Avanti MO1450TW Instruction Manual

Model / Modelo / Modèle: MO1450TW

MICROWAVE OVEN

MANUEL D’INSTRUCTIONS

INSTRUCTION MANUAL

MANUAL DE INSTRUCCIONES

BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.

Avanti has a policy of continuous improvement on its products and reserves the right to change materials and specifications without notice.

Avanti Products LLC

P.O. Box 520604 - Miami, Florida 33152

www.avantiproducts.com

TABLE OF CONTENTS

Help Us Help You

Parts and Features

Important Safety Instructions

Installation Instructions

Before Using Your Microwave Oven

Installation of Your Microwave Oven

Safety Precautions

6 – 7

Electrical Connection

Operating Your Microwave Oven

Cooking Techniques

Care and Maintenance

Cleaning Your Microwave Oven

Problems with Your Microwave Oven?

Troubleshooting Guide

Service for Your Microwave Oven

Avanti Microwave Oven Warranty

Instrucciones en Español

18 – 30

Registration Information and Registration Card

Control Panel 9

Operation Procedure 10 – 14

HELP US HELP YOU…

Read this guide carefully.

It is intended to help you operate and maintain your new microwave oven properly.

Keep it handy to answer your questions. If you don't understand something or you need more assistance, please call:

Avanti Customer Service 800-220-5570

Keep proof of original purchase date (such as your sales slip) with this guide to establish the warranty period.

IF YOU NEED SERVICE

We're proud of our service and want you to be pleased. If for some reason you are not happy with the service you recei ve, her e are s ome s teps to follow for further assistance. FIRST, contact the people who serviced your microwave oven. Explain why you are not pleased. In most cases, this will solve the problem.

Write down the model and serial numbers.

You'll find them on a label located on the rear wall of the microwave oven.

Please write these numbers here:

____________________________________ Date of Purchase

____________________________________ Model Number

____________________________________ Serial Number

Use these numbers in any correspondence or service calls concerning your microwave oven.

If you received a damaged microwave oven, immediately contact the dealer (or builder) that sold you the microwave oven.

Save time and money. Before you call for service, check the Troubleshooting Guide. It lists causes of minor operating problems that you can correct yourself.

NEXT, if you are still not pleased, write all the details, including your telephone number, and send it to:

Customer Servic e

Avanti Products 10880 NW 30 Street Miami, FL 33172 USA

Parts and Features

MO1450TW

Door Safety Lock System

Oven Window

Roller Ring

Turntable Shaft

Door Release Button

Control Panel

Oven Air Vent

Glass Tray

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances basic safety precautions should be followed, including the following:



To red uce the r isk of burns, electrical shock, fire,

follow these basic precautions:

• Read all instructions before using the appliance.

-SAVE THESE INSTRUCTIONS-

WARNING

• Read and follow the specific “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO

EXCESSIVE MICROWAVE ENERGY” found on page 6.

• This appliance must be grounded. Connect only to properly grounded outlet.

SEE GROUNDING INSTRUCTIONS found on page 8.

• Install or locate the appliance only in accordance with the provided installation instructions.

• When cleaning surfaces of door and oven that comes together on the closing door, use only mild,

nonabrasive soaps, or detergents applied with a sponge or soft cloth.

• Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without

appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID.

• Some products such as whole eggs and sealed containers-(for example, closed glass jars) may

explode and should not be heated in microwave oven.

• Use this microwave oven only for its intended use as described in this manual.

• Do not use corrosive chemicals or vapors in this appliance. This type of oven is specifically

designed to heat, cook, or dry food. It is not designed for industrial or laboratory use.

• As with any appliance, close supervisi on is necess ary when used by children.

• Do not operate this microwave oven if it has a damaged cord or plug, if it is not working properly, or

if it has been damaged or dropped.

• To reduce the risk of fire in the oven cavity:

• Do not overcook food. Carefully attend microwave oven if paper, plastic, or combustible

materials are placed inside the oven to facilitate cooking.

• Remove wire twist-ties from bags before placing bag in oven.

• If materials inside the oven should ignite, keep oven door closed, turn oven off at the wall

switch, or shut off power at the fuse or circuit breaker panel.

• Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils, or

food in the cavity when not in use.

• Only qualified service personnel should service this appliance. Contact the nearest authorized

service facility for examination, repair or adjustment.

• Do not cover or block any openings on this appliance.

• Do not use this microwave oven to heat corrosive chemicals (for example, sulfides and chlorides).

Vapors from such corrosive chemicals may interact with the contact and springs of the safety interlock switches thereby rendering them inoperable.

• Do not immerse cord or plug in water.

• Keep cord away from heated surfaces.

• Do not let cord hang over edge of table or counter.

• Never clean appliance parts with flammable fluids. The fumes can create a fire hazard or

explosion.

• Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of this or any

other appliance. The fumes can create a fire hazard or explosion.

• Do not store this appliance outdoors. Do not use this product near water – for example near a

kitchen sink, in a wet basement, near a swimming pool, or similar locations

injury to persons, or exposure to excessive microwave energy when using your appliance,

INSTALLATION INSTRUCTIONS

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE

TO EXCESSIVE MICROWAVE ENERGY

(a) Do not attem pt to operate this oven with the door-op en since open-door operation can resu lt in

The oven should not be adjusted or repaired by anyone except properly qualified service personnel.

 BEFORE USING YOUR MICROWAVE OVEN

• Remove the exterior and interior packing.

• Check to be sure you have all of the following parts:

• Glass Tray

• Turntable Roller Assembly (Roller or Roller Ring)

• Instruction Manual

• Inspect the oven after unpacking for any visual damage such as:

• Misaligned Door

• Damaged Door

• Dents or Holes in Door Window and Screen

• Dents in Cavity

If any of the above is visible, DO NOT use the oven.

 INSTALLATION OF YOUR MICROWAVE OVEN

• When positioning the microwave oven, it should be set on a flat, steady surface.

• Do not block air vents. If they are blocked during operation, the oven may overheat and

eventually cause oven failure.

• Poor television reception and radio interference may result if the oven is located close to a TV, radio, antenna, or antenna wire. Position the oven as far from them as possible.

• Clean the interior surface with lukewarm water using a soft cloth.

• Keep the oven away from hot air, steam or splashing liquids when choosing a place to locate it,

otherwise, the unit’s operation may be adversely affected, causing it to break down.

• Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption.

• Plug the appliance into an exclusive properly installed-grounded wall outlet. Do not under any circumstances cut or remove the third (ground) prong from the power cord. Any questions concerning power and or grounding should be directed toward a certified electrician or an authorized Avanti Products s ervice cen ter .

• DO NOT place anything on the top of the oven.

• Keep the oven at least 5 inches away from both sidewalls and away from rear wall to ensure the

proper ventilation.

• DO NOT remove the turn-table drive shaft.

 SAFETY PRECAUTIONS

harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

(b) Do not place any object bet ween the oven f ront fac e and the door or a llow soil or cleaner r esidue

to accumulate on sealing surfaces.

properly and that there is n o dam age to the : (1) Door ( bent ), ( 2) Hi nges and l atc hes ( brok en or loosened ), (3) Door seals and sealing surfaces.

(d)

General Use

Utensils

Food

• DO NOT attempt to tamper with or make any adjustments or repairs to door, control panel or any other part of the oven. Do NOT remove outer panel from oven. Repairs should only be done by qualified service personnel.

• DO NOT operate the oven empty. The microwave energy will reflect continuously throughout the oven if no food or water is present to absorb energy.

• If a fire occurs in the oven, touch the START/STOP pad and LEAVE THE DOOR CLOSED. Disconnect the power cord, or shut off power at the fuse or circuit breaker panel.

• DO NOT attempt to dry clothes, newspapers or other materials in oven. They may catch on fire.

• DO NOT use recycled paper products, as they may contain impurities, which may cause sparks

and/or fires when used.

• DO NOT hit or strike control panel. Damage to controls may occur.

• METAL CONTAINERS or dishes with metallic rims should not be used. Arcing may occur.

• METAL TWIST-TIES may not be used in the microwave oven.

• DO NOT use SEALED JARS or NARROW NECK bottles for cooking or reheating. They may

shatter.

• DO NOT use CONVENTIONAL THERMOMETERS in the microwave oven. They may cause arcing. Use only those labeled “Microwave Safe” and follow all directions. Check the food in several places.

• Remove PLASTIC STORE WRAPS before cooking or defrosting in the oven. RECOMMENDED

• Microwave browning dish – Use to brown exterior of small items such as steaks, chops, or pancakes. Follow the directions provided with your browning dish.

• Microwaveable plastic wrap – Use to retain steam. Leave a small opening for some steam to escape and avoid placing it directly on the food.

• Paper towels and napkins – Use for short-term heating and covering; these absorb excess moisture and prevent splattering. Do not use recycled paper towels, which may contain metal and could ignite.

• Never use your microwave oven for HOME CANNING. The oven is not designed to permit proper canning. Improperly canned food may spoil and be dangerous to consume.

• COOKING TIMES are approximate. Factors that may affect cooking are starting temperature, altitude, volume, size and shape of food and utensils used. As you become familiar with the oven, you will be able to adjust for these factors.

• It is better to UNDERCOOK RATHER THAN OVERCOOK foods. If food is undercooked, it can always be returned to the oven for further cooking. If food is overcooked, nothing can be done. Always start with minimum cooking times.

• SMALL QUANTITIES of food or foods with LOW MOISTURE content can burn, dry out or catch on fire if cooked too long.

• DO NOT boil eggs in their shell. Pressure may build up and the eggs will explode.

• Potatoes, apples, egg yolks, whole ac orn squash and sausage are examples of food with

NONPOROUS SKINS. These must be pierced before cooking to prevent bursting.

• POPCORN must be popped in a microwave corn popper. Microwave popped corn produces a lower yield than conventional popping. DO NOT use oven for popcorn unless popped in a microwave approved popcorn utensil or unless it’s commercially packaged and recommended especially for microwave ovens. DO NOT use oil unless specified by the manufacturer.

• DO NOT attempt to deep fat fry in your oven.

• HEATED LIQUIDS can ERUPT if not mixed with air. DO NOT heat liquids in your microwave

oven without first stirring.

 ELECTRICAL CONNECTION

Warning

exists as to whether the appliance is properly grounded.

GROUNDING INSTRUCTIO NS

This appliance m us t be gr o unde d. I n t he event of an electr ica l s h ort c ir cuit, gr o u ndi ng reduces the ris k of electrical shock by providing an escape wire for the electric curr ent. This appliance is equipped with a cord having a grounding wire with a grounding plug. T he plug must be inserted into an outlet that is properly installed and grounded .

Improper use of the grounded plug can result in the risk of electrical shock. Consult a qualified electrician or service person if the grounding instructions are not completely understood, or if doubt

The power cord of th is appliance is equipped with a three-prong plug which m ates with standard three prong wall outlets to minimize the possibility of electrical shock.

Do not under any circumstances cut or remove the third ground prong from the power cord supplied. Do not use the extension cord. If the power supply cord is too short, have a qualified electrician or

serviceman to install an outlet near the appliance. This appliance requires a standard 115/120 Volts A.C. ~/60Hz electrical outlet with three-prong ground.

The cord should be secured be hind the appl iance and not left expos ed or dangl ing to preven t accidental injury.

OPERATING YOUR MICROWAVE OVEN

Although your oven is provided with safety features, it is important to observe the following:

• It is important not to defeat or tamper with safety interlocks.

• Do not place any object between the oven front face and the door or allow residue to accumulate on

sealing surfaces. Wipe the sealing area frequently with a mild detergent, rinse and wipe dry. Never use abrasive powders or pads.

• When opened, the door must not be subjected to strain, for example, a child hanging on an opened door or any load which could cause the oven to fall forward and cause injury and damage the door. Do not operate the oven if it is damaged, until it has been repaired by a qualified service person. It is particularly important that the oven closes properly and that there is no damage to the:

• Door (bent)

• Hinges and latches (broken or loosened)

• Door seals and sealing surfaces

• The oven should not be adjusted or repaired by anyone except properly qualified service personnel.

CONTROL PANEL

UNIT FEATURES

Popcorn

Baked Potato

Pizza

Beverage

Frozen Dinner

Reheat

Fresh Vegetable

Frozen Vegetable

Soup

Cook By Weight

Defrost By Weight

Timed Defrost

Express

Clock: 12 Hour

Kitchen Timer

UNIT SPECIFICATIONS

Power

Consumption:

120V ~ 60Hz,

1450W

Output

(Watts):

Operation

Frequency:

Unit

(HxWxD):

Oven Cavit y

(HxWxD):

Oven

Capacity:

Cooking

Uniformity:

Net Weight:

Approx. 40 Lbs

Pre-Programmed

Cooking Modes

1000W

Dimensions

2450MHz

12 ¼” x 21 ¾”

x 17 ¾”

Dimensions

9 7/16“ x 14 13/

/8“

“ x

1.4 cu. Ft. Turntable

CONTROL PANEL FEATURE

DESCRIPTION

DISPLAY

Electronic display shows Cooking Time, Cooking Power, Time Remaining in Cooking Cycle, and the Present Time.

POPCORN BAKED POTATO PIZZA

level or time.

POWER

Use to set power level

Touch to set the weight of the food to be cooked. The oven automatically sets the cooking time and power level.

Touch to set the weight of the food to be defrosted. The oven automatically sets the defrosting time and power level.

Touch to set defrosting time. The oven automatically divides the cycling on and off.

You can use the T IMER f unc tion i ndepen dentl y, even while a cook ing program is going on in the oven.

NUMBER PADS (0-9)

Touch to set times or amounts.

CLOCK

Touch to set the clock.

Stops the cooking cycle and clears all previous settings if touched before cooking starts.

Touch to start the cooking cycle press again to add c ooking time in one (1) minute intervals.

One touch option to se t the c ooking c ycle on full p ower in inter vals of pressing the EXPRESS button.

PRE-PROGRAMMED

COOKING MODES

COOK BY WEIGHT

DEFROST BY WEIGHT

SPEED DEFROST

TIMER

STOP / RESET

START / MINUTE PLUS

EXPRESS

 OPERATION PROCEDURE:

• Plug the power supply cord into a standard 3-pronged 15 Amps, 120Volts A.C.~/60Hz.

• After placing the food in a suitable contai n er , open the oven door and put it on the glass tray.

The glass tray and roller guide must always be in place during cooking.

• Shut the door. Make sure that it is firmly closed.

• The oven door can be opened at any time during operation by pulling on the door handle.

• The oven will automatically shut off. To restart the oven, close the door and then touch

START/STOP.

• Each time a pad is touched, a BEEP will sound to acknowledge the touch. One of the function pads must be touched before the number pads. Two BEEPS indicates the oven does not accept the entry, check and try again.

• The oven automatically cooks on high power and defrosts on low power.

• When the oven is first plugged in the display will show a flashing “ : ”, if you prefer not to have the

clock displayed, touch reset.

• When the START/STOP pad is touched during the oven operation, the oven stops cooking. If the oven door is opened during the oven operation, all information is retained.

• If the START/STOP pad is touched and the oven does not operate, check the area between the door and door seal for obstructions and make sure the door is closed securely. The oven will not start cooking until the door is completely closed and the program has been set.

 SPECIAL OVEN FEATURES

SPEED DEFROST: Used to defrost frozen foods by time.

This cycle starts at medium – high power, then automatically reduces to medium – low and then to low as the food thaws. DEFROST indicator light and cook indicator light will both come on during the defrost cycle.

TIME R: Use for timing things without oven function. A long beep will sound at the end of the elaps ed time.

BEVERAGE FROZEN DINNER REHEAT

Allow you to reheat or cook food automaticall y without enteri ng power

defrosting time into peri ods of alternating defros t and stand times by

30 seconds. You can add additional time in 30 second interv als by

SETTING THE CLOCK

CONTINUE TO SHOW UNTIL THE UNIT IS

SETTING THE OVEN TIMER

AUTO TIMER: After a DEFROST or COOK PROGRAM has completed, the oven will automatically

continue to sound four beeps every two minutes until the oven door is opened or the RESET pad is touched.

CHILD PROOF LOCK: Use to prevent unsupervised operation of the oven by children. The word LOCK will be shown in the display and the oven cannot be operated while the CHILD PROOF LOCK is set.

SETTING CHILD LOCK: To set, press and hold RESET for 3 seconds. LOCK is indicated on the display. To cancel, press and hold RESET for 3 seconds. LOCK indication disappears.

TOUCH PAD: Use to set cooking time. Allows you to set up to 99 minutes and 99 seconds RESET: Touch to cancel the selected power level, cook or defrost times previously programmed. The

time of day clock is not cancelled. START/STO P: Touch to start the defros t or cook programs . The cook indicat or light and the oven l ight

will come on and the cooling fan will operate.

NOTE: END OF OPERATION- Display will show “END”.

• Four beeps will sound, th e c ook indicator light will go o ut and wi ll sho w “ END” on displ a y win do w unt il the door is opened and the tim e of day will r eturn to t he displa y windo w. The ove n light and c ooking fan will turn off.

• The oven will autom atically continue to sound four beeps every two minutes until the ove n door is opened or the RESET pad is touched.

NOTE: TO INTERRUPT OPERATION –Open the oven door.

• The oven immediately stops.

• If no further cooking is required, touch the RESET pad.

• To continue cooking, close the oven door and touch the START/STOP pad. The oven will restart.

HOW TO SET THE OVEN CONTROLS

AUDIBLE SIGNALS

DURING OVEN SETTINGS

1. Touch CLOCK pad. This is a 12 hour clock.

2. Use the number pads to enter the correct time.

If you selected 12 hour clock system, the digital clock allows you to set from 1:00 to 12:59. You must touch at least three numbers to set the clock (one for hour and two for minutes).

3. Touch CLOCK pad again.

NOTE: When the oven is first plugged in or when power resumes after a power interruption, t he display will show “ENTER CLOCK TIME”. If you prefer to not have the clock displayed, touch the RESET button. You can check the clock time while cooking is in progress by touching the CLOCK pad.

NOTE: ONCE THE TIME HAS BEEN SET IT WILL

ONE SIGNAL: Oven accepts the entry. TWO SIGNALS: Oven does not accept the entry, check and try again.

1. Touch TIMER.

2. Enter the amount of time by touching the

number pads. Digit time is in minutes and seconds and set left to right. Set one digit (a 5 for 5 seconds) or up to four digits (2405 for 24 minutes, 5 seconds).

3. Touch the START / STOP button.

NOTE: Time countdown can be seen in display for 3 seconds before clock or cooking time is returned to display. Touch TIMER and then touch STOP / RESET to cancel TIMER during timing process.

UNPLUGGED OR POWER LOST.

SETTING A COOKING PROGRAM

A. One-stage Cooking

Number pad

Cooking power

90%

80%

70%

60%

50%

40%

30%

20%

10%

B. Multi-stage Cooking

sound, signaling the beginning of

stage 2. After the total time (selected cooking

SPEED DEFROST

COOK BY WEIGHT

ne digit code by touching the

CODE

TYPE

MAX WEIGHT

Beef

5 lb. 16 oz.

Mutton

5 lb. 16 oz.

Pork

5 lb. 4 oz.

DEFROST BY WEIGHT

Weight must be in pounds and ounces.

1. Use the number pads to set a cooking time.

You can set a cooking time from one second to 99 minutes and 99 seconds.

2. If you want to set a power level other than

100% power, touch POWER, then use the number pads to enter the power level. You can set the power level from 1 to 9.

Use single digits to set a cooking power level:

3. Touch START / STOP to start cooking.

For added convenience your oven offers the ability to operate in a “Multi-Stage” cooking cycle. Each cycle or stage can be set with a separate cooking time and or power level.

a) To set the oven in Multi-Stage cooking

model, simply set the time and power level of the first stage (as described in Section One-Stage Cooking to the left).

b) To set the second cooking stage, press the

COOK key (“MEM” will appear in the display window).

c) Select the desired cooking time and power

level for the second stage.

d) Press “START / STOP” to begin the

cooking process.

NOTE:

After cooking stage 1 has elapsed, you will hear

one “beep” times for both stages) has elapsed, 4 “beeps”

will sound and “END” will appear in the displa y window. Touch the “START / STOP or RESET” button or open the oven do or to clear or end th e cooking program bef ore sta rting an other cook ing function.

1. Touch TIME DEFROST.

2. Enter desired defrosting time by touching

correct number pads. Digital timer sets minutes and seconds from left to right so a single digit can be set (5 for 5 seconds ) or up to 4 digits (2405 for 24 minutes 5 seconds).

3. Touch START / STOP.

NOTE: After time has elapsed four signals sound and END appears in display. Touch STOP/RESET pad or open door to clear END before starting another cooking function. During defrosting program, the system will pause and sound beeps to remind user to turn food over, and then press START / STOP to resume the defrosting.

5. Touch DEFROST BY WEIGHT pad.

6. Enter weight.

7. Touch START / STOP pad.

Note:

1. Touch COOK BY WEIGHT.

2. Enter the o

correct number 1~3 (shown below) pad .

3. Enter weight.

4. Touch START / STOP pad.

Cook By Weight Code Description

Note: Weight must be in pounds and ounces. For weights less than 10 ounces you must precede the number with a 0. . If label gives weight in pounds only, change the fraction of a pound to ounces using the following chart (See page 14).

Ounce weights less than 10 must be preceded by a

0. If label gives weight in pounds only, change the

chart (See page 14).

The QUICK COOK settings allow you to cook or reheat food automatically without entering power level or

food. Simply touch pad once, and ENTER AMOUNT

Bag Size

Cooking Time

1.2 oz

1 min. 40 sec.

Enter the cook time.

1 potato

3 min. 20 sec.

2 potatoes

5 min. 30 sec.

3 potatoes

7 min. 40 sec.

4 potatoes

9 min. 50 sec.

3. Touch START / STOP.

1 potato

5 min. 00 sec.

For best results we recommend that you follow on the popcorn packaging.

IMPORTANT INFORMATION ABOUT THE MICROWAVE POPCORN FEATURE

or unless you are using popcorn specifically labeled for use in microwave ovens.

fraction of a pound to ounces using the following

QUICK COOK (PRE-PROGRAMMED) SETTINGS

time. For smaller portions, simply touch the applicable pad and start. For larger portions, push the pad twice. FROZEN DINNER, BAKED POTATO and BEVERAGE allow you to cook multiple amounts of the same

• In order for microwave popcorn to “POP” evenly and to avoid burning, the bag must be able to rotate freely inside the oven while cooking.

• Some brands of microwave popcorn bags are larger than others and these larger bags may get stuck inside the oven in one position even though the platter is turning properly. This will result in uneven cooking or burning of the popcorn.

• To avoid this, please watch the bag until popping is completed. If the bag gets stuck and does not rotate, open the door, reposition the bag and restart the oven.

** Caution ** Use an oven mitt or pot holder when moving the bag, as the contents can be very hot.

** The POPCORN touch button on this microwave is designed for use with three diff er ent si zes of popcorn bags. See instructions for proper use.

For best results, we recommend that you follow all instructions and cooking times as indicated on the packaging supplied with your popcorn. ** DO NOT pop popcorn in your microwave oven unless in a special microwave popcorn accessory

POPCORN

1. Touch POPCORN.

2. Press the POPCORN button once for the 1.2

oz bag. For larger bags, press the POPCORN button again and enter the appropriate amount of time as indicated on the package.

BAKED POTATO

For 4 to 6 oz. potatoes:

1. Touch BAKED POTATO once.

2. Enter number of potatoes by touching number

pads from 1 to 4. Cooking times for smallmedium potatoes are as follows:

3. Touch START / STOP.

all instructions and cooking times as indicated

PIZZA

Reheating a slice (or two thin ones) of pizza:

1. Touch PIZZA once.

2. CODE and 1:30 (1 minute and 30 sec.)

appears.

3. Touch START / STOP.

For the large 8 to 10 oz. potatoes:

1. Touch BAKED POTATO twice.

2. Enter number of potatoes by touching number

pads from 1 to 4. Cooking times for large potatoes are as follows:

Heating a whole frozen pizza:

1. Touch PIZZA twice.

2 potatoes

8 min. 20 sec.

3 potatoes

11 min. 40 sec.

4 potatoes

15 min. 00 sec.

1 cup.

1 min. 10 sec

2 cups.

2 min. 10 sec

3 cups.

3 min. 10 sec

4 cups.

4 min. 10 sec

1 mug

1 min. 40 sec.

2 mugs

2 min. 50 sec.

3 mugs

4 min. 00 sec.

4 mugs

5 min. 10 sec.

1 entree

5 min. 15 sec.

2 entrees

7 min. 30 sec.

1 entree

6 min. 00 sec.

2 entrees

11 min. 00 sec.

Note: place in dish or casserole slightly larger

Fractions of a

pound

Less than .03

.03 to .09

.10 to .15

.16 to .21

.22 to .27

.28 to .34

.35 to .40

.41 to .46

.47 to .53

.54 to 59

.60 to .65

.66 to .71

.72 to .78

.79 to .84

.85 to .90

.91 to .97

above .97

go to next even

Maximum weight for defrosting is 6 lbs.

2. CODE and 2:30 (2 minutes and 30 seconds.)

appears.

3. Touch START / STOP.

BEVERAGE

For 5 to 7 oz. coffee cups:

1. Touch BEVERAGE once.

2. Enter number of cups by touching number

pads from 1 to 4. Cooking times are as follows:

3. Touch START / STOP.

For the larger 9 to 11 oz. coffee mugs:

1. Touch BEVERAGE twice.

2. Enter number of mugs by touching number

pads from 1 to 4. Cooking times are as follows:

3. Touch START / STOP.

REHEAT

1. Touch REHEAT and

2. CODE and 3:00 (3 minutes.00 sec) appears.

3. Touch START / STOP.

FROZEN DINNER

For one or two small (7-9 oz.) frozen dinners:

1. Touch FROZEN DINNER once.

2. For 1 entree, touch the number pad “1” and

touch START/STOP. For 2 entrees, touch the number pad “2”. Cooking times for small-size entrees are as follows:

3. Touch START / STOP pad.

Microwaving one large (10-12 oz.) frozen dinner :

1. Touch FROZEN DINNER twice.

2. For 1 entree, just touch START/STOP. For 2

entrees, touch the number pad “2”. Cooking times for larger entrees are as follows:

3. Touch START / STOP.

Converting Fractions of a Pound to Ounces

Ounces

than the amount indicated. Continue to heat with variable power and time if at the end of sensor reheat the food is not sufficiently hot.

NOTE:

This setting lets you reheat a dinner plate of chilled leftovers with good results.

Turn food over when oven signals twice. Touch

START / STOP to resume defrosting.

After total defrosting time, 4 signals sound and

END appears in display. Touch STOP / RESET or

open oven door to clear END before starting

another cooking function.

 COOKING TECHNIQUES

Your microwave makes cooking easier than conventional cooking, provided you keep these considerations in mind.

Stirring

Stir foods such as casseroles and vegetables while cooking to distribute heat evenly. Food at the outside of the dish absorbs more energy and heats more quickly, so stir from the outside to the center. The oven will turn off when you open the door to stir your food.

Arrangement

Arrange unevenly shaped foods, such as chicken pieces or chops, with the thicker, meatier parts toward the outside of the turntable where they receive more microwave energy. To prevent overcooking, place delicate areas, such as asparagus tips, toward the center of the turntable.

Turning

Turn foods over midway through cooking to expose all parts to microwave energy. This is especially important with large foods such as roasts.

Standing

Foods cooked in the microwave build up internal heat and continue to cook for a few minutes after heating stops. Let foods stand to complete cooking, especially foods such as cakes and whole vegetables. Roasts need this time to complete cooking in the center without overcooking the outer areas. All liquids, such as soup or hot chocolate, should be shaken or stirred when cooking is complete. Let liquids stand a moment before serving. When heating baby food, stir well at removal and test the temperature before serving.

Adding Moisture

Microwave energy is attracted to water molecules. Food that is uneven in moisture content should be covered or allowed to stand so that the heat disperses evenly. Add a small amount of water to dry food to help them cook.

CARE AND MAINTENANCE

 CLEANING YOUR APPLIANCE

• Turn the oven off and remove the power plug from the wall socket before cleaning.

• Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe

with a damp cloth. Mild detergent may be used if the oven gets very dirty. The use of harsh detergent or abrasives is not recommended.

• The outside oven surfaces should be cleaned with a damp cloth. To prevent damage to the operating parts inside the oven, water should not be allowed to seep into the ventilation openings.

• Do not allow the control panel to become wet. Clean with a soft, damp cloth. Do not use detergents, abrasives or spray-on cleaners on the control panel. When cleaning the control Panel, leave oven door open to prevent oven from accidentally turning on.

• If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may occur when the microwave oven is operated under high humidity conditions and in no way indicates malfunction of the unit.

• It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water or in a dishwasher.

• The roller ring and oven cavity floor should be cleaned regularly to avoid excessive noise. Simply wipe the bottom surface of the oven with mild detergent, water or window cleaner and dry. The roller ring may be washed in mild sudsy water or dishwasher. Cooking vapors collect during repeated use but in no way affect the bottom surface or roller ring wheels. When removing the roller ring from cavity floor for cleaning, be sure to replace it in the proper position.

• Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in a deep microwavable bowl. Microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth.

• When it becomes necessary to replace the oven light, please consult a dealer to have it replaced.

+ 35 hidden pages
