Avanti OCRB43W User Manual
MINI KITCHEN
INSTRUCTION MANUAL
MANUAL DE INSTRUCCCIONES
Model Number / No. de Modelo: OCRB43W
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
Avanti has a policy of continuous improvement on its products and reserves the right to change materials and specifications without
notice.
La sección en español empieza en la página 18.
Avanti Products, A Division of The Mackle Co., Inc.
P.O. Box 520604 - Miami, Florida 33152
www.avantiproduct s.com
2
3
REGISTRATION INFORMATION
Thank you for purchasing this fine Avanti product. Please fill out this form and return it within 100 days of
purchase and receive these important benefits to the following address:
Avanti Products, A Division of The Mackle Co., Inc.
P.O. Box 520604 - Miami, Florida 33152 USA
? Protect your product:
We will keep the model number and date of purchase of your new Avanti product on file to help
you refer to this information in the event of an insurance claim such as fire or theft.
? Promote better products:
We value your input. Your responses will help us develop products designed to best meet your
future needs.
--------------------------------------------------------(detach here) ---------------------------------------------------------------
Avanti Registration Form
__________________________________ ______________________________________
Name Model # Serial #
__________________________________ ______________________________________
Address Date Purchased Store/Dealer Name
__________________________________ ______________________________________
City State Zip Occupation
__________________________________ As Your Primary Residence, Do You:
Area Code Phone Number ?Own ?Rent
Did You Purchase An Additional Warranty: Your Age:
?Extended ?None ?under 18 ?18-25 ?26-30
Reason For Choosing This Avanti Product: ?31-35 ?36-50 ?over 50
Please indicate the most important factors Marital Status:
that influenced your decision to purchase ?Married ?Single
this product. Is This Product Used In The:
?Price ?Home ?Business
?Product Features How Did You Learn About This Product:
?Avanti Reputation ?Advertising
?Product Quality ?In Store Demo ?Personal Demo
?Salesperson Recommendation ?Other_______________________________
?Friend/Relative Recommendation Comments____________________________
?Warranty _____________________________________
?Other_______________________ _____________________________________
4
5
HELP US HELP YOU ...
Read this guide carefully.
It is intended to help you operate and maintain
your new appliance properly.
Keep it handy to answer your questions.
If you don't understand something or you need
more assistance, please call:
Avanti Customer Service
800-220-5570
Keep proof of original purchase date (such as
your sales slip) with this guide to establish the
warranty period.
IF YOU NEED SERVICE
We're proud of our service and want you to be
pleased. If for some reason you are not happy
with the service you receive, here are some steps
to follow for further assistance.
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased. In
most cases, this will solve the problem.
Write down the model and serial numbers.
You'll find them on a label located on the back
side of the unit.
Please write these numbers here:
____________________________________
Date of Purchase
____________________________________
Model Number
____________________________________
Serial Number
Use these numbers in any correspondence or
service calls concerning your appliance.
If you received a damaged appliance,
immediately contact the dealer (or builder) that
sold you the appliance.
Save time and money. Before you call for
service, check the Problem Solver Guide. It lists
causes of minor ope rating problems that you
can correct yourself.
NEXT, if you are still not pleased, write all the
details, including your telephone number, and
send it to:
Customer Service
Avanti Products
10880 NW 30 Street
Miami, FL 33172 USA
6
PARTS AND FEATURES
4
1
1. 500W BURNER 6 . FUNCTION SELECTOR KNOB
2. HANDLE 7. OVEN INDICAT OR LIGHT
3. FULL VIEW GLASS DOOR 8. TIMER SELECTOR KNOB
4. 900W BURNER 9. BURNERS INDICATOR LIGHT
5. TEMPERATURE CONTROL KNOB 10. OPERATION SELECTOR KNOB
2
3
7
ACCESSORIES
1. OVEN WIRE RACK 5. ROTISSERIE MEAT FORKS
2. BAKE/BROIL/DRIP PAN 6. ROTISSERIE SKEWER
3. ROTISSERIE SKEWER HANDLING TOOL 7. CRUMB TRAY
4. METAL HANDLING TOOL
7
TABLE OF CONTENTS
Registration Information 3
Help Us Help You 5
Parts and Features 6
Important Safety Instructions 8
Installation Instructions 9
Before Using Your Appliance 9
Installation of Your Appliance 9
Electrical Connection 10
Operating Your Appliance 11
Control Panel 11
Using Your Oven 12
Using Your Range Top 14
Care and Maintenance 15
Cleaning Your Appliance 15
Storing Your Appliance 15
Troubleshooting Guide 16
Service for Your Appliance 16
Your Avanti Products Warranty 17
Wiring Diagram 17
Instrucciones en Español 18-21
