IP Office
4400, 4600, 6400 & TransTalk MDW
9040 Telephones
40DHB0002USAL - Issue 6 (04/25/2003)
Page 2
Introduction Page ii
Contents
Introduction.............................. 3
4400, 4600 and 6400 Telephones ...............3
TransTalk
Phone Key Symbols..................................... 4
The Display .................................................. 5
®
MDW 9040 ................................3
Making Calls............................. 6
Make a Call .................................................. 6
Using the Directory ......................................6
Redial...........................................................7
Make a Page Call......................................... 7
Leave a Message......................................... 7
Arrange a Callback ......................................8
Leave a Message in Voicemail ....................8
Answering Calls....................... 9
Answer a Call...............................................9
Internal Auto-Answer ...................................9
Direct Pickup................................................9
Answering a Message Indicator ................. 10
Answering a Page Call...............................10
Other Call Controls................ 11
Account Codes........................................... 11
Recording a Call ........................................11
Handsfree Operation..................................11
Drop a Call ................................................. 12
Mute a Call.................................................12
Display the Call History .............................. 12
Conferencing Calls..................................... 13
Lock/Unlock the Phone.............................. 20
Change the Login Code............................. 21
Change the Extension Name..................... 21
Change the Phone Language.................... 21
DSS Key Functions ................22
Overview.................................................... 22
Storing Abbreviated Dialing Under a DSS
Key ............................................................ 22
Storing User, Park Slot and Queue
Numbers.................................................... 23
Programming Functions Against DSS
Keys .......................................................... 24
Functions................................................... 25
System Features.....................26
Introduction................................................ 26
Making Calls .............................................. 26
Answering Calls......................................... 26
Call Waiting ............................................... 27
Call Forwarding ......................................... 27
Diverting Calls ........................................... 27
Do Not Disturb ........................................... 28
Voicemail................................................... 28
The System Administrator ......................... 29
Default Speed Dial and Feature Codes ..... 29
Index ........................................31
Diverting Calls........................ 14
Switch Divert On ........................................14
Call Forwarding.......................................... 14
Send All Calls (Do Not Disturb)..................15
Setting Absence Text................................. 15
Hold, Park & Transfer ............ 16
Parking Calls.............................................. 16
Holding Calls.............................................. 17
Transfer a Call ...........................................17
Phone Controls ...................... 18
Labeling Softkey Functions ........................ 18
Display the Date and Time.........................18
Call Timer................................................... 18
Display Call Information ............................. 19
Changing the Volume................................. 19
Changing the Ringer Sound.......................19
Using Headsets.......................................... 19
Hot Desking ...............................................20
Group Enable/Disable ................................ 20
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page ii
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 3
Introduction Page 3
Introduction
4400, 4600 and 6400 Telephones
This guide covers the use of 4400, 4600 and 6400 series telephones on IP
Office telephone systems.
Note that this guide assumes that the phone you are using has its default
settings. Be aware that the System Administrator can reprogram the
system and/or individual extensions to offer different sets of features. If in
doubt please contact your System Administrator.
• Default Buttons
Each phone is configured by default with 3 Call Appearance buttons.
These buttons are located on the top 3 buttons of the leftmost column.
They are used to make and receive calls.
• DSS Keys
This guide details accessing many functions by pressing Menu
Many of those functions can be assigned to the DSS keys on your
phone. See "DSS Key Functions" on page 22. Note that the 4406D+,
4606D+ sets do not have the Menu
can either have a button programmed through the manager (contact
your system administrator) or by using the shortcodes. When using
these sets, use shortcodes. This operation is described beginning in
the System Features section on page 26.
• 4450 DSS Module
Some phones have a DSS port which allows the number of DSS
keys available to can be increased by the addition of a DSS module.
The 4450 DSS module is available for use with both the 4412D+ and
4424D+ sets. When using the 4450, ensure that the power supply
must be connected to the phone. The 4450 DSS module enhances
functionality by providing an array of buttons that can be used to
track Extensions, Users or Park fields, or be programmed for other
functions that help the user to handle calls more efficiently.
• System & User Short Codes
The system has a wide range of features that are triggered by dialing a
particular sequence. These shortcodes can be system-wide or specific
to an individual user. For details of the shortcodes available to you
contact your System Administrator. For details of the normal default
shortcodes see "System Features" on page 26.
.
button. For those sets, a user
TransTalk® MDW 9040
The TransTalk® MDW 9040 set is a wireless set that can be used with the
system. It is plugged into a DS port on either the base Control Unit or a
DS expansion module. When using the set, the user must configure it to
work with the system, by defining the button map to be used. This can be
done by going to the set and pressing the Menu button, then using the
arrow button to select Configuration, then Button Map and then selecting
Merlin Magix.
Although the TransTalk
local to the set and is used for features local to the set. For this reason,
when using this set, an administrator must program the buttons for the
user. Features can also be accessed on these sets via shortcodes.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 3
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
®
MDW 9040 has a Menu button, this button is
Page 4
Introduction Page 4
Phone Key Symbols
Your phone may use either text or icon markings for some keys.
• Spkr:
The light above the key is lit when working handsfree. See
"Handsfree Operation" on page 11.
• Mute:
The light above the key is lit or blinking when using mute. See
"Mute a Call" on page 12.
• Hold:
See "Holding Calls" on page 17.
• Redial:
See "Redial" on page 7.
• Trnsfr:
See "Transfer a Call" on page 17.
• Conf:
See "Conferencing Calls" on page 13.
• Message Indicator:
See "Answering a Message Indicator" on page 10.
• Menu:
Used to access features and functions (Not available on the
4406D+, 4606D+ and TransTalk
• The two keys are used to make display selections and data
entry (Not available on the 4406D+, 4606D+ and TransTalk®
MDW 9040).
• Exit:
Use this key to exit the administration menus and return to
normal phone operation (Not available on the 4406D+,
4606D+ and TransTalk
®
MDW 9040).
®
MDW 9040).
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 4
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 5
Introduction Page 5
The Display
• Phone locked:
B
Internal calls only, see "Lock/Unlock the Phone" on page 20.
• Call Forwarding On:
D
See "Call " on page 14.
• In Group:
G
• Held Call:
H
Shows the number of held calls, see "Holding Calls" on page
17.
• Do Not Disturb On: See "Send All Calls (Do Not Disturb)" on
N
page 15.
• Parked Calls:
P
Shows the number of parked calls, see Parking Calls on page
16.
• Unavailable:
U
This is displayed on the calling station when the called station
has Do Not Disturb activated, but is not being covered by
Voicemail.
• Voicemail:
V
This is displayed on the calling station when the called station
has Do Not Disturb activated, but is being covered by
Voicemail.
• Calls in Call History:
01
See "Display the Call History" on page 12.
DISC
CONN
CONF
PAGE
• Pressing Menu
and
to select it.
• Pressing Menu
• Disconnected:
Press Spkr
• Connected:
You are on a call.
• Conference Call:
You are part of a conference call, see "Conferencing Calls" on
page 13. This is displayed on the left hand side of the display
• Page Call:
See "Answering a Page Call" on page 10.
• Time & Date:
See "Display the Date and Time" on page 18.
• Timer:
See "Call Timer" on page 18.
• Indicates that the displayed item is either the currently
selected value or has selectable sub-options.
to show the functions and press the display key beneath an option
to end the call.
gives access to up to 12 softkey functions. Use
twice gives access to additional functions.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 5
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 6
Making Calls Page 6
Making Calls
Make a Call
All phones in these series have a handsfree speaker so that you can dial
and hear the call progress without having to pickup the handset.
On some models this facility is only one-way so you must use the handset
to be heard once the call is connected
To make a call
1. Dial the number you require.
• If ENTER ACCOUNT appears then you are required to enter an
account code before making calls, see page 11.
2. When answered either pickup the handset or, if your phone supports it,
continue handsfree, see "Handsfree Operation" on page 11.
3. To end the call either put down the handset or if working handsfree
press Spkr
Using the Directory
The phone can display a directory of group names, extension names or
directory names from which you can select and then dial. This feature is
not supported on phones without Menu
Note: This feature can work in two modes, Classic or Dial Name mode (the
default). Contact your System Administrator if unsure which mode your
telephone system uses.
To use the directory
1. Press Menu
DSS key, see page 22).
• Alternatively, press Menu
2. Select from INDeX (internal extensions), Group (hunt groups) or Extrn
(numbers in the IP Office Directory).
3. The next steps depend on which mode of working your system is using:
• Dial Name Mode
a. Using the letter keys, start dialing the name that you want, eg. for
names starting with John dial 5646. Ignore any spaces in the name.
b. The display will show the first match to the letters entered so far.
Either enter further letters or:
• Press the
the other matches found so far.
• If NO MATCH is displayed press
c. When the name you want is shown select Call.
d. If you cannot find the name you want press Exit
• Classic Mode
a. Press the dialpad button that matches the first letter of the name you
want. For example, to select L press the 5 key three times.
b. Use the
press another key on the dialing pad to select a different first letter.
c. When the name you want is shown select Call.
d. If you cannot find the name you want press Exit twice.
:
.
and keys.
:
and select Dir (this feature can also be set under a
twice. Press and then select Dir.
and keys on either side of the current name to display
to go back to the previous step.
twice.
and keys to move through the matching entries. You can
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 6
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 7
Making Calls Page 7
Redial
The phone stores a record of the numbers that you have dialed. You can
display and select a number from that record.
4406D+, 4606D+ and TransTalk
the button is pressed, the last number that was dialed is used.
To redial a number dialed
1. Press Redial
2. The display shows numbers that you have recently dialed.
3. Use the
4. Press the key below a number to redial it or press Exit
display without making a call.
and keys to move through the stored numbers.
.
®
MDW 9040 sets can use redial. When
:
to leave the
Make a Page Call
You can make page calls to any extension or group of extensions that have
suitable handsfree speakers. You call is only heard by those extension that
are free.
4406D+ users can make a page call via the shortcodes. Contact your
system administrator for the appropriate code.
TransTalk
them. 4600 Series phones cannot make or receive page calls.
To make a page call:
1. Press Menu
2. Select Call.
3. Enter the extension or group number (use the top-left display key to
backspace).
4. Select Page.
®
MDW 9040 users can make Page Calls, but cannot receive
twice.
Leave a Message
When you call another extension that doesn't answer you can leave them a
message indication. Depending on the type of their phone, they may have a
message indicator lamp, which lights (stations that do not have the Menu
also display your name and number for a return call.
On your phone the
Answering a Message Indicator on page 10.
To send a message indication
1. Press Menu
2. Select Call.
3. Enter the extension number (use the top-left display key to backspace).
4. Select Messa.
5. Press Exit
button and softkeys do not light). If their phone has a display it may
lamp indicates when you have messages, see
:
twice.
.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 7
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 8
Making Calls Page 8
Arrange a Callback
If an extension is busy, or does not answer when you call you can arrange
a callback rather than leave a message. With a callback set, after that
extension is next used you phone will ring and when you answer the
extension is rung.
To set a callback during a call
1. If when you make a call you are not answered or the station is busy,
press Menu
2. Using the
be set under a DSS key, see page 22).
3. End your call attempt.
4. After the extension you were calling is next used, your phone will ring
and when you answer the other extension is rung. Your phone rings the
number of times that has been specified in the Allocated Answer
Interval (either for the system, or if there has been an individual one set
for your user id). The default is three rings.
5. Press Exit
To arrange a callback without making a call
1. Press Menu
2. Select Call.
3. Enter the extension number (use the top-left display key to backspace).
4. Press
5. Press Exit
6. When that extension becomes free, you phone is rung and if you
answer the other extension then rings. Your phone rings the number of
times that has been specified in the Allocated Answer Interval (either for
the system, or if there has been an individual one set for your user id).
The default is three rings.
and select CallB.
.
and keys, display and select AutCB (This feature can also
if you desire.
twice.
.
:
:
Leave a Message in Voicemail
You can leave a message for directly in voicemail for an extension without
ringing the extension. This will light that extension message indicator if they
have one.
4406D+, 4606D+ and TransTalk
for an extension via the shortcodes. Contact your system administrator for
the appropriate code.
To leave a message directly in voicemail
1. Press Menu
2. Select Call.
3. Enter the extension or group number (use the top-left display key to
backspace).
4. Press
5. You should hear the mailbox greeting and then be prompted to leave a
message.
and select Vmail.
twice.
®
MDW 9040 users can leave a message
:
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 8
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 9
Answering Calls Page 9
Answering Calls
Answer a Call
To answer a call:
1. Your display will show whatever information the system has about the
calling party.
2. Press Spkr
Internal Auto-Answer
Internal auto-answer connects your internal calls after just one ring. This
feature also applies when a user is in Headset Mode (See Using Headsets
on Page 19).
TransTalk
To set/cancel internal auto-answer
1. Press Menu
2. Select HfAns (This feature can also be set under a DSS key, see page
22).
3. Press Exit
®
to answer handsfree or pickup the handset.
MDW 9040 users do not have access to Internal Auto Answer.
:
.
.
Direct Pickup
You can pickup a call ringing at another extension if you know the
extension number.
®
4406D+, 4606D+ and TransTalk
extension via the shortcodes. Contact your system administrator for the
appropriate code or if using the default shortcodes see Answering Calls on
page 26.
To do a direct pickup
1. When you here the extension ringing, press Menu .
2. Using the
can also be set under a DSS key, see page 22).
3. Enter the extension number and then select Done. Note that a DSS
key cannot be used to enter the extension number.
and keys, display and then select DpkUp (This feature
:
MDW 9040 users can pickup a call for an
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 9
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 10
Answering Calls Page 10
Answering a Message Indicator
If another extension has left you a message or you have voicemail, then
your
Note: If you have voicemail ringback switched on, then whenever you have
new messages the voicemail system will ring you after you use the phone.
4406D+, 4606D+ and TransTalk
Voicemail Messages by using the shortcode for Voicemail Collect. Contact
your system administrator for the appropriate code or if using the default
codes see Voicemail on page 28.
To answer a message indication
1. Press Menu twice.
2. Select Msgs.
3. Select the type of message you want to answer.
4. To check message indicators, select Recvs.
5. To check voicemail messages, select Voice.
lamp is lit.
®
MDW 9040 sets can access their
:
• A
• A
• The display will show the time, date and caller's extension number. It
• Use the
• Press the top-right display key to delete the displayed messages.
• The display will show you how many voicemail messages you have
• Follow the prompt to check your messages.
• For further details see "Voicemail" on page 28.
above Voice indicates that you have voicemail messages.
above Recvs indicates that another extension has lit you
message indicator.
also shows the message number and total number of messages.
and keys to move through the stored messages.
in your mailbox. It you are a member of a hunt group that has
messages, the hunt group name is also shown. Select the display
key for the mailbox you want to check.
Answering a Page Call
Other users may page you or a group to which you belong. You will hear
the page through your phone handsfree speaker and Page is displayed.
See "Make a Page Call" on page 7.
To answer a page and turn it into a normal call between you and the person
doing the paging, press the Conf
TransTalk
them. 4600 Series phones cannot make or receive page calls.
key.
®
MDW 9040 users can make Page Calls, but cannot receive
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 10
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 11
Other Call Controls Page 11
Other Call Controls
Account Codes
You can enter an account code during a call. Some extension may also be
required to enter an account code before making a call.
®
4406D+, 4606D+ and TransTalk
code via a short code. Contact your system administrator for the
appropriate short code.
Note: A list of valid account codes is stored on the system. Contact you
System Administrator for a list of account codes which you should use.
To enter an account code
You can do this before or during a call. If done before you will then hear dial
tone at which you can dial the number required.
1. Press Menu twice.
2. Select Func and then Acct (This feature can also be set under a DSS
key, see page 22). The display shows ENTER ACCOUNT.
3. Enter the account code to associate with the call and then select Set.
4. If REENTER ACCOUNT appears then the code was not recognized by
the system. Enter a valid code.
5. If already on a call you can now continue the call. If entering the
account code before making a call, the display now shows Dial and you
should hear dial tone.
MDW 9040 users must enter the account
:
Recording a Call
This function is not available on all systems or phones. You must have
Voicemail Pro running on the system. If the feature does not work, check
with your System Administrator to see what Voicemail Package you are
using. The recording is placed into your voicemail mailbox.
To record a call
1. During the call, press Menu
2. Select Func and then Recor.
Handsfree Operation
On some models of phone you can make and answer calls handsfree, that
is without lifting the handset.
• To switch from handsfree to handset operation pickup the handset.
• To switch from handset to handsfree operation, press Spkr
put down the handset.
• To answer a call handsfree press the Spkr
• While working handsfree pressing the Spkr key again will end the
call.
• Note also that whilst using the handset, if you hold a call and don't
replace the handset, to answer any call press the Spkr
:
twice.
and then
key.
key
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 11
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 12
Other Call Controls Page 12
Drop a Call
You can use this function to disconnect a caller. This feature can also be
used with conferencing - See "Conferencing Calls" on page 13.
4406D+ and 4606D+ sets should have a Drop button programmed on the
phone. Contact your system administrator to do this.
To drop a call
1. Press Menu
2. Select Drop (This feature can also be set under a DSS key, see page
22).
or
1. Press Menu
2. Select Func and then select Drop.
:.
.
twice.
Mute a Call
The Mute key allows you to stop the caller from hearing you while still
allowing you to hear them. While a call is muted, the lamp above the Mute
key is on (on the 6400 sets) and flashing (on 4400 and 4600 sets).
On the 4400 sets, when headset mode is active (see Using Headsets on
Page 19), the Mute button works for the Headset.
Display the Call History
The number shown in the right-hand of the phone display when idle is the
number of incoming calls stored in your phone's call history. These are calls
that have rung your phone (answered or unanswered) for which a CLI was
available. The phone can store the 32 most recent calls.
The redial facility allows you to see a record of the outgoing calls dialed
from your phone, see "Redial" on page 7.
Call History is not available on the 4406D+, 4606D+ and TransTalk
9040 sets.
To display the call history:
1. Press Menu
2. Press
3. The display shows the time, date and number of the caller. Use the
and
4. You can then select to either callback the caller or delete the call from
the call history.
• To delete the call from call history: Select Delet.
• To call the caller: Select Call.
and then select Hist.
keys to display the details of different callers.
twice.
®
MDW
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 12
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 13
Other Call Controls Page 13
Conferencing Calls
The number of callers that you can have in a conference depends on the
telephone system. Contact your System Administrator for details.
Note that 4600 series telephones cannot add callers to a conference when
working handsfree. They can return to handsfree once they have
completed adding a call to the conference.
To add another caller to a call or conference
1. During the existing call or conference, press Conf
2. Dial the other party.
• If not answered, end the call either by pressing the Drop or Hold
button, then press Conf.
• When answered, press Conf again. Any call that was put on Hold
is now conferenced in.
To drop a caller from a conference
Note: If the conference only contains four parties (including yourself), using
Drop to remove the last caller added will end the whole conference.
1. During the conference, press Menu
2. Using the
also be set under a DSS key, see page 22).
To display calls in a conference
1. CONF on your display indicates that you are in a conference call.
2. Press Menu
3. Select HC&P (held, conference and parked).
4. The
5. Use the
conference.
• To remove a caller from the conference: Select Drop.
and keys, display and then select Drop (This feature can
twice.
above Confs indicates a conference call. Select Confs.
and keys to see the details of the different callers in the
:.
:
:
.
.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 13
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 14
Diverting Calls Page 14
Diverting Calls
Switch Divert On
4406D+, 4606D+ and TransTalk® MDW 9040 users must use shortcodes to
activate these features.
To set the divert all calls (unconditional) number and modes
1. Press Menu
2. Press
3. Select Divrt .
4. Set the required divert number. Use the left-hand display key to
backspace. When you have activated CFrwd (see below), the extension
number is automatically filled in with the call forwarding number. Select
Next.
5. Use the display keys to switch Group (hunt group) and Divrt between Y
(on) and N (off).
• Diverting group calls is only used when divert all calls is also on. It
6. Select Done.
7. Press Exit
To set the divert on busy/no answer number and modes
1. Press Menu
2. Press
3. Select OnBsy.
4. Set the required divert number. Use the left-hand display key to
backspace. Select Next.
5. Use the display keys to switch OnBsy (busy) and NoAns (no answer)
between Y (on) and N (off).
6. Select Done.
7. Press Exit
and select ProgA.
also only works for calls to circular or linear groups.
and select ProgA.
twice.
.
twice.
.
:
:
Call Forwarding
You can forward you calls to another extension. While forwarding your calls
your phone will display a D in the top-right of the display. If the station that
you are forwarding calls to also has forwarding active, your call will go to
the final destination.
To set call forwarding
1. Press Menu
2. Using the
also be set under a DSS key, see page 22).
3. Set the required divert number. Use the left-hand display key to
backspace. When you have activated Divert (see above), the forward
number is automatically filled in with the Divert number. Then select
Done.
4. Press Exit
To clear call forwarding
1. Press Menu
2. Using the
3. Press Exit
and keys, display and then select CFrwd (This feature can
and keys, display and then select CFrwd.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 14
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
:
.
.
:
.
.
Page 15
Diverting Calls Page 15
Send All Calls (Do Not Disturb)
When on, all your callers either hear busy tone or are diverted to voicemail
if installed. The System Administrator can setup a list of exception numbers
for you who can still call you during Do Not Disturb.
4406D+and 4606D+ users can activate this feature via a short code or
programmed button.
TransTalk
To switch send all calls on/off
1. Press Menu
2. Using the
also be set under a DSS key, see page 22). A
on.
3. Press Exit .
®
MDW 9040 users activate this via a short code.
:
.
and keys, display and then select SAC (This feature can
above it indicates it is
Setting Absence Text
You can set some absence text that then appears on your phone's display.
The same text is also shown on other extension with suitable displays when
they call you.
Setting an absence text does not redirect your calls in any way, that must
be done using Call Forwarding, Divert or Do not Disturb.
4406D+, 4606D+ and TransTalk
feature via a shortcode.
To set your absence text
1. Press Menu
2. Press
3. Select Absnt.
4. To select an absence text select CHNGE.
5. When the text required is shown select DONE.
6. If you want some personal text to accompany your chosen message,
select EDIT, otherwise select NONE.
7. If you chose to have some personal, use the dialing keys and Rotat to
enter characters. For example, to enter an L press the 5 key and then
press Rotat until an L is displayed. When the text is as you require
press Done. You can use the top-left display key to backspace.
8. To display the message select SET.
9. Press Exit
To clear your absence text
1. Repeat the process above but select Clear when available.
and select ProgA.
twice.
.
®
MDW 9040 users can activate this
:
:
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 15
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 16
Hold, Park & Transfer Page 16
Hold, Park & Transfer
Parking Calls
You can park a call or several calls. You are then free to make and receive
other calls. You can also arrange for the parked call to be retrieved by
another extension.
Note that the system only allows calls to be parked for a short while before
reconnecting them, the default setting is 5 minutes.
When you park a call it is given number based on your extension number
followed by 0. If you now park another call that is given your extension
number followed by 1. If you inform another extension of the number given
to a parked call, they can then unpark that call (see below).
4406D+, 4606D+ and TransTalk
or a programmed button for this operation.
To park a call:
1. During a call, press Menu
2. Using the
also be set under a DSS key, see page 22). The caller is parked and
your phone displays a P as a reminder.
or
1. During a call, press Menu
2. Select Func and then select CPark. The caller is parked and your
phone displays a P as a reminder.
To retrieve the parked call at your extension
1. Press Menu .
2. Using the
3. The display shows the parked calls as your extension number plus a
number for the order in which it was parked. For example, for extension
206, the first parked call is 2060, the next parked call is 2061.
4. Select the call to unpark.
or
1. Press Menu
2. Select Func and then select CPark.
3. The display shows the parked calls as your extension number plus a
number for the order in which it was parked. For example, for extension
206, the first parked call is 2060, the next parked call is 2061.
4. Select the call to unpark.
To retrieve a parked call at another extension
1. At any extension on the system, dial *38*N# where N is the number that
was assigned to the parked call (usually the parking extension number
followed by 0) of the parked call.
• For example: To unpark the first call parked by 206, dial *38*2060#.
To display parked calls
1. A P on your display indicates that you have a parked call.
2. Press Menu
3. Select HC&P (held, conference and parked).
4. The
5. The displays show the parked calls using the number assigned to each
parked call.
6. To unpark a particular call, press the display key under the parked call.
and keys, display and then select CPark (This feature can
and keys, display and then select CPark.
twice.
:
twice.
above Parks indicates that there are parked calls. Select Parks.
®
MDW 9040 users can use the shortcode
.
twice.
:
:
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 16
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 17
Hold, Park & Transfer Page 17
Holding Calls
The system automatically reconnects held calls after a set period, the
default setting is 2 minutes.
To display held calls:
1. An H on your display indicates that you have a held call.
2. Press Menu
3. Select HC&P (held, conference and parked).
4. The
5. If you have several held calls you can use the
above Helds indicates that there are held calls. Select Helds.
of the different held calls.
• To clear a held call: Select Drop.
• To reconnect a held call: Select Pickup.
twice.
and keys to the details
Transfer a Call
To transfer a call:
1. During the call, press Trnsfr
2. Dial the number to which you want to transfer the call.
• If the extension doesn't answer or doesn't want the call press the
call appearance button to return to the original call.
• If the extension answers and will accept the transfer press Transfr
again.
• To do a blind transfer, hang up the call or hit the transfer button
again.
. The call is put on hold.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 17
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 18
Phone Controls Page 18
Phone Controls
Labeling Softkey Functions
You can rename the softkey functions that appear when you press Menu
. Note that this doesn't affect the function names shown when you
select Prog or Admin.
4406D+, 4606D+ and TransTalk
this feature.
To relabel softkey functions
1. Press Menu
2. Using the
also be set under a DSS key, see page 22).
3. Use the
4. Press Label.
5. Use the dialing keys and Rotat to enter characters, e.g. to enter an L
press the 5 key and then press Rotat until an L is displayed.
6. When the label is as you require press Done.
and keys to display and select the function to relabel.
.
and keys, display and then select Prog (This feature can
®
MDW 9040 users do not have access to
:
Display the Date and Time
You can change your phone display to show the date and time. This uses
the TmDay function. Note that this function overwrites all other display
information.
TransTalk
To set/cancel date and time display
1. Press Menu .
2. Using the
also be set under a DSS key, see page 22).
®
MDW 9040 users do not have access to this feature.
and keys, display and select TmDay (This feature can
Call Timer
You can run a call timer. If you start the timer before making a call, it will
reset to zero when you dial and again when you are connected.
Note that after ending a caller the timer is switched off.
®
TransTalk
To start the call timer
1. Press Menu
2. Select Timer (This feature can also be set under a DSS key, see page
22).
MDW 9040 users do not have access to this feature.
:
:
.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 18
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 19
Phone Controls Page 19
Display Call Information
You can display information about which number another extension is
calling.
To display call information:
1. Press Menu
2. Select Call.
3. Enter the extension or group number (use the top-left display key to
backspace).
4. Press
5. Press Exit
and select Listen.
twice.
.
Changing the Volume
You can alter the volume of the handsfree speaker, the handset speaker
and the ringer.
To change the ringer volume:
1. Without lift the handset, press the either end of the volume button. Use
either end of the button to adjust the volume.
To change the speaker volume
1. Lift the handset to adjust handset volume or press Spkr
handsfree volume.
2. Press the either end of the Volume
button to adjust the volume up
:
to adjust the
key. Use either end of the
or down .
Changing the Ringer Sound
This feature is available on the 6400 series phones only. You can select
the type of ring that your phone uses.
To change the ringer sound
This feature can also be set under a DSS key, see page 22.
1. Without lift the handset, press Conf
2. You will hear a ring. Press Conf again to hear another ring type.
3. Repeat pressing Conf until you hear the ring that you want. Wait until
you hear a ring again and then a tone. The ring is now saved.
Using Headsets
Using headsets is documented separately. Refer to your System
Administrator.
:
.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 19
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 20
Phone Controls Page 20
Hot Desking
Hot desking is the ability to log on at any phone on the system and have
that phone adopt your user settings until you log off. You cannot use hot
desking unless the System Administrator has allocated you as a hot
desking user. Note that this is only available when you have a defined
password.
To Log On
1. Press Menu twice.
2. Press
3. Select LogOn.
4. Enter your extension number and then select Next.
5. Enter your password and then select Done.
To Log Off
1. Press Menu
2. Press
3. Select LogOff.
4. The phone will now display NoUser.
:
and then select Hdesk.
:
twice.
and then select Hdesk.
Group Enable/Disable
You can enable or disable your group membership. Enabling your
membership means that you are available for calls.
4406D+ sets must use the shortcodes.
To switch send all calls on/off
1. Press Menu
2. Using the
indicates group membership is enabled.
3. Press Exit
Lock/Unlock the Phone
While locked the phone displays a B and can only make internal calls to
other extension. Attempts to make other calls display CALL BARRED.
To lock/unlock the phone:
1. Press Menu
2. Press
3. Select Bar.
4. Select Change to switch the phone between locked and unlocked, then
select Done.
5. Press Exit
and select ProgA.
:
twice.
and keys, display and then select Group. A above it
.
twice.
.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 20
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 21
Phone Controls Page 21
Change the Login Code
This changes the user's Login Code, used for functions such as Hot
Desking (see "Hot Desking" on page 20).
To set your phone password:
1. Press Menu
2. Press
3. Select Pswd.
4. Enter the existing password if requested and press Done.
5. Enter the new password and then press Done.
6. Press Exit
and select ProgA.
twice.
.
Change the Extension Name
This changes the full name stored by the telephone system. The full name
is used within the directory function and by the PhoneManager application.
It does not change the name shown when making and receiving calls.
To change your extension name
1. Press Menu
2. Press
3. Press
4. Enter the new name. Use the dialing keys and Rotat to enter
characters. For example, to enter an L press the 5 key and then press
Rotat until an L is displayed. You can use the top-left display key to
backspace.
5. When the text is as you require press Done.
6. Press Exit
and select ProgA.
and select Name.
twice.
.
:
Change the Phone Language
This will change the language used in the phone's display. On some
voicemail systems it will also change the language of the voicemail prompts
played when you collect your messages.
To change your phone language
1. Press Menu
2. Press
3. Press
4. Use the
DEFAULT is the system's default language.
5. When the text is as you require press Done.
6. Press Exit
and select ProgA.
and select Lang.
and keys to display the different language options.
twice.
.
:
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 21
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 22
DSS Key Functions Page 22
DSS Key Functions
Overview
You can program many of the phone’s functions to a DSS key. You can
also program dialing digits or user, group and park slot numbers.
®
• 4406D+, 4606D+ and TransTalk
The DSS keys on the 4406D+, 4606D+ and TransTalk
only be programmed through the Manager Application. Contact your
System Administrator.
• 4450 DSS module
The buttons of the 4450 DSS module are programmed via the station to
which the 4450 is connected. A user can program a button on the 4450
in the same manner that they would a button on their phone. In the
following sections, the “DSS key” can either be a button on the actual
station, or a button on the 4450 DSS module.
Storing Abbreviated Dialing Under a DSS Key
Each button can be programmed with the number that you would normally
dial. Typically you would use this for an external number or a system or
personal short code, consult your System Administrator for a list of
shortcodes.
To store digits under a DSS key
1. Press Menu
2. Using the
3. Press the required DSS key.
4. Enter the number to store. Note: You can store partial strings as after
pressing the DSS key you can dial further digits, e.g. you could store an
international dial prefix for all calls to a particular country.
5. Select Done.
6. Select another DSS key or press Exit
or
1. Press Menu
2. Using the
3. Use the
4. Enter the number to store. Note: You can store partial strings as after
pressing the DSS key you can dial further digits, e.g. you could store an
international dial prefix for all calls to a particular country.
5. Press the required DSS key.
6. Select Done.
7. Select another DSS key or press Exit
and keys to select AD.
.
and keys, display and then select Prog.
.
and keys, display and then select Admin
MDW 9040 Telephone:
.
.
®
MDW 9040 can
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 22
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 23
DSS Key Functions Page 23
Storing User, Park Slot and Queue Numbers
The following functions provide both number storage plus additional
functions and DSS key lamp usage.
To store user, park slot and queue numbers under a DSS key:.
1. Press Menu
2. Press
3. Press
4. The options shown are Park, User, Group and Dial.
• Park:
• User:
• Group:
• Dial:
5. Enter the number to store under the key (the park slot, user, group or
dial number). Use the left-hand display key to backspace.
6. Press the DSS key under which you want to store the function.
• If the DSS key is already set you will see options to Replace, Keep
7. When BUTTON PROGRAMMED is shown select Cont.
8. Press Exit
and select ProgA.
and select DSS.
Monitor a call park slot by entering the slot number (the extension
number followed by a single digit). When a call is parked in that slot
the DSS key flashes. If you press the key you have options to Drop
or Answr the call.
Monitor another extension. If the extension is ringing the lamp
flashes and when you press the DSS key you can see details of the
caller and have a DPkUp option to answer the call yourself. When
the lamp is on the extension is busy and pressing the DSS key
display information about any call in progress.
Monitor the status of a hunt group queue. Flashes green is a call is
incoming to the group. Flashes red if the group has queued calls.
Press the key to show call information, press the key again to pickup
a call.
This is similar storing a general number but the DSS lamp remains lit
until the call is disconnected.
or Delete the existing function. Select the option required.
twice.
.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 23
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 24
DSS Key Functions Page 24
Programming Functions Against DSS Keys
Any of the functions normally accessed by pressing Menu can also be
programmed under a DSS key. This allows faster access to the function.
To add a function to a DSS key:
1. Press Menu .
2. Using the
keys to display the function you want and then press the key below that
function. Selecting Expl? explains the function names.
• For a list of the available functions see "Functions" on page 25.
3. If the function requires some parameter such as an extension or group
number you can enter it now. If you don't enter a parameter then it will
be requested when you press the DSS key during usage.
4. Press the DSS key against which you want the function programmed.
• If the key is already programmed you will see options to Repla,
Keep or Delete. Select the option required.
5. Select Cont.
6. Either select another function and program another DSS key or press
Exit
To remove a function from a DSS key
1. Press Menu
2. Using the
3. Press the DSS key against which the function is programmed.
4. Press the key below Clear and then press the DSS key again.
5. Select Delet to remove the function.
7. Press the key below Cont.
8. Either select another function to program another key or press Exit
and keys, display and then select Admin Use the and
.
:
.
and keys, display and then select Admin.
.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 24
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 25
DSS Key Functions Page 25
Functions
The following can be programmed under a DSS key via the Prog or Admin
softkeys:
• Dir: A Directory button
• Drop: A Drop button
• Hfans: Hands Free Answer
• Timer: A Call Timer button
• AutoCB: Auto Callback button
• Cfrwd: Call forward button
• CPark: Call Park button. Leaving the telephone number blank allows
for more user flexibility by allowing the user to choose which call to
unpark.
• SAC: Send All Calls (Do Not Disturb) button
• TmDay: Time of Day button
• Hdset: Activate Headset Mode on the 4406D+, 4412D+ and 4424D+
phones.
In addition, the following can be done via the Admin softkey:
• Acct: Account Code button
• AD: Abbreviated Dial button (allows one touch dialing of a number)
• Park: Park a call to the extension that answered the call
• GrpPg: Group Page
• CPkup: Pickup next alerting call
• DPkup: Pickup call for a specific destination
• Rngof: Ringing disabled
• Spres: Abbreviated Dialing Suppression is similar to Abbreviated
Dialing.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 25
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 26
System Features Page 26
System Features
Introduction
As well as your phones specific features, you can access a number of
system features by dialing short codes.
These instructions are for the system's default configuration. They assume
that you are using the default feature codes. It also assumes that you have
full access to all features and the public telephone network. Users with
Making Calls
stations that do not have the Menu
TransTalk
numbers - ie. external number, Hunt Group) via the shortcodes.
Internal Calls: To make a call to another extension, simply dial the
number. If the number is busy, you can use Ring Back When Free as
below:
1. Dial any digit and hang up.
2. When the extension you called is free, your phone will ring (a burst of
three rings).
3. Lift the handset and the extension is called automatically.
External calls: To make an external call, either dial the number (prefixed
by the access code if required) or use a speed dial code (contact your
system manager for a list of your speed codes).
If you hear busy tone while dialing, then the call may be barred. Your
system manager can bar certain calls, such as those to premium rate
numbers and international calls
®
MDW 9040) must activate features (those requiring additional
button (4406D+, 4606D+ and
Answering Calls
Ringing at your own extension: Simply pick up the handset; internal calls
have a single ring cadence, external calls have a double ring cadence.
When in headset mode, press the button associated with the alerting call.
Ringing at another extension: You can answer from your own phone by
using Call Pick-Up; lift your handset and dial:
- *30 to answer a call ringing anywhere.
- *31 to answer a call within your group.
- *32*201# to answer the call for a particular extension, in this example
201.
Note that if your phone rings for any longer than a specified period (15
seconds in default), any re-direction feature that you have activated, such
as voicemail or call forwarding, will come into effect.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 26
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 27
System Features Page 27
Call Waiting
Call Waiting tells you if another call arrives while you are already making a
call by making providing call waiting tone. If you hear the Call Waiting
signal, use HOLD
Appearance button (of the alerting call) or HOLD
the alerting call.
To turn call waiting on use the code *15; to turn it off use *16.
to put the present caller on hold, press the Call
again to connect to
Call Forwarding
Your calls can be forwarded to another extension or an external number
either when you are away from your desk (on no answer), when your
extension is busy, and all calls (for example when you go on holiday).
- To switch forward direct station (i.e. not Hunt Group) calls on dial
*01, to switch it off dial *02.
- To switch forward on busy on dial *03, to switch it off dial *04.
- To switch forward on no answer on dial *05, to switch it off dial *06.
- To set the number to which your calls are forwarded dial *07*201#,
forwarding to 201 in this example.
Note: Your System Administrator may have configured a forwarding
number on your behalf; if so, by using the star code from your extension,
you over-ride the configured number. Forwarding on No Answer is not
effective if you are using voicemail.
Diverting Calls
You can divert your calls to another extension. In the examples below N is
the extension to which you want your calls diverted. Note that, if you do not
answer calls at the temporary extension, they are forwarded to your own
voicemail or call forwarding number.
At another extension:
- *12*N# from the extension you are temporarily using.
- *13*N# to re-direct the calls back to your own extension, before you
return to it.
At your own extension:
- *14*N# from your own extension.
- *14*# to cancel either feature from your own extension.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 27
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 28
System Features Page 28
Do Not Disturb
You may choose to receive no calls at all or only those from particular
callers on your exceptions list:
- To switch Do Not Disturb on (with or without exceptions) dial *08, to
switch it off dial *09.
- *10*N# to add a number to the exception list.
- *11*N# to delete a number from the exception list.
Note: Your callers, other than your exceptions, either hear busy tone or are
re-directed to your voicemail.
Voicemail
Note that not all systems support voicemail or have voicemail installed.
- To switch voicemail on dial *18, to switch it off dial *19.
- To retrieve your voicemail, use the code *17.
Note also that your voicemail may be set up to deliver your messages by
calling you whenever you hang up: this feature is known as Voicemail
Ringback.
- To turn Voicemail Ringback on dial *48; to turn it off dial *49.
Dialing a number while listening to your messages invokes further facilities:
Once messages have been delivered, they are held on the system for 24
hours.
You can collect your voicemail from another extension by using the PIN
your System Administrator has set up for you. You can collect your
messages if you are out of the office, by either dialing from a number that
has been registered for the purpose or by dialing your extension number
and PIN when prompted. If validation is successful, then dial 1 to retrieve
your mail.
The System Administrator also specifies the reception number, to which the
call is diverted if the caller dials 0, and your email address if your voicemail
and email are integrated.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 28
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 29
System Features Page 29
The System Administrator
The system enables you set up a wide range of advanced telephony
features, with your own numbering plan, speed dialing and feature codes. It
also allows you to restrict access, selectively, to certain numbers for
external calls and to permit controlled access to your local network for staff
working away from your premises.
Codes and phone numbers can be set up for the benefit of all users or can
be assigned to individual extensions. Codes for speed dialing may be up to
eight digits and may include the * and # symbols. The default feature codes
can be deleted and replaced by alternatives if required.
In use, phone numbers programmed for individual extensions take
precedence over general ones, and those entered at extensions take
overall precedence; these remain in force until canceled by the user or
when the system is re-booted.
Default Speed Dial and Feature Codes
Your System Administrator can set up Speed Dial codes for frequently used
numbers. These can be full numbers, area codes, or prefixes, which give
access to other telephone service providers.
*01 Forward Unconditionally On *15 Call Waiting On
*02 Forward Unconditionally Off *16 Call Waiting Off
*03 Forward on Busy On *17 Voicemail Collect
*04 Forward on Busy Off *18 Voicemail On
*05 Forward on No Answer On *19 Voicemail Off
*06 Forward on No Answer Off *26 Clear Call Waiting
*07*N# Forward to number *27*N# Hold Call Waiting
*08 Do Not Disturb On *30 Call Pick Up Any
*09 Do Not Disturb Off *31 Call Pick Up Group
*10*N# Do Not Disturb Exception Add *32*N# Call Pick Up Extension
*11*N# Do Not Disturb Exception Delete *33*N# Call Queue
*12*N# Follow Me Here *48 Voicemail Ringback On
*13*N# Follow Me Here Cancel *49 Voicemail Ringback Off
*14*N# Follow Me To *57*N# Forward on busy number
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 29
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 30
System Features Page 30
This page is intentional blank.
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 30
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 31
Index Page 31
Index
0
01 5
A
Absence text 15
Absnt 15
Account codes 11
Answer
Call 9
Internal auto-answer 9
Message indicator 10
Pickup 9
AutoCB 8
Automatic callback 8
B
B 5, 20
Bar 20
C
Call
Answer 9
Conference 13
Divert 14
Drop 12
Forwarding 14
Hold 17
Information 19
Make 6
Mute 12
Page 7
Park 16
Record 11
Timer 18
Transfer 17
Call history
Dialled 7
Call History
Incoming Calls 12
CallB 8
Callback 8
CFrwd 14
Clear a call 12
Conf 13
CONF 5
Conference calls 13
CONN 5
CPark 16
D
D 5, 14
Date 18
Default language 21
Dial 23
Dir 6
Directed pickup 9
DISC 5
Disconnect a call 12
Divert on busy 14
Divert on no answer 14
Diverting calls 14
Do not disturb 15, 20
DPkUp 9
Drop a call 12
DSS keys 22
E
Enter account 11
Enter Account 6
Exception numbers 15,
20
Extension name 21
Extrn 6
F
Forced account codes 11
Forwarding 14
G
G 5
Group 23
Call divert 14
Directory 6
H
H 5
Handset
Volume 19
Handsfree operation 11
HC&P 13, 16, 17
HfAns 9
Hist 12
History 12
Holding calls 17
Hot desking 20
I
Icons
Display 5
Keys 4
Incoming call history 12
INDeX 6
Internal auto-answer 9
K
Key markings 4
L
Label 18
Language 21
Leave a message 7
Leave voicemail
message 8
Lock 20
log off 20
Log on 20
M
Make Call 6
Messa 7
Message
Leave 7
Voicemail 8
Message indicator 7
Msgs 10
Mute 12
N
N 5
Name 21
P
P 5
PAGE 5, 7
Page call 7
Park 23
Parking calls 16
Password 21
Pickup 9
Pswd 21
R
Record call 11
Recvs 10
Redial 7
Reneter account 11
Ringer
Sound 19
Volume 19
S
Send all calls 15, 20
Speaker 11
Volume 19
Spkr 11
Symbols
Display 5
Keys 4
T
Time 18
Timer 18
TmDay 18
Transfer a call 17
U
Unlock 20
User 23
User language 21
User name 21
V
Vmail 8
Voice 10
Volume 19
X
Xfer 13
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 31
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Page 32
Index Page 32
Performance figures and data quoted in this document are typical, and
must be specifically confirmed in writing by Avaya before they become
applicable to any particular order or contract. The company reserves the
right to make alterations or amendments to the detailed specifications at
its discretion. The publication of information in this document does not
imply freedom from patent or other protective rights of Avaya or others.
Intellectual property related to this product (including trademarks) and
registered to Lucent Technologies have been transferred or licensed to
Avaya.
All trademarks identified by the ® or
trademarks, respectively, of Avaya Inc. All other trademarks are the
This document contains proprietary information of Avaya and is not to be
disclosed or used except in accordance with applicable agreements.
Any comments or suggestions regarding this document should be sent
© 2003 Avaya Inc. All rights reserved.
™
are registered trademarks or
property of their respective owners.
to "wgctechpubs@avaya.com".
Avaya
Sterling Court
15 - 21 Mundells
Welwyn Garden City
Hertfordshire
AL7 1LZ
England
Tel: +44 (0) 1707 392200
Fax: +44 (0) 1707 376933
Email: contact@avaya.com
Web: http://www.avaya.com
4400, 4600, 6400 & TransTalk MDW 9040 Telephones Page 32
IP Office 40DHB0002USAL - Issue 6 (04/25/2003)
Loading...
