................................................................................................................ 57

Do Not Disturb ....................................................................................................................... 57

Voicemail ............................................................................................................................... 58

Default Feature Codes...........................................................................................................58

Web Browsing..................................................................................................... 59

Overview of Web Browsing.................................................................................................... 59

Accessing External WAP Websites ....................................................................................... 59

Web Navigation Controls ....................................................................................................... 60

Entering Data......................................................................................................................... 61

Management and Troubleshooting ................................................................... 62

Overview................................................................................................................................ 62

Testing your phone ................................................................................................................ 62

Testing the Telephone's Lights and Display..................................................................................................62

Troubleshooting Chart ...........................................................................................................62

Resetting the IP Telephone ...................................................................................................64

Resetting Your Phone....................................................................................................................................64

Power Cycling Your Phone............................................................................................................................64

EU24 Expansion Module.................................................................................... 65

EU24 Overview...................................................................................................................... 65

Connection............................................................................................................................. 65

Using the EU24 Expansion Module ....................................................................................... 66

Viewing the Alternate Display...........................................................................................................................66

Selecting a Call Appearance/Feature Button ...................................................................................................66

Understanding Call Appearance/Feature Button Status Icons.........................................................................66

Index .................................................................................................................... 67

IP Office 3.0 5620SW + EU24 User’s Guide Contents - Page v 40DHB0002USEP – Issue 1 (1st March 2005)

Page 6 - Overview of the 5620 The 5620 IP Telephone

The 5620 IP Telephone

Overview of the 5620

This guide covers the use of the Avaya 5620 telephone, running in Key and Lamp mode, on Avaya IP Office telephone systems operating with Level 3.0 software. The diagram below shows the main 5620 telephone features.

1. Display, Call Appearance and Feature buttons: The Call Appearance Keys allow the user to handle multiple calls with the display showing call information, e.g. the name/phone number, etc. There are four pages in the display; giving (at default) three call appearance lines and up to 21system features that can be allocated to the function keys. See Call Appearance Keys on page 8 and Function Keys on page 27. The information displayed varies according to the active feature.

2. Message waiting lamp:

Lit continuously when the user has voicemail messages waiting. Can also be set to flash when the phone is ringing.

4. Options:

Page 6 - Overview of the 5620 IP Office 3.0 5620SW + EU24 User’s Guide The 5620 IP Telephone Error! No text of specified style in document.

Page Right/Left:

Shifts from one page to another in the same application when the display presents the paging indicator ( is not displayed.

Displays the Options main screen, from which display and application settings can be updated.

). These buttons have no effect when the paging indicator

Overview of the 5620 The 5620 IP Telephone - Page 7

5. Call Handling Buttons: See Basic Call Handling on page 10.

•

Red button used to place a call on hold

•

Transfers a call to another phone

•

Sets up conference calls with more than one other person.

•

Drops the current call or, if on a conference call, drops you from the conference.

•

Redials the last number dialed or displays the last 6 numbers dialed from the phone, depending on configuration via the Options menu.

6. Numeric (Dialing) Pad: Standard 12 button pad for dialing phone numbers.

Adjusts the handset, speaker, headset, or ringer volume, depending on which item is in use. As you increase or decrease the volume, the top display area provides either a speaker, headset, handset, or ringer icon to indicate for which item you are adjusting volume, followed by a visual “volume meter” showing the volume level. These buttons also control the volume of the key click sounds made when you press fixed buttons on the phone, such as the dial pad or softkeys.

Hold:

Transfer:

Conference:

Drop:

Redial:

Volume Controls:

Turns off the active Speaker, handset, or headset microphone to prevent the other person from hearing you. The associated LED lights steadily when the handset or headset is muted.

With a headset connected, changes audio control from the handset or speaker to the headset. The associated LED lights steadily when the headset is active. The headset jack socket is located on the base of the telephone underneath the front edge.

10.

Access the speakerphone. The light associated with this button turns on when the speakerphone is active.

11.

Displays the phone application main screen or, if applicable, exits the current IP Office based feature, such as Speed Dial or Call Log, and normalizes the display.

12.

Used to navigate to or initiate certain features, such as Speed Dial or Call Log, as well as control certain actions within the features. These keys correspond to the text prompts in the display screen immediately above them.

Mute and LED Indicator:

Headset and LED Indicator:

Speaker and LED Indicator:

Phone/Exit:

Softkeys:

IP Office 3.0 5620SW + EU24 User’s Guide The 5620 IP Telephone - Page 7 40DHB0002USEP – Issue 1 (1st March 2005) Overview of the 5620

Page 8 - Call Appearance Keys The 5620 IP Telephone

Call Appearance Keys

There are four pages of Call Appearance and Function Keys. You can step through these with the

keys set as ‘call appearance’ keys. These keys show that the 5620 is a multi-line phone and are indicated as a=, b= and c=. The remaining 21 Function Keys can have system features allocated to them, by your System Administrator, that are specific to your requirements (see page 27).

Your System Administrator can change a call appearance key with:

• A Bridged Appearance

A bridged appearance key matches the status and operation of the Call Appearance Key on a pre-defined colleague’s telephone. Hence, you can pick-up, make and receive calls on behalf of your colleague.

• A Line Appearance

An IP Office exchange line (but not IP lines) can be allocated to you such that the status of that line is displayed and you can use the line appearance key to make and receive calls.

• Call Coverage Appearance

A call coverage appearance key alerts you when a pre-defined colleague is receiving a call. The covered user does not need to be using call appearance keys. Hence, you can pick-up calls on behalf of your colleague.

• A System Feature

System Features, such as Abbreviated Dial (that automatically dials a frequently used number) can be set against key and/or dial pad digits. See Function Keys on page 27.

All of the above can only be allocated to you by your System Administrator. For details of Bridged, Line and Call Coverage Appearance Keys set-up and their operation, refer the IP Office Key and Lamp Operation manual.

CAUTIONS:

1. Having more than two Call Appearance keys is very useful. When holding a call you can answer/make another call and then switch between calls or transfer or conference. If you are set to receive call waiting indication, the waiting call is shown against the next call appearance key.

keys. At default, first page of the main call screen contains three

2. Although the System Administrator can replace the Call Appearance Keys with:

• A Bridged Appearance

• A Line Appearance

• Call Coverage Appearance

• System Features

This would severely restrict the use of features such as conference and transfer.

It is for these reasons that it is strongly recommended that all Call

Appearance keys remain at their default settings.

Page 8 - The 5620 IP Telephone IP Office 3.0 5620SW + EU24 User’s Guide Call Appearance Keys 40DHB0002USEP – Issue 1 (1st March 2005)

Call Appearance Keys The 5620 IP Telephone - Page 9

System Features

System Features can only be set against soft Function Keys by your System Administrator. However, your System Administrator may allocate you two ‘self administrator’ features that will enable you to add System Features to your soft Function Keys. Refer to Function Key Features on page 30 for details of the System Feature that can only be allocated to you by your System Administrator.

In addition, there are a number of System Features that you can always access yourself by the use of short codes. Refer to System Features on page 56 for details of System Features that you can always access yourself by dialing short codes, e.g. *17 to listen to your VoiceMail messages.

Call Appearance/Function Key Icons

The icons displayed against the Call Appearance/Feature Keys allow you to determine the status (for example, on Hold) of each call. Icons also indicate whether a feature has been activated for a particular button.

• Incoming Call:

symbol next to a call appearance key indicates an incoming call.

A Pressing the adjacent hold.

• Connected

symbol next to a call appearance key indicates that it is the currently connected

A call. The caller's telephone number (if available) is also shown. Pressing the adjacent display.

• On Hold

A Pressing the adjacent call on hold.

• Function Active:

The button to the left or right of the function key is active.

symbol next to a call appearance key indicate a call on hold.

key answers the call and puts any other current call on

key puts the call on hold. An H is also shown on the

key takes the call off hold and puts any other current

e or f

IP Office 3.0 5620SW + EU24 User’s Guide The 5620 IP Telephone - Page 9 40DHB0002USEP – Issue 1 (1st March 2005) Call Appearance Keys

Page 10 - Answer Incoming Calls Basic Call Handling Features

Basic Call Handling Features

Answer Incoming Calls

When a call arrives at your 5620 telephone, you will hear a ringing tone and a blinking bell icon (

To answer an incoming call:

Do one of the following:

• If you are not active on another call, answer the call using your handset, headset, or

speakerphone (see Speakerphone on page11).

• If you are active on a call already, place the active call on hold (see Hold on page

12), and then answer the incoming call by selecting the call appearance key.

• If the call appearance for the ringing call is not displayed on the current screen

page, use locate the call appearance for the ringing call, press the corresponding call appearance button.

Make a Call

You can make calls from the 5620 telephone using a variety of methods as follows:

) icon appears against the associated call appearance key.

Exit to return to the first page of the Home screen. When you

To manually make a call:

1. Dial the required number on the key pad (remember to include the required access code (for example, 9) for an outside line) and listen to the progress of the call.

2. Adjust speakerphone volume as necessary.

• To change the volume use the

the volume level. (There are eight volume levels.)

3. If the call is not answered, you can clear the call by pressing

Drop

4. When the call is answered, either speak or pick up the handset and speak to the called party.

To automatically make a call: Do any of the following:

• Press

key or

• Access the Call Log and initiate a call to a specific entry.

See To Access the Call Logs on page 19. or

• Access the Speed Dial List in your personal directory and initiate a call to a specific

entry. See Using Speed Dials on page 15.

• When the call is answered, either speak or pick up the handset and speak to the

called party.

Redial. Select from up to the last three dialed numbers and press the

next to next to your choice.

and buttons. The display shows

Speaker or

Clearing a Call

To clear an established call either:

1. Replace the handset or

2. Press working when you will then hear silence.

Page 10 - Basic Call Handling Features IP Office 3.0 5620SW + EU24 User’s Guide Answer Incoming Calls 40DHB0002USEP – Issue 1 (1st March 2005)

Drop. You will hear dial tone, unless you are in ‘call centre mode’ of

Headset Working Basic Call Handling Features - Page 11

Headset Working

When a headset is to be used on your 5620, it must be plugged in to the headset socket on the side of your 5620 telephone. To activate the headset and switch off the

handset, press headset working is activated.

To answer an incoming call:

1. Press the call appearance key next to the flashing bell icon (

To clear a headset call:

1. Press

To manually make a call:

1. Dial the number (remember to include the required access code (for example, 9) for an outside line) and listen to the progress of the call.

To automatically make a call:

Do any of the following:

• Press

key or

• Access the Call Log and initiate a call to a specific entry.

See Using the Call Log on page 18. or

• Access the Speed Dial List in your personal directory and initiate a call to a specific

entry. See Using Speed Dials on page 15.

• When the call is answered, speak to the called party.

next to next to your choice.

Headset. The lamp beside the button is illuminated when

Drop.

Redial. Select from up to the last three dialed numbers and press the

Speakerphone

The two-way built-in speakerphone allows you to make and answer calls without lifting the handset. Keep in mind that two-way speakerphones may not operate satisfactorily in every environment (such as in very noisy locations).

To make or answer a call without lifting the handset, or to use the speakerphone with any feature:

1. Press

2. Make or answer the call, or access the selected feature.

3. Adjust the speakerphone volume if necessary.

• To change the volume, use the

To change from the speakerphone to handset (or headset if fitted)

1. Pick up the handset (or press

Changing from handset to speakerphone:

1. Press

2. Hang up the handset.

Ending a speakerphone call:

1. Press

Speaker. The LED beside the button illuminates.

and buttons. The display bar at the top of the display screen shows the volume level. (There are eight volume levels.)

Headset) and talk.

Speaker. The LED beside the button illuminates.

Speaker again. The LED beside the button goes out.

IP Office 3.0 5620SW + EU24 User’s Guide Basic Call Handling Features - Page 11 40DHB0002USEP – Issue 1 (1st March 2005) Headset Working

Page 12 - Mute Basic Call Handling Features

Mute

During an active call, the Mute feature prevents the party with whom you are speaking from hearing you. This feature is most commonly used in conjunction with the Speakerphone, but can be used to hold an off-line conversation at any time during a call.

Preventing the other person on the line from hearing you:

1. Press

• The other party cannot hear you. The indicator next to the Mute button lights when Mute is active.

2. To reinstate two-way conversation, press

Mute.

Mute again.

Hold

The Hold feature puts a call on hold until you retrieve it.

Placing a call on hold:

1. Press the

• The

Retrieving the held call:

1. Press the call appearance key with the

• The call is now active.

Note: After a pre-set time (defined by your System Administrator), you are reminded

that you have a call on hold by the

and the phone ringing.

Also see Transfer on page 13.

Hold or the Call Appearance key for the call.

Hold icon is displayed.

hold icon changing for a few moments to

Speed Dial

The Speed Dial feature allows you to have the 5620 telephone automatically dial calls to telephone numbers stored in your personal directory. See Speed Dials on page 14.

To make a call to a personal directory entry using the Speed Dial feature:

1. Press the

2. Press the button next to the entry you want to call.

3. If the entry you want is not displayed, use

4. The 5620 telephone dials the number for you.

Redial

The Redial (or Last Number Dialed) feature automatically redials a previously dialed extension or outside number (up to 24 digits). Your 5620 will store the up to three of the last numbers dialed.

Note: If you have dialed the same number twice in succession, it will only have one

To redial previously dialed number:

1. Press

SpDial softkey. The Speed Dial screen is displayed.

and to cycle through the entries or key the first letter of the required name to jump to the page with a matching entry.

appearance in the redial list.

Redial and press the call appearance key next to the required

number.

Page 12 - Basic Call Handling Features IP Office 3.0 5620SW + EU24 User’s Guide Mute 40DHB0002USEP – Issue 1 (1st March 2005)

Transfer Basic Call Handling Features - Page 13

Transfer

The Transfer feature allows you to transfer a call from your telephone to another extension or outside number.

To transfer the current call to another extension

1. With a call in progress, press

2. When you hear dial tone, dial the number to which the call is to be transferred.

3. Do one of the following:

Conference

The Conference feature allows you to conference other parties (including yourself) into a call.

Notes: 1. The number of parties allowed in a conference is controlled by your

2. Two Call Appearance keys are required for the conference feature.

Transfer or Hold.

• To transfer the call without announcing it, press

hang up. The transfer is complete.

• To announce the call before transferring it, wait for the called party to answer.

If the called party is willing to accept the call, press complete the transfer. If the called party does not wish to accept the call, press return to the held call by pressing its call appearance button.

• If the line is busy or if there is no answer, press

You can return to the held call by pressing its call appearance button.

telephone system.

Transfer again and

Transfer again to

Drop. You can

Drop.

To add another party to a call:

1. Press

2. Dial the number of the person you want to add to the call.

3. Wait for an answer.

4. To add the person to the call, press

• If the called party does not answer or does not want to join the conference,

press You can return to the held call by pressing its call appearance button.

5. Repeat steps 1 through 4 for additional conference connections.

To add a held call to an active call:

1. Press

2. Press the call appearance button corresponding to the held call.

3. Press again

To leave a conference call:

To leave a conference, press

Conference.

Conference again.

Drop.

Conference.

Drop.

IP Office 3.0 5620SW + EU24 User’s Guide Basic Call Handling Features - Page 13 40DHB0002USEP – Issue 1 (1st March 2005) Transfer

Page 14 - Overview of Speed Dials Speed Dials

Speed Dials

Overview of Speed Dials

The 5620 can store up to 108 personal speed dials, accessed by selecting SpDial on the display.

• The speed dials are sorted alphabetically.

• Pressing the

with that name.

• The

W X symbol indicates that there are more pages.

You can more between pages using the

or key adjacent to a name, dials the speed dial number stored

Page Left and Page Right keys.

Pressing on page 16.

You can also press settings. Editing a Speed Dial on page15.

Note: Speed dials can be used for any numbers that can be manually dialed from

Add allows you to add a new speed dial. See Adding a New Speed Dial

Edit to display an existing speed dial and edit it’s current

the extension. Where, for external calls, a dialing prefix is required then that prefix must be part of the speed dial number.

Page 14 - Speed Dials IP Office 3.0 5620SW + EU24 User’s Guide Overview of Speed Dials 40DHB0002USEP – Issue 1 (1st March 2005)

Using Speed Dials Speed Dials - Page 15

Using Speed Dials

Dialing a Speed Dial

You can use the speed dial directory to make a call with the handset on hook or off hook.

1. Press

2. The W X symbol is shown if there is more than one page of speed dials. You can move between pages using the

3. When the speed dial required is shown on the screen, press the adjacent to the speed dial name.

4. Continue as per a normal call.

Adding a Speed Dial from the Call Log

You can create a new speed dial from a call log entry. See To Turn a Log Entry into a Speed Dial on page 20. This process will start the normal speed entry screen but prefilled with the name and number from the call log entry.

Editing a Speed Dial

1. Press SpDial

2. Press

3. Select the speed dial entry you want to edit. Press

4. When the required entry is displayed, press the adjacent

5. Edit the speed dial using the same methods as for adding a new speed dial. See Adding a New Speed Dial on page 16.

6. Press Save to return to the speed dial list

SpDial to display the speed dial directory.

Page Left and Page Right keys.

or key

Edit.

and to display different pages of speed dials.

or key.

Deleting a Speed Dial

1. Press SpDial

2. Press

3. Select the speed dial entry you want to delete. Press

4. When the required entry is displayed, without deleting.

5. Select another entry to delete or press

Delete.

and to display different pages of speed dials.

Delete again or Cancel to exit

Exit to return to the speed dial list.

IP Office 3.0 5620SW + EU24 User’s Guide Speed Dials - Page 15 40DHB0002USEP – Issue 1 (1st March 2005) Using Speed Dials

Page 16 - Using Speed Dials Speed Dials

Adding a New Speed Dial

1. Press SpDial followed by Add. If Add does not appear, then the speed dial list is full. Hence, you must first delete an existing entry before adding any new entry. See Deleting a Speed Dial on page15.

2. Begin entering text using the telephone keypad. Each key is marked with the letters it provides. You may have to press the key more than once depending on the character you require.

• For example, the 2 key is also marked as A, B and C. To enter a C press the

key until a C is displayed.

• To enter the next character from the same key, e.g. a, press

the cursor right and then enter the character or simply press another key.

• If you make a mistake, use

the incorrect character and then use

4. As you enter the Name characters you can use a number of other controls.

•

• - Moves the cursor right one character.

•

5. When the Name has been entered, press

Case - Change the case of the current character between upper and lower

case.

- Moves the cursor left one character Clear - Delete the whole name. Backspace - Delete the character to the left of the cursor. Apostrophe – Inserts an Apostrophe between characters. Hyphen – Inserts a Hyphen (-) between characters. Comma – Inserts a Comma (,) between characters. Space – Inserts a space between characters.

Cancel - Return back to the speed dial directory without making any

changes.

or to move the cursor to the right of

Backspace to delete it.

Number.

to move

Page 16 - Speed Dials IP Office 3.0 5620SW + EU24 User’s Guide Using Speed Dials 40DHB0002USEP – Issue 1 (1st March 2005)

Using Speed Dials Speed Dials - Page 17

6. The Number menu is displayed. Enter the required number, including any external line access digit (9 say):

• If you make a mistake, use

the incorrect character and then use

7. As you enter Number characters you can use other controls. Note: The controls on this screen are context sensitive, i.e. they only appear

when applicable. For example Save only appears when both a name and number have been entered.

•

- Moves the cursor right one character.

•

- Moves the cursor left one character.

•

8. When the Number has been entered, press

Clear - Delete the whole number. Backspace - Delete the character to the left of the cursor. Apostrophe – Inserts an Apostrophe between characters. Hyphen – Inserts a Hyphen (-) between characters. Comma – Inserts a Comma (,) between characters. Space – Inserts a space between characters.

Save - Save the speed dial changes. Cancel - Return back to the speed dial directory without making any

changes.

or to move the cursor to the right of

Backspace to delete it.

Save.

IP Office 3.0 5620SW + EU24 User’s Guide Speed Dials - Page 17 40DHB0002USEP – Issue 1 (1st March 2005) Using Speed Dials

Page 18 - Overview of the Call Log Using the Call Log

Using the Call Log

Overview of the Call Log

The 5620 maintains a call log, accessed by selecting Log on the display.

The call logs keeps logs of missed calls, outgoing calls made and incoming calls answered. Each of these logs includes the 30 most recent calls in its category. The details shown are:

• The name of the called or calling party if available.

• The number of the called or calling party.

• The time of the call.

• The date of the call if prior to the current day.

• The

between pages using the

symbol indicates that the log contain more pages of entries. You can more

Page Left and Page Right keys.

Note: Only outgoing calls made using the dial pad or a SpDial entry are logged.

Pressing the Each individual log entry includes:

• The number of the called or calling party if available.

• The number of the called or calling party.

• The time of the call.

• The date of the call.

• The duration of the call for outgoing and answered calls (not shown above for

missed calls)

or key adjacent to a log entry displays full details of that log entry:

Page 18 - Using the Call Log IP Office 3.0 5620SW + EU24 User’s Guide Overview of the Call Log 40DHB0002USEP – Issue 1 (1st March 2005)

Using the Call Logs Using the Call Log - Page 19

Using the Call Logs

Apart from using the call logs for information, you can turn a call log entry into a speed dial for future calls. You can also delete individual log entries or the all entries in a particular log. The following paragraphs detail how to use the Logs.

Note: Call log entries are lost whenever 5620 telephone are disconnected from the

IP Office.

To Access the Call Logs

1. Press Log.

2. The call log always opens in the Missed calls log.

• Missed: The log of missed calls, i.e. those calls that rang your extension but

were not answered. This includes calls that were diverted to voicemail or another number after ringing your extension.

3. To select the log required type press either:

• InAns: The log of incoming calls that were answered. This includes both

internal and external calls.

• Outgo: The log of calls made. This includes both internal and external calls.

4. If the selected log contains more than one page of entries, the the

Page Left and Page Right keys to move between pages.

is shown. Use

To Display an Individual Log Entry

1. Locate the log entry in which you are interested from Missed, InAns or

Outgo.

2. Press the

3. The log entry details are shown.

4. Using

or key adjacent to the entry.

Return key to return to the call log.

To Make a Call from an Individual Log entry

1. Locate the log entry in which you are interested from Missed, InAns or

Outgo.

2. Press the

3. The log entry details are shown.

4. Press If the number shown is external but doesn't include the external dialing prefix used by your telephone system, go off-hook, dial the prefix and then press

or key adjacent to the entry.

Call make the call.

Call.

IP Office 3.0 5620SW + EU24 User’s Guide Using the Call Log - Page 19 40DHB0002USEP – Issue 1 (1st March 2005) Using the Call Logs

Page 20 - Using the Call Logs Using the Call Log

To Turn a Log Entry into a Speed Dial

1. Locate the log entry in which you are interested from Missed, InAns or

Outgo.

2. Press the

3. Press

4. The screens for editing and adding speed dials will appear, pre-filled with the information from the log entry. Edit the details if required (see Editing a Speed Dial on page 15).

5. Press

6. You will be returned to the speed dials selection menu.

or key adjacent to it.

Add to SD.

Save or Cancel.

To Delete an Individual Log Entry

1. Locate the log entry in which you are interested from Missed, InAns or

Outgo.

2. Press the

3. Press Press

4. You will be returned to the call log.

or key adjacent to it.

Delete twice. Or: Cancel to return to the call log without deleting the log entry.

To Delete All Entries from a Log

1. Press Log.

2. Press

3. Press

4. Select log without deleting the log entries.

Missed, InAns or Outgo to select the log. DeleteAll.

Delete to delete the log entries. Press Cancel to return to the call

To Exit the Call Logs

1. Press Exit.

Page 20 - Using the Call Log IP Office 3.0 5620SW + EU24 User’s Guide Using the Call Logs 40DHB0002USEP – Issue 1 (1st March 2005)

Telephone Options Overview Changing the 5620 Options - Page 21

Changing the 5620 Options

Telephone Options Overview

The Options button will allow viewing and configuring of certain phone settings. These options are different from the function keys that require configuration by the system administrator.

The phone settings available include:

Application Option:

• Displaying the Phone screen when making a call and/or answering a call.

• Determining how you want the Redial feature to work (redial the last

number called or select from a list of the last three calls).

• Displaying the Call Timer.

• Changing the rate at which messages display.

• Allowing the Voice message light to flash when the telephone rings.

Personal Ringing

• Select from eight personal ringing tones.

IP Options:

• View the IP Addresses data

• View the QoS data

• View the interface data

• View miscellaneous data on the 5620 telephone.

Contrast Control

• Allows you to change the contrast of your 5620 telephone’ display.

Log Off

• Allows you to log your telephone off to prevent unauthorized use during an absence,

or for privacy purposes.

Backup/Restore

• Provides protection of your personal options, preference setting, speed dial data, etc

in the case of system failure.

This option must only be used by the System Administrator.

Feature Button Labeling

• Enables you to change a feature key label, e.g. SAC to DoNotDisturb.

PC Ethernet interface

• Displays and enables the PC Ethernet setting to be changed.

This option must only be used by the System Administrator.

Select display language

• Enables you to select which of eight languages is used to on your 5620 display.

Does not effect the language selected on the IP Office.

IP Office 3.0 5620SW + EU24 User’s Guide Changing the 5620 Options - Page 21 40DHB0002USEP – Issue 1 (1st March 2005) Telephone Options Overview

Page 22 - Application Options Changing the 5620 Options

Application Options

Redial

Redial can be configured to dial the last number dialed or list the last three

numbers dialed for you to choose from. The default is the last number dialed.

To change Redial:

1. Press Redial feature button. It will toggle between Last Number and Last 3 Numbers.

2. Select (To restore the previous setting without changing it, press

After saving or canceling, the first Options main screen is displayed.

Options, Applications Options and then select the

Save.

Cancel.)

Phone Screen on Answer

This action controls the phone screen display when the phone is answered.

When the Phone Screen on Answer? option is set to Yes (the default setting), the phone screen appears in the display area when you answer a call, regardless of the screen you were working with at that time. You will lose any unsaved work in progress on that screen (for example, labeling a Speed Dial button).

When the Phone Screen on Answer? option is set to No answering an incoming call has no impact on the application screen displayed, although the top display line will provide an appropriate message.

To change Phone Screen on Answer:

1. Press Screen on Answer feature button. It will toggle between Yes and No.

2. Select (To restore the previous setting without changing it, press

Options, Applications Options and then select the Phone

Save.

Cancel.)

After saving or canceling, the first Options main screen is displayed.

Phone Screen on Calling

This action controls the phone screen display when you make a call.

When the Phone Screen on Calling? option is set to Yes (the default setting), the phone screen appears in the display area when you make a call, regardless of the screen you were working with at that time. You will lose any unsaved work in progress on that screen (for example, labeling a Speed Dial button).

When the Phone Screen on Calling? option is set to No answering an incoming call has no impact on the application screen displayed, although the top display line will provide an appropriate message.

To change Phone Screen on Calling:

1. Press Screen on Calling feature button. It will toggle between Yes and No.

2. Select (To restore the previous setting without changing it, press

After saving or canceling, the first Options main screen is displayed.

Options, Applications Options and then select the Phone

Save.

Cancel.)

Page 22 - Changing the 5620 Options IP Office 3.0 5620SW + EU24 User’s Guide Application Options 40DHB0002USEP – Issue 1 (1st March 2005)

Application Options Changing the 5620 Options - Page 23

Display Call Timers

This action controls whether the duration of the current call is displayed or not. If set to

Yes, the duration of the current call is displayed on the call appearance key. If set to No, the call duration will not be displayed.

To change the Display Call Timers status:

1. Press Call Timers? feature button. It will toggle between Yes and No.

2. Select (To restore the previous setting without changing it, press

After saving or canceling, the first Options main screen is displayed.

Options, Applications Options, and then select the Display

Save.

Cancel.)

Message Display Rate

When the IP Office sends messages to your phone that are longer than the display area, the first part of the message is presented for a specific time interval. The second part of the message is then displayed for a specific time interval. The Message Display Rate can be either Fast (display interval is 2 seconds) or Slow - default (display interval is 3 seconds).

To change Message Display Rate:

1. Press Display Rate feature button. This will toggle between Fast and Slow.

2. Select (To restore the previous setting without changing it, press

Options, Applications Options, and then select the Message

Save.

Cancel.)

After saving or canceling, the first Options main screen is displayed.

Visual Alerting

When this option is set to Yes (the default), your phone rings and your voice message indicator light flashes to alert you to an incoming cal. When set to No, ringing is the only notification of an incoming call.

To change Visual Alerting:

1. Press Alerting feature button. It will toggle between No and Yes.

2. Select (To restore the previous setting without changing it, press

After saving or canceling, the first Options main screen is displayed.

Options, Applications Options, and then select the Visual

Save.

Cancel.)

IP Office 3.0 5620SW + EU24 User’s Guide Changing the 5620 Options - Page 23 40DHB0002USEP – Issue 1 (1st March 2005) Application Options

Page 24 - Personal Ringing Changing the 5620 Options

Personal Ringing

You can choose from among eight different ring patterns. This alters the tone and style of ringing used by the 5620, e.g. the number of rings will still vary according to the type of call.

1. Press A menu with the current ring pattern appears.

2. To select a ringing pattern use press Pattern 1 to 8. You will hear the selected ringing pattern.

3. When you have selected a ringing pattern, press confirmation tone and be returned to the options menu.

4. If you want to return to the options menu without changing the ring pattern, press

Cancel.

Options and select Personal Ringing.

Save. You will hear a

View IP Settings

Views of telephone and system information are available from this screen. A user normally does not need to view this information, however your System Administrator may ask you to report certain values from any of the status screens in the event of problems.

The status screen data can be viewed, but cannot be changed from your 5620.

1. Press

2. There are two pages of display. Use

• IP Addresses

• Quality of Service

• Interfaces

• Miscellaneous.

3. To return to the first View IP Settings screen, press

Each option is described in the sub-sections that follow.

Options and then select View IP Settings.

and select from:

Return.

IP Address Settings

IP (Internet Protocol) address information identifies certain components and connections. The IP Address information includes the location (address) of your phone on the IP Office unit, the location and port (connection) of the IP Office itself, the call routing and mask addresses, and the identification of the File Server with which your telephone interacts. Although technical in nature, having this information available and knowing how to get to it can assist your System Administrator in tracking questions about or problems with phone functions or connections.

Quality of Service (QoS) Information

QoS refers to a number of mechanisms used to improve audio quality over the network.

Phone Interface

Your phone interfaces with several system hardware devices and software. This screen provides information about three of the main interfaces.

Miscellaneous Information

The miscellaneous status screens provide additional information about your telephone and its connections.

Page 24 - Changing the 5620 Options IP Office 3.0 5620SW + EU24 User’s Guide Personal Ringing 40DHB0002USEP – Issue 1 (1st March 2005)

Adjusting the Display Contrast Changing the 5620 Options - Page 25

Adjusting the Display Contrast

You can adjust the contrast level on the telephone display. You can choose from among fifteen levels of contrast.

1. Press

2. Use either the

3. When the contrast is set as required, either:

• Save and return to the options menu by pressing

• Press

Options and then select Contrast Control

or key to adjust the level of contrast.

Save.

Cancel to return to the options menu.

Logging off the 5620 IP Telephone

Allows you to log your telephone off to prevent unauthorized use during an absence, or for privacy purposes

CAUTION: Logging off deletes all Call Log entries and returns any options you may

have changed to their default values.

To log your phone off:

1. Press

2. Select entries and returns any options you may have configured to their default values.

3. Selecting on to the network and your Call Log and options values remain unchanged.

To log back on:

1. The display will show Ext.=xxx in the top row. Simply press # and enter your password (consult your System Administrator).

Options and Log off.

Yes to un-register your phone from the IP Office, delete all Call Log

No returns you to the main Option menu; your phone remains logged

Backup/Restore Options

The 5620 IP Telephone's backup/restore options require set up and configuration by the system administrator prior to use. These options are displayed on the telephone screen via the Options button, but will only be amendable if they have been configured by the system administrator.

The backup/restore options provide the ability to:

• Back up your options/preference settings, your Speed Dial button labels, names,

and numbers automatically whenever you save a change to any one of those settings or buttons. Automatic backup protects this data against system failure.

• Restore options settings and Speed Dial button labels, names and numbers

following a phone failure or replacement.

• Establish or modify FTP (File Transfer Protocol) settings such as the network

server address, directory path for saving backed-up data, and a User ID and Password for server access via your phone.

• Verify whether an automatic backup has occurred.

Because each telephone system has unique characteristics and settings, modifying the Backup/Restore options generally require the assistance of the System Administrator. For example, it is unlikely that a 5620 IP Telephone user would know the specific Server IP Address to enter when setting up FTP parameters. Hence:

Due to the technical nature of this feature, it is highly recommended that this feature is only used by the System Administrator.

IP Office 3.0 5620SW + EU24 User’s Guide Changing the 5620 Options - Page 25 40DHB0002USEP – Issue 1 (1st March 2005) Adjusting the Display Contrast

Page 26 - Changing Feature Key Labels Changing the 5620 Options

Changing Feature Key Labels

This action is not supported with the 5620 IP Telephone on Avaya IP Office System.

Language Selection

When the 5620 telephone is first installed, it is set to display screen text in English. You can select the language that you would prefer from the following:

English, German (Deutsch), French (Français), Spanish (Español), Italian (Italiano), Dutch (Nederlands), Portuguese (Português) or Japanes (Katakana characters).

Note: This does not alter your user language setting on the telephone system.

1. Press A menu listing the available languages appears.

2. Press the original language “Are you sure?” with the same message in the new language below.

3. Do one of the following:

• To return to the options menu without saving any changes, press

• To save the settings and return to the options menu, press

displayed in both the original and the selected language).

Options, and Language.

or key next to the language required. You are asked in the

Yes (which is

Return.

Page 26 - Changing the 5620 Options IP Office 3.0 5620SW + EU24 User’s Guide Changing Feature Key Labels 40DHB0002USEP – Issue 1 (1st March 2005)

Overview of Function Keys Function Keys - Page 27

Function Keys

Overview of Function Keys

Both the left hand and right hand Function Keys can be used to access a range of features. The display adjacent to the key shows the feature name.

Some of these features are default features supported by all 5620 telephones (e.g. the call appearance lines labeled a=, b= and c=). Others are features that can only be programmed by the System Administrator for your telephone system.

The main screen has three pages. This means that the six on the first and last page and the 12 Function keys on the second page can be used for

up to 24 features. To move between pages use the

In the following example:

• The first three keys have been set (default setting) as call appearance lines. See

Call Appearance Keys on page 8.

• Keys 4 and 5 have been set to access the Admin and Admin1 programmable

functions. See Function Key Programming on page 28.

• Key 6 has been set to monitor system park slot 1. The highlighted text indicates that

a call is currently parked in slot 1. See Park - Park (#) on page 47.

• Key 7 has been set to the SAC (Send All Calls) function. In this example all calls will

be sent to extension 104 when the function is activated. See SAC - Send All Calls on page 53.

• Key 8 has been set to VMOn, a function which toggle use of the user's voicemail

mailbox on/off. The highlighted text indicates that this function is currently on. See VMOn - Voicemail On on page 55.

• Pressing either

for this phone.

or will display the other pages of programmed functions set

and keys.

and Function Keys

Programming Your Own Functions: If the phone has been setup with either or both the Admin and Admin1 features assigned to display keys, you can select and program your own feature choices against other keys. See Function Key Programming on page 28.

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 27 40DHB0002USEP – Issue 1 (1st March 2005) Overview of Function Keys

Page 28 - Function Key Programming Function Keys

Function Key Programming

If any one of the keys on the telephone is programmed with an Admin or Admin 1 feature, it allows you to program further features against other function keys. Both Admin and Admin1 are allocated to your function keys by your System Administrator and would appear on a menu screen that is similar to the following:

The two tables below list the user programmable features available for Admin and Admin1 respectively. For full details of how each feature works see Function Key Features on page 30.

Admin: The programmable functions available via an Admin key.

Name Description Toggles Data

Acct Account Code Entry No Optional AD Abbreviated Dial No Yes Admin Self-Administer No No AutCB Automatic Callback Yes No CFrwd Call Forwarding All Yes Optional CPark Call Park Yes Optional CPkUp Call Pickup No No Dir Directory No No DPkUp Directed Call Pickup No Yes Drop Drop No No GrpPg Group Paging No Yes HdSet Headset Toggle Yes No HfAns Internal Auto-Answer Yes No HGNS+ Set Hunt Group Night Service Yes Yes Park Call Park to Other Extension No Yes Prog Abbreviate Dial Program No Yes RngOf Ringer Off Yes No SAC Send All Calls Yes No Spres AD Suppress Yes No Timer Timer Yes No TmDay Time of Day Yes No

In addition to the above, there is a key labeled Exlp? This key enables you to change the display from the shorthand version displayed at default to a longhand version of you own. See Shorthand Programming Mode on page 30 and Longhand Programming on page 30 respectively.

Admin1: The programmable functions available via an Admin 1 key.

Name Description Toggles Data

Park Park No Yes <User> User No Yes <Group> Group No Yes <Number> Dial No Yes Flash Hook Flash No No

Page 28 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Programming 40DHB0002USEP – Issue 1 (1st March 2005)

Function Key Programming Function Keys - Page 29

Shorthand Programming Mode

1. Press Admin or Admin 1.

See Function Key Programming on page 28.

2. The Admin or Admin1 menu appears as follows:

Admin Pages

With the exception of Expl?, the names shown are the features that you can assign to soft keys. When Admin has been selected you can display the full name of the feature by pressing Expl?. (see Longhand Programming on page 30).

Admin1 Page

Similarly, when Admin1 is pressed, you can assign any one of the functions shown to a soft key.

3. On the Admin pages, use the >>> or <<< keys to move through the feature pages.

4. When the function required is shown, press the

5. If the function requires some data to be entered, [ is shown at the top of the display.

Enter the data using the normal telephone keypad.

6. Select the display key against which to program the new function by pressing that

or key. Use the or keys to move through the pages.

CAUTION: Do not select the slot used for the Admin function. Replacing this

function will lock the phone for further programming until reset through the telephone system by your System Administrator.

7. If the display slot is not already used, the display shows BUTTON PROGRAMMED!.

• Press or

• Press Cont

8. If the display slot already has a programmed function, the display shows FEATURE ON BUTTON.

• Press Repla

The display then shows BUTTON PROGRAMMED! As in step 8 above.

• Press Keep

programmed.

• Press Delete

programmed.

EXIT to end programming

to continue programming other functions.

to replace that existing function with the one just programmed.

to keep the existing function and forget the function just

to delete the existing function and forget the function just

key adjacent to its name.

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 29 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Programming

Page 30 - Function Key Features Function Keys

Longhand Programming

1. Press Admin. See Function Key Programming on page 28.

2. Pressing Expl?

display.

3. Press

Selct. (You can also use <<< to step back through the list of Admin functions).

4. If the function requires some data to be entered, [ is shown at the top of the display. Enter the data using the normal telephone keypad.

5. Select the display key against which to program the new function by pressing that

or key. Use the or keys to move through the pages.

CAUTION: Do not select the slot used for the Admin function. Replacing this

6. If the display slot is not already used, the display shows BUTTON PROGRAMMED!

• Press

• Press Cont

7. If the display slot already has a programmed function, the display shows FEATURE ON BUTTON.

• Press Repla

The display then shows BUTTON PROGRAMMED! As in step 8 above.

• Press Keep

programmed.

8. Press Delete programmed.

Next or >>> until the required feature required is shown, then press

function will lock the phone for further programming until reset through the telephone system by your System Administrator.

. The longhand text for the function is shown at the top of the

EXIT to end programming

to continue programming other functions.

to replace that existing function with the one just programmed.

to keep the existing function and forget the function just

to delete the existing function and forget the function just

Function Key Features

This section lists the features that can be programmed against and Function Keys. Both the shorthand and longhand names are shown. The shorthand name is the name that is displayed next to the programmed key, along with any data programmed for the feature.

All of the following functions can only be programmed onto your 5620 by your System Administrator.

Were applicable the command path used by the System Administrator is shown, for example:

[User | Digital Telephony | Emulation | Directory].

Dial (#)

Automatically dials the displayed number.

This function requires entry of the number to dial when programmed. The number is then displayed next to the phone by the user using an

Pressing the Dial

[User | Digital Telephony | Dial]

key dials the associated number.

key. This function can be programmed through the

Admin 1 key.

See also:

• AD - Abbreviated Dial (!) on page 32.

• Prog - Abbreviated Dial Program (!) on page 49.

Page 30 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Features 40DHB0002USEP – Issue 1 (1st March 2005)

Function Key Features Function Keys - Page 31

Group (#)

Answer or clear calls ringing a specific group.

This function requires entry of the group number (allocated by your System Administrator). When programmed, the group name is then displayed next to the key. This function can be programmed through the phone by the user using an Admin 1 key and the group number.

appears against the group when calls to that group are ringing. Pressing displays details of one of those calls and options to drop (Drop the call (Answn

[User | Digital Telephony | Group]

) or exit the group monitor ( EXIT).

) the call, answer

User (#)

See the status of a specific user, call that user and pick-up calls to that user.

When programmed by your System Administrator (on the IP Office), the user name is entered. That name is then displayed next to the programmed through the phone by the user using an user number. Pressing the

key calls the user.

key. This function can also be

Admin 1 key and then the

The when the user is called the user name is underlined with a Press the

key next to the name. DkPickup appears against a call appearance key.

symbol beside it.

To pick up the call press this key.

If the System Administrator has setup group monitoring of the same user, pressing the

user key when the user is busy on a call displays several options. These are Drop (end the user's call), Listn (listen to the call), and Aquir (takeover the call). If the System Administrator has not setup group monitoring, then the options shown are Call, Message, Vmail and CallB.

[User | Digital Telephony | User]

Absnt - Set Absent Text

Set the users current absence message setting.

This function is currently not supported on the 5620 telephone.

Acct - Account Code Entry (!)

Make a call using an account code or enter an account code during a call.

This function can be programmed with or without data. This function can be programmed through the phone by the user using an

Admin key.

If programmed with data, the account code entered when programmed must match a valid account code set on the telephone system. The

Acct key displays that

number.

If programmed without data, ENTER ACCOUNT is displayed after Enter an account code and press Set

Acct is pressed.

If the account code entered does not match a valid account code set on the telephone system, RENTER ACCOUNT is displayed.

[User | Digital Telephony | Emulation | Account Code Entry]

Acct key can be pressed before or during a call.

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 31 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Features

Page 32 - Function Key Features Function Keys

AD - Abbreviated Dial (!)

Dial the displayed number.

This function requires entry of a number to dial when programmed. The

AD key

displays that number. This function can be programmed through the phone by the user.

The number does not have to be a complete number, the user can dial additional digits after pressing AD. * and # can be entered in the number to match IP Office shortcodes.

[User | Digital Telephony | Emulation | Abbreviated Dial]

See also:

• Dial (#) on page 30.

• Prog - Abbreviated Dial Program (!) on page 49.

Admin - Self-Administer (!)

Access menus for programming functions against display keys.

This function can be programmed with or without data. If programmed with a setting of 1, the key accesses a different set of functions. See Function Key Programming on page 28. This function can be programmed through the phone by the user using an existing

The and

[User | Digital Telephony | Emulation | Self-Administer]

Admin key.

Admin key gives access to the menus for programming functions against

keys.

Apear - Appearance

Add a display line for call appearances with symbols being displayed for Incoming Calls, Connected and On Hold. See Error! Reference source not found. on page Error! Bookmark not defined..

This function does not require any data entered when programmed. However it is normal to enter some text such as a=, b= and so on for each call appearance key.

This function cannot be programmed through the phone by the user.

[User | Digital Telephony | Emulation | Appearance]

AutCB - Automatic Callback (!)

Sets a callback when free on busy extensions and callback when next used on unanswered extensions.

This function does not require any data entered when programmed. This function can be programmed through the phone by the user using an

When the called target extension does not answer or is busy, pressing a callback on that extension. Whilst the callback is set, AutCB is shown with a symbol. Pressing

AutCB again cancels the callback.

Hence, when the callback target extension becomes free or is next used, pressing

starts a call to that extension.

[User | Digital Telephony | Emulation | Automatic Callback]

Admin key.

AutCB sets

See also:

• RBak - Cancel Ringback When Free on page 50.

• RBak+ - Ringback When Free on page 50.

Page 32 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Features 40DHB0002USEP – Issue 1 (1st March 2005)

Function Key Features Function Keys - Page 33

Busy - Busy

Sets the extension as being busy. This feature is not applicable when working with multiple Call Appearance lines as all the call appearance lines must be in use before this function becomes active.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

The

Busy key sets the extension as busy to callers. If a forward on busy number is set, it is followed (see FwBNo - Forward On Busy Number on page 39). Otherwise calls go to voicemail if on or receive busy tone if internal and ringing if external.

To return the extension from busy, press

[User | Digital Telephony | Advanced | Busy | Busy]

Busy and then Speaker.

BusyH - Busy On Held

Switch the users busy on held status on/off.

This function requires data entered when programmed. Enter 0 for off or 1 for on.

This function cannot be programmed through the phone by the user.

Pressing

BusyH switches the user's 'busy on held' state to either on or off as indicated by the data value. When on, if the user has a call on hold, new callers receive busy tone (ringing if analogue) or are diverted to voicemail (if enabled), rather than ringing the user. This function also overrides call waiting indication when the user has a call on hold.

[User | Digital Telephony | Advanced | Busy | Busy On Held]

CFrwd - Call Forwarding All (!)

Switch call forwarding on/off and set the forwarding number.

This function can be programmed with or without a target forwarding number. This function can be programmed through the phone by the user using an

Admin key.

If programmed with a forwarding number, that number is shown next to CFrwd. Pressing CFrwd switches on forwarding to that number.

If programmed without a forwarding number, when

CFrwd is pressed, the user's current forwarding number setting is shown. Change the number using the telephone keypad and <<<

When call forwarding is on, CFrwd is shown with a at the top of the display. To switch call forwarding off, press

[User | Digital Telephony | Emulation | Call Forwarding All]

to backspace. When the number set as required press Done .

symbol and D (Diverted) is shown

CFrwd again.

See also:

• FwNOn - Forward On No Answer On on page 41

• FwUOn - Forward Unconditional On on page 41.

• FwdNo - Forward Number on page 40.

• FwdH+ - Forward Hunt Group Calls On on page 40

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 33 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Features

Page 34 - Function Key Features Function Keys

ClrCW - Clear CW

Clears the current connected call and connects any waiting call. This feature is not applicable when working with multiple Call Appearance lines.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

ClrCW disconnects the extension's current call and connects any waiting

call.

[User | Digital Telephony | Advanced | Call | Clear CW]

CnfRV - Conference Meet Me

Allows the extension to join a specified conference.

This function requires the conference number to be entered when programmed. That number is then shown next to CnfRV. This function cannot be programmed through the phone by the user.

Pressing

CnfRV places the extension into the specified conference. Note that the number of conference parties allowed at any time is determined by the telephone system.

[User | Digital Telephony | Advanced | Call | Conference Meet Me]

Conf+ - Conference Add

Places all calls held by the extension into a conference.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

Pressing conference. This function will not work if the extension has a current call.

[User | Digital Telephony | Advanced | Call | Conference Add]

Conf+ places the extension and any calls it has put on hold into a

CPark - Call Park (!)

Park the current call.

This function can be programmed with or without data. This function can be programmed through the phone by the user using an

If programmed with data, the number entered is shown next to the is the number assigned to the parked call.

If programmed without data, the key displays just CPark. Calls parked using this key are is assigned a number based on the parking extensions number. For example, extension 290's first parked call is numbered 2900, its next 2901 if 2900 is still parked and so on. If calls are parked using this key, CPark is shown with a the key again displays the user's parked calls and allow them to be retrieved. Parked calls are retrieved with the Ride function (see page 52).

If not retrieved elsewhere, a parked call will recall to the parking extension after a set time.

[User | Digital Telephony | Emulation | Call Park]

See also:

• Park - Park (#) on page 47.

• Park - Call Park to Other Extension (!) on page 48.

• Ride - Ride Call on page 52.

Admin key.

CPark key and

symbol. Pressing

Page 34 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Features 40DHB0002USEP – Issue 1 (1st March 2005)

Function Key Features Function Keys - Page 35

CPkUp - Call Pickup (!)

Answer a call ringing elsewhere on the telephone system.

This function does not require any data entered when programmed. This function can be programmed through the phone by the user using an

Admin key.

The

CPkUp call answers (pickup) any call currently ringing on the telephone

system.

Note: We recommend that this function is only used on systems with a small number

of users all in one area. Use of this function on larger system may lead to confusion.

[User | Digital Telephony | Emulation | Call Pickup]

See also:

• PickA - Call Pickup Any on page 49.

• PickG - Call Pickup Group on page 49.

• PickM - Call Pickup Members on page 49.

CWOff - Call Waiting Off

Switches call waiting for the extension off.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

The

[User | Digital Telephony | Advanced | Call | Call Waiting Off]

CWOff key switches call waiting for the extension off.

CWOn - Call Waiting On

Switches call waiting for the extension on/off.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

The with a

CWOn key toggles call waiting on/off. When call waiting is on, CWOn is shown

symbol. When call waiting is on and the extension is on a call, any additional

call receives ringing rather than busy tone.

[User | Digital Telephony | Advanced | Call | Call Waiting On]

CWSus - Call Waiting Suspend

Suspend the current call at the exchange and answer the waiting call. This function is not supported in the USA.

If no slot number is specified when the function is programmed, exchange slot 0 is used. This function cannot be programmed through the phone by the user.

Pressing facility.

[User | Digital Telephony | Advanced | Call | Call Waiting Suspend]

See also:

• Resum - Resume Call on page 52.

CWSus is only supported if the exchange provides a Q.931 suspend call

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 35 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Features

Page 36 - Function Key Features Function Keys

DCW - Dial CW

Allows the user to force another extension to have call waiting mode on for the duration of a call attempt. This function is not supported in the USA.

This function requires the target extension number to be entered when programmed. That number is then shown next to DCW. This function cannot be programmed through the phone by the user.

Normally, if the target extension is on a call and doesn't have call waiting on, any new call will receive busy tone or be diverted to voicemail. Pressing

DCW will cause the target extension to receive call waiting indication and allow the caller to hear ringing until answered.

[User | Digital Telephony | Advanced | Dial | Dial CW]

See also:

• Queue - Call Queue on page 50.

Dir - Directory (!)

Accesses the telephone system directory.

This function does not require any data entered when programmed. This function can be programmed through the phone by the user using an

Admin key.

Pressing

• INDeX

• Group

• Extrn

Dir displays a number of options.

- Search for a matching extension user name on the telephone system.

- Search for a matching group name on the telephone system.

- Search for a name match in the telephone systems directory of

external numbers.

[User | Digital Telephony | Emulation | Directory]

Dirct - Dial Direct

Connects a call to the target extension without any ringing.

This function requires the target extension number to be entered when programmed. That number is then shown next to Dirct. The target extension must be capable of auto-answering. This function cannot be programmed through the phone by the user.

[User | Digital Telephony | Advanced | Dial | Dial Direct]

DNDOn - Do Not Disturb On

Puts the extension into 'do not disturb' (no calls) mode.

This function does not required any data to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing shown with a

[User | Digital Telephony | Advanced | Do Not Disturb | Do Not Disturb On]

DNDOn toggles the extension's do not disturb state. When on, DNDOn is

symbol and the display includes an N (No calls).

See also:

• SAC - Send All Calls (!)on page 53.

Page 36 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Features 40DHB0002USEP – Issue 1 (1st March 2005)

Function Key Features Function Keys - Page 37

DNDOf - Do Not Disturb Off

Takes the extension out of 'do not disturb' (no calls) mode.

This function does not required any data to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

DNDOf switches the extension's do not disturb state off.

[User | Digital Telephony | Advanced | Do Not Disturb | Do Not Disturb Off]

DNDX+ - Do Not Disturb Exception Add

Adds the specified number to the extension's do not disturb exception list.

This function requires entry of the calling number when programmed. That number is then shown next to DNDX+. This function cannot be programmed through the phone by the user.

Pressing

DNDX+ adds the set number to the extension's do not disturb exception list. That number can then call the extension and transfer calls to the extension even when the extension is in do not disturb mode.

[User | Digital Telephony | Advanced | Do Not Disturb | Do Not Disturb Exception Add]

DNDX- - Do Not Disturb Exception Delete

Removes the specified number from the extension's do not disturb exception list.

This function requires entry of the calling number when programmed. That number is then shown next to DNDX-. This function cannot be programmed through the phone by the user.

Pressing

DNDX- removes the set number from the extension's do not disturb exception list. That number can then call the extension and transfer calls to the extension even when the extension is in do not disturb mode.

[User | Digital Telephony | Advanced | Do Not Disturb | Do Not Disturb Exception Del]

DPkUp - Directed Call Pickup (!)

Answer a call currently ringing at a specified user or group.

This function can be programmed with or without a a the target extension or group number. This function can be programmed through the phone by the user using an Admin key.

If programmed with a target number, the call is ringing at that extension or group, press

If programmed without a target number, pressing the target number for that pickup attempt.

[User | Digital Telephony | Emulation | Directed Call Pickup]

DPkUp key displays that number. When a

DPkUp to answer (pick up) that call.

DPkUp allows the user to enter

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 37 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Features

Page 38 - Function Key Features Function Keys

Drop - Drop (!)

Clears a current calls.

This function does not require any data entered when programmed. This function can be programmed through the phone by the user using an Admin key.

For a call in progress, pressing Drop disconnects the caller.

When drop is used, silence is returned to the user rather than dial tone. This is intended operation, reflecting that Drop is mainly used by call center headset users.

[User | Digital Telephony | Emulation | Drop]

DTone - Secondary Dial Tone

Return secondary dial tone to the user.

This function is currently not supported on the 5620 telephone.

Emrgy - Dial Emergency

Dials a specified number regardless of any call barring applied to the user.

This function requires entry of a number to dial when programmed. That number is then shown next to Emrgy. This function cannot be programmed through the phone by the user.

[User | Digital Telephony | Advanced | Dial | Dial Emergency]

Flash - Flash Hook (#)

Send a hook flash signal to the currently connected line.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user. This function can be programmed through the phone by the user using an Admin 1 key.

[User | Digital Telephony | Advanced | Miscellaneous | Flash Hook]

FolTo - Follow Me To

Forwards calls from this extension to the specified target.

This function requires the target extension to be entered when programmed. The extension number is then shown next to FolTo. This function cannot be programmed through the phone by the user.

Pressing extension and switches follow me use on. Whilst on, FolTo is shown with a Press

[User | Digital Telephony | Advanced | Follow Me | Follow Me To]

FolTo sets the extension's Follow Me To number to the specified

symbol.

FolTo again to switch off.

Page 38 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Features 40DHB0002USEP – Issue 1 (1st March 2005)

Function Key Features Function Keys - Page 39

FwBNo - Forward On Busy Number

Sets the extensions forwarding number for use with forward on busy and forward on no answer.

This feature requires the target number to be entered when programmed. The number set is shown next to FwBNo. This function cannot be programmed through the phone by the user.

Pressing

FwBNo set the extension's forwarding number to that specified by the key pressed.

[User | Digital Telephony | Advanced | Forward | Forward On Busy Number]

See also:

• FwBOn - Forward On Busy On on page 39

• FwNOn - Forward On No Answer On on page 41.

FwBOn - Forward On Busy On

Switches the extension to forward on busy on.

Note: When Call Appearance keys have been allocated, all the call appearance lines

must be in use before this function becomes active.

This function does not required any data to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

FwBOn toggles the extension's forward on busy state and can also be used in conjunction with FwBOf - Forward On Busy Off on page 39. When on, FwBOn is shown with a

symbol. When on, calls are forwarded to the extension's forward on

busy number.

[User | Digital Telephony | Advanced | Forward | Forward On Busy On]

See also:

• FwBNo - Forward On Busy Number on page 39.

FwBOf - Forward On Busy Off

Switches the extension to forward on busy off. Used in conjunction with FwBOn Forward On Busy On on page 39

This function does not required any data to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

[User | Digital Telephony | Advanced | Forward | Forward On Busy Off]

FwBOf switches the extension's use of forward on busy off.

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 39 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Features

Page 40 - Function Key Features Function Keys

FwdH+ - Forward Hunt Group Calls On

Switches the extension to forward hunt group calls it receives.

Note: Calls are only forwarded when forward unconditional (see CFrwd - Call

Forwarding All (!) on page 33) or FwUOn - Forward Unconditional On on page 41 is also on.

This function does not required any data to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

FwdH+ toggles the feature on/off. When on, FwdH+ is shown with a symbol. Can also be used in conjunction with FwdH- - Forward Hunt Group Calls Off on page 40.

[User | Digital Telephony | Advanced | Forward | Forward Hunt Group Calls On]

FwdH- - Forward Hunt Group Calls Off

Switches the extension to forward unconditional off.

This function does not required any data to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

FwdH- switches the extension's use of forward hunt group calls off. Can also be used in conjunction with FwdH+ - Forward Hunt Group Calls On on page 40

[User | Digital Telephony | Advanced | Forward | Forward Hunt Group Calls Off]

FwdNo - Forward Number

Sets the extension's forwarding number for use when forwarding all calls.

This feature requires the target number to be entered when programmed. The number set is shown next to FwdNo. This function cannot be programmed through the phone by the user.

Pressing

FwdNo set the extension's forwarding number to that specified by the key pressed.

Also See:

• FwBOn - Forward On Busy On on page 39

• FwUOn - Forward Unconditional On on page 41

[User | Digital Telephony | Advanced | Forward | Forward Number]

FwdOf - Cancel All Forwarding

Switch off all call forwarding.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

Pressing delete the forwarding number settings.

[User | Digital Telephony | Advanced | Call | Cancel All Forwarding]

FwdOf switches off all the extensions call forwarding options. It does not

Page 40 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Features 40DHB0002USEP – Issue 1 (1st March 2005)

Function Key Features Function Keys - Page 41

FwNOn - Forward On No Answer On

Switches the extension to forward on no answer on.

This function does not required any data to be entered when programmed and cannot be programmed through the phone by the user.

Pressing FwNOn is shown with a

FwNOn toggles the extension's forward on no answer state. When on,

symbol. When on, calls are forwarded to the extension's

forward on busy number (see FwBNo - Forward On Busy Number on page 39).

[User | Digital Telephony | Advanced | Forward | Forward On No Answer On]

FwNOf - Forward On No Answer Off

Switches the extension to forward on no answer off.

This function does not required any data to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

FwNOf switches the extension's use of forward on no answer off. Can also be used in conjunction with FwNOn - Forward On No Answer On on page 41.

[User | Digital Telephony | Advanced | Forward | Forward On No Answer Off]

FwUOn - Forward Unconditional On

Switches the extension to forward all its calls except hunt group calls.

Note: When Call Appearance keys have been allocated, all the call appearance lines

must be in use before this function becomes active.

This function does not required any data to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing is shown with a

FwUOn toggles the extension's forward on busy state. When on, FwUOn

symbol and the display includes a D. When on, calls are forwarded to

the extension's forward number (see FwBNo - Forward On Busy Number on page 39).

[User | Digital Telephony | Advanced | Forward | Forward Unconditional On]

FwUOf - Forward Unconditional Off

Switches the extension’s forward unconditional off.

This function does not required any data to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

FwUOf switches the extension's use of forward unconditional off. Can also be used in conjunction with FwUOn - Forward Unconditional On on page 41.

[User | Digital Telephony | Advanced | Forward | Forward Unconditional Off]

GrpPg - Group Paging (!)

This function can be programmed with or without a target extension or group number. This function can be programmed through the phone by the user using an key.

If programmed with a target number, the

GrpPg key displays that number. When

GrpPg is pressed, it will make a paging call to that number.

If programmed without a target number, the number must be dialed after the user presses

GrpPg.

[User | Digital Telephony | Emulation | Group Paging]

Admin

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 41 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Features

Page 42 - Function Key Features Function Keys

HdSet - Headset Toggle (!)

This function does not require any data entered when programmed. This function can be programmed through the phone by the user using an

The programmed key will then switch the phone between handset and headset operation. When on, HdSet is shown on a dark background.

Admin key.

There is no linkage between a programmed HdSet key and the phone's HEADSET key.

[User | Digital Telephony | Advanced | Miscellaneous | Headset Toggle]

Here- - Follow Me Here Cancel

If another extension has follow me set to this extension, switches off the follow me action.

This function requires the original target extension to be entered when programmed. The extension number is then shown next to Here-. This function cannot be programmed through the phone by the user.

Pressing

Here- cancels the use of follow me at the target extension.

[User | Digital Telephony | Advanced | Follow Me | Follow Me Here Cancel]

Here+ - Follow Me Here

Forwards calls to the target extension to this extension.

This function requires the original target extension to be entered when programmed. The extension number is then shown next to Here+. This function cannot be programmed through the phone by the user.

Pressing extension. Calls to the target extension are then forwarded to this extension.

[User | Digital Telephony | Advanced | Follow Me | Follow Me Here]

Here+ sets the target extension's Follow Me To number to that this

HfAns - Internal Auto-Answer (!)

Answers internal calls after a single ring.

This function does not require any data entered when programmed. This function can be programmed through the phone by the user using an

The a

HfAns key toggles internal auto-answer on/off. When on, HfAns is shown with

symbol.

[User | Digital Telephony | Emulation | Internal Auto Answer]

See also:

• RngOf - Ringer Off (!) on page 52.

• CWOn - Call Waiting On on page 35.

Admin key.

Page 42 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Features 40DHB0002USEP – Issue 1 (1st March 2005)

Function Key Features Function Keys - Page 43

HGEna - Hunt Group Enable

Sets the extension's membership of a group or groups as enabled. This function does not take the Hunt Group In/Out of Service.

This function can be programmed with or without a target group number. This function cannot be programmed through the phone by the user.

If programmed without a group number, pressing group memberships to either enabled or disabled. A

HGEna toggles all the extension's

is shown next to HGEna

when the group memberships are enabled.

If programmed with a group number, that number is shown next to Pressing

HGEna will enable the extension's membership of that group. In this

HGEna.

mode the key does not toggle.

When enabled, G is shown on the display and the extension will receive group calls.

[User | Digital Telephony | Advanced | Hunt Group | Hunt Group Enable]

See also:

• HGNS+ - Set Hunt Group Night Service (!) on page 43.

•

HGOS+ - Set Hunt Group Out of Service44 on page.

• HGDis - Hunt Group Disable on page 43.

HGDis - Hunt Group Disable

Sets the extension's group membership as disabled. This function does not take the Hunt Group Out of Service.

This function can be programmed with or without a target group number. This function cannot be programmed through the phone by the user.

If programmed without a group number, pressing extension's group memberships.

If programmed with a group number, pressing membership of that group.

[User | Digital Telephony | Advanced | Hunt Group | Hunt Group Disable]

HGDis disables all the

HGDis disables just the extension's

HGNS+ - Set Hunt Group Night Service (!)

Put a specific hunt group into night service mode.

This function requires the hunt group number to be entered when programmed. The hunt group number is then shown next to HGNS+. This function can be programmed through the phone by the user using an

Pressing

HGNS+ puts the hunt group into night service. Group calls then go to its

Admin key.

night service fallback group if set or, if not answered, to voicemail.

[User | Digital Telephony | Advanced | Set | Set Hunt Group In Service]

HGNS- - Clear Hunt Group Night Service

Returns a hunt group that has been manually put into night service back to normal service. Used with HGNS+ - Set Hunt Group Night Service (!) on page 43.

This function requires that the hunt group number is entered when programmed. This function cannot be programmed through the phone by the user.

The hunt group number is shown next HGNS-. Pressing back into normal service if in night service.

[User | Digital Telephony | Advanced | Call | Clear Hunt Group Night Service]

HGNS- puts the group

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 43 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Features

Page 44 - Function Key Features Function Keys

HGOS+ - Set Hunt Group Out of Service

Put a specific hunt group out of service mode.

This function requires the hunt group number to be entered when programmed. The hunt group number is then shown next to HGOS+. This function cannot be programmed through the phone by the user.

Pressing

HGOS+ puts the hunt group out of service. Group calls then go to its out of service fallback group if set or, if not answered, to voicemail.

[User | Digital Telephony | Advanced | Set | Set Hunt Group Out Service]

HGOS- - Clear Hunt Group Out of Service

Returns a hunt group that has been manually put into out of service back to normal service. Used with HGNS+ - Set Hunt Group Night Service (!) on page 43.

This function requires that the hunt group number is entered when programmed. This function cannot be programmed through the phone by the user.

The hunt group number is shown next HGOS-. Pressing

HGOS- puts the group

back into normal service if in night service.

[User | Digital Telephony | Advanced | Call | Clear Hunt Group Out Of Service]

Hold - Hold Call

Place the current call on hold at the central office. This function is not supported in the USA.

If no exchange slot number is specified when the function is programmed, central office slot 0 is used.

Pressing

Hold is only supported if the central office provides a Q.931 hold facility. It is not the same as local hold provided by the IP Office.

[User | Digital Telephony | Advanced | Hold | Hold Call]

See also:

• Rtriv - Retrieve Call on page 52.

HoldCW - Hold Call Waiting

Place the current call on hold and connects any call waiting. This function is not supported in the USA.

This function does not required any data to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing without any ringing.

[User | Digital Telephony | Advanced | Hold | Hold CW]

HoldCW places the current call on hold and connects any call waiting

Page 44 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Features 40DHB0002USEP – Issue 1 (1st March 2005)

Function Key Features Function Keys - Page 45

IAuto - Automatic Intercom

Connects call to the extension without ringing.

This function requires entry of an extension number when programmed. The target extension must be support handsfree operation. This function cannot be programmed through the phone by the user.

Press

IAuto connects the call without any ringing at the remote extension. If the target extension is busy or not available, the call will follow any forwarding or diversion to voicemail set.

[User | Digital Telephony | Emulation | Automatic Intercom]

ICSeq - Set Inside Call Sequence

Sets the ringing pattern (sequence) used for internal calls.

This function is currently not supported on the 5620 telephone.

IDial - Dial Intercom

The same as IAuto - Automatic Intercom on page 45. This function cannot be programmed through the phone by the user.

[User | Digital Telephony | Emulation | Dial Intercom]

Inclu - Dial Inclusion

Intrudes on a call in progress at the target extension.

This function is currently not supported on the 5620 telephone.

Intru - Call Intrude

Intrudes on a call in progress at the target extension, creating a conference between the callers and the intruding extension.

This function requires entry of the target extension number when programmed. The Intru key shows the target extension number. This function cannot be programmed through the phone by the user.

Pressing

Note: That the System Administrator must configure the intruding extension as being

[User | Digital Telephony | Advanced | Call | Call Intrude]

Intru intrudes on the call in progress.

able to intrude. Additionally none of the other extensions involved in the call can have "Cannot be intruded on" status.

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 45 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Features

Page 46 - Function Key Features Function Keys

Listn - Call Listen

Allow the extension to listen to groups calls to the target extension. The call parties cannot hear the listening extension.

This function requires entry of the target extension number when programmed. This function cannot be programmed through the phone by the user.

The

Listn key shows the target extension number.

Use of this function requires setup of the extension's monitor group by the System Administrator. This function requires the telephone system to have some free conference capacity when invoked.

[User | Digital Telephony | Advanced | Call | Call Listen]

See also:

• Intru - Call Intrude on page 45.

• Recor - Call Record on page 53.

• Steal - Call Steal on page 53.

Login - Extn Login

Logs the current user onto the extension.

This function does not require any data to be entered when programmed. The user cannot program this function through the phone. Pressing the soft key login prompts the user Enter Extn:. The user enters the desired extension and presses the soft function key Next. The user is prompted for the password. The user enters the password and presses the soft function key “Done.”

[User | Digital Telephony | Advanced | Extn | Extn Login]

Logof - Extn Logout

Logs the current user off the extension.

This function does not required any data to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

Logof logs the current user off the extension. A new user must then log

on to use the extension or dial *36 to re-associate the extension with its default user.

[User | Digital Telephony | Advanced | Extn | Extn Logout]

Music - Hold Music

Plays the telephone system's music on hold.

This function does not required any data to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

[User | Digital Telephony | Advanced | Hold | Hold Music]

Music plays the telephone system's music on hold through the extension.

Page 46 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Features 40DHB0002USEP – Issue 1 (1st March 2005)

Function Key Features Function Keys - Page 47

NATim - Set No Answer Time

Sets the extension's no answer time after which ringing calls are forwarded or go to voicemail.

This function requires the time in seconds to be entered when programmed. The value is shown next to NATim. This function cannot be programmed through the phone by the user.

Pressing

NATim sets the extension's no answer time to the indicated number of seconds. This time is used to set a delay between ending one call and the next call ringing the extension (the waiting call may be indicated on the display however).

[User | Digital Telephony | Advanced | Set | Set No Answer Time]

See also:

• VMOff - Voicemail Offon page 55.

OCSeq - Set Outside Call Sequence

Sets the ringing pattern (sequence) used for internal calls. This function is currently not supported on the 5620 telephone.

Page - Page

Page the specified target extension or group. The target must be capable of hands-free speech.

This function requires the target extension or group number to be specified when programmed. The target is then shown next to programmed through the phone by the user.

[User | Digital Telephony | Advanced | Dial | Dial Paging]

See also:

• GrpPg - Group Paging (!)on page 41.

Page. This function cannot be

Park - Park (#)

Park calls to and retrieve calls from a specific park slot. This function requires entry of a park slot number when programmed. That number and

Park then appears next to the phone by the user using an

The user can use the

key to park calls into that park slot and unpark calls from that

slot. Parked calls can also be retrieved with the Ride function (see page 52). When a call is parked in that park slot by the user, a

key and parked by another user, then Park is underlined.

[User | Digital Telephony | Park]

See also:

• CPark - Call Park (!) on page 34.

• Park - Call Park to Other Extension (!) on page 48.

• Ride - Ride Call on page 52.

key. This function can be programmed through the

Admin 1 key.

symbol appears next to the

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 47 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Features

Page 48 - Function Key Features Function Keys

Park - Call Park to Other Extension (!)

Allows a call to be parked against another extension. Depending on the other extension's type, its parked call indication is triggered. Parked calls are retrieved with the Ride function (see page 52).

This function can be programmed with or without a target extension number. This function can be programmed through the phone by the user using an

If programmed with a number, the a call, pressing

Park parks the call against that extension.

If programmed without a number, after pressing

Park key displays that number. After answering

Park the target for the parked call

must be entered. The parked call is assigned a number based on the parking extensions number. For

example, extension 290's first parked call is numbered 2900, it’s next 2901 if 2900 is still parked and so on. If not retrieved elsewhere, a parked call will recall to the parking extension after a set time.

[User | Digital Telephony | Emulation | Call Park to Other Extension]

See also:

• CPark - Call Park (!) on page 34.

• Park - Call Park to Other Extension (!) on page 48.

• Ride - Ride Call on page 52.

Admin key.

PCall - Priority Call

Call a specified target extension even if that extension is set to 'Do not Disturb'.

This function can be programmed with or without an extension number being specified. If programmed with an extension number then the target extension is shown next to PCall. If programmed without an extension number then the user has to enter the extension number when

PCall is pressed

This function cannot be programmed through the phone by the user.

[User | Digital Telephony | Advanced | Call | Priority Call]

PhyEx - Dial Physical Extension by Number

Dial a specified extension regardless of the current logged on user at that extension and any forwarding, follow me and do not disturb settings applied by the extension user.

This function requires the target extension number to be specified when programmed. The target extension is then shown next to programmed through the phone by the user.

This function is currently only available on US based systems.

[User | Digital Telephony | Dial | Dial Physical Extension by Number]

PhyEx. This function cannot be

Page 48 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Features 40DHB0002USEP – Issue 1 (1st March 2005)

Function Key Features Function Keys - Page 49

PickA - Call Pickup Any

Pickup any ringing call.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

PickA answers any call currently ringing on the telephone system.

Note: We recommend that this function is only used on systems with a small number of users all in one area. Use of this function on larger system may lead to confusion.

[User | Digital Telephony | Advanced | Call | Call Pick Up Any]

See also:

• CPkUp - Call Pickup (!) on page 35.

• DPkUp - Directed Call Pickup (!) on page 37.

PickG - Call Pickup Group

Pickup any ringing call to a group of which the extension is a member.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

Pressing a member.

[User | Digital Telephony | Advanced | Call | Call Pick Up Group]

See also:

• CPkUp - Call Pickup (!) on page 35.

• DPkUp - Directed Call Pickup (!) on page 37.

PickG answers any call currently ringing a group of which the extension is

PickM - Call Pickup Members

Pickup any call ringing an extension that is a member of the specified group.

This function requires entry of the target group number when programmed or the group name in quotation marks. This function cannot be programmed through the phone by the user.

Pressing

PickM answers any call currently ringing a member of the specified group. The call does not have to be a call to the group number.

[User | Digital Telephony | Advanced | Call | Call Pickup Members]

See also:

• CPkUp - Call Pickup (!) on page 35.

• DPkUp - Directed Call Pickup (!) on page 37.

Prog - Abbreviated Dial Program (!)

Select and program numbers against display keys.

This function can be programmed through the phone by the user using an key.

[User | Digital Telephony | Emulation | Abbreviated Dial Program]

Admin

See also:

• Dial (#)on page 30.

• AD - Abbreviated Dial (!) on page 32.

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 49 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Features

Page 50 - Function Key Features Function Keys

Quota - Clear Quota

Clears (resets) the time quota for connections to a specified external data service (eg. the internet).

This function requires entry of the service name when programmed. If left blank then the quotas for all services are cleared (reset). This function cannot be programmed through the phone by the user.

[User | Digital Telephony | Advanced | Call | Clear Quota]

Queue - Call Queue

Places a current call into the call queue of a specified extension. Allows calls to be transferred to extensions that return busy tone. This feature is not applicable when working with multiple Call Appearance lines.

This function requires entry of a target extension number when programmed. This function cannot be programmed through the phone by the user.

During a call, pressing

Queue places that call in the target extensions call queue. If the target extension is free, it rings immediately. If the target extension is busy, it rings when it becomes free again.

[User | Digital Telephony | Advanced | Call | Call Queue]

See also:

• DCW - Dial CW on page 36.

RBak+ - Ringback When Free

Sets a callback when free on busy extensions and callback when next used on unanswered extensions.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

When an extension called does not answer or is busy, pressing callback on that extension. Whilst the callback is set, AutCB is shown with a Pressing

AutCB again cancels the callback.

When the extension becomes free or is next used, Ring Back to and the number appears on the phone that set the callback. Pressing

answers the ringback and

starts a call to the callback target.

[User | Digital Telephony | Advanced | Miscellaneous | Ringback When Free]

AutCB sets a

symbol.

See also:

• AutCB - Automatic Callback (!) on page 32.

RBak - Cancel Ringback When Free

Cancels any set ringback when free function.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

Pressing using a by pressing the

[User | Digital Telephony | Advanced | Miscellaneous | Cancel Ringback When Free]

Page 50 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Features 40DHB0002USEP – Issue 1 (1st March 2005)

RBak- switches off any set ring back when free. If the ringback was set

AutCB key, that key will still appear with a symbol that can be cancelled

AutCB key again.

Function Key Features Function Keys - Page 51

RBSeq - Set Ringback Sequence

Sets the ringing pattern (sequence) used for voicemail and ringback calls.

This function is currently not supported on the 5620 telephone.

Recor - Call Record

Records the current call at the specified target extension.

This function requires entry of a target extension number when programmed. This function cannot be programmed through the phone by the user.

When

Recor is pressed, the target extensions current call is recorded into their

voicemail mailbox.

Note: This function requires Voicemail Pro to be installed. If advice of call recording

is enabled, the call parties will hear a warning before the recording takes place. In some locations it may be a legal requirement to advise callers that a call is being recorded.

[User | Digital Telephony | Advanced | Call | Call Record]

See also:

• Listn - Call Listen on page 46.

• Steal - Call Steal on page 53.

Relay - Relay Pulse

Pulse the specified external output relay (1 or 2) on for 5 seconds.

This function requires the relay switch (1 or 2) on the telephone system to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

[User | Digital Telephony | Advanced | Relay | Relay Pulse]

Relay switches the specified relay on for 5 seconds and then off.

Rely+ - Relay On

Switch the specified external output relay (1 or 2) on.

This function requires the relay switch (1 or 2) on the telephone system to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

Relay switches the specified relay on.

[User | Digital Telephony | Advanced | Relay | Relay On]

Rely- - Relay Off

Switch the specified external output relay (1 or 2) off.

This function requires the relay switch (1 or 2) on the telephone system to be entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

[User | Digital Telephony | Advanced | Relay | Relay Off]

Relay switches the specified relay off.

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 51 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Features

Page 52 - Function Key Features Function Keys

Resum - Resume Call

Resume a call previously suspended into a specified ISDN exchange slot. This function is not supported in the USA.

This function requires the exchange slot number to be specified when programmed. The slot number is then shown next to

Resum. This function cannot be

programmed through the phone by the user. Pressing

Resum resumes any call previous suspended into the specified exchange

slot. Suspended calls can be resumed by any extension.

[User | Digital Telephony | Advanced | Call | Resume Call]

See also:

• SusCW - Suspend CW on page 53.

• Suspe - Suspend Call on page 54.

Rtriv - Retrieve Call

Retrieve a call previously held into a specified ISDN central office slot and is only supported if the central office provides a Q.931 hold facility. This function is not supported in the USA.

This function requires the central office slot number to be specified when programmed. The slot number is then shown next to through the phone by the user.

Pressing

Rtriv retrieves any call previous held into the specified central office slot.

Held calls can only be retrieved by the extension that put the call on central office hold.

[User | Digital Telephony | Advanced | Call | Retrieve Call]

See also:

• Hold - Hold Call on page 44.

Rtriv. This function cannot be programmed

Ride - Ride Call

Unpark a parked call from a specified system park slot.

This function requires the park slot number to be specified when programmed. The slot number is then shown next to

Ride. This function cannot be programmed through

the phone by the user.

Pressing

Ride unparks any call previously parked into the specified system park

slot by the same or another extension.

[User | Digital Telephony | Advanced | Call | Ride Call]

See also:

• CPark - Call Park (!) on page 34

• Park - Park (#) on page 47.

• Park - Call Park to Other Extension (!) on page 48.

RngOf - Ringer Off (!)

Switches the phones audible ringer on/off. This function does not require any data entered when programmed. This function can

be programmed through the phone by the user using an The programmed

RngOf is shown with a

RngOf key toggles the phones call ringer on/off. When off,

symbol.

[User | Digital Telephony | Emulation | Ringer Off]

See also:

• CWOn - Call Waiting On on page 35

• HfAns - Internal Auto-Answer (!) on page 42.

Admin key.

Page 52 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Features 40DHB0002USEP – Issue 1 (1st March 2005)

Function Key Features Function Keys - Page 53

SAC - Send All Calls (!)

Switch do not disturb on/off.

This function does not require any data entered when programmed. This function can be programmed through the phone by the user using an

Admin key.

The

SAC key switches "do not disturb" on/off. When on, SAC is shown with a

symbol and the display includes an N (No calls).

When SAC is on, callers receive busy tone or are diverted to voicemail. For each user the System Administrator can set which numbers can still call when SAC is on. If the extension user has Phone Manager, they can set those numbers themselves. With a call already connected and another call already alerting, activating SAC will not affect the already alerting call.

[User | Digital Telephony | Emulation | Send All Calls]

See also:

• DNDOn - Do Not Disturb On on page 36.

Spres - AD Suppress (!)

Replace the display of dialed digits with s characters.

This function does not require any data entered when programmed. This function can be programmed through the phone by the user using an

The programmed Spres is shown with a

Spres key toggles the display of dialed digits on/off. When on,

symbol and each dialed digit is replaced by s on the display.

[User | Digital Telephony | Emulation | AD Suppress]

Admin key.

Steal - Call Steal

Take over a call from a specified extension or retrieve a call just transferred or forwarded. This function cannot be programmed through the phone by the user.

If a target extension number is entered when this function is programmed, displays that number. Pressing

Steal when the target extension has a call will take

Steal

over the call.

If no target extension number is entered when the function is programmed,

Steal retrieves the last calls transferred from the extension. This includes calls diverted to voicemail.

Notes: 1. Target extension must not have Cannot Intrude set.

2. Extension with Steal allocated must also have Can Intrude set.

[User | Digital Telephony | Advanced | Call | Call Steal]

SusCW - Suspend CW

Suspend the current call at the exchange and answer the waiting call.

If no exchange slot number is specified when the function is programmed, exchange slot 0 is used. This function cannot be programmed through the phone by the user.

Pressing facility.

[User | Digital Telephony | Advanced | Suspend | Suspend CW]

See also:

• Resum - Resume Call on page 52.

SusCW is only supported if the exchange provides a Q.931 suspend call

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 53 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Features

Page 54 - Function Key Features Function Keys

Suspe - Suspend Call

Suspend the current call at the exchange.

If no exchange slot number is specified when the function is programmed, exchange slot 0 is used. This function cannot be programmed through the phone by the user.

Pressing

Suspe is only supported if the exchange provides a Q.931 suspend call

facility.

[User | Digital Telephony | Advanced | Suspend | Suspend Call]

See also:

• Resum - Resume Call on page 52.

Timer - Timer (!)

Starts a timer on the phone's display.

This function does not require any data entered when programmed. This function can be programmed through the phone by the user using an

Admin key.

The timer is reset for each new call made or answered. When timer mode is selected, a

is shown next to Timer.

[User | Digital Telephony | Emulation | Timer]

TmDay - Time of Day (!)

Replaces the user name and number details on the phone display with the date and time.

This function does not require any data entered when programmed. This function can be programmed through the phone by the user using an

Admin key.

When time and date mode is selected, a

is shown next to TMDay.

[User | Digital Telephony | Emulation | Time of Day]

Toggl - Toggle Calls

Cycle through each of the extension user's current held calls.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

Pressing

Toggl puts the user's current call on hold and connects a previously held

call.

[User | Digital Telephony | Advanced | Call | Toggle Calls]

VMRB- - Voicemail Ringback Off

Switches voicemail ringback for the extension off.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

The

[User | Digital Telephony | Advanced | Voicemail | Voicemail Ringback Off]

VMRB- key switches voicemail ringback for the extension off.

Page 54 - Function Keys IP Office 3.0 5620SW + EU24 User’s Guide Function Key Features 40DHB0002USEP – Issue 1 (1st March 2005)

Function Key Features Function Keys - Page 55

VMRB+ - Voicemail Ringback On

Switches voicemail ringback for the extension on/off.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

The VMRB+ is shown with a

VMRB+ key toggles voicemail ringback for the extension on/off. When on,

symbol and the extension is called when new messages are

left in its mailbox.

[User | Digital Telephony | Advanced | Voicemail | Voicemail Ringback On]

VMCol - Voicemail Collect

Accesses a specified voicemail mailbox to collect or leave messages.

This function requires entry of the target mailbox name prefixed by either ? to collect messages or # to leave a message. If just ? or # is entered then the calling extension's mailbox is assumed. This function cannot be programmed through the phone by the user.

The

VMCol key appears followed by the mailbox name.

[User | Digital Telephony | Advanced | Voicemail | Voicemail Collect]

VMOff - Voicemail Off

Disables access to the user’s voicemail box.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

The

[User | Digital Telephony | Advanced | Voicemail | Voicemail Off]

VMOff key switches voicemail operation for the extension off.

VMOn - Voicemail On

Enables/disables access to the user’s voicemail box.

This function does not require any data entered when programmed. This function cannot be programmed through the phone by the user.

The voicemail is on, VMOn is shown with a

VMOn key toggles voicemail operation for the extension on/off. When

symbol.

[User | Digital Telephony | Advanced | Voicemail | Voicemail On]

WUTim - Set Wrap Up Time

Sets the extension's busy wrap up time to be inserted between calls.

This function requires the time in seconds to be entered when programmed. The value is shown next to WUTim. This function cannot be programmed through the phone by the user.

Pressing seconds. This time is used to set a delay between ending one call and the next call ringing the extension (the waiting call may be indicated on the display however).

[User | Digital Telephony | Advanced | Set | Set Wrap Up Time]

See also:

• NATim - Set No Answer Time on page 47.

WUTim sets the extension's busy wrap up time to the indicated number of

IP Office 3.0 5620SW + EU24 User’s Guide Function Keys - Page 55 40DHB0002USEP – Issue 1 (1st March 2005) Function Key Features

Page 56 - Introduction System Features

System Features

Introduction

As well as your phones specific features, you can access a number of system features by dialing short codes.

These instructions are for the system's default configuration. They assume that you are using the default feature codes. It also assumes that you have full access to all features and the public telephone network

Making Calls

Internal Calls: To make a call to another extension, simply dial the number.

If your System Administrator has allocated you the Ring Back When Free feature (see page 50) under a dial pad digit, you can:

1. When you call an extension that does not answer or is busy, press

and then the relevant dial pad digit to set a callback on that extension.

2. When the extension you called becomes free, your phone will ring (a burst of three

rings).

3. Lift the handset and the extension is called automatically.

Feature

External calls: To make an external call, either dial the number (prefixed by the

access code if required) or use a speed dial code (contact your System Administrator for a list of your speed codes).

If you hear busy tone while dialing, then the call may be barred. Your system manager can bar certain calls, such as those to premium rate numbers and international calls

Answering Calls

Ringing at your own extension:

Simply pick up the handset. When in headset mode, press the button associated with the alerting call.

The default ringing cadences are:

• Internal calls have a single ring cadence

• External calls have a double ring cadence.

These can be changed by your System Administrator.

Ringing at another extension:

You can answer from your own phone by using Call Pick-Up; lift your handset and dial:

- *30 to answer a call ringing anywhere.

- *31 to answer a call within your group.

- *32*201# to answer the call for a particular extension, in this example 201.

Note: If your phone rings for any longer than a specified period (15 seconds in

default), any re-direction feature that you have activated, such as voicemail or call forwarding, will come into effect.

Page 56 - System Features IP Office 3.0 5620SW + EU24 User’s Guide Introduction 40DHB0002USEP – Issue 1 (1st March 2005)

Call Waiting System Features - Page 57

Call Waiting

Call Waiting tells you if another call arrives while you are already making a call by providing call waiting tone. If you hear the call waiting tone, either end your current call or put the caller on hold. The waiting call should then ring.

• To turn call waiting on use the code *15; to turn it off use *16.

Call Forwarding

Your calls can be forwarded to another extension or an external number either when you are away from your desk (on no answer), when your extension is busy, and all calls (for example when you go on holiday).

• To switch forward direct station (i.e. not Hunt Group*) calls on dial *01, to switch it

off dial *02.

• To switch forward on busy on dial *03, to switch it off dial *04.

• To switch forward on no answer on dial *05, to switch it off dial *06.

• To set the number to which your calls are forwarded dial *07*201#, forwarding to

201 in this example.

* To forward Hunt Group Calls On/Off, use *50 and *51 respectively.

Diverting Calls

You can divert your calls to another extension.

Note: If you do not answer calls at the temporary extension, they are forwarded to

your own voicemail or call forwarding number.

At another extension:

• *12*N# from the extension you are temporarily using (where N is your extension

number). Hence, calls to your extension will be diverted to the extension you are temporarily using.

• *13*N# to re-direct the calls back to your own extension, before you return to it.

At your own extension:

• *14*N# from your own extension (where N is the extension to which you want

your calls diverted).

• *14*# to cancel either feature from your own extension.

Do Not Disturb

You may choose to receive no calls at all or only those from particular callers on your exceptions list:

To switch Do Not Disturb on/off (with or without exceptions):

• Dial *08 and to switch it off dial *09.

• Dial *10*N# to add a number to the exception list.

• Dial *11*N# to delete a number from the exception list.

Note: Your callers, other than your exceptions, either hear busy tone or are re-

directed to your voicemail.

IP Office 3.0 5620SW + EU24 User’s Guide System Features - Page 57 40DHB0002USEP – Issue 1 (1st March 2005) Call Waiting

Page 58 - Voicemail

Voicemail

Where your system has voicemail support and has been installed:

• To switch voicemail on dial *18, to switch it off dial *19.

• To retrieve your voicemail, use the code *17.

Your voicemail may be set up to deliver your messages by calling you whenever you hang up: this feature is known as Voicemail Ringback.

• To turn Voicemail Ringback on dial *48; to turn it off dial *49. Dialing a number while listening to your messages invokes further facilities: Once messages have been delivered, they are held on the system for 24 hours (can be

modified by your System Administrator). You can collect your voicemail from another extension by using the PIN your System

Administrator has set up for you. You can collect your messages if you are out of the office, by either dialing from a number that has been registered for the purpose or by dialing your extension number and PIN when prompted. If validation is successful, then dial 1 to retrieve your mail.

The System Administrator also specifies the reception number, to which the call is diverted if the caller dials 0, and your email address if your voicemail and email are integrated.

Default Feature Codes

The following are the normal default feature codes available to all users. Your System Administrator may add additional codes for other features and for speed dials.

The N, where shown, should be replaced by the appropriate number. For example, with *07*N#, replace N with the extension to which you want your calls forwarded when you have forwarding switched on.

*00 Cancel All Forwarding *32*N# Call Pick Up Extension *01 Forward Unconditionally On *33*N# Call Queue *02 Forward Unconditionally Off *34 Hold Music *03 Forward on Busy On *35*N# Extn Login *04 Forward on Busy Off *36*N# Extn Logout *05 Forward on No Answer On *37*N# Park Call *06 Forward on No Answer Off *38*N# Ride Call *07*N# Forward to number *39 Relay On *08 Do Not Disturb On *40 Relay Off *09 Do Not Disturb Off *41 Relay Pulse *10*N# Do Not Disturb Exception Add *42 Relay On *11*N# Do Not Disturb Exception Delete *43 Relay Off *12*N# Follow Me Here *44 Relay Pulse *13*N# Follow Me Here Cancel *45*N# Call Steel *14*N# Follow Me To *46 Call Steel *15 Call Waiting On *47 Conference Add *16 Call Waiting Off *48 Voicemail Ringback On *17 Voicemail Collect *49 Voicemail Ringback Off *18 Voicemail On *50 Forward Hunt Group Calls On *19 Voicemail Off *51 Forward Hunt Group Calls Off *20*N# *21*N# Clear Hunt Group Night Service *53*N# Call Pickup Members *29 Toggle Calls *57*N# Forward on busy number *30 Call Pick Up Any *70*N# Dial Physical Extn by Number *31 Call Pick Up Group *71*N# Dial Physical Extn by ID

Set Hunt Group Night Service *52 Clear Call

Page 58 - IP Office 3.0 5620SW + EU24 User’s Guide Voicemail 40DHB0002USEP – Issue 1 (1st March 2005)

Overview of Web Browsing Web Browsing - Page 59

Web Browsing

Overview of Web Browsing

The 5620 can act as a web browser for WAP (Wireless Application Protocol) web sites. These web sites contain pages written in a language called WML (Wireless Markup Language). The 5620 supports WML1.2.

If your telephone system has been setup with a default WAP website, the 5620 will display links and services on this site will control the WAP website and services you can access.

Web. Pressing this key will display your systems default WAP website. The

While browsing, you can still make and receive calls. But if you have Phone Screen on Answer option set to Yes and you answer an incoming call, the default phone screen will replace the existing web page in the display area.

To enter web browsing mode

1. Press the key under Web.

To exit web browsing mode

1. Press

2. If

be displayed when

Phone Exit.

Phone Exit is pressed while browsing the web, the last web page viewed will

Web is pressed again before a system reboot.

Accessing External WAP Websites

Your default WAP web site may contain a page where you can select or enter the URL of external WAP websites. If this is the case, you should be aware that some website may contain information that the 5620 is not able to display.

If the WAP web page uses WML features that the 5620 does not support, those features will not be shown.

If the WAP web page uses features that the 5620 does not recognize as valid WML

1.2, the 5620 will display Not a valid WML page.

IP Office 3.0 5620SW + EU24 User’s Guide Web Browsing - Page 59 40DHB0002USEP – Issue 1 (1st March 2005) Overview of Web Browsing

Page 60 - Web Navigation Controls Web Browsing

Web Navigation Controls

Having pressed display Web to access your default WAP website, the 5620 display shows a number of navigation controls.

• Navigation Icon Buttons:

These appear on the right-hand side of the web display. Note that they may appear grayed out when not useable.

• Up Page:

Press the adjacent

key to move up the page by one screen (six lines).

• Up Line:

Press the adjacent

• Home:

Press the adjacent

• Refresh:

Press the adjacent

key to move up the page by one line.

key to return to the default WAP website's home page.

key to reload the current page. If you had already selected another page to load this will cancel the loading of that page and reload the current page.

• Down Line:

Press the adjacent

• Down Page:

Press the adjacent

• Link Buttons:

The

keys at the left hand edge of the screen are used to select links within the

key to move down the page by one line.

key to move down the page by one screen (six lines).

displayed web page. Links are indicated by underlined text. Only one link will appear on a line and pressing the adjacent

• Page Buttons:

The

keys across the base of the web display may be used to provide labeled

links to other pages. If there are more than 3 such links, the right-hand

key will activate that link.

key will

be labeled as More, press this key to display the additional options.

• Phone Icon:

If the telephone number. Pressing the adjacent

icon appears next to a link in the web page, it indicates that the link is a

key to select the link will dial the

number.

Page 60 - Web Browsing IP Office 3.0 5620SW + EU24 User’s Guide Web Navigation Controls 40DHB0002USEP – Issue 1 (1st March 2005)

Entering Data - Page 61

Entering Data

Some web pages may require you to enter data into a text field and then submit that data. For example, if you browse to a search engine web site like Google, you may be asked to enter a search field.

• : Option (Radio Buttons)

These allow you to select an option from a list by clicking on the adjacent left-hand

key. The selected option appears as .

• [] : Text Entry Fields

These normally appear as [Enter text here] or pre-filled with some data.

• Submit Buttons

Text entry and option key selections are not completed until submitted. Normally this will be done by a link, using a exact appearance will vary between different web pages.

or key, labeled as Submit or similar. The

To enter text into a [ ] text entry field

1. Press the left-hand

2. The four

• DONE: Press this key when your text entry is complete.

• BKSP: Press this to key delete the previous character.

• SPACE: Press this key to add a space.

• alpha: This indicates the current text entry mode (in this example lower-case

keys at the bottom of the screen change to:

letters). Press the

key adjacent to the [ ] text entry field.

key to select a different text entry mode.

3. Begin entering text using the telephone keypad. Each key is marked with the letters it provides. You may have to press the key more than once depending on the character you require.

• For example, the 2 key is also marked as A, B and C. To enter a C press the key

three times.

• If the next character you want to enter is on the same key, press 1 and then enter

the next character.

4. The right-most

key indicates the current text entry mode. To change the current mode, press the right-hand key. The available modes are shown along the bottom of the screen. They are:

• ALPHA: Enter upper-case letters using the telephone keypad.

• alpha: Enter lower-case letters using the telephone keypad.

• Num: Enter numbers using the telephone keypad.

• Symbol: Enter a symbol from the displayed menu. Possible symbols are: . , # @

* ' " ; : \ / – | $ % ! ? & + = > < ( ) ~ _ ^ [ ] { }. These are arranged in pages and you may have to press MORE press the

key next to it.

5. When you have completed your text entry, press

6. You can return to text entry by pressing the left-hand

to select the required page. To enter a symbol,

DONE .

key adjacent to the [ ] text

entry field again.

IP Office 3.0 5620SW + EU24 User’s Guide - Page 61 40DHB0002USEP – Issue 1 (1st March 2005) Entering Data

Page 62 - Overview Management and Troubleshooting

Management and Troubleshooting

Overview

The 5620 IP Telephones are relatively trouble-free. This chapter provides helpful information for:

• Testing your telephone to be sure it is operating correctly.

• Basic Troubleshooting; this chart provides the most common problems an end user

might encounter and suggested resolutions.

• Application-specific troubleshooting; this chart describes problems and solutions specific to a 5620 application (Phone, Speed Dial, Call Log, or Web Access).

• Resetting or power-cycling your phone, when Basic Troubleshooting does not resolve a problem.

Testing your phone

This test function enables you to verify that your telephone’s lights and display are operating properly.

Testing the Telephone's Lights and Display

1. With the telephone idle (on-hook), press and release the Mute button, then

press the following numbers on the dial pad: 8 3 7 8 # (which stands for TEST).

• The display should indicate the self-test has started. If the test is successful, the message “Self test Passed #=end” displays; if the test is not successful, the message “Self test Failed #=end” displays instead.

2. Press # to return to the Phone screen.

• If nothing appears on the display and the phone is receiving power, your phone may need to be replaced. Contact your System Administrator for assistance or additional troubleshooting information.

Troubleshooting Chart

Problem/Symptom Suggested Solution

Phone does not activate when connected for the first time.

Phone does not activate after a power interruption.

Display shows an error/informational message

Speakerphone does not operate. Ask your System Administrator if your

Unless your System Administrator has already initialized your telephone, you may experience a delay of several minutes before it becomes operational. Upon plug-in, your telephone immediately begins downloading its operational software, its IP address, and any special features programmed by your System Administrator from the server to which it is connected. Report any delay of more than 10 minutes to your System Administrator.

Allow a few minutes for re-initialization after unplugging, powering down the phone, server problems, or other power interruption causes.

Most messages involve server/phone interaction. If you cannot resolve the problem based on the message received, contact your System Administrator for resolution.

Speakerphone has been disabled.

Page 62 - Management and Troubleshooting IP Office 3.0 5620SW + EU24 User’s Guide Overview 40DHB0002USEP – Issue 1 (1st March 2005)

Troubleshooting Chart Management and Troubleshooting - Page 63

Problem/Symptom Suggested Solution

Characters do not appear on the display screen.

See " Phone does not activate when connected for the first time" above.

Check all lines into the phone to be sure it is properly connected.

Check the power source to be sure your telephone is receiving power.

Perform the following Test procedure: with the telephone idle (onhook), press and release the

Mute button, then press the following numbers on the dial pad: 8 3 7 8 # (which stands for TEST). The display should indicate the self-test has started, then report if the test was successful or failed. If nothing appears on the display, and the phone is receiving power, your phone may need to be replaced.

If the above suggested solutions do not resolve the problem, reset or power cycle the phone with your System Administrator’s assistance.

No dial tone. Make sure both the handset and line cords into the phone are

securely connected. Note that there may be a slight operational delay if you unplug and reconnect the phone.

Contact your System Administrator if the problem persists.

Phone does not ring

Set your ringer volume to a higher level using the

and

Up/Down Volume keys.

From another phone, place a call to your extension to test the above suggested solution.

All other IP problems Contact your System Administrator.

SPEED DIAL APPLICATION:

You cannot dial out using any Speed Dial entries.

You cannot add an entry to the Speed Dial list

Dial button. Check that all call appearances (incoming/outgoing lines) are not already in use. If all lines are in use, wait until a line is available to make your call.

You have 108 Speed Dial entries, the maximum allowed. You must delete at least one entry before adding a new entry.

CALL LOG APPLICATION:

You cannot dial out after selecting a call log entry.

You cannot add an entry to the Speed Dial list.

Dialing from this application does not go through.

Check that all call appearances incoming/outgoing lines) are not already in use. If all lines are in use, wait until a line is available to make your call.

You have 108 Speed Dial entries, the maximum allowed. You must delete at least one entry before adding a new entry.

Your administrator must administer settings for the Enhanced Dialing feature beyond the defaults.

OPTIONS:

No Options other than “View IP

Your administrator has turned off all user-settable options.

Settings” display

IP Office 3.0 5620SW + EU24 User’s Guide Management and Troubleshooting - Page 63 40DHB0002USEP – Issue 1 (1st March 2005) Troubleshooting Chart

Page 64 - Resetting the IP Telephone Management and Troubleshooting

Resetting the IP Telephone

Reset your IP Telephone when other troubleshooting suggestions do not correct the problem or after being advised to do so by your System Administrator.

Resetting Your Phone

This basic reset procedure should resolve most problems.

1. Press the Mute button.

2. Using the dial pad, press the following keys in sequence: 73738#

• The display shows the message “Reset values? * = no # = yes.”

3. Choose one of the following:

• If you want to reset the phone without resetting any assigned values, press * (asterisk).

- A confirmation tone sounds and the display prompts “Restart phone?

* = no

# = yes.”

• If you want to reset the phone and any previously assigned (programmed) values, press # (the pound key). (Use this option only if your phone has programmed, static values)

- The display shows the message “Resetting values” while your IP

Telephone resets its programmed values, such as the IP address, to its default values, and re-establishes the connection to the server. The display then prompts “Restart phone?

* = no

# = yes.”

Note: Any reset/restart of your phone may take a few minutes.

Power Cycling Your Phone

Use the power cycle with your System Administrator’s approval only if the basic or programmed reset procedure cannot be performed or does not correct the problem:

1. Unplug the phone and plug it back in.

• The phone connection is re-established.

2. If power-cycling does not correct the problem, your System Administrator can perform a more severe power cycle routine by unplugging both the phone and the Ethernet cables.

WARNING: Because the type of power cycle mentioned in Step 2 involves re-

programming certain values, it should only be performed by your System Administrator.

Page 64 - Management and Troubleshooting IP Office 3.0 5620SW + EU24 User’s Guide Resetting the IP Telephone 40DHB0002USEP – Issue 1 (1st March 2005)

EU24 Overview EU24 Expansion Module - Page 65

EU24 Expansion Module

EU24 Overview

The EU24 Expansion Module is an optional device that can be connected to your 5620 IP Telephone to extend the number of call appearance and feature buttons available on the telephone.

The expansion module has 24 buttons arranged in two columns. Depending on how they have been programmed by your System Administrator, these buttons can be used for call appearances or features. You can adjust the viewing angle of the EU24 display to match that of your 5620 telephone.

The following figure shows a top view of the EU24 (the left hand column is displayed).

Key:

1. Call Appearance/Feature Button

2. Feature Active icon for feature in right column

3. Alternate Display Button

4. Feature Active icon for feature in left column

5. Display

Connection

Before you can begin using the EU24 Expansion Module, the module must be connected to the 5620 telephone according to the instructions in the EU24 Expansion Module Installation and Safety Instructions (555-233-136).

The following diagram shows an overview of these connections.

IP Office 3.0 5620SW + EU24 User’s Guide EU24 Expansion Module - Page 65 40DHB0002USEP – Issue 1 (1st March 2005) EU24 Overview

Page 66 - Using the EU24 Expansion Module EU24 Expansion Module

Using the EU24 Expansion Module

The following sections explain how to use the features of the EU24 Expansion Module. For more information, consult your System Administrator.

Viewing the Alternate Display

Although the EU24 Expansion Module supports an additional 24 call appearance/feature buttons, it only displays the button labels and icons for one column at a time. A dotted line separates the left column from the right column.

When you are viewing the labels and icons for the left column, the icons for the right column are displayed to the right of the dotted line. To view the column not currently displayed, press the Alternate Display button.

Selecting a Call Appearance/Feature Button

To select an available call appearance or feature, press the button next to the label in the column currently displayed.

If the call appearance or feature is not currently displayed, use the Alternate Display key to access the additional 12 call appearance/feature button labels.

Understanding Call Appearance/Feature Button Status Icons

When a call arrives for a call appearance on the EU24 Expansion Module, the bell icon blinks on the corresponding call appearance. To answer the call, press the button associated with the call appearance.

The icons displayed on the call appearance allow you to determine the status (for example, on hold) of each call on the EU24 Expansion Module. Icons also indicate whether a feature has been administered for a particular button on the EU24 Expansion Module. For an explanation of these icons see Call Appearance/Function Key Icons on page 9.

Page 66 - EU24 Expansion Module IP Office 3.0 5620SW + EU24 User’s Guide Using the EU24 Expansion Module 40DHB0002USEP – Issue 1 (1st March 2005)

Index - Page 67

Index

Abbreviated Dial ............................................ 32

Program .................................................... 52

Absent Text ................................................... 32

Absnt ............................................................. 32

Account Code Entry....................................... 32

Acct................................................................ 32

AD.................................................................. 32

AD Suppress ................................................. 56

Admin ............................................................ 32

Apear ............................................................. 34

Appearance ................................................... 34

Aquir .............................................................. 31

AutCB ............................................................ 34

Auto-Answer .................................................. 45

Automatic

Callback .................................................... 34

Intercom .................................................... 47

Backup/restore

modifying................................................... 25

Backup/restore .............................................. 25

Backup/Restore Options................................ 25

Busy............................................................... 34

Forward Calls............................................ 42

On Held..................................................... 34

BusyH ............................................................ 34

Call

Appearance............................................... 34

Forwarding All ........................................... 36

Hold........................................................... 47

Intrude....................................................... 48

Listen ........................................................ 48

Park.................................................... 37 , 50

Park to Other Extension............................ 50

Pickup ....................................................... 37

Priority....................................................... 51

Queue ....................................................... 52

Record ...................................................... 53

Resume..................................................... 54

Retrieve..................................................... 55

Ride........................................................... 55

Steal.......................................................... 56

Suspend.................................................... 57

Timer......................................................... 57

Toggle ....................................................... 57

Call Pickup

Any............................................................ 51

Directed..................................................... 41

Group ........................................................ 51

Members ................................................... 52

Call Waiting

Clear ......................................................... 36

Dial............................................................ 38

Hold .......................................................... 47

Off............................................................. 37

On............................................................. 38

Suspend............................................. 38 , 56

Callback......................................................... 34

Cancel

All Forwarding........................................... 43

Ringback When Free................................ 53

Cfrwd ............................................................. 36

Characteristics............................................... 25

Clear

CW............................................................ 36

Hunt Group Night Service......................... 46

Hunt Group Out of Service ....................... 47

Clear Quota ................................................... 52

ClrCW............................................................ 36

CnfRV............................................................ 36

Conf+............................................................. 36

Conference

Add ........................................................... 36

Rendezvous.............................................. 36

CPark ............................................................ 37

CPkUp ........................................................... 37

CWOff............................................................ 37

CWOn............................................................ 38

CWSus .......................................................... 38

DCW.............................................................. 38

Dial ................................................................ 30

CW............................................................ 38

Direct ........................................................ 40

Emergency................................................ 41

Inclusion.................................................... 48

Intercom.................................................... 48

Physical Extension.................................... 51

Dial Tone ....................................................... 41

Dir 38

Dirct ............................................................... 40

Directed Call Pickup ...................................... 41

Directory ........................................................ 38

Display Key

Dial............................................................ 30

Group........................................................ 31

User .......................................................... 31

DNDOf........................................................... 40

DNDOn.......................................................... 40

DNDX- ........................................................... 40

DNDX+ .......................................................... 40

IP Office 3.0 5620SW + EU24 User’s Guide Index - Page 67 40DHB0002USEP – Issue 1 (1st March 2005)

Page 68 - Index

Index (Cont.)

Do Not Disturb

Exception Add........................................... 40

Exception Delete....................................... 40

Off ............................................................. 40

On ............................................................. 40

DpkUp............................................................ 41

Drop............................................................... 31

DTone............................................................ 41

Emergency Dial ............................................. 41

Emrgy ............................................................ 41

Extn

Logout ....................................................... 49

Flash.............................................................. 41

Follow Me

Here .......................................................... 45

Here Cancel .............................................. 45

To.............................................................. 42

To Number ................................................ 45

FolTo ............................................................. 42

Forward

All .............................................................. 36

Cancel All.................................................. 43

Forward Number ....................................... 43

Hunt Group Calls Off................................. 43

Hunt Group Calls On................................. 43

On Busy Number ...................................... 42

On Busy Off .............................................. 42

On Busy On .............................................. 42

On No Answer Off..................................... 44

On No Answer On..................................... 43

Unconditional Off ...................................... 44

Unconditional On ...................................... 44

FTP................................................................ 25

FwBNo........................................................... 42

FwBOf............................................................ 42

FwbOn ........................................................... 42

FwdH ............................................................. 43

FwdH+ ........................................................... 43

FwdOf ............................................................ 43

FwNOf ........................................................... 44

FwNOn .......................................................... 43

FwUOf ........................................................... 44

FwUOn .......................................................... 44

Group............................................................. 31

Disable ...................................................... 46

Enable....................................................... 46

Forward Calls............................................ 43

Night Service............................................. 46

Out of Service ........................................... 47

Paging....................................................... 44

Pickup ....................................................... 51

GrpPg ............................................................ 44

HdSet ............................................................ 45

Headset Toggle ............................................. 45

Here- ............................................................. 45

Here+ ............................................................ 45

HfAns............................................................. 45

HGDis............................................................ 46

HGEna........................................................... 46

HGNS-........................................................... 46

HGNS+.......................................................... 46

HGOS-........................................................... 47

HGOS+.......................................................... 47

Hold ............................................................... 47

Call Waiting............................................... 47

Hold Music..................................................... 49

HoldCW ......................................................... 47

Hook Flash .................................................... 41

Hunt Group.................................................... 31

Disable...................................................... 46

Enable....................................................... 46

Forward Calls............................................ 43

Night Service ............................................ 46

Out of Service........................................... 47

Paging....................................................... 44

Pickup....................................................... 51

IAuto .............................................................. 47

ICSeq ............................................................ 48

IDial ............................................................... 48

Inclu............................................................... 48

Inclusion ........................................................ 48

Inside Call Sequence .................................... 48

Intercom ................................................. 47 , 48

Internal Auto-Answer..................................... 45

Intru ........................................................ 31 , 48

Intrude ........................................................... 48

IP Telephone's .............................................. 25

IP Telephone's backup/restore...................... 25

Listen............................................................. 48

Listn........................................................ 31 , 48

Logof ............................................................. 49

Modifying

Backup/Restore ........................................ 25

Modifying ....................................................... 25

Music ............................................................. 49

NATime ......................................................... 49

Night Service ................................................. 46

No Answer

Forward Calls............................................ 43

Time.......................................................... 49

Number

Follow Me To ............................................ 42

Forward Number....................................... 43

Forward On Busy...................................... 42

Page 68 - Index IP Office 3.0 5620SW + EU24 User’s Guide 40DHB0002USEP – Issue 1 (1st March 2005)

Index (Cont.)

OCSeq........................................................... 49

On Busy

Forward Calls............................................ 42

On No Answer

Forward Calls............................................ 43

Option button ................................................. 25

Options/preference ........................................ 25

Out of Service................................................ 47

Outside Call Sequence.................................. 49

Paging ........................................................... 44

Park ........................................................ 37 , 50

Park to Other Extension ................................ 50

Password....................................................... 25

PCall .............................................................. 51

Phone Button, Description............................... 6

PhyEx ............................................................ 51

PickA ............................................................. 51

PickG ............................................................. 51

PickM............................................................. 52

Pickup

Any............................................................ 51

Call............................................................ 37

Directed..................................................... 41

Group ........................................................ 51

Members ................................................... 52

Priority Call .................................................... 51

Prog ............................................................... 52

Queue............................................................ 52

Quota............................................................. 52

RBak-............................................................. 53

RBak+............................................................ 53

RBSeq ........................................................... 53

Recor ............................................................. 53

Record Call.................................................... 53

Relay ............................................................. 54

Off ............................................................. 54

On ............................................................. 54

Pulse ......................................................... 54

Rely- .............................................................. 54

Rely+ ............................................................. 54

Resum ........................................................... 54

Resume Call .................................................. 54

Retrieve Call .................................................. 55

Ride ............................................................... 55

Ringback

Cancel....................................................... 53

Sequence.................................................. 53

When Free ................................................ 53

Ringback Off.................................................. 57

Ringback On.................................................. 58

Ringer Off ...................................................... 55

RngOf ............................................................ 55

Rtriv ............................................................... 55

SAC ............................................................... 56

Index - Page 69

Secondary Dial Tone..................................... 41

Self-Administer .............................................. 32

Send All Calls ................................................ 56

Sequence

Outside Call .............................................. 49

Ringback................................................... 53

Server IP Address ......................................... 25

Set

Absent Text............................................... 32

Hunt Group Night Service......................... 46

Hunt Group Out of Service ....................... 47

Inside Call Sequence................................ 48

No Answer Time ....................................... 49

Outside Call Sequence............................. 49

Ringback Sequence.................................. 53

Wrap Up Time........................................... 58

Speed Dials ................................................... 25

Spres ............................................................. 56

Steal .............................................................. 56

Suppress ....................................................... 56

SusCW .......................................................... 56

Suspe ............................................................ 57

Suspend

Call............................................................ 57

Call Waiting Suspend ............................... 38

CW............................................................ 56

System Administrator .................................... 25

Time

No Answer ................................................ 49

Wrap Up.................................................... 58

Time of Day ................................................... 57

Timer ............................................................. 57

TmDay........................................................... 57

Toggl ............................................................. 57

Toggle Calls .................................................. 57

Toggle Headset ............................................. 45

Transfer ......................................................... 25

Transfer Protocol........................................... 25

User............................................................... 31

User ID .......................................................... 25

VMCol............................................................ 58

VMOff ............................................................ 58

VMOn ............................................................ 58

VMRB-........................................................... 57

VMRB+.......................................................... 58

Voicemail

Collect....................................................... 58

Off............................................................. 58

On............................................................. 58

Ringback Off............................................. 57

Ringback On............................................. 58

Wrap Up Time ............................................... 58

WUTim .......................................................... 58

IP Office 3.0 5620SW + EU24 User’s Guide Page 69 - Index 40DHB0002USEP – Issue 1 (1st March 2005)

Performance figures and data quoted in this document are typical, and

must be specifically confirmed in writing by Avaya before they become

applicable to any particular order or contract. The company reserves the

right to make alterations or amendments to the detailed specifications at

its discretion. The publication of information in this document does not

imply freedom from patent or other protective rights of Avaya or others.

Intellectual property related to this product (including trademarks) and

registered to Lucent Technologies have been transferred or licensed to

™

All trademarks identified by the ® or

are registered trademarks or trademarks,

respectively, of Avaya Inc. All other trademarks are the property of their respective

This document contains proprietary information of Avaya and is not to be

disclosed or used except in accordance with applicable agreements.

Any comments or suggestions regarding this document should be sent

to "wgctechpubs@avaya.com".

Sterling Court

15 - 21 Mundells

Welwyn Garden City

Hertfordshire

Avaya.

owners.

Avaya

AL7 1LZ

England

Tel: +44 (0) 1707 392200

Fax: +44 (0) 1707 376933

Email: contact@avaya.com

Web: http://www.avaya.com

IP Office 3.0 5620SW + EU24 User’s Guide 40DHB0002USEP – Issue 1 (1st March 2005)

Avaya IP Office 5620SW + EU24 User's Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

The 5620 IP Telephone

Overview of the 5620

Call Appearance Keys

System Features

Call Appearance/Function Key Icons

Basic Call Handling Features

Answer Incoming Calls

Make a Call

Clearing a Call

Headset Working

Speakerphone

Mute

Hold

Speed Dial

Redial

Transfer

Conference

Speed Dials

Overview of Speed Dials

Using Speed Dials

Dialing a Speed Dial

Adding a Speed Dial from the Call Log

Editing a Speed Dial

Deleting a Speed Dial

Adding a New Speed Dial

Using the Call Log

Overview of the Call Log

Using the Call Logs

To Access the Call Logs

To Display an Individual Log Entry

To Make a Call from an Individual Log entry

To Turn a Log Entry into a Speed Dial

To Delete an Individual Log Entry

To Delete All Entries from a Log

To Exit the Call Logs

Changing the 5620 Options

Telephone Options Overview

Application Options

Redial

Phone Screen on Answer

Phone Screen on Calling

Display Call Timers

Message Display Rate

Visual Alerting

Personal Ringing

View IP Settings

IP Address Settings

Quality of Service (QoS) Information

Phone Interface

Miscellaneous Information

Adjusting the Display Contrast

Logging off the 5620 IP Telephone

Backup/Restore Options

Changing Feature Key Labels

Language Selection

Function Keys

Overview of Function Keys

Function Key Programming

Shorthand Programming Mode

Longhand Programming

Function Key Features

Dial (#)

Group (#)

User (#)

Absnt - Set Absent Text

Acct - Account Code Entry (!)

AD - Abbreviated Dial (!)

Admin - Self-Administer (!)

Apear - Appearance

AutCB - Automatic Callback (!)

Busy - Busy

BusyH - Busy On Held

CFrwd - Call Forwarding All (!)

ClrCW - Clear CW

CnfRV - Conference Meet Me

Conf+ - Conference Add
