Page 1
Models / Modelos: MO7220MW / MO7221MB
MICROWAVE OVEN
MANUAL DE INSTRUCCIONES
INSTRUCTION MANUAL
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
La sección en español empieza en la página 14.
Avanti has a policy of continuous improvement on its products and reserves the right to change materials and
specifications without notice.
Avanti Products, A Division of The Mackle C o ., Inc.
P.O. Box 520604 - Miami, Florida 33152
www.avantiproducts.com
Page 2
2
Help Us Help You
3
Parts and Features
4
Important Safety Instructions
5
Installation Instructions
6
Before Using Your Microwave Oven
6
Installation of Your Microwave Oven
6
Safety Precautions
MICROWAVE ENERGY
6 – 7
Electrical Connection
8
Operating Your Microwave Oven
9
Cooking Techniques
11
Care and Maintenance
11
Problems with Your Microwave Oven?
12
Troubleshooting Guide
12
Service for Your Microwave Oven
12
Avanti Microwave Oven Warranty
13
Instrucciones en Español
14 - 18
Registration Information and Registration Card
LAST PAGE
TABLE OF CONTENTS
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
Control Panel / Operating Instructions Overview 9
Operation Procedure 10
Page 3
3
HELP US HELP YOU…
Read this guide carefully.
It is intended to help you operate and maintain
your new microwave oven properly.
Keep it handy to answer your questions.
If you don't understand something or you need
more assistance, please call:
Avanti Customer Service
800-220-5570
Keep proof of original purchase date (such as
your sales slip) with this guide to establish the
warranty period.
IF YOU NEED SERVICE
We're proud of our service and want you to be
pleased. If for some reason you are not happy
with the service you recei ve, here are s ome steps
to follow for further assistance.
FIRST, contact the people who serviced your
microwave oven. Explain why you are not
pleased. In most cases, this will solve the
problem.
Write down the model and serial numbers.
You'll find them on a label located on the rear wall
of the microwave oven.
Please write these numbers here:
____________________________________
Date of Purchase
____________________________________
Model Number
____________________________________
Serial Number
Use these numbers in any correspondence or
service calls concerning your microwave oven.
If you received a damaged microwave oven,
immediately contact the dealer (or builder) that
sold you the microwave oven.
Save time and money. Before you call for service,
check the Troubleshooting Guide. It lists causes
of minor operating problems that you can correct
yourself.
NEXT, if you are still not pleased, write all the
details, including your telephone number, and
send it to:
Customer Servic e
Avanti Products
10880 NW 30 Street
Miami, FL 33172 USA
Page 4
4
Models MO7220MW / MO7221MB
1
Glass Tray
2
Turntable Roller Guide
3
Power Selector Knob
4
Timer Selector Knob
5
Door Push Button
Parts and Features
Page 5
5
When using electrical appliances basic safety precautions should be followed, including the
following:
To reduce the risk of fire, electrical shock, or
basic precautions:
IMPORTANT SAFETY INSTRUCTIONS
WARNING
injury when using your appliance, follow these
Page 6
6
SAVE THESE INSTRUCTIONS
• Read all instructions before using the appliance.
• Read and follow the specific “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY” found on page 6.
• This appliance must be grounded. Connect only to properly grounded outlet.
SEE GROUNDING INSTRUCTIONS found on page 8.
• Install or locate the appliance only in accordance with the provided installation instructions.
• When cleaning surfaces of door and oven that comes together on the closing door, use only mild,
nonabrasive soaps, or detergents applied with a sponge or soft cloth.
• Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without
appearing to be boiling. Visible bubbling or boiling when the container is removed from the
microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS
SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A UTENSIL IS
INSERTED INTO THE LIQUID.
• Some products such as whole eggs and sealed containers-(for example, closed glass jars) may
explode and should not be heated in microwave oven.
• Use this microwave oven only for its intended use as described in this manual.
• Do not use corrosive chemicals or vapors in this appliance. This type of oven is specifically
designed to heat, cook, or dry food. It is not designed for industrial or laboratory use.
• As with any appliance, close supervision is necess ary when used by children.
• Do not operate this microwave oven if it has a damaged cord or plug, if it is not working properly, or
if it has been damaged or dropped.
• To reduce the risk of fire in the oven cavity:
• Do not overcook food. Carefully attend microwave oven if paper, plastic, or combustible
materials are placed inside the oven to facilitate cooking.
• Remove wire twist-ties from bags before placing bag in oven.
• If materials inside the oven should ignite, keep oven door closed, turn oven off at the wall
switch, or shut off power at the fuse or circuit breaker panel.
• Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils, or
food in the cavity when not in use.
• Only qualified service personnel should service this appliance. Contact the nearest authorized
service facility for examination, repair or adjustment.
• Do not cover or block any openings on this appliance.
• Do not use this microwave oven to heat corrosive chemicals (for example, sulfides and chlorides).
Vapors from such corrosive chemicals may interact with the contact and springs of the safety
interlock switches thereby rendering them inoperable.
• Do not immerse cord or plug in water.
• Keep cord away from heated surfaces.
• Do not let cord hang over edge of table or counter.
• Never clean appliance parts with flammable fluids. The fumes can create a fire hazard or
explosion.
• Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of this or any
other appliance. The fumes can create a fire hazard or explosion.
• Do not store this appliance outdoors. Do not use this product near water – for example near a
kitchen sink, in a wet basement, near a swimming pool, or similar locations
-
INSTALLATION INSTRUCTIONS
BEFORE USING YOUR MICROWAVE OVEN
• Remove the exterior and interior packing.
• Check to be sure you have all of the following parts:
• Glass Tray
-
Page 7
7
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to op erate this oven with the door-open s ince open-door operation can resu lt in
personnel.
• Turntable Roller Assem bl y (Roller and Roller Ring)
• Instruction Manual
• Inspect the oven after unpacking for any visual damage such as:
• Misaligned Door
• Damaged Door
• Dents or Holes in Door Window and Screen
• Dents in Cavity
If any of the above is visible, DO NOT use the oven.
INSTALLATION OF YOUR MICROWAVE OVEN
• When positioning the microwave oven, it should be set on a flat, steady surface.
• Do not block air vents. If they are blocked during operation, the oven may overheat and
eventually cause oven failure.
• Poor television reception and radio interference may result if the oven is located close to a TV,
radio, antenna, or antenna wire. Position the oven as far from them as possible.
• Clean the interior surface with lukewarm water using a soft cloth.
• Keep the oven away from hot air, steam or splashing liquids when choosing a place to locate it,
otherwise, the unit’s operation may be adversely affected, causing it to break down.
• Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption.
• Plug the appliance into an exclusive properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and or grounding should be directed toward a certified electrician or an
authorized Avanti Products s ervice cen ter .
• DO NOT place anything on the top of the oven.
• Keep the oven at least 5 inches away from both sidewalls and away from rear wall to ensure the
proper ventilation.
• DO NOT remove the turn-table drive shaft.
SAFETY PRECAUTIONS
harmful exposure to microwave energy. It is important not to defeat or tamper with the safety
interlocks.
(b) Do not place any object bet ween the oven f ront fac e and the door or a llow soil or c leaner residue
to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is n o dam age to the : ( 1) D oor ( bent ), (2) Hi nges and lat ches ( brok en or
loosened ), (3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualified service
Page 8
8
General Use
Utensils
Food
• DO NOT attempt to tamper with or make any adjustments or repairs to door, control panel or any
other part of the oven. Do NOT remove outer panel from oven. Repairs should only be done by
qualified service personnel.
• DO NOT operate the oven empty. The microwave energy will reflect continuously throughout the
oven if no food or water is present to absorb energy.
• If a fire occurs in the oven, turn the timer knob to the “0” position and LEAVE THE DOOR
CLOSED. Disconnect the power cord, or shut off power at the fuse or circuit breaker panel.
• DO NOT attempt to dry clothes, newspapers or other materials in oven. They may catch on fire.
• DO NOT use recycled paper products, as they may contain impurities, which may cause sparks
and/or fires when used.
• DO NOT hit or strike control panel. Damage to controls may occur.
• METAL CONTAINERS or dishes with metallic rims should not be used. Arcing may occur.
• METAL TWIST-TIES may not be used in the microwave oven.
• DO NOT use SEALED JARS or NARROW NECK bottles for cooking or reheating. They may
shatter.
• DO NOT use CONVENTIONAL THERMOMETERS in the microwave oven. They may cause
arcing. Use only those labeled “Microwave Safe” and follow all directions. Check the food in
several places.
• Remove PLASTIC STORE WRAPS before cooking or defrosting in the oven.
RECOMMENDED
• Microwave browning dish – Use to brown exterior of small items such as steaks, chops, or
pancakes. Follow the directions provided with your browning dish.
• Microwaveable plastic wrap – Use to retain steam. Leave a small opening for some steam to
escape and avoid placing it directly on the food.
• Paper towels and napkins – Use for short-term heating and covering; these absorb excess
moisture and prevent splattering. Do not use recycled paper towels, which may contain metal and
could ignite.
• Never use your microwave oven for HOME CANNING. The oven is not designed to permit
proper canning. Improperly canned food may spoil and be dangerous to consume.
• COOKING TIMES are approximate. Factors that may affect cooking are starting temperature,
altitude, volume, size and shape of food and utensils used. As you become familiar with the
oven, you will be able to adjust for these factors.
• It is better to UNDERCOOK RATHER THAN OVERCOOK foods. If food is undercooked, it can
always be returned to the oven for further cooking. If food is overcooked, nothing can be done.
Always start with minimum cooking times.
• SMALL QUANTITIES of food or foods with LOW MOISTURE content can burn, dry out or catch
on fire if cooked too long.
• DO NOT boil eggs in their shell. Pressure may build up and the eggs will explode.
• Potatoes, apples, egg yolks, whole acorn squash and sausage are examples of food with
NONPOROUS SKINS. These must be pierced before cooking to prevent bursting.
• POPCORN must be popped in a microwave corn popper. Microwave popped corn produces a
lower yield than conventional popping. DO NOT use oven for popcorn unless popped in a
microwave approved popcorn utensil or unless it’s commercially packaged and recommended
especially for microwave ovens. DO NOT use oil unless specified by the manufacturer.
• DO NOT attempt to deep fat fry in your oven.
• HEATED LIQUIDS can ERUPT if not mixed with air. DO NOT heat liquids in your microwave
Page 9
9
exists as to whether the appliance is properly grounded.
oven without first stirring.
ELECTRICAL CONNECTION
GROUNDING INSTRUCTIO NS
This appliance m us t be grounded. In the event of an electr ical short circuit, gro u ndi ng reduces the risk of
electrical shock by providing an escape w ire for the electric curren t. This appliance is equipped with a
cord having a grounding wire with a grounding plug. The plug must be inserted into an outlet that is
properly installed and grounded .
Improper use of the grounded plug can result in the risk of electrical shock. Consult a qualified
electrician or service person if the grounding instructions are not completely understood, or if doubt
The power cord of th is appliance is equipped with a three-prong plug which m ates with standard three
prong wall outlets to minimize the possibility of electrical shock.
Do not under any circumstances cut or remove the third ground prong from the power cord supplied.
Do not use the extension cord. If the power supply cord is too short, have a qualified electrician or
serviceman to install an outlet near the appliance.
This appliance requires a standard 115/120 Volts A.C. ~/60Hz electrical outlet with three-prong ground.
The cord should be secured behi nd the appl iance and not left exposed or danglin g to prevent ac cidental
injury.
A short power suppl y cor d i s provi ded to reduce the risks r es ulting f r om becoming entangled in or tr ippin g
over a longer cord.
Longer cord sets or extensions cords are available and may be used if care is exercised in their use.
If long cord or extension cord is used:
(1) The marked electric al rating of the cord set or extens ion cord sho uld be at least as great as the
electrical rating of the appliance
(2) The extension cord must be a grounding-type 3-wire cord, and
(3) The longer cord should be arranged so that it will not drape over the counter top or table top
where it can be pulled on by children or tripped over unintentionally.
Warning
Page 10
10
Power Setting
Power Output
Reheat
17%
Defrost
33%
Low
55%
Medium
77%
High
100%
Power Consumption:
120V ~ 60Hz, 1100W
Output (Watts):
700W
Operation Frequency:
2450MHz
Unit Dimensions (HxWxD):
10.6 x 17.6 x 13.5
Oven Cavity Dimensions
(HxWxD):
Oven Capacity:
0.7 cu. Ft.
Cooking Uniformity:
Turntable
Net Weight:
Approx. 22 Lbs
Power Selections:
5 Levels
OPERATING YOUR APPLIANCE
Although your oven is provided with safety features, it is important to observe the foll o wing:
• It is important not to defeat or tamper with safety interlocks.
• Do not place any object be tween the oven fr ont face and the door or all ow residue to accum ulate on
sealing surfaces. W ipe the sealing area frequen tly with a m ild detergent , rinse and w ipe dry. Ne ver
use abrasive powders or pads.
• When opened, the door mus t not be subjected to strain, f or example, a child hanging on an op ened
door or any load which could c ause the oven to fall for ward and cause injur y and damage the door.
Do not operate the o ve n if i t is damaged, until it has be en r e pair ed by a qualified service person. It is
particularly important that the oven closes properly and that there is no damage to the:
• Door (bent).
• Hinges and latches (broken or loosened).
• Door seals and sealing surfaces.
• The oven should not be adjusted or repaired by anyone except properly qualified service personn el.
Operating Instructions:
The control panel of your unit consists of two function selector
knobs.
• Power Selector Knob
Use this knob to select the power level at which you want to cook.
Power level increase when turning the knob in a clockwise direction
as well as decrease when turned in a counter clockwise direction.
Power levels are represented in the table below:
The power setting can be changed at any time during the cooking
process by turning the power selector knob to the desired setting.
• Time Selector Knob
Use this knob to select the appropriate cooking time desired.
Cooking times can be set up to a maximum
of 35 minutes per cooking session.
Note:
As soon as the time is turned, the oven will
start cooking. When setting the timer for
less than two (2) minutes, turn the timer
knob past the two (2) minute mark and then
return to the correct time. When the
cooking time has elapsed, a bell will ring
and the unit will turn off automatically.
8.3 x 11.6 x 11.9
Page 11
11
Power Selector Knob
desired power level
Time Selector Knob
desired cooking time (0-35 minutes)
OPERATION PROCEDURE:
• Plug the power supply cord into a standard 3-pronged 15 Amps, 120Volts A.C.~/60Hz.
• After placing the food in a suitable container, open the oven door and put it on the glas s tray.
The glass tray and roller guide must always be in place during cooking.
• Shut the door. Make sure that it is firmly closed.
• The oven door can be opened at any time during operation by pushing the door button.
The oven will automatically shut off. To restart the oven, close the door and the oven will start
automatically.
• The oven will automatically cook or defrost at the power as set on the Power Selector Knob.
The power setting can be changed at any time during the cooking process by turning the power
selector knob to the desired setting.
• The oven will not start cooking until the door is completely closed and the cooking time has been set
on the Time Selector Knob.
Turn the Power selector knob to the
NOTE:
As soon as the timer is turned, the oven will start cooking. When setting the timer for less than two (2)
minutes, turn the knob past the two (2) minute mark and then return to the correct time.
When the cooking time has elapsed, a bell will ring and the unit will turn off automatically.
CAUTION:
ALWAYS RETURN THE TIMER BACK TO THE ZERO POSITION, when food is removed from the oven
prior to the end of the cooking cycle or when the oven is not in use.
INTERIOR LIGHT:
As soon as the timer is turned, the interior light will turn on and will remain on during the cooking process.
Once the timer selector knob reaches the “0” position the light will turn off automatically.
Turn the Time selector knob to the
Page 12
12
COOKING TECHNIQUES
Your microwave makes cooking easier than conventional cooking, provided you keep these
considerations in mind.
Stirring
Stir foods such as casseroles and vegetables while cooking to distribute heat evenly. Food at the outside
of the dish absorbs more energy and heats more quickly, so stir from the outside to the center. The oven
will turn off when you open the door to stir your food.
Arrangement
Arrange unevenly shaped foods, such as chicken pieces or chops, with the thicker, meatier parts toward
the outside of the turntable where they receive more microwave energy. To prevent overcooking, place
delicate areas, such as asparagus tips, toward the center of the turntable.
Turning
Turn foods over midway through cooking to expose all parts to microwave energy. This is especially
important with large foods such as roasts.
Standing
Foods cooked in the microwave build up internal heat and continue to cook for a few minutes after
heating stops. Let foods stand to complete cooking, especially foods such as cakes and whole
vegetables. Roasts need this time to complete cooking in the center without overcooking the outer areas.
All liquids, such as soup or hot chocolate, should be shaken or stirred when cooking is complete. Let
liquids stand a moment before serving. When heating baby food, stir well at removal and test the
temperature before serving.
Adding Moisture
Microwave energy is attracted to water molecules. Food that is uneven in moisture content should be
covered or allowed to stand so that the heat disperses evenly. Add a small amount of water to dry food to
help them cook.
CARE AND MAINTENANCE
CLEANING YOUR APPLIANCE
• Turn the oven off and remove the power plug from the wall socket before cleaning.
• Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe
with a damp cloth. Mild detergent may be used if the oven gets very dirty. The use of harsh
detergent or abrasives is not recommended.
• The outside oven surfaces should be cleaned with a damp cloth. To prevent damage to the
operating parts inside the oven, water should not be allowed to seep into the ventilation openings.
• Do not allow the control panel to become wet. Clean with a soft, damp cloth. Do not use detergents,
abrasives or spray-on cleaners on the control panel. When cleaning the control Panel, leave oven
door open to prevent oven from accidentally turning on.
• If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may
occur when the microwave oven is operated under high humidity conditions and in no way indicates
malfunction of the unit.
• It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy
water or in a dishwasher.
• The roller ring and oven cavity floor should be cleaned regularly to avoid excessive noise. Simply
wipe the bottom surface of the oven with mild detergent, water or window cleaner and dry. The roller
ring may be washed in mild sudsy water or dishwasher. Cooking vapors collect during repeated use
but in no way affect the bottom surface or roller ring wheels. When removing the roller ring from
cavity floor for cleaning, be sure to replace it in the proper position.
• Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in a
deep microwavable bowl. Microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth.
• When it becomes necessary to replace the oven light, please consult a dealer to have it replaced.
Page 13
13
PROBLEM
POSSIBLE CAUSE
The door is not closed properly.
section for the replacement procedure).
Vibrations.
Check to assure that the appliance is level.
800-323-5029
help is available.
red directly to your home by personal
know your appliance inside and out.
PROBLEMS WITH YOUR APPLIANCE?
You can solve many com mon appliance problems eas ily, saving you the cost of a pos sible service call.
Try the suggestions below to see if you can solve the problem before calling the servicer.
TROUBLESHOOTING GUIDE
Appliance does not operate.
The light does not work.
Not plugged in.
The circuit breaker tripped or a blown fuse.
The circuit breaker tripped or a blown fuse.
The appliance is unplugged.
The bulb has burned out (see the maintenance
SERVICE FOR YOUR APPLIANCE
We are proud of our cust omer service organizatio n and the network of professional service tech nicians
that provide service on your Avanti appliances. W ith the purchase of your Avanti appl iance, you can be
confident that if you ever need additional information or assistance, the Avanti Products Customer
Service team will be here for you. Just call us toll-free.
AVANTI PRODUCTS CUSTOMER SERVICES
Product Information
Part Orders
800-220-5570
In-Home Repair Service
800-220-5570
Whatever your questions a re about our products ,
You may order parts and ac cessories that will be
delive
check, money order, Master Card, or Visa.
An Avanti Products authorized ser vice center will
provide expert repair s ervic e, sc hedule d at a t im e
that is convenient for you. Our trained servicers
Page 14
14
Avanti Microwave Ovens
LIMITED WARRANTY
LIMITED ONE-YEAR WARRANTY
Avanti Products will repair or replac e, witho ut charg e, any part of your product, which proves to be
defective in material or workmanship under normal use during the first year after the date of original
purchase by a consumer. This warranty is good for the original purchaser during the warranty period and
applies only in the continental United States. Transportation of this product to and from the designated
service facility is the responsibility of the consumer.
LIMITED TWO-YE AR WARRANTY
During the second year of use, Avanti Prod ucts will f urnish, as need ed, a rep lacement par t at no char ge
in exchange for any origin al part, which fails due to a defect in mat erial or workmanship. All labor and
transportation charges are the responsibility of the owner.
LIMITED SEVEN-YEAR WARRANTY-MAGNETRON TUBE
For an additional 6-year period beyond the first year of the general coverage of this warranty, Avanti
Products will replace a magnetron tube, which fails due to a defect in material or workmanship. The
consumer will be responsible for all labor, service charge and transportation.
This warranty is good for the original purchaser during the warranty period and applies only in the
continental United States.
Implied warranties of the mer chantabilit y or, to the ext ent applica ble, fitness for a part icular purpose, are
limited in duration to seven years, the same duration as the basic limited warranty provided hereby. Some
states do not allow limitations on how long an implied warranty may last.
So, this limitation may not apply to you.
Avanti Products shall not b e liable f or any food loss or for any other inci dental or c onsequential d amages
not for any special damages or any further loss which may arise in connection with its warranted
appliance or any claims under this warranty. Some states do not allow the exclusion or limitation of
incidental or consequential damages. So the above exclusion or limitation may not apply to you.
To obtain service under this warranty, contact an y of the Avanti Products service c enters. A list of the
service centers can be obtained from your dealer or from Avanti Products, 10880 N.W. 30
Fl 33172. The user must keep a copy of the bill of sale verifying the purchase date to validate the
warranty.
THE ABOVE WARRANTIES DO NOT APPLY
1. To damages or problems, which result from improper installation or delivery.
2. To damages or problems, which result form misuse, abuse, accident, alteration, or incorrect
electrical current or voltage.
3. To service calls. (Unit must be brought or shipped to and from applicable service centers)
4. To any other product used for anything other than normal private household use.
5. To light bulbs.
This warranty gives you specific legal rights, and you may also have other rights, which vary from state to
state.
AVANTI PRODUCTS, A DIVISION OF THE MACKLE CO., INC.
P.O. BOX 520604 – MIAMI, FLORIDA 33152 USA
th
Street, Miami,
Page 15
15
PARA REDUCIR EL RIESGO DE INCENDIO,
SIGA ESTAS INDICACIONES.
GUARDE LAS INSTR UC CIONES CERCA DE SU ALC AN C E.
INSTRUCCIONES EN ESPAÑOL
PRECAUCION
• LEA TODAS LAS INSTRUCCIONES ANTES DE USAR SU HORNO MICROONDAS.
• ALGUNOS PRODUCTOS TALES COMO HUEVOS ENTEROS Y ENVASES SELLADOS
(POR EJEMPLO, FRASCOS DE VIDRIO) PUEDEN EXPLOTAR, POR LO QUE NO DEBEN
SER CALENTADOS EN SU HORNO MICROONDAS.
• USE SU HORNO MICROONDAS SOLAMENTE PARA LO QUE SE INDICA EN ESTE
MANUAL.
• NO USE SUSTANCIAS QUIMICAS CORROSIVAS O GASES EN ESTE HORNO. ESTE
TIPO DE HORNO MICROONDAS ESTA DISEÑADO ESPECIFICAMENTE PARA
CALENTAR, COCINAR, Y DESHIDRATAR ALIMENTOS, NO ESTA DISEÑADO PARA USO
INDUSTRIAL O DE LABORATORIO.
• COMO CON TODO ELECTRODOMESTICO, ES NECESARIA LA SUPERVISION DE UNA
PERSONA ADULTA CUANDO SEA OPERADO POR NIÑOS.
• NO USE SU HORNO MICROONDAS SI TIENE EL CORDON O EL ENCHUFE DAÑADOS,
SI NO ESTA FUNCIONANDO APROPIADAMENTE, O SI ESTE SUFRIO UN GOLPE O UNA
CAIDA.
• PARA REDUCIR EL RIESGO DE CHISPAS O FUEGO EN EL INTERIOR DEL HORNO
MICROONDAS:
• NO RECOCINE ALIMENTOS. ESTE PENDIENTE DE SU HORNO MICROONDAS
CUANDO COCINE ALIMENTOS QUE VENGAN CON ALGUN TIPO DE ENVOLTURA
COMO: PAPEL, PLASTICO, O MATERIAL QUE PUEDA SERVIR COMO
COMBUSTIBLE, PODRIA INICIAR UN INCENDIO.
• RETIRE EL ALAMBRE METALICO QUE SE UTILIZA PARA CERRAR LAS BOLSAS
ANTES DE COLOCAR EL ALIMENTO DENTRO DEL HORNO.
• SI ALGUNO DE LOS MATERIALES QUE ESTAN DENTRO DEL HORNO SE
INCENDIAN, MANTENGA LA PUERTA DEL HORNO MICROONDAS BIEN CERRADA,
DESCONECTELO O APAGUE LA LLAVE GENERAL DE ELECTRICIDAD.
• NO ALMACENE OBJETOS, NI DEJE PAPELES, UTENSILIOS DE COCINA, O
ALIMENTOS DENTRO DE SU HORNO MICROONDAS.
• SOLO PERSONAL DE SERVICIO AUTORIZADO PUEDE BRINDAR SERVICIO TECNICO A
SU HORNO MICROONDAS. COMUNIQUESE CON EL SERVICIO TECNICO AUTORIZADO
MAS CERCANO PARA EXAMINAR, O REPARAR SU HORNO MICROONDAS.
• NO CUBRA NI OBSTRUYA NINGUN TIPO DE VENTILACION DE SU HORNO.
• NO USE SU HORNO MICROONDAS PARA CALENTAR SUSTANCIAS QUIMICAS
CORROSIVAS (POR EJEMPLO, SULFUROS Y CLORUROS), EL GAS DE DICHOS
QUIMICOS PUEDE INTERACTUAR CON LOS CONTACTOS Y RESORTES DE LA LLAVE
DE SEGURIDAD, DEJANDOLA INOPERABLE.
• NO SUMERJA EL CORDON NI EL ENCHUFE DENTRO DEL AGUA.
• MANTENGA SU HORNO MICROONDAS ALEJADO DE SUPERFICIES CALIENTES.
• NO DEJE EL CORDON COLGANDO EN EL BORDE DE MESAS O MOSTRADORES.
• NO LIMPIE SU HORNO MICROONDAS CON LIQUIDOS INFLAMABLES. LOS GASES QUE
ESTOS EMITEN PUEDEN OCASIONAR UNA EXPLOCION Y/O INCENDIO.
• NO ALMACENAR NI USAR GASOLINA, NINGUN TIPO DE GAS O LIQUIDO INFLAMABLE
CERCA DE SU HORNO MICROONDAS O DE OTR OS ELECTRODOMESTICOS, YA QUE
PUEDEN PRODUCIR UN INCENDIO Y DESENCADENAR UNA EXPLOSION.
ESTE USANDO SU HORNO MICROONDAS,
DESCARGA ELECTRICA, O DAÑO CUANDO
Page 16
16
INDICACIONES PARA LA INSTALACION
ANTES DE USAR SU HORNO MICROONDAS
• RETIRE LA ENVOLTURA EXTERIOR E INTERIOR
• VERIFIQUE QUE TENGA LAS SIGUIENTES PARTES:
• PLATO DE VIDRIO
• ARO GIRATORIO
• MANUAL DE USO
• VERIFICAR QUE EL HORNO MICROONDAS NO TENGA LOS SIGUIENTES DAÑOS:
• PUERTA MAL ALINEADA O DESCUADRADA
• PUERTA DAÑADA
• ABOLLADURAS O AGUJEROS EN LA PUERTA Y/O PANTALLA.
• ABOLLADURAS DENTRO DEL HORNO.
SI SU HORNO MICROONDAS MUESTRA ALGUNA DE LAS CARACTERISTICAS ARRIBA
MENCIONADAS, NO LO USE.
INSTALACION DE SU HORNO MICROONDAS
• DEBE UBICAR SU HORN O MICRO O N D AS EN UNA SU P ERF ICIE PLANA Y EST ABLE.
• NO OBSTRUYA NINGUN TIPO DE VENTILACION. SI ESTO SUCEDE MIENTRAS USTED OPERA
SU HORNO MICROONDAS OCASIONARA QUE ESTE SE RECALIENTE Y QUE
EVENTUALMENTE SE MALOGRE.
• COLOCAR EL HORNO MICROONDAS CERCA A SU TELEVISOR, RADIO, ANTENA O CABLES
DE LA ANTENA, PODRI A O CASI O N AR MA LA S EÑ A L EN LA T ELE VI SIO N E IN TERFERENCIA EN
LA RADIO. POR LO TANTO RECOMENDAMOS UBICAR SU HORNO MICROONDAS LO MAS
ALEJADO POSIBLE DE ESTOS ARTEFACTOS.
• LIMPIE LA SUPERFICIE INTERIOR DEL HORNO MICROONDAS CON UN TRAPO SUAVE
HUMEDECIDO CON UN POCO DE AGUA TIBIA.
• MANTENGA SU HORN O MICR O O NDAS ALEJADO DEL AIR E CALIENTE, VAPOR O DE LAS
SALPICADURAS DE LIQUIDOS CUANDO ESCOJA UN LUGAR DONDE UBICARLO, DE NO
HACERLO SU FUNCIONAMIENTO PODRIA SER AFECTADO.
• LOS RAYOS SOLARES DIRECTOS PODRIAN AFECTAR EL REVESTIMIENTO ACRILICO Y LAS
FUENTES DE CALOR PODRIAN INCREMENTAR EL CONSUMO ELECTRICO.
• CONECTE SU HORNO MICROONDAS A UN TOMACORRIENTE DE PARED EXCLUSIVO Y
APROPIADO. BAJO NINGUNA RAZON SE DEBE RETIRAR LA TERCERA PUNTA (CABLE DE
TIERRA) DEL ENCHUFE. CUALQUIER CONSULTA RESPECTO A LA CORRIENTE ELECTRICA
Y/O EL CABLE DE TIERRA, DEBE SER DIRIGIDA A UN ELECTRICISTA CERTIFICADO O A UN
CENTRO DE SERVICIOS AUTORIZADO POR AVANTI PRODUCTS.
• NO COLOQUE OBJETOS SOBRE SU HORNO MICROONDAS.
• PARA ASEGURAR UN A V EN TILACION APROPI AD A MANTENGA SU HORNO MIC RO O NDAS A
POR LO MENOS 5 PULGADAS DE LA PARED.
• NO REMUEVA EL EJE DEL MOTOR GIRATORIO.
MEDIDAS DE PRECAUCION
USO GENERAL
• NO INTENTE MANIPULAR, AJUSTAR O REPARAR LA PUERTA, EL PANEL DE CONTROL O
CUALQUIER PARTE DE SU HORNO MICROONDAS. NO REMUEVA EL PANEL DE CONTROL
DEL HORNO. LAS REPARACIONES DEBERAN SER REALIZADAS POR PER SO N A L DE
SERVICIO CALIFI C AD O .
• NO UTILICE EL HORNO CUANDO ESTE VACIO. SI NO HAY ALIMENTOS O AGUA DENTRO DEL
HORNO MICROONDAS, QUE PUEDAN ABSORBER TODA LA ENERGIA DE LAS MICROONDAS,
ESTA SE REFLEJARA CONTINUAMENTE DENTRO DEL HORNO.
Page 17
17
• DE SUCEDER UN INCENDIO, PRESIONE LA TECLA START/STOP EN EL PANEL DE CONTROL
Y DEJE LA PUERTA CERRADA. DESCONECTE EL ENCHUFE O DESCONECTELO DE LA CAJA
GENERAL DE LA ELECTRICIDAD.
• NO INTENTE SECAR ROPA, PERIODICOS, U OTRO TIPO DE MATERIALES EN EL HORNO.
ESTOS PODRIAN INCENDIARSE.
• NO USE PRODUCTOS DE PAPEL RECICLADO, ESTOS CONTIENEN IMPUREZAS QUE PUEDEN
CAUSAR CHISPAS Y FUEGOS CUANDO SON USADOS.
• NO GOLPEE EL PANEL DE CONTROL, PODRIA DAÑAR LOS CONTROLES.
UTENSILIOS
• NO USE ENVASES DE METAL O PLATOS CON BORDES METALICOS, PODRIAN OCASIONAR
CHISPAS.
• NO USE ALAMBRES METALICOS PARA CERRAR BOLSAS EN SU HORNO MICROONDAS.
• NO USE FRASCOS SELLADOS O BOTELLAS DE CUELLO ESTRECHO PARA COCINAR O
RECALENTAR. PODRIAN ROMPERSE.
• NO USE TERMOMETROS CONVENCIONALES EN EL MICROONDAS. SOLO USE LOS
LLAMADOS “MICROWAVE SAFE” (PARA USO EN MICROONDAS) SIGUIENDO SUS
INSTRUCCIONES.
• RETIRE LAS ENVOLTURAS PLASTICAS DE LOS ALIMENTOS ANTES DE COCINARLOS O
DESCONGELARLOS.
CONEXION ELECTRICA
ESTA UNIDAD DEBE SER CONECTADO A TIERRA. EN EL CASO QUE OCURRA UN CORTO
CIRCUITO, LA CONEXION A TIERRA REDUCIRA EL RIESGO DE RECIBIR UNA DESCARGA
ELECTRICA POR TENER UN ALAMBRE PARA EL ESCAPE DE LA CORRIENTE ELECTRICA. ESTE
HORNO MICROONDAS ESTA EQUIPADO CON UN ENCHUFE QUE POSEE UN CABLE DE TIERRA.
EL CABLE DEBE SER CONECTADO EN UN TOMACORRIENTE QUE ESTE APROPIADAMENTE
INSTALADO Y QUE POSEA UN RECEPTOR PARA CABLE DE TIERRA.
ADVERTENCIA
EL USO INAPROPIADO DEL CABLE DE TIERRA PUEDE RESULTAR EN UNA DESCARGA
ELECTRICA. CONS ULTE A UN ELECT RICIST A O PERSONAL DE S ERVICIO CALIFICADO SI TIEN E
ALGUNA DUDA SOBRE LAS INSTRUCCIONES DE INSTALACION DEL CABLE DE TIERRA.
EL CORDON DEL HORNO MICROONDAS ESTA EQUIPADO CON UN ENCHUFE DE TRES PUNTAS
EL CUAL ENCAJA PERFECTAMENTE EN UN TOMACORRIENTE DE PARED DE TRES PUNTAS
ESTANDAR PARA REDUCIR EL RIESGO DE UNA DESCARGA ELECTRICA.
BAJO NINGUNA CIRCUNSTANCIA CORTE O RETIRE LA TERCERA PUNTA DEL ENCHUFE YA QUE
ESTA ES LA CONEXION A TIERRA.
NO USE UNA EXTENSION ELECTRICA.
LA CORRIENTE ELECTRICA DE ESTE HORNO MICROONDAS ES DE 115 A 120 VOLTIOS, TIENE
UNA SALIDA ELECTRICA DE 60 HZ Y UN ENCHUFE DE TIERRA DE TRES PUNTAS QUE VA
CONECTADO AL TOMACORRIENTE DE PARED.
OPERANDO SU HORNO MICROONDAS
AUNQUE SU HORNO MICROONDAS ESTE EQUIPADO CON CARACTERISTICAS DE SEGURIDAD,
ES IMPORTANTE TOMAR NOTA DE LO SIGUIENTE:
• NO TRABE O FUERZE LOS SEGUROS INTERNOS.
• NO DEJE NINGUN OBJETO ENTRE LA CARA FRONTAL DEL HORNO Y LA PUERTA. NO DEJE
Page 18
18
GIRE EL SELECTOR DE PO TENCIA
GIRE EL SELECTOR DE
TIEMPO DESEADO
NIVEL DE POTENCIA
PORCENTAJE DE LA POTENCIA TOTAL
REHEAT (RECALENTAR)
17%
DEFROST (DESCONGELAR)
33%
LOW (BAJO)
55%
MEDIUM (MEDIANO)
77%
HIGH (ALTO)
100%
QUE SE ACUMULEN RESIDUOS EN LAS SUPERFICIES SELLADAS. LIMPIE DICHAS
SUPERFICIES FRECUENTEMENTE CON UN DETERGENTE SUAVE, ENJUAGUE Y SEQUELO.
NUNCA USE DETERGENTE EN POLVO O ESPONJAS ABRASIVAS.
• CUANDO LA PUERTA ESTE ABIERTA NO LA FUERZE DEMASIADO, POR EJEMPLO UN NIÑO
COLGANDOSE DE ELLA O UNA CARGA QUE CAUSE QUE EL HORNO SE CAIGA HACIA
DELANTE Y DE ESTA MA NERA DAÑE LA PUERTA
• SI SU HORNO MICROONDAS ESTA MALOGRADO NO LO USE HASTA QUE HAYA SIDO
REPARADO POR PERSONAL DE SERVICIO CALIFICADO. ES IMPORTANTE QUE SU HORNO
MICROONDAS CIERRE APROPIADAMENTE Y QUE NO TENGA DAÑOS EN:
• PUERTA (DOBLADA)
• BISAGRAS Y MANIJAS (ROTAS O SUELTAS)
• SELLOS DE LAS PUERT AS Y SU PE RF IC I ES S ELLADAS
• SU HORNO MICROONDAS DEBE SER REPARADO SOLO POR PERSONAL DE SERVICIO
DEBIDAMENTE CALIFICADO
MODO DE EMPLEO:
• COMO PROGRAMAR EL CICLO DE COCCION:
COLOQUE EL ENVASE CON LOS ALIMENTOS EN EL PLATO GIRATORIO Y CIERRE LA
PUERTA.
HASTA EL NIVEL APRO PIADO
CONTROL DE TIEMPO HASTA EL
NOTA:
APENAS EL CONTROL DE TIEMPO SEA PROGRAMADO EL HORNO EMPEZARA A COCINAR.
PARA PROGRAMAR TIEMPOS MENORES A DOS MINUTOS, GIRE EL SELECTOR PASADO LOS
DOS MINUTOS DESPUES GIRE EL SEL E CTOR AL TIEMPO DESEADO.
CUANDO EL TIEMPO DE COCCION HAYA TERMINADO, UNA CAMPANA SONARA Y EL HORNO
SE AP AGARA AUT O MAT I CAMENTE.
ATENCION:
GIRE EL SELECTOR DE TIEMPO HASTA LA MARCA DEL CERO CUANDO EL HORNO NO ESTE
EN USO O SI SACA LA COMIDA DEL HORNO ANTES QUE EL TIEMPO DE COCCION HAYA
Page 19
19
FINALIZADO. USTED PUEDE ABRIR LA PUERTA MIENTRAS EL HORNO E STE OPERANDO, YA
QUE EL MECHANISMO DE SEGURIDAD DE SU HORNO HARA QUE ESTE SE DETENGA.
LUZ INTERIOR:
APENAS EL CONTROL DE TIEMPO SEA PROGRAMADO EL HORNO LA LUZ INTERIOR SE
ALUMBRARA Y SE APAGARA AUTOMATICAMENTE CUANDO EL TIEMPO DE COCCION HAYA
TERMINADO
Page 20
20
CUIDADO Y MANTENIMIENTO
LIMPIEZA DE SU HORNO MICROONDAS
APAGUE Y DESCONECTE EL ENCHUFE DE PARED ANTES DE LIMPIAR SU HORNO.
MANTENGA EL INTERIOR DE SU HORNO MICROONDAS LIMPIO. LOS ALIMENTOS SALPICAN O
DERRAMAN PART IC UL AS Y LIQU ID O S QU E SE AD H IEREN A LAS PAREDES DEL HO R N O, ES
RECOMENDABLE LIMPIARLAS CON UN PAÑO HUMEDO. PUEDE USAR UN DETERGENTE MUY
SUAVE SI EL HORNO SE ENCUENTRA MUY SUCIO. NO RECOMENDAMOS EL USO DE
DETERGENTES O ABRASIVOS FUERTES.
USTED DEBE LIMPIAR LAS PARTES EXTERNAS DE SU HORNO MICROONDAS CON UN PAÑO
HUMEDO. PARA PREVENIR DAÑOS EN LAS PARTES INTERNAS DE SU HORNO, EL AGUA NO SE
DEBE FILTRAR DENTRO DE LAS REJILLAS DE VENTILACION.
NO PERMITA QUE EL PANEL DE CONTROL SE MOJE. LIMPIELO CON UN PAÑO SUAVE Y
HUMEDO. NO USE DETERGENTES, ABRASIVOS O LIMPIADORES EN SPRAY.
CUANDO LIMPIE EL PANEL DE CONTROL DEJE LA PUERTA DEL HORNO ABIERTA PARA
PREVENIR QUE ESTE COMIENCE A FUNCIONAR ACCIDENTALMENTE.
SI SE ACUMULA VAPOR DE AGUA DENTRO O ALREDEDOR DE LA PUERTA DEL HORNO
MICROONDAS LIMPIELA CON UN PAÑO SUAVE. ESTO PUEDE OCURRIR CUANDO SU HORNO
MICROONDAS ESTA FUNCIONANDO DENTRO DE UN AMBIENTE HUMEDO, Y DE NINGUNA
MANERA SE DEBE DE INTERPRETAR COMO UN MAL FUNCIONAMIENTO DEL HORNO.
OCASIONALMENTE ES NECESARIO RETIRAR EL PLATO GIRATORIO DE VIDRIO PARA LAVARLO.
HAGALO CON AGUA TIBIA JABONOSA O EN LA LAVADORA DE PLATOS.
EL ARO GIRATORIO Y EL PISO INTERIOR DEL HORNO DEBEN SER LIMPIADOS REGULARMENTE
PARA EVITAR EL RUIDO EX C E SIVO . SIM P LE MENTE LIMPIE LA SUPERFICIE INFERIOR DE SU
HORNO CON UN PAÑO, DETERGENTE SUAVE, UN POCO DE AGUA O CON LIQUIDO PARA
LIMPIAR VIDRIOS Y LUEGO SEQUELO. EL ARO GIRATORIO PUEDE SER LAVADO EN AGUA
LIGERAMENTE JABONOSA O EN LA LAVADORA DE PLATOS.
DEBIDO AL USO REPETIDO DEL HORNO, ESTE ACUMULA VAPORES DE COCINA, ESTO NO
AFECTA EL PISO INTERIOR NI LAS RUEDAS DEL ARO GIRATORIO. CUANDO RETIRE EL ARO
GIRATORIO DE LA CAVIDAD INFERIOR PARA LIMPIARLO, ASEGURESE DE COLOCARLA
NUEVAMENTE EN L A POSI CIO N AP RO PI ADA.
SI SU HORNO MICROONDAS TIENE MAL OLOR, COMBINE EN UNA TAZA DE AGUA EL JUGO Y
LA CASCARA DE UN LIMON. PONGA EN MARCHA SU HORNO MICROONDAS POR 5 MINUTOS.
FROTE Y SEQUE COMPLETAMENTE TODO SU HORNO MICROONDAS CON UN PAÑO SUAVE.
POR FAVOR VISITE A UN REPRESENTANTE AUTORIZADO PARA QUE EFECTUE EL REEMPLAZO
DEL BOMBILLO CUANDO SEA NECESARIO.
Page 21
21
-------------------------------------------------------(detach here)-----------------------------------------------------------------
Name
Model # Serial #
Address
Date Purchased Store / Dealer Name
City State Zip
E-mail Address
Area Code Phone Number
Occupation
Did You Purchase An Additional Warranty
As your Primary Residence, Do You:
Extended
Own
Rent
None
Your Age:
product:
Married Single
Price
Other: _____________ ____ __
Comments:
REGISTRATION INFORMATION
Thank you for purchasing this fine Avanti product. Please fill out this form and return it to the following
address within 100 days from the date of purchase and receive these important benefits:
Avanti Products, A Division of The Mackle C o ., Inc.
P.O.Box 520604 – Miami, Florida 33152
Protect your product:
We will keep the model number and date of purchase of your new Avanti product on file to help
you refer to this information in the event of an insurance claim such as fire or theft.
Promote better products:
We value your input. Your responses will help us deve lop produc ts desig ned to bes t m eet your
future needs.
Avanti Registration Card
Reason for Choosing This Avanti Product:
Please indicate the most important factors
That influenced your decision to purchase this
Product Features
Avanti Reputation
Product Quality
Salesperson Recommendation
Other: _____________ ____ __
Friend / Relative Recommendation
Warranty
under 18 18-25 26-30
31-35 36-50 over 50
Marital Status:
Is This Product Used In The:
Home Business
How Did You Learn About This Product:
Advertising
In-Store Demo
Personal Demo
Page 22
22
Page 23
23
Ver: 2.0 – 03082011
PRINTED IN CHINA
Loading...
